Honeywell T6000 User Manual

T6000 Series

Thera-3

RADIATOR THERMOSTATS WITH ERGONOMICAL DESIGN

PRODUCT DATA

Application

Thermostats are installed onto thermostatic valve bodies
(TRV bodies). The combination of thermostat and TRV body,
(TRV), controls the room temperature by regulating the flow
of heating water into a heat exchanger.

TRVs are installed in water-based heating systems at the
supply or, less commonly at the return connection of radiators
or other heat exchangers.

Thera-3 type thermostats conform to the European Standard
EN215 when used with Honeywell TRV bodies according to
table 2 on page 8.

Thera-3

eywell TRV bodies and radiator inserts as well as other TRV
bodies and radiator inserts with M30 x 1,5 connection and
11,5 mm closing dimension.

Thera-3-DA

TRV bodies and valve inserts with a Danfoss RA type com­patible snap connection.

Thera-3-HZ

bodies with M28 x 1,5 connection and 9,5 mm closing dimen­sion.

M30 x 1,5 connection

with

Danfoss type connection

with

Herz type connection

with

are suitable for all Hon-

are suitable for

are suitable for TRV

Design

The thermostat consists of:

•

Handwheel with lid and socket

•

Sensor with support cage

•

Spindle assembly

•

Connection nut

Materials

•

Handwheel, lid and socket made of plastic, white to

RAL9010 or anthracite

•

Support cage and spindle construction made of plastic

•

Sensor filled with liquid or wax

•

Connection nut made of brass, nickel-plated

Features

• Thera-3 with M30 x 1.5 connection conforms to Euro-

pean standard EN215

• Available with liquid- or wax-filled sensing element

• Modern ergonomical design

• Equipped with easy to use limiting tabs

Specifications

Thermostat connection

Setpoint range

Temperature range

Closing dimension

NOTE: Zero-position is also thermostatically controlled –

when temperature falls the TRV may open.

• M30 x 1,5

• Danfoss type snap connection

• M28 x 1,5 (HZ-type)

• 0 - ! - 1..5 (with zero-position)

• ! - 1..5 (without zero-position)

With zero-position (‘0’):

1...28°C (34...82°F)

Without zero-position:

6...28°C (43...82°F)

11,5 mm (Thera-3)
9,5 mm (Thera-3-HZ)

Copyright © 2001 Honeywell AG • All rights reserved EN0H-0154GE25 R1001

THERA-3 (T6000 SERIES)

Dimensions

Fig. 1. Thera-3 with internal sensor Fig. 2. Thera-3 with remote sensor

Table 1. Dimensions

Item H closed H open Ø L

Fig. 1 and Fig. 2 87 93 60 0,8 – 2,0 – 5,0 – 8,0 m

All dimensions in mm if not stated differently.

Accessories

Theft-protection ring, white

TA6900A001

Screwdriver for theft-protection ring

TA6900B001

Cover cap for customer specific logos, white

TA6000A001

Trim ring, white

Cover ring, white

Adapters

DA-Adapter from Danfoss
snap connection to M30 x 1.5

HZ-Adapter from M28 x 1.5
with 9,5 mm closing dimen­sion to M30 x 1.5 with
11,5 mm closing dimension

TA1000B001

TA1000A001

TA1010DA01

TA1010HZ01

EN0H-0154GE25 R1001 2 Honeywell AG • All rights reserved

Ordering Information

THERA-3 (T6000 SERIES)

Item Zero-

position

(‘0’)

Thera-3, Thera-3-DA and Thera-3-HZ with internal sensor

Liquid-filled sensing element M30 x 1,5 — white MNG T6001

• M30 x 1,5 — white MNG T6001W0

• M30 x 1,5 — white none T6001W0C

• M30 x 1,5 — white Honeywell T6001W0H

• M30 x 1,5 — anthracite MNG T6011W0

• DA type — white MNG T6001DAW0

• DA type — white none T6001DAW0C

• DA type — white Honeywell T6001DAW0H

• M28 x 1,5 — white MNG T6001HZW0

Wax-filled sensing element M30 x 1,5 — white MNG T6002

• M30 x 1,5 — white MNG T6002W0

• M30 x 1,5 — white none T6002W0C

• M30 x 1,5 — white Honeywell T6002W0H

Thera-3 and Thera-3-DA with remote sensor

Liquid-filled sensing element M30 x 1,5 0,8 m white MNG T600108

• M30 x 1,5 0,8 m white MNG T600108W0

• M30 x 1,5 2,0 m white MNG T600120W0

• M30 x 1,5 5,0 m white MNG T600150W0

• M30 x 1,5 8,0 m white MNG T600180W0

• M30 x 1,5 0,8 m white Honeywell T600108W0H

• M30 x 1,5 2,0 m white Honeywell T600120W0H

• DA type 2,0 m white MNG T600120DAW0

Connection Capillary

tube length

M30 x 1,5 — white none T6001C

M30 x 1,5 — white Honeywell T6001H

M30 x 1,5 — anthracite MNG T6011

DA type — white MNG T6001DA

DA type — white none T6001DAC

DA type — white Honeywell T6001DAH

M28 x 1,5 — white MNG T6001HZ

M30 x 1,5 — white none T6002C

M30 x 1,5 — white Honeywell T6002H

M30 x 1,5 2,0 m white MNG T600120

M30 x 1,5 5,0 m white MNG T600150

M30 x 1,5 8,0 m white MNG T600180

DA type 2,0 m white MNG T600120DA

Colour Cap OS-No.

Honeywell AG • All rights reserved 3 EN0H-0154GE25 R1001

THERA-3 (T6000 SERIES)

EN215 Information

OS-Nos. T6001, T6001W0, T6002, T6002W0, T6001xx and T6001xxW0 type Thera-3 thermostats in connection with below
TRV bodies (marked ●) conform to the European Standard EN215. The highlighted boxes identify available body patterns of
one certain valve type.

Table 2. Comparison of Thera-3 specs and EN 215 requirements

Thera-3 EN 215 requirements
Min. setpoint temperature
Max. setpoint temperature
Hysteresis ≤
Influence of differential pressure
Influence of static pressure
Influence of heating medium
Response time

NOTE: Influence of differential pressure depends on used TRV body.

6°C (43°F) 5...12°C (41...54°F)

28°C (82°F)

0,3K

0,1...0,5K

0,4K

0,4K

22 min.

≤

32°C (90°F)

≤
≤
≤
≤

≤

40 min.

Table 3. EN 215 cross reference

1,0K

1,0K

1,0K

1,5K

Valve type

BB

3

KV

4

KV

5

KV

UBG

GB

SL

V

FV

SC

H

Angle to

DIN

Straight to

DIN

Angle toNFStraight toNFCompact

angle

• • • • • •

• • • •

• • • •

• • • •

• • • • • •

• • • • • •

Compact

straight

Horizontal

angle

Corner

angle

Swanneck

Other

Angle (re-

turn)

Straight

(return)

•

EN0H-0154GE25 R1001 4 Honeywell AG • All rights reserved

Setpoint

Thera-3 type thermostats with zero-position (‘0’)

Setpoint 0

°C

°F

Thera-3 type thermostats without zero-position (‘0’)

Setpoint

°C

°F

!

12345

1 6 12 16 20 24 28

34 43 54 61 68 75 82

!

12345

6 1216202428

43 54 61 68 75 82

Installation Examples

THERA-3 (T6000 SERIES)

NOTE: All °C and °F-values approximate.
NOTE: Heating can freeze when thermostats with zero-

position are set at position ‘0’.

NOTE: Zero-position is also thermostatically controlled –

when temperature falls the TRV may open.

Fig. 3. Installation of Thera-3 with internal sensor

Fig. 4. Installation of Thera-3 with remote sensor

Honeywell AG • All rights reserved 5 EN0H-0154GE25 R1001

THERA-3 (T6000 SERIES)
