Hoover HWCB 15, HWCB 45, HWCB 60, HWCB 60D, HWCB 30 User Manual

Wine Coolers

USER MANUAL

HWCB 15 HWCB 30 HWCB 45 HWCB 60 HWCB 60D

NOTE: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference, for you or any person not familiar with the operation of the appliance.

EN Ver.2/2016

--CONTENTS--

01 SAFETY INFORMATION 03 SCRAPPING OLD APPLIANCES

03 Conformity 03 Energy Saving 04 Service

04 DESCRIPTION OF APPLIANCE

04 Product Features 06 Control Panel 06 Interior light 07 The Wine Cooler shelves

07 USING YOUR WINE COOLER

07 Before Switching On 08 During First Use 08 Turning The Appliance On And Off 08 Unlocking The Control Panel 09 The Interior Light 09 Setting The Temperature Range 10 Setting The Temperature 11 Changing Between Fahrenheit And Celsius 11 Silent Mode 11 Function Indicator 12 Loading The Wine Cooler 14 Storing Your Wines 15 Wine Storage Problems

16 CLEANING AND MAINTENANCE

17 Removing The Shelves For Cleaning 18 Carbon Filter Change 19 Defrosting 19 Moving Your Wine Cooler 19 Power Failure 20 Vacation Time 20 Disconnecting From Power

21 INSTALLATION

21 Electrical Connection 21 Positioning 22 Built-In Installation 27 Adjusting the height and levelling off your wine cabinet 27 Installing The Handle 28 Reversing The Door Of Your Wine Cooler

34 TROUBLESHOOTING 36 TECHNICAL DATA

Thank you for purchasing this product.

Before using your Wine Coolers, please carefully read this instruction manual in order to maximize its performance. Store all documentation for subsequent use or for other owners. This product is intended solely for household use or similar applications such as:

--the kitchen area for personnel in shops, offices and other working environments

--on farms, by clientele of hotels, motels and other environments of a residential type

--at bed and breakfasts (B & B)

--for catering services and similar applications not for retail sale. This appliance must be used only for purposes of storage of food, any other use is considered dangerous and the manufacturer will not be responsible for any omissions. Also, it is recommended that you take note of the warranty conditions.

SAFETY INFORMATION

The Wine Coolers contains a refrigerant gas (R600a: isobutane) and insulating gas (cyclopentane), with high compatibility with the environment, that are, however, inflammable. We recommend that you follow the following regulations so as to avoid situations dangerous to you:

Before performing any operation, unplug the power cord from the power socket.

● The refrigeration system positioned behind and inside the Wine Coolers

contains refrigerant. Therefore, avoid damaging the tubes.

● If in the refrigeration system a leak is noted, do not touch the wall outlet

and do not use open ames. Open the window and let air into the room.

Then call a service centre to ask for repair.

● Do not scrape with a knife or sharp object to remove frost or ice that

occurs. With these, the refrigerant circuit can be damaged, the spill from

which can cause a re or damage your eyes.

● Do not install the appliance in humid, oily or dusty places, nor expose it

to direct sunlight and to water.

● Do not install the appliance near heaters or inammable materials.

● Do not use extension cords or adapters.

● Do not excessively pull or fold the power cord or touch the plug with wet

hands.

.01.

● Do not damage the plug and/or the power cord; this could cause electrical shocks or res.

● It is recommended to keep the plug clean, any excessive dust residues on the plug can be the cause re.

● Do not use mechanical devices or other equipment to hasten the defrosting

process.

● Absolutely avoid the use of open ame or electrical equipment, such as

heaters, steam cleaners, candles, oil lamps and the like in order to speed up the defrosting phase.

● Do not use or store inflammable sprays, such as spray paint, near the Wine Coolers. It could cause an explosion or  re.

● Do not use electrical appliances inside the food storage compartments,

unless they are of the type recommended by the manufacturer.

● Do not place or store inflammable and highly volatile materials such

as ether, petrol, LPG, propane gas, aerosol spray cans, adhesives, pure alcohol, etc. These materials may cause an explosion.

● Do not store medicine or research materials in the Wine Coolers. When the material that requires a strict control of storage temperatures is to

be stored, it is possible that it will deteriorate or an uncontrolled reaction may occur that can cause risks.

● Maintain the ventilation openings in the appliance enclosure or in the

built-in structure, free of obstruction.

● Do not place objects and/or containers lled with water on the top of the

appliance.

● Do not perform repairs on this Wine Coolers. All interventions must be performed solely by qualied personnel.

● This appliance can be used by children aged from 8 years and above

and by persons with reduced physical, sensory or mental capabilities or

with a lack of experience and knowledge; provided that they have been given adequate supervision or instruction concerning how to use the

appliance in a safe way and understand the hazards involved.

● Children should not play with the appliance. Cleaning and user

maintenance should not be made by children without supervision

.02.

SCRAPPING OLD APPLIANCES

This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE).

WEEE contains both polluting substances (which can cause negative

consequences for the environment) and basic components (which can be re-used). It is important to have WEEE subjected to specic treatments,

in order to remove and dispose properly all pollutants, and recover and recycle all materials. Individuals can play an important role in ensuring that WEEE does not

become an environmental issue; it is essential to follow some basic rules:

--WEEE should not be treated as household waste;

--WEEE should be handed over to the relevant collection points managed

by the municipality or by registered companies. In many countries, for large WEEE, home collection could be present.

In many countries, when you buy a new appliance, the old one may be returned to the retailer who has to collect it free of charge on a one-to-one

basis, as long as the equipment is of equivalent type and has the same functions as the supplied equipment.

Conformity

By placing the marking on this product, we declare, on our own responsibility, compliance to all of European safety ,health and

environmental requirements stated in the legislation for this product.

Energy Saving

--Always ensure good ventilation. Do not cover ventilation opening or grille.

--Always keep fan louvers clear.

--Do not place appliance in areas of direct sunlight or close to a stove, heather or similar object.

--Open or keep the doors open as little as possible

--Remove dust present on the rear of the appliance

.03.

Service

● You should not attempt to repair the appliance

yourself, as this could cause injury or a more serious malfunction. If you require a service call then please contact the Customer Care Department

DESCRIPTION OF APPLIANCE

Product Features

HWCB 15: Single Zone--7 Bottles

HWCB 30: Single Zone--19 Bottles

A. Control Panel

B. Glass Door

C. Handle

D. Beech Shelves

E. Front Vent

F. Adjustable Foot

A. Control Panel

B. Glass Door

C. Handle

D. Beech Shelves

E. Front Vent

F. Adjustable Foot

.04.

HWCB 45: Single Zone--18 Bottles

Beech Shelves

HWCB 60: Dual Zone--46 Bottles

Control Panel

Glass Door

Handle

E F

HWCB 60D: 2 Single Zones (Left & Right)--19+19 Bottles

A. Glass Door

B. Control Panel

C. Handle

D. Beech Shelves

E. Front Vent

F. Adjustable Foot

A1. Control Panel (Left

A2. Control Panel (Right

B. Glass Door

C. Handle

D. Beech Shelves

E. Front Vent

F. Adjustable Foot

）

.05.

Control Panel

ºC/ºF

A B DC E

Single Zone：HWCB 15, HWCB 30,HWCB 45, HWCB 60D

A. Power B. Lighting C. Display Window D. Temp. Plus E. Temp.Minus

F. Lock / Unlock G. Function Indicator H.

*HWCB 60D is without Function Indicator

G H

Switch

Dual Zone：HWCB 60

A. Power B. Lighting C.

Lock/ Unlock

ºC/ºF

Switch

G H I J K

Upper Zone Display Window

Function Indicator 1

D. Temp. Plus E. Temp.Minus

Lower Zone

Display Window

Function

Indicator 2

K. Zone Select

Interior light

Note:

call aftersales center to get a new one. A replacement made by unqualified people without supervision from electrical engineer would result in electrical shock and injury. o The cooling zone has an interior light. The light can be switched on and

This LED light has a long life time. Once it is broken, it is mandatory to

off by using the light button.

.06.

The Wine Cooler shelves

o To prevent damaging the door gasket, make sure the door is fully open

when pulling shelves out of the rail compartment.

o For easy access to the bottles stored, pull the shelves out approximately

1/3 of the way.

o For a model without telescopic rails, 2 plastic Stoppers of each shelf is on

left and right side of the interior cabinet to prevent the shelf from falling out.

A. Stopper

o For a model with telescopic rail, 2 Stoppers is xed on each rail base.

A. Stopper

USING YOUR WINE COOLER

Before Switching On

o Make sure that it has been installed by a suitably qualied person, as per

the information contained in the installation instructions.

o After delivery, wait for eight hours before connecting the appliance to

your mains supply. This will allow any refrigerant gasses that may have been disturbed during the transportation process to settle.

o The outside of the appliance and the removable accessories contained

within it, should be cleaned with a solution of liquid detergent and water.

o The interior of the appliance should be cleaned with a solution of sodium bicarbonate dissolved in lukewarm water. The interior and accessories should be thoroughly dried, after the cleaning process has been completed.

.07.

o There can be an odour when you first switch on the appliance. It will

lessen as the appliance starts to cool.

During First Use

IMPORTANT: When you use the Wine Cooler for the rst time or restart the appliance after it has been turned off for a long time, there could be a few degrees variance between the temperature you select and the one indicated on the LED display. This is normal and it is due to the length of activation time. Once the Wine Cooler has been running for a few hours everything will be back to normal.

o When you first switch on the appliance, the compressor will run

continuously until the Wine Cooler reaches a cool enough temperature.

o During this period of time, you should try not to open the door frequently

or place bottles inside of the appliance.

o If the unit is switched off or unplugged, you must allow at least 5 minutes

before restarting the appliance or reconnecting it to your mains supply.

Turning The Appliance On And Off

HWCB 15, HWCB 30,HWCB 45. HWCB 60, HWCB 60D

o When the Wine Cooler is connected to the power outlet it will turn on

automatically.

o Press and hold the power button for 10 seconds to turn the appliance on and off.

o Even if the safety lock is activated, the appliance can still be turned off

by pressing and holding the power button for 10 seconds.

* For HWCB 60D, the power of Left and Right Zone will be turn off/on at the

same time no matter the operation above on Left or Right Zone.

Unlocking The Control Panel

HWCB 15, HWCB 30,HWCB 45. HWCB 60, HWCB 60D

o To unlock the control panel, press the power and light buttons simultaneously for 3 seconds. A beep will sound to indicate that the control panel has unlocked.

o The control panel will automatically lock after 10 seconds if no buttons

are pressed. A beep will sound to indicate that the control panel has locked.

o When the control panel is locked, no buttons can be operated except

for the power button to turn the appliance off.

.08.

The Interior Light

HWCB 15, HWCB 30,HWCB 45. HWCB 60, HWCB 60D

o When the control panel is unlocked, you can use the light button to switch the interior light on and off. o The light will remain on unless it is turned off manually by pressing the light button.

Setting The Temperature Range

o The appliance is with 4 temperature ranges for option, the ranges list of

each model is as below.

o To change temperature range, when the control panel is locked, press the temperature minus button for 3 seconds, the

display window will ash "E"--"F"--"H"--"L" in loop with a sound of

beep by every pressing.

o Leave the display window ashing for 3 seconds, a beep will sound to

indicate that the setting is conrmed.

HWCB 15, HWCB 30,HWCB 45, HWCB 60D

o The default range of Single Zone is E: 5-22 ºC (41-72 ºF).

Display Temp. Range (Single Zone)

* For

HWCB 60D

ºF) for Left Zone, F:

E (Default) 5 - 22 °C (41

F 2 - 20 °C (36

H 10 - 19 °C (50

L 0 - 20 °C (36

, the defualt temperature setting range is E: 5-22 ºC (41-72

2 - 20 °C (36

ºF-68ºF)

for Right Zone.

ºF-72ºF)

ºF-68ºF)

ºF-66ºF)

ºF-68ºF)

HWCB 60

o The default range of Dual Zone is

12-22 ºC (54-72 ºF) for the lower zone

Display

Upper Zone Lower Zone

E (Default) 5 - 12 °C (41

F 2 - 12 °C (36

H 5 - 12°C (41

L 2 - 10 °C (36

Temp.Range (Dual Zone)

ºF-54ºF)

ºF-50ºF)

E: 5-12 ºC (41-54 ºF) for the upper zone and

12 - 22 °C (54

12 - 20 °C (54

8 - 19 °C (46

12 - 22 °C (54

.09.

ºF-72ºF)

ºF-68ºF)

ºF-66ºF)

ºF-72ºF)

Setting The Temperature

HWCB 15, HWCB 30,HWCB 45, HWCB 60D

o Use the temperature plus button and minus button to select the

temperature you want the Wine Coolers to operate at.

o Each press of the temperature plus button will increase the set temperature by 1°C/1°F.

o Each press of the temperature minus button will decrease the set temperature by 1°C/1°F.

o The first touch of these buttons will automatically set the previous set

temperature.

o When the display shows the desired temperature, release all buttons and

the display will change to show the actual temperature inside of the cabinet after about 10 seconds.

HWCB 60

o Use the zone selection button to choose which zone you want

to set the temperature for. The relevant LED display will ash to

show you can set the temperature for that zone.

o Use the temperature plus and minus buttons to select the temperature

you want the wine cabinet to operate at.

o The first touch of these buttons will automatically set the previous set temperature.

o Each press of the temperature plus button will increase the set temperature by 1°C/1°F. Each press of the temperature minus button will decrease the set temperature by 1°C/1°F.

o When the display shows the desired temperature release all buttons and

the display will change to show the actual temperature inside of the cabinet after about 10 seconds.

.10.

+ 26 hidden pages
