Hoover SX70-HU04001, SX70-HU03 User Manual
USER MANUAL (GB) ..............................P 01
MANUEL D’UTILISATION (FR) ...............P 05
BEDIENUNGSANLEITUNG (DE) ..........P 09
Q*
P
O
CA
M1**
HF
M2**
R
®
S*
K*
L*
D
H
E
T*
I*
B
C
F
A
G
U*
w
PRINTED IN P.R.C.
48013562
®
1
M**
GP
N**
J
* Certain models only
V*
** Certain models only, nozzles may vary according to model
2 3 4 5
***
14
Max
15
16
17
* *
6
*
**
7 8 9
** **
10 11 12 13
18
19
20
* Certain models only
21
** Certain models only, nozzles may vary according to model
GB
INSTRUCTIONS FOR SAFE USE
This appliance should only be used for domestic cleaning,
as described in this user guide. Please ensure that this
guide is fully understood before operating the appliance.
Do not leave the appliance plugged in. Always switch off
and remove the plug from the socket after use, or before
cleaning the appliance or any maintenance task.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
If the power cord is damaged stop using the appliance
immediately. To avoid a safety hazard, an authorised
HOOVER service engineer must replace the power cord.
Keep hands, feet, loose clothing and hair away from rotating
brushes.
Use only attachments, consumables or spares recommended
or supplied by HOOVER.
Do not spray with or pick up ammable liquids, cleaning
uids, aerosols or their vapours.
Do not run over the power cord when using your appliance
or remove the plug by pulling on the power cord.
Do not continue to use your appliance if it appears faulty.
HOOVER service: To ensure the continued safe and efcient
operation of this appliance we recommend that any servicing
or repairs are only carried out by an authorised HOOVER
service engineer.
Do not stand on or wrap the cord around arms or legs when
using your appliance.
Do not use the appliance to clean animals or people.
Do not position the appliance above you when cleaning the
stairs.
The Environment
The symbol on this appliance indicates that this appliance may not be treated
as household waste. Instead it must be handed over to the applicable collection
point for the recycling of electrical and electronic equipment. Disposal must
be carried out in accordance with local environmental regulations for waste
disposal. For more detailed information about treatment, recovery and recycling
of this appliance, please contact your local city ofce, your household and waste disposal
service or the shop where you purchased the appliance.
Static electricity: Some carpets can cause a small build up of
static electricity. Any static discharge is not hazardous to health.
Do not use your appliance out of doors or on any wet surface
or for wet pick up.
Do not pick up hard or sharp objects, matches, hot ashes,
cigarette ends or other similar items.
1
This appliance complies with the European Directives 2006/95/EC, 2004/108/EC
and 2011/65/EU.
HOOVER Limited, Pentrebach, Merthyr Tydl, Mid Glamorgan, CF48 4TU, UK
GETTING TO KNOW YOUR CLEANER
A. Cleaner Main Body
B. Dust Container
C. Dust Container Release Latch
D. Dust Container Door Release Button
E. Pre Motor Filter
F. On/Off Button
G. Cord Rewind Button
H. Cleaner Carry Handle
I. Variable Power Control Slider*
J. Park Slot
K. Telescopic Tube*
L. Telescopic Tube Adjuster*
M. Carpet and Floor nozzle (GP)**
M1. Carpet Nozzle (CA)**
M2. Hard Floor Nozzle (HF)**
N. Floor Type Selector**
O. Hose
P. Hose Handle
Q. Suction Regulator*
R. 2 in 1 Tool: Crevice tool + Dusting Brush
S. Pet Hair Remover Mini Turbo Nozzle*
T. Allergy Remover Mini Turbo Nozzle*
U. Grand Turbo Nozzle*
V. Parquet Nozzle*
W. Exhaust Filter
GB
Emptying the Dust Container the red marker. [5]
2. Adjust the telescopic tube* to the desired height by moving the telescopic tube adjuster*
up and raise or lower the handle to the most comfortable cleaning position. [6]
3. Carpet & Floor Nozzle. Press the oor type selector on the nozzle [7] to select the ideal
cleaning mode for the oor type.
Carpet – Brushes are raised for the deepest clean.
4. Switch the cleaner on by pressing the on/off button on the cleaner main body.
5. Adjust the power level by sliding the variable power control slider* on carry handle.
6. Adjust the suction regulator to the desired level.
7. Switch off at the end of use by pressing the on/off button. Unplug and press the cord
8. To store your cleaner adjust telescopic tube* to the lowest height setting and park the
Hard Floor – Brushes are lowered to protect the oor.
[10]
rewind button to rewind the power cord back into the cleaner. [11]
nozzle in the park slot on the cleaner main body. [12]
[8]
[9]
ACCESSORIES
#1
To obtain the best performance and energy efciency
correct nozzles are used for the main cleaning operations. These nozzles are indicated
in the diagrams by the letters GP, HF or CA.
A nozzle type GP can be used to clean both carpet and hard oor.
A nozzle type HF is suitable for use only on hard oor.
A nozzle of type CA is suitable for use only on carpet.
The other nozzles are accessories for specialist cleaning tasks and are recommended
for occasional use only.
It is important to note that this vacuum cleaner is supplied with an Energy Label as
required by European Regulation (EU) 665/2013.
it is recommended that the
ASSEMBLING YOUR CLEANER
Remove all components from the packaging.
1. Connect the hose to the cleaner main body, rotate clockwise and ensure it locks into
position. To release: anticlockwise the hose end and pull. [2]
2. Connect the handle to the tube upper end. [3]
3. Connect the tube lower end to carpet and oor nozzle. [4]
USING YOUR CLEANER
1. Extract power cord and plug it into the power supply. Do not pull the cord beyond
*Certain Models Only ** Certain models only, nozzles may vary according to model
If the label shows a red prohibition circle on the left covering the carpet symbol, then this
indicates that the vacuum cleaner is not suitable use on carpets.
If the label shows a red prohibition circle on the right covering the hard oor symbol, then
this indicates that the vacuum cleaner is not suitable for use on hard oors.
#1
NOTE: Dust pick up ability carpet, dust pick up ability hard oor, and energy efciency
in accord with Commission Regulations (EU) 665/2013 and (EU) 666/2013.
All accessories can be tted to the end of the hose handle or the end of the tube.
2 in 1 tool
underneath the hose handle. [1R]
Crevice Tool
– Combines several functions in one.The 2 in 1 tool can be stored neatly
– For corners and hard to reach areas.
2
Dusting Brush – For bookshelves, frames, keyboards and other delicate areas. To
B. Check if there is any other blockage in the system -Use a rod or pole to remove
extend the brushes push the button on the body of the tool.
Parquet Nozzle** – For wooden oors and other delicate oors. [1V]
Pet Hair Remover Mini Turbo Nozzle* - Use the mini turbo nozzle on stairs or for
deepcleaning on textile surfaces and other hard to clean areas. Particularly suitable for
pet hairs removal. [1S]
Allergen Remover Mini Turbo Nozzle* – Use the mini turbo nozzle on stairs or for
deepcleaning on textile surfaces and other hard to clean areas. Particularly suitable for
allergen removal. [1T]
Grand Turbo Nozzle* – Use the turbo nozzle for deep cleaning on carpets. [1U]
IMPORTANT: Do not use the Grand turbo and mini turbo nozzles on rugs with long
fringes, animal hides and carpet pile deeper than 15mm. Do not keep the nozzle station
ary while the brush is rotating.
CLEANER MAINTENANCE
GB
4. Separate the mesh from the pre-motor lter by rotating it anti clockwise from the
pre-motor lter. [17]
5. Gently tap and wash the lter and mesh, [18] Do not use hot water or detergents. Remove
excess water from the lter and mesh and leave to dry fully before re-using. [21]
6. Reassemble the lter pack once fully dry and ret to the cleaner.
IMPORTANT: Always ensure the lter pack is fully dry before use.
IMPORTANT: Do not use the product without the lter pack tted.
To access the exhaust lter:
1. Unclip the exhaust lter pack from the rear of the cleaner . [19]
2. Separate the grey foam lter from the holder. Gently tap and wash the grey foam
lter using warm water.[20] Do not use hot water or detergents. Remove excess
water from the lter and leave to dry fully before reusing. [21]
Removing a blockage
1. Check if the dust container is full. If so refer to ‘Emptying the dust container.
2. If the dust container is empty but suction is still low:
A. Do the lter need cleaning ? If so refer to ‘Cleaning the washable lters’
Emptying the Dust Container
When the dust reaches the max level indicator in the container, empty the dust container.
IMPORTANT: To maintain optimum performance do not allow the dust to sit higher than
the max level.
1. Release the Dust Container by lifting the Dust Container Release Latch. Lift the
Dust Container from the cleaner mainbody. [13]
2. To empty, hold the Dust Container over a bin with one hand, and use another hand
to press the Dust Container Door Release Button. [14]
3. Close the Dust Container door and ret to the cleaner main body.
Cleaning the washable lters
The cleaner is tted with a pre-motor lter pack. To maintain optimum cleaning
performance regularly remove the lters and tap them against the side of bin to release
dust. The lters should be washed after every 5 container empties or when the lter has
excessive dust levels.
MPORTANT: CLEAN FILTERS REGULARLY
Dirty lters affect performance, cause air blockage and motor failure. Failure to
clean the lters may affect your Hoover guarantee.
1. Release the Dust Container by lifting the Dust Container Release Latch, Lift the
Dust Container from the cleaner mainbody. [13]
2. Hold the Dust Container over a bin with one hand, and separate the dust bin from
the dust bin lid to access the pre-motor lter pack [15]
3. Remove the lter pack by rotating it anti-clockwise from Dust Container lid. [16]
*Certain Models Only ** Certain models only, nozzles may vary according to model
any blockage from the extension tube or exible hose.
C. Check if pre-motor lter is lted.
USER CHECKLIST
Should you have a problem with the product, complete this simple user checklist
before calling your local Hoover service.
• Is there a working electricity supply to the cleaner? Please check with another
electrical appliance.
• Is the dust container over-filled? Please refer to ‘Cleaner Maintenance’.
• Is the filter blocked? Please refer to ‘Cleaner Maintenance’.
• Is the hose or nozzle blocked? Please refer to ‘Removing a blockage from the
system’.
• Has the cleaner overheated? If so, it will take approximately 30 minutes to automatically reset. CLEANING FAQS
IMPORTANT INFORMATION
Hoover spares and Consumables
Always replace parts with genuine Hoover spares. These are available from your local
Hoover dealer or direct from Hoover. When ordering parts always quote your model number.
3
