Hoover DXC85TCEX-AUS User Manual

DX C85TCEX-AUS

Please read and follow these instructions carefully and operate the machine accordingly. This booklet provides important gu ide lines fo r sa fe u se, install ati on, maintenance and some useful advice for best

results when using your machine.

Keep all documentation in a safe place for future reference or for any future owners.

Please check that the following items are delivered with the appliance:

● Instruction manual

● Guarantee card

● Energy label

By placing the mark on this product, we are confirming compliance to all relevant European safety, health and environmental requirements which are applicable in legislation for this product.

Index

1. SAFETY REMINDERS

2. DRAIN HOSE KIT: FITTING

INSTRUCTIONS

3. PREPARING THE LOAD

4. CLEANING AND ROUTINE MAINTENANCE

5. WATER CONTAINER

6. DOOR AND FILTER AND CONDENSER

7. CONTROLS AND INDICATORS

8. SELECTING THE PROGRAMME AND SET THE FUNCTION

9. TROUBLESHOOTING CUSTOMER SERVICE

Check that no damage has occurred

to the machine during transit. If it has,

above can compromise the safety of the appliance. You may be charged for a service call if a problem with your machine is caused by misuse.

Failure to comply with thecall for service.

SAFETY REMINDERS

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

●

WARNING Misuse

of a tumble

dryer may create a fire hazard.

●

This appliances is intended to be used in household and similar applications such as:

Staff kitchen areas in shops , offices and other working environments;

Farm houses;

By clients in hotels, motels and

o t h e r r e s i d e n t i a l t y p e environments;

Bed a n d bre akfa st ty pe environments. A different use of this appliance

from household environment or from typical housekeeping functions,as commercial use by expert or trained users, is excluded even in the above applications.

If the appliance is used in a

manner inconsistent with this it may reduce the life of the appliance and may void the manufacturer’s warranty. Any damage to the appliance or other damage or loss arising through use that is not consistent with domestic or household use ( even if located in a domestic or household e n v i r o n m e n t) shall not be accepted by the manufacturer to the fullest extent permitted by law.

● This machine should only be used for its intended purpose as described in this manual.

Ensure that the instructions for installation and use are fully unde rstood before operating the appliance.

● Do not touch the appliance

when hands or feet are damp or wet.

● Do not lean on the door when

loading the machine or use the door to lift or move the machine.

● Do not allow children to play

with the machine or its controls.

WARNING Do

not use the product if the lint filter is not in position or is

damaged; lint

could be ignited.

WARNING Where

the hot surface symbol is located the temperature rise during

operation of the tumble dryer may be in excess of 60 degrees C. Remove the plug from the

electricity supply. Always remove the plug before

cleaning the appliance.

Do not continue to use this machine if it appears to be faulty.

Lint

must not be allowed to

collect on the floor around the

outside of the machine.

The final part of a tumble dryer cycle occurs without heat (cool

down cycle) to ensure that the items are left at a temperature that ensures that the items will not be damaged. The tumble dryer is not to be used if industrial chemicals have been used for cleaning. WARNING: Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.

Maximum load drying weight : see energy label.

You will find this symbol on your appliance. It indicates surfaces that become hot when the appliance is in use, care is required around these areas.

This symbol indicates there is a risk of fire if the appliance is not used correctly.

WARNING:

Flammable materials. Read these warnings

carefully to avoid the possible danger fire.

Installation

●

Do not use adapters, multiple connectors and/or extensions.

●

Never install the dryer against curtains and be sure to prevent items from falling or collecting behind the dryer.

●

The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the tumble dryer.

of fire/ Risk

The Laundry

Do not dry unwashed items in the tumble dryer. WARNING Do not tumble dry

fa b ri cs tr ea te d w it h d ry cleaning fluids. WAR N I N G F o a m

r u b b e r materials can, under certain circumstances, when heated

b e c o m e i g n i t e d b y sponta neous combu s tion. Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads MUST NOT be dried in the tumble dryer.

Always refer to the laundry care la be l s fo r d i r ec ti on s on suitability for drying. Clothes should be spin dried or thoroughly wrung before they are put into the tumble dryer.

Clothes that are dripping wet should not be put into the dryer.

Lighters and matches must not be left in pockets and NEVER use flammable liquids near the

machine.

Glass fibre curtains should NEVER be put in this machine. Skin irritation may occur if other

garments are contaminated with the glass fibres.

Items that have been soiled with substances such as

cooking oil, acetone, alcohol,

p et r o l , ke r os en e, sp ot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer.

● Fabric softeners, or similar products, should be used as specified by the fabric softener instructions.

Ventilation

Adequate ventilation must be provided in the room where the tumble dryer is located to prevent gases from appliances burning other fuels, including open fires, being drawn into the room during operation of the tumble dryer. Installing the rear of the appliance close to a wall or vertical surface. There should be a gap of at least 12 mm between the m a c h i n e a n d a n y obstrubtions.The inlet and outlet should be kept clear of ob s t r uc t io n . To e ns u re adequate ventilation the space between the bottom of the machine and the floor must not be obstructed. Check regularly that the air flowing through the dryer is not restricted.

●

After each use check the lint

filter and clean out any lint.

●

Prevent items from falling or collecting behind the dryer as these may obstruct the air inlet and outlet.

●

NEVER install the dryer up

against curtains.

●

In cases where the dryer is installed on top of a washing machine, a suitable stacking kit must be used according to the follow configuration.

Stacking kit Mod 35100019: for

minimum washing machine depth 49 cm.

Stacking kit Mod 35900120: for minimum washing machine depth 51 cm.

The stacking kit shall be one of that above, obtainable from our spare service. The instructions for installation and any fixing attachments, are provided with the staking kit.

• Oil-affected items can ignite spontaneously, especially when exposed to heat sources

such as in a tumble dryer. The items become warm, causing an oxidation reaction in the oil.

Oxidation creates heat. If the

item s heat cannot escape, the can become hot enough to catch fire. Pilling, stacking or storing oil-affected items can prevent heat from escaping and so create a fire hazard.

• If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair care products be placed in a tumble dryer they should first be washed in hot water with extra detergent- this will reduce but not eliminate, the hazard.

• For appliances with ventilation openings in the base, carpet must not obstruct the openings.

Do not install the product in a low temperature room or in a room where there is a risk of frost occurring. At temperatures around freezing point the product may not be able to operate properly: there is a risk of damage if the water is allowed to freeze in the hydraulic circuit (valves, hoses, pumps). For a better product performance the ambient room temperature must be between 5-35° C. Please not e the operating conditions in cold

may (between +2 and +5°C) create some water condensation and water drops on floor.
