The Warm Front controller fitted to your new heating system is designed to provide an
economical but comfortable pattern of heating whilst also being very easy to use.
To increase
warm setting
press
To decrease
the warm
setting
press
To switch
between warm
and cool settings
press
Please see reverse for full user instructions
The controller contains
a heating pattern that
has already been set
up for you by the
installer and the built
in clock adjusts itself
for Summer and Winter
time. You can change
the room temperature
by pressing the '+' or '-'
buttons. You can
switch between warm
or cool by pressing the
round middle button.
The '+' and '-' buttons
only work in the warm
mode which is when
red lights are on.
All the buttons can be
used as often as you
like and you will not
damage the controller
or your heating system.
USING THE WARM FRONT ROOM THERMOSTAT
Warm is shown by red lights (6) and Cool is shown by a
blue light (5). The centre button (3) marked 'Warm /
Cool' allows you to toggle between warm and cool
settings.
When one or more red lights are on, you can increase
the temperature by pressing the '+' button (1). For
example, press once to go up by 1 degree C, or press
twice to go up by 2 degrees C.
When the two or three red lights are on, the temperature can also be lowered to the centre position by
using the '-' button (2). For example, press once to go
down to the central temperature and press again to go
down to one degree below central temperature.
The Blue light means the unit is working to the lower
temperature and the '+' or '-' buttons do not work when
this blue light is on.
Under the flap (7) is a Blue button (4). During the summer, or when you want your central heating off for long periods, for example
if you go on holiday, press the Blue button and close the flap. When you want to go back to normal operation, open the flap and
press the Blue button again, remembering to close the flap once finished.
User Operations
1
4
2
3
5
6
7
