Homelite UT42100 User Manual
OPERATOR’S MANUAL
MANUEL D’UTILISATION
MANUAL DEL OPERADOR
ELECTRIC BLOWER
SOUFFLANTE ÉLECTRIQUE
SOPLADORA ELÉCTRICA
UT42100
(ALL VERSIONS /
TOUTES LES VERSIONS /
TODAS LAS VERSIONES)
Your blower has been engineered and manufactured to Homelite’s high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before
using this product.
Thank you for buying a Homelite product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Cette soufflante a été conçue et fabriquée conformément aux strictes
normes de fiabilité, simplicité d’emploi et sécurité d’utilisation de
Homelite. Correctement entretenue, elle vous donnera des années
de fonctionnement robuste et sans problème.
AVERTISSEMENT : Pour réduire les risques de
blessures, l’utilisateur doit lire et veiller à bien comprendre le
manuel d’utilisation avant d’employer ce produit.
Merci d’avoir acheté un produit Homelite.
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE
Su sopladora ha sido diseñada y fabricada de conformidad con
las estrictas normas de Homelite para brindar fiabilidad, facilidad
de uso y seguridad para el operador. Con el debido cuidado, le
brindará muchos años de sólido y eficiente funcionamiento.
ADVERTENCIA: Para reducir el riesgo de lesiones,
el usuario debe leer y comprender el manual del operador antes
de usar este producto.
Le agradecemos la compra de un producto Homelite.
GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS
Fig. 1
See this fold-out section for all the figures
referenced in the operator’s manual.
Voir que cette section d’encart pour toutes les figures
a adressé dans le manuel d’utilisation.
Vea esta sección de la página desplegable para todas las figuras
mencionó en el manual del operador.
A
D
B
A - Two-speed switch (interrupteur de deux vitesses, interruptor de dos velocidades)
B - Blower tube (tube de soufflante, tubo de sopladora)
C - Cord retainer (retenue de cordon, retén para el cordón)
D - Plug (fiche, clavija)
C
ii
OFF
LOW
HIGH
Fig. 2
Fig. 4
A
B
C
D
A - Notched area (zone striée, área estriada)
B - Slot (fente, ranura)
C - Blower tube (tube de soufflante, tubo de sopladora)
D - Air outlet (sortie d’air, toma de aire)
Fig. 3
A
A - Two-speed switch (interrupteur de deux vitesses, interruptor de dos
velocidades)
Fig. 5
B
A
A - Cord retainer (retenue de cordon, retén para el cordón)
B - Loop (boucle, argolla)
C - Plug (fiche, clavija)
D - Extension cord (rallonge, cordón de extensión)
C
D
iii
TABLE OF CONTENTS
TABLE DES MATIÈRES / ÍNDICE DE CONTENIDO
Introduction ......................................................................................................................................................................2
Introduction / Introducción
Important Safety Instructions ......................................................................................................................................3 - 4
Instructions importantes concernant la sécurité / Instrucciones de seguridad importantes
Specific Safety Rules ........................................................................................................................................................4
Règles de sécurité particulières / Reglas de seguridad específicas
Symbols ............................................................................................................................................................................ 5
Symboles / Símbolos
Electrical ........................................................................................................................................................................... 6
Caractéristiques électriques / Aspectos eléctricos
Features ............................................................................................................................................................................ 7
Caractéristiques / Características
Assembly .......................................................................................................................................................................... 7
Assemblage / Armado
Operation .......................................................................................................................................................................... 8
Utilisation / Funcionamiento
Maintenance ..................................................................................................................................................................... 9
Entretien/ Mantenimiento
Troubleshooting ................................................................................................................................................................ 9
Dépannage / Corrección de problemas
Warranty .........................................................................................................................................................................10
Garantie/Garantía
Parts Ordering and Service ...............................................................................................................................Back Page
Commande de pièces et réparation / Pedidos de piezas y servicio ......................................................... Page arrière / Pág. posterior
INTRODUCTION
INTRODUCTION / INTRODUCCIÓN
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
* * *
Ce produit offre de nombreuses fonctions destinées à rendre son utilisation plus plaisante et satisfaisante. Lors de la
conception de ce produit, l’accent a été mis sur la sécurité, les performances et la fiabilité, afin d’en faire un outil facile à
utiliser et à entretenir.
* * *
Este producto ofrece numerosas características para hacer más agradable y placentero su uso. En el diseño de este producto
se ha conferido prioridad a la seguridad, el desempeño y la fiabilidad, por lo cual se facilita su manejo y mantenimiento.
Page 2 – English
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
READ AND UNDERSTAND ALL INSTRUCTIONS. Fail-
ure to follow all instructions listed below may result in
electric shock, fire, and/or serious personal injury.
READ THESE INSTRUCTIONS BEFORE USING
THIS BLOWER
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases, or
dust. Power tools create sparks which may ignite the dust
or fumes.
To reduce the risk of electric shock, this tool has a polarized plug (one blade is wider than the other) and will require
the use of a polarized extension cord. The plug will fit into
a polarized extension cord only one way. If the plug does
not fit fully into the extension cord, reverse the plug. If the
plug still does not fit, obtain a correct polarized extension
cord. A polarized extension cord will require the use of a
polarized wall outlet. This plug will fit into the polarized
wall outlet only one way. If the plug does not fit fully into
the wall outlet, reverse the plug. If the plug still does not
fit, contact a qualified electrician to install the proper wall
outlet. Do not change the equipment plug, extension cord
receptacle, or extension cord plug in any way.
Avoid body contact with grounded surfaces such as
radiators, ranges, and refrigerators. There is an increased
risk of electric shock if your body is grounded.
Don’t expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
Do not handle plug or tool with wet hands.
Use outdoor extension cords marked W-A, W,
SOW-A, STW-A, STOW-A, SJW-A, SJTW-A, or SJTOW-A.
These cords are rated for outdoor use and reduce the risk
of electric shock.
Never allow children to operate the equipment. Never
allow adults to operate the equipment without proper
instruction.
Wear eye protection with side shields which is marked
to comply with ANSI Z87.1 as well as hearing protection
when operating this product.
Always use face or dust mask if operation is dusty.
Use extra care when cleaning on stairs.
Do not leave appliance plugged in. Unplug from outlet
when not in use and before servicing.
Do not expose to rain, store indoors.
Use only as described in this manual. Use only manufac-
turer’s recommended attachments.
Keep hair, loose clothing, fingers and all body parts away
from openings and moving parts.
To reduce the risk of electric shock, this appliance has a
pipes,
SW-A,
Page 3 – English
polarized plug (one blade is wider than the other). This
plug will fit in a polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician to install the
proper outlet. Do not change the plug in any way.
Wear heavy long pants, long sleeves, boots, and gloves.
Avoid loose garments or jewelry that could get caught in
moving parts of the machine or its motor.
Do not force tool. Use the correct tool for your
application. The correct tool will do the job better and
safer at the rate for which it is designed.
Do not operate the equipment while barefoot or when
wearing sandals or similar lightweight footwear. Wear
protective footwear that will protect your feet and improve
your footing on slippery surfaces.
Do not use on steps, a ladder, roof top, tree, or other un-
stable support. Stable footing on a solid surface enables
better control of the blower in unexpected situations.
Secure long hair so it is above shoulder level to prevent
entanglement in any moving parts.
Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance.
Turn off all controls before unplugging.
Do not allow to be used as a toy. Close attention is nec-
essary when used by or near children.
Avoid accidental starting. Be sure the power switch is
not on before plugging in. Turn off power switch before
unplugging.
Do not use tool if switch does not turn it on or off. Any
tool that cannot be controlled with the switch is dangerous and must be repaired.
Do not use with damaged plug. If tool is not working as
it should or has been dropped, damaged, left outdoors,
or dropped into water, return it to an authorized service
center.
Do not leave the tool when plugged in. Unplug from
the power outlet when not in use, before servicing, and
before storing the tool. Such preventative safety measures
reduce the risk of starting the tool accidentally.
Keep all bystanders, children, and pets at least 50 ft.
away.
Do not operate this unit when you are tired, ill, upset or
under the influence of alcohol, drugs, or medication.
Do not operate in poor lighting.
Keep all parts of your body away from any moving parts
and all hot surfaces of the unit.
Do not put any object into openings. Do not use with any
opening blocked; keep openings free of dust, lint, hair,
and anything that may reduce air flow.
Check the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string which
can be thrown or become entangled in the machine.
Never use blower near fires, fireplaces, hot ashes, bar-
becue pits, etc., which may cause fire to spread.
IMPORTANT SAFETY INSTRUCTIONS
Do not pull or carry by cord, use cord as a handle, close
a door on a cord, or pull cord around sharp edges or
corners. Do not run appliance over cord. Keep cord away
from heated surfaces.
Do not unplug by pulling on cord. To unplug, grasp the
plug, not the cord.
Do not handle plug or appliance with wet hands.
Do not put any object into openings. Do not use with any
opening blocked; keep free of dust, lint, hair, and anything
that may reduce air flow.
Use only identical manufacturer’s replacement parts and
accessories. Use of any other parts may create a hazard
or cause product damage.
SPECIFIC SAFETY RULES
Make sure your extension cord is in good condition.
When using an extension cord, be sure to use one heavy
enough to carry the current your product will draw. A wire
gauge size (A.W.G.) of at least 14 is recommended for an
extension cord 50 feet or less in length. If in doubt, use the
next heavier gauge. The smaller the gauge number, the
heavier the cord. An undersized cord will cause a drop in
line voltage resulting in loss of power and overheating.
Do not point the blower nozzle in the direction of people
or pets.
Never place blower on any surface, except a hard, clean
surface when motor is running. Gravel, sand, and other
debris can be picked up by the air inlet and thrown at
the operator or bystanders, causing possible serious
injuries.
Never run the unit without the proper equipment attached.
Always ensure the blower tubes are installed.
When not in use, blower should be stored indoors in a
dry, locked up place—out of the reach of children.
Maintain tool with care. Keep fan area clean for best
and safest performance. Follow instructions for proper
maintenance.
Do not use with damaged cord or plug. If appliance is
not working as it should, has been dropped, damaged,
left outdoors, or dropped into water, return it to a service
center.
In a double insulated appliance, two systems of insulation
are provided instead of grounding. No grounding means
is provided on a double insulated appliance, nor should
a means for grounding be added to the appliance.
Servicing a double insulated appliance requires extreme
care and knowledge of the system and should be done
only by qualified service personnel. Replacement parts
for a double insulated appliance must be identical to the
parts they replace.
For household use only.
Do not attempt to clear clogs from tool without first
unplugging it.
Do not pull or carry by cord, use cord as a handle, or pull
cord around sharp edges or corners. Keep cord away
from heated surfaces.
Do not unplug by pulling on cord. To unplug, grasp the
plug, not the cord.
To reduce the risk of electrical shock, do not expose to
rain, do not use on wet surfaces. Store indoors.
If the power supply cord is damaged, it must be replaced
only by the manufacturer or by an authorized service
center to avoid risk.
Protect your lungs. Wear a face or dust mask if the
operation is dusty. Following this rule will reduce the risk
of serious personal injury.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this power tool.
If you loan someone this power tool, loan them these
instructions also.
SAVE THESE INSTRUCTIONS
Page 4 – English
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER:
WARNING:
CAUTION:
CAUTION:
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME
Safety Alert Indicates a potential personal injury hazard.
Read The Operator’s Manual
Eye and Hearing Protection
Indicates an imminently hazardous situation, which, if not avoided, will result
in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, could result
in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
(Without Safety Alert Symbol) Indicates a situation that may result in property
damage.
DESIGNATION/EXPLANATION
To reduce the risk of injury, user must read and understand
operator’s manual before using this product.
Always wear eye protection with side shields marked to comply
with ANSI Z87.1, along with hearing protection.
Wet Conditions Alert Do not expose to rain or use in damp locations.
Keep Bystanders Away Keep all bystanders at least 50 ft. away.
Long Hair
Blower Tubes Do not operate without tubes in place.
Loose Clothing
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
min Minutes Time
Alternating Current Type of current
Direct Current Type or a characteristic of current
Failure to keep long hair away from the air inlet could result in
personal injury.
Failure to keep loose clothing from being drawn into air intake
could result in personal injury.
Class II Construction Double-insulated construction
Page 5 – English
ELECTRICAL
DOUBLE INSULATION
Double insulation is a concept in safety in electric power
tools, which eliminates the need for the usual threewire grounded power cord. All exposed metal parts are
isolated from the internal metal motor components with
protecting insulation. Double insulated tools do not need
to be grounded.
WARNING:
The double insulated system is intended to protect
the user from shock resulting from a break in the tool’s
internal insulation. Observe all normal safety precautions
to avoid electrical shock.
NOTE: Servicing of a product with double insulation requires
extreme care and knowledge of the system and should be
performed only by a qualified service technician. For service,
we suggest you return the tool to your nearest authorized
service center for repair. Always use original factory replacement parts when servicing.
ELECTRICAL CONNECTION
This product has a precision-built electric motor. It should
be connected to a power supply that is 120 volts, AC only
(normal household current), 60 Hz. Do not operate this
product on direct current (DC). A substantial voltage drop
will cause a loss of power and the motor will overheat. If
your product does not operate when plugged into an outlet,
double-check the power supply.
GFCI
Ground Fault Circuit Interrupter (GFCI) protection should be
provided on the circuit(s) or outlet(s) to be used for the product. Receptacles are available having built-in GFCI protection
and may be used for this measure of safety.
EXTENSION CORDS
When using a power product at a considerable distance from
a power source, be sure to use an extension cord that has
the capacity to handle the current the product will draw. An
undersized cord will cause a drop in line voltage, resulting in
overheating and loss of power. Use the chart to determine
the minimum wire size required in an extension cord. Only
round jacketed cords listed by Underwriter’s Laboratories
(UL) should be used.
When working outdoors with a product, use an extension
cord that is designed for outside use. This type of cord is
designated with “W-A” or “W” on the cord’s jacket.
Before using any extension cord, inspect it for loose or
exposed wires and cut or worn insulation.
**Ampere rating (on product data plate)
0-2.0 2.1-3.4 3.5-5.0 5.1-7.0 7.1-12.0 12.1-16.0
Cord Length Wire Size (A.W.G.)
25´ 16 16 16 16 14 14
50´ 16 16 16 14 14 12
100´ 16 16 14 12 10 —
**Used on 12 gauge - 20 amp circuit.
NOTE: AWG = American Wire Gauge
WARNING:
Keep the extension cord clear of the working area.
Position the cord so that it will not get caught on lumber,
tools, or other obstructions while you are working with
a power tool. Failure to do so can result in serious personal injury.
WARNING:
Check extension cords before each use. If damaged
replace immediately. Never use product with a damaged
cord since touching the damaged area could cause electrical shock resulting in serious injury.
Page 6 – English
FEATURES
PRODUCT SPECIFICATIONS
Weight .........................................................................................................................................................................4.9 lbs.
Input ..............................................................................................................................................120 V, AC only, 60 Hz, 7 A
Air Velocity:
MPH ...............................................................................................................................................................................150
KNOW YOUR BLOWER
See Figure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
ASSEMBLY
UNPACKING
This product requires assembly.
Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
WARNING:
Do not use this product if any parts on the Packing List
are already assembled to your product when you unpack
it. Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the product.
If any parts are damaged or missing, please call
1-800-242-4672 for assistance.
BLOWER TUBE
The blower tube can be easily installed on the blower without
any additional tools.
CORD RETAINER
A convenient cord retainer helps keep the extension cord
connection secure during blower operation.
TWO-SPEED
The two-speed switch is designed for LOW or HI speeds.
WARNING:
If any parts are damaged or missing do not operate this
product until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
WARNING:
Do not attempt to modify this product or create accessories not recommended for use with this product. Any
such alteration or modification is misuse and could result
in a hazardous condition leading to possible serious
personal injury.
WARNING:
Do not connect to power supply until assembly is complete. Failure to comply could result in accidental starting
and possible serious personal injury.
PACKING LIST
Blower
Blower Tube
Operator’s Manual
ASSEMBLING THE BLOWER TUBE
See Figure 2.
Slide blower tube forward until the notched areas on the
blower housing click into the slots on the tube.
Page 7 – English
Loading...
