Honda Civic Si 2007, Civic 2007 User Manual
2007 Civic Coupe Online Reference Owner's Manual
Use these links (and links throughout this manual) to navigate through this reference.
For a printed owner's manual, click on authorized manuals or go to www.helminc.com.
Contents
Owner's Identification Form
Introduction .........................................................................................................................................i
A Few Words About Safe
Your Vehicle at a Glance.....................................................................................................................3
Driver and Passenger Safety ..............................................................................................................5
Proper use and care of your vehicle's seat belts, and Supplemental Restraint System.
Instruments and Controls.................................................................................................................53
Instrument panel indicator and gauge, and how to use dashboard and steering column controls.
Comfort and Convenience Features ..............................................................................................109
How to operate the climate control system, the audio system, and other convenience features.
Before Driving..................................................................................................................................179
What gasoline to use, how to break -in your new vehicle, and how to load luggage and other cargo.
Driving ..............................................................................................................................................191
The proper way to start the engine, shift the transmission, and park, plus towing a trailer.
Maintenance.....................................................................................................................................209
The Maintenance Schedule shows you when you need to take you r vehicle to the dealer.
Taking Care of the Unexpected......................................................................................................253
This section covers several problems motorists sometimes experience, an d how to handle them.
Technical Information.....................................................................................................................277
ID numbers, dimensions, capacities, and technical information.
Warranty and Customer Relations (U.S. and Canada)................................................................291
A summary of the warranties covering your new Acura, and how to contact us.
Authorized Manuals (U.S. only)......................................................................................................295
How to order manuals and other technical literature.
Index...................................................................................................................................................... I
Service Information Summary
A summary of information you need when you pull up to the fuel pump.
Navigation System
................................................................................................................iii
ty
Introduction
Main Menu
▲
▼
Congratulations! Your selection of a 2007 Honda Civic was a wise investment.
It will give you years of driving pleasure.
One of the best ways to enhance the enjoyment of your new vehicle is to
read this manual. In it, you will learn how to operate its driving controls and
convenience items. Afterwards, keep this owner’s manual in your vehicle so
youcanrefertoitatanytime.
Several warranties protect your new vehicle. Read the warranty booklet
thoroughly so you understand the coverages and are aware of your rights
and responsibilities.
Maintaining your vehicle according to the maintenance minder shown in the
instrument panel helps to keep your driving trouble-free while it preserves
your investment. When your vehicle needs maintenance, keep in mind that
your dealer’s staff is specially trained in servicing the many systems unique
to your vehicle. Your dealer is dedicated to your satisfaction and will be
pleased to answer any questions and concerns.
As you read this manual, you will
find inf ormation that is preceded by
a symbol. This
information is intended to help you
avoid damage to your vehicle, other
property, or the environment.
i
Introduction
Main Menu
▲
▼
California Proposition 65 Warning
WARNING:
This product contains or emits chemicals known to the state of California to cause cancer and birth
defects or other reproductive harm.
Event Data Recorders
This vehicle is equipped with one or more devices commonly ref erred to as event data recorders. These devices
record front seat belt use, front passenger seat occupancy, airbag deployment data, and the failure of any airbag
system component. This data belongs to the vehicle owner and may not be accessed by anyone else except as legally
required or with the permission of the vehicle owner.
Service Diagnostic Recorders
This vehicle is equipped with service-related devices that record information about powertrain perf ormance. The data
can be used to verify emissions law requirements and/or help technicians diagnose and solve service problems. It may
also be combined with data f rom other sources for research purposes, but it remains conf idential and is never linked to
the vehicle owner.
California Perchlorate Contamination Prevention Act
The airbags, seat belt tensioners, and CR type batteries in this vehicle contain perchlorate materials - special handling
may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate.
ii
AFewWordsAboutSafety
Main Menu
▲
▼
Your safety, and the safety of others,
is very important. And operating this
vehicle safely is an important
responsibility.
To help you make informed
decisions about safety, we have
provided operating procedures and
other information on labels and in
this manual. This inf ormation alerts
you to potential hazards that could
hurt you or others.
Of course, it is not practical or
possible to warn you about all the
hazards associated with operating or
maintaining your vehicle. You must
use your own good judgement.
You will f ind this important safety information in a variety of forms,
including:
−
Safety Labels
Safety Messages
three signal words: , , or .
on the vehicle.
−
preceded by a safety alert symbol and one of
DANGER WARNING CAUTION
These signal words mean:
You WILL be KILLED or SERIOUSLY
HURT if you don’t follow instructions.
You CAN be KILLED or SERIOUSLY
HURT if you don’t follow instructions.
You CAN be HURT if you don’t follow
instructions.
−
Safety Headings
such as Important Safety Reminders or Important
Safety Precautions.
−
Safety Section
Instructions
This entire book is f illed with important saf ety information please read it
such as Driver and Passenger Safety.
−
how to use this vehicle correctly and safely.
−
carefully.
iii
Your Vehicle at a Glance
Main Menu
▲
▼
INSTRUMENT PANEL
INDICATORS
GAUGES
DRIVER’S FRONT AIRBAG
(P.9, 23)
MIRROR CONTROLS
(P.101)
POWER DOOR LOCK
MASTER SWITCH
(P.79)
POWER WINDOW
SWITCHES
(P.97)
HOOD RELEASE
HANDLE
(P.182)
A/T model is shown.
(P.57)
(P.64)
HAZARD WARNING
BUTTON
FUEL FILL DOOR/
TRUNK RELEASE HANDLE
(P.181, 89)
(P.73)
MOONROOF SWITCH
ACCESSORY POWER
SOCKETS
(P.105)
(P.99)
(P.173)
CLOCK
PASSENGER’S FRONT
AIRBAG
AUDIO SYSTEM
(P.115)
HEATING/COOLING
CONTROLS
(P.110)
AUTOMATIC TRANSMISSION
(P.198)
MANUAL TRANSMISSION
(P.195)
(P.9, 23)
Your Vehicle at a Glance
3
Your Vehicle at a Glance
Main Menu
▲
▼
HEADLIGHTS/TURN SIGNALS
(P.71)
INSTRUMENT PANEL
BRIGHTNESS
(P.72)
DISPLAY CHANGE
BUTTON
WINDSHIELD WIPERS/WASHERS
(P.70)
(P.65)
SEL/RESET BUTTON
(P.64)
MIRROR CONTROLS
(P.101)
VEHICLE
STABILITY
ASSIST (VSA)
SYSTEM OFF
SWITCH
(P.207)
REMOTE
AUDIO
CONTROLS
(P.170)
＊
VOICE CONTROL SWITCHES
＊
Only on vehicles equipped with navigation system. Refer to the navigation system manual.
1:
＊
To use the horn, press the center pad of the steering wheel.
2:
＊
If equipped.
3:
1
＊
HORN
TILT/
TELESCOPIC
ADJUSTMENT
＊
3
(P.74)
2
CRUISE
CONTROL
BUTTONS
(P.175)
＊
4
PASSENGER AIRBAG OFF
INDICATOR
(P.29)
REAR WINDOW
DEFOGGER
(P.73)
HEATED MIRRORS
(P.102)
HAZARD WARNING
BUTTON
(P.73)
ACCESSORY POWER
SOCKET
3
(P.105)
＊
3
Driver and Passenger Saf ety
Main Menu
▲
▼
This section gives you important
information about how to protect
yourself and your passengers. It
shows you how to use seat belts. It
explains how your airbags work. And
it tells you how to properly restrain
infants and children in your vehicle.
5. Fasten and Position the Seat
.....................................Belts . 14
6. Maintain a Proper Sitting
................................Position . 15
.........Important Safety Precautions . 6
.......Your Vehicle’s Safety Features . 7
.........Protecting Adults and Teens . 11
.....1. Close and Lock the Doors . 11
...........2. Adjust the Front Seats . 11
............3. Adjust the Seat-Backs . 12
...4. Adjust the Head Restraints . 13
.....Advice for Pregnant Women . 16
...Additional Safety Precautions . 16
Additional Information About
.......................Your Seat Belts . 18
......................Lap/Shoulder Belt . 19
Automatic Seat Belt
...............................Tensioners . 19
...............Seat Belt Maintenance . 20
Additional Information About
...........................Your Airbags . 21
How Your Front Airbags
.........................................Work . 23
How the Side Curtain Airbags
.........................................Work . 28
How the Side Airbag Of f
......................Indicator Works . 29
How the Passenger Airbag Off
......................Indicator Works . 29
.............................Airbag Service . 30
Protecting Children General
−
................................Guidelines . 32
All Children Must Be
...............................Restrained . 32
..Seat Belt System Components . 18
......Airbag System Components . 21
...How Your Side Airbags Work . 26
..How the SRS Indicator Works . 28
...Additional Safety Precautions . 31
All Children Should Sit in a
.................................Back Seat . 33
The Passenger’s Front Airbag
If You Must Drive with Several
...................................Children . 35
If a Child Requires Close
..................................Attention . 35
Protecting Infants and Small
...................................Children . 37
.......................Protecting Infants . 37
.....................Selecting a Child Seat . 39
....................Installing a Child Seat . 40
...............................With LATCH . 41
..............................With a Tether . 45
...............Checking Seat Belt Fit . 46
..................Using a Booster Seat . 47
When Can a Larger Child Sit in
.........................................Front . 48
.............Carbon Monoxide Hazard . 50
...................................Safety Labels . 51
.........Can Pose Serious Risks . 33
...Additional Safety Precautions . 35
.........Protecting Small Children . 38
.........With a Lap/Shoulder Belt . 43
...........Protecting Larger Children . 46
...Additional Safety Precautions . 49
Driver and Passenger Safety
5
Important Saf ety Precautions
Main Menu
Table of Contents
▲
▼
You’ll find many safety
recommendations throughout this
section, and throughout this manual.
Therecommendationsonthispage
are the ones we consider to be the
most important.
Always Wear Your Seat Belt
A seat belt is your best protection in
all types of collisions. Airbags are
designed to supplement seat belts,
not replace them. So even though
your vehicle is equipped with airbags,
make sure you and your passengers
always wear your seat belts, and
wear them properly (see page ).
6
14
Restrain All Children
Children age 12 and under should
ride properly restrained in a back
seat, not the front seat. Infants and
smallchildrenshouldberestrained
in a child seat. Larger children
should use a booster seat and a lap/
shoulder belt until they can use the
belt properly without a booster seat
(see pages ).
−
32 49
Be Aware of Airbag Hazards
While airbags can save lives, they
can cause serious or fatal injuries to
occupants who sit too close to them,
or are not properly restrained.
Infants, young children, and short
adults are at the greatest risk. Be
sure to follow all instructions and
warnings in this manual.
Don’t Drink and Drive
Alcohol and driving don’t mix. Even
one drink can reduce your ability to
respond to changing conditions, and
your reaction time gets worse with
every additional drink. So don’t drink
and drive, and don’t let your friends
drink and drive, either.
Control Your Speed
Excessive speed is a major factor in
crash injuries and deaths. Generally,
the higher the speed, the greater the
risk, but serious injuries can also
occur at lower speeds. Never drive
faster than is safe for current
conditions, regardless of the
maximum speed posted.
Keep Your Vehicle in Safe
Condition
Having a tire blowout or a
mechanical failure can be extremely
hazardous. To reduce the possibility
of such problems, check your tire
pressures and condition frequently,
and perform all regularly scheduled
maintenance (see page ).
211
Your Vehicle’s Saf ety Features
Main Menu
Table of Contents
▲
▼
(5)
(7)
(11)
(8)
(1) (3)
(2)
(6)(4)
(9)
(10)
(8)
(12)
(7)
(1) Safety Cage
(2) Crush Zone
(3) Seats and Seat-Backs
(4) Head Restraints
(5) Collapsible Steering Column
(6) Seat Belts
(7) Front Airbags
(8) Side Airbags
(9) Side Curtain Airbags
(10) Front Seat Belt Tensioners
(11) Door Locks
(12) Front Seat Belt Buckle
Tensioners
(2)
Your vehicle is equipped with many
features that work together to
protect you and your passengers
during a crash.
Some features do not require any
action on your part. These include a
strong steel framework that forms a
safety cage around the passenger
compartment; front and rear crush
zones; a collapsible steering column;
and tensioners that tighten the front
seat belts in a crash.
However, you and your passengers
can’t take full advantage of these
features unless you remain sitting in
a proper position and
your seat belts
always wear
. In fact, some safety
features can contribute to injuries if
they are not used properly.
The f ollowing pages explain how you
cantakeanactiveroleinprotecting
yourself and your passengers.
Driver and Passenger Safety
7
Your Vehicle’s Saf ety Features
Main Menu
Table of Contents
▲
▼
Seat Belts
Your vehicle is equipped with seat
belts in all seating positions.
Your seat belt system also includes
an indicator on the instrument panel
and a beeper to remind you and your
passengers to fasten your seat belts.
Why Wear Seat Belts
Seat belts are the single most
effectivesafetydeviceforadultsand
larger children. (Infants and smaller
children must be properly restrained
in child seats.)
Not wearing a seat belt properly
increases the chance of serious
injury or death in a crash, even
though your vehicle has airbags.
In addition, most states and all
Canadian provinces require you to
wear seat belts.
8
Not wearing a seat belt properly
increases the chance of serious
injury or death in a crash, even
though your vehicle has airbags.
Be sure you and your
passengers always wear seat
belts and wear them properly.
When properly worn, seat belts:
Keep you connected to the vehicle
so you can take advantage of the
vehicle’s built-in safety features.
Help protect you in almost every
type of crash, including frontal,
side, and rear impacts and
rollovers.
Help keep you from being thrown
against the inside of the vehicle
and against other occupants.
Keep you from being thrown out
of the vehicle.
Help keep you in a good position
should the airbags ever deploy. A
good position reduces the risk of
injury from an inflating airbag and
allows you to get the best
advantage from the airbag.
Of course, seat belts cannot
completely protect you in every
crash.Butinmostcases,seatbelts
can reduce your risk of serious
injury.
What You Should Do:
Always wear your seat belt, and
make sure you wear it properly.
Airbags
Main Menu
Table of Contents
▲
▼
Your Vehicle’s Saf ety Features
Driver and Passenger Safety
Your vehicle has a supplemental
restraint system (SRS) with front
airbags to help protect the heads and
chests of the driver and a front seat
passenger during a moderate to
severe frontal collision (see page
for more information on how
23
your front airbags work).
Your vehicle also has side airbags to
help protect the upper torso of the
driver or a front seat passenger
during a moderate to severe side
impact (see page for more
26
information on how your side airbags
work).
In addition, your vehicle has side
curtain airbags to help protect the
heads of the driver, front passenger,
and passengers in the outer rear
seating positions during a moderate
to severe side impact (see page
for more information on how
28
your side curtain airbags work).
CONTINUED
9
Your Vehicle’s Saf ety Features
Main Menu
Table of Contents
▲
▼
The most important things you need
to know about your airbags are:
Airbags do not replace seat belts.
They are designed to supplement
the seat belts.
Airbags off er no protection in rear
impacts, or minor frontal or side
collisions.
Airbags can pose hazards.
their job, airbags must inflate with
tremendous f orce. So while
airbags help save lives, they can
cause minor injuries or more
serious or even fatal injuries if
occupants are not properly
restrained or sitting properly.
10
To do
What you should do:
Always wear
your seat belt properly, and sit
upright and as far back from the
steering wheel as possible while
allowing full control of the vehicle. A
front passenger should move their
seat as far back from the dashboard
as possible.
The rest of this section gives more
detailed inf ormation about how you
can maximize your safety.
Remember, however, that no safety
system can prevent all injuries or
deaths that can occur in a severe
crash, even when seat belts are
properly worn and the airbags deploy.
The following pages provide
Main Menu
Table of Contents
▲
▼
instructions on how to properly
protect the driver, adult passengers,
and teenage children who are large
enough and mature enough to drive
or ride in the front.
See pages for important
−
32 36
guidelines on how to properly
protect infants, small children, and
larger children who ride in your
vehicle.
Close and Lock the Doors1.
After everyone has entered the
vehicle, be sure the doors are closed
and locked.
Your vehicle has a door-
openindicatoronthe
instrument panel to indicate when
either door is not tightly closed.
Locking the doors reduces the
chance of someone being thrown out
of the vehicle during a crash, and it
helps prevent passengers from
accidentally opening a door and
falling out.
Locking the doors also helps prevent
an outsider from unexpectedly
opening a door when you come to a
stop.
See page for how to lock the
doors, and page for how the door
78
62
monitor indicator works.
Some models have auto door
locking/unlocking features. For
more information, see page .
79
Protecting Adults and Teens
Adjust the Front SeatsIntroduction
2.
Adjust the driver’s seat as far to the
rear as possible while allowing you to
maintain full control of the vehicle.
Have a front passenger adjust their
seat as far to the rear as possible.
CONTINUED
Driver and Passenger Safety
11
Protecting Adults and Teens
Main Menu
Table of Contents
▲
▼
If you sit too close to the steering
wheel or dashboard, you can be
seriously injured by an inflating front
airbag, or by striking the steering
wheel or dashboard.
The National Highway Traffic Safety
Administration and Transport
Canada recommend that drivers
allow at least 10 inches (25 cm)
between the center of the steering
wheel and the chest. In addition to
adjusting the seat, you can adjust the
steering wheel up and down, and in
and out (see page ).74
If you cannot get far enough away
from the steering wheel and still
reach the controls, we recommend
that you investigate whether some
type of adaptive equipment may help.
12
Sitting too close to a front
airbag can result in serious
injury or death if the front
airbags inflate.
Always sit as far back from the
front airbags as possible.
Once your seat is adjusted correctly,
rock it back and forth to make sure
the seat is locked in position.
See page for how to adjust the
91
front seats.
Adjust the Seat-Backs3.
Adjust the driver’s seat-back to a
comfortable, upright position,
leaving ample space between your
chest and the airbag cover in the
center of the steering wheel.
Passengers with adjustable seatbacks should also adjust their seatback to a comfortable, upright
position.
Protecting Adults and Teens
Main Menu
Table of Contents
▲
▼
Adjust the Head Restraints4.
Reclining the seat-back too far
can result in serious injury or
death in a crash.
Adjust the seat-back to an
upright position, and sit well
back in the seat.
Reclining a seat-back so that the
shoulder part of the belt no longer
rests against the occupant’s chest
reduces the protective capability of
the belt. It also increases the chance
of sliding under the belt in a crash
and being seriously injured. The
farther a seat-back is reclined, the
greater the risk of injury.
See page for how to adjust the
91
seat-backs.
Adjust the driver’s head restraint so
the back of your head rests against
the center of the restraint.
Have passengers adjust their head
restraints properly as well. Taller
persons should adjust their restraint
as high as possible.
Improperly positioning head
restraints reduces their
effectiveness and you can be
seriously injured in a crash.
Make sure head restraints are
in place and positioned properly
before driving.
Properly adjusted head restraints
will help protect occupants from
whiplash and other crash injuries.
See page for how to adjust the
94
head restraints.
CONTINUED
Driver and Passenger Safety
13
Protecting Adults and Teens
Main Menu
Table of Contents
▲
▼
Fasten and Position the Seat
5.
Belts
then tug on the belt to make sure the
belt is securely latched. Check that
the belt is not twisted, because a
twisted belt can cause serious
injuries in a crash.
14
This spreads the forces of a crash
over the strongest bones in your
upper body.Insert the latch plate into the buckle,
Improperly positioning the seat
belts can cause serious injury
or death in a crash.
Make sure all seat belts are
properly positioned before
driving.
Position the lap part of the belt as
low as possible across your hips,
then pull up on the shoulder part of
the belt so the lap part fits snugly.
This lets your strong pelvic bones
take the force of a crash and reduces
the chance of internal injuries.
If necessary, pull up on the belt again
to remove any slack, then check that
the belt rests across the center of
your chest and over your shoulder.
Protecting Adults and Teens
Main Menu
Table of Contents
▲
▼
Never place the shoulder portion of a
lap/shoulder belt under your arm or
behind your back.
This could cause
very serious injuries in a crash.
If a seat belt does not seem to work
properly, it may not protect the
occupant in a crash.
No one should sit in a seat with an
inoperative seat belt.
Using a seat
belt that is not working properly can
result in serious injury or death.
Have your dealer check the belt as
soon as possible.
See page for additional
18
information about your seat belts
and how to take care of them.
Maintain a Proper Sitting
6.
Position
After all occupants have adjusted
their seats and put on seat belts, it is
very important that they continue to
sit upright, well back in their seats,
with their feet on the floor, until the
vehicle is parked and the engine is
off.
Sitting improperly can increase the
chance of injury during a crash. For
example, if an occupant slouches,
lies down, turns sideways, sits
forward, leans forward or sideways,
or puts one or both feet up, the
chance of injury during a crash is
greatly increased.
In addition, an occupant who is out of
position in the front seat can be
seriously or fatally injured in a crash
by striking interior parts of the
vehicle or being struck by an
inflating front airbag.
Sitting improperly or out of
position can result in serious
injury or death in a crash.
Always sit upright, well back in
the seat, with your feet on the
floor.
15
Driver and Passenger Safety
Protecting Adults and Teens
Main Menu
Table of Contents
▲
▼
Advice for Pregnant Women Additional Safety Precautions
When driving, remember to sit
upright and adjust the seat as far
back as possible while allowing full
control of the vehicle. When riding
as a front passenger, adjust the seat
Two people should never use the
same seat belt.
If they do, they
could be very seriously injured in a
crash.
as far back as possible.
Do not put any accessories on seat
This will reduce the risk of injuries
to both you and your unborn child
that can be caused by a crash or an
inflating front airbag.
belts.
Devices intended to improve
occupant comf ort or reposition the
shoulder part of a seat belt can
reduce the protective capability of
the belt and increase the chance of
Each time you have a checkup, ask
serious injury in a crash.
your doctor if it’s okay for you to
If you are pregnant, the best way to
protect yourself and your unborn
child when driving or riding in a
vehicle is to always wear a seat belt,
and keep the lap part of the belt as
low as possible across the hips.
drive.
Do not place hard or sharp objects
between yourself and a front
airbag.
Carrying hard or sharp
objects on your lap, or driving with
a pipe or other sharp object in
your mouth, can result in injuries
if your front airbag inflates.
16
Protecting Adults and Teens
Main Menu
Table of Contents
▲
▼
Keep your hands and arms away
from the airbag covers.
hands or arms are close to an
airbag cover, they could be injured
if the airbag inflates.
Do not attach or place objects on
the f ront airbag covers.
the covers marked ‘‘SRS AIRBAG’’
could interf ere with the proper
operation of the airbags or be
propelled inside the vehicle and
hurt someone if the airbags inf late.
Do not attach hard objects on or
near a door.
side curtain airbag inflates, a cup
holder or other hard object
attached on or near the door could
be propelled inside the vehicle and
hurt someone.
If your
Objects on
If a side airbag or a
Never let passengers ride on top of
a folded-down rear seat.
If they do,
they could be very seriously
injuredinacrash.
Driver and Passenger Safety
17
Additional Information About Your Seat Belts
Main Menu
Table of Contents
▲
▼
Seat Belt System Components
Your seat belt system includes lap/
shoulder belts in all five seating
positions. The front seat belts are
also equipped with automatic seat
belt tensioners.
This system uses the same sensors
as the front airbags to monitor
whether the front seat belts are
latched or unlatched, and how much
weight is on the front passenger’s
seat (see pages and ).
22 25
The seat belt system
includes an indicator on the
instrument panel and a beeper to
remind you and your passengers to
fasten your seat belts.
18
This system monitors the front seat
belts. If you turn the ignition switch
to the ON (II) position before your
seat belt is fastened, the beeper will
sound and the indicator will flash. If
your seat belt is not fastened before
the beeper stops, the indicator will
stop flashing but remain on.
If a front passenger does not fasten
their seat belt, the indicator will
come on about 6 seconds after the
ignition switch is turned to the ON
(II) position.
If either the driver or a front
passenger does not fasten their seat
belt while driving, the beeper will
sound and the indicator will flash
again at regular intervals.
When no one is sitting in the front
passenger’s seat, or a child or small
adult is riding there, the indicator
should not come on and the beeper
should not sound.
If the indicator comes on or the
beeper sounds when the driver’s seat
belt is latched and there is no front
seat passenger and no items on the
front seat, something may be
interfering with the monitoring
system. Look f or and remove:
Any items under the f ront
passenger’s seat.
Any objects hanging on the seat or
in the seat-back pocket.
Any objects, such as a folded-down
back seat, that are touching the
rear of the seat-back.
If no obstructions are found, have
your vehicle checked by a dealer.
Additional Information About Your Seat Belts
Main Menu
Table of Contents
▲
▼
Lap/Shoulder Belt Automatic Seat Belt Tensioners
The lap and shoulder belt goes over
your shoulder, across your chest,
and across your hips.
All seat belts have an emergency
locking retractor. In normal driving,
the retractor lets you move freely in
your seat while it keeps some
tension on the belt. During a collision
To fasten the belt, insert the latch
plate into the buckle, then tug on the
belt to make sure the buckle is
or sudden stop, the retractor
automatically locks the belt to help
restrain your body.
latched (see page for how to
properly position the belt).
In addition, the lap/shoulder belts in
all seating positions except the
To unlock the belt, press the red
PRESSbuttononthebuckle.Guide
the belt across your body so that it
retracts completely. After exiting the
vehicle, be sure the belt is out of the
way and will not get closed in the
door.
driver’s have a lockable retractor
that must be activated to secure a
child seat (see page ).1443
If the shoulder part of the belt is
pulled all the way out, the lockable
retractor will activate. The belt will
retract, but it will not allow the
passenger to move freely.
For added protection, the front seat
belts are equipped with automatic
seat belt tensioners. When activated,
the tensioners immediately tighten
the belts to help hold the driver and
a front passenger in position.
To deactivate the lockable retractor,
unlatch the buckle and let the seat
belt fully retract. To refasten the
seat belt, pull it out only as far as
needed.
Driver and Passenger Safety
CONTINUED
19
Additional Information About Your Seat Belts
Main Menu
Table of Contents
▲
▼
The tensioners are designed to
activate in any collision severe
enough to cause the front airbags to
deploy.
If a side airbag or side curtain airbag
deploys during a side impact, the
tensioner on that side of the vehicle
will also deploy.
The tensioners can also be activated
during a collision in which the front
airbags . In this case, the
do not deploy
airbags would not be needed, but the
additional restraint could be helpful.
When the tensioners are activated,
the seat belts will remain tight until
they are unbuckled.
20
Seat Belt Maintenance
For safety, you should check the
condition of your seat belts regularly.
Pull each belt out fully, and look for
frays, cuts, burns, and wear. Check
that the latches work smoothly and
the belts retract easily. If a belt does
not retract easily, cleaning the belt
may correct the problem (see page
). Any belt that is not in good
239
condition or working properly will
not provide good protection and
should be replaced as soon as
possible.
Honda provides a limited warranty
on seat belts. See your
Warranty Information
Honda
booklet for
details.
If a seat belt is worn during a crash,
it must be replaced by your dealer. A
belt that has been worn during a
crash may not provide the same level
of protection in a subsequent crash.
The dealer should also inspect the
anchors for damage and replace
them if needed. If the automatic seat
belt tensioners activate during a
crash, they must be replaced.
Not checking or maintaining
seat belts can result in serious
injury or death if the seat belts
do not work properly when
needed.
Check your seat belts regularly,
and have any problem
corrected as soon as possible.
Airbag System Components
Main Menu
Table of Contents
▲
▼
Additional Information About Your Airbags
(1) Driver’s Airbag
(2) Front Passenger’s Airbag
(3) Control Unit
(4) Front Seat Belt Tensioners
(5) Side Airbags
(6) Driver’s Seat Position Sensor
(7) Front Passenger’s Weight Sensors
(8) Front Impact Sensors
(9) Passenger Airbag Off Indicator
(10) Side Impact Sensors (First)
(11) Occupant Position Detection System (OPDS) Sensors
(12) SRS Indicator
(13) Occupant Detection System (ODS) Unit
(14) Front Seat Belt Buckle Tensioners
(15) Rear Safing Sensor
(16) Side Impact Sensors (Second)
(17) Side Curtain Airbags
(8) (12) (8) (9) (17) (2) (13) (17)
(1)
(3)
(10)
(6)
(5)
(16)
(4)
(14)
(15)
(7)
(11)
Driver and Passenger Safety
(5)
(10)
(4)
(16)
CONTINUED
21
Additional Information About Your Airbags
Main Menu
Table of Contents
▲
▼
Your airbag system includes:
Two SRS (supplemental restraint
system) front airbags. The driver’s
airbag is stored in the center of
the steering wheel; the front
passenger’sairbagisstoredinthe
dashboard. Both are marked ‘‘SRS
AIRBAG’’ (see page ).
Two side airbags, one for the
driver and one for a front
passenger. The airbags are stored
in the outer edges of the seatbacks. Both are marked ‘‘SIDE
AIRBAG’’ (see page ).
Two side curtain airbags, one for
each side of the vehicle. The
airbags are stored in the ceiling,
above the side windows. The front
and rear pillars are marked ‘‘SIDE
CURTAIN AIRBAG’’ (see page
).
28
Automatic front seat belt
tensioners (see page ).
22
23
26
19
Sensors that can detect a
moderate to severe front impact or
side impact.
Sensors that can detect whether a
child is in the passenger’s side
airbag path and signal the control
unit to turn the airbag off (see
page ).
27
Sensors that can detect whether
the driver’s seat belt and a front
passenger’s seat belt is latched or
unlatched (see page ).
18
A driver’s seat position sensor that
monitors the distance of the seat
from the front airbag. If the seat is
too far forward, the airbag will
inflate with less force (see page
25
).
Sensors that monitor the weight
on the front passenger’s seat. If
the weight is about 65 lbs (29 kg)
or less (the weight of an infant or
small child), the passenger’s front
airbag will be turned off (see page
).
25
A sophisticated electronic system
that continually monitors and
records information about the
sensors, the control unit, the
airbag activators, the seat belt
tensioners, and driver and front
passenger seat belt use when the
ignition switch is in the ON (II)
position.
An indicator on the instrument
panel that alerts you to a possible
problem with your airbags,
sensors, or seat belt tensioners
(see page ).
28
Additional Information About Your Airbags
Main Menu
Table of Contents
▲
▼
An indicator on the instrument
panel that alerts you that the
passenger’s side airbag has been
turned off (see page ).2529
An indicator on the dashboard that
alerts you that the passenger’s
front airbag has been turned off
(see page ).
Emergency backup power in case
your vehicle’s electrical system is
disconnected in a crash.
29
How Your Front Airbags Work
If you ever have a moderate to
severe frontal collision, sensors will
detect the vehicle’s rapid
deceleration.
If the rate of deceleration is high
enough, the control unit will instantly
inflate the driver’s and front
passenger’s airbags, at the time and
with the force needed.
During a frontal crash, your seat belt
restrains your lower body and torso,
and the front airbag helps protect
your head and chest.
Although both airbags normally
inflate within split second of each
other, it is possible for only one
airbag to deploy.
This can happen if the severity of a
collision is at the margin, or
threshold, that determines whether
or not the airbags will deploy. In
such cases, the seat belt will provide
sufficient protection, and the
supplemental protection offered by
the airbag would be minimal.
Only the driver’s airbag will deploy if
there is no passenger in the front
seat, or if the advanced airbag
system has turned the passenger’s
airbag off (see page ).
CONTINUED
23
Driver and Passenger Safety
Additional Information About Your Airbags
Main Menu
Table of Contents
▲
▼
After inflating, the front airbags
immediately deflate, so they won’t
interfere with the driver’s visibility,
or the ability to steer or operate
other controls.
The total time for inflation and
deflation is one-tenth of a second, so
fast that most occupants are not
aware that the airbags deployed until
they see them lying in their laps.
24
After a crash, you may see what
looks like smoke. This is actually
powder from the airbag’s surface.
Although the powder is not harmful,
people with respiratory problems
mayexperiencesometemporary
discomfort. If this occurs, get out of
the vehicle as soon as it is saf e to do
so.
Dual-Stage Airbags
Your front airbags are dual-stage
airbags. This means they have two
inflation stages that can be ignited
sequentially or simultaneously,
depending on crash severity.
more severe
In a crash, both stages
will ignite simultaneously to provide
the quickest and greatest protection.
less severe
In a crash, one stage will
ignite first, then the second stage
will ignite a split second later. This
provides longer airbag inflation time
with a little less force.
Dual-Threshold Airbags
Your front airbags are also dualthreshold airbags. Airbags with this
feature have two deployment
thresholds that depend on whether
sensors detect the occupant is
wearing a seat belt or not.
If the occupant’s belt is ,
not latched
the airbag will deploy at a slightly
lower threshold, because the
occupant would need extra
protection.
If the occupant’s belt is , the
latched
airbag will inf late at a slightly higher
threshold, when the airbag would be
needed to supplement the protection
provided by the seat belt.
Advanced Airbags
Main Menu
Table of Contents
▲
▼
Your front airbags are also advanced
airbags. The main purpose of this
feature is to help prevent airbagcaused injuries to short drivers and
children who ride in front.
Additional Information About Your Airbags
Driver and Passenger Safety
For both advanced airbags to work
properly:
Occupants must sit upright and
wear their seat belts properly.
Do not spill any liquids on or
under the seats, cover the sensors,
or put any objects or metal items
under the f ront seats.
Back-seat passengers should not
put their feet under the front seats.
Failure to follow these instructions
could damage the sensors or prevent
them from working properly.
DRIVER’S
SEAT
POSITION
SENSOR
The driver’s advanced front airbag
system includes a seat position
sensor under the seat. If the seat is
too far forward, the airbag will
inflate with less force, regardless of
the severity of the impact.
If there is a problem with the sensor,
the SRS indicator will come on, and
the airbag will inflate in the normal
manner regardless of the driver’s
seating position.
PASSENGER’S
SEAT WEIGHT
SENSORS
The passenger’s advanced f ront
airbag system has weight sensors
under the seat. Although Honda
does not encourage carrying an
infant or small child in front, if the
sensors detect the weight of an
infant or small child (up to about 65
lbs or 29 kg), the system will
automatically turn the passenger’s
front airbag off.
CONTINUED
25
Additional Information About Your Airbags
Main Menu
Table of Contents
▲
▼
Be aware that objects placed on
the passenger’s seat can also
cause the airbag to be turned off.
When the airbag is turned off, a
‘‘passenger airbag off’’ indicator in
the center of the dashboard comes
on (see page ).
29
If the weight sensors detect there is
no passenger in the front seat, the
airbag will be off. However, the
passenger airbag off indicator will
not come on.
To ensure that the passenger’s
advanced front airbag system will
work properly,
that would increase or decrease the
weight on the front passenger’s seat.
do not do anything
This includes:
A rear passenger pushing or
pulling on the back of the front
passenger’s seat.
26
Moving the front seat forcibly
back against cargo on the seat or
floor behind it.
Moving the front seat or seat-back
forcibly back against the folded
rear seat.
The rear seat-back interfering
with the reclined front passenger’s
seat-back when the rear seat is
folded down.
Hanging heavy items on the front
passenger seat, or placing heavy
items in the seat-back pocket.
If your vehicle is equipped with
thefloormats,makesurethefloor
matbehindthefrontpassenger’s
seat is hooked to the floor mat
anchor (see page ). If it is not,
240
the mat may interfere with the
proper operation of the sensors
and operation of the seat.
How Your Side Airbags Work
If you ever have a moderate to
severe side impact, sensors will
detect rapid acceleration and signal
the control unit to instantly inf late
either the driver’s or the passenger’s
side airbag and activate the seat belt
tensioner on the affected side.
Additional Information About Your Airbags
Main Menu
Table of Contents
▲
▼
Only one airbag will deploy during a
side impact. If the impact is on the
passenger’s side, the passenger’s
side airbag will deploy even if there
is no passenger.
To get the best protection from the
side airbags, front seat occupants
should wear their seat belts and sit
upright and well back in their seats.
Side Airbag Cutoff System
Your vehicle has a side airbag cutoff
system designed primarily to protect
a child riding in the front passenger’s
seat.
Although Honda does not encourage
children to ride in front, if sensors in
the seat detect a child has leaned
into the side airbag’s deployment
path, the airbag will shut off.
Thesideairbagmayalsoshutoffifa
short adult leans sideways, or a
larger adult slouches and leans
sideways into the airbag’s
deployment path.
Objects placed on the front
passenger seat can also cause the
side airbag to be shut off.
If the side airbag off indicator comes
on (see page ), have the
29
passenger sit upright. Once the
passenger is out of the airbag’s
deployment path, the system will
turn the airbag back on, and the
indicator will go out.
There will be some delay between
the moment the passenger moves
into or out of the airbag deployment
pathandwhentheindicatorcomes
on or goes off.
A front seat passenger should not
use a cushion or other object as a
backrest. It may prevent the cutoff
system f rom working properly.
27
Driver and Passenger Safety
Additional Information About Your Airbags
Main Menu
Table of Contents
▲
▼
How Your Side Curtain Airbags
Work
SIDE CURTAIN AIRBAG
In a moderate to severe side impact,
sensors will detect rapid acceleration
and signal the control unit to
instantly inflate the side curtain
airbag and activate the seat belt
tensioner on the driver’s or the
passenger’s side of the vehicle.
28
If the impact is on the passenger’s
side, the passenger’s side curtain
airbag will inflate even if there are no
occupants on that side of the vehicle.
To get the best protection from the
side curtain airbags, occupants
should wear their seat belts and sit
upright and well back in their seats.
How the SRS Indicator Works
The SRS indicator alerts
you to a potential problem
with your airbags or seat belt
tensioners.
When you turn the ignition switch to
the ON (II) position, this indicator
comes on briefly then goes off. This
tells you the system is working
properly.
If the indicator comes on at any
other time, or does not come on at all,
you should have the system checked
by your dealer. For example:
If the SRS indicator does not come
on after you turn the ignition
switch to the ON (II) position.
If the indicator stays on after the
engine starts.
If the indicator comes on or
flashesonandoffwhileyoudrive.
Loading...
