Bar Stool
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
A.
Seat
1 pc.
G.
Front Frame
1 pc.
C.
Side Frame
1 pc.
E.
Rail
1 pc.
D.
Side Frame
1 pc.
F.
Rail
1 pc.
B.
Back Frame
1 pc.
Hardware List
Hex Wrench
1 pc.
Tool(s) required for assembly: Phillips screwdriver
Small Hex Wrench
1 pc.
Home Styles Customer Service: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com,
M6x13
Head Cap Bolt
12 pcs. (+1 extra)
Spring Washer
12 pcs. (+1 extra)
Flat Washer
12 pcs. (+1 extra)
888-680-7460, 877-831-0319
M3.5x16
Wood Screw
4 pcs. (+1 extra)
Assembly Instructions 2/2
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
Keep Hex Wrench as the bolts may need to be tightened in the future.
STEP 1
Attach Side Frames (C), (D) and
Rails (E), (F) to Back Frame (B) with
Flat Washers, Spring Washers and
Head Cap Bolts, tightening bolts
only halfway. (See Figure 1)
Note: Arrow label indicates back of
Rails (E) and (F).
Attach Front Frame (G) to unit with
Flat Washers, Spring Washers and
Head Cap Bolts, tightening bolts
only halfway.
Tighten all bolts used in this step.
Head Cap Bolt
Spring Washer
Flat Washer
Arrow label at back
E
G
C
D
B
F
A
Figure 1
STEP 2
Place Seat (A) upside down on a soft cloth.
Attach unit to Seat (A) with Wood Screws.
Turn unit over to it’s upright position.
Wood Screw
CARE INSTRUCTIONS
NEVER
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
Do not write
directly on surface.
PREVENT
MARKING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
CLEAN
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
