Hosa Technology Audio Digital Solutions User Manual

Audio
Video
Digital
Solutions
RETAIL CATALOGHOSA TECHNOLOGY, INC.
2007 Retail Catalog
Hosa Technology, Inc. 2007 Product Catalog
www.hosatech.com
Table of Contents
Where to Buy
1) Local Retailer
We encourage you to buy Hosa products from your local retailer. You can visit our website (www.hosatech.com) to find a retailer near you. Additionally, most retailers are happy to special order items that they don’t normally stock.
2) Internet
There are dozens of retailers on the internet. Some are listed on our website. If you know the model num­ber, try entering it into a search engine, like Google or Yahoo.
3) Order Direct
If you need a Hosa item, and can’t locate it locally or through the web, you can order it directly from Hosa.
Call Toll-Free (877) 736-9270.
Shipping: There will be a flat $5.00 ship-
ping charge for orders under $20.00. Orders over $20.00 will receive free shipping. This applies to UPS ground only. Expedited and other shipping options are available, but will be charged accordingly. Some restictions apply, please call for details.
Contact Information
Hosa Technology, Inc. 6650 Caballero Blvd. Buena Park CA 90620 (714) 736-9270 voice (714) 522-4540 facsimile
Prices subject to change without notice. Not responsible for pictorial or typographical inaccuracies.
Website: www.hosatech.com Email: sales@hosatech.com Business Hours: Monday – Friday 8 a.m. – 5 p.m. Pacific Time
LIMITED LIFETIME WARRANTY
All Hosa cables and adaptors, including hard-wired stage snakes with stage boxes, purchased in the USA are warranted by Hosa Technology, Inc. to be free of defects in material and workmanship for the lifetime of the original purchaser. ALL OTHER Hosa products are warranted for one year. Call us or visit our website for further details, limitations and exclusions.
©2007 HOSA TECHNOLOGY, INC. Photos, Drawings And/Or Text May Not Be Reproduced Photographically, Electronically, Or By Any Other Means Without The Express, Written Consent Of Hosa Technology, Inc. “Sony”, “Tascam & DA88”, “Alesis & Adat”, “Fender and Fender Telecaster,” “Fostex”, “Yamaha”, “Akai”, “EDAC”, “Mackie”, “Amphenol”, “Switchcraft” And “Neutrik” Are All Trademarks Of Their Respective Companies. No Relationship To Hosa Is Implied.
Microphone Preamplifi er 4 Direct Boxes (D.I.) 4 Switchers 5 Hum Eliminator 5 Cable Testers 5 Patch Bays & Cables 6—8 Stage & Studio 9—11 Digital Speakers 9 P.A. Systems & Mixers 9—10 Microphones 12 Data Links 12 Digital / Data / Computer Cables 13—17 MIDI 17 Video Products 18—23 Visionary Series 18 Video Cables 18—22 Microphone Cables 24—25 Guitar / Instrument Cables 26—27 Speaker Cables 28—30 Single Interconnect 31—34 Tiny-Tel (Bantam) Cables 35 DMX Lighting Cables 35 Dual Interconnects 36—37 Mini (1/8”) Cables 38—39 Eight Channel Snakes 40—44 Stage Box Snakes 44—45
Y-Cables (including Send & Return) 46—49 Adaptors 50—53
Phoenix Adaptors 53 AC Power Cords & Adaptors 54—55 Lights 56 Cable Organizers 57 Gaffers Tape 57 Foot Switches 58 Equipment Racks 58 Headphones & Extension Cords 59 Stands 60—61 Cleaners, Lubricants, Polishes 62—63 Connectors 64—65 Bulk Cable 66 Connector Guide 68—69 Index 70—71
3
www.hosatech.com
Studio Microphone Preamplifier
Hi-Spec Pro Studio Microphone Preamplifier, with AC/DC Adaptor.
• Dedicated Studio Microphone Preamplifier
• State-of-the-Art Electronics
• Sweeter than the Channel “Pre” on Mixers!
• Three-Position Mic Attenuation
• Continuous Gain Control
• Switchable Phantom Power
• XLR Line Output and 1/4” Hi-Z Output.
• AC/DC Power Adapter Included.
• Indestructible Extruded Aluminum Chassis.
• Rugged, Utilitarian Design.
Preamplifi er / Direct Box
2007 Retail Catalog
Works with Fine Studio Condenser Mics.
Don’t let its rugged, good looks fool you. Beneath the surface of the utilitarian industrial design lies the heart of a world-class studio microphone pre­amplifier worthy of sharing the stage or studio with the very best!
MODEL MSRP
MCA 428
..$150.00
Active Direct Box for Guitar & Bass
Active direct box with terminal for AC/DC power supply.
Input & Hi-Z Out.
Features a terminal for the ACA-281 AC/DC adaptor, sold separately. Price for Adaptor is listed below.
Optional power supply, Model ACA-281. 12-volt, 500mA
Battery compartment, (battery included)
Output
Ground lift (Defeats Phantom Power)
“SIDEKICK” Passive Direct Box for Guitar & Bass
Hosa’s new DIB-443 “SIDEKICK” Passive Direct Box utilizes a high-quality isolation transformer to change a guitar’s very high-impedance output into a low-impedance output suitable for sending long distances via microphone cable or stage snake. Imparts a slight gain to your signal (gain is a good thing), that is useful and very musical.
Electronically prepares guitar and bass signals for direct-to­mixer connections via Low-Z mic inputs. Perfect for sending guitar or bass through long microphone snakes.
“Amp-In” feature allows your amp’s speaker output to feed the console. Now your amplified sound can go directly into the console without time-consuming microphone selection and placement.
Automatically switches from 9-volt battery (included) to phan- tom power when phantom power is present.
Ground-Lift Switch breaks “ground-loops”, reducing 60-cycle hum.
No-compromise electronics for world-class performance. Sound is smmmmooth. Compare to other brands at twice the price!
MODEL MSRP
DIB 307A ..$100.00 ACA 281 ..$18.30
XLR OUTPUT AND GROUND LIFT SWITCH ON THE BACK.
4
Extras include a Hi-Z output for sending to an on-stage amp, Ground Lift (for stopping buzz and hum), and an Instrument/ Speaker switch to choose either direct input from the gui­tar, or amplified input from the guitar amp! NO BATTERY REQUIRED.
MODEL MSRP
DIB 443 ..$29.95
AUDIO SWITCHERS
Audio Signal Selector
2007 Retail Catalog
AUDIO SWITCHERS
Audio Signal Selector With Volume and Mute
www.hosatech.com
Signal Switchers / Hum Eliminator / Cable Testers
Noiseless BALANCED 3-IN, 1-OUT switching (or vice-versa) in left / right pairs. Great for selecting among multiple powered monitor speakers. Does not require power. For line-level only. Not for after amp speaker connections.
Noiseless BALANCED 1-IN, 2-OUT switching IN STEREO. Perfect for selecting between two sets of powered monitor speakers. Features Independent Volume controls for each output, plus master Mute Button. Does not require power. For line-level only. Not for after amp speaker connections.
MODEL MSRP MODEL MSRP
SLW 333 ..$150.00 MVS 413 ..$150.00
Hum Eliminator
Two channel Hum Eliminator is designed to get rid of “ground loop” problems, such as AC hum or buzz and / or pop noises. Use it to convert between balanced and unbalanced lines.
2 UNBAL. 1/4” INPUTS 2 BALANCED 1/4”
OUTPUTS GROUND LIFT
SWITCHES PASSIVE CIRCUITRY
WITH TRANSFORMER NO BATTERY
REQUIRED CONVERTS UNBAL. to
BALANCED
Hum Eliminator for PC Audio Integration
Two channel Hum Eliminator is designed to get rid of “ground loop” problems, such as AC hum or buzz and / or pop noises. Use it to convert between balanced and unbalanced lines. Works in either direction.
XLR OUTS
ON REAR
Computer Sound Buzzing and Humming?
2 UNBAL. RCA INPUTS 2 BALANCED XLR (M)
OUTPUTS GROUND LIFT SWITCHES PAD IN/OUT SELECTOR
SWITCH STEREO/MONO SWITCH
ALLOWS COMBINING OUTPUTS
PASSIVE CIRCUITRY WITH TRANSFORMER
NO BATTERIES REQUIRED
MODEL MSRP MODEL MSRP
HEM 462 ..$127.00 HEM 331 ..$115.00
Video Cable Tester Cable Tester
One button automatic audio cable tester. Just plug in your cables, press the button and the readout will tell you if your cable is good or bad.
Tests: RCA, 1/4”, 3.5 mm, XLR, Speakon and Banana Tests: RCA, BNC, “F”, and S-Video!
MODEL MSRP MODEL MSRP
CBT 375 ..$130.00
One button automatic video cable tester. Designed specifically for video applications. Just plug in your cables, press the but­ton and the readout will tell you if your cable is good or bad.
VCT 377 ..$110.00
5
www.hosatech.com
2007 Retail Catalog
Balanced XLR Patch Bay
12-Point XLR Patch Bay
Simple straight through XLR patch bay. Ships with XLR female jacks on front and XLR male on the rear. Each chan­nel can easily be reversed. Internal wiring is shielded.
Patch Bays
MODEL MSRP
PDR 369 ..$190.00
Switchable Un-balanced 1/4” Patch Bay
48-Point “Switchbay,” Full-Normal, Half-Normal, or De­Normalled via Front Panel Switch.
PHB-265 features recessed front-panel switches on every channel for selecting the normalling scheme. It’s an unbal- anced bay, but it will pass balanced signals when switched to the “De-Normal” setting only.
MODEL MSRP
PHB 265 ..$179.00
Unbalanced 1/4” Patch Bay
48-Point, Versatile Half-Normal Configuration.
The PHB-340 is an unbalanced (TS) 1/4” half-normalled patch bay. De-Normalled (straight through) operation is possible by rotating the individual internal channel modules. Includes detailed instructions.
MODEL MSRP
PHB 340 ..$120.00
Fiber Optic Patch Bay Module
6-Point Fiber Optic (Toslink) Half-Normal Module
Up to 24 Bit, 48KHz Compatible, S/PDIF or ADAT Litepipe. Works just like an analog half-normal patch bay! Fit up to four modules in the PPP-000 19” Patch Bay Frame (Page 7) or use as stand-alone units. AC/DC Adaptor Included. Internal jumper defeats half-normalling for De-normalled (straight-through) operation. Switching jack in bottom-front position features Auto-Sensing Circuitry to detect incoming signal.
MODEL MSRP
MFO 363B
..$280.00
Word Clock Generator
World Clock Generator, Includes AC Power Supply
44.1K, 48K,
88.2K and 96K. 16~24 BIT.
(FOUR OUTPUTS ON REAR PANEL)
6
Balanced 1/4” Patch Bay
48-Point, Versatile Half-Normal Configuration.
The PHB-350 is a balanced (TRS) 1/4” half-normalled patch bay. De-Normalled (straight through) operation is possible by rotating the individual internal channel modules. Includes detailed instruc­tions.
MODEL MSRP
PHB 350 ..$146.00
Unbalanced 1/4” to RCA Patch Bay
48-Point, Versatile Half-Normal Configuration. 1/4” on the front, RCA on the rear.
The PHB-360 is an unbalanced half-normalled patch bay. 1/4” patch points on the front, RCA on the rear. Includes detailed instructions.
MODEL MSRP
PHB 360
..$126.00
Rock-Solid Internal Reference Clock. Individually-buffered 75-ohm and TTL Level Outputs. LED Illuminates When Clock Output Signal is Present. Use as a Stand-alone unit, or mount in Hosa’s PPP-000 frame, see Page 7.
MODEL MSRP
WDC 427 ..$130.00
Modular XLR Patch Bay
2007 Retail Catalog
Modular Balanced 1/4” Patch Bay
www.hosatech.com
Patch Bays
3-Point XLR Patch Bay.
Modular design can be used as a stand-alone unit or mounted in the PPP-000 frame, see this page. Simple straight through XLR patch bay. Internal wiring is shielded.
MODEL MSRP
MXL 369 ..$48.00
Modular Unbalanced 1/4” Patch Bay
8-Point, Versatile Half-Normal Configuration.
8-Point, Versatile Half-Normal Configuration.
Modular design can be used as a stand-alone unit or mounted in the PPP-000 frame, see this page.
MODEL MSRP
MHB 350 ..$52.00
Modular Balanced 1/4” Patch Bay
8-Point, Versatile Half-Normal Configuration. 1/4” on the front, RCA on the rear.
Modular design can be used as a stand-alone unit or mounted in the PPP-000 frame, see this page.
MODEL MSRP
MHB 340 ..$50.00
Modular design can be used as a stand-alone unit or mounted in the PPP-000 frame, see this page.
MODEL MSRP
MHB 360 ..$50.00
Modular Patch Bay Rack Mount Frame
Four slot, 19” Rack Frame for Patch Bay Modules
About Patch Bays and “Normalling” Schemes
All Hosa patch bays feature “half-normalled” configuration (except for the PHB-265, the PDR-369, and the MXL-369). Two pieces of gear that are con-
nected, one to the rear-panel top and one to the rear-panel bottom jacks, in any single bay channel are automatically connected to each other. Plugging into the bottom-front jack of that same channel breaks the connection.
This “half-normal” configuration is the perfect combination of versatility and affordability, and it easily handles all of the patching scenarios needed by most commercial and home studios.
De-Normalled operation for Hosa patch bays (straight-through wiring) is accomplished by turning around selected internal channel modules 180 degrees, except on the PHB-360 and MHB-360 which can not be de-nor­malled.
This is “Half-Normalling”
1. 2. 3.
REAR FRONT REAR FRONT REAR FRONT
From Recorder
To Mixing Console
Make permanent connections at the REAR of the bay.
A “Half-Normalled” patch bay is incredibly versatile. By inserting a plug into the switching jack at the front bottom position, you can break the “normal connection” between top and bottom at the rear. Here’s a simplified example:
From Recorder
To Mixing Console
Signal from the recorder is also available at the FRONT TOP jack.
Use the PPP-000 to mount Hosa’s modular patch bays. Comes with three covers. One rack unit high (1.75”).
MODEL MSRP
PPP 000 ..$24.00
The PHB-265 uses recessed, front-panel switches to select half-normalled, full­normalled or de-normalled operation, so rotating the modules isn’t necessary.
The PDR-369 and MDR-369 XLR bays have no normalling (straight through only).
To Reverb To
Plugging the reverb’s return signal into the FRONT BOTTOM jack breaks the connection between top and bottom at the rear of the bay, and completes the outboard loop.
Front
From Recorder
To Mixing Console
Rear
Reverb
From Reverb
7
www.hosatech.com
2007 Retail Catalog
Balanced 1/4” Patch Bay Cable Set
Set of Eight Balanced (TRS) 1/4” Cables. Individually Colored.
Outside Diameter of cable: 4mm
MODEL LENGTH MSRP
CSS 830 1 ft. ..$30.00
Patch Bay Cable Sets
CSS 845 1.5 ft. CSS 890 3 ft.
..$35.00 ..$48.00
Balanced 1/4” Patch Bay Cable Set
Set of Eight Balanced (TRS) 1/4” Cables. Individually Colored.
Outside Diameter of cable: 5mm
Balanced TT Patch Bay Cable Set
Set of Eight Balanced TT (a.k.a. Tiny-Tel and Bantam) Cables. Individually Colored.
NOT 1/4”
Find more TT cables on page 35 and 40.
MODEL LENGTH MSRP
TTS 830 1 ft. ..$75.00 TTS 845 1.5 ft. TTS 890 3 ft.
..$80.00 ..$90.00
Optical (Toslink) Patch Bay Cable Set
Set of Six Toslink Fiber Optic Cables. Individually Colored.
Find more Optical cables on Page 13.
MODEL LENGTH MSRP
OPT 601 1 ft. ..$50.00
MODEL LENGTH MSRP
CSS 845 OD5 1.5 ft .. $39.00 CSS 890 OD5 1.5 ft
.. $50.00
Unbalanced 1/4” Patch Bay Cable Set
Set of Eight Unbalanced (TS) 1/4” Cables. Individually Colored.
MODEL LENGTH MSRP
CPP 830 1 ft. ..$20.00 CPP 845 1.5 ft. CPP 890 3 ft.
..$23.00 ..$27.00
RCA Patch Bay Cable Set
Set of Eight RCA Cables. Individually Colored.
8
MODEL LENGTH MSRP
CRA 830 1 ft. ..$20.70 CRA 845 1.5 ft.
..$21.75
See Pages 54 and 55
for all your
Power Cable Needs.
2007 Retail Catalog
All Digital
Studio Monitoring System
• Binary Drive™ Digital Amplifi cation
• Accurate, Precise, Focused and Detailed Sound
• ZERO Inter-modulation Distortion
• On-Board Digital EQ with Memory: Program and Store 8 EQ & Tone Settings
• 5.25” Carbon Fiber Woofer
• 1” Silk Dome Tweeter
• Free, downloadable Audio Controller Software for Windows™ and Macintosh™ OS X™
• Incredible 93% Effi ciency—Runs Cooler
• Light Weight (No Heavy Heat Sinks of Transformers)
www.hosatech.com
Stage & Studio: Monitors
All of the CUE 5’s electronics, controls, and connections are located on the rear panel of the right speaker. Connection to the left speaker is via a 5-Pin XLR cable (included).
Analog inputs are provided, but the CUE 5 really shines when you provide either an opti­cal or coaxial digital input, and network the system with your Mac OS X or Windows PC via ethernet or RS-232 (adaptor is included).
The free downloadable Audio Controller software offers you a graphic user interface to control volume, auto fade in/out, bass, treble, 7-band parametric equalizer and 8 user­confi gurable memory patches that store your favorite tone and equalizer settings.
Studio Monitors Speakers
Sold in Pairs
MODEL MSRP
QCUE 5 ..$899.00
• 8” Polypropylene Mineral Filled Cone Woofers
• Ferrofluid Cooled 1” Soft-Dome Tweeters
• Very Linear Frequency Response at All Levels, from 45Hz to Beyond 20KHz
• Full Magnetic Shielding For Use Around TVs and Computers
• Incredible Performance-to-Price Ratio!
• Calibrated Rear Port for Extended Bass
QZS-8 Passive Speakers. Accepts 1/4” inputs.
QZS-8P Active (powered) Speakers. Internally
Biamplified (100 Watts for Frequencies, 50 Watts for the Highs), Crossed-Over at 2.6KHz. Accepts 1/4” or XLR, Balanced or Unbalanced Inputs.
Sold in Pairs
MODEL TYPE MSRP
QZS 8 Non-Powered ..$280.00 QZS 8P Powered ..$400.00
9
www.hosatech.com
Pro P.A. Speakers
2007 Retail Catalog
Solid, well-built cabinets with braced construction for tight sound. Dual front ported design helps the heavy-duty woofer really...well..woof! The compression horn is designed to hit the back row without cutting the front row to pieces! Great to know when the most sensitive ears in the room park themselves right up front. Ergonomically placed side handles make toting these speakers easy. Sockets in bottom for mounting on speaker stands.
QSP-200 Twelve inch woofer, 200-watt power handling capac­ity at 4 Ohms.
QSP-250 Fifteen inch woofer, 250-watt power handling capac­ity at 4 Ohms.
Complete 150-Watt Portable PA System
Package includes: (1) 4-Channel Mixer / Amplifier (2) Speakers (2) Speaker Cables (1) Microphone (1) Microphone Cable (2) Stands (2) Power Cord (2) Extra Fuses
Complete 100-Watt Portable PA System
Package includes: (1) 4-Channel Mixer / Amplifier (2) Speakers (2) Speaker Cables (1) Microphone (1) Microphone Cable (3) Stands (2) Power Cord
Inputs: 1/4” and Banana Jacks
MODEL SIZE MSRP
QSP 200 12" Woofer ..$165.00 QSP 250 15" Woofer
A small P.A. for those on the go. Great for coffee house gigs, small church groups, business meetings, and more. Easy to setup and breakdown. The cables, stands, and microphone all fit inside the case to form a self con­tained, highly portable, package. Each channel has Volume, Bass, Treble, and Reverb. Channel 4 also has two 1/4” inputs (left/mono and right) for line input devices. Onboard digital effects (DSP), 5-band graphic EQ, and Master Volume. Power output is 75-Watts per side (150-Watts total). RCA inputs and outputs for connecting CD player or tape recorders.
MODEL MSRP
QMS 5 ..$645.00
Portable P.A. system that all fits in a Soft Luggage Style Rolling Case for easy transportation. Great for conferences, coffeehouse, and church gigs. Loaded with great features like: Onboard digital effects (DSP), 5-band graphic EQ, and Master Volume. Power output is 50­Watts per side (100-Watts total) at 4 Ohms. RCA inputs and outputs for connecting CD player or tape recorders.
..$199.00
Power Amplifiers
Stage & Studio: P.A. Systems / Power Amps / Guitar Amp
Guitar Amplifiers
MODEL MSRP
QMS 6
..$625.00
Two Great Professional Power Amplifiers at 305 Watts (QA-8) and 380 Watts (QA-10) respectively per side into 4 Ohms. Quiet cooling fans. Unbalanced 1/4” inputs, Speakon® compatible outputs. Great for bands or DJs!
MODEL MSRP
QA 10 ..$229.00 QA 8
..$199.00
Screaming 20-Watt Guitar amp with Reverb. This little solid-state gem is really loud, with character! Features a single input, with a swithcable overdrive section which has its own level control, making for easy, one-button “channel switching.” Three band EQ and onboard reverb round out the control section. There’s an extension speaker output jack for times when you need to supplement the on-board 8” heavy-duty guitar speaker, and even a headphone jack for silent jamming.
MODEL MSRP
QGA 20 ..$110.00
10
2007 Retail Catalog
Audio Mixer Audio Mixer
16 Channel Compact Mixer with Carrying Handle
www.hosatech.com
Stage & Studio: Mixers / Microphones
12 Channel Compact Mixer with Carrying Handle
Features Include: 8 Mic / Line Inputs, 2 Stereo Inputs, 2 Effects Returns, Stereo Tape I/O, Alps 60mm Faders, JRC4580 Op-Amps, 3-Band EQ (each Channel), Monitor Send, Effects (Send, Trim, Pan, Low Cut, and Mute).
MODEL MSRP
QMX 16X2
Audio Mixer
..$399.00
18 Channel Mixer
MODEL MSRP
QMX 12X2 .. . T.B.A.
400-Watt Integrated Mixer-Amp
Features Include: 8 Mic / Line Inputs, 2
Stereo Inputs, 2 Effects Returns, Stereo Tape I/O, Alps 60mm Faders, JRC4580 Op-Amps, 3-Band EQ (each Channel), Monitor Send, Effects (Send, Trim, Pan, Low Cut, and Mute).
Rack-Mountable Compact
Features Include: 10 Mic / Line Inputs, 2 Stereo Inputs, 2 Effects Returns, Stereo Tape I/O, Alps 60mm Faders, JRC4580 Op-Amps, 3-Band EQ (each Channel), Monitor Send, Effects (Send, Trim, Pan, Low Cut, and Mute).
MODEL MSRP
QMX 18X2R .. . $449.00
MODEL MSRP
QMX 150 ..$379.00
Features Include: 8 Mic / Line
Inputs, 200-Watts Main, 200-Watts Monitor, 360-Watts Bridged, Limiter (Main / Monitor), On Board Delay Effects, 3-Band EQ, Monitor Send, Effects Send.
Professional Tube Microphone Professional Tube Microphone
Big, Lush Sound, Mulitple Pickup Pattern, -10dB Pad and Bass Roll-Off Switches.
Features Include: Aluminum Flight Case , Multi-Pattern Power Supply, Remote Pickup Pattern Switch, Elastic Shock Mount, Wind Screen, Adaptor, and Cables.
Max SPL for 1% THD: 130dB Sensitivity: 14mv/Pa= -37dB
MODEL MSRP
QCM 2 ..$520.00
MODEL MSRP
QCM 3
Big, Lush Sound, Mulitple Pickup Pattern, -10dB Pad and Bass Roll-Off Switches.
Features Include: Aluminum Flight Case , Multi-Pattern Power Supply, Remote Pickup Pattern Switch, Elastic Shock Mount, Wind Screen, Adaptor, and Cables.
Max SPL for 1% THD: 141dB Sensitivity: 22.4mv/Pa= -33dB
..$550.00
Professional Microphone
Detailed and Smooth. Suspension shock­mount included. FET condenser. Cardioid pattern. Requires phantom power.
Max SPL for 1% THD: 145dB Sensitivity: -38dB +/- 2dB
MODEL MSRP
QMF 18
..$149.00
Dynamic Stage Microphone
Solid, Hi-dB Stage Vocal Microphone. Smooth. Rugged!
Features Include: built in on / off switch and XLR to 1/4” cable.
MODEL MSRP
QMD 4
..$39.00
Professional Microphone
Amazing on cymbals, drums, acoustic guitar, and piano. Great ambient room mic. Requires phantom power. Unidirectional (wide cardioid).
Features Include: Zippered wallet, storage box, and mic clip.
Max SPL for 1% THD: 145dB Sensitivity: -14dB +/- 3dB
MODEL MSRP
QCM 5
..$110.00
Dynamic Stage Microphone
Solid, Hi-dB Stage Vocal Microphone. Smooth. Rugged!
Features Include: built in on / off switch and XLR microphone cable.
MODEL MSRP
QMD 6
.. . T.B.A.
11
www.hosatech.com
2007 Retail Catalog
Digital Links
S/PDIF Coax (RCA) to S/PDIF Fiber Optic (Toslink)
Features:
24 Bit / 96K Simultaneous Transfer of 2 Channels of S/PDIF Coax
(RCA) 2 Channels of S/PDIF Optical (Toslink)
A.C. Adaptor Included
The ODL-276 by Hosa is a high quality, optical/coaxial data link, allowing simultaneous transfer of two channels of digital­audio in either or both directions between S/PDIF (RCA coax) and S/PDIF (Toslink fiber optic).
MODEL MSRP
ODL 276A ..$110.00
Digital Links
S/PDIF Coax (RCA) to AES / EBU (XLR)
Cables: Digital / Data / Computer
The CDL-313 by Hosa is a high quality digital link, allowing simultaneous transfer of two channels of digital-audio in either or both directions between AES / EBU (XLR) and S/PDIF (RCA).
Features:
Transfers AES / EBU digital audio signals to S/DIF Digital Audio Signal, and Vice-Versa 2 Channels AES / EBU to Coax (RCA) 2 Channels of S/PDIF Coax (RCA) to AES / EBU 2 Channels of S/PDIF Optical (Toslink)
A.C. Adaptor Included 16 Bit / 48K
Fiber Optic Splitter
Fiber Optic Splitter, 1-IN, 2-OUT “Y” Box
Features:
16 Bit / 48K One In, Two Out Fiber Optic
Splitter. Sends data to two destinations at Once.
Compatible with Dolby. A.C. Adaptor Included. NOT COMPATIBLE WITH
ADAT LITEPIPE.
Use this professional optical data splitter whenever you need to send your fiber optic signals to two destinations at once.
MODEL MSRP
ODY 314
..$80.00
Digital Links
Fiber Optic S/PDIF to AES / EBU (XLR)
Features:
16 Bit / 48K 2 Channels AES / EBU to
Optical S/PDIF. 2 Channels Optical S/PDIF to AES / EBU. A.C. Adaptor Included.
The ODL-312 by Hosa is a high quality, converter, allow­ing simultaneous transfer of two channels of digital-audio in either or both directions between AES/EBU (XLR) and Optical (Toslink) S/PDIF.
12
MODEL MSRP
CDL 313 ..$95.00
Fiber Optic Selector
Fiber Optic (Toslink) Selector, 2-IN, 1-Out via Switch.
Features:
16 Bit / 48K 2 Fiber Optic Inputs Switched
to One Fiber Optic Output Select Source Via Rocker Switch.
A.C. Adaptor Included. NOT COMPATIBLE WITH
ADAT LITEPIPE.
The ODS-330 is a high quality, fiber optic switcher. Select between source 1 or source 2 via switch.
MODEL MSRP
ODS 330
..$80.00
MODEL MSRP
ODL 312 ..$95.00
BNC 50 Ohm Coax Cables
BNC Male to BNC Male, RG58 50ohm. For use with anten­nas, data, or wireless microphones.
MODEL LENGTH MSRP
BNC 58 101 1 ft. ..$5.50 BNC 58 101.5 1.5 ft. BNC 58 103 3 ft. ..$6.90 BNC 58 106 6 ft. BNC 58 110 10 ft. BNC 58 115 15 ft. BNC 58 125 25 ft. BNC 58 150 50 ft. BNC 58 1100 100 ft.
..$6.00
..$8.25 ..$9.75 ..$12.50 ..$16.25 ..$26.75 ..$47.65
2007 Retail Catalog
Fiber Optic Cables — Professional
Professional Toslink to Toslink Fiber Optic Cables
The OPM-300 series features metal headshells, metal guides, and heavy-duty outer jacketing. For use with ADATs and other Toslink-equipped recording gear.
MODEL LENGTH MSRP
OPM 303 3 ft. ..$21.50 OPM 305 5 ft. ..$24.00 OPM 310 10 ft. OPM 315 15 ft. OPM 320 20 ft. OPM 330 30 ft. OPM 350 50 ft. ..$77.50
Fiber Optic Cables — Standard
Standard Toslink to Toslink Fiber Optic Cables
For use with ADATs and other Toslink-equipped recording gear. Also available in convenient 1 ft. six pack for patching, see page 8.
MODEL LENGTH MSRP
OPT 102 2 ft. ..$11.00 OPT 103 3 ft. OPT 106 6 ft. OPT 110 10 ft. OPT 113 13 ft. ..$27.50 OPT 117 17 ft. OPT 130 30 ft. OPT 150 50 ft.
Fiber Optic Toslink to 3.5mm Sony Type
Toslink to 3.5mm Sony Compatible Fiber Optic, also Used with Macs.
..$33.50 ..$37.00 ..$47.00 ..$57.00
..$12.50 ..$16.00 ..$23.50
..$33.50 ..$42.00 ..$60.00
www.hosatech.com
Category 5E
CAT-5E Patch Cable, 350 MHz, UTP.
UTP indicates Standard Unshielded Twisted Pair. The CAT-5E series is available in five color choices: BLK, GRY, RED, YEL. See below for Blue. Add color code to end of model for color choice. Example “CAT-503E RED” for red. Note, for Blue, see
MODEL LENGTH MSRP
CAT 503E BLK 3 ft. ..$4.00 CAT 505E BLK 5 ft. CAT 510E BLK 10 ft. ..$7.00
..$4.50
Category 5E — In BLUE
CAT-5E Patch Cable, 350 MHz, UTP. Same As Above, But In Popular Blue Color and Longer Lengths.
MODEL LENGTH MSRP
CAT 503E BLU 3 ft. ..$4.00 CAT 505E BLU 5 ft. CAT 510E BLU 10 ft. CAT 5100E BLU 100 ft. CAT 5150E BLU 150 ft. ..$78.00 CAT 525E BLU 25 ft. CAT 550E BLU 50 ft.
..$4.50 ..$7.00 ..$52.00
..$14.00 ..$24.00
Category 6
CAT-6 Patch Cable, 350 MHz, UTP.
UTP indicates Standard Unshielded Twisted. Available in Black Only .
MODEL LENGTH MSRP
CAT 603 BLK 3 ft. ..$6.95 CAT 605 BLK 5 ft. CAT 610 BLK 10 ft. CAT 615 BLK 15 ft.
..$8.50 ..$10.50 ..$14.00
Cables: Digital / Data / Computer
MODEL LENGTH MSRP
OPQ 215 15 ft.
..$31.00
Fiber Optic 3.5mm to 3.5mm Sony Type
3.5mm to 3.5mm Sony Compatible Fiber Optic , also Used with Macs.
Premium!
MODEL LENGTH MSRP
OMM 305 5 ft. ..$16.50 OMM 310 10 ft. OMM 315 15 ft.
..$24.50 ..$31.00
13
www.hosatech.com
2007 Retail Catalog
AES / EBU Snake — For Yamaha & Mackie
25-Pin D-Sub to 25-Pin D-Sub. The DBK-347 is an AES / EBU
110 ohm snake configured for use with Yamaha, Mackie, TC Electronics, and Black Magic Design.
MODEL LENGTH 5+ PCS. MSRP
DBK 347 15 ft. ..$80.00
AES / EBU Snake — For Tascam
25-Pin D-Sub to 25-Pin D-Sub.
The DES-300 series AES / EBU 110 ohm snakes are configured for use with Tascam, Digidesign, and Apogee.
MODEL LENGTH MSRP
DES 303 3 ft. ..$27.00
Cables: Digital / Data / Computer
DES 315 15 ft.
..$90.00
AES / EBU Breakout Snake — For Yamaha & Mackie
25-Pin D-Sub to 4 XLR Male and 4 XLR Female. The DBK-258 series 110
ohm AES / EBU Breakout snakes are designed for use with Yamaha (O2R and O3D), Mackie (D8B), TC Electronics, and Black Magic Design.
AES / EBU 110ohm — Professional
Professional AES / EBU, XLR Male to XLR Female.
The AES series features Belden’s 110 ohm “French-Braid” cable.
MODEL LENGTH MSRP
AES 003 3 ft. ..$20.00 AES 005 5 ft. AES 010 10 ft. ..$40.90 AES 015 15 ft. AES 020 20 ft. AES 025 25 ft. AES 030 30 ft. AES 050 50 ft. ..$160.00
..$26.25
..$55.65 ..$70.00 ..$86.00 ..$100.00
AES / EBU 110ohm — Standard
Standard AES / EBU, XLR Male to XLR Female.
A great 110 ohm AES / EBU cable for those on a budget. For use with 3-Pin DMX systems.
MODEL LENGTH MSRP
EBU 003 3 ft. ..$19.00 EBU 005 5 ft. EBU 010 10 ft. EBU 020 20 ft. EBU 025 25 ft. EBU 030 30 ft. ..$40.00 EBU 050 50 ft. EBU 100 100 ft. EBU 150 150 ft.
..$20.00 ..$24.00 ..$31.00 ..$35.00
..$55.00 ..$95.00 ..$130.00
14
MODEL LENGTH MSRP
DBK 258 16.5 ft. ..$97.00
AES / EBU Breakout Snake — For Tascam and Panasonic
25-Pin D-Sub to 4 XLR Male and 4 XLR Female. For use with Tascam, Panasonic, Digidesign, and Apogee.
The DMP-235 series 110 ohm AES / EBU Breakout snakes are designed for use with Tascam (MX-24) and Panasonic (DA7).
MODEL LENGTH MSRP
DMP 235 16.5 ft. ..$97.00
S/PDIF 75ohm Coax
Double Shielded 75 ohm Coax Cable with Gold Plated RCA Connectors.
The DRA-500 series cables are designed specifically for S/PDIF. They are also great for use as a composite video cable.
MODEL LENGTH MSRP
DRA 501 1M (3.3 ft.) ..$12.00 DRA 502 2M (6.6 ft.) DRA 503 3M (9.9 ft.) ..$16.00 DRA 504 4M (13.2 ft.) DRA 506 6M (19.8 ft.)
Looking for
Analog Recording Snakes?
See pages 40–44
..$14.00
..$18.00 ..$22.00
2007 Retail Catalog
Firewire — 6-Pin to 6- Pin (for Firewire 400 — 400Mb/s)
MODEL LENGTH MSRP
FIW 66 101.5 1.5 ft. ..$11.25 FIW 66 103 3 ft. FIW 66 106 6 ft. FIW 66 110 10 ft. ..$17.10 FIW 66 115 15 ft.
..$11.40 ..$14.70
..$22.95
www.hosatech.com
Cables: Digital / Data / Computer
USB 2.0 — “A” Male to “B” Male
USB-A to USB-B, 2.0 Compliant Universal Serial Bus Cable
Firewire — 6-Pin to 4-Pin (for Firewire 400 — 400Mb/s)
MODEL LENGTH MSRP
FIW 46 101.5 1.5 ft. ..$11.25 FIW 46 103 3 ft. FIW 46 106 6 ft. ..$14.70 FIW 46 110 10 ft. FIW 46 115 15 ft.
..$11.40
..$17.10 ..$22.95
Firewire — 4-Pin to 4-Pin (for Firewire 400 — 400Mb/s)
MODEL LENGTH MSRP
FIW 44 103 3 ft. ..$11.40 FIW 44 106 6 ft. FIW 44 110 10 ft. ..$17.10 FIW 44 115 15 ft.
Firewire 800 — 9-Pin to 9-Pin
MODEL LENGTH MSRP
FIW 99 106 6 ft. ..$21.90 FIW 99 110 10 ft. FIW 99 115 15 ft. ..$28.35
Firewire 800 — 9-Pin to 6-Pin
..$14.70
..$28.95
(Firewire 800 — 800Mb/s)
..$25.05
(Firewire 800 — 800Mb/s)
Data transfer up to 480 Mbps. That’s 40 times better than the original 1.1.
MODEL LENGTH MSRP
USB 200.5AB 6 in. ..$4.50 USB 203AB 3 ft. USB 205AB 5 ft. ..$8.40 USB 210AB 10 ft. USB 215AB 15 ft.
..$7.50
..$9.60 ..$12.00
USB 2.0 — 3-Pack
USB-A to USB-B, Version 2.0, Pack of 3 Individually Colored Cables: BLUE, ORANGE, and CLEAR.
MODEL LENGTH MSRP
USB 305 PAK 5 ft. ..$23.25 USB 310 PAK 10 ft.
..$27.00
USB 2.0 — “A” Male to “A” Female
Not Shown. USB Extension Cable. USB-A Male to USB-A Female.
MODEL LENGTH MSRP
USB 210AF 10 ft. ..$10.00 USB 205AF 5 ft.
..$9.00
Alesis ADAT Sync & Control Cable
DB-9 to DB-9, Double Shielded Control/Sync for ADAT
MODEL LENGTH MSRP
FIW 96 106 6 ft. ..$16.50 FIW 96 110 10 ft. FIW 96 115 15 ft. ..$24.75
Firewire 800 — 9-Pin to 4-Pin
MODEL LENGTH MSRP
FIW 94 106 6 ft. ..$15.75 FIW 94 110 10 ft. FIW 94 115 15 ft. ..$22.50
..$20.25
(Firewire 800 — 800Mb/s)
..$18.75
Guaranteed compatibility for all ADAT Sync and BRC controller func­tions. Double shielded. This 9-Pin cable is not intended for serial or RS-232 type applications. It will not work for AKAI controller applica­tions.
MODEL LENGTH MSRP
CMT 401.5DS 1.5 ft. ..$11.00 CMT 403DS 3 ft. CMT 405DS 5 ft. CMT 410DS 10 ft. CMT 415DS 15 ft.
..$12.00 ..$14.00 ..$19.00 ..$24.00
15
www.hosatech.com
2007 Retail Catalog
TDIF Digital Dubbing Cable — Tascam & Others
TDIF Cable, 25-Pin D-Sub to 25-Pin D-Sub. Double Shield, Twisted Pair.
MODEL LENGTH MSRP
DBK 303 3 ft. ..$33.00 DBK 315 15 ft.
..$50.00
Sync Cable For Use with Tascam
15-Pin D-Sub to 15-Pin D-Sub, Sync for DA88
MODEL LENGTH MSRP
Cables: Digital / Data / Computer
TAS 275 15 ft. ..$39.00
Tascam Compatible Termination
Tascam Compatible Terminator for DA88 and Others
D-Sub Replacement Screws
Replacement Screws for D-Sub Connecectors. Choose US Thread or Metric. Four pieces per pack.
MODEL TYPE MSRP
SCR 403 US Thread ..$2.50 SCR 404 Metric Thread ..$2.50
MIDI to PC Sound Card Interface
Sound Blaster-Compatible MIDI interface cable. Uses joy­stick I/O port of the sound card. Allows you to keep a joystick connected while using the port for MIDI. The
MIDI connections are female on the SBC-195, so you will need to add two MIDI cables of the appropriate length. See NEXT PAGE for MIDI cables.
MODEL LENGTH MSRP
SBC 195 1.5 ft.
..$39.50
MODEL MSRP
TMN 348
..$20.00
“Host” Style Synthesizer Controller
9-Pin D-Sub Female to 8-Pin DIN Male. PC to Host Cable.
MODEL LENGTH MSRP
DBK 103 3 ft. ..$10.00 DBK 110 10 ft.
..$12.50
Universal CD Player Controller Cable
8-Pin Din to 8-Pin Din Universal CD Player Controller Cable.
USB to MIDI
MIDI OUT
USB
INCLUDES PC DRIVERS on CD-ROM. Compatible with Windows 98SE, ME, 2000, XP, Vista*, and Mac OSX. Not for use with 64-bit PCs. *Complete details and Vista Driver avail­able online at www.hosatech.com.
MODEL LENGTH MSRP
USM 422 10 ft. ..$69.00
MIDI IN
16
MODEL LENGTH MSRP
CCD 103 3 ft. ..$7.00 CCD 110 10 ft.
..$9.00
MIDI Cable — Premium
Premium MIDI Cable with Metal Plugs
2007 Retail Catalog
MIDI Cable with Right-Angle Plugs
Molded MIDI Cable with Right Angle Plugs
www.hosatech.com
Cables: Digital / Data / Computer
All Hosa MIDI cables are wired 5-PIN discrete. All five Pins are con­nected. Perfect for all MIDI transmissions including SYSEX. Black Only.
MODEL LENGTH MSRP
MID 403 3 ft. ..$10.00 MID 405 5 ft. MID 410 10 ft. ..$13.00 MID 415 15 ft. MID 420 20 ft. MID 425 25 ft.
..$11.00
..$15.00 ..$17.00 ..$19.00
MIDI Cable — Standard
Standard MIDI Cable with Molded Plugs
Quite possibly the most popular MIDI cable on the planet. Available in five colors. For colors other than Black, please add the three letter suffix. Example: MID-310RED, MID-310ORG, MID-310BLU, or MID­310WHT. All Hosa MIDI cables are wired 5-PIN discrete. All five Pins are connected.
MODEL LENGTH MSRP
MID 301 1 ft. ..$5.00 MID 303 3 ft. MID 305 5 ft. MID 310 10 ft. ..$8.40 MID 315 15 ft. MID 320 20 ft. MID 325 25 ft.
..$5.70 ..$6.00
..$10.50 ..$12.60 ..$14.10
MIDI Cable — Dual
Premium MIDI Cable with Metal Plugs
All Hosa MIDI cables are wired 5-PIN discrete. All five Pins are connected. Perfect for MIDI transmissions including SYSEX. Black only.
MODEL LENGTH 1-4 PCS. 5+ PCS. MSRP
MDR 103 3 ft. ..$5.90 MDR 105 5 ft. ..$6.50 MDR 110 10 ft. MDR 115 15 ft.
..$8.00 ..$10.50
MIDI Snake
MIDI Snake, 8-Element, Color Coded.
All Hosa MIDI cables are wired 5-PIN discrete. All five Pins are connected. Perfect for MIDI transmissions including SYSEX. Black only.
MODEL LENGTH MSRP
MID 812 12.5 ft. ..$70.00
MIDI Cable — Coiled
Coiled MIDI Cable, Black. 25 ft. When Fully Extended.
All Hosa MIDI cables are wired 5-PIN discrete. All five Pins are connected. Perfect for MIDI transmissions including SYSEX. Black only.
MODEL LENGTH MSRP
MID 325C 25 ft. ..$19.00
All Hosa MIDI cables are wired 5-PIN discrete. All five Pins are connected. Perfect for MIDI transmissions including SYSEX. Black only with colored ends.
MODEL LENGTH MSRP
MID 201 1M (3.3 ft.) ..$11.00 MID 202 2M (6.6 ft.) MID 203 3M (9.9 ft.) ..$15.00 MID 204 4M (13.2 ft.)
..$13.00
..$17.00
7-Pin DIN Controller Cable
Right-Angle 7-Pin Din Male to Straight 7-Pin Din Male. Works for ADA brand MP1 Guitar Preamp and certain Rocktron Devices.
MODEL LENGTH MSRP
MID 725 BULK 25 ft.
..$19.00
17
www.hosatech.com
2007 Retail Catalog
Video Distribution Amp
The DHD-104 is a high-quality distribution ampli­fier for HD (High Definition) and SD (Standard Definition) Serial Digital Interface (SDI) signal. It features one input, four outputs, a distinctive blue LED power light and our unique angled
chassis design, all in a compact 1/4 rack size compatible with other manufacturers’ standard rack adaptors. Perfect for SDI distribution in broadcast, post-production, digital theaters, theme parks, and high-end home theaters. Power Adaptor Included.
MODEL MSRP
DHD 104
..$550.00
Video Distribution Amp
Video Inputs: 1 BNC Video Outputs: 4 BNC
Power Adaptor Included
MODEL MSRP
DCV 104
Size: 1/4 Rack Space Height: 1 Rack Unit
..$180.00
Cables: Digital / Data / Computer
Video Distribution Amp
Stereo Audio Distribution Amp
Audio Inputs: 1 Phoenix Audio Outputs: 4 Phoenix
Power Adaptor Included
MODEL MSRP
DSA 104 ..$180.00
Size: 1/4 Rack Space Height: 1 Rack Unit
Stereo Audio Distribution Amp
Audio Inputs: 1 Phoenix Audio Outputs: 8 Phoenix
Power Adaptor Included
MODEL MSRP
DSA 108
Size: 1/4 Rack Space Height: 1 Rack Unit
..$280.00
Video Switcher
Video Inputs: 1 BNC Video Outputs: 8 BNC
Power Adaptor Included
MODEL MSRP
DCV 108 ..$280.00
Size: 1/2 Rack Space Height: 1 Rack Unit
Video Distribution Amp with Audio
Video Inputs: 1 BNC Audio Inputs: 1 Phoenix Video Outputs: 4 BNC Audio Outputs: 4 Phoenix
MODEL MSRP
DCA 104 ..$240.00
Size: 1/4 Rack Space Height: 1 Rack Unit
Power Adaptor Included
Video Distribution Amp with Audio
Video Inputs: 4 BNC Video Outputs: 1 BNC
Power Adaptor Included
MODEL MSRP
SCV 401 ..$400.00
Size: 1/2 Rack Space Height: 1 Rack Unit
Audio / Video Switcher
Video Inputs: 4 BNC Audio Inputs: 4 Phoenix Video Outputs: 1 BNC Audio Outputs: 1 Phoenix
MODEL MSRP
SCA 401
Size: 1/2 Rack Space Height: 1 Rack Unit
Power Adaptor Included
..$800.00
Audio Switcher
18
Video Inputs: 1 BNC Audio Inputs: 1 Phoenix Video Outputs: 8 BNC Audio Outputs: 8 Phoenix
MODEL MSRP
DCA 108 ..$360.00
Size: 1/2 Rack Space Height: 1 Rack Unit
Power Adaptor Included
Audio Inputs: 4 Phoenix Audio Outputs: 1 Phoenix
MODEL MSRP
SSA 401
Size: 1/2 Rack Space Height: 1 Rack Unit
Power Adaptor Included
..$380.00
HDMI to DVI-D
HDMI Male to DVI-D Male, Single Link .
2007 Retail Catalog
DVI-D (Digital)
DVI-D Cable, Dual Link, DVI-D to DVI-D. Digital Only.
www.hosatech.com
Cables: Digital / Data / Computer
MODEL LENGTH MSRP
HDMD 103 3 ft. ..$21.75 HDMD 106 6 ft. ..$26.25 HDMD 110 10 ft. HDMD 115 15 ft.
..$31.50 ..$41.85
HDMI to HDMI
HDMI Male to HDMI Male, Single Link.
MODEL LENGTH MSRP
HDMI 103 3 ft. ..$34.80 HDMI 106 6 ft. ..$41.55 HDMI 110 10 ft. HDMI 115 15 ft.
..$49.35 ..$64.05
DVI (Digital Visual Interface)
DVI Cable, Dual Link, DVI-I to DVI-I. Digital / Analog.
MODEL LENGTH MSRP
DVD 103 3 ft. ..$23.25 DVD 105 5 ft. DVD 110 10 ft. ..$40.00
..$29.00
Coax Video Cables — “F-Type”
Double Shielded Coax Video Cable with “F” Connectors.
MODEL LENGTH MSRP
VDF 103 3 ft. ..$5.50 VDF 105 5 ft. VDF 110 10 ft. ..$9.50 VDF 115 15 ft. VDF 120 20 ft.
..$6.50
..$11.50 ..$14.50
BNC 75 ohm Coax Cables
BNC Male to BNC Male, RG59 75ohm. For Video or Word­Clock Use.
For 50 ohm BNC to BNC Cables, See Page 12.
MODEL LENGTH MSRP
BNC 59 103 3 ft. ..$6.90 BNC 59 106 6 ft. BNC 59 110 10 ft. ..$9.75 BNC 59 115 15 ft. BNC 59 125 25 ft. BNC 59 150 50 ft. BNC 59 1100 100 ft.
..$8.25
..$12.50 ..$16.25 ..$26.75 ..$47.65
MODEL LENGTH MSRP
DVI 103 3 ft. ..$25.50 DVI 105 5 ft. DVI 110 10 ft.
..$30.00 ..$42.00
BNC / RCA 75 Ohm Coax Cables
BNC Male to RCA Male. For Video.
MODEL LENGTH MSRP
BNR 103 3 ft. ..$7.00 BNR 106 6 ft. BNR 110 10 ft. ..$9.75 BNR 125 25 ft.
..$8.50
..$16.50
19
www.hosatech.com
2007 Retail Catalog
15-Pin VGA Cable
Premium 15-Pin VGA Cable. 15-Pin Male to 15-Pin Male
MODEL LENGTH MSRP
VGA 301.5 1.5 ft. ..$10.80 VGA 303 3 ft. VGA 306 6 ft. ..$17.50 VGA 310 10 ft. VGA 315 15 ft. VGA 325 25 ft. VGA 335 35 ft. VGA 350 50 ft. ..$102.00 VGA 375 75 ft. VGA 3100 100 ft.
..$13.75
..$25.75 ..$35.00 ..$55.00 ..$74.00
..$151.00 ..$199.00
Video Cables and Adaptors
15-Pin VGA Cable with Ferrite Core
Premium 15-Pin VGA Cable with Interference Reducing Ferrite Core. 15-Pin Male to 15-Pin Male
VGA Video Y-Cable
VGA Y-Cable, 15-Pin VGA Male to Two 15-Pin VGA Females.
Male
MODEL LENGTH MSRP
YVG 449 6 in.
..$11.50
2 Females
15-Pin VGA Breakout Cable
VGA Video Breakout, 15-Pin Male to Five BNC Females.
Male
MODEL LENGTH MSRP
VGF 300.7 7 in. ..$18.00 VGF 301.5 1.5 ft. VGF 303 3 ft.
Five BNC Females
..$19.50 ..$21.00
MODEL LENGTH MSRP
VGA 306FR 6 ft. ..$20.25 VGA 310FR 10 ft. VGA 315FR 15 ft. ..$37.00 VGA 325FR 25 ft. VGA 335FR 35 ft. VGA 350FR 50 ft. VGA 375FR 75 ft. VGA 3100FR 100 ft. ..$202.00
..$28.00
..$58.00 ..$76.00 ..$105.00 ..$153.00
15-Pin VGA Extension Cable
Premium 15-Pin VGA Extension Cable. 15-Pin Male to 15-Pin Female.
MODEL LENGTH MSRP
VGA 306MF 6 ft. ..$17.50 VGA 310MF 10 ft. ..$25.75 VGA 315MF 15 ft. VGA 325MF 25 ft. VGA 350MF 50 ft. VGA 375MF 75 ft. VGA 3100MF 100 ft. ..$199.00
..$35.00 ..$55.00 ..$102.00 ..$151.00
15-Pin VGA Breakout Cable
VGA Video Breakout, 15-Pin Male to Five BNC Males.
Male
MODEL LENGTH MSRP
RGB 500.7 7 in. ..$19.50 RGB 501.5 1.5 ft. RGB 503 3 ft. ..$22.50 RGB 506 6 ft. RGB 510 10 ft. RGB 515 15 ft. RGB 520 20 ft.
Five BNC Males
..$21.00
..$27.00 ..$33.00 ..$36.00 ..$42.00
15-Pin VGA Breakout Cable with Ferrite Core
VGA Video Breakout with Interference-Reducing Ferrite Core, 15-Pin Male to Five BNC Males.
Male
MODEL LENGTH MSRP
RGB 506FR 6 ft. ..$30.00 RGB 510FR 10 ft. RGB 515FR 15 ft. RGB 520FR 20 ft.
Five BNC Males
..$36.00 ..$42.00 ..$45.00
20
2007 Retail Catalog
Audio / Visual Cable — VGA + Audio
15-Pin VGA Male + Two RCA Males to 15-Pin VGA Male +
3.5mm Stereo. Great for connecting a laptop to a video moni­tor.
MODEL LENGTH MSRP
VGM 305 5 ft. ..$21.25 VGM 310 10 ft. VGM 325 25 ft. ..$46.90
..$27.50
www.hosatech.com
Video Cables and Adaptors
Component Video Cable
Triplex 75 ohm Video Cable. Three RCA Males to Three RCA Males — colored Red, Blue, Green. Gold Plated finish.
MODEL LENGTH MSRP
VCC 302G 2M (6.6 ft.) ..$18.00 VCC 303G 3M (9.9 ft.) ..$24.00 VCC 304G 4M (13.2 ft.) ..$30.00 VCC 315G 15M (49.5 ft.) ..$96.00 VCC 330G 30M (99 ft.) ..$180.00
Audio / Visual Cable — VGA + Audio
15-Pin VGA Male + 3.5mm Audio. Audio connections are ste­reo 3.5mm males on each end. Use this cable for connecting laptops to projectors or other displays. Great for presenta­tions.
MODEL LENGTH MSRP
VGM 405 5 ft.
.. $21.25
BNC Video Snake
BNC Video Snake, Five BNC Males to Five BNC Males.
MODEL LENGTH MSRP
BNC 506FR 6 ft. ..$39.00 BNC 510FR 10 ft. BNC 515FR 15 ft. ..$57.00
..$47.00
A/V Camcorder Cable.
Works with Sony, Panasonic, JVC, and others. Special 4­Conductor Right Angle 3.5mm to Three RCA Connectors (Video plus Left and Right Audio).
Component Video Cable
Triplex 75 ohm Video Cable. Three RCA Males to Three RCA Males — colored Red, Blue, Green. Nickel Plated finish.
MODEL LENGTH MSRP
VCC 302 2M (6.6 ft.) ..$14.00 VCC 303 3M (9.9 ft.) ..$18.90 VCC 304 4M (13.2 ft.)
..$24.00
Audio Video Cables
The VRA Series combines stereo audio cables with a single 75 ohm composite video cable. Just like those that come with VCR’s and DVD players. RCA Male to RCA Male.
MODEL LENGTH MSRP
VRA 300.5 0.5M (1.65 ft.) ..$7.00 VRA 301 1M (3.3 ft.) ..$8.50 VRA 302 2M (6.6 ft.) ..$10.00 VRA 303 3M (9.9 ft.) ..$12.00 VRA 304 4M (13.2 ft.) ..$14.25 VRA 305 5M (16.5 ft.) ..$15.75 VRA 308 8M (26.4 ft.) ..$23.00 VRA 315 15M (49.5 ft.) ..$38.00 VRA 330 30M (99 ft.) ..$72.00
Audio Video Cables
The VSR Series combines stereo audio cables with a single S-Video cable. Excellent for DVD players. RCA Male to RCA Male.
4-Conductor 3.5mm Plug carries Stereo Audio plus Video.
MODEL LENGTH MSRP
C3M 103 3 ft. ..$8.25 C3M 105 5 ft. C3M 110 10 ft. ..$10.50
..$8.75
MODEL LENGTH MSRP
VSR 302 2M (6.6 ft.) ..$14.25 VSR 303 3M (9.9 ft.) VSR 304 4M (13.2 ft.)
..$17.25 ..$20.75
21
www.hosatech.com
2007 Retail Catalog
S-Video Cable
26AWG Stranded Copper Conductors, Gold Plated Pins.
MODEL LENGTH MSRP
SVC 105G 5 ft. ..$8.70 SVC 110G 10 ft. SVC 115G 15 ft. SVC 125G 25 ft. SVC 150G 50 ft. SVC 1100G 100 ft.
..$9.75 ..$11.25 ..$14.85 ..$25.50 ..$46.95
S-Video Breakout
S-Video to Two RCA Males.
Video Cables and Adaptors
MODEL LENGTH MSRP
VSA 356 6 ft. ..$12.00
S-Video Breakout
S-Video to Two BNC Males.
S- Video Breakout
S-Video Male to RCA Female. Sums Y and C.
MODEL LENGTH MSRP
SVR 456 6 in.
..$3.90
Video Adaptor
DVI-I Male to 15-Pin VGA Female
Front
MODEL MSRP
NDV 431
..$9.75
Back
Video Adaptor
Coupler / Gender Changer, 9­Pin Female to 9-Pin Female.
MODEL LENGTH MSRP
VSB 346 6 ft.
..$16.00
S-Video Breakout
S-Video Male to Two S-Video Females.
MODEL LENGTH MSRP
VSS 453 10 in. ..$8.40
S-Video Breakout
S-Video to Two BNC Females.
MODEL LENGTH MSRP
VSB 455 10 in. ..$13.50
MODEL MSRP
GGC 301
..$6.00
Video Adaptor
Coupler / Gender Changer, 15­Pin Female to 15-Pin Female. With machine nuts.
MODEL MSRP
GGC 451
..$8.00
Video Adaptor
HDMI Male to DVI-D Female.
MODEL MSRP
NDH 444
..$31.00
Video Adaptor
22
S-Video Breakout
S-Video Male to Two RCA Females.
MODEL LENGTH MSRP
VSF 454 10 in.
..$5.40
HDMI Female to DVI-D Male.
MODEL MSRP
NDH 445 ..$31.00
Loading...
+ 50 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
