Hoover HOC709-6BX, HOC1060-6X, HOC709-6X, HOC024-6X, HOC1060-6B User Manual

...
OVENS
USER INSTRUCTIONS
FIRIN
KULLANMA KILAVUZU
FORNI
HOC024/6X HOC1060/6B HOC1060/6X HOC709/6BX HOC709/6X HCM906/6BPP
GB
TR
IT
CANDY HOOVER GROUP S.R.L. • Via Privata Eden Fumagalli • 20047 Brugherio Milano Italy
CONTENTS
Safety Instructions
1. General Warnings
1.1 Declaration Of Compliance
1.2 Safety Hints
1.3 Installation
1.4 Fitting The Oven Into The Kitchen Unit
1.5 Important
1.6 Connecting To The Power Supply
1.7 Oven Equipment (according To The Model)
1.8 Removing and cleaning wiıre racks
2. Useful Tips
2.1 Shelf Safety System
2.2 Grilling
2.3 Cooking Time
2.4 Cleaning And Maintenance
2.5 Hydro Easy Clean Function
2.6 Service Centre
3. Timer
3.1 Using The Minute Minder
3.2 Using The End Of Cooking Timer
3.3 Use Of The Electronic Programmer (6 Buttons)
3.4 Setting The Correct Time
3.5 Use Of The Electronic Programmer (touch)
3.6 Setting The Correct Time
3.7 Use Of Touch Control Clock Programmer
3. Setting The Correct Time8
4. Operating Instructions
5. Tables Of Cooking Times
................................................................................05
...................................................................................06
.................................................................03
...............................................................04
.................................................04
........................................................................04
...........................................................................04
..............................04
............................................................................04
......................................04
.......................04
....................................05
...........................................................................05
...........................................................05
.....................................................................05
.................................................05
...............................................05
....................................................................05
...................................................06
.......................................06
....................................................06
.......................07
...................................................07
.........................08
...................................................08
......................................................09
.............................................10-11
GB
................06
İÇİNDEKİLER
Güvenlik Uyarıları
1. Genel Uyarılar
1.1 Uygunluk Beyanı
1.2 Güvenlik İpuçları
1.3 Kurulum
1.4 Fırının Mutfak Ünitesine Montajı
1.5 Önemli Not
1.6 Cihazın Elektrik Bağlantısının Yapılması
1.7 Fırın Ekipmanları (modele Göre)
1.8 Yan ızgaraların çıkarılması ve temizlenmesi
2. Faydalı İpuçları
2.1 Raf Güvenliği Sistemi
2.2 Izgara
2.3 Pişirme Süreleri
2.4 Cihazın Temizlenmesi Ve Bakımı
2.5 Kolay Temizlenme Fonksiyonu
2.6 Servis Merkezi
3. Zamanlayıcı
3.1 Zaman Sayacının Kurulması
3.2 Pişirme Süresi Zamanlayıcısının Ayarlanması
3.3 Elektronik Programlayıcının Kullanılması (6 Buton)
3.4 Saatin Ayarlanması
3.5 Elektronik Programlayıcının Kullanılması (Dokunmatik)
3.6 Saatin Ayarlanmas
3.7 Dokunmatik Zamanlayıcı
3.8 Saatin Ayarlanması
4. Kullanma Talimatları
5. Pişirme Süresi Tabloları
..................................................................................14
...................................................................12
.....................................................................13
................................................................13
.................................................................13
..............................................................................13
.........................................13
..........................................................................13
.............................13
.........................................13
.......................14
....................................................................14
..........................................................14
..................................................................14
........................................14
..........................................14
...................................................................14
........................................................................15
..............................................15
.................15
...........15
.............................................................15
.............................................................16
...................................................17
............................................................17
..........................................................18
................................................19-20
TR
.....16
CONTENUTO
Indicazioni Di Sicurezza
1. Avvertenze Generali
1.1 Dichiarazione Di Conformità
1.2 Informazioni Sulla Sicurezza
1.3 Installazione
1.4 Inserimento Del Mobile
1.5 Importante
1.6 Allacciamento Elettrico
1.7 Dotazione Del Forno (secondo Modello)
1.8 Rimozione e pulizia delle griglie
2. Consıglı Utili
2.1 Griglie Forno - Sistema Di Arresto
2.2 La Cottura Al Grıll
2.3 Tempı Di Cottura
2.4 Pulizia E Manutenzione
2.5
La Funzione Hydro Easy Clean
2.6 Servizio Assistenza Clienti
3. Temporizzatore
3.1 Uso Del Contaminuti
3.2 Uso Del Temporizzatore
3.3 Uso Del Programmatore Elettronico (6 Tasto)
3.4 Regolazione Ora
3.5 Uso Del Programmatore Elettronico
3.6 Regolazione Ora
3.7 Timer Elettronico A Sfioramento
3.8 Regolazione Ora
4. Istruzioni Per L’uso
5. Tabella Tempi Di Cottura
.......................................................................23
............................................................................23
....................................................................23
.......................................................................24
.......................................................22
.........................................................22
...............................................22
..............................................22
......................................................23
.......................................................23
...........................23
......................................24
...............................................................24
...............................................................24
....................................................24
..........................................................24
................................................24
...................................................................25
.........................................................25
...................................................25
................................................................25
...................................26
...............................................................26
........................................27
................................................................27
...........................................................28
..............................................29-30
IT
....................25
SAFETY INSTRUCTIONS
WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements.
• Children under 8 Year of age must be kept away from the appliance unless they are continuously supervised.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
• Children must not play with the appliance.
• Cleaning and user maintenance shall not be made by children without supervision.
• During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven. WARNING: Accessible parts may become hot during use. Young children must be kept away.
• Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
• The oven must be switched off before removing the guard, after cleaning, the guard must be replaced in accordance with the instructions.
• Only use the temperature probe recommended for this oven.
• Do not use a steam cleaner for cleaning operations.
• WARNING: Avoid possibility of electric shock - ensure the appliance is switched off before replacing the lamp.
• The means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.
• The instructions state the type of cord to be used, taking into account the temperature of the rear surface of the appliance.
• If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or its service agent.
• CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cutout, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility. CAUTION: Accessible parts may be hot when the grill is in use. Young children must be kept away.
• Excess spillage must be removed before cleaning.
• During self-cleaning pyrolytic operation the surfaces may get hotter than usual and children MUST be kept away.
03 GB
1. GENERAL WARNINGS
Thank you for choosing one of our products. To get the most out of your oven we recommend that you:
• Read the notes in this manual carefully: they contain important instructions on how to install, use and service this oven safely.
• Keep this booklet in a safe place for easy, future reference. All accessible parts are hot when the appliance is in operation, take care to not touch these elements. When the oven is first switched on it may give out acrid smelling fumes. This is because the bonding agent for insulating panels around the oven has been heated up for the first time. This is a completely normal, if it does occur you merely have to wait for the fumes to clear before putting the food into the oven. An oven by its very nature becomes very hot. Especially the glass of the oven door.
1.1 DECLARATION OF COMPLIANCE
The parts of this appliance that may come into contact with foodstuffs comply with the provisions of EEC Directive 89/109. Appliance
complies with European Directives 73/23/EEC and 89/336/EEC, replaced by 2006/95/EC and 2004/108/EC, and
subsequent amendments. When you have unpacked the oven, make sure that it has not been damaged in any way. If you have any doubts at all, do not use it: contact a professionally qualified person. Keep packing materials such as plastic bags, polystyrene, or nails out of the reach of children because they are dangerous for children.
1.2 SAFETY HINTS
•The oven must be used only for the purpose for which it was designed: it must only be used for cooking food. Any other use, e.g. as a form of heating, is an improper use of the oven and is therefore dangerous.
•The manufacturers cannot be held responsible for any damage caused by improper, incorrect or unreasonable use. When using any
electrical appliance you must follow a few basic rules.
– Do not pull on the power cable to remove the plug from the socket. – Do not touch the oven with wet or damp hands or feet. – Do not use the oven unless you are wearing something on your feet. – It is not generally a good idea to use adapters, multiple sockets for several plugs and cable extensions. – If the oven breaks down or develops a fault switch it off at the mains and do not touch it.
•If the cable is at all damaged it must be replaced promptly. When replacing the cable, follow these instructions. Remove the power cable and replace it with one of the H05RRF, H05VV-F, H05V2V2-F type. The cable must be able to bear the electrical current required by the oven. Cable replacement must be carried out by properly qualified technicians. The earthing cable (yellow-green) must be 10 mm longer than the power cable. Use only an approved service centre for repairs and ensure that only original parts are used. If the above instructions are not adhered to the manufacturers cannot guarantee the safety of the oven.
•Do not line the oven walls with aluminium foil or single-use protection available from stores. Aluminium foil or any other protection, in direct contact with the hot enamel, risks melting and deteriorating the enamel of the insides.
1.3 INSTALLATION
Installation is the customer’s responsibility. The manufacturers have no obligation to carry this out. If the assistance of the manufacturer is required to rectify faults arising from incorrect installation, this assistance is not covered by the guarantee. The installation instructions for professionally qualified personal must be followed. Incorrect installation may cause harm or injury to people, animals or belongings. The manufacturer cannot be held responsible for such harm or injury.
1.4 FITTING THE OVEN INTO THE KITCHEN UNIT
Fit the oven into the space provided in the kitchen unit; it may be fitted underneath a work top or into an upright cupboard. Fix the oven in position by screwing into place, using the two fixing holes in the frame.(Fig.on last page). To locate the fixing holes, open the oven door and look inside.To allow adequate ventilation, the measurements and distances indicated in the diagram on last page must be adhered to when fixing the oven. Note: For ovens that are combined with a hob unit the instructions contained in the manual for the hob unit must be followed.
1.5 IMPORTANT
If the oven is to work properly, the kitchen housing must be suitable. The panels of the kitchen unit that are next to the oven must be made of a heat resistant material. Ensure that the glues of units made of veneered wood can withstand temperatures of at least 120 °C. Plastics or glues that cannot withstand such temperatures will melt and deform the unit. Once the oven has been lodged inside the unit, the electrical parts must be completely insulated. This is a legal safety requirement. All guards must be firmly fixed into place so that it is impossible to remove them without using special tools.
Remove the back of the kitchen unit to ensure an adequate current of air circulates around the oven. The hob must have a rear gap of at least 45 mm.
1.6 CONNECTING TO THE POWER SUPPLY
Plug into the power supply. Ensure first that there is a third contact that acts as earthing for the oven. The oven must be properly earthed. If the model of oven is not fitted with a plug, fit a standard plug to the power cable. It must be able to bear the power supply indicated on the specifications plate. The earthing cable is yellowgreen. The plug must be fitted by a properly qualified person. If the socket and the plug are incompatible the socket must be changed by a properly qualified person.A properly qualified person must also ensure that the power cables can carry the current required to operate the oven. An ON/OFF switch may also be connected to the power supply. The connections must take account of the current supplied and must comply with current legal requirements. The yellow-green earthing cable must not be governed by the ON/OFF switch. The socket or the ON/OFF switch used for connecting to the power supply must be easily accessible when the oven has been installed. Important: During installation, position the power cable in such a way that it will not be subjected to temperatures of above 50°C at any point. The oven complies with safety standards set by the regulatory bodies. The oven is safe to use only if it has been adequately earthed in compliance with current legal requirements on wiring safety. You must ensure that the oven has been adequately earthed.
The manufacturers cannot be held responsible for any harm or injury to persons, animals or belongings caused by failure to properly earth the oven. WARNING: the voltage and the supply frequency are showed on the rating plate (fig. on last page).
The cabling and wiring system must be able to bear the maximum electric power required by the oven. This is indicated on the specifications plate. If you are in any doubt at all, use the services of a professionally qualified person.
1.7 OVEN EQUIPMENT (according to the model)
It is necessary to do an initial cleaning of the equipment before the first use of each of them.Wash them with a sponge. Rinse and dry off. The simple shelf can take moulds and
dishes. The tray holder shelf is especially good for grilling things. Use it with the drip tray.
The special profile of the shelves means they stay horizontal even when pulled right out. There is no risk of a dish sliding or spilling.
04 GB
The drip tray catches the juices from grilled foods. It is only used with the Grill, Rotisserie, or Fan Assisted Grill ; remove it from the oven for other cooking methods.
Never use the drip tray as a roasting tray as this creates smoke and fat will spatter your oven making it dirty.
The pizza set is designed for pizza cooking. In order to obtain the best results the set must be used together with Pizza function.
The tray holder
The tray holder shelf is ideal for grilling. Use it in conjunction with the drip tray. A handle is included to assist in moving the both accessories safely. Do no leave the handle inside the oven.
1.8 Removing and cleaning wiıre racks
1- Remove the knurled nuts by turning them counter clockwise. 2- Remove the wire racks by pulling them towards yourself. 3- To clean the wire racks either put them in the dishwasher or use a wet sponge, ensuring that they are dried afterwards. 4- After the cleaning process install the wire racks in reverse order. 5- Replace the knurled nuts.
2. USEFUL TIPS
2.1 SHELF SAFETY SYSTEM
The oven features a new shelf safety system. This allows you to pull out the oven shelves when inspecting the food without danger of food spillages or shelves falling accidentally out of the oven. To remove the shelves pull out and lift.
2.2 GRILLING
Grilling makes it possible to give food a rich brown colour quickly. For browning we recommend that you insert the grill onto the fourth level, depending on the proportions of the food (see fig. page 08). Almost all food can be cooked under the grill except for very lean game and meat rolls. Meat and fish that are going to be grilled should first be lightly doused with oil.
2.5 HYDRO EASY CLEAN FUNCTION
The HYDRO EASY CLEAN procedure uses steam to help remove remaining fat and food particles from the oven.
1. Pour 300 ml of water into the HYDRO EASY CLEAN container at the bottom of the oven.
2. Set the oven function to Static ( )or Bottom ( )heater
3. Set the temperature to the HYDRO EASY CLEAN icon
4. Allow the program to operate for 30 minutes.
5. After 30 minutes switch off the program and allow the oven to cool down.
6. When the appliance is cool, clean the inner surfaces of the oven with a cloth.
Warning
Make sure that the appliance is cool before you touch it. Care must be taken with all hot surfaces as there is a risk of burns. Use distilled or drinkable water.
A
2.3 COOKING TIME
For recommended cooking times and temperatures the first time you use the oven, refer to the tables on pages 08, 09. You may then wish to vary these times and settings in the light of your own experience.
2.4 CLEANING AND MAINTENANCE
Clean the stainless steel and enamelled surfaces with warm, soapy water or with suitable brand products. On no account use abrasive powders that may damage surfaces and ruin the oven’s appearance. It is very important to clean the oven each time that it is used. Melted fat is deposited on the sides of the oven during cooking. The next time the oven is used this fat could cause unpleasant odours and might even jeopardise the success of the cooking. Use hot water and detergent to clean; rinse out thoroughly. To make this chore unnecessary all models can be lined with catalytic self-cleaning panels: these are supplied as an optional extra (see the section SELF-CLEANING OVEN WITH CATALYTIC LINING). Use detergents and abrasive metal pads like «brillo pads» for the stainless steel grills. The glass surfaces as the top, oven door and warming compartment door must be cleaned when they are cold. Damage that occurs to them because this rule was not adhered to are not covered by the guarantee. To replace the interior light: . switch off the mains power supply and unscrew bulb. Replace with an identical bulb that can withstand very high temperatures
300 ml
2.6 SERVICE CENTRE
Before calling the Service Centre
If the oven is not working, we recommend that: you check that the oven is properly plugged into the power supply.
If the cause of the fault cannot be detected: disconnect the oven from the mains, do not touch the oven and call the after sales service.
Before calling the Service Centre remember to make a note of the serial number on the specifications plate (see fig. On last page).
The oven is supplied with a guarantee certificate that ensures that it will be repaired free of charge by the Service Centre
05 GB
3. TIMER
3.1 USING THE MINUTE MINDER 3.2 USING THE END OF COOKING TIMER
To set the cooking time, turn dial one complete revolution and then position the index to the required time. When the time has lapsed, the signal will ring for a few seconds.
120
110
100
90
3.3 USE OF THE ELECTRONIC PROGRAMMER (6 BUTTONS)
FUNCTION
MINUTE MINDER
MANUAL
FUNCTION
COOKING
TIME
HOW TO ACTIVATE IT
•Press and hold the button
•Press the buttons or to set the required time
•Release all the buttons
•Press the button
•Set the cooking function with the oven function selector
•Press and hold the TIMER button
•Press the buttons or to set the lenght of cooking required
•Release all buttons
•Set the cooking function with the oven function selector
HOW TO SWITCH IT OFF WHAT IT DOES WHAT IT IS FOR
•When the set time as elapsed an audible alarm is activated (this alarm will stop on its own, however it can be stopped immediately by pressing the button)
•Turn the oven function selector to position O.
•When the time is elapsed the oven will switch off automatically. Should you wish to stop cooking earlier either turn the function selector to 0, or set time to 0:00 (TIMER and buttons)
This control enables to set the desired cooking time (max. 120 min.) the oven will automatically switch off at the end of
30
the set time. The timer will count down from the set
40
time return to the O position and switch
50
off automatically. For normal use of oven set the timer to the position. To set the oven ensure the timer is not on the O position.
80
70
10
20
60
•Sounds an alarm at the end of the set time.
•To check how long is left to run press the button
•Enables you to operate the oven.
•It allows to preset the cooking time required for the recipe chosen
•To check how long is left to run press the TIMER button.
•To alter/change the preset time press TIMER and buttons
•Allows to use the oven as alarm clock (could be activated either with operating the oven or with out operating the oven)
•For cooking the desired recipes
•At the end of the cooking set time, the oven will switch off automatically and an audible alarm will ring.
•At the time set, the oven will switch off. To switch off manually, turn the oven function selector to position O.
END OF
COOKING
•Press and hold the END button
•Press the buttons to set the time at which you wish the oven to switch off
•Release the buttons
•Set the cooking function with the oven function selector
3.4 SETTING THE CORRECT TIME
WARNING : the first operation to carry out after the oven has been installed or following the interruption of power supply (this is recognizable the display pulsating and showing ) is setting the correct time. This is achieved as follows
• Press and hold the TIMER and END buttons ( and TIMER on some models
• Set time with buttons
• Release all buttons
ATTENTION the oven only operates if set on manual function or preset time. N.B.: on some models the symbols are replaced by and
•Enables you to set the end of cooking time
•To check the preset time press the END button
•To modify the preset time press buttons END +
•This function is typically used with “cooking time” function. For example if the dish has to be cooked for 45 minutes and needs to be ready by 12:30, simply select the required function, set the cooking time to 45 minutes and the end of cooking time to 12:30.
•Cooking will start auto­matically at 11:45 (12:30 minus 45 mins) and will continue until the pre-set end-of-cooking-time, when the oven will switch itself off automatically.
WARNING. If the END of cooking is selected without setting the length of cooking time, the oven will start cooking immediately and it will stop at the END of cooking time set.
06 GB
3.5 USE OF THE ELECTRONIC PROGRAMMER (TOUCH)
•Child Lock function is activated by touching Set
KEY LOCK
(+) for a minimum of 5 seconds until the Child Lock symbol is displayed. From this moment on all other function are locked.
3.6 SETTING THE CORRECT TIME
WARNING : the first operation to carry out after the oven has been installed or following the interruption of power supply (this is recognizable the display pulsating and showing This is achieved as follows
•Push the central button 1 times
•Set time with ▼ ▲ buttons.
•Release all buttons.
•Child Lock function is deactivated by touching touchpad Set (+) again for a minimum of 5 seconds until the Child Lock symbol switches off. From this moment on all functions are selectable again.
12:00 ) is setting the correct time.
L1, L2, L3 SET ACUSTIC SIGNAL
• Push the central button 5 times.
• Set time with ▼ ▲ buttons.
• Release all buttons.
07 GB
3.7 USE OF TOUCH CONTROL CLOCK PROGRAMMER
FUNCTION
MINUTE
MINDER
COOKING
TIME
END OF
COOKING
KEY LOCK
HOW TO ACTIVATE IT
•Push the central button 1 times
•Press the buttons " to set the required time
•Release all the buttons
•Push the central button 2 times
•Press the buttons
-" or "+"
" to set the lenght of cooking required
•Release all buttons
•Set the cooking function with the oven function selector
•Push the central button 3 times
•Press the buttons to set the time at which you wish the oven to switch off
•Release the buttons
•Set the cooking function with the oven function selector
•Child Lock function is activated by touching Set (+) for a minimum of 5 seconds. From this moment on all other function are locked and the display will flash STOP and preset time intermittently.
-" "+"
"-" "+"
HOWTO SWITCH ITOFF WHAT IT DOES WHAT IT IS FOR
•When the set time as elapsed an audible alarm is activated (this alarm will stop on its own, however it can be stopped immediately by pressing the button) SELECT.
•When the time is elapsed the oven will switch off automatically. Should you wish to stop cooking earlier either turn the function selector to 0, or set time to 0:00 (SELECT and
-" "+" buttons)
"
•At the time set, the oven will switch off. To switch off manually, turn the oven function selector to position O.
•Child Lock function is deactivated by touching touchpad Set (+) again for a minimum of 5 seconds. From this moment on all functions are selectable again.
•Sounds an alarm at the end of the set time.
•During the process, the display shows the remaining time.
•It allows to preset the cooking time required for the recipe chosen
•To check how long is left to run press the SELECT button 2 Times.
•To alter/change the preset time press SELECT
-
" "+" buttons
and "
•Enables you to set the end of cooking time
•To check the preset time push the central button 3 times
•To modify the preset time press buttons SELECT + "
-" "+"
•Allows to use the oven as alarm clock (could be activated either with operating the oven or with out operating the oven)
•Push any button to stop the signal. Push the central button to return to the clock function
•This function is typically used with “cooking time” function. For example if the dish has to be cooked for 45 minutes and needs to be ready by 12:30, simply select the required function, set the cooking time to 45 minutes and the end of cooking time to 12:30.
•At the end of the cooking set time, the oven will switch off automatically and an audible alarm will ring.
•Cooking will start automatically at 11:45 (12:30 minus 45 mins) and will continue until the pre-set end­of-cooking-time, when the oven will switch itself off automatically.
WARNING. If the END of cooking is selected without setting the length of cooking time, the oven will start cooking immediately and it will stop at the END of cooking time set.
3.8 SETTING THE CORRECT TIME
WARNING : the first operation to carry out after the oven has been installed or following the interruption of power supply (this is recognizable the display pulsating and showing
00:00

ATTENTION: The oven will only operate providing the clock is set.
is achieved as follows
•Push the central button 4 times
•Set time with
•Release all buttons.
"-" "+" buttons.
12:00 ) is setting the correct time. This
08 GB
4. OPERATING INSTRUCTIONS
Temperature
pre-set and
Function
dial
setting.
(Model with
electronic
programmer)
(Type A)
220
50 ÷ 240
200
50 ÷ 230
Thermostat
dial
50 ÷ MAX
50 ÷ MAX
Function
Turns on the oven light This will automatically activate the cooling fan (on fan cooled models only)
Defrosting
When the dial is set to this position. The fan circulates air at room temperature around the, frozen food so that it defrosts in a few minutes without the protein content of the food being changed or altered
Natural convection
Bottom and top oven elements are used. This is the traditional form of baking and roasting. It is ideal for roasting joints of meat and game, baking biscuits and apples and making the food nice and crunchy.
Fan cooking
Both top and bottom heating elements are used with the fan circulating the air inside the oven. We recommend you use this method for poultry, pastries, fish and vegetables. Heat penetrates into the food better and both the cooking and preheating times are reduced. You can cook different foods at the same time with or without the same preparation in one or more positions. This cooking method gives even heat distribution and the smells are not mixed. Allow about ten minutes extra when cooking foods at the same time.
160
50 ÷ 200
Level 4
1 ÷ 4
190
180 ÷ 200
Level 4
1 ÷ 4
220
* Tested in accordance with the CENELEC EN 50304. ** Tested in accordance with the CENELEC EN 50304 used for definition of energy class.
50 ÷ MAX
50 ÷ MAX
50 ÷ 200
50 ÷ 200
50 ÷ MAX
Fan plus lower element
This function is ideal for delicate dishes (pies-souffle).
GRILL: use the grill with the door closed.
The top heating element is used alone and you can adjust the temperature. Five minutes preheating is required to get the elements red-hot. Success is guaranteed for grills, kebabs and gratin dishes. White meats should be put at a distance from the grill; the cooking time is longer, but the meat will be tastier. You can put red meats and fish fillets on the shelf with the drip tray underneath.
FAN ASSISTED GRILL (a): use the turbo-grill with the door closed.
The top heating element is used with the fan circulating the air inside the oven. Preheating is necessary for red meats but not for white meats. Ideal for cooking thick food items, whole pieces such as roast pork, poultry, etc. Place the food to be grilled directly on the shelf centrally, at the middle level. Slide the drip tray under the shelf to collect the juices. Make sure that the food is not too close to the grill. Turn the food over halfway through cooking.
Grill/spit element.
This is used for roasting on the spit.
Function Pizza
This function with hot air circulated in the oven ensure perfect result for dishes such as pizza or focaccia.
09 GB
5. TABLES OF COOKING TIMES
The overall suggested cooking times set out below are intended as a rough guide only. They may in fact vary according to the quality, the freshness, the size and the thickness of the food cooked and of course cooking time is also partly a matter of taste. Let the food stand for a few minutes before serving because the ingredients continue cooking after they have been removed from the oven.
HANDY TIP: Lower the temperature so as to avoid the surface of the food becoming hard and dry.
Static electric oven
Food
Quantity
Shelf
Time of cooking in minutes
Oven
tempe-
rature
• Pasta
Lasagne
Cannelloni Oven baked
pasta
Kg 3,5
Kg 1,8
Kg 2,5
22 22 22
70 ÷ 75
50 ÷ 60
55 ÷ 60
220
220
220
• Baking (not cakes)
Bread
Pizza
Pastry (frozen) vol au vents
Focaccia (n° 4)
Kg 1
di pasta
Kg 1
n° 24
gr. 200 of
dough each
22
35 10
(pre-heating)
25 ÷ 35
30 ÷ 35
25 ÷ 30
200
190
220
200
• Meat
Electric fan oven
Shelf
of cooking in minutes
(pre-heating)
11
21
22
Shelf position
Time
60 ÷ 65
40 ÷ 50
45 ÷ 50
30 ÷ 35
10
20 ÷ 25
25 ÷ 30
20 ÷ 25
Oven
tempe-
rature
200
200
200
180
190
200
180
4 3 2 1
Remarks
Put the lasagne into an unheated oven
Put the cannelloni into an unheated oven
Put the oven baked pasta into an unheated oven
Form the dough into a loaf and make a cross with a knife on top of the dough leave the dought to rise for at least 2 hours. Grease the baking tin and put the dough in the middle of it.
Warm the oven for 15 minutes and place the pizzas on the greased baking tray. Garnish them with tomatoes, mozzarella, ham, oil, salt and origano.
Place 24 vol au vents in the oven and bake.
Warm the oven for 15 minutes, grease the baking tray, season the 4 focaccia with oil and salt and leave them to rise at room temperature for at least 2 hours before put ting them in the oven.
All meats can be roasted in shallow or deep roasting trays. It is advisable to cover the shallow trays to avoid splattering the sides of the oven with grease. The roasting times are the same whether the meat has been covered up or not.
Whole joint of beef
Joint of deboned
Joint of deboned veal
Joint of fillet of beef
• Fish
• Fish
Trout
Salmon
Sole
Bream
Kg 1
Kg 1
Kg 1,3
Kg 1
3 whole trout
or / Kg 1
700 g
2,5 cm slice
Kg 1
2 whole ones
70 ÷ 80
100 ÷ 110
90 ÷ 110
80 ÷ 90
40 ÷ 45
30 ÷ 35
40 ÷ 45
40 ÷ 45 220
220
220
220
220
220
220
220
33
22
21
22
22
22
22
22
50 ÷ 60
80 ÷ 90
90 ÷ 100
80 ÷ 90
35 ÷ 40
30 ÷ 25
35 ÷ 40
35 ÷ 40
200
200
200
200
200
200
200
200
Put the meat into a deep Pyrex dish and season with salt and pepper; turn the meat half way through cooking.
Cook the meat in a covered Pyrex dish with herbs, spice, oil and butter.
Cook as indicated above
Cook as indicated above.
Cover the trout with salt, oil and onions and cook in a Pyrex dish.
Cook the salmon in an open Pyrex dish with salt, pepper and oil.
Cook the sole with salt and a spoonful of oil.
Cook the bream in oil and salt in a covered dish.
10 GB
TABLES OF COOKING TIMES
Electric fan oven
Shelf
of cooking in minutes
Time
Oven
tempe-
rature
Remarks
Food
Quantity
Static electric oven
Shelf
Time of cooking in minutes
Oven
tempe-
rature
• Rabbits and Poultry
Place the guinea fowl in a deep Pyrex or
Guinea fowl
Chicken
Rabbit pieces
Kg 1-1,3
Kg 1,5-1,7
Kg 1-1,2
22
22
22
60 ÷ 80
110 ÷ 120
55 ÷ 65
220
220
220
60 ÷ 70
100 ÷ 110
50 ÷ 60
200
200
200
pottery dish with very little oil and season with herbs and spices.
Follow the procedure for cooking the guinea fowl.
Put all the pieces of the same size in the glazed tray.Season with herbs and spices turn the pieces as and when required.
• Cakes
Coconut cake baked in a tin
Sponge cake
Carrot cake baked in a tin
Apricot pie
700 gr
1
1
1
1
55
55
65
40
180
175
180
200
1
1
1
2
50
40 ÷ 45
50 ÷ 60
30 ÷ 35
160
160
160
180
Use a tin that is 22 cm deep. Pre-heat for 10 mins.
Use a tin that is 22 cm deep. Pre-heat for 10 mins.
Use a tin that is 22 cm deep. Pre-heat for 10 mins.
Use a tin that is 22 cm deep. Pre-heat for 10 mins.
• Vegetable
Cut the fennel into four pieces, add butter,
Fennel
Courgettes
Potatoes
Carrots
800 gr
800 gr
800 gr
800 gr
1
1
2
1
70 ÷ 80
70
60 ÷ 65
80 ÷ 85
220
220
220
220
1
1
2
1
60 ÷ 70
60 ÷ 70
60 ÷ 65
70 ÷ 80
200
200
200
200
salt and potatoes if required and place in a Pyrex face up. Cover the dish.
Slice the courgettes, place in a Pyrex dish and add butter and salt.
Cut the potatoes into equal parts and place in a Pyrex dish. Season with salt, origano and rosemary. Cook in oil.
Slice the carrots, place in a Pyrex dish and cook.
• Fruit
Whole apples
Pears Peaches
Kg 1
Kg 1 Kg 1
1
1 1
45 ÷ 55
45 ÷ 55 45 ÷ 55
220
220 220
2
2 2
45 ÷ 55
45 ÷ 55 45 ÷ 55
200
200 200
Bake the fruit in an open Pyrex or earthen­ware dish. Leave it to cool inside the oven.
Follow procedure above.
Follow procedure above.
• Grilling
Place the food to be grilled underneath the infra-red grill. Warning: When the grill is on it takes on a bright red colour. Place the tray underneath the grill to collect juices and fat from the food being grilled.
Squares of bread for toasting
Toasted sandwiches
Sausages
Ribs of beef
Chicken legs
4 pieces
4
n°6 / Kg 0,9
n°4 / Kg 1,5
n°4 / Kg 1,5
5
(5 to heat up
44
grill)
Grill Grill
10
(10 to heat up
33
grill)
Grill Grill
25/30
(5 to heat up
44
44
33
grill)
25 (5 to
heat up grill)
50/60 (5 to
heat up grill)
Grill Grill
Grill Grill
Grill Grill
5
(10 to heat up
grill)
5/8
(10 to heat up
grill)
15/20
(10 to heat up
grill)
15/20 (10 to
heat up grill)
50/60 (10 to
heat up grill)
Lay the bread on the grill tray. When one side of the bread has been toasted, turn over and toast the other side. Remember: keep the toast warm at the bottom of the oven until you are ready to serve it.
Lay the bread on the grill tray. When one side of the sandwich has been toasted, turn over and toast the other side.
Cut the sausages in half and lay them face down on the grill. Half way through grilling turn them over. Every so often, check that they are being cooked equally all over. (If this is not happening, turn and reposition the ones being cooked ether less or more than the others.
Make sure that the ribs of beef are exposed to the full effect on the main grill.
Turn them over twice during grilling
11 GB
GÜVENLİK UYARILARI
UYARI: Cihaz ve aparatları kullanım sırasında ısınır. Isınmış parçalara dokunmaktan kaçınınız.
• 8 yaşın altındaki çocukları cihazdan uzakta tutmalı ve sürekli denetlemelisiniz.
• Bu cihaz, 8 yaş ve üzeri çocuklar ve fiziksel, duyusal veya zihinsel yetenekleri veya bilgi ve tecrübe açısından yetersiz kişiler tarafından ancak yetişkin bir bireyin denetiminde ve cihazın nasıl kullanılacağına dair verilen talimatların uygulanması durumunda ve oluşabilecek tehlikleri kavradıkları takdirde güvenle kullanılabilir.
• Çocuklar cihazla oynamamalıdırlar.
• Cihazın temizlik ve bakımı gözetmen olmaksızın çocuklar tarafından yapılmamalıdır.
• Kullanım sırasında cihaz ısınabilir. Fırının içindeki ısıtma elemanlarının dokunurken dikkatli olunmalıdır. UYARI: Erişilebilir parçalar kullanım sırasında ısınabilir. Küçük çocuklar uzak tutulmalıdır.
• Fırın kapak camını temizlerken kuvvetli aşındırıcı temizleyiciler veya keskin metal kazıyıcılar kullanmayın çünkü bu camın kırılmasına veya yüzeyin çizilmesine neden olabilir.
• Koruma çıkarılmadan önce fırın kapatılmalıdır ve temizlikten sonra koruma parçası talimatlara uygun olarak yerine koyulmalıdır.
• Sadece bu fırın için önerilen sıcaklık probu kullanın.
• Fırını temizlemerken buharlı temizleyiciler kullanmayınız. UYARI: Lambayı değiştirmeden önce elektrik çarpması olasılığını önlemek için cihazın kapalı olduğundan emin olun.
• Bağlantının sağlanamaması kablolama kurallarına göre kabloların bağlanmamasından kaynaklanmıştır.
• Talimatlarda kullanılacak prizin tipi cihazın arka kısmındaki sıcaklık düşünülerek belirtilmelidir.
• Elektrik kablosu hasarlı ise, özel bir kablo ya da üretici veya yetkili servisin uygun gördüğü kablo ile değiştirilmelidir. Uyarı: Termal ısı kesici dikkatsizce yerleşiminden doğacak zararları engellemek için, bu cihaz kaynağı zamanlayıcı veya sürekli açık ya da kapalı olacak devre gibi dış devre cihazlarına bağlanmamalıdır. DİKKAT: Erişilebilir parçalar sıcak olabilir ızgara kullanılırken Küçük çocuklar uzak tutulmalıdır.
• Dökülen artıklar temizliğe başlamadan önce çıkarılmalıdır.
• Kendi kendine temizlik pirolitik işlemi sırasında yüzey normalden sıcak olabilir, bu nedenle bu işlem esnasında çocuklar uzak tutulmalıdır.
12 TR
1. GENEL UYARILAR
Ürünlerimizden birini tercih etmiş olduğunuz için teşekkür ederiz. Fırınınızdan en yüksek faydayı sağlayabilmeniz için size şu önerilerde bulunuyoruz:
•Bu kullanma kılavuzundaki notları dikkatli bir şekilde okuyun: bu notlar, fırının monte edilmesine, kullanılmasına ve servisine ilişkin önemli talimatlar içerir.
•Bu kullanma kılavuzunu, daha sonra başvurmak üzere, kolayca erişebileceğiniz güvenli bir yerde saklayın.
•Cihaz çalışırken erişilebilir tüm parçaları ısınır. Isınan kısımlara dokunmamaya özen gösteriniz.
•Fırın ilk defa çalıştırıldığında yanık kokan dumanlar çıkartabilir. Bunun nedeni, fırının etrafındaki yalıtım panellerinin tutkallarının ilk defa ısınmasıdır. Bu tamamen normaldir ve sadece yiyecekleri fırın içerisine koymadan önce dumanın sona ermesini beklemeniz yeterlidir. Bir fırın doğası gereği son derece yüksek sıcaklıklara kadar ısınabilir. Özellikle de fırın kapağının camı son derece kızgın olabilir.
1.1 UYGUNLUK BEYANI
Bu cihazın yiyecekler ile temas edebilecek parçaları 89/109 sayılı EEC yönergesinin koşullarına uygundur.
Bu cihazlar 89/336/EEC, 73/23/EEC Avrupa direktiflerine uygundur. 2006/95/EC, 2004/108/EC ve sonradan ortaya çıkan
değişiklikler ile yer değiştirebilir. Fırını ambalajından çıkardığınızda, herhangi bir şekilde hasar görmemiş olduğundan emin olun. Herhangi bir şüpheye düşmeniz durumunda, cihazı kullanmayın: profesyonel uzman bir kişiye başvurun. Naylon torbalar, polistiren veya çiviler gibi ambalaj malzemelerini çocukların erişemeyecekleri yerlere kaldırın, çünkü bunlar çocuklar için tehlikeli olabilir.
1.2 GÜVENLİK İPUÇLARI
Fırın sadece tasarlanmış olduğu amaç için kullanılmalıdır: fırın sadece yiyeceklerin pişirilmesi için kullanılmalıdır. Fırının diğer bir kullanım, örneğin, ısınma amacı için, kullanılması uygun olmayan bir kullanım şeklidir ve bu nedenle tehlikelidir. Üreticiler, cihazın uygun olmayan, yanlış veya makul olmayan kullanımından dolayı herhangi bir şekilde sorumlu tutulamaz.
Herhangi bir elektrikli cihazı kullanırken bazı basit kurallara uyulması gerekir.
-Cihazın fişini elektrik prizinden çekerken elektrik kablosundan tutarak çekmeyin.
-Elleriniz veya ayaklarınız ıslak yada nemliyken fırına dokunmayın.
-Ayaklarınıza bir şey giymeden (çıplak ayaklarla) fırını kullanmayın.
-Genellikle adaptörlerin, çoklu prizlerin veya uzatma kablolarının kullanılması önerilmez.
-Fırının arızalanması veya bozukluğunun ortaya çıkması durumunda, cihazın şebeke elektriği beslemesini kapatın ve cihaza dokunmayın. Cihazın elektrik kablosunun hasar görmüş olması durumunda, bunun acilen değiştirilmesi gerekir. Cihazın elektrik kablosu değiştirilirken aşağıdaki talimatlara uyulmalıdır. Elektrik kablosunu sökün ve bunun yerine H055RR-F, H05VV-E, H05V2V2 tipi kauçuk içerisinde yalıtılmış olan aynı uzunlukta bir yeni elektrik kablosu takın. Elektrik kablosu fırının gerektirdiği elektrik akımına dayanabilmelidir. Cihazın elektrik kablosu konusunda uzman teknisyenler tarafından değiştirmelidir. Elektrik kablosunun topraklama iletkeni (sarı-yeşil) diğer elektrik kablosu iletkenlerinden 10 mm daha uzun olmalıdır. Cihazı sadece yetkili servis merkezlerinde tamir ettirin ve sadece orijinal parçaların kullanılmasını sağlayın. Yukarıdaki talimatlara uyulmaması durumunda üretici fırının güvenliğini garanti edemez.
•Fırının yan duvarlarını aluminyum folyo veya dükkanlardan alınabilen tek kullanımlık koruma malzemeleriyle kaplamayın. Aluminyum folyo veya diğer koruma malzemeleri sıcak emaye ile doğrudan temas ettiğinde erime ve iç taraftaki emayeyi bozma riski oluşturur.
1.3 KURULUM
Cihazın monte edilmesi müşterinin sorumluluğundadır. Üretici bunu gerçekleştirmekle yükümlü değildir. Yanlış montajdan kaynaklanan arızaların onarılması için üreticinin yardımı talep edildiğinde, bu yardım garanti dahilinde olmayacaktır. Profesyonel uzman personel için hazırlanmış olan montaj talimatlarına uyulmalıdır. Cihazın yanlış monte edilmesi, insanlara, hayvanlara veya eşyalara zarar verebilir, insanların veya hayvanların yaralanmasına neden olabilir. Üretici böyle bir zarar veya yaralanmadan sorumlu tutulamaz.
1.4 FIRININ MUTFAK ÜNİTESİNE MONTAJI
Fırını mutfak ünitesindeki yerine yerleştiriniz; fırın mutfak ünitesinde tezgah altına ya da dik bir mutfak dolabı içerisine yerleştirilebilir. Fırını ön çerçevesindeki 4 adet vida deliğini kullanarak yerleştirdiğiniz şekilde mutfak ünitesine vidalayarak sabitleyiniz. (Son sayfadaki resme bakınız.) Sabitleme vida delikleri için fırın kapısını açınız ve çerçevenin yanlarına bakınız. Uygun havalandırmanın sağlanması için klavuzun son sayfasındaki resimde belirtilen montaj ölçülerine göre fırını monte ediniz. Not: Ankastre ocaklı fırınlar için ocak klavuzunda belirtilen kurallara da muhakkak uyunuz.
1.5 ÖNEMLİ NOT
Fırının düzgün çalışması için mutfak içerisinde konulduğu yuva uygun olmalıdır. Mutfak dolaplarının fırının hemen bitişiğindeki panelleri ısıya dayanıklı malzemeden üretilmiş olmalıdır. Kaplamalı ahşaptan yapılmış mutfak dolaplarında en az 120°C sıcaklığa kadar dayanabilen tutkal kullanılmış olduğundan emin olun. Bu sıcaklıklara dayanamayacak plastikler veya tutkallar erir ve dolabın deforme olmasına neden olur. Fırının mutfak dolabı içerisine yerleştirilmesinden sonra, elektrikli parçalar tamamen yalıtılmalıdır. Bu, yasal bir güvenlik koşuludur. Bütün koruyucular, özel aletler kullanılmadan sökülmeler mümkün olmayacak şekilde, sıkıca yerlerine tespit edilmiş olmalıdır.
Fırın civarında yeterli hava dolaşımının sağlanabilmesi için, mutfak dolabının arkalığını sökün. Ocağın arkasında en az 45 mm yer bırakılmalıdır.
1.6 CİHAZIN ELEKTRİK BAĞLANTISININ YAPILMASI
Fırının elektrik fişini prize takın. Önce priz üzerinde topraklama görevini gören üçüncü bir kontağın bulunduğundan emin olun. Fırın uygun şekilde
topraklanmalıdır.
Fırının modelinde elektrik kablosunun ucuna bağlı bir elektrik fişi takılı değilse, elektrik kablosuna standart bir elektrik fişi takın. Takılan fişin cihazın tip etiketi üzerindeki özelliklerde belirtilen elektrik akımı ve gerilimi değerlerine dayanabilecek kapasitede olması gerekir. Topraklama kablosu sarı-yeşil renklidir. Fişin uzman bir kişi tarafından takılması gerekir. Fiş ile priz birbirine uymuyorsa, elektrik prizinin uzman bir kişi tarafından değiştirilmesi gerekir. Uzman kişinin ayrıca elektrik kablolarının fırını çalıştırmak için yeterli akımı kaldırabileceğini garanti etmesi de gerekir. Ayrıca elektrik şebekesine bir AÇMA/KAPATMA anahtarı da bağlanabilir. Bağlantılar yapılırken çekilecek akım dikkate alınmalı ve bölgenizde yürürlükte bulunan yasal koşullara uyulmalıdır. Sarı-yeşil topraklama kablosu AÇMA/KAPATMA anahtarı tarafından kontrol edilmemelidir. Elektrik prizine veya cihazın elektrik kablosunun bağlandığı AÇMA/ KAPATMA anahtarına fırının montajı tamamlandıktan sonra kolayca erişilebilmelidir. Önemli Not: Montaj esnasında cihazın elektrik kablosunu hiçbir noktasının 50°C sıcaklığın üzerindeki bir sıcaklığa maruz kalmayacak şekilde konumlandırın. Fırın düzenleyici kurumların saptamış olduğu güvenlik standartlarına uygundur. Fırın, ancak elektrik bağlantılarının güvenliğine ilişkin yerel yasal düzenlemelere uygun şekilde topraklanmış olması durumunda güvenli bir şekilde kullanılabilir. Fırının gereğince topraklanmış olduğundan emin olmalısınız.
Üretici, cihazın gereğince topraklanmamış olmasından dolayı insanların, hayvanların veya eşyaların zarar görmesinden ya da insanların veya hayvanların yaralanmasından sorumlu tutulamaz. UYARI: Cihazın gerilimi (voltajı) ve şebeke frekansı tip etiketi üzerinde belirtilmiştir (arka kapaktaki resme bakınız).
Kabloların ve kablo bağlantısı sisteminin fırının gereksinim duyacağı maksimum elektrik gücünü kaldıracak yeterlilikte olması gereklidir. Bu güç cihazın tip etiketi üzerinde belirtilmiştir. Şüpheye düşmeniz durumunda, profesyonel bir uzmandan yardım talep edin.
1.7 FIRIN EKİPMANLARI (modele göre)
Fırın ekipmanlarını ilk kullanımdan önce temizleyiniz. Sünger ile temizleyip yıkadıktan sonra kurulayınız.
Normal tel raf pişirme kapları veya tabakları için kullanılır.
Tepsi taşıyıcı tel raf özellikle ızgaralar için dizayn edilmiştir. Bu rafı damlama tepsisi ile birlikte kullanınız.
Tel raflar özel yapısı sayesinde fırından
dışarı doğru çekildiğinde bile yatay pozisyonda kalmaya devam eder. Kabın kayma ve yiyeceklerin dökülme riski yoktur.
13 TR
Damlama tepsisi, ızgara yapılan yiyecek-lerden damlayan sıvıları toplamak için kullanılır. Bu ekipman sadece ızgara ve fanlı ızgara fonksiyonları ile kullanılır; diğer pişirme fonksiyonlarında tepsiyi fırından alınız.
Koku yapması ve yağların tepsiden sıçrayarak fırını kirletmesi nedeniyle damlama tepsisini kesinlikle pişirme için kullanmayınız.
Pizza pişirme seti pizza pişirmek için tasarlanmıştır. İyi sonuç almak için Pizza fonksiyonu ile birlikte pizza tepsisini kullanınız.
Tepsi Tutacağı
Tepsi tutacağı ızgara tepsisi için idealdir ve damlama tepsisi ile birlikte kullanılmalıdır. Tutacak fırın içerisinde bırakılmamalıdır.
1.8 Yan ızgaraların çırarılması ve temizlenmesi
1- Sağ ve soldaki (A) yuvarlak, tırtıklı somunları, saatin tersi yönde çevirerek açın. 2- Tel rafları fırın duvarına ters yönde, kendinize doğru çekerek çıkarın. 3- Tel rafları bulaşık deterjanı, ılık su ve yumuşak bir bez ya da sünger kullanarak temizleyip kuru bir bezle kurulayın. 4- Temizlik işlemi ardından, tel rafları yerine takın. 5- Tırtıklı somunları sıkın.
2. FAYDALI İPUÇLARI
2.1 RAF GÜVENLİĞİ SİSTEMİ
Fırınınız yeni bir raf güvenliği özelliğine sahiptir. Bu sistem sayesinde pişirdiğiniz yiyecekleri kontrol etmek için fırın raflarını yiyeceklerin dökülmesi veya rafın düşme tehlikesi olmadan dışarıya doğru güvenli bir şekilde çekebilirsiniz. Rafları tamamen çıkartmak için dışarı çektikten sonra kaldırın.
2.2 IZGARA
Izgara yiyeceklere hızla zengin bir kahverengileşme kazandırılabilme­sine olanak sağlar. Yiyeceklerin kahverengileşerek kızarmaları için bunların yiyeceklerin orantılarına bağlı olarak dördüncü seviyeye konulmalarını öneriyoruz (şekil 15’teki şekle bakınız). Yağsız av hayvanları ile rulo etler haricinde kalan hemen hemen tüm yiyecekler ızgarada pişirilebilir. Izgara yapılacak olan et ve balıkların üzerine önce hafif sıvı yağ sürülmelidir.
2.5 KOLAY TEMİZLENME FONKSİYONU (HYDRO EASY CLEAN - )
Hydro easy clean buhar yardımı ile fırınınızdaki yağ ve yemek artıklarını temizler.
1. Fırınınızın Hydro Easy Clean – Kolay Temizlenme bölümüne 300 ml su ilave edin.
2. Fırınınızı sabit ( ) ya da taban ( )sıcaklığına ayarlayın.
3. Isı göstergesini Hyro Easy Clean – Kolay Temizlenme ( ) fonksiyonuna getirin.
4. Programı 30 dakika çalıştırın.
5. Cihaz soğuduğunda fırınınızın iç kısmını temiz bir bezle temizleyin.
Uyarı:
Cihazınıza dokunmadan önce soğuk olduğundan emin olun. Sıcak yüzeylerin yanık riski taşıdığını unutmayın. İçme suyu kullanın.
A
2.3 PİŞİRME SÜRELERİ
Fırını ilk defa kullanacağınızda, önerilen pişirme süreleri ile sıcaklıklar için 15-16 sayfalarda yer alan tablolara başvurun. Daha sonra deneyimleriniz doğrultusunda bu süreleri ve ayarları değiştirmek isteyebilirsiniz.
2.4 CİHAZIN TEMİZLENMESİ VE BAKIMI
Paslanmaz çelik ve emaye yüzeyleri ılık sabunlu su veya uygun markalı ürünler kullanarak temizleyin. Hiçbir zaman yüzeylere zarar verebilecek ve cihazın görünümünü bozabilecek aşındırıcı tozlar kullanmayın. Fırının her kullanıldıktan sonra temizlenmesi önemlidir. Eriyen yağlar pişirme esnasında fırının yanları üzerinde birikir. Fırının bir sonraki kullanımında bu yağlar arzu edilmeyen ve hoş olmayan kokulara neden olabilir ve hatta pişirilen yiyeceğin başarısını tehlikeye atabilir. Cihazı temizlemek için sıcak su ve deterjan kullanın; daha sonra iyice durulayın. Bu zorlu işi gereksiz hale getirebilmek üzere bütün modellere katalitik kendi kendini temizleyen paneller: bunlar isteğe bağlı ilave aksesuar olarak temin edilebilir. Paslanmaz çelikten yapılmış ızgara raflarını temizlemek için deterjan ve bulaşık telleri gibi aşındırıcı metal teller kullanın. Üst kısım, fırın kapası ve kapı iç yüzeyi gibi cam yüzeyler soğukken temizlenmelidir. Bu kurala uyulmaması sonucu ortaya çıkan hasarlar garanti kapsamına girmez. Dahili aydınlatma lambasının ampulünü değiştirmek için: cihazın elektrik beslemesini kesin (fişini prizden çekin) ve vidalı duylu ampulü döndürerek yerinden çıkartın. Çok yüksek sıcaklıklara dayanabilen aynı tipteki yeni bir ampulü yerine takın.
300 ml
2.6 SERVİS MERKEZİ
Servis merkezini aramadan önce Eğer fırın çalışmıyorsa, şunları yapmanızı öneririz:
-Fırının fişinin elektrik prizine sıkı bir şekilde takılmış olduğundan emin olacak şekilde fişi kontrol edin. Arızanın saptanamaması durumunda: Fırının fişini elektrik prizinden çekin. Fırına dokunmayın ve satış sonrası servisi arayın.
Servis merkezini aramadan önce cihazın tip etiket üzerinde yer alan seri numarasını bir yere not etmeyi unutmayın (arka kapaktati resme bakınız).
Cihaz ile birlikte cihazın Servis merkezinde ücretsiz olarak tamir edilmesini sağlayacak bir garanti belgesi verilir.
14 TR
3. ZAMANLAYICI
3.1 ZAMAN SAYACININ KURULMASI
Pişirme süresini ayarlamak için, kadran tam bir tur çevrilir ve daha sonra istenen zamanı gösteren pozisyona getirilir. Zaman geçtiğinde sinyal birkaç saniyeliğine çalacaktır.
3.2 PİŞİRME SÜRESİ ZAMANLAYICISININ AYARLANMASI
Bu kontrol istenen pişirme süresinin ayarlanmasını sağlar (maks. 120 dk.) Fırın
20
otomatik olarak ayarlanan süre sonunda
30
kapanacaktır.
40
Zamanlayıcı ayarlanan zamandan “O” pozisyonuna geri sayar ve otomatik olarak
50
kapanır. Zaman ayarı yapmadan fırını kullanmak istiyorsanız zamanlayıcıyı pozisyonuna getiriniz. Fırını istediğiniz fonksiyonda çalıştırmanız için zamanlayıcının “O” pozisyonunda olmaması gerekmektedir.
110
120
100
10
90
60
80
70
3.3 ELEKTRONİK PROGRAMLAYICININ KULLANILMASI (6 BUTON)
PROGRAM
ZAMAN SAYACI
MANUEL
PROGRAM
PİŞİRME
SÜRESİ
PROGRAMI
PİŞİRME
SONU
PROGRAMI
DEVREYE SOKULMASI
• düğmesine basıp düğmeyi basılı tutun.
•Arzu ettiğiniz süreyi ayarlamak için düğmelerine basın.
•Bütün düğmelere basmaya son verin.
• düğmesine basın.
•Fırın fonksiyon düğmesi ile pişirme fonksiyonunu ayarlayın.
•Timer (süre ayarı) düğmesine basıp düğmeyi basılı tutun.
•Arzu ettiğiniz pişirme süresini ayarlamak için düğmelerine basın.
•Bütün düğmelere basmaya son verin.
•Fırın fonksiyon düğmesi ile pişirme fonksiyonunu seçin.
•END (SON) düğmesine basıp düğmeyi basılı tutun
•Arzu ettiğiniz pişirmenin sona erme saatini ayarlamak için düğmelerine basın.
•Bütün düğmelere basmaya son verin.
•Fırın fonksiyon düğmesi ile pişirme fonksiyonunu seçin.
DEVREDEN ÇIKARILMASI
•Ayarlanmış olan süre sona erdiğinde, sesli bir alarm verilir (bu alarm kendiliğinden durur) ancak, düğmesine basılarak istendiği takdirde daha önce de durdurulabilir.
•Fırın fonksiyon düğmesini ( O ) konumuna getirin.
•Ayarlanmış olan süre sona erdiğinde, fırın otomatik olarak kapanır. Pişirme işlemini daha önce durdurmak istemeniz durumunda, fonksiyon düğmesini 0 konumuna getirin veya süreyi 0:00 olarak ayarlayın (Timer (Süre ayarı) ve düğmeleri)
•Ayarlanmış olan süre sona erdiğinde, fırın otomatik olarak kapanır. Pişirme işlemini kendiniz müdahale ederek durdurmak için fırın fonksiyon düğmesini O konumuna getirin.
•Ayarlanmış olan sürenin sonunda alarmı çaldırır.
•Ne kadar çalışma süresi kaldığını görmek için düğmesine basın
•Fırını çalıştırabilmenize olanak sağlar.
•Seçilmiş olan tarif için gerekli olan pişirme süresini ayarlayabilmenize olanak sağlar.
•Ne kadar çalışma süresi kaldığını görmek için Timer (Süre Ayarı) düğmesine basın.
•Programlanmış olan süreyi değiştirmek için Timer(Süre Ayarı) ve düğmelerine basın.
•Pişirme sonu zamanını ayarlayabilmenize olanak sağlar.
•Ayarlanmış olan saati kontrol etmek (görmek) için END (SON) düğmesine basın.
•Programlanmış olan saati değiştirmek için END (SON) ve düğmelerine basın.
İŞLEVİ
3.4 SAATİN AYARLANMASI
UYARI: Fırın yerine monte edilip elektrik bağlantısı yapıldığında veya elektrik beslemesi kesilip tekrar geri geldiğinde, gösterge yanıp sönmeye başlar. Bu aşamada saatin ( ) ayarlanması gerekir. Saat aşağıdaki gibi ayarlanır:
•TIMER (SÜRE AYARI) ve END (Pişirme sonu) düğmelerine (bazı modellerde ve TIMER ) basıp düğmeleri basılı tutun.
• düğmelerini kullanarak saati ayarlayın.
•Bütün düğmelere basmayı bırakın.
DİKKAT: Fırın sadece manuel kullanım veya zaman programlaması ayarlandığında çalıştırılabilir. Önemli Not: bazı modellerde sembollerinin yerine ve kullanılmıştır.
NE İÇİN KULLANILDIĞI
•Fırını bir alarmlı saat olarak kullanabilmenize olanak sağlar (fırın çalışırken de çalışmıyorken de kullanılabilir)
•Arzu ettiğiniz tarifleri pişirmeniz için kullanılır.
•Programlanmış (ayarlanmış) olan pişirme süresinin sonunda fırın otomatik olarak kapanır ve bir sesli alarm verilir.
•Bu işlev genellikle “pişirme süresi” işlevi ile birlikte kullanılır. Örneğin yiyeceğin pişme süresi 45 dakikaysa ve saat 12:30'da hazır olması gerekiyorsa, sadece pişirme süresini 45 dakikaya ve pişirme sonu saatini de 12:30' a ayarlamanız yeterlidir.
•Pişirme saat 11:45'de (12:30 eksi 45 dakika) otomatik olarak başlar ve programlanmış olan pişirme süresi (45dakika ) kadar sürdükten sonra fırın otomatik olarak kapanır.
UYARI:Pişirme sonu (END) programı pişirme süresi seçilmeden ayarlanmış olması durumunda, fırın hemen çalışmaya başlar ve programlanmış olan pişirme sonu saatine kadar çalışıp otomatik olarak durur.
15 TR
3.5 ELEKTRONİK PROGRAMLAYICININ KULLANILMASI (DOKUNMATİK)
PROGRAM
ZAMAN SAYACI
MANUEL
PROGRAM
PİŞİRME
SÜRESİ
PROGRAMI
PİŞİRME
SONU
PROGRAMI
ÇOCUK KİLİDİ
DEVREYE SOKULMASI
•Orta düğmeye 1 kez basınız
•Arzu ettiğiniz süreyi ayarlamak için düğmelerine basın.
•Bütün düğmelere basmaya son verin.
•Orta düğmeye 1 kez basınız
•Fırın fonksiyon düğmesi ile pişirme fonksiyonu ayarlayın.
•Orta düğmeye 2 kez basınız
•Arzu ettiğiniz pişirme süresini ayarlamak için düğmelerine basın.
•Bütün düğmelere basmaya son verin.
•Fırın fonksiyon düğmesi ile pişirme fonksiyonunu seçin.
•Orta düğmeye 3 kez basınız
•Arzu ettiğiniz pişirmenin sona erme saatini ayarlamak için düğmelerine basın.
•Bütün düğmelere basmaya son verin.
•Fırın fonksiyon düğmesi ile pişirme fonksiyonunu seçin.
• Çocuk kilidi fonksiyonu dokunmatik ekrandaki (+) sembolüne ekranda çocuk kilidi sembolü görüntülenene kadar en az 5 saniye dokunarak aktif hale getirilir. Bu andan itibaren diğer tüm fonksiyonlar kilitlenir.
DEVREDEN ÇIKARILMASI İŞLEVİ NE İÇİN KULLANILDIĞI
•Ayarlanmış olan süre sona erdiğinde, sesli bir alarm verilir (bu alarm kendiliğinden durur) ancak, 7 dakika sonra düğmesine basılarak istendiği takdirde daha önce de durdurulabilir. SELECT
•Fırın işlevi seçicisini ( O ) konumuna getirin.
•Ayarlanmış olan süre sona erdiğinde, fırın otomatik olarak kapanır. Pişirme işlemini daha önce durdurmak istemeniz durumunda, işlev seçicisini 0 konumuna getirin veya süreyi 0:00 olarak ayarlayın SELECT ve düğmeleri
•Ayarlanmış olan süre sona erdiğinde, fırın otomatik olarak kapanır. Pişirme işlemini kendiniz müdahale ederek durdurmak için fırın fonksiyon düğmesini O konumuna getirin.
• Çocuk kilidi fonksiyonu tekrar dokunmatik ekrandaki (+) sembolüne ekrandan çocuk kilidi sembolü kaybolana kadar en az 5 saniye dokunarak iptal edilir. Bu andan itibaren tüm fonksiyonlar tekrar seçilebilir hale gelir.
•Ayarlanmış olan sürenin sonunda alarmı çaldırır.
•İşlem sırasında kalan süreyi gösterir: dk, sn.
•Fırını çalıştırabilmenize olanak sağlar.
•Seçilmiş olan tarif için gerekli olan pişirme süresini ayarlayabilmenize olanak sağlar.
•Ne kadar çalışma süresi kaldığını görmek için SELECT düğmesine basın.
•Programlanmış olan süreyi değiştirmek için SELECT ve düğmelerine basın.
•Pişirme sonu saatini ayarlayabilmenize olanak sağlar.
•Ayarlanmış olan saati kontrol etmek için orta düğmeye 3 kez basınız
•Programlanmış olan saati değiştirmek için SELECT ve düğmelerine basın.
•Fırını bir alarmlı saat olarak kullanabilmenize olanak sağlar (fırın çalışırken de çalışmıyorken de kullanılabilir)
•Arzu ettiğiniz tarifleri pişirmeniz için kullanılır.
•Sinyali durdurmak için herhangi bir düğmeye basın. saat fonksiyonuna geri dönmek için orta düğmeye basın
•Bu işlev genellikle “pişirme süresi” işlevi ile birlikte kullanılır. Örneğin yiyeceğin pişme süresi 45 dakikaysa ve saat 12:30'da hazır olması gerekiyorsa, sadece pişirme süresini 45 dakikaya ve pişirme sonu saatini de 12:30' a ayarlamanız yeterlidir.
•Programlanmış olan pişirme süresinin sonunda fırın otomatik olarak kapanır ve bir sesli alarm verilir.
•Pişirme saat 11:45'de (12:30 eksi 45 dakika) otomatik olarak başlar ve programlanmış olan pişirme süresi (45 dakika) kadar sürdükten sonra fırın otomatik olarak kapanır.
UYARI:Pişirme sonu(END) programı pişirme süresi seçilmeden ayarlanmış olması durumunda, fırın hemen çalışmaya başlar ve programlanmış olan pişirme sonu saatine kadar çalışıp otomatik olarak durur.
3.6 SAATİN AYARLANMASI
UYARI: Fırın yerine monte edilip elektrik bağlantısı yapıldığında veya elektrik beslemesi kesilip tekrar geri geldiğinde, gösterge yanıp sönmeye başlar. Bu aşamada saatin (
aşağıdaki gibi ayarlanır:
•Orta düğmeye 1 kez basınız.
• Butonlarıyla zamanı ayarlayınız.
•Bütün düğmelere basmaya son verin.
DİKKAT: Fırın sadece manuel kullanım veya zaman programlaması ayarlandığında çalıştırılabilir.
Önemli Not: bazı modellerde sembollerinin yerine ve kullanılmıştır.
12:00 ) ayarlanması gerekir. Saat
L1, L2, L3 SİNYAL SES AYARI
• Orta düğmeye 5 kez basınız.
• Butonlarıyla zamanı ayarlayınız.
• Bütün düğmelere basmaya son verin.
16 TR
3.7 DOKUNMATİK ZAMANLAYICI
PROGRAM
ZAMAN SAYACI
PİŞİRME
SÜRESİ
PROGRAMI
PİŞİRME
SONU
PROGRAMI
ÇOCUK KİLİDİ
DEVREYE SOKULMASI
•Orta düğmeye 1 kez basınız
•Arzu ettiğiniz süreyi ayarlamak için düğmelerine basın.
•Bütün düğmelere basmaya son verin.
•Orta düğmeye 2 kez basınız
•Arzu ettiğiniz pişirme süresini ayarlamak için
"-" "+"
"-" "+" düğmelerine basın.
•Bütün düğmelere basmaya son verin.
•Fırın fonksiyon düğmesi ile pişirme fonksiyonunu seçin.
•Orta düğmeye 3 kez basınız
•Arzu ettiğiniz pişirmenin sona erme saatini ayarlamak için düğmelerine basın.
•Bütün düğmelere basmaya son verin.
•Fırın fonksiyon düğmesi ile pişirme fonksiyonunu seçin.
• Çocuk kilidi fonksiyonu dokunmatik ekrandaki (+) sembolüne en az 5 saniye dokunarak aktif hale getirilir. Bu andan itibaren diğer tüm fonksiyonlar kilitlenir. Ekran ya “Stop” ya da zaman ayarlayıcıyı gösterir. İkisini de aynı anda göstermez.
"-" "+"
DEVREDEN ÇIKARILMASI İŞLEVİ NE İÇİN KULLANILDIĞI
•Ayarlanmış olan süre sona erdiğinde, sesli bir alarm verilir (bu alarm kendiliğinden durur) ancak, düğmesine basılarak istendiği takdirde daha önce de durdurulabilir.
•Ayarlanmış olan süre sona erdiğinde, fırın otomatik olarak kapanır. Pişirme işlemini daha önce durdurmak istemeniz durumunda, işlev seçicisini 0 konumuna getirin veya süreyi 0:00 olarak ayarlayın SELECT ve
•Ayarlanmış olan süre sona erdiğinde, fırın otomatik olarak kapanır. Pişirme işlemini kendiniz müdahale ederek durdurmak için fırın fonksiyon düğmesini O konumuna getirin.
• Çocuk kilidi fonksiyonu tekrar dokunmatik ekrandaki (+) sembolüne en az 5 saniye dokunarak iptal edilir. Bu andan itibaren tüm fonksiyonlar tekrar seçilebilir hale gelir.
"-" "+" düğmeleri
•Ayarlanmış olan sürenin sonunda alarmı çaldırır.
•İşlem sırasında kalan süreyi gösterir.
•Seçilmiş olan tarif için gerekli olan pişirme süresini ayarlayabilmenize olanak sağlar.
•Ne kadar çalışma süresi kaldığını görmek için SELECT düğmesine basın.
•Programlanmış olan süreyi değiştirmek için SELECT ve
"-" "+" düğmelerine
basın.
•Pişirme sonu saatini ayarlayabilmenize olanak sağlar.
•Ayarlanmış olan saati kontrol etmek için orta düğmeye 3 kez basınız
•Programlanmış olan saati değiştirmek için SELECT ve düğmelerine basın.
"-" "+"
•Fırını bir alarmlı saat olarak kullanabilmenize olanak sağlar (fırın çalışırken de çalışmıyorken de kullanılabilir)
•Sinyali durdurmak için herhangi bir düğmeye basın. saat fonksiyonuna geri dönmek için orta düğmeye basın
•Bu işlev genellikle “pişirme süresi” işlevi ile birlikte kullanılır. Örneğin yiyeceğin pişme süresi 45 dakikaysa ve saat 12:30'da hazır olması gerekiyorsa, sadece pişirme süresini 45 dakikaya ve pişirme sonu saatini de 12:30' a ayarlamanız yeterlidir.
•Programlanmış olan pişirme süresinin sonunda fırın otomatik olarak kapanır ve bir sesli alarm verilir.
•Pişirme saat 11:45'de (12:30 eksi 45 dakika) otomatik olarak başlar ve programlanmış olan pişirme süresi (45 dakika) kadar sürdükten sonra fırın otomatik olarak kapanır.
UYARI:Pişirme sonu(END) programı pişirme süresi seçilmeden ayarlanmış olması durumunda, fırın hemen çalışmaya başlar ve programlanmış olan pişirme sonu saatine kadar çalışıp otomatik olarak durur.
3.8 SAATİN AYARLANMASI
UYARI: Fırın yerine monte edilip elektrik bağlantısı yapıldığında veya elektrik beslemesi kesilip tekrar geri geldiğinde, gösterge yanıp sönmeye başlar. Bu aşamada saatin (
00:00

UYARI: Fırın ancak saat ayarlandıysa çalışmaya başlar.
aşağıdaki gibi ayarlanır:
•Orta düğmeye 1 kez basınız.
"-" "+" Butonlarıyla zamanı ayarlayınız.
•Bütün düğmelere basmaya son verin.
12:00 ) ayarlanması gerekir. Saat
17 TR
4. KULLANMA TALİMATLARI
Önceden
belirlenmiş
Fonksiyon
sıcaklık
aralığı
(elektronik
programlayıcılı
modellerde)
(Type A)
220
50 ÷ 240
200
50 ÷ 230
Termostat
50 ÷ MAX
50 ÷ MAX
ayarı
Fonksiyon
Fırın lambasını yakar. Aynı zamanda soğutucu fan otomatik olarak devreye girer (Sadece soğutucu fanlı modellerde).
Buz Çözdürme Fonksiyonu
Fonksiyon düğmesi bu konuma getirildiğinde turbo fan donmuş gıdaların protein içeriğini değiştirmeden bir kaç dakika içerisinde çözülmesini sağlar.
Fansız Pişirme Fonksiyonu
Alt ve üst fırın ısıtıcılar birlikte kullanılır. Bu seçenek yiyecekleri pişirme ve üzerlerini kızartmak için kullanılan geleneksel bir yöntemdir. Bu seçenek pişirme ve üzerini kızartma için geleneksel kullanım şeklidir. Bu seçenek, et ve av hayvanı butlarının kızartılması, bisküvi ve elma pişirme ile yiyeceklerin üzerlerini kızartmak için idealdir.
Fanlı Pişirme Fonksiyonu
Alt üst ısıtıcılar hava sirkülasyonunun da sağlanması için turbo fan ile birlikte çalıştırılır. Bu fonksiyon kümes hayvanları, hamur işleri, balık ve sebzelerin pişirilmesi için tavsiye edilmektedir. Isı yiyeceklerin içine daha iyi nüfuz eder ve bu sayede ön ısıtma ve pişirme süreleri kısalır. Böylece farklı türden yiyecekleri tat ve kokuları birbirine karışmadan aynı anda pişirebilirsiniz. Farklı yiyecekleri aynı zamanda pişirebilmeniz için 10 dk ekstra süre önerilmektedir.
160
50 ÷ 200
Level 4
1 ÷ 4
190
180 ÷ 200
Level 4
1 ÷ 4
220
* CENELEC EN 50304 standardına uygun olarak test edilmiştir. ** Enerji sınıfı tanımında kullanılmış olan CENELEC EN 50304 standardına uygun olarak test edilmiştir.
50 ÷ MAX
50 ÷ MAX
50 ÷ 200
50 ÷ 200
50 ÷ MAX
Fan ve Alt Isıtıcı Fonksiyonu
Bu işlev hassas yiyecekler için idealdir (tartlar, sufle).
Izgara Fonksiyonu
Sadece üst ısıtıcı kullanılır. Isıtıcı elemanın tam olarak pişirmeye hazır hale gelmesi için 5 dk.’lık ön ısıtma yapınız. Izgaraları, kebap ve üst kapalı yiyecekleri başarılı bir şekilde pişirebilirsiniz. Beyaz etler ızgara elemanından belli bir mesafede tutulur ve pişirme süresi daha uzundur. Fakat lezzetli bir pişirme sağlanır. Kırmızı etler ve balıkları tel ızgara üzerinde damlama tepsisi ile birlikte pişirebilirsiniz.
Fanlı Izgara Fonksiyonu
Üst ısıtıcı eleman fırın içerisindeki havanın sirkülasyonunu sağlayan turbo fan ile birlikte devreye sokulur. Beyaz etler hariç kırmızı etler için ön ısıtma yapılmalıdır. Kalın ve tek parça halindeki yiyeceklerin pişirilmesi için idealdir. Yiyecekleri fırın içerisinde orta seviyeye yerleştiriniz ve altına damlama tepsisini yerleştiriniz. Ayrıca yiyeceklerin ısıtıcı elemana yakın olmamasına dikkat ediniz. Pişirme süresince yiyecekleri çevirerek eşit şekilde pişmesini sağlayınız.
Izgara/piliç çevirme
Bu fonksiyon döndürerek pişirme için kullanılır.
Pizza Fonksiyonu
Bu seçenekte sıcak hava sirkülasyonuyla pizza ve kek gibi yiyecekler mükemmel bir şekilde pişirilir.
18 TR
5. PİŞİRME SÜRESİ TABLOLARI
Aşağıda önerilmiş olan genel pişirme süreleri sadece kabaca yol gösterme amaçlıdır. Bunlar aslında pişirilen yiyeceğin niteliğine, tazeliğine, büyüklüğüne ve kalınlığına ve doğal olarak kişisel zevklere göre değişiklik gösterebilir. Yiyecekleri ikram etmeden önce birkaç dakika bekletin, çünkü içindeki malzemeler fırından çıktıktan sonra da pişmeye devam eder.
PRATİK TAVSİYE : Yiyeceğin yüzeyinin kuru ve sert olmasını engellemek için sıcaklığı düşür.
Statik elektrikli fırın
Yiyecek
Miktar
Raf
Pişirme
Süresi
(dakika)
Fırın
sıcaklığı
• Hamur işleri ( makarnalar )
Lazanya
Dolma makarna
Fırında makarna
Kg 3,5
Kg 1,8
Kg 2,5
22 22 22
70 ÷ 75
50 ÷ 60
55 ÷ 60
220
220
220
• Fırında Pişirme ( Pasta ve kekler hariç )
35
Ekmek
Pizzalar
1 kg undan
Kg 1
2
10
(ön ısıtma)
25 ÷ 35
200
190
Hamur işleri (donmuş)
24 adet
30 ÷ 35
220
talaş böreği
Küçük pizza
Her biri
200 gr
25 ÷ 30
200
• Etler
Raf pozisyonları
Fanlı elektrikli fırın
Pişirme
Raf
2
11
21
22
Süresi
(dakika)
60 ÷ 65
40 ÷ 50
45 ÷ 50
30 ÷ 35
10
(ön ısıtma)
20 ÷ 25
25 ÷ 30
20 ÷ 25
Fırın
sıcaklığı
200
200
200
180
190
200
180
Uyarılar
Isıtılmamış fırına koyun
Isıtılmamış fırına koyun
Isıtılmamış fırına koyun
Hamuru somun haline getirin ve hamurun üzerini bıçakla çizin. Hamuru en az 2 saat kabarmaya bırakın. pişirme tepsisini yağlayın ve hamuru ortasına koyun.
Fırını 15 dakika ısıtın ve pizzaları yağlanmış pişirme tepsisine yerleştirin. Üzerlerine domates, mozarella peyniri, salam, sıvı yağ, tuz ve origano koyun.
24 adet "böreği" i fırına koyup pişirin.
Fırını 15 dakika ısıtın, pişirme tepsisini yağlayın, 4 adet küçük pizza'yı yağ ve tuz ekleyerek bunları fırına koymadan önce oda sıcaklığında en az 2saat kabarmaya bırakın.
4 3 2 1
Bütün etler yayvan veya derin pişirme tepsilerinde kızartılabilir. Fırının yan duvarlarına yağ sıçramaması için yayvan tepsilerin üzerlerinin örtülmesi önerilir. Etlerin üzerleri örtülmesi ile açık bırakılması durumlarında pişirme süreleri aynıdır.
Kemikli dana parça et
Kemiksiz dana parça et
Kemiksiz sığır parça et
Kemiksiz dana bonfile
• Fish
• Balıklar
Alabalık
Somon
Dil balığı
Çipura
Kg 1
Kg 1
Kg 1,3
Kg 1
3 bütün alabalık
veya 1 kg
700 gr eşit boyutlu
2,5 cm'lik dilimler
Fileto / 1 kg
2 adet bütün
70 ÷ 80
100 ÷ 110
90 ÷ 110
80 ÷ 90
40 ÷ 45
30 ÷ 35
40 ÷ 45
40 ÷ 45 220
220
220
220
220
220
220
220
33
22
21
22
22
22
22
22
50 ÷ 60
80 ÷ 90
90 ÷ 100
80 ÷ 90
35 ÷ 40
30 ÷ 25
35 ÷ 40
35 ÷ 40
200
200
200
200
200
200
200
200
Etleri derin bir Pyrex kap içine koyun ve tuz ve karabiber ilave edin; etleri pişme süresinin yarısında çevirin.
Etleri üzeri kapaklı bir Pyrex kap içerisinde yeşillikler, baharat, sıvı yağ ve tereyağı ile pişirin.
Yukarıda belirtildiği şekilde pişirin
Yukarıda belirtildiği şekilde pişirin
Alabalığın üzerine tuz, sıvı yağ ve soğan ilave edip Pyrex kapta pişirin.
Somonun üzerine tuz, sıvı yağ ve karabiber ilave edip açık Pyrex kapta pişirin.
Dil balığını üzerine tuz ve bir kaşık sıvı yağ ilave ederek pişirin.
Çipurayı tuz ve sıvı yağ ile kapaklı bir kap içerisinde pişirin.
19 TR
5. PİŞİRME SÜRESİ TABLOLARI
Fanlı elektrikli fırın
Pişirme
Raf
Süresi
(dakika)
Fırın
sıcaklığı
Uyarılar
Yiyecek Miktar
Statik elektrikli fırın
Raf
Pişirme
Süresi
(dakika)
Fırın
sıcaklığı
• Tavşan ve Kümes hayvanları
Hindiyi derin bir Pyrex veya güveç kabına
Hindi
Tavuk
Tavşan eti (parça et)
1 - 1,3 Kg
1,5 - 1,7 Kg
1 - 1,5 Kg
2
2
2
60 ÷ 80
110 ÷ 120
55 ÷ 65
220
220
220
2
2
2
60 ÷ 70
100 ÷ 110
50 ÷ 60
200
200
200
koyun ve az miktarda sıvı yağ ve şifalı otlar ve baharat ilave edin.
Hindi için tarif edildiği gibi pişirin.
Aynı boydaki bütün parçaları sırlı bir tepsiye koyun. Şifalı otlar ve baharat ilave edin. Gerektiğinde parçaları çevirin.
• Kekler ( kek kalıbında )
Hindistan cevizli kek Margarita turtası
Havuçlu kek
Elmalı turta
700 gr
1
1
1
1
55
55
65
40
180
175
180
200
1
1
1
2
50
40 ÷ 45
50 ÷ 60
30 ÷ 35
160
160
160
180
22 cm derinlikte kalıp kullanın. Fırını önce 10 dakika ısıtın.
22 cm derinlikte kalıp kullanın. Fırını önce 10 dakika ısıtın.
22 cm derinlikte kalıp kullanın. Fırını önce 10 dakika ısıtın.
22 cm derinlikte kalıp kullanın. Fırını önce 10 dakika ısıtın.
• Sebzeler
Rezene soğanı
Kabak
Patates
Havuç
800 gr
800 gr
800 gr
800 gr
1
1
2
1
70 ÷ 80
70
60 ÷ 65
80 ÷ 85
220
220
220
220
1
1
2
1
60 ÷ 70
60 ÷ 70
60 ÷ 65
70 ÷ 80
200
200
200
200
Rezeneyi dörde bölün, tereyağı, tuz ve arzu edilirse patates ilave edin ve bir Pyrex kaba yukarı bakacak şekilde yerleştirin. Üzerini örtün.
Kabakları dilimleyin, bir Pyrex kaba koyun ve tereyağı ile tuz ilave edin.
Patatesleri eşit parçalara bölün ve bir Pyrex kap içerisine koyun. Tuz, origano ve biberiye ilave edin. Sıvı yağ içinde pişirin.
Havuçları dilimleyin, bir Pyrex kap içerisine koyun ve pişirin.
• Meyvalar
Elmaları üstü açık bir Pyrex kap veya toprak
Bütün Elma
Armut Şeftali
Kg 1
Kg 1 Kg 1
1
1 1
45 ÷ 55
45 ÷ 55 45 ÷ 55
220
220 220
2
2 2
45 ÷ 55
45 ÷ 55 45 ÷ 55
200
200 200
kap içerisine koyun. Piştikten sonra fırının içinde soğumaya bırakın.
Yukarıdaki prosedürü uygulayın
Yukarıdaki prosedürü uygulayın
• Izgaralar
Izgara yapılacak yiyecekleri kızılötesi ızgaranın altına yerleştirin. Uyarı: Izgara çalışırken parlak kırmızı bir renk alır. Tepsiyi ızgaranın altına koyarak ızgara yapılan yiyecekten akan su ve yağları toplayın.
Ekmekleri ızgara tepsisi üzerine yerleştirin. Ekmeklerin bir yüzleri kızardıktan sonra diğer yüzlerini çevirin. Hatırlatma: tost ekmeklerini ikram edene kadar fırının altında sıcak tutun.
Ekmekleri ızgara tepsisi üzerine koyun. Sandviçin bir yüzü kızardığında diğer yüzünü çevirin.
Sosisleri ortadan ikiye ayırın ve yüzleri aşağı gelecek şekilde ızgara üzerine koyun. Izgara yapma süresinin yarısında diğer yüzlerini çevirin. Hatırlatma: Sık sık sosislerin her tarafının eşit pişip pişmediğini kontrol edin. Eğer her tarafları eşit pişmiyorsa, az pişenlerle çok pişenlerin yerlerini değiştirin.
Kaburgaların ana ızgaranın tamamen etki alanı içerisinde olduğundan emin olun.
Izgara süresinin yarısında çevirin.
Kare tost ekmeği
Sandviç ekmeği
Sosis
Dana kaburga
Tavuk butu
4 dilim
4 adet
6 adet 0,9 kg
4 adet / 1,5 kg
4 adet / 1,5 kg
5dak. ızgarayı
4
10dak. ızgarayı
3
4
5dak. ızgarayı
4
3
25 / 5dak.
ızgarayı ısıtma
5dak. ızgarayı
5
ısıtma
10
ısıtma
25/30
ısıtma
50/60
ısıtma
Izgara
( Grill )
Izgara
( Grill )
Izgara
( Grill )
Izgara
( Grill )
Izgara
( Grill )
10dak. ızgarayı
4
3
4
ısıtma
10dak. ızgarayı
ısıtma
10dak. ızgarayı
ısıtma
15/20 (10 to
4
heat up grill)
3
10dak. ızgarayı
ısıtma
5
5/8
15/20
50/60
Izgara ( Grill )
Izgara ( Grill )
Izgara ( Grill )
Izgara ( Grill )
Izgara ( Grill )
20 TR
Yetkili servislerimizden hizmet talebiniz olduğunda ekteki servis listesinden size en yakın yetkili servisimize ulaşabilirsiniz. Servis hizmeti ve ürünlerimiz ile ilgili genel öneri ve talepleriniz için aşağıdaki numaradan müşteri hizmetleri merkezimize ulaşabilirsiniz.
Müşteri Hizmetleri:
Candy - Hoover Euroasia tarafından sağlanan garanti şartları aşağıdaki koşullarda geçersiz olacaktır.
•Ürüne, yetkili servis dışındaki kişiler tarafından müdahale edilmesi.
•Kullanım hatalarından dolayı oluşan arıza ve hasarlar.
•Ürünün, müşteriye ulaştırılması sonrası yapılan taşıma işlemine bağlı arıza ve hasarlar.
•Doğal afetler veya yangın sonucu oluşan arıza ve hasarlar.
•Hatalı elektrik tesisatı, ürünün üzerinde belirtilen voltajdan farklı voltajda kullanılması veya şebeke voltajındaki dalgalanmalar sonucu oluşan arıza ve hasarlar.
•Kullanım kılavuzunda belirtilen hususlara aykırı kullanılmasından kaynaklanan arıza ve hasarlar. Yukarıda belirtilen arızaların giderilmesi ücret karşılığı yapılır.
Ürününüzün kullanım ömrü 10 yıldır. (Ürünün işlevlerini yerine getirebilmesi için gerekli yedek parça süresi).
CANDY HOOVER EUROASİA EV GEREÇLERİ SAN VE TİC A.Ş
İçerenköy Mh Hal Yolu cd Çayır Yolu Sk. No:11 Sayar İş Hanı Kat:7 34752 Ataşehir/İstanbul Tel (0216) 466 42 42 Fax (0216) 466 15 45 Kozyatağı 703 003 9546
444 03 98
CANDY HOOVER EUROASIA EV GEREÇLERİ SAN. VE TİC. A.Ş.
Organize Sanayi Bölgesi 8. Cad. 26110 Eskişehir / TÜRKİYE Tel: 0222 236 00 75 - Fax: 0222 236 03 14
ANKASTRE FIRIN
Ankastre Fırın’ın kullanma kılavuzunda gösterildiği şekilde kullanılması ve yetkili kıldığımız servis elemanları dışındaki şahıslar tarafından bakımı, onarımı veya başka bir nedenle müdahale edilmemiş olması şartıyla bütün parçaları dahil olmak üzere tamamı malzeme, işçilik ve üretim hatalarına karşı ürünün teslim tarihinden itibaren 3 (ÜÇ ) YIL SÜRE İLE GARANTİ EDİLMİŞTİR.
Ürünün garanti kapsamı içinde malzeme, işçilik ve montaj hatalarından dolayı arızalanması halinde yapılan işlemler için işçilik masrafı, değiştirilen parça bedeli ya da başka bir ad altında hiçbir ücret talep edilmeyecektir. Garanti süresi içinde yapılacak onarımlarda geçen süre, garanti süresine ilave edilir. Tamir süresi 20 (yirmi) iş günüdür. Bu süre mamulün yetkili servis atölyelerimize, yetkili servis atölyelerimizin bulunmaması durumunda yetkili satıcılarımıza veya firmamıza bildirildiği tarihten itibaren başlar. Ürünün arızasının 10 iş günü içerisinde giderilmemesi halinde Candy Hoover Euroasia Ev Gereçleri San. Ve Tic. A.Ş. ürünün tamiri tamamlanıncaya kadar, benzer özelliklere sahip başka bir ürünü, müşterinin kullanımına tahsis edecektir. Arızanın giderilmesi konusunda uygulanacak teknik yöntemlerin tespiti ile değiştirilecek parçaların saptanması tamamen firmamıza aittir.
Arızanın giderilmesi için yapılacak faaliyetler ürünün bulunduğu yerde veya yetkili servis atölyesinde yapılabilir. Müşterinin buna onayı şarttır. Aşağıda belirtilen üç koşuldan birinin oluşması halinde sırasıyla yetkili satıcılarımız, bayi, acente temsilciliğimizden birisinin bölgeye en yakın servis yetkilisiyle birlikte veya firmamız yetkilisince düzenlenecek raporla, arızanın tamirinin mümkün bulunmadığının belirlenmesi durumunda, ürün ücretsiz olarak yenisiyle değiştirilecektir.
1.Ürünün teslim tarihinden itibaren, garanti süresi içinde kalmak kaydıyla, bir yıl içersinde en az dört defa veya Candy Hoover Euroasia Ev Gereçleri San. Ve Tic. A.Ş. tarafından belirlenen garanti süresi içersinde altı defa arızalanmasının yanı sıra bu arızaların maldan yararlanamamayı sürekli kılması,
2.Ürünün tamiri için gerekli sürenin aşılması,
3.Ürüne hizmet verecek yetkili servis istasyonunun mevcut olmaması. Garanti şartları ile ilgili olarak çıkabilecek sorunlar için Sanayi ve Ticaret Bakanlığı, Tüketicinin ve Rekabetin Korunması Genel Müdürlüğü'ne
başvurulabilir. Bu Garanti Belgesi'nin kullanılmasına 4077 sayılı Tüketicinin Korunması Hakkında Kanun ile bu Kanun'a dayanılarak yürürlüğe konulan Garanti Belgesi Uygulama Esaslarına Dair Tebliğ uyarınca, T.C. Sanayi ve Ticaret Bakanlığı, Tüketicinin ve Rekabetin Korunması Genel Müdürlüğü tarafından izin verilmiştir.
CANDY HOOVER EUROASIA EV GEREÇLERİ SAN VE TİC. A.Ş.
Bu Belge, Sanayi ve Ticaret Bakanlığı’nın 109292 No’lu ve 30.01.2012 izin tarihli belgesine göre düzenlenmiştir.
Bu bölümü, ürünü aldığınız Yetkili Satıcı imzalayacak ve kaşeleyecektir.
INDICAZIONI DI SICUREZZA
• ATTENZIONE: l'apparecchio e le parti accessibili diventano calde durante l'uso. Prestare attenzione a non toccare le parti calde.
• I bambini al di sotto di 8 anni dovrebbero essere tenuti a distanza se non continuamente supervisionati.
• L'apparecchio può essere usato da bambini dagli 8 anni in su e persone con ridotte capacità fisiche, sensoriali o mentali o senza esperienza e conoscenza del prodotto se supervisionate o dando loro istruzioni riguardo al funzionamento dell'apparecchio in maniera sicura e coscente del rischio possibile.
• I bambini non dovrebbero giocare con l'apparecchio.
• La pulizia e la manutenzione non dovrebbero essere fatte da bambini senza supervisione
• Durante l’uso l’apparecchio diventa molto caldo. Si dovrebbe fare attenzione a non toccare gli elementi riscaldanti all’interno del forno.
• ATTENZIONE: Le parti accessibili possono diventare molto calde durante l’uso. I bambini dovrebbero essere tenuti a distanza.
• Non usare per la pulizia materiali ruvidi abrasivi o raschietti metallici affilati per pulire le porte di vetro del forno dato che possono graffiare la superficie e causare la frantumazione del vetro.
• Spegnere il forno prima di rimuovere lo schermo di protezione e, dopo la pulizia, rimontarlo secondo le istruzioni.
• Usare solo la sonda termica raccomandata per questo forno.
• Non utilizzare un pulitore a vapore.
• ATTENZIONE: Assicurarsi che l’apparecchio sia spento prima di sostituire la lampada per evitare la possibilità di scosse elettriche.
• Il mezzo di disconnessione deve essere incorporato nel cablaggio fisso in accordo con le leggi di cablaggio.
• Le istruzioni devono indicare quale tipo di cavo debba essere utilizzato, tenendo presente la temperatura della superficie posteriore dell’apparecchio.
• Se il cavo di alimentazione è danneggiato, esso deve essere sostituito da un cavo o un assieme speciali disponibili presso il costruttore o il suo servizio assistenza tecnica.
• ATTENZIONE: Al fine di evitare ogni pericolo dovuto al riarmo accidentale del dispositivo termico di interruzione, il presente apparecchio non deve essere alimentato con un dispositivo di manovra esterno, quale un temporizzatore oppure essere connesso a un circuito che viene regolarmente alimentato o disalimentato dal servizio.
• ATTENZIONE: Le parti accessibili possono diventare calde quando il grill è in uso. I bambini dovrebbero essere tenuti a distanza.
• Gli eccessi di materiale tracimato devono essere tolti prima della pulizia.
• Durante la Pyrolisi le superfici possono scaldarsi più del solito è pertanto consigliato tenere i bambini a distanza.
1. AVVERTENZE GENERALI
Vi ringraziamo per aver scelto uno dei nostri prodotti, per ottenere da questo elettrodomestico le migliori prestazioni consigliamo di:
• Leggere attentamente le avvertenze contenute nel presente libretto.
• Conservare con cura questo libretto per ogni ulteriore consultazione. Alla prima accensione del forno può svilupparsi fumo di odore acre, causato dal primo riscaldamento del collante dei pannelli d’isolamento avvolgenti il forno. Si tratta di un fenomeno assolutamente normale e, in caso si verificasse, occorre attendere la cessazione del fumo prima di introdurre le vivande. Il forno è per sua natura un apparecchio che diventa caldo, in modo particolare in corrispondenza del cristallo porta.
1.1 DICHIARAZIONE DI CONFORMITÀ
Questa apparecchiatura nelle parti destinate a venire a contatto con sostanze alimentari, è conforme alla prescrizione della dir. CEE 89/109 e
al D.L. di attuazione N° 108 del 25/01/92.
Apparecchio conforme alle Direttive Europee 73/23/CEE e
89/336/CEE, sostituite rispettivamente da 2006/95/CE e 2004/108/CE, e successive modifiche.
1.2 INFORMAZIONI SULLA SICUREZZA
•Questo apparecchio dovrà essere destinato solo all’uso per il quale è stato espressamente concepito, e cioè per la cottura di alimenti. Ogni altro uso (ad esempio riscaldamento ambiente) è da considerarsi improprio e quindi pericoloso. Il costruttore non può essere considerato responsabile per eventuali danni derivanti da usi impropri, erronei ed irragionevoli.
•L’uso di un qualsiasi apparecchio elettrico comporta l’osservanza di alcune regole fondamentali.
In particolare:
-non tirare il cavo di alimentazione per staccare la spina dalla presa di corrente
-non toccare l’apparecchio con mani o piedi bagnati o umidi
-non usare l’apparecchio a piedi nudi
-in generale è sconsigliabile l’uso di adattatori, prese multiple e prolunghe.
- In caso di guasto e/o di cattivo funzionamento dell’apparecchio, spegnerlo e non manometterlo.
•In caso di danneggiamento del cavo, provvedere tempestivamente alla sua sostituzione secondo le seguendi indicazioni: aprire il coperchio morsettiera, togliere il cavo di alimentazione e sostituirlo con uno corrispondente, (tipo H05RR-F, H05VVF, H05V2V2-F) e adeguato alla portata dell’apparecchio. Tale operazione dovrà essere eseguita da personale professionalmente qualificato. Il conduttore di terra (giallo-verde), deve obbligatoriamente essere più lungo di circa 10 mm rispetto ai conduttori di linea. Per l’eventuale riparazione rivolgersi solamente ad un centro di assistenza tecnica autorizzato e richiedere l’utilizzo di ricambi originali. Il mancato rispetto di quanto sopra può compromettere la sicurezza dell’apparecchio.
Non rivestire le pareti del forno con fogli d'alluminio da cucina o
fogli monouso commerciali, perche potrebbero fondersi a contatto con le superfici in smalto caldo e danneggiare le superfici in smalto all'interno del forno.
22 IT
1.3 INSTALLAZIONE
L’installazione è a carico dell’acquirente e la Casa Costruttrice è esonerata da questo servizio; gli eventuali interventi richiesti alla Casa Costruttrice che dipendono da una errata installazione non sono compresi nella garanzia. L’installazione deve essere effettuata secondo le istruzioni da personale professionalmente qualificato. Una errata installazione può causare danni a persone, animali o cose, nei confronti dei quali il costruttore non può essere considerato responsabile.
1.4 INSERIMENTO DEL MOBILE
Inserire l’apparecchio nel vano del mobile (sottopiano o in colonna). Il fissaggio si esegue con 4 viti attraverso i fori della cornice, visibili aprendo la porta.(vedere ultima pagina). Per consentire la migliore aerazione del mobile, i forni devono essere incassati rispettando le misure e le distanze indicate nella figura in ultima pagina. Nota: per i forni da abbinamento con piano cottura è indispensabile rispettare le istruzioni contenute nel libretto allegato all’ apparecchiatura da abbinare.
1.5 IMPORTANTE
Per garantire un buon funzionamento dell’apparecchio da incasso è necessario che il mobile sia di caratteristiche adatte. I pannelli dei mobili adiacenti il forno dovranno essere in materiale resistente al calore. In particolare nel caso di mobili in legno impiallicciato le colle dovranno essere resistenti alla temperatura di 120°C: materiali plastici o collanti non resistenti a questa temperatura sono causa di deformazioni o scollature. In conformità alle norme di sicurezza, una volta incassato l’apparecchio, non debbono essere possibili eventuali contatti con le parti elettriche. Tutte le parti che assicurano la protezione debbono essere fissate in modo tale da non poter essere tolta senza l’aiuto di qualche utensile.
Per garantire una buona areazione è necessario eliminare la parete posteriore del vano; inoltre il pianale di appoggio deve avere una luce posteriore di almeno 45 mm.
La griglia semplice serve da supporto
per teglie, pirofile, stampi per i dolci. La griglia porta-piatto serve in particolare per le grigliate di carne poiché sostiene anche la leccarda che raccoglie i grassi che colano.
Grazie ai loro profili speciali, le griglie restano sempre in orizzontale, anche quando vengono estratte verso l'esterno. Non c'é nessun rischio quindi che i tegami scivolino o si ribaltino.
La leccarda serve a raccogliere i grassi che colano durante la cottura con il grill. Deve essere utilizzata solamente con il grill, il girarrosto o il turbo girarrosto, secondo il modello. Attenzione: in tutti gli altri modi di cottura, la leccarda deve essere tolta dal forno.
Non usare mai la leccarda per cuocere gli arrosti perché ne risulterebbe un eccessivo sviluppo di fumo e vapori e il forno si sporcherebbe inultimente.
Pizza set é l'idéale per la cottura delle pizze. Il set deve essere utilizzato in abbinamento alla funzione Pizza.
La griglia piatta da combinare con la leccarda per tutti i tipi di grigliate. Una presina è fornita per permettere di estrarre l’insieme dal forno senza scottarsi. Non lasciare mai la presina nel forno.
Gli accessori devono essere tolti dal forno se non vengono utilizzati.
1.6 ALLACCIAMENTO ELETTRICO
Inserire la spina in una presa di corrente munita di un terzo contatto corrispondente alla presa di terra, che deve essere collegata in modo efficiente. Per i modelli sprovvisti di spina, montare sul cavo una spina normalizzata che sia in grado di sopportare il carico indicato in targa. Il conduttore di messa a terra e contraddistinto dai colori giallo-verde. Tale operazione dovrà essere eseguita da personale professional-mente qualificato. In caso di incompatibilità tra la presa e la spina dell’apparecchio fare sostituire la presa con altra di tipo adatto, da personale professional­mente qualificato. Si può effettuare anche l’allacciamento alla rete interponendo tra l’apparecchio e la rete un interruttore omnipolare dimensionato al carico e rispondente alle norme in vigore. Il cavo di terra giallo-verde non deve essere interrotto dall’interruttore. La presa o l’interruttore omnipolare usati per l’allacciamento devono essere facilmente accessibili ad elettrodomestico installato. Importante: in fase di installazione, posizionare il cavo di alimentazione in modo che in nessun punto si raggiungano temperature superiori di 50°C alla temperatura ambiente. L’apparecchio è conforme ai requisiti di sicurezza previsti dagli istituti normativi. La sicurezza elettrica di questo apparecchio è assicurata soltanto quando lo stesso è correttamente collegato ad un efficace impianto di messa a terra come previsto dalle vigenti norme di sicurezza elettrica, (in caso di dubbio, richiedere un controllo accurato dell’impianto da parte di personale professionalmente qualificato).
Importante: la ditta costruttrice resta sollevata da ogni responsabilità per eventuali danni a persone o cose, derivanti dal mancato allacciamento della linea di terra. ATTENZIONE: la tensione e la frequenza di alimentazione sono indicate in targa matricola (figura in ultima pagina). Verificare che la portata elettrica dell’impianto e delle prese di corrente siano adeguate alla potenza massima dell’apparecchio indicate in targa. In caso di dubbio rivolgersi ad una persona professionalmente qualificata.
1.8 Rimozione e pulizia delle griglie
1. Svitare in senso antiorario i dadi zigrinati
2. Rimuovere le griglie tirandole verso se stessi
3. Pulire le griglie lavandole in lavastoviglie o con una spugna bagnata e asciugandole subito dopo
4. Dopo aver pulito le griglie, installarle nuovamente
5. Fissare i dadi zigrinati
A
1.7 DOTAZIONE DEL FORNO (secondo modello)
Prima di utilizzare gli accessori del forno per la prima volta è necessario pulirli. Per questa operazione si consiglia di utilizzare una spugna. Successivamente risciacquare ed asciugare gli accessori.
23 IT
2. CONSIGLI UTILI
2.1 GRIGLIE FORNO - SISTEMA DI ARRESTO
Il forno è dotato di un nuovo sistema di arresto griglie. Questo sistema consente di estrarre le griglie quasi completamente senza che queste fuoriescano dal forno mantenendole perfettamente in piano, consentendo di verificare e mescolare il cibo con la massima tranquillità e sicurezza.
Per estrarre le griglie è sufficiente, come indicato sul disegno, alzarle, prendendole dalla parte anteriore e tirarle.
2.2 LA COTTURA AL GRILL
Questo tipo di cottura consente la doratura rapida dei cibi. A questo scopo consigliamo di inserire la griglia generalmente nel 3° o 4° ripiano, secondo le dimensioni dei cibi (Fig. pag. 8). Quasi tutte le carni possono essere cotte al grill, fanno eccezione alcune carni magre di selvaggina ed i polpettoni. La carne ed il pesce da cucinare al grill vanno leggermente unti con olio.
2.3 TEMPI DI COTTURA
Alle pagine 8-9 riportiamo una tabella indicativa dove sono indicati tempi e temperature consigliati per le prime cotture.Ad esperienza acquisita potrete variare a vostro piacimento i valori riportati nella tabella stessa.
2.4 PULIZIA E MANUTENZIONE
Pulire le superfici in acciaio inox e smaltate con acqua tiepida e sapone, oppure con appositi prodotti in commercio, evitando assolutamente l’uso di polveri abrasive che danneggerebbero le superfici e le parti estetiche. La pulizia del forno è molto importante e deve essere effettuata ogni volta che questo viene usato. Infatti, sulle pareti si depositano grassi sciolti durante la cottura che potrebbero, alla successiva accensione, produrre odori sgradevoli che nuocerebbero al buon esito della cottura. Per la pulizia usare acqua calda e detersivo, sciacquando accuratamente. Per eliminare questo fastidioso intervento, su tutti i modelli possono essere inseriti pannelli autopulenti, offerti come accessori opzionali: vedere apposito paragrafo«FORNO AUTOPULENTE CATALITICO » Usare detersivi e pagliette d’acciaio per le griglie inox. La pulizia delle superfici in cristallo temperato deve essere eseguita quando le superfici sono fredde. Eventuali rotture dovute alla non osservanza di questa regola elementare non rientrano nei termini di garanzia. La lampada forno può essere sostituita disinserendo elettricamente l’apparecchio e svitando l’ampolla che la racchiude, sostituendo la lampada non funzionante con una analoga resistente alle alte temperature.
2.5 LA FUNZIONE HYDRO EASY CLEAN
La procedura “HYDRO EASY CLEAN” utilizza il vapore per facilitare la rimozione dal forno del grasso e dei pezzi di cibo rimasti.
1. Inserire 300 ml di acqua distillata o potabile nel contenitore dell'HYDRO EASY CLEAN sul fondo del forno
2. Impostare la funzione del forno su Statico ( ) o su Riscaldamento ( ) dal basso
3. Impostare la temperatura sull'icona HYDRO EASY CLEAN ( )
4. Lasciar funzionare l'elettrodomestico per 30 minuti
5. Disattivare la macchina e lasciare che si raffreddi Una volta che l'elettrodomestico si è raffreddato, pulire la superfice interna del forno con uno straccio
Attenzione
Assicurarsi che l'elettrodomestico sia freddo prima di toccarlo, c'è il rischio di scottarsi. Utilizzare acqua distillata o potabile.
300 ml
2.6 SERVIZIO ASSISTENZA CLIENTI
CERTIFICATO DI GARANZIA CONVENZIONALE: cosa fare?
Il Suo prodotto è garantito, alle condizioni e nei termini riportati sul certificato inserito nel prodotto ed in base alle previsioni del decreto legislativo 24/02, nonché del decreto legislativo 6 settembre 2005, n. 206, per un periodo di 24 mesi decorrenti dalla data di consegna del bene. Così come riportato nei testi dei Decreti Legislativi citati, il certificato di garanzia dovrà essere da Lei conservato, debitamente compilato, per essere mostrato al Servizio Assistenza Tecnica Autorizzato, in caso di necessità, unitamente ad un documento fiscalmente valido rilasciato dal rivenditore al momento dell’acquisto (bolla di consegna, fattura, scontrino fiscale, altro) sul quale siano indicati il nominativo del rivenditore, la data di consegna, gli estremi identificativi del prodotto ed il prezzo di cessione. Resta pure inteso che, salvo prova contraria, poiché si presume che i difetti di conformità che si manifestano entro sei mesi dalla consegna del bene esistessero già a tale data, a meno che tale ipotesi sia incompatibile con la natura del bene o con la natura del difetto di conformità, il Servizio diAssistenza Tecnica Autorizzato Gias, verificato il diritto all’intervento, lo effettuerà senza addebitare il diritto fisso di intervento a domicilio, la manodopera ed i ricambi. Per contro, nel successivo periodo di diciotto mesi di vigenza della garanzia, sarà invece onere del consumatore che intenda fruire dei rimedi accordati dalla garanzia stessa provare l’esistenza del difetto di conformità del bene sin dal momento della consegna; nel caso in cui il consumatore non fosse in grado di fornire detta prova, non potranno essere applicate le condizioni di garanzia previste e pertanto il Servizio di Assistenza Tecnica Autorizzato Gias effettuerà l’intervento addebitando al consumatore tutti i costi relativi.
ESTENSIONE DELLA GARANZIA FINO A 5 ANNI: come?
Le ricordiamo inoltre che sullo stesso certificato di garanzia convenzionale Lei troverà le informazioni ed i documenti necessari per prolungare la garanzia dell’apparecchio sino a 5 anni e così, in caso di guasto, non pagare il diritto fisso di intervento a domicilio, la manodopera ed i ricambi. Per qualsiasi informazione necessitasse, La preghiamo rivolgersi al numero telefonico del Servizio Clienti 199.12.13.14.
ANOMALIE E MALFUNZIONAMENTI: a chi rivolgersi?
Per qualsiasi necessità il centro assistenza autorizzato è a Sua completa disposizione per fornirLe i chiarimenti necessari; comunque qualora il Suo prodotto presenti anomalie o mal funzionamenti, prima di rivolgersi al Servizio Assistenza Autorizzato, consigliamo vivamente di effettuare i controlli indicati sopra.
UN SOLO NUMERO TELEFONICO PER OTTENERE ASSISTENZA Qualora il problema dovesse persistere, componendo il “Numero Utile” sotto indicato, sarà messo in contatto direttamente con il
ServizioAssistenza TecnicaAutorizzato che opera nella Sua zona di residenza. Attenzione, la chiamata è a pagamento; il costo verrà comunicato, tramite messaggio vocale, dal Servizio clienti dell’operatore telefonico utilizzato. Dettagli sono presenti sul sito internet www.candy-group.com
MATRICOLA DEL PRODOTTO. Dove si trova?
E’ indispensabile che comunichi al Servizio Assistenza Tecnica Autorizzato la sigla del prodotto ed il numero di matricola (16 caratteri che iniziano con la cifra 3) che troverà sul certificato di garanzia
oppure sulla targa matricola del prodotto (figura in ultima pagina). In questo modo Lei potrà contribuire ad evitare trasferte inutili del tecnico, risparmiando oltretutto i relativi costi.
24 IT
3. TEMPORIZZATORE
3.1 USO DEL CONTAMINUTI 3.2 USO DEL TEMPORIZZATORE
Per selezionare il tempo prescelto, ruotare la manopola di un giro completo, quindi ritornare con l’indice nella posizione corrispondente al tempo desiderato. Allo scadere del tempo, entrerà in azione la suoneria per alcuni secondi.
120
110
100
Il forno può essere acceso solo impostando un tempo di cottura o girando la manopola in posizione .
3.3 USO DEL PROGRAMMATORE ELETTRONICO (6 TASTO)
FUNZIONE
CONTAMINUTI
FUNZIONAMENTO
MANUALE
COME SI ATTIVA
•Premere e tenere premu­to il tasto
•Premere i tasti o per regolare la durata
•Lasciare i tasti
•Premere tasto
•Selezionare la funzione di cottura con la manopola commutatore
COME SI SPEGNE COSA FA A COSA SERVE
•Al termine della durata impostata la funzione si spegne da sola ed avvisa con un segnale sonoro (il segnale sonoro si ferma da solo; per fermarlo subito premere il tasto )
•Riportare manopola commutatore in posizione O.
Con questo meccanismo è possibile programmare la durata espressa in minuti della cottura e quindi lo
30
spegnimento automatico del forno al termine del tempo desiderato (max. 120
40
minuti).
50
Allo scadere del tempo prescelto, la manopola raggiungerà la posizione di suoneria O in corrispondenza della qua le i l forno s i spegne automaticamente.
90
80
70
10
20
60
•Da un segnale sonoro al termine di un tempo stabilito
•Per visualizzare il tempo rimanente premere il tasto
•Permette il funzionamento del forno
•Permette di utilizzare il programmatore del forno come una sveglia (può essere usato con forno funzionante o spento.
•Realizzare le cotture volute
DURATA
COTTURA
FINE
COTTURA
•Premere e tenere premuto il tasto TIMER
•Premere i tasti o per regolare la durata
•Lasciare i tasti
•Selezionare la funzione di cottura con la manopola commutatore
•Premere e tenere premuto il tasto END
•Premere i tasti o per regolare l’ora di fine cottura
•Lasciare i tasti
•Selezionare la funzione di cottura con la manopola commutatore
•Al termine della durata impostata il forno si spegne da solo; se deve essere fermato prima si deve portare la manopola commutatore in posizione O oppure portare a 0:00 la durata della cottura (tasti TIMER e o ).
•All’ora impostata il forno si spegne da solo; se deve essere fermato prima è necessario portare la manopola commutatore in posizione O.
•Permette di impostare la durata della cottura del cibo inserito nel forno
•Per visualizzare il tempo rimanente premere il tasto TIMER.
•Per modificare il tempo rimanente premere il tasto TIMER + o
•Permette di memorizzare l’ora di fine cottura
•Per visualizzare l’ora programmata premere il tasto END
•Per modificare l’ora programmata premere i tasti END + o
3.4 REGOLAZIONE ORA
ATTENZIONE: la prima operazione da eseguire dopo l’installazione o dopo una interruzione di corrente (tali situazioni si riconoscono perchè sul dispay lampeggia l’ora ) è la regolazione dell’ora, come di seguito descritto.
•Premere e tenere premuto i tasti TIMER e END (oppure e TIMER su alcuni modelli)
•Premere i tasti o per regolare l’ora
•Lasciare i tasti
ATTENZIONE: il forno funziona solo se impostato in manuale o cottura programmata
N.B.: per regolare le varie funzioni del forno, in alcuni modelli compaiono i simboli o in altri modelli abbiamo + o -
I
•Al termine della durata impostata il forno si spegne automaticamente ed avvisa con un segnale sonoro.
Tipicamente si utilizza questa funzione con la funzione DURATA COTTURA–ad esempio il cibo desiderato deve cuocere per 45 minuti e desidero che sia pronto per le ore 12:30; in tal caso:
Selezionare la funzione di cottura desiderata Impostare la durata cottura a 45 minuti (Timer + o ) Impostare la fine cottura alle ore 12:30 (End + o )
La cottura avrà auto­maticamente inizio alle 11:45 (12:30 meno 45 minuti), all’ora impostata come fine cottura il forno si spegne automaticamente.
ATTENZIONE: impostando solo la fine cottura e non la durata della cottura, il forno si accenderà subito e si spegnerà all’ora di fine cottura impostata
25 IT
3.5 USO DEL PROGRAMMATORE ELETTRONICO
FUNZIONE
CONTAMINUTI
FUNZIONAMENTO
MANUALE
DURATA
COTTURA
FINE
COTTURA
BLOCCO
BAMBINO
COME SI ATTIVA
•Premere il tasto centrale 1 volta.
•Premere i tasti o per regolare la durata
•Lasciare i tasti
•Premere il tasto centrale 1 volta.
•Selezionare la funzione di cottura con la manopola commutatore
•Premere il tasto centrale 2 volte
•Premere i tasti o per regolare la durata
•Lasciare i tasti
•Selezionare la funzione di cottura con la manopola commutatore
•Premere il tasto centrale 3 volte
•Premere i tasti o per regolare l’ora di fine cottura
•Lasciare i tasti
•Selezionare la funzione di cottura con la manopola commutatore
Tenere premuto per
5 secondi il tasto (+), fino a che compare il simbolo . Da questo momento tutte le funzioni sono bloccate.
COME SI SPEGNE COSA FA A COSA SERVE
•Al termine della durata impostata la funzione si spegne da sola ed avvisa con un segnale sonoro (il segnale sonoro si ferma da solo; Dopo 7 minuti per fermarlo subito premere il tasto) SELECT.
•Riportare manopola commutatore in posizione O.
•Al termine della durata impostata il forno si spegne da solo; se deve essere fermato prima si deve portare la manopola commutatore in posizione O oppure portare a 0:00 la durata della cottura (tasti SELECT e o ).
•All’ora impostata il forno si spegne da solo; se deve essere fermato prima è necessario portare la manopola commutatore in posizione O.
•Da un segnale sonoro al termine di un tempo stabilito
•Durante il funzionamento il display visualizza il tempo rimanente: min., Sec.
•Permette il funzionamento del forno
•Permette di impostare la durata della cottura del cibo inserito nel forno
•Per visualizzare il tempo rimanente premere il tasto SELECT.
•Per modificare il tempo rimanente premere il tasto SELECT + o
•Permette di memorizzare l’ora di fine cottura
•Per visualizzare l’ora programmata premere il tasto centrale 3 volte
•Per modificare l’ora programmata premere i tasti SELECT + o
•Permette di utilizzare il programmatore del forno come una sveglia (può essere usato con forno funzionante o spento.
•Realizzare le cotture volute
•Per interrompere il segnale premere un tasto qualsiasi. Premere il tasto centrale per tornare alla funzione orologio.
•Tipicamente si utilizza questa funzione con la funzione DURATA COTTURA–ad esempio il cibo desiderato deve cuocere per 45 minuti e desidero che sia pronto per le ore 12:30; in tal caso:
•Al termine della durata impostata il forno si spegne automaticamente ed avvisa con un segnale sonoro.
Selezionare la funzione di cottura desiderata Impostare la durata cottura a 45 minuti ( o ) Impostare la fine cottura alle ore 12:30 ( o )
La cottura avrà auto­maticamente inizio alle 11:45 (12:30 meno 45 minuti), all’ora impostata come fine cottura il forno si spegne automaticamente.
ATTENZIONE: impostando solo la fine cottura e non la durata della cottura, il forno si accenderà subito e si spegnerà all’ora di fine cottura impostata
3.6 REGOLAZIONE ORA
ATTENZIONE: la prima operazione da eseguire dopo l’installazione o dopo una interruzione di corrente (tali situazioni si riconoscono perchè sul dispay lampeggia l’ora descritto.
•Premere il tasto centrale 1 volta. L1, L2, L3 IMPOSTA SEGNALE ACUSTICO
•Imposta l'ora con i tasti ▼ ▲ •Premere il tasto centrale 5 volta
•Lasciare i tasti. •Imposta l'ora con i tasti ▼ ▲
•Lasciare i tasti.
ATTENZIONE: il forno funziona solo se impostato in manuale o cottura programmata
N.B.: per regolare le varie funzioni del forno, in alcuni modelli compaiono i simboli o in altri modelli abbiamo - o +
26 IT
12:00 ) è la regolazione dell’ora, come di seguito
3.7 TIMER ELETTRONICO A SFIORAMENTO
FUNZIONE
CONTAMINUTI
DURATA
COTTURA
FINE
COTTURA
BLOCCO
BAMBINO
COME SI ATTIVA
•Premere il tasto centrale 1 volta.
•Premere i tasti "- " "+" per regolare la durata
•Lasciare i tasti
•Premere il tasto centrale 2 volte
•Premere i tasti "- " "+" per regolare la durata
•Lasciare i tasti
•Selezionare la funzione di cottura con la manopola commutatore
•Premere il tasto centrale 3 volte
•Premere i tasti "- " "+" per regolare l’ora di fine cottura
•Lasciare i tasti
•Selezionare la funzione di cottura con la manopola commutatore
•Tenere premuto per 5 secondi il tasto (+), Da questo momento lo schermo visualizza alternativamente “STOP” e il tempo preimpostato.
COME SI SPEGNE COSA FA A COSA SERVE
•Al termine della durata impostata la funzione si spegne da sola ed avvisa con un segnale sonoro (il segnale sonoro si ferma da solo; per fermarlo subito premere il tasto) SELECT.
•Al termine della durata impostata il forno si spegne da solo; se deve essere fermato prima si deve portare la manopola commutatore in posizione O oppure portare a 0:00 la durata della cottura (tasti SELECT e "- " "+").
•All’ora impostata il forno si spegne da solo; se deve essere fermato prima è necessario portare la manopola commutatore in posizione O.
•Tenere premuto per 5 secondi il tasto (+). Da questo momento tutle le funzioni sono riabilitate.
•Da un segnale sonoro al termine di un tempo stabilito
•Durante il funzionamento il display visualizza il tempo rimanente.
•Permette di impostare la durata della cottura del cibo inserito nel forno
•Per visualizzare il tempo rimanente premere il tasto SELECT.
•Per modificare il tempo rimanente premere il tasto SELECT +"- " "+"
•Permette di memorizzare l’ora di fine cottura
•Per visualizzare l’ora programmata premere il tasto centrale 3 volte
•Per modificare l’ora programmata premere i tasti SELECT + "- " "+"
•Permette di utilizzare il programmatore del forno come una sveglia (può essere usato con forno funzionante o spento.
•Per interrompere il segnale premere un tasto qualsiasi. Premere il tasto centrale per tornare alla funzione orologio.
•Tipicamente si utilizza questa funzione con la funzione DURATA COTTURA–ad esempio il cibo desiderato deve cuocere per 45 minuti e desidero che sia pronto per le ore 12:30; in tal caso:
•Al termine della durata impostata il forno si spegne automaticamente ed avvisa con un segnale sonoro.
Selezionare la funzione di cottura desiderata Impostare la durata cottura a 45 minuti ( "- " "+") Impostare la fine cottura alle ore 12:30 ( "- " "+" )
La cottura avrà auto­maticamente inizio alle 11:45 (12:30 meno 45 minuti), all’ora impostata come fine cottura il forno si spegne automaticamente.
ATTENZIONE: impostando solo la fine cottura e non la durata della cottura, il forno si accenderà subito e si spegnerà all’ora di fine cottura impostata
3.8 REGOLAZIONE ORA
ATTENZIONE: la prima operazione da eseguire dopo l’installazione o dopo una interruzione di corrente (tali situazioni si riconoscono perchè sul dispay lampeggia l’ora
00:00

ATTENZIONE: Il forno funziona solo se impostato in modalità manuale o cottura programmata.
descritto.
•Premere il tasto centrale 4 volte.
•Imposta l'ora con i tasti "- " "+".
•Lasciare i tasti.
12:00 ) è la regolazione dell’ora, come di seguito
27 IT
4. ISTRUZIONI PER L’USO
Temperatura
Manopola
commutatore
proposta
e regolazione
(Type A)
220
50 ÷ 240
200
50 ÷ 230
Manopola
termostato
50 ÷ MAX
50 ÷ MAX
FUNZIONE
Accende la luce interna.
Scongelamento
Questa posizione permette di far circolare l’aria a temperatura ambiente intorno al cibo surgelato facendolo così scongelare in pochi minuti senza modificare od alterare il contenuto proteico.
Convezione naturale
Sono in funzione le resistenze superiore e inferiore. È la cottura tradizionale, ottima per arrostire cosciotti, selvaggina, ideale per biscotti, mele al forno e per rendere i cibi molto croccanti
Forno ventilato
L’aria calda, viene ripartita sui diversi ripiani; è l’ideale per cuocere contemporaneament e diversi tipi di cibo (carne, pesce), senza miscelare sapori e odori. Cottura delicata ­indicata per pan di Spagna, torte Margherita, pasta sfoglia, ecc...
160
50 ÷ 200
Level 4
1 ÷ 4
190
180 ÷ 200
Level 4
1 ÷ 4
220
50 ÷ MAX
50 ÷ MAX
50 ÷ 200
50 ÷ 200
50 ÷ MAX
Suola ventilata
Adatta per cotture delicate (torte-soufflè).
Grigliatura tradizionale a porta chiusa
In questa posizione viene inserita la resistenza del grill. Ottima nella cottura di carni di medie e piccolo spessore (salsicce, costine, bacon).
TURBO-GRILL (a) : l'utilizzo del turbo-grill richiede la porta chiusa. Utilizzando la ventilazione e la resistenza cielo contemporaneamente. Si cuociono perfettamente grandi pezzi di cibo, come arrosti, pollame, ecc.. Mettete la griglia a metà del forno e posizione la leccarda sotto di essa per raccogliere i grassi. Assicuratevi che il cibo non sia troppo vicino al grill. Girate la carne a metà cottura.
Grill più girarrosto
Inserimento resistenza grill e motorino girarrosto. Serve per effettuare cotture allo spiedo.
Funzione pizza
Il calore avvolgente in questa funzione ricrea un ambiente simile a quello dei forni a legna di pizzeria.
* Programma di prova secondo CENELEC EN 50304 ** Programma di prova secondo CENELEC EN 50304 utilizzato per la definizione della classe energetica.
28 IT
5. TABELLA TEMPI DI COTTURA
I tempi suggeriti nelle seguenti tabelle sono indicativi, infatti possono variare secondo la qualità, la freschezza, la dimensione e lo spessore degli alimenti e secondo il vostro gusto. Lasciare sempre riposare per alcuni minuti prima di servire, perché tutti gli alimenti continuano a cuocere dopo averli tolti dal forno.
CONSIGLIO UTILE: Per non rendere le superfici troppo secche è consigliato abbassare la temperatura e allungare i tempi di cottura.
Forno elettrico statico Forno elettrico ventilato
Pietanza
Quantità
Ripiano
Tempo
di cottura
in minuti
Tempe-
ratura
forno
• Pasta
Lasagne
Cannelloni
Pasta al forno
Kg 3,5
Kg 1,8
Kg 2,5
22 22 22
70 ÷ 75
50 ÷ 60
55 ÷ 60
220
220
220
• Paste salate
Pane
Pizze
Pasta sfoglia Vol au vent
Focaccia (n° 4)
(Surgelati)
Kg 1
di pasta
Kg 1
n° 24
gr. 200
di pasta cad
22
35
prerisc.10
25 ÷ 35
30 ÷ 35
25 ÷ 30
200
190
220
200
Ripiano
11
21
22
Posizione ripiani
Tempo
di cottura
in minuti
Tempe-
ratura
forno
60 ÷ 65 40 ÷ 50 45 ÷ 50
30 ÷ 35
prerisc.10
20 ÷ 25
25 ÷ 30
20 ÷ 25
Osservazioni
200 200 200
180
190
200
180
Inserire le lasagne nel forno freddo
Inserire i cannelloni nel forno freddo
Inserire la pasta al forno nel forno freddo
Preparate la pasta a forma di pagnotta e incidere con un coltello una croce sulla parte superiore della forma. Lasciare lievitare a temperatura ambiente almeno 2 ore, ungere la leccarda e posizionate la forma bene al centro della stessa.
Preriscaldate per 15min. il forno e preparate le pizze nella leccarda smaltata con pomodori, mozzarella e prosciutto, olio, sale, origano
Disponete 24 vol au vent nella leccarda e cuocete.
Preriscaldate per 15 min., ungere la teglia del forno, disporre le 4 focacce oliate e salate prima di infornare, lasciare lievitare a temperatura ambiente per almeno 2 ore
4 3 2 1
• Carne
Tutte le carni possono essere cotte in recipiente con bordo basso o bordo alto. È consigliabile coprire il recipiente a bordo basso con un coperchio per evitare di sporcare il forno con schizzi del condimento. Le carni coperte risultano più morbide e succose, mentre quelle scoperte risultano più croccanti. I tempi indicati valgono per cotture con recipiente coperto o scoperto.
Roastbeef intero
Arrosto di maiale arrotolato
Arrosto di vitello arrotolato
Arrosto di manzo filetto
• Fish
• Pesci
Trota
Salmone
Sogliola
Orata
Kg 1
Kg 1
Kg 1,3
Kg 1
3 intere/Kg 1
700 g a fette
2,5 cm s.p.
Filetti / Kg 1
2 intere
70 ÷ 80
100 ÷ 110
90 ÷ 110
80 ÷ 90
40 ÷ 45
30 ÷ 35
40 ÷ 45
40 ÷ 45 220
220
220
220
220
220
220
220
33
22
21
22
22
22
22
22
50 ÷ 60
80 ÷ 90
90 ÷ 100
80 ÷ 90
35 ÷ 40
30 ÷ 25
35 ÷ 40
35 ÷ 40
200
Disporre la carne in una teglia Pirex a bordo alto con sale pepe. Voltare a metà cottura
Cuocere come sopra
200
Cuocere come sopra
200
Cuocere come sopra
200
Cuocere le trote coperte con olio, sale e
200
cipolle in teglia Pirex.
Cuocere il salmone non coperto in teglia
200
Pirex con sale, pepe e olio.
Cuocete la sogliola con sale e un
200
cucchiaio d’olio.
Cuocere in recipiente coperto le orate con
200
olio e sale
29 IT
5. TABELLA TEMPI DI COTTURA
Forno elettrico statico Forno elettrico ventilato
Pietanza
Quantità
Ripiano
Tempo
di cottura
in minuti
Tempe-
ratura
forno
Ripiano
Tempo
di cottura
in minuti
Tempe-
ratura
forno
Osservazioni
• Pollame, Coniglio
Faraona
Pollo
Coniglio a pezzi
Kg 1-1,3
Kg 1,5-1,7
Kg 1-1,2
22
22
22
60 ÷ 80
110 ÷ 120
55 ÷ 65
220
220
220
60 ÷ 70
100 ÷ 110
50 ÷ 60
200
200
200
Sistemare la faraona in teglia Pirex o ceramica a bordo alto condita con aromi naturali e pochissimo olio.
Come per la faraona
Mettete i pezzi di uguali dimensioni nella leccarda smaltata, condite con aromi naturali. Se necessario voltate i pezzi.
• Dolci, Torte
Torta cacao
Torta margherita
Torta di carote Torta crostata
albicocca
Scatola
Scatola
Scatola
700 gr
1
1
1
1
55
55
65
40
180
175
180
200
1
1
1
2
50
40 ÷ 45
50 ÷ 60
30 ÷ 35
160
160
160
180
In teglia per torte Ø 22. Prerisc. per 10 min. In teglia per torte Ø 22. Prerisc. per 10 min.
In teglia per torte Ø 22. Prerisc. per 10 min.
In teglia per torte Ø 22. Prerisc. per 10 min.
• Verdura
Disponete i finocchi tagliati in 4 parti e
Finocchi
Zucchine
Patate
Carote
800 gr
800 gr
800 gr
800 gr
1
1
2
1
70 ÷ 80
70
60 ÷ 65
80 ÷ 85
220
220
220
220
1
1
2
1
60 ÷ 70
60 ÷ 70
60 ÷ 65
70 ÷ 80
200
200
200
200
coperti in teglia di Pirex con burro e sale e possibilmente con la parte interna verso l’alto
Affettate le zucchine e cuocete in teglia Pirex coperte con burro e sale Tagliate le patate in parti uguali e cuocetele coperte con olio, sale e origano o rosmarino in teglia Pirex.
Tagliate le carote a fettine, copritele e cuocetele in teglia Pirex.
• Frutta
Mele intere
Pere Pesche
Kg 1
Kg 1 Kg 1
1
1 1
45 ÷ 55
45 ÷ 55 45 ÷ 55
220
220 220
2
2 2
45 ÷ 55
45 ÷ 55 45 ÷ 55
200
200 200
Cuocere la frutta in teglia di Pirex o ceramica non coperta. Lasciare raffreddare in forno.
Come sopra Come sopra
• Cottura a grill
La cottura con il grill deve essere eseguita ponendo il cibo sotto il grill elettrico. Attenzione: durante il funzionamento il grill diventa di colore rosso vivo. La leccarda deve essere inserita sotto la griglia per raccogliere i sughi.
Pane carrè tostato
Toasts farciti
Salsiccie
Costate di manzo
Coscie di pollo
4 fette
4
n°6 / Kg 0,9
n°4 / Kg 1,5
n°4 / Kg 1,5
Inserire il pane carrè sulla griglia supporto.
44
5 (5 prerisc.)
10 (5 prerisc.)
33
44
44
33
25/30
(5 prerisc.)
25
(5 prerisc.)
50/60
(5 prerisc.)
Grill Grill
Grill Grill
Grill Grill
Grill Grill
Grill Grill
5 (10 prerisc.)
5/8
(10 prerisc.)
15/20
(10 prerisc.)
15/20
(10 prerisc.)
50/60
(10 prerisc.)
Dopo la 1° cottura capovolgere fino a cottura ultimata.
Inserire i toasts sulla griglia supporto leccarda;dopo la prima brunitura capovolgere i toasts fino a brunitura ultimata.
Tagliare le salsiccie a metà e disporle sulla griglia, con la parte interna verso l’alto. A metà cottura capovolgere le salsiccie fino a cottura ultimata. Avvertenza: ogni tanto controllate visivamente l’uniformità di cottura. Nel caso di disuniformità intercambiare quelle cotte con quelle meno cotte.
Disporre le fette bene sotto l’azione del grill e voltarle due volte.
Condite con aromi naturali e voltatele ogni tanto.
30 IT
INSTALLATION
GB
TRMONTAJ
INSTALLAZIONE
IT
545
Rating plateGB Ürün tanıtım etiketiTR
Targhetta matricola
IT
545
4x3.5x25
GB
The manufacturer will not be responsible for any inaccuracy resulting from printing or transcript errors contained in this brochure. We reserve the right to carry out modifications to products as required, including the interests of consumption, without prejudice to the characteristics relating to safety or function.
TR
Üretici bu kullanma kılavuzunda bulunabilecek baskı veya tercüme hatalarından dolayı herhangi bir sorumluluk üstlenmez. Cihaz üzerinde güvenlik veya işlevsellik karakteristiklerinden ödün vermeksizin tüketim faydaları da dahil olmak üzere, gerekli görülen değişiklikleri yapma hakkımızı saklı tutuyoruz.
IT
La Ditta costruttrice declina ogni responsabilità per eventuali errori di stampa contenuti nel presente libretto. Si riserva inoltre il diritto di apportare le modifiche che si renderanno utili ai propri prodotti senza compromettere le caratteristiche essenziali.
12.2013 • REV:0 • 42812940
Loading...
