Page 1
Size : 90*63 MM
Smart IR PRO
with Temperature and Humidity
Universal control
for infrared devices
remotely
be smart, be wireless
User manual
Code 559593021
Thank you for choosing the HOM-iO products!
Product Specification
Size: 60*60*20mm
Micro Input: DC 5V/1A
LED Indicator: Blue
Infrared Frequency: 38KHz
Infrared Range: ≤10 Meters
Wi-Fi Protocol: 2.4GHz
Wi-Fi Standard: IEEE 802.11 b/g/n
Temperature Measure Range: 0°~ 60°C
Temperature Accuracy: ± 1°C
Humidity Measure Range: 0% ~ 99% RH
Humidity Accuracy: ± 5% RH
Product Presentation
Front Side Back Side
Reset ButtonLED Indicator
Note: please place it like the front side when use.
-2-
Micro Input port
App installation
Download the HOM-iO app from the App Store or Google Play.
Record the account on your app.
Available on the
Get it on
Checklist before using the device
a. Your smartphone has connected to a 2.4GHz Wi-Fi network
b. You have input the correct Wi-Fi password
c. Your smartphone must be Android 4.4 + or iOS 8.0 +
d. Your Wi-Fi router is MAC-open
e. If the numbers of devices connected to the Wi-Fi router reach the
limit, you can try to disable a device to cavate the channel or try
with another Wi-Fi router
Discover the full range on: www.hom-io.it
Connect the Alexa skill or Google Action "Hom-io" or
*
"Smart Life" and log in with the credentials created in
the Hom-io APP
Voice instructions may vary depending on the assistant
*
used
-3-
How to set up
1. Connect your mobile to your Wi-Fi router, supply power to the
remote control with Micro charging cable, click“+” in the upper
right corner of homepage or click “Add Device”.
2. Turn on the bluetooth in mobile:
The App will ask you to turn on the bluetooth in your mobile,
then you choose the device to add. Enter into your Wi-Fi
name and Wi-Fi password, it will connect the network
automatically.
-4-
3. If you don’t want use bluetooth:
Select ”Smart IR PRO” from
“Small Appliance”, enter into the
Wi-Fi password, make sure the
LED indicator is blinking rapidly,
if not, please hold the reset
button for about 5s till indicator
blink quickly. It will connect
automatically.
-5- -6-
4. If your Wi-Fi router open both 2.4GHz and 5GHz with the
same name, enter Wi-Fi password, please select “AP Mode”,
hold the reset button for about 5 seconds till LED indicator
blink slowly, connect your mobile to the device’s hotspot:
“SmartLife-XXXX”, then click to return to App interface, it will
connect to Wi-Fi router automatically, configuration complete.
-7- -8-
5. Tap “Smart IR PRO”, then click
”Add ”, select the device and its
brand you need control, you can
click “Quick Match” or “Manual
Mode” to match the buttons, please
match at least 3 buttons to check if
the device reacts properly, if yes,
then match completed, you can
control the device.
If you added the same device type
with the same brand in one room,
please edit the device with different
names to avoid control confusion.
-9-
Product compliance
SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby, manufacturer Melchioni Ready S.r.l. declares that the radio
equipment type Universal Smart IR, Mod. HOM-IR REMOTEpro
(code 559593021) is in compliance with Directive 2014/53/EU. The
full text of the EU declaration of conformity is available at the
following internet address: http://www.melchioni.it.
According to Directive 2012/19/EU of the European Parliament and
of the Council, of 4 july 2012, on waste electrical and electronic
equipment (WEEE), the presence of the crossed-out bin symbol
indicates that this appliance is not to be considered as urban waste:
its disposal must therefore be carried out by separate collection.
Disposal in a non-separate manner may constitute a potential harm
to the environment and health. This product can be returned to the
distributor when purchasing a new device. Improper disposal of the
appliance constitutes misconduct and is subject to sanctions by the
Public Security Authority. For further information, contact the local
administration responsible for environmental matters.
Made in China
Melchioni Ready S.r.l.
Via Colletta, 37 - 20135 Milano | www.melchioni-ready.com
-10-
6. If you can not find the brand of the device in the brand list, you
can choose “DIY” to learn the buttons of other brands’ remote
control, so you can also control the device.
-11-
Step 2Step 1
Step 4
7. You can click “+” to continue to copy other buttons or click “Finish”
Step 5
-12-
Step 3
Step 6
Notes
1. It only support 38KHz frequency, if the IR remote unable to
receive commands from the IR device, it is likely that the
frequency of IR device does not match, unable to study
commands.
2. DIY does not support voice control.
Functions
1. Customize Scenario/Automation
Click ”Smart” page, select “Scenario” or “Automation”, than
click ”+” at the upper right corner to set conditions and tasks.
-13- -14-
2. Intelligent Linkage
When the ambient
environment change, you can
execute intelligent linkage.
For example, when the room
temperature surpass 30°C,
the air-conditioner will open
automatically, or when the
humidity lower than 20% RH,
the humidifier will spray.
3. Remote control
With all-in-one integration, you can control added IR devices
remotely wherever you are at anytime on the mobile App.
4. Set Schedule
Select “Scenario” or “Automation” in “Smart” page, tap “+” to
select “Schedule” to set power on/off for specific devices.
-15-
5. Share devices
Click "Profile", "Home
Management", select your
home, click "Add Members"
and select the sharing
method.
-16-
6. Monitor Temperature
& Humidity
You can real-time monitor
the temperature and
humidity on the App, and
take actions to make
some adjustments if
necessary, creating
Scenarios or Automations
based on his parameters.
-17-
7. Third-party Voice Control
Compatible with Amazon Alexa and Google Home.
The devices can be automatically found by modern voice control
systems.
Download the "Amazon Alexa" or "Google Assistant" App to connect
the devices.
By selecting a device in the “ ” menu, help is available for
connecting to the voice control systems.
For Alexa select "Skill and
play" and search for
"Hom-io" or "Smart Life".
For Google "+ button",
"configure device",
"compatible with Google"
and search for "Hom-io"
or "Smart Life".
Connect with the credentials
of the Hom-io APP.
-18-
Reset and remove device
Click on the device, in the " "
menu at the top right scroll down to
"Removing a device" and click to
“Disconnect and clear all data”.
To reset the device, press the Reset
button until Blue LED flash quickly.
FAQ
1. What devices can be controlled with IR remote?
You can control TV, Air-conditioner, Fan, DVD, TV box, Light,
Set-top box, Projector, Audio, Camera, Water Heater, Air
purifer, etc.
2. What should i do when i cannot control the device with
the IR remote?
Make sure your mobile device and the IR remote is close and
connected to the same network, assure the IR remote is always
being power supplied.
-19-
3. What should i do when device configuration proccess fail?
You can:
1) Check whether IR remote is powered on or not.
2) Check whether your mobile phone is connected to
2.4GHz wifi network.
3) Check your network connectivity, make sure the router
is working properly.
4) Make sure the wifi password entered is correct.
4. The IR remote can go through walls or be used to control
devices in upstairs/downstairs rooms?
IR can not penetrate walls, so make sure there is no obstacle
between IR remote and the IR devices.
5. What should we do when we are unable to use IR remote to
control device?
Please check the following:
1) IR remote network in good condition (click any keys on the
remote control panel in the app and see whether the indicator
light starts flashing. If it flashes, it indicates to work properly.
2) There are no obstacles or barriers between the IR remote
and the electric device.
3) The factory remote control of electric device is IR-enabled.
(Cover the top of the IR remote with hand or any objects,
then press any keys of the remote control, if the device does
not response, it is IR based. Otherwise, it is bluetooth or RF
based remote control.
