Honeywell EDA50-111, EDA50-011 User Manual

ScanPal EDA50

Enterprise Hybrid Device
(Model EDA50-011/EDA50-111)

Android™ 4.4 OS version

User Guide

ScanPal EDA50 Enterprise Hybrid Device User Guide i

Disclaimer

Honeywell International Inc. (abbr. HII) reserves the rights to modify the specifications and
other information mentioned in this User Guide without prior notification. In any case, users
should confirm with HII whether any changes were made. This publication does not represent
any commitments of HII.

HII is not responsible for any technical or editing errors or omissions contained in this manual,
nor for any incidents or indirect damages caused by providing, implementing or using this
material. HII is not responsible for the softwares or hardwares selected or used in orde r to
achieve the desired results.

The proprietary information contained in this article is protected by copyright. All rights
reserved. Without prior written consent from HII, any form of photocopy, copy or translation
into other languages is not allowed.

Trademark Rights

Android, Google and other marks are trademarks of Google Inc.
The Bluetooth trademarks are owned by Bluetooth SIG, Inc. U.S.A. and licensed to Honeywell

International Inc.
Other product names mentioned in this manual may be trademarks or registered trademarks

of their respective companies, which are owned by these companies.

Patents

For information on patents, please refer to www.hsmpats.com.

Copyright © 2016 Honeywell International Inc. All rights reserved.

ii ScanPal EDA50 Enterprise Hybrid Device User Guide

Content

Content

1 Features of ScanPal EDA50 Enterprise Hybrid Device ................................................. 1

EDA50 Brief Introduction ..................................................................................................... 2

Battery ................................................................................................................................. 6

Charging ..................................................................................................................... 6

Replacing batteries ..................................................................................................... 7

Battery icon ............................................................................................................... 10

Changing power indicators ....................................................................................... 12

Checking the remaining battery capacity .................................................................. 13

Battery life and maintenance .................................................................................... 13

Enabling Airplane mode ............................................................................................ 15

Powering on ....................................................................................................................... 16

Unlocking the screen ......................................................................................................... 16

Scanning Indicator ............................................................................................................. 17

Setting screen backlight .................................................................................................... 18

Audio features .................................................................................................................... 18

Adjusting the ringtone volume for calls and messages ............................................ 18

Enabling vibration mode ........................................................................................... 20

Audio settings ........................................................................................................... 21

Inserting SD card ............................................................................................................... 22

File transfer ........................................................................................................................ 23

How to view files on EDA50 .............................................................................................. 23

EDA50's accessories ......................................................................................................... 24

2 User interface and applications ..................................................................................... 25

User interface .................................................................................................................... 26

The main interface .................................................................................................... 26

Navigation and function keys .................................................................................... 27

Status bar icons ........................................................................................................ 27

Key mapping ............................................................................................................. 28

Viewing system messages ....................................................................................... 29

Managing system messages .................................................................................... 29

Personalizing the main interface ............................................................................... 30

Customizing common applications ........................................................................... 30

ScanPal EDA50 Enterprise Hybrid Device User Guide iii

Content

Searching with Google™ .......................................................................................... 30

Touch screen gestures ............................................................................................. 31

Setting timezones ..................................................................................................... 31

Honeywell applications ...................................................................................................... 32

Unlocking developer options ............................................................................................. 32

3 Scan Function .................................................................................................................. 33

Scan Function .................................................................................................................... 34

How to transfer data via Android keyboard input ...................................................... 34

Changing scan settings ............................................................................................. 35

Restoring default scan settings ................................................................................. 36

Scanner default settings ........................................................................................... 36

Scanning barcodes ............................................................................................................ 43

4 Using Telecommunication Function ............................................................................. 44

Telecommunication Function ............................................................................................. 45

Activating UMTS calls ............................................................................................... 45

Making a call ............................................................................................................. 46

Answering a call ........................................................................................................ 47

Switching applications during a call .......................................................................... 47

Making an emergency call ................................................................................................. 47

Configuring call settings .................................................................................................... 47

5 Using Camera .................................................................................................................. 48

Color camera ..................................................................................................................... 49

Adjusting camera and video settings ................................................................................. 49

Zooming .................................................................................................................... 49

Changing camera settings ........................................................................................ 49

Taking photos .................................................................................................................... 49

Shooting videos ................................................................................................................. 50

Changing video settings .................................................................................................... 50

6 Terminal configurations .................................................................................................. 51

Terminal configurations ..................................................................................................... 52

Start Application Settings .......................................................................................... 52

Structure of the Application Settings ......................................................................... 52

Network communication .................................................................................................... 56

Connecting to Wi-Fi networks ................................................................................... 56

Connecting to a virtual private network ..................................................................... 59

Wireless Security ............................................................................................................... 60

Certificates ................................................................................................................ 60

Content

iv ScanPa l EDA5 0 Enterprise Hybrid Device User Guide

Bluetooth communication .................................................................................................. 62

Pairing with a Bluetooth-enabled device ................................................................... 62

Configuring Bluetooth settings .................................................................................. 64

Searching for EDA50 ................................................................................................ 64

Renaming or disconnecting a paired device ............................................................. 64

Communication via serial port and USB ............................................................................ 65

Near Field Communication ................................................................................................ 65

7 Management and maintenance ...................................................................................... 66

Upgrading system software ............................................................................................... 67

Upgrading AutoInstall application ............................................................................. 67

Upgrading composite key ......................................................................................... 67

Manually upgrading Recovery Menu ........................................................................ 67

Restarting the terminal ...................................................................................................... 68

Terminal resetting ..................................................................................................... 68

Restore factory settings ............................................................................................ 69

Cleaning the terminal ......................................................................................................... 69

Terminal disinfection .......................................................................................................... 70

8 Specifications .................................................................................................................. 71

Mechanical and environmental specifications ................................................................... 71

ScanPal EDA50 Enterprise Hybrid Device User Guide v

vi ScanPa l EDA5 0 Enterprise Hybrid Device User Guide

Technical Support

If you need installation or troubleshooting help, please contact us via:
Knowledge base: www.hsmknowledgebase.com
Honeywell knowledge base provides thousands of turnkey solutions. If the

knowledge base can't help you solve your problems, you can submit your
questions or ask question on Honeywell technical support website.

Technical support website: www.hsmsupportportal.com
Login Honeywell technical support website to search for knowledge base,

submit your difficulties or questions, ask for call-back services or provide
feedbacks. Please provide more detailed information when filling the forms. You
can also upload attachments for explanation.

Contacts: www.honeywellaidc.com/locations
For the latest contacts, please visit our website.

Product Service and Maintenance

Honeywell International Inc. provide services for all of its products all over the
world via its service centers. For information about the site of service centers,
please visit www.honeywellaidc.com and select English as preferred
language, then select Support > Contact Support > Service and
Maintenance. Please contact our service center to get RMA (Return Material
Authorization) numbers before sending the products for maintenance.

To get Honeywell service during warranty or out of warranty, please send the
product together with the purchase date records to Honeywell service center
(postage paid).

Limited Warranty

For information about the warranty, please visit www.honeywellaidc.com and
select Chinese as preferred language, tap Resources > Warran ty.

Feedback

Your feedback is very important for us to improve the quality of documentation.
Please contact technical communication departments to submit your feedback
on the User Guide: [e-mail].

ScanPal EDA50 Enterprise Hybrid Device User Guide vii

viii ScanPal EDA50 Enterprise Hybrid Device User Guide

1. Features of ScanPal EDA50 Enterprise Hybrid Device

1 Features of ScanPal EDA50

Enterprise Hybrid Device

EDA50 with Android 4.4 operating system will be introduced in this chapter.
Users can learn something about the main features, functions and accessories
of this terminal from this chanpter.

ScanPal EDA50 Enterprise Hybrid Device User Guide 1

1. Features of ScanPal EDA50 Enterprise Hybrid Device

EDA50 Brief Introduction

Honeywell EDA50 enterprise hybrid device is a smart phone for enterprise
users, delivering stable and secure enterprise data management and wireless
communications through Android operating system. The main features of
ScanPal EDA50 are: field-proven architure, large-screen display, high-capacity
battery, barcode imaging and ergonomic design.

• Android™ 4.4 OS

• 2 GB dynamic RAM, 8GB flash memory

• Large display with sensitive multi-touch screen.

• High-performance area imaging features with an ergonomic scan trigger.

• WCDMA / GSM wireless WA N communications ensure high-speed data
transmission and high-fidelity sound support for all network technologies.

• IEEE 802.11a/b/g/n.

• Bluetooth 4.0.

• Near-field com m unication (NFC) technology for short-range wireless data
transmission.

• High value-added software components support professional imaging and
optical character recognition (OCR) features.

• IP54 rated protection.

• Conveni ent Micro SD slot that supports up to 32GB expansion.

• Integrated GPS receiver (support WAN wireless communications).

• 5 mega pi xels color camera.

2 ScanPa l EDA50 Enterprise Hybrid Device User Guide

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Power
Indicator

Scan
Indicator

Display

Function
Key

Home Key

Return Key

EDA50 front view

ScanPal EDA50 Enterprise Hybrid Device User Guide 3

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Left Side View Right Side View

Power
Button

Reset
Button

Scan
Button

The Bottom

Volume
Up

Volume
Down

Scan
Button

Charging
Contact

USB
Cover

EDA50 side and bottom view

4 ScanPa l EDA50 Enterprise Hybrid Device User Guide

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Scan
Engine

Speaker

Camera

Battery Cover

Battery Cover
Buckle Handle

Battery
Cover

String
Buckle

Safety Lock

Battery Cover

Buckle
Battery Cover
Safety Button

EDA50 back view

ScanPal EDA50 Enterprise Hybrid Device User Guide 5

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Battery

EDA50 uses 3.8 v rechargable lithium ion battery as its main power supply. The
battery capacity is 15.2 watt/hour. Battery life is influenced by many factors,
such as: screen brightness, the length of time the device waits before the
screen automatically go to sleep, input configurations, extreme temperature and
using behaviors, etc.

Honeywell suggests you to keep the battery charged to avoid data loss. When
replacing the battery, the terminal will be automatically turned off and then you
need to cold start it.

If you need to buy a replacable battery, please contact regional resellers.

Warning: Improper use of the battery of this terminal can cause a fire or
chemical burns. Please don't disassemble the battery or heat it to 100 ° C
(212 ° F) or more, or incinerate the battery. Make sure waste batteries are
properly disposed. Keep out of reach of the children.

We recommend users to use Honeywell Li-ion battery pack. Damg aes
caused by using non-Honeywell batteries will not be covered by
Honeywell warranty.

Charging

Before using EDA50, you need to make sure the battery (model number BAT­EDA50) is fully charged. You can charge the battery before or after installing it
to EDA50. It will take about 4 hours for the battery to be fully charged,
regardless what kind of chargers are used:

Insert EDA50 with battery installed into the charger or cradle.

6 ScanPa l EDA50 Enterprise Hybrid Device User Guide

Replacing batteries

When the battery power is low, you can charge it together with the terminal, or
replace it with a fully-charged battery.

1. Save all the files and close all running apps.

2. Long press the power key. Until the follow interface pop up:

1. Features of ScanPal EDA50 Enterprise Hybrid Device

3. Tap Turn off.

4. EDA will ask whether to turn off, tap Yes.

ScanPal EDA50 Enterprise Hybrid Device User Guide 7

1. Features of ScanPal EDA50 Enterprise Hybrid Device
After it's turned off, do as the following instructions manually:

1. Press down the battery cover safety button to move the lock to the unlock

position at right;

2. Open the battery cover with the battery cover buckle handle;

8 ScanPa l EDA50 Enterprise Hybrid Device User Guide

1. Features of ScanPal EDA50 Enterprise Hybrid Device

3. Insert the battery (Insert the non-connector side first, then press the battery

down to establish connection between the battery and the phone)

4. Press down the battery cover

ScanPal EDA50 Enterprise Hybrid Device User Guide 9

1. Features of ScanPal EDA50 Enterprise Hybrid Device

5. Press down the battery cover safety button to move the battery cover safety

lock to the lock position at left

Battery icon

Battery icon on the status bar shows the power status of the battery. The
following table only contains several of the icons. For detailed information about
battery life and power remained, please go to Settings > Battery.

Battery icon

Icon Status

Battery power is 100% full

Battery power is 50% full

Battery power is too low. Replacing the battery right now.

The terminal has been connected to external power supply for

10 ScanPal EDA50 Enterprise Hybr id Device User Guide

charging.
Battery failure occurs. Please replace the battery. If the failure still

exists, please contact Honeywell technical support.

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Power indicator on the upper left corner of the terminal shows the battery
charging status. It can also be used as system message indicator. For detailed
setting methods, please refer to

http://developer.android.com/guide/topics/ui/notifiers/notifications.html.

Default power indicator description

Connect to
power supply

No

No No light

Yes

Yes Flashing green

Yes Stable green

Yes/no Flashing red Battery failure

Indicator status Description

Flashing amber
(Orange)

Stable amber
(Orange)

Battery power is less than 15%
full

Battery power is higher than
15% full

Battery power is between 0% to
60% full

Battery power is between 60%
to 95% full

Battery power is higher than
95% full

ScanPal EDA50 Enterprise Hybrid Device User Guide 11

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Changing power indicators

If the default indicators for battery charging (flashing green) is inappropriate for
your environment, you can change the indicator.

In addition to changing the default power indicator, you can also select:

• Default Battery LED

• No Battery LED
If you prefer the indicator to be solid amber and to change to solid green when

in charging, you need to perform Default Battery LED settings. If you prefer the
indicator as message notification (application or device management solution
notification) indicator, you need to select No Battery LED settings.

Default power indicator meanings

Connect to
power supply

No Flashing red

No No light Battery power is 15% or more

Yes Stable red

Yes Stable amber

Yes Stable green Battery power is over 90% full

1. Tap ll Applications > Settings > Battery LED

2. Select from the following options:

• Default Battery LED

• HSM Battery LED (Factory settings)

• No Battery LED

Indicator status Description

Battery power is less than 15%
full

Battery power is less than 15%
full

Battery power is between 15%
to 90% full

12 ScanPal EDA50 Enterprise Hybr id Device User Guide

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Checking the remaining battery capacity

Except for the battery icon and power indicator, you can also get the battery
capacity information from Settings.

1. Tap All Applications > Settings

2. Tap Battery. The current percentage of remaining battery capacity and the

remaining time will be displayed. The list will present the power consumed
by each application and service. For detailed usage information, please tap
the respective applications and services in the list.

Battery life and maintenance

The battery will discharge slowly if it's placed outside of the terminal.

Tips for battery maintenance

If you have the
following needs:

Low power icon
shows on the
screen or the
power indicator
lights on when the
terminal is in use

The terminal will
not be in use for 5
mins or more

The terminal will be
stored for more
than one day

Power saving plan:

Long press the power key and choose Turn Off.

Make sure no low power icon displayed and the power
indicators doesn't light on. Switch to sleep mode by
pressing the Power key.

• If you need to store this terminal for several days
(like a weekend), you need to install a fully
charged battery or connect the terminal to the
power supply.

• If you need to store it for a longer time, remove
the battery and charge it. Put the terminal and the
battery in a shady and cool place after the battery
is fully charged.

• If the battery is to be stored for several months,
regular charging is needed for excellent battery
performance.

ScanPal EDA50 Enterprise Hybrid Device User Guide 13

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Store the battery
outside the terminal

Put the battery in the charger.

14 ScanPal EDA50 Enterprise Hybr id Device User Guide

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Battery maintenance recommendations and safety
protection measures

• Fully charge the battery before using it. The battery is only partly charged
when get packed.

• Refer to the chapter "charging" to get the right process for battery charging.
Using the battery for other devices may cause damages on the device or
the battery.

• Avoid battery or terminal drops. If you suspect that a battery or terminal
fails, send it to Honeywell service center for verification.

• This battery can only replace another BAT-EDA50 battery. These batteries
have been tested and meet the appropriate safety standards. If you need to
replace the battery, please contact Honeywell service representatives or
the resellers.

• There are security risks in waste batteries. Before cleaning up the battery,
stick the poles with insulation tape.

• Do not modify the battery or attempt to insert foreign objects into the
battery.

• Do not solder directl y to the battery poles.

• Do not short connect the batter y and put the battery away from metal
objects.

• Do not drop or mecha nica lly shock or extrude the battery.

• Do not disassemble or o pe n the battery. Do not crush, bend or deform the
battery; Do not puncture, shred or burn the battery.

• Do not immerse the battery in water.

Enabling Airplane mode

If you don't need to connect to any wireless network, you can enable the
airplane mode to turn off all wireless receivers to save power.

1. Tap Settings.

2. Tap More under Wireless & Networks.

3. Select Airplane Mode box to enable airplane mode.

ScanPal EDA50 Enterprise Hybrid Device User Guide 15

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Powering on

After the battery is fully charged and installed into ScanPal EDA50, turn on it for
the first time:

Press down and then release the power key.
Please note: after complete the installation instructions, the welcome interface

will not appear again. The interface appears as locked screen interface after
each time you turn on the terminal.

Unlocking the screen

Every time you turn on the terminal, you need to unlock the screen.

• Slide the lock icon to any edge of the screen to unlock it.

• After the EDA50 is deployed, we suggest you to set password to protect
your terminal. Tap All Applications > Settings > Security > Encryption.

16 ScanPal EDA50 Enterprise Hybr id Device User Guide

Scanning Indicator

The scanning indicator indicates the status of the scanner. For barcode
scanning method, please refer to the chapter "Scanning barcodes".

Scanning
Indicator

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Scanning indicator definition

Light of the
indicator

Green Good read for the barcodes

Red Barcodes reading failed

ScanPal EDA50 Enterprise Hybrid Device User Guide 17

Meanings

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Setting screen backlight

The terminal's screen is equipped with background light sensor which can
automatically adjust backlight intensity to save power and ensure the display
readability. You may set the backlight intensity based on the environment.

1. Tap Settings.

2. Tap Display > Brightness

3. Tap Auto to automatically adjust the backlight intensity, or slide adjustment
bar to set the backlight intensity.

Audio features

EDA50 is equipped with speaker, receiver and software utilities for volume
setting.

Adjusting the ringtone volume for calls and messages

With the volume key on the side of the terminal, you can quickly adjust the
ringtone volume.

Note: Volume key can only adjust ringtone volume for calls and messages. To
adjust volumes of other sound, open Settings, and tap Sound > Volumes.

18 ScanPal EDA50 Enterprise Hybr id Device User Guide

1. Features of ScanPal EDA50 Enterprise Hybrid Device

1. Press the key on the right side of the terminal (+ or -). Volume bar will show
on the screen.

2. Adjust the volume by pressing volume key or slide volume bar.

ScanPal EDA50 Enterprise Hybrid Device User Guide 19

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Enabling vibration mode

In office environment, you can enable the vibration mode for the terminal and
mute the speakers.

1. Long press the power key. Power options will be displayed on the screen:

2. Tap

20 ScanPal EDA50 Enterprise Hybr id Device User Guide

Enabling vibration mode.

Audio settings

This chapter will describe about audio and sound settings. To change audio
setting, go to Settings and tap Sound.

Audio and sound settings

Settings Description

Volume

Ringtones
(Model EDA50-

111)

Vibrates when
ringing
(Model EDA50-

111)

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Use the volume adjustment bar to set the volume for:
Music, videos, games and other medias.
Ringtones for calls and message notifications. They

can also be adjusted by the volume key on the side of
the phone.

Alarm and alert tones

Select one of the rigntones

If checked, the terminal will vibrates when a call is in

Default notification
tone

Dialpad touch
tones
(Model EDA50-

111)

Touch tones If checked, touch tone will be enabled

Lock-screen tone If checked, lock-screen tone will be enabled

Touch vibration

ScanPal EDA50 Enterprise Hybrid Device User Guide 21

Select notifications tones

If checked, the dial tone will be enabled

If checked, the terminal will vibrates when you touch
Function key, Home key, Return key, All Application

icon

and lock or unlock screen

1. Features of ScanPal EDA50 Enterprise Hybrid Device

Inserting SD card

You can use a SD card to expand the memory or to install softwares. Honeywell
recommend the using of Single Level Cell (SLC) graded SD memory card or
SDHC memory card in order to achieve optimum performance and durability.

Note: format the memory card when you use it for the first time.

1. Turn off the terminal.

2. Press down the battery cover safety button to move the lock to the unlock
position at right;

3. Open the battery cover with the battery cover buckle handle;

4. Pull out the battery (First open the battery connector side, then pull out the
battery)

5. Insert the Micro SD card to SD card slot until it taps;

6. Insert the battery (Insert the non-connector side first, then press the battery
down to establish connection between the battery and the phone)

7. Press down the battery cover (Insert the connector side first, then press the
battery cover down);

8. Press down the battery cover safety button to move the battery cover safety
lock to the lock position at left;

9. Press down the battery cover and slide the battery cover buckle handle to
lock it.

SD Card

SD Card Slot

22 ScanPal EDA50 Enterprise Hybr id Device User Guide

1. Features of ScanPal EDA50 Enterprise Hybrid Device

File transfer

Files can be transfered between the terminal and a computer by using a USB
adapter or standard USB cable. By connecting the terminal to a computer with a
USB cable, you can view the files in the terminal, or transfer the files to the
computer, or transfer files from the computer to the terminal. If you transfer files
with a Mac computer, you need to use Android File Transfer app (it can be
download via www.android.com/filetransfer)

The terminal will use MTP (Media Transfer Protocol) connection as default. If
you mainly transfer camera photos, you can use PTP (Picture Transfer Protocol)
connection settings. If the computer with Windows system doesn't support MTP,
you can use PTP transmission.

Note: EDA50 supports high-speed USB communication (USB2.0), with
maximum data transfer rate at 480 Mbps.

1. Connect EDA50 to the computer.

2. Select Media device (MTP) or Camera (PTP) on the EDA50 screen. EDA50
will set your selection as default selection.

3. View the files stored in EDA50. You can copy, delete or transfer the files
between EDA50 and the computer.

How to view files on EDA50

Users can view the files in EDA50 and its memory card through File Explorer.
Note: Due to system permission issues, some files cannot be opened. Based

on your needs, you can select respective apps to open the file.

1. Tab Applications> File Explorer.

2. Tab the folder name or file name to open the file.

ScanPal EDA50 Enterprise Hybrid Device User Guide 23

1. Features of ScanPal EDA50 Enterprise Hybrid Device

A

EDA50's accessories

EDA50 is shipped with original battery. All other accessories require separate
order and shipment. If necessary, please contact your local sales
representatives.

EDA50's accessories and descriptions

ccessories Description

EDA50 battery
(BAT-EDA50)

Wall charger Used for charge EDA50.

Single Cradle
(Single Charging
cradle)

This battery can last several hours to power EDA50.
Spare battery packs can be ordered to extend the
service time.

Single Cradle can be used to place EDA50 with
battery in to charge the main battery pack while
provide power for the terminal.

24 ScanPal EDA50 Enterprise Hybr id Device User Guide

2. User interface and applications

2 User interface and applications

This chapter introduces the Android system user interface, and how to interact
with the screen. Users can also learn about a variety of Honeywell applications
on the terminal through this chapter.

ScanPal EDA50 Enterprise Hybrid Device User Guide 25

2. User interface and applications

User interface

Android 4.4 operating system user interface provides users with a perfect touch
and easy navigation experience.

The main interface

After turning on the terminal and setting up your preferred language, the main
interface will be displayed on the screen first.

Status bar

Search bar

Camera

Common
application bar

The main interface description

Name Description

The left side of the status bar displays system
messages sent by the application, such as information

Status bar

Common
applications

Search bar

26 ScanPal EDA50 Enterprise Hybr id Device User Guide

notifications. The right of the status bar displays the
current wireless and network connection status and
remaining battery power.

The applications on this bar will be displayed on the
main interface. All Applications option is in the
middle of the common application bar.

Use Google Search to search on the web or the
terminal.

Navigation and function keys

There are navigation and function keys below the common applications i n the
main interface of EDA50; other function keys are on the two sides of the
terminal.

Navigation and function keys

Keys Description Functions

Return Return to the previous screen

2. User interface and applications

Function Key

Home Key Return to the main interface

Volume

Scan Button Press and hold to scan graphics

Power key Turn on, turn off, lock the screen

Reset Button Reset the system

Wallpaper; Manage apps; System
settings

Increase or decrease the speaker
volume

Status bar icons

Status and notification icons display the current network connections, power,
notifications and sound settings. Please refer the following table for detailed
status bar icons:

Status and notification icons:

Icons Description Icons Description

Incomplete calendar

ScanPal EDA50 Enterprise Hybrid Device User Guide 27

events

Not ringing alarm clock;
alarm clock set

Sound is disabled

Vibration mode has
been enabled

2. User interface and applications

New text messages or
multimedia information

Text messages or
multimedia information
transmission failed

New mails

The terminal is
connected to the
computer via USB
cable

ABD has been enabled
(USB troubleshooting
has been enabled)

Data Sync

Sync or account logon
failed

Memory card is full Network connected

Battery power is 100%
full

Being in charge with
external power supply

Airplane mode is
enabled

EDA50 is syncing with
a Bluetooth-enabled
device

Bluetooth has been
enabled

Wi-Fi signal is
adequate

Wi-Fi is connected, but
with no signal

Key mapping

Users can change the default functions of the left and right scan keys.

1. Tap All Applications > Settings > Key Remap.

2. Touch the keys you want to redefine.

3. Tap KEYS or APPs to view options.

4. Select the required functions for the key. The new functions selected will be
displayed under the name of the key.

28 ScanPal EDA50 Enterprise Hybr id Device User Guide

Viewing system messages

Users can view EDA50's system messages in the notification page.

2. User interface and applications

• Open the notification p ag e: swipe down from the top of the screen.

• Close the notification page: swipe up from the bottom of the screen or tap

Return key or Home key.

Managing system messages

When the applications send system messages to EDA50, users can manage
them quickly.

1. When the system message icon appears, swipe down the screen.

2. To manage the system message, touch it. The respective application will be
opened for users to manage it.

• Swipe the system message to the side to cl ear it.

• Tap the icon on the top right
messages.

ScanPal EDA50 Enterprise Hybrid Device User Guide 29

of the screen to clear all system

2. User interface and applications

Personalizing the main interface

You can add application icons to either one of the main interface to open these
applications more quickly.

1. Tap

2. To move the application icon to the main interface: long press the icons to
be added to the main interface, then slide your finger to place it on either
one of the the main interface.

To move the widget icon to the main interface: touch the widget on the top

of the screen, long press the widget icon, then slide your finger to place the
control icon on either one of the main interface.

3. To remove the applications or widgets from the main interface: long press
the icons and slide to X Delete on the top of the interface.

. To display all applications.

Customizing common applications

Users can add applications to the common application bar to open these
applications more quickly.

1. Tap

2. Long press the icons in the common application bar and slide it to the X
Delete on the top of the interface.

3. To add application icon to the common application bar: long press the
application to be added, and slide your finger to place the icon on the
common application bar.

To add the widget to the common application bar: touch the widget on the

top of All Application Interface, long press the widget icon to be added, then
slide your finger to place the icon on the common application bar.

. To display all applications.

Searching with Google™

Using Google search engine on the top of the main interface can help users to
search any information on the terminal or the Internet.

1. Tap the Google search field on either one of the main interface and enter
the search term. Search results from the terminal (like applications and
contacts) will also appear below the search results from Internet.

2. Tap a search item to immediately start the search, or touch only its arrow to
enter it in the search box without immediate search.

30 ScanPal EDA50 Enterprise Hybr id Device User Guide

Touch screen gestures

Use your finger can operate applications, menus, on-screen keyboard and other
functions on the interface.

• Tap a function or application to select or start it.

• To enter a name or password, touch the place to enter and on-screen
keyboard will appear for input.

Other touch screen gestures include:

• Long press: press an icon and hold until the system reacts.

• Drag: Press an icon, and then move your finger across the screen to the
destination. For example: With dragging method, you can rearrange some
shortcuts on the main interface.

• Swipe or slide: Quickly move your finger on the screen and keep your finger
touching on the screen. For example, users can swipe the home screen to
the left or right to view other home screens.

• Double-click: tap twice rapidly in a row on the map or other interface to
enlarge it. Double-click again to return to the original size.

• Kneading: In some applications, subjects can be zoomed out by kneading
two fingers on the screen, or zoom in by expanding two fingers.

Setting timezones

2. User interface and applications

EDA50 can automatically sync the time and date according to the network.
Users can also set timezones for their regions manually.

1. Open Settings.

2. Tap Date & Time.

3. Uncheck timezone automation.

4. Tap Selecting Timezones and tap the timezone for your region.

ScanPal EDA50 Enterprise Hybrid Device User Guide 31

2. User interface and applications

A

Honeywell applications

Honeywell helps users troubleshoot and connect the terminals to other devices
and networks. Tap All Applications to show the applications below. For

more details, please visit: www.honeywellaidc.com.

Honeywell software applications available on EDA50

Icons

pplications Descriptions

Scan Demo, NFC

Demo

Auto Install
Settings

Demo and more included, allows testing
and using functions like scanning.

This application can automatically
identify and install installation packages
and APK files.

Unlocking developer options

If you are a developer for EDA50, you can easily unlock developer options.
Developer options can help you test and troubleshoot during the process of
developing EDA50. After Developer options is unlocked, the system menu will
present developer option connections.

1. Tap Settings.

2. Tap About the phone.

3. Click the Build number 7 times and notification as "You are now in
developer mode" will appear.

32 ScanPal EDA50 Enterprise Hybr id Device User Guide

3 Scan Function

This chapter describes how to scan barcodes and set scan functions.

3. Scan Function

ScanPal EDA50 Enterprise Hybrid Device User Guide 33

3. Scan Function

Scan Function

Integrated scanner enables reading for 1D and 2D barcode, composite code
and postcode. It supports comprehensive, highly flexible scanning in real
applications. Imaging Engine can capture black and white images, such as
signatures and damaged inventory lists.

How to transfer data via Android keyboard input

Scan wedge feature enables transferring scanned barcode data to active
applications via Android keyboard input. Scan wedge function is enabled by
default on EDA50. Users can use applications that can accept scan wedge
function through scanners or applications. If an application obtains scan function
through Barcode Reader API, the scan wedge function will be temporarily
disabled.

Users can build customized applications in Software Development Kit (SDK) for
ScanPal EDA50. Please download SDK at: www.honeywellaidc.com.

Processing and settings for scanned data

Processing steps Respective scan settings

Decode barcodes Symbology settings
Parsing the barcodes as

ISO8859-1

Special barcodes detected
activate special actions,
rather than performing the
normal operations.

Converted to the selected
character set

34 ScanPal EDA50 Enterprise Hybr id Device User Guide

Symbology settings

Data processing
settings

Data processing
settings

Start your browser
Scan to Intent
EZConfig enabled

Character set

Add a prefix and suffix to
make the data string in the
following order:

3. Scan Function

• Prefix

• Sign prefix

• Barcode data

• Suffix
Parsing the replacement

for prefix and suffix string
Activate Total Freedom

plug-in
Input the final data as

Android Key Events

Prefix and suffix will be replaced within the string value.

Prefix and suffix parsing

Substring

\r 13 No

\n 10 Yes

Replacement
character code

Data processing
settings

Data processing
settings

Data processing
settings

Wedge in form of KeyEvent

Prefix
Sign prefix
Suffix

Data editing plugin

wedge

\t 9 Yes
\\ ‘\’ No

Changing scan settings

Changes made to the default file apply for all non-document applications.

1. Tap Settings.

2. Tap Scanning.

3. Tap Default.

4. Select Data Processing Settings, Symbology Settings, Decode Settings,
Imager Settings, Trigger Settings or Notification Settings.

5. Modify the setting to meet application needs.

ScanPal EDA50 Enterprise Hybrid Device User Guide 35

3. Scan Function

Restoring default scan settings

Users can easily cancel all the changes made to default folder and restore the
factory defaults.

Note: Restore factory defaults for a certain setting, all the settings under this
folder will be restored to factory defaults.

1. Tap the icon on the upright of any Scan Settings interface.

2. Tap Restore all defaults.

Scanner default settings

Study the following table to learn about Data Processing Settings, Symbology
Settings, Decode Settings, Imager Settings, and Trigger Settingsand Notification
Settings.

Data processing settings

Use data processing settings to set the barcode data processing patterns for
EDA50.

Data processing settings

Settings Description Default

Wedge

Character
set

36 ScanPal EDA50 Enterprise Hybr id Device User Guide

Enable or disable the transferring of barcode data as Android Events when
sending data to the application.

Explain the selected character set when the barcode is a character,
options including:

• ISO-8859-1

• US-ASCII

• UTF-16

• UTF-16BE

• UTF-16LE

• UTF-8
The related BarCodeReader attributes:

PROPERTY_DATA_PROCESSOR_CHARSET

Enabled

ISO-8859-1

3. Scan Function

Prefix Define the character to be added in front of the decoding barcodes No
Suffix Define the character to be added at the end of the decoding barcodes No
Data

editing
plugin

Character
prefix

Start your
browser

Scan
Intent

Specify a free plug-in for data editing No

Specify a character prefix to decode the barcode data

• None

• Honeywell

• AIM
To open or close URL barcode, if the barcode start with http:// or https://,

the browser will open the respective URL
The related BarCodeReader attributes:
PROPERTY_DATA_PROCESSOR_LAUNCH- BROWSER

Enable or disable scan processing for specified targets. Apply the barcode
as the follwing format

‘//’ ACTION
‘//’ intent-suffix ‘$’ extra-data
Where:

Additional operations and data include the following characters, to enable
Intent or respective applications

Intent action:
“com.honeywell.scantointent.intent.action.”+ ACTION

Intent extra
“com.honeywell.scantointent.intent.extra.DATA” contains the remainder of
the bar code data after the first ‘$’ character.

The related BarCodeReader attributes:
PROPERTY_DATA_PROCESSOR_SCAN_TO_INTE N T

No

Enabled

Enabled

ScanPal EDA50 Enterprise Hybrid Device User Guide 37

3. Scan Function

Enable or disable specifying EZ Config operations to barcode. Adopt

Aztec code and include specified header data.
Start EZ
Config

The related BarCodeReader attributes:

PROPERTY_DATA_PROCESSOR_LAUNCH_EZ_ CONFIG

Enabled

38 ScanPal EDA50 Enterprise Hybr id Device User Guide

3. Scan Function

Symbology settings

Enable or disable a barcode symbology with Symbolog y Settings. Tap on a
symbol to view and modify the configuration parameters of the symbol.

Symbology settings

Settings Default

Code 128 Enabled
GS1-128 Enabled

Code 39 Enabled
Datamatrix Enabled
UPC-A Enabled
UPC-E Disabled
EAN-8 Disabled
EAN-13 Enabled

Aztec Enabled
China Post Disabled
Codabar Enabled
Codablock A Disabled
Codablock F Disabled
Code 11 Disabled
Code 93 Disabled

ScanPal EDA50 Enterprise Hybrid Device User Guide 39

3. Scan Function

Composite Disabled
Han Xin Disabled
IATA 2 of 5 Disabled
Interleaved 2 of 5 Enabled

Korean Post Disabled
Matrix 2 of 5 Disabled
Maxicode Disabled
Micro PDF 417 Disabled
MSI Disabled
PDF 417 Disabled
QR Code Disabled

RSS (GS1) Disabled
Standard 2 of 5 Disabled
Telepen Disabled
TLC 39 Disabled
Trioptic Disabled
2D Postal Settings Disabled
OCR Disabled

40 ScanPal EDA50 Enterprise Hybr id Device User Guide

3. Scan Function

Image settings

There should be no need for users to change image color rendering. Coveri ng
the recommended value is disabled by default. Recommended image settings
can be applied in many environments; only the users who have more in-depth
understanding on the image can change the settings.

Trigger settings

Trigger settings can set up the using patterns for scan key.

Trigger settings

Settings Description Default

If the scan trigger is held down but

Decoding timeout

decoding is not successfully performed,
Scanning will automatically shut down
after 20 seconds

20

ScanPal EDA50 Enterprise Hybrid Device User Guide 41

3. Scan Function

Notification settings

You can set up the responses during scanning process for EDA50 in the
notification settings.

Notification settings

Settings Description Default

Enable or disable Good Read

Good Read Notification

Bad Read Notification

Vibrate Enabled

Notification. Notification includes
green indicator, short beep and
optional short vibration

Enable or disable Fail to Read
notification. Notification includes red
indicator, failure beep and optional
short vibration

Regardless of succeeding or failing to
read, turn on or off the phone
vibrations

Enabled

Disabled

Disabled

42 ScanPal EDA50 Enterprise Hybr id Device User Guide

Scanning barcodes

Scan engine will emit scanning beams for accurate barcode aiming. It will also
support a full range of 360° scanning, which will make barcode scanning more
convenient.

Note: Before scanning a barcode, you only need to enable the desired barcode
symbology in the settings.

1. Tap Applications >Demos>ScanDemo.

2. Align the scanning window with the barcode and stably place the terminal a
few inches away from the barcode.

3. Press one of the scan keys or tap Scan on the interface. Make sure the
entire barcode is within the scanning beam range.

3. Scan Function

Scan Engine

When the scanning is successfully completed, you will hear a "beep" sound, and
the Good Read LED will open immediately.

ScanPal EDA50 Enterprise Hybrid Device User Guide 43

4. Using Telecommunication Function

4 Using Telecommunication

Function

You can use the phone function of the terminal (Only for EDA50-111) to make
and receive calls, and to transmit data via wireless network as well.

44 ScanPal EDA50 Enterprise Hybr id Device User Guide

4. Using Telecommunication Function

Telecommunication Function

The phone function of the terminal is realized with a speaker and a microphone.
The phone function also supports a Bluetooth headset or hands-free device.
The phone function is enabled by default.

This terminal supports the following network types:

• GSM&EDGE: Band3/Band8/

• WCDMA: Band1/Band8

For local network carriers, please contact Honeywell technical support.
When users enable the phone function and activate the service through wireless

carriers, they can customize the phone features and network settings in the
Mobile Network interface in Settings.

Note: WWAN version supports automatic system time setting with
network messages and timezone messages (NITZ).

Activating UMTS calls

UMTS calls can be activated by inserting Micro SIM card in the terminal. Micro
SIM card can be purchased from the network service provider.

1. Turn off the terminal.

2. Press down the battery cover safety button to move the lock to the unlock
position at right;

3. Open the battery cover with the battery cover buckle handle;

4. Pull out the battery (First open the battery connector side, then pull out the
battery)

ScanPal EDA50 Enterprise Hybrid Device User Guide 45

4. Using Telecommunication Function

5. Insert SIM card to SIM card slot until it clicks;

6. Insert the battery (Insert the non-connector side first, then press the battery
down to establish connection between the battery and the phone)

7. Press down the battery cover (Insert the connector side first, then press the
battery cover down);

8. Press down the battery cover safety button to move the battery cover safety
lock to the lock position at left;

9. Turn on the terminal.

SIM Card

Making a call

After the phone is successfully activated, you can make calls.

1. Tap in the main interface or application interface.

If the screen shows the list of numbers instead of a dial keypad, tap

get back to the dial keypad.

2. Tap the keys to enter the numbers, and then tap the below the keys to
make the call after all numbers have been entered.

3. To end the call, tap .

46 ScanPal EDA50 Enterprise Hybr id Device User Guide

to

Answering a call

r

When a user receives an incoming call, the screen will be illuminated with the
caller's number displayed. All calls are recorded in the call log. If you have
missed calls, you will receive reminding notifications.

When there is an incoming call, tap the white phone icon and slide to any one of
the following icons:

4. Using Telecommunication Function

• Ans wer the call:

• Hang up:

• Send a messa ge from the default list:

Switching applications during a call

Users can switch applications during a call. For example, users can use the
Contacts application to find contact information during a call.

Note: If the use
data connection may not be able to obtain network data during the call.
Due to restrictions from network carriers, you can not receive multiple
simultaneous calls and connections and voice calls will get priority. For
more information, please contact your network carrier.

During the call, tap the icon of other applications on the main interface or
application interface to run the application, while the green call icon shows in the
status bar.

only has WWAN connection, the applications requiring

Making an emergency call

Users can still make emergency calls even if the user's SIM card for his UMTS
phone is lost or he has no effective CDMA accounts. In both cases, the phone
will show that you are out of service, however, if you dial an emergency phone
number (such as: 112,911,000,08,118,119 or 999), you will get connected.

Configuring call settings

Users can customize phone settings, including ringtones, voice mailing options,
key tone, intercom settings and other options.

1. Tap

2. Tap

3. Change the settings based on your needs.

ScanPal EDA50 Enterprise Hybrid Device User Guide 47

.

Settings to show Call Settings menu.

5. Using Camera

5 Using Camera

This chapter describes how to use a color camera to take photos and videos.

48 ScanPal EDA50 Enterprise Hybr id Device User Guide

5. Using Camera

Color camera

EDA50 is equipped with 5 megapixels color camera which can be used to take
photos and videos. The camera and flash light are located on the back of the

terminal. Tap Photo
the terminal.

Gallery app to view all the photos and videos stored on

Adjusting camera and video settings

Adjust the camera and video settings in the Camera apps.

Zooming

Focus adjustment is realized by zooming actions of the fingers on the screen.
Place two fingers on the screen at the same time, then:

• Separate the two fingers in opposite directions to zoom in the images
(enlarge objects).

• Fold the two fingers in opposite directions to zoom out the images

Changing camera settings

In order to obtain the best results when taking photos, users can change the
camera settings beforehand.

1. Tap All Applications and then tap Camera

2. Tap the Flash Light icon on the bottom right to view Camera Options.

3. Tap HDR or any icons to change the basic settings of the camera.

• When HDR is enabled, the terminal will automatically capture multiple
photos and composite them into one to achieve the best possible
image quality.

• Enable or disable various options, like viewfinder mode, storage
location and image size.

.

Taking photos

1. Tap All Applications and then tap Camera .

2. Take the screen as a viewfinder and move the terminal until you get the
images you want to capture.

3. Tap the screen to focus. By default, the camera automatically senses the
ambient light, and the flashlight will be opened if necessary.

ScanPal EDA50 Enterprise Hybrid Device User Guide 49

5. Using Camera

4. Press the camera key

• To vie w photographs, slide the screen to the left.

• To return to the camera application, slide the screen to the right.

to take photos

Shooting videos

This section describes how to use the camera function to shoot videos.

1. Tap All Applications and then tap Camera

2. Tap Camera Shooting Options on the bottom left .

3. Tap

4. Tap
fingers on the screen; to capture images, you can tap on the screen for
instant capturing during video shooting process.

5. To stop video shooting, tap

to choose videos

to start video shooting. To adjust the focus, you can knead two

Changing video settings

In order to obtain the best results when shooting videos, users can change the
camera settings beforehand.

.

.

1. Tap All Applications and then tap Camera .

2. Tap .

3. Tap

4. Tap any other positions of the screen to enable or disable Camera Options.

50 ScanPal EDA50 Enterprise Hybr id Device User Guide

to view Video Options.

6. Terminal configurations

6 Terminal configurations

This chapter describes how to configure EDA50. Users can also learn about
how to configure network communications and wireless security.

ScanPal EDA50 Enterprise Hybrid Device User Guide 51

6. Terminal configurations

Terminal configurations

Users can configure many parameters for the terminal, such as barcode
symbologies to be decoded or network settings. These parameters set by the
user decide how the terminal works.

Users can configure the terminal in Application Settings.

Start Application Settings

Application Settings is in Applications Menu.
Tap Applications > Settings.

Structure of the Application Settings

The section describes the structure of Application Settings to make it easier for
users to quickly locate respective specifications.

52 ScanPal EDA50 Enterprise Hybr id Device User Guide

Wireless & networks

Settings Introductions

To enable or disable Wi-Fi radios. When Wi-Fi is

WLAN

Mobile Data

Bluetooth

enabled, available Wi-Fi networks can be viewed by
taping this bar.

To enable or disable Mobile Data. When Mobile Data
is enabled, available Mobile Data networks can be
viewed by tapping this bar.

To enable or disable Bluetooth radios. When Bluetooth
connection is enabled, Bluetooth-enabled devices
within the range can be viewed by tapping this bar.

6. Terminal configurations

Data traffic usage

More...

Displays the current call data usage during the cycle.
Tap Data usage cycle to select another date range.

Airplane mode: to enable or disable Airplane mode.
Mobile network: including mobile network settings,

such as to enable data transceiver and roaming, select
the transceiver point and carriers, or choose only to
enable 2G mode (to extend battery life).

Default SMS application: SMS application is enabled
by default

NFC: enabling NFC allows NFC tag information to be
read when the terminal touches NFC tag.

Android Beam: when NFC is enabled, this function
allows users to send the application contents from the
terminal directly to another NFC-supported device
when the two get closer.

Network sharing and hot spots: a handheld device can
be used as a wireless router to radiate the wireless
network, and then other WLAN-enabled device can
receive it.

VPN: Set a password for accessing the virtual private
network.

Mobile phone usage plan: plans provided by network
carriers.

Cell Broadcast: Set desired emergency information
and ways to receive it.

ScanPal EDA50 Enterprise Hybrid Device User Guide 53

6. Terminal configurations

Device

Settings Introductions

Sound

Display

Memory Shows the remaining memory space.

Battery

Applications Shows applications downloaded and on the run.

Personalization

Settings Introductions

Location
information

Security

Language & input

Set sound for calls and notifications, including the tone
and volume.

Set screen brightness, wallpaper, screen timeout, font
size and screen rotation.

Shows battery usage data and the current battery
status.

To enable or disable location information (Google and
GPS satellite data).

Set screen lock and administrator privileges, including
application installation and data storage security.

Select the current language and the default keyboard.
Set automatic input function, such as: capitalization
and punctuation. Set the cursor speed for external
mouse or touch screen.

Backup & reset Factory Data Reset.

54 ScanPal EDA50 Enterprise Hybr id Device User Guide

Honeywell Settings

Settings Introductions

6. Terminal configurations

Key Remap

Battery LED Configuring b attery LED lighting modes.

Scanning

Adding accounts

Settings Introductions

Adding account Set up an e-mail account.

System

Settings Introductions

Data & Time Configure all time and date settings.

Auxiliary functions

Printing Configure printing options.

Redefine the left scan key and the right scan key. For
more help, please refer to Key Mapping.

Configure ScanPal EDA50 imager. For more help,
please refer to changing scan settings.

Set auxiliary function level, for example: large font and
text-to-speech output.

About the phone Shows information about the terminal system.

ScanPal EDA50 Enterprise Hybrid Device User Guide 55

6. Terminal configurations

Network communication

Users can connect the terminal to wireless and wired networks. Users can get
the terminal connected via the following ways:

• 802.11 radios

• Bluetooth

• USB

Connecting to Wi-Fi networks

When communicating through wireless networks, ScanPal EDA50 transfer data
through 802.11 radios. Before connecting to a Wi-Fi network, users need to
know the Security Protocol of the network and the certificates it required.
Usually, 802.11 radio is diabled by default.

1. Enter Settings, slide the WLAN switch to enable it.

2. When the WLAN switch turns blue, tapping the WLAN bar will display the
detected network list.

56 ScanPal EDA50 Enterprise Hybr id Device User Guide

6. Terminal configurations

3. To quickly connect to a network via WLAN Protected Access (WPS), tap

. To search the network outside of the list, tap and enter the network

name.

4. Tap on a network name to view its details.

If the network is secure, a form will pop up asking you to fill in the necessary
information (for example: certificate name, password or other credentials).
To connect to a secure network, enter the required information, and then
tap Connect.

• To leave the network that has been connected, tap Forget. For
example, users can choose to forget a network that they won't use
again.

• To close the network information screen, tap Cancel.

Configuring Wi-Fi network proxy servers

If users need to connect to network resources through a proxy server, they need
to configure a proxy server for each Wi-Fi network added. By default, none of
the Wi-Fi networks added by users has done proxy server settings.

ScanPal EDA50 Enterprise Hybrid Device User Guide 57

6. Terminal configurations

Note: Proxy server settings only apply to the Wi-Fi networks that users
modified. Users have to set proxy servers for each netwrok that req uires
the using of proxy server.

1. Enter Application Settings screen, tap Wi-Fi to show avaiable Wi-Fi
networks.

2. Long press the network name, then tap Modify the Network, then a
network setting list will pop up.

3. Choose Show Advanced Options at the bottom of the network setting list.

4. If the network does not have proxy server settings, tap None on the proxy
server setting list, and then tap Manual Settings.

5. Enter the network proxy server settings.

6. Tap Save.

Disable Wi-Fi notifications

Wi-Fi is enabled by default. Users will receive notifications in the Status Bar
when the terminal finds wireless networks. Users can disable these notifications.

1. Enter Application Settings screen.

2. Tap WLAN bar.

3. Tap the Settings icon on the bottom right.

4. Tap Advanced to display Wi-Fi Advanced Menu.

5. Uncheck the network notification to disable Wi-Fi Notifications.

58 ScanPal EDA50 Enterprise Hybr id Device User Guide

Connecting to a virtual private network

The terminal supports connection to virtual private networks (VPNs). This
section describes how to add and connect to VPNs. To configure a VPN, users
must consult your network administrator. Users can view and change VPN
settings in the Application Settings.

Note: Before accessing VPNs, users need to set a lock screen p assword.

Add VPNs

Before connecting to a VPN, users must first add the relevant information of the
VPN.

1. Enter Application Settings screen.

2. Tap More under Wireless and Networks.

3. Tap VPN.

4. Tap Adding +.

5. Input the VPN information.

6. Tap Save, and VPN name will be displayed in the list.

Connect to VPN

1. Enter Application Settings screen.

2. Tap More under Wireless and Network.

3. Tap VPN.

4. Tap the VPN name in the list, and enter the certificate information based on
the tips.

5. Tap Connect. The terminal gets connected to the VPN, and the status
icons and notification will be displayed. To disconnect from the VPN, tap
the notification.

6. Terminal configurations

Edit VPN information

1. Enter Application Settings screen.

2. Tap More under Wireless and Network.

3. Tap VPN.

4. Long press the name of the VPN to be edited and select Editing Networks
from the list.

5. Edit VPN information based on your needs.

ScanPal EDA50 Enterprise Hybrid Device User Guide 59

6. Terminal configurations

6. Tap Save after editing.

Wireless Security

The terminal provides the following security solutions for users' wireless
network.

• WPA2™

• WPA

• 802.1x

• LEAP

• WEP

Before setting up security program, you must first enable the radio and set the
date and SSID on the terminal. To use 802.1x program, users must download a
root certificate to the terminal. To use Transport Layer Security protocol (TLS)
together with 802.1x , users also need to download a user certificate first.

View and configure all of the wireless security settings in the Application
Settings screen.

Certificates

Users can use digital certificates to identify the terminal's network access or
server validation. To identify the device with certificates, users must first install
the device to the trusted certification store on the terminal.

Android supports DER encoded X.509 certificate stored in the documents with
.crt or .cer extension. Install a valid DER-format certificate. Android also
supports X.509 certificate stored in PKCS # 12 key store file with p12 or .pfx
extension. To install a valid key storage file with other extensions at the end,
users must change the extension to .p12 or .pfx first. If users installed a
certificate from the PKCS # 12 key store file, Android will also install the private
key certificate or a certificate authority that came with it.

Download certificates

To use the certificate, users must first install the certificate to the trusted
certification store on the terminal.

Note: Some applications that support certificates, such as email and browsers,
allow users to install the certificate directly from the application. For more
information, please refer to the Help Documentation in the application.

1. Copy the certificate or key storage from computer to the SD card.

2. Install the SD card in the terminal and turn on the terminal.

3. Enter Application Settings, tap Safety > Install From SD Card.

60 ScanPal EDA50 Enterprise Hybr id Device User Guide

6. Terminal configurations

4. Tap the name of the certificate or key storage to intall. Following the tips to
enter the password of the key storage, then tap OK.

5. Enter the certificate name and tap OK.

Disable or delete certificates

If the certificate is a stolen one or the organization selected by the user does not
trust the certificate, the user can disable or delete the certificate.

1. Enter Application Settings, tap Safety > Trusted Credentials. There are
two tabs in the Trusted Certificate screen:

• System tab displays CA certificates installed in ROM.

• User tab displays CA certificates installed by users.

2. Tap the certificate name to disable or delete it, and the certificate details
screen will pop up.

3. Slide the screen down to the bottom, tap Disable (system certificates) or
delete (user certificates).

If necessary, users can enable the disabled system certificate here. For

deleted user certificates, users must reinstall it to enable it again.

4. Tap OK.

ScanPal EDA50 Enterprise Hybrid Device User Guide 61

6. Terminal configurations

Bluetooth communication

EDA50 supports Bluetooth communication, allowing users to get connectted
with other Bluetooth-enabled devices.

Before searching for and connectting to other Bluetooth-enabled devices, users
must enable the Bluetooth radio. By default, Bluetooth radio is disabled.

Bluetooth radio can be restored to its current state by system resetting. If users
have reset the system data, they must re-establish the paired devices. Bluetooth
status is displayed on the System Icon bar.

Pairing with a Bluetooth-enabled device

To connect to a Bluetooth-enabled device, users should enable Bluetooth radio
first and then choose the device from the detected device list.

1. Enter Application Settings screen.

2. If Bluetooth switch is off, slide it on.

3. Tap Bluetooth to display avaiable Bluetooth-enabled device list.

62 ScanPal EDA50 Enterprise Hybr id Device User Guide

6. Terminal configurations

4. (Optional) If the desired device is not listed, please check if the Bluetooth of
that device has been enabled and is detectable, and then tap Scan Device.

5. Select the device to pair with. After Pairing Dialog Box is displayed, enter
the device PIN code, and tap OK. When the device and the terminals have
been successfully paired, the device name will appear in the list of paired
devices at the top.

6. To disconnect with the paired device, tap the Quick Setting icon beside the
device name

ScanPal EDA50 Enterprise Hybrid Device User Guide 63

, and then tap Cancel Pairing.

6. Terminal configurations

Configuring Bluetooth settings

Searching for EDA50

Users can configure for Bluetooth in Application Settings.

1. Enter Application Settings screen, and tap Bluetooth.

2. Tap Menu icon to select one for setting:

• Tap Rename phone to change the name of the terminal. Enter a new name
and then tap Rename.

• Tap Visibility timeout to set the timeout duration for the terminal to be
detectable, which is 2mins by default. Users can set it up as 5mins, 1hour
or Never timeout. The shorter of the duration, the more power it could save.

• Tap Show received files to view data in the received files.

By default, EDA50 is not detectable by other devices, which means it's not
visible for other Bluetooth-enabled devices.

1. Tap All Applications > Settings.

2. Make sure Bluetooth radio has already been enabled.

3. Tap Bluetooth.

4. Tap ScanPal EDA50 (the default terminal name) at the top of the screen to
change it to be detectable. Then the terminal begins 2mins countdown,
during which period other devices can detect EDA50 through Bluetooth
techonology.

Renaming or disconnecting a paired device

Users can rename or disconnect a paired Bluetooth-enabled device in the
Application Settings.

1. Enter Application Settings screen, and tap Bluetooth.

2. Tap Settings icon in the Paired List

3. To rename the device, tap Rename, enter a new name and click OK.

To disconnect with this device, tap Cancel Pairing.

64 ScanPal EDA50 Enterprise Hybr id Device User Guide

.

6. Terminal configurations

Communication via serial port and USB

By communication via serial port and USB, users can transfer data to other
devices or receive data from other devices with the following accessories.

• USB cable

• RS-232 cable

For more information about accessories, please contact local resellers.

Near Field Communication

NFC technology provides short-range wireless data transmission between
ScanPal EDA50 with NFC tags or other NFC-enabled devices near its back.

NFC-enabled ScanPal EDA50 models support the following operations:
NFC tag read / write mode: The terminal reads digital information from the NFC

tag or writes information into NFC tag.

Note: When in sleep mode (suspend mode) and lock-screen state, NFC
radio will be temporarily disabled.

ScanPal EDA50 Enterprise Hybrid Device User Guide 65

7. Management and maintenance

7 Management and maintenance

This chapter will describes how to upgrade softwares, reset terminals and
maintain EDA50.

66 ScanPal EDA50 Enterprise Hybr id Device User Guide

Upgrading system software

The other system softwares of EDA50 can be upgraded by downloading ".zip"
files from the Technical Support Website. Website:

www.hsmcontactsupport.com or www.honeywellaidc.com.

Upgrading AutoInstall application

1. Copy the upgrade file "eda50-ota-xxx.zip" to the following EDA50's system
folder:

File Explorer\External Memory Card\Honeywell\Autoinstall

2. Tap All Applications > AutoInstall Settings.

3. Choose Packages update, and ScanPal EDA50 will restart and install the
upgrade file.

Upgrading composite key

1. Copy the file "eda50-ota-xxx.zip" to the root directory of the T card.

2. Restart the terminal, when the green light of the device turns on, press and
hold the "(left) Scan key" + "Volume-" key at the same time.when the green
light turns off, the terminal will automatically select the zip package and
install it.

3. After the installation is complete, the terminal will restart automatically.

7. Management and maintenance

Manually upgrading Recovery Menu

1. Copy the file "eda50-ota-xxx.zip" to the root directory of the T card.

2. Turn off the terminal, press and hold the "Power Key" + "Volume+" key for
about 15s, then the phone will enter Recovery Menu.

3. Press "Volume-", and select "Apply update from SD card". Press "Power
Key", select the zip file just copied, then press and hold the "Power Key".

4. After the upgrading is completed, it will automatically move to Reboot
System Now Menu. Please press the "Power Key" to restart the terminal.

ScanPal EDA50 Enterprise Hybrid Device User Guide 67

7. Management and maintenance

Restarting the terminal

If the terminal or an application is locked or doesn't respond when pressing the
power key, you need to restart the terminal.

When restarting, the terminal will use the current configuration saved in the flash
memory. Try the following ways to restart the terminal:

• Reset: Restart the terminal a nd initialize it

• Restore to factory settings: Clear all data in the terminal, including all
applications and data files, but excluding built-in files or data stored in a
removable storage device.

Terminal resetting

When an application is not responding, you may need to restart the terminal to
resolve the issue.

1. Save the file and close open applications.

2. Press and hold "Power Key" until the following interface displayed:

3. Tap Power off.

4. Tap OK when message as "Your phone will shut down" pops up.

5. Press down "Power Key" to restart EDA50.

68 ScanPal EDA50 Enterprise Hybr id Device User Guide

Restore factory settings

r

If the terminal appears to be locked, try a cold boot. If resetting is invalid, try to
restore factory settings, restart the terminal to make it work again and do
troubleshooting later.

Warning: This action will clear all data in the terminal, including all
applications and data, but excluding data stored in flash memory or
external storage device.

1. Tap All Applications > Settings.

2. Tap Backup & Reset.

3. Tap Restore Factory Settings.

4. Tap Reset the Phone.

5. EDA50 will restart and automatically clear user data.

Cleaning the terminal

In order to ensure the terminal in good working condition, you need to clean the
scan window, camera and touch screen. Based on the environmental conditions
where the terminal is being used, clean these parts at regular intervals. Use a
clean, soft cloth dampened with the following solvents for the cleaning, and
quickly wipe it with another piece of clean, soft cloth.

• Acetic acid (10% soluble in water)

• Ethanol (10% soluble in water)

• Neutral soap s olution

Warnings: this product includes non use
Disassembling the product may prevent warranty and cause internal
damages to the product.

Note: We advise you not to open the battery cover or remove the battery,
so as to avoid the liquid flowing into the internal part of the terminal from
the SIM card and SD card interface.

1. Press the power key to enter standby mode.

2. Dip a clean cloth in detergent, then wrung out excessive water.

3. Wipe the scanning window, camera and flash area, avoiding touching these
areas with hard objects or abrasive materials.

4. Dry the cleaned area.

5. Make sure the terminal is fully dry before using it again.

7. Management and maintenance

-serviceable parts inside.

ScanPal EDA50 Enterprise Hybrid Device User Guide 69

7. Management and maintenance

Terminal disinfection

The medical version of the terminal supports wiping with chemical disinfectants.
Chemical disinfectants supported including:

• Medical alcohol (75% concentration)

• Hydrogen peroxide (3% concentration)

• Isopropyl alcohol (70% concentration)

• Sodium hypochlorite solution (500PPM concentration)

• Peracetic acid (0.02% concentration)

Warnings: this product includes non user-serviceable parts inside.
Disassembling the product may prevent warranty and cause internal
damages to the product.

Note: We advise you not to open the battery cover or remove the battery,
so as to avoid the liquid flowing into the internal part of the terminal from
the SIM card and SD card interface.

1. Press the power key to enter standby mode.

2. Dip a clean cloth in disinfectants.

3. Wipe the scanning window, camera and flash area, avoiding touching these
areas with hard objects or abrasive materials.

4. Make sure the terminal is fully dry before using it again.

70 ScanPal EDA50 Enterprise Hybr id Device User Guide

8 Specifications

Mechanical and environmental
specifications

This section describes the mechanical and enviromental specifications of EDA50.

Product dimensions

Length 153.5 mm

Width 78.9 mm

Thickness 18 mm

Weight (with battery) 270 g (with battery)

8. Specifications

Tumble and drop standards

Tumble 200 tumbles within 0.5m

Drop Multiple 1.2m drops to concrete at room temperature

Power and electrical specifications

Battery Rechargeable Li-ion battery, 3.8v, 4000mAh

Charging power 5 V, 2 A

Temperature and humidity specifications

Operating
temperature

Storage temperature -20 °C to 60 °C (-4 °F to 140 °F)

ScanPal EDA50 Enterprise Hybrid Device User Guide 71

-10 °C to 50 °C (14 °F to 122 °F)

8. Specifications

Relative humidity
(during operation)

Enviromental sealing IP54

10% to 90%, non condensing

Display specifications

5.0" backlit color LCD display / 720 pixel HD / wide viewing angle / touch

screen.

Language Support

Language Support and not limited to WW English, French, German, Italian,
Spanish, Simplified Chinese, Traditional Chinese.

Symbolgies support

The following symbologies are supported:

1D codes:

• Codabar

• Code 3 of 9

• Code 11

• Code 32

• Code 93

• Code 128

• EAN-8

• EAN-13

• GS1-128

• Korea Post

• IATA 2 of 5

• Industrial 2 of 5

• Interleaved 2 o f 5

• ISBN

• ISBT 128

• Matrix 2 of 5

• MSI Plessey

• EAN.RCC (RSS-14)

• RSS Limited

72 ScanPal EDA50 Enterprise Hybr id Device User Guide

• RSS Expanded

• Telepen

• Trioptic Code

• UPC-A

• UPC-E

2D codes:

• Aztec Code

• Codablock A

• Codablock F

• DataMatrix

• HanXin

• Maxicode

• Micro PDF 417

• MicroQr

• PDF 417

• QR Code

• TLC39

• OCR-A

• OCR-B

Postal codes:

• Australian Postcode

• Canadian Postcode

• KIX (Dutch) Postcode

• Japanese Postcode

• UK Postcode

• Planet Code

• Postnet

• UsIntelligent

• Info mail

• UPU(ID-tag)

8. Specifications

ScanPal EDA50 Enterprise Hybrid Device User Guide 73

8. Specifications

Scan Depth of Field (DOF)

DOF performance of the product was measured under the following conditions:

• DOF is the distance from the top of scan engine to the barcode

• 23 °C (73 °F), 0 ~ 10K lux

• Clear, high quality barcodes

Note: If the barcode is not aligned well with the scan engine, reading time
and depth of field (DOF) will b e affected and the device performance will
be decreased.

5mil code39/128 2.5 (6.3) 4.3 (10.9) 1.8 (4.6)

13mil UPC-A 2.2 (5.5) 10.5 (27.8) 8.3 (22.3)

6.7mil PDF417 2.2 (5.5) 4.6 (11.7) 2.4 (6.2)

20mil QR 1.5 (4.0) 8.7 (22.0) 7.2 (18.0)

Short range
(in/cm)

Long range
(in/cm)

Increments
(in / cm)

74 ScanPal EDA50 Enterprise Hybr id Device User Guide

Honeywell Sensing and Productivity Solutions

9680 Old Bailes Road
Fort Mill, SC 29707

www.honeywellaidc.com

ScanPal EDA50 for Android User Guide
P/N: EDA50-ENG-UG Rev. A

http://www.cn.security.honeywell.com

©2015 Honeywell International Inc. All rights reserved.
