HomeMatic HmIP-HAP-UK Mounting Instruction And Operating Manual

Mounting instruction and operating manual

Access Point (UK)
HmIP-HAP-UK

2

Package contents

Quantity Description

1

Homematic IP Access Point (UK)

1 Plug-in mains adapter

1 Network cable

2 Screws

2 Plugs

1 Operating manual

Documentation © 2017 eQ-3 AG, Germany
All rights reserved. Translation from the original version in German. This manual may not be reproduced in any format, either in
whole or in part, nor may it be duplicated or edited by electronic, mechanical or chemical means, without the written consent of the
publisher.
Typographical and printing errors cannot be excluded. However, the information contained in this manual is reviewed on a regular
basis and any necessary corrections will be implemented in the next edition. We accept no liability for technical or typographical
errors or the consequences thereof.
All trademarks and industrial property rights are acknowledged.
Printed in Hong Kong
Changes may be made without prior notice as a result of technical advances.

151413
Version 1.0 // (01/2017)

3

Table of contents

1 Homematic IP - the next smart home generation ............................................................................................................4

2 Function and device overview ...............................................................................................................................................4

3 Information about this manual...............................................................................................................................................6

4 Hazard information ...................................................................................................................................................................6

5 Start-up .......................................................................................................................................................................................7

5.1 Set-up and mounting ......................................................................................................................................................................................7

5.2 First steps: Teaching-in devices and adding rooms ................................................................................................................................. 9

5.3 Operation and configuration ........................................................................................................................................................................ 9

6 Troubleshooting ......................................................................................................................................................................10

6.1 Command not confirmed ............................................................................................................................................................................ 10

6.2 Duty cycle ....................................................................................................................................................................................................... 10

6.3 Error codes and flashing sequences ......................................................................................................................................................... 10

7 Restore factory settings ......................................................................................................................................................... 11

8 Maintenance and cleaning ....................................................................................................................................................12

9 General information about radio operation ......................................................................................................................12

10 Technical specifications .........................................................................................................................................................13

Homematic IP - the next smart home generation

4

2 Function and device overview

The Homematic IP Access Point is the central unit of
the system.
The Access Point connects the smartphone via the
Homematic IP cloud with all Homematic IP devices
and transmits the configuration data and control
commands of the app to all Homematic IP devices.
With Homematic IP, you can simply adjust your smart
home solution to your personal needs at any time and
place.

1 Homematic IP -

the next smart home generation

With Homematic IP, you can install your smart home
solution in just a few little steps.
The Homematic IP Access Point is the central unit of
the Homematic IP system and communicates via the
Homematic IP radio protocol. All devices of the system
can be configured comfortably and individually with a
smartphone via the Homematic IP app. The available
functions provided by the Homematic IP system in
combination with other components are described in
the Homematic IP User Guide. All current technical
documents and updates are provided at www.eQ-3.de.

Function and device overview

5

Back

B

E

D

C

(B) QR code and device number (SGTIN)
(C) Screw holes
(D) Interface: Network cable
(E) Interface: Plug-in mains adapter

Device overview

Front

A

(A) System button and LED
