Homestyles 20 08000 0089 Assembly Instructions

20 08000 0089
Bar Stool
IMPORTANT
Carefully remove all the parts from the carton and place them individually on a soft cloth to prevent scratches or other damage.
Carefully and strictly follow these assembly instructions to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
A. Seat
E. Side Stretcher
F. Side Stretcher
Hardware List
B. Leg
G. Front Stretcher
C. Leg
D. Back Frame
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
M3x38 Wood Screw
6 pcs. (+1 extra)
M8x82 Head Cap Bolt (long)
2 pcs. (+1 extra)
Tool(s) required for assembly: Phillips screwdriver
Home Styles Customer Service: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com,
M8x38 Head Cap Bolt (short)
3 pcs. (+1 extra)
M8x51 Head Cap Bolt
4 pcs. (+1 extra)
888-680-7460, 877-831-0319
Flat Washer
9 pcs.(+1 extra)
Spring Washer
9 pcs.(+1 extra)
Assembly Instructions 2/3
IMPORTANT
Use a soft cloth between these parts and the floor.Do not use power tools above 8 volts to assemble.Do not tighten all the bolts until each part is properly assembled.Keep Hex Wrench in a safe place as the bolts may need to be tightened in the future.
Wood Screw
Arrow label at front
G
F
C
E
B
Head Cap Bolt Spring Washer
Flat Washer
A
STEP 1
Attach Legs (B) and (C) to Seat (A) with Flat Washers, Spring Washers and Head Cap Bolts, tightening bolts only halfway. (See Figure 1)
Attach Front Stretcher (G) to unit with Wood Screws. (See Figure 2)
Orientate Side Stretchers (E) and (F) so Arrow labels are at front of unit, then attach Side Stretcher (E) to Leg (B) and Side Stretcher (F) to Leg (C) with Wood Screws. (See Figure 3)
Figure 1 Figure 2 Figure 3
Flat Washer
Spring Washer
Head Cap Bolt (long)
Assembly Instructions 3/3
Wood Screw
D
Flat Washer
Spring Washer
STEP 2
Attach Back Frame (D) to unit with Flat Washers, Spring Washers, Head Cap Bolt (short), Head Cap Bolts (long) and Wood Screws, tightening bolts only halfway. (See Figures 4 and 5)
Tighten all Head Cap Bolts used in Steps 1 and 2.
Head Cap Bolt (short)
Figure 4 Figure 5
CARE INSTRUCTIONS
NEVER
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
Do not write
directly on surface.
PREVENT
MARKING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
CLEAN
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized retail affiliate, Home Styles is underno obligation to provide replacement parts. Parts are not available forfully assembled items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
www.homestyles-furniture.com/customer-service/replacement-parts
Home Styles Customer Service: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com,
888-680-7460, 877-831-0319
