Horizon Hobby FLZU1012 User Manual

®

™

Fokker D.VII

Instruction

Manual

WARNING: This product may use a lithium polymer (LiPo) battery. Improper handling may result in FIRE! You are
responsible for following all safety precautions as outlined in this instruction manual.

NOTICE

All instructions, warranties and other collateral documents are subject to change at the sole discretion
of Horizon Hobby, LLC. For up-to-date product literature, visit www.horizonhobby.com and click on
the support tab for this product.

Meaning of Special Language

The following terms are used throughout the product literature to indicate various levels of potential
harm when operating this product:

WARNING: Procedures, which if not properly followed, create the probability of property damage,
collateral damage, and serious injury OR create a high probability of super cial injury.

CAUTION: Procedures, which if not properly followed, create the probability of physical property
damage AND a possibility of serious injury.

NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage
AND little or no possibility of injury.

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the
product before operating. Failure to operate the product correctly can result in damage to the

product, personal property and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and common sense and
requires some basic mechanical ability. Failure to operate this product in a safe and responsible
manner could result in injury or damage to the product or other property. This product is not intended
for use by children without direct adult supervision. Do not use with incompatible components
or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This
manual contains instructions for safety, operation and maintenance. It is essential to read and follow
all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate
correctly and avoid damage or serious injury.

AGE RECOMMENDATION: Not for children under 14 years. This is not a toy.

+

14

INCLUDED ITEMS

Transmi t ter

AA Batteries

2

Fokker D.VII

Check the parts against those
shown. If any parts are damaged or
missing, please call Horizon Product
Support at: [phone]

LiPo Battery

FLZU1014 Batter y 1S 80 mAh

LiPo: Flyzone Micro

FCC INFORMATION

FCC ID: BRWFLZU1012

This equipment has been tested and found to comply with the limits for Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:

● Reorient or relocate the receiving antenna.

● Increase the separation between the equipment and receiver.

● Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

This devic e complie s with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.

NOTICE: Modifications to this product will void the user’s authority to operate this equipment.

3

PRECAUTIONS

Your Micro Fokker D.VII model should not be considered a toy, but rather a sophisticated, working
model that functions very much like a full-size airplane. Because of its performance capabilities, the
model, if not assembled and operated correctly, could possibly cause injury to yourself or spectators
and damage to property.

1. Operate the plane according to the instructions. DO NOT alter or modify the model. If you make any
modifications, you void your warranty.

2. Test the operation of the model before each flight to ensure that all equipment is operating properly
and that the model remains structurally sound.

3. Fly only indoors or outdoors on very calm days (with wind speeds less than 5 mph) and in large open
areas free of trees, people, buildings, or any other obstacles.

4. Although the model is designed to be successfully flown by the first time pilot, you may still benefit
from the assistance of an experienced pilot for your first flights. If you’re not a member of an R/C
club, your local hobby shop has information about clubs in your area whose membership includes
experienced pilots. You can also contact the National Academy of Aeronautics (AMA) which has
over 2,500 chartered clubs across the country. Instructor training programs and insured newcomer
training are available through any of these clubs. Contact the AMA at the following address or toll­free phone number:

Academy of Model Aeronautics

5151 East Memorial Drive Ph. [phone]
Muncie, IN 47302-9252 Fx. [phone]
www.modelaircraft.org

The R/C model hobby becomes more and more enjoyable as your experience grows. Your chances
for success and graduation to higher levels are very good if you take your time and follow the flying
instructions carefully and completely. We hope you enjoy flying your Micro Fokker D.VII model.

TRANSMITTER CAUTIONS

● Do not use rechargeable (NiCd) batteries.

● Do not mix old and new batteries.

● Do not mix alkaline, standard (carbon-zinc) or rechargeable (NiCd) batteries.

CHARGING WARNINGS

CAUTION: All instructio n s and warnings must be followed exa c tly. Misha n dling of Li-Po bat teries

can result in a fire, personal injury and/or property damage.

● NEVER LEAVE CHARGING BATTERIES UNATTENDED.

● NEVER CHARGE BATTERIES OVERNIGHT.

● By handling, charging or using the included Li-Po battery, you assume all risks associated with

lithium batteries.

● If at any time the battery begins to balloon or swell, discontinue use immediately. If charging or
discharging, discontinue and disconnect. Continuing to use, charge or discharge a battery that
is ballooning or swelling can result in fire.

4

● Always store the battery at room temperature in a dry area for best results.

● Always transport or store the battery in a temperature range of 40–120º F (5–49° C).

● Do not store battery or model in a car or direct sunlight. If stored in a hot car, the battery can

be damaged or even catch fire.

● Always charge batteries away from flammable materials.

● Always inspect the battery before charging.

● Always disconnect the battery after charging, and let the charger cool between charges.

● Always constantly monitor the temperature of the battery pack while charging.

● ONLY USE A CHARGER SPECIFICALLY DESIGNED TO CHARGE LI-PO BATTERIES. Failure to

charge the battery with a compatible charger may cause a fi re resulting in personal injury and/
or property damage.

● Never discharge Li-Po cells to below 3V under load.

● Never cover warning labels with hook and loop strips.

● Never charge batteries outside recommended levels.

● Never charge damaged batteries.

● Never attempt to dismantle or alter the charger.

● Never allow minors to charge battery packs.

● Never charge batteries in extremely hot or cold places (recommended between 40–120° F or

(5–49° C) or place in direct sunlight.

BATTERY CHARGING PRECAUTIONS

1. Always remove the battery from the model before charging.

2. Do not leave a charging battery unattended! Unplug the battery if it gets warm, even if the charge

LED has not gone out.

3. Charge on a fireproof surface away from potentially flammable objects.

4. Use only the charger built into the included transmitter!

WARNING: Misuse or malfunction may overheat the battery and charger, resulting in personal
injury or damage to surroundings.

LITHIUM POLYMER BATTERY RECYCLING
ATTENTION: The product you have purchased is powered by a rechargeable battery. At the

end of the battery’s useful life, under various state and local laws, it may be illegal to dispose
of this battery into the municipal waste system. Check with your local solid waste officials for
details in your area for recycling options or proper disposal.

WARNING: This product contains a chemical known to the State of California to cause cancer.
