Honda VT700c '84, VT750c '84 shop manual
Specifications and Main Features
- Overall Length: 2,190 mm
- Overall Width: 860 mm
- Overall Height: 1200 mm
- Wheelbase: 1,525 mm
- Height of seat: 760 mm
- Height of foot peg: 330 mm
- Height of ground clearance: 150 mm
- Weight dry: 211 kg
- Weight curb: 225 kg
- Weight frame double: cradle type
- Travel front suspension: telescopic fork: 145 mm telescopic: 145 mm
- Travel rear suspension: swinger-arm/shock absorber 103mm Swing Aarm/SHOCK: 103mm
- Gross vehicle weight rating: 395 kg rating
- Vehicle capacity load limit of: 168 kg
- Size of front tire: 110/90 - 19 62H
- Size of rear tire: 140/90 -15 70H
- Capacity of fuel tank: 12.5 liters
- Ratio compression: ’83: 9.8:1; After ‘83: 9.6:1
- Engine type: Water cooled twin 4 stroke Engine SOHC
- Displacement: ‘83: 749.5 cm³ After ‘83: 694.5 cm³
- Maximum horse power : ‘83: 66 BHP/7500rpm : 62 BHP/7500rpm
- Maximum Miscellaneous expenses: ‘83: 6.8 kg-m(49.4 ft-lb)/6000rpm: ‘After 83-‘6 3 kg-m(45 8 ft-lb)/6000 rpm
Frequently Asked Questions
- What type of fuel does the VT750C use?
VT750C utilizes regular gas.
- How often should I change the engine oil?
Once every year, or after a minimum mileage as mentioned in the manual, is generally the rule for the maintenance schedule for changing the engine oil.
- What is the recommended tire pressure for the front and rear tires?
Maximum load capacity recommended tire pressure for front and rear tires is: Front: 32 psi (225 kPa, 2.25 kg/cm²), Rear: 40 psi (280 kPa, 2.80 kg/cm²).
- What kind of oil filter does the VT750C require?
This motorcycle, based on the owner's Manual, uses a special Honda 4-Stroke Oil filter and its equivalents.
- What is valve clearance adjustment?
Procedures for valve adjustment are accompanied by appropriate measuring procedures, as well as being provided in the manual.
- Where is the VIN on a VT750C?
A vehicle identification number (VIN) is fitted on the right side of the steering head.
- What is the load capacity of the VT750C?
There is a load capacity limit of 168Kg (370 lbs).
