Parts List
Storage Bin
Models
B-250PF B-300SF
B-300PF B-500SF
B-500PF B-700SF
B-700PF B-800SF
B-800PF B-900SF
B-900PF BD-300SF
BD-300PF BD-500SF
BD-500PF
hoshizakiamerica.com
Number: 71213
Issued: 12-17-2002
Revised: 3-23-2017
CONTENTS
Auxiliary Codes ...................................................................................................................... 3
Note About Ordering Parts .................................................................................................... 6
A. Storage Bin ........................................................................................................................ 7
B. Accessories & Labels ...................................................................................................... 10
2
Auxiliary Codes
B-250PF
L-5 August 2001
M-5 February 2002
N-5 December 2002
P-5 December 2003
Q-5 December 2004
R-5 December 2005
S-5 January 2007
T-5 January 2008
U-5 January 2009
V-5 January 2010
A-5 January 2011
B-5 January 2012
C-5 January 2013
D-5 January 2014
E-5 January 2015
E-6 August 2015
F-5 January 2016
G-5 January 2014
B-300PF
L-5 July 2001
M-5 December 2001
N-5 December 2002
P-5 December 2003
Q-5 December 2004
R-5 December 2005
S-5 January 2007
T-5 January 2008
U-5 January 2009
V-5 January 2010
A-5 January 2011
B-5 January 2012
C-5 January 2013
D-5 January 2014
D-6 March 2014
E-5 January 2015
E-6 August 2015
F-5 January 2016
G-5 January 2017
BD-300PF
A-5 April 2011
D-5 April 2014
E-5 February 2015
E-6 October 2015
F-5 May 2016
G-5 January 2017
B-500PF
L-5 June 2001
M-5 December 2001
N-5 December 2002
P-5 December 2003
Q-5 December 2004
R-5 December 2005
S-5 January 2007
T-5 January 2008
U-5 January 2009
V-5 January 2010
A-5 January 2011
B-5 January 2012
C-5 January 2013
D-5 January 2014
E-5 January 2015
E-6 August 2015
F-5 January 2016
G-5 January 2017
BD-500PF
A-5 July 2011
B-5 April 2015
C-5 April 2013
D-5 January 2014
E-5 January 2015
E-6 September 2015
F-5 February 2016
G-5 January 2017
B-700PF
L-5 June 2001
M-5 December 2001
N-5 December 2002
P-5 December 2003
Q-5 December 2004
R-5 December 2005
S-5 January 2007
T-5 January 2008
U-5 January 2009
V-5 January 2010
A-5 January 2011
B-5 January 2012
C-5 January 2013
D-5 January 2014
E-5 January 2015
E-6 August 2015
F-5 January 2016
G-5 January 2017
B-800PF
L-5 June 2001
M-5 December 2001
N-5 December 2002
P-5 December 2003
Q-5 December 2004
R-5 December 2005
S-5 January 2007
T-5 January 2008
U-5 January 2009
V-5 January 2010
A-5 January 2011
B-5 January 2012
C-5 January 2013
D-5 January 2014
E-5 January 2015
E-6 August 2015
F-5 January 2016
G-5 January 2017
B-900PF
L-5 June 2001
M-5 December 2001
N-5 December 2002
P-5 January 2004
Q-5 December 2004
R-5 December 2005
S-5 January 2007
T-5 January 2008
U-5 January 2009
V-5 January 2010
A-5 January 2011
B-5 January 2012
C-5 January 2013
D-5 January 2014
E-5 January 2015
E-6 August 2015
F-5 January 2016
G-5 January 2017
3
Auxiliary Codes
Continued
B-300SF
L-5 June 2001
M-5 December 2001
N-5 December 2002
P-5 December 2003
Q-5 December 2004
R-5 December 2005
S-5 January 2007
T-5 January 2008
U-5 January 2009
V-5 February 2010
A-5 January 2011
B-5 January 2012
C-5 January 2013
D-5 January 2014
D-6 February 2014
E-5 January 2015
E-6 August 2015
F-5 January 2016
G-5 January 2017
BD-300SF
A-5 April 2011
D-5 April 2014
E-5 February 2015
E-6 October 2015
F-5 October 2016
G-5 February 2017
B-500SF
L-5 June 2001
M-5 December 2001
N-5 December 2002
P-5 December 2003
Q-5 December 2004
R-5 December 2005
S-5 January 2007
T-5 January 2008
U-5 January 2009
V-5 January 2010
A-5 January 2011
B-5 January 2012
C-5 January 2013
D-5 January 2014
E-5 January 2015
E-6 August 2015
F-5 January 2016
G-5 January 2017
BD-500SF
A-5 April 2011
B-5 March 2012
C-5 May 2013
D-5 February 2014
E-5 May 2015
E-6 August 2015
F-5 June 2016
G-5 March 2017
B-700SF
L-5 September 2001
M-5 December 2001
N-5 December 2002
P-5 December 2003
Q-5 December 2004
R-5 December 2005
S-5 January 2007
T-5 January 2008
U-5 January 2009
V-5 January 2010
A-5 January 2011
B-5 January 2012
C-5 January 2013
D-5 January 2014
E-5 January 2015
E-6 August 2015
F-5 January 2016
G-5 January 2017
B-800SF
L-5 September 2001
M-5 December 2001
N-5 December 2002
P-5 December 2003
Q-5 December 2004
R-5 December 2005
S-5 January 2007
T-5 January 2008
U-5 January 2009
V-5 January 2010
A-5 January 2011
B-5 January 2012
C-5 January 2013
D-5 January 2014
E-5 January 2015
E-6 August 2015
F-5 January 2016
G-5 January 2017
4
Auxiliary Codes
Continued
B-900SF
L-5 June 2001
M-5 December 2001
N-5 January 2003
P-5 December 2003
Q-5 December 2004
R-5 December 2005
S-5 January 2007
T-5 January 2008
U-5 January 2009
V-5 January 2010
A-5 January 2011
B-5 January 2012
C-5 January 2013
D-5 January 2014
E-5 January 2015
E-6 August 2015
F-5 January 2016
G-5 January 2017
5
Auxiliary Code Breakdown
The auxiliary code is the rst two characters in the serial number. The rst character
indicates the year. Years progress or regress in alphabetical order. The series runs from
"A" through "V" and the letters "I" and "O" are skipped. The second character indicates
signicant part changes within a year. Base is "5" and this number advances for each
change. In cases where there is a letter in parentheses, this designates the month. This is
the last character in the serial number. The series runs from "(A)" through "(M)" and the
letter "(I)" is skipped. This designation is only included when identifying a parts change
within an auxiliary code.
Note About Ordering Parts
Most assemblies cannot be ordered as complete units; parts in the assemblies generally
must be ordered separately.
6
A. Storage Bin
B-___PF, BD-___PF, B-___SF, BD-___SF
L-5 to G-5
9
8
7
6
6a
11
2
5
4a
4b
4
5b
5a
3a
3
3b
2
1
12
10
Model Shown: B-900PF
7
Title: A.Storage Bin Model: B-___PF, BD-___PF, B-___SF, BD-___SF
L-5
U-5
to
(D)
A-5
Index
No. Description
1 Bin Door (includes item 2) B-250PF
2 Bushing 4A2582-01 2 -
3 Right Hinge 3A0105G01 1 -
3a Hex Head Bolt 5×14, SS 7B02-0514 2 2 2 2
3b Washer 4A0198-01 2 2 2 2
4 Left Hinge 3A0106G01 1 -
4a Hex Head Bolt 5×14, SS 7B02-0514 2 2 2 2
4b Washer 4A0198-01 2 2 2 2
5 Baffle B-250PF
5a Thumbscrew B-250PF
5b Thumbscrew 434168G01 2 2 2 2
6 Front Frame B-250PF
6a Hex Head Tapping Screw 7B03I0834 2 2 2 2
Material or
Model Number Part Number
HS-2144 1 1 1 1
B-500PF/SF
BD-500PF/SF 1 1
B-300PF/SF HS-2143 1 1 1 1
BD-300PF/SF 1 1
B-700PF/SF HS-2140 1 1 1 1
B-800PF/SF HS-2141 1 1 1 1
B-900PF/SF HS-2142 1 1 1 1
4A3914-01 2 2 2
3A3725G01 1 1 1
3A3726G01 1 1 1
104322-01 1 1 1 1
B-500PF/SF
BD-500PF/SF 1 1
B-300PF/SF 104391-01 1 1 1 1
BD-300PF/SF 1 1
B-700PF/SF 104323-01 1 1 1 1
B-800PF/SF 105012-01 1 1 1 1
B-900PF/SF 104324-02 1 1 1 1
415949G12 2 2 2 2
B-300PF/SF
BD-300PF/SF
B-500PF/SF
BD-500PF/SF
B-700PF/SF 3 3 3 3
B-800PF/SF
B-900PF/SF
3A0420-01 1 1 1 1
B-500PF/SF
B-300PF/SF 3A8180-01 1
BD-300PF/SF 3A6594-01 1 1
BD-500PF/SF 3A6594-02 1 1
B-700PF/SF 3A0446-01 1 1 1 1
B-800PF/SF 3A0447-01 1 1 1 1
B-900PF/SF 3A0447-02 1 1 1 1
U-5
to
to
(C)
V-5
D-5
4 4 4 4
Required Number
D-6
to
G-5
8
Title: A.Storage Bin Model: B-___PF, BD-___PF, B-___SF, BD-___SF
L-5
U-5
to
(D)
A-5
Index
No. Description
7 Front Frame Cover B-250PF
8 Top Cover B-250PF
9 Right Bin Cap B-250PF
10 Left Bin Cap B-250PF
11 Back Bin Cap B-250PF
12 Drain Cap 322015-01 1 1 1 1
Material or
Model Number Part Number
324625-01 1 1 1 1
B-500PF/SF
B-300PF/SF 324617-01 1 1 1 1
B-700PF/SF 3A0155-01 1 1 1 1
B-800PF/SF 325510-01 1 1 1 1
B-900PF/SF 324619-01 1 1 1 1
3A0157-01 1 1 1 1
B-500PF/SF
B-300PF/SF 3A0156-01 1 1 1 -
3A8189-01 1
BD-300PF/SF 3A6538-01 1 1
BD-500PF/SF 3A6537-01 1 1
B-700PF/SF 3A0158-01 1 1 1 1
B-800PF/SF 2A0106-01 1 1 1 1
B-900PF/SF 2A0107-01 1 1 1 1
3A7473-01 1
B-300PF/SF
B-500PF/SF
B-700PF/SF
B-800PF/SF
B-900PF/SF
3A7474-01 1
B-300PF/SF
B-500PF/SF
B-700PF/SF
B-800PF/SF
B-900PF/SF
3A7475-02 1
B-500PF/SF
B-300PF/SF 3A7475-01 1
B-700PF/SF 3A7475-03 1
B-800PF/SF 3A7475-05 1
B-900PF/SF 3A7475-04 1
U-5
(C)
to
V-5
to
D-5
Required Number
D-6
to
G-5
9
B. Accessories & Labels
B-___PF, BD-___PF, B-___SF, BD-___SF
L-5 to G-5
1
2
B-250PF
3
B-300PF/SF
BD-300PF/SF
Title: B. Accessories & Labels Model: B-___PF, BD-___PF, B-___SF, BD-___SF
Index
No. Description
1 Scoop 4A2246-01 1
2 Leg B-300PF/SF
3 Leg Protector B-300PF/SF
Material or
Model Number Part Number
4A2526-01 4
BD-300PF/SF
B-250PF
B-500PF/SF
BD-500PF/SF
B-700PF/SF
B-800PF/SF
B-900PF/SF
BD-300PF/SF
4A2525-01
3A0134-01 4
B-500PF/SF
BD-500PF/SF
B-700PF/SF
B-800PF/SF
B-900PF/SF
L-5
to
G-5
4
Required Number
10
