OPERATOR’S MANUAL
YARD BROOM II
UT08514
Your blower has been engineered and manufactured to our high standard for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
TABLE OF CONTENTS
Introduction ..................................................................................................................................................................... 2
� General Safety Rules ....................................................................................................................................................... 3
� Specific Safety Rules ....................................................................................................................................................... 3
� Symbols ........................................................................................................................................................................4-5
�� Features ........................................................................................................................................................................6-7
�� Assembly ......................................................................................................................................................................7-8
� Operation ....................................................................................................................................................................9-11
� Maintenance ............................................................................................................................................................. 12-13
Accessories ................................................................................................................................................................... 13
� Troubleshooting ............................................................................................................................................................. 14
Warranty ...................................................................................................................................................................15-17
Parts Ordering / Service ................................................................................................................................................ 18
INTRODUCTION
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
Page 2
GENERAL SAFETY RULES
WARNING:
READ AND UNDERSTAND ALL INSTRUCTIONS. Fail-
ure to follow all instructions listed below, may result in
electric shock, fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
Do not allow children or untrained individuals to use this
unit.
Never start or run the engine inside a closed area; breath-
ing exhaust fumes can kill.
� Wear eye protection which is marked to comply with ANSI
Z87.1 as well as hearing protection when operating this
product.
Keep all bystanders, children, and pets at least 50 ft.
away.
Wear heavy long pants, boots, and gloves. Do not wear
loose fitting clothing, short pants, jewelry of any kind, or
go barefoot.
To reduce the risk of injury associated with objects being
drawn into rotating parts, do not wear loose clothing,
scarves, neck chains, and the like.
� Secure long hair so it is above shoulder level to prevent
entanglement in any rotating parts.
� Do not operate this unit when you are tired, ill, or under
the influence of alcohol, drugs, or medication.
Do not operate in poor lighting.
Keep all parts of your body away from any moving parts
and all hot surfaces of the unit.
Wear a face filter mask in dusty conditions to reduce the
risk of injury associated with the inhalation of dust.
Check the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string which
can be thrown or become entangled in the machine.
Keep firm footing and balance. Do not overreach. Over-
reaching can result in loss of balance or exposure to hot
surfaces.
Never operate the unit without a spark arrestor screen;
this screen is located inside the muffler.
Product users on United States Forest Service land, and
in some states, must comply with fire prevention regulations.
This product is equipped with a spark arrestor; however,
other user requirements may apply. Check with the fed-
eral, state, or local authorities in your area.
Before storing, allow the engine to cool.
� Empty fuel tank and restrain the unit from moving before
transporting in a vehicle.
To reduce the risk of fire and burn injury, handle fuel with
care. It is highly flammable.
Do not smoke while handling fuel.
Mix and store fuel in a container approved for gasoline.
Mix fuel outdoors where there are no sparks or flames.
Select bare ground, stop engine, and allow to cool before
refueling.
� Loosen fuel cap slowly to release pressure and to keep
fuel from escaping around the cap.
Tighten the fuel cap securely after refueling.
Wipe spilled fuel from the unit. Move 30 ft. away from
refueling site before starting engine.
Never attempt to burn off spilled fuel under any circum-
stances.
Use only identical manufacturer’s replacement parts and
accessories. Use of any other parts may create a hazard
or cause product damage.
Maintain the unit per maintenance instructions in this
Operator’s Manual.
Inspect the unit before each use for loose fasteners, fuel
leaks, etc. Replace damaged parts.
SPECIFIC SAFETY RULES
Always hold the control handle in your right hand. Refer
to the Operation section later in this manual for additional
instructions.
To reduce the risk of hearing loss associated with sound
level(s), hearing protection is required.
To reduce the risk of injury associated with contact-
ing rotating parts, stop the engine before installing or
Page 3
removing attachments. Always disconnect the spark plug
before performing maintenance or accessing any movable
parts.
Do not point the blower nozzle in the direction of people
or pets.
� Never run the unit without the proper equipment attached.
Always ensure the blower tubes are installed.
SYMBOLS
Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert
Read The Operator’s Manual
Eye and Hearing Protection
Long Hair
Blower Tubes
Vacuum Door
Loose Clothing
Gasoline and Oil
Precautions that involve your safety.
To reduce the risk of injury, user must read and understand
operator’s manual before using this product.
Wear eye and hearing protection when operating this equipment.
Failure to keep long hair away from the air inlet could result in
personal injury.
Do not operate without tubes in place.
Do not run unit while vacuum door is unsecured.
Failure to keep loose clothing from being drawn into air intake
could result in personal injury.
Use unleaded gasoline intended for motor vehicle use with an
octane rating of 87 [(R + M)/2] or higher. This product is powered
by a 2-cycle engine and requires pre-mixing gasoline and 2-cycle
oil.
Page 4
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may
result in minor or moderate injury.
CAUTION: (Without Safety Alert Symbol) Indicates a situation that may result in
property damage.
SERVICE
Servicing requires extreme care and knowledge and should
be performed only by a qualified service technician. For
service we suggest you return the product to your nearest
AUTHORIZED SERVICE CENTER for repair. When servicing,
use only identical replacement parts.
WARNING:
To avoid serious personal injury, do not attempt to use this
product until you read thoroughly and understand completely the operator’s manual. If you do not understand
the warnings and instructions in the operator’s manual,
do not use this product. Call Homelite customer service
for assistance.
WARNING:
The operation of any power tool can result in foreign objects being thrown into your eyes, which can
result in severe eye damage. Before beginning power tool operation, always wear safety goggles or
safety glasses with side shields and, when needed, a full face shield. We recommend Wide Vision
Safety Mask for use over eyeglasses or standard safety glasses with side shields. Always use eye
protection which is marked to comply with ANSI Z87.1.
SAVE THESE INSTRUCTIONS
Page 5
FEATURES
PRODUCT SPECIFICATIONS
Weight .........................................................................................................................................................................9.7 lbs.
Engine displacement .......................................................................................................................................................30cc
Air Velocity:
MPH ...............................................................................................................................................................................170
CFM ...............................................................................................................................................................................375
ENGINE
SWITCH
STARTER GRIP
PRIMER BULB
CHOKE LEVER
CRUISE CONTROL
(THROTTLE LOCK)
THROTTLE TRIGGER
HANDLE
TUBE CLAMP
WIDE SWEEPER
NOZZLE
BLOWER TUBE
Fig. 1
Page 6
FEATURES
KNOW YOUR BLOWER
See Figure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
BLOWER TUBE AND NOZZLE
The blower tube and nozzle can be assembled and installed
on the blower using no tools.
CRUISE CONTROL (THROTTLE LOCK)
The cruise control (throttle lock) feature allows you to operate the blower without continuously holding the throttle
trigger.
ASSEMBLY
UNPACKING
This product requires assembly.
Carefully remove the tool and any accessories from the
box. Make sure that all items listed in the packing list are
included.
Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.
Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the tool.
If any parts are damaged or missing, please call
1-800-242-4672 for assistance.
PACKING LIST
Blower
Blower Tube
Wide Sweeper Nozzle
Tube Clamp
2-Cycle Engine Oil
Operator’s Manual
MOTOR
The blower has a powerful 30cc engine with sufficient power
to handle tough jobs.
THROTTLE TRIGGER
The blower can be operated at any speed between idle and
full throttle.
WIDE SWEEPER NOZZLE
The wide sweeper nozzle allows for more area to be covered
during blower operation.
WARNING:
If any parts are damaged or missing, do not operate
this tool until the parts are replaced. Failure to heed this
warning could result in serious personal injury.
WARNING:
Do not attempt to modify this tool or create accessories not recommended for use with this tool. Any such
alteration or modification is misuse and could result in a
hazardous condition leading to possible serious personal
injury.
NOTE: Read and remove all hang tags and store with your
Operator’s Manual.
Page 7
ASSEMBLY
WARNING:
Stop the engine and disconnect the spark plug wire
before installing parts, making adjustments, cleaning, or
when not in use. Failure to do so could result in possible
serious personal injury.
ASSEMBLING THE BLOWER TUBES
See Figure 2.
� Screw the nozzle onto the blower tube and tighten
securely. Check tightness after initial run and retighten if
needed.
Place clamp around the neck of the blower housing outlet.
Do not tighten the knob yet.
Align the locking tab on blower tube with the slot in the
blower housing outlet; push the tube into the housing.
Twist to lock into place.
Rotate the tube so the nozzle is pointing upward as
shown. Tighten the knob securely.
To remove the tubes, loosen the knob on the clamp.
Rotate the tubes to unlock them and remove from the
blower housing outlet.
NOZZLE
BLOWER
TUBE
KNOB
Fig. 2
Page 8
WARNING:
OPERATION
FILLING THE TANK
Do not allow familiarity with tools to make you careless. Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING:
Always wear safety goggles or safety glasses with
side shields when operating this tool. Failure to do
so could result in objects being thrown into your eyes
resulting in possible serious injury.
APPLICATIONS
You may use this tool for the purposes listed below:
Clearing leaves and other debris from your lawn
Keeping decks and driveways free from leaves and pine
needles
MIXING THE FUEL
This product is powered by a 2-cycle engine and requires
premixing gasoline and 2-cycle oil. The mixture should be at
a 50:1 ratio, using Premium Exact Mix™ 2-cycle engine oil.
If Premium Exact Mix™ 2-cycle engine oil is not available,
use a high quality 2-cycle engine oil, mixed at a 50:1 ratio.
See chart later in this section.
TO MIX THE FUEL:
� Use a clean container that is approved for use with
gasoline.
� Mix the Premium Exact Mix™ 2-cycle engine oil with
unleaded gasoline in the container, according to the
instructions on the oil package.
This engine is certified to operate on unleaded gasoline
intended for automotive use with an octane rating of 87
([R + M] / 2) or higher. Do not use automotive oil or 2-cycle
outboard oil.
NOTE: Premium Exact Mix™ fuel mixture will stay fresh up
to 30 days. DO NOT mix quantities larger than usable in a
30 day period.
WARNING:
Gasoline is extremely flammable and explosive. A fire or
explosion from gasoline will burn you and others. Always
stop the engine before filling the fuel tank. Never add fuel
to a machine with a running or hot engine. Move at least
30 ft. from the refueling area before starting engine. Do
not smoke while filling the tank.
Clean the surface around the fuel cap to prevent con-
tamination.
Loosen the fuel cap slowly by turning counterclock-
wise.
Pour the fuel mixture carefully into the tank.
� Clean and inspect the fuel cap gasket before replacing
the fuel cap.
� Replace the fuel cap and tighten it by turning it clock-
wise.
� Wipe spilled fuel from the product.
�� Move at least 30 ft. away from refueling area before start-
ing the product.
NOTE: It is normal for smoke to be emitted from a new
engine during first use.
WARNING:
Check for fuel leaks. A leaking fuel cap is a fire hazard
and must be replaced immediately. If you find any leaks,
correct the problem before using the product. Failure
to do so could result in a fire that could cause serious
personal injury.
PREMIUM EXACT MIX™ (50:1)
GASOLINE OIL
1 Gallon (US) 2.6 oz.
1 Liter 20 cc (20 ml)
Page 9
OPERATION
STARTING AND STOPPING
See Figures 3 - 4.
Starting the product differs depending on whether the engine
is cold or warm.
To start a cold engine:
Set switch to ON.
Push the primer bulb, slowly, 8 times.
Set the choke lever to FULL.
Squeeze throttle trigger fully (thru next 2 steps) and pull
starter handle sharply (no more than 4 times).
Set the choke lever to HALF.
Pull the starter rope until the engine runs (no more than
6 times).
Set the choke lever to RUN.
To start a warm engine:
Set the choke lever to RUN.
Pull the starter rope until the engine runs.
To stop:
Release the throttle trigger and push STOP on the engine
switch.
THROTTLE
TRIGGER
PRIMER
BULB
CHOKE
LEVER
TO STOP, PUSH
“STOP” ON
ENGINE SWITCH
Fig. 3
WARNING:
Keep away from all hot surfaces of the blower. Failure to
do so could result in possible serious personal injury.
OPERATING THE BLOWER
See Figures 5 - 6.
�WARNING:
Always hold the blower away from your body, keeping
clearance between your body and the product. Any contact with the housing can result in burns and/or other
serious personal injury.
Hold the blower with the handle in your right hand.
To keep from scattering debris, blow around the outer
edges of a debris pile. Never blow directly into the center
of a pile.
Operate power equipment at reasonable hours only
— not early in the morning or late at night when people
might be disturbed. Comply with the times listed in local
ordinances.
� To reduce sound levels, limit the number of pieces of
equipment used at any one time.
�� Operate blower at the lowest possible throttle speed to
do the job.
Fig. 4
PROPER OPERATING
POSITION
Page 10
Fig. 5
OPERATION
�� Check your equipment before operation, especially the
muffler, air intakes, and air filters.
�� Use rakes and brooms to loosen debris before blowing.
� In dusty conditions, slightly dampen surfaces when water
is available.
��� Watch out for children, pets, open windows or freshly
washed cars, and blow debris safely away.
� Use the full blower nozzle extension so the air stream can
work close to the ground.
� After using blowers or other equipment, CLEAN UP!
Dispose of debris in trash receptacles.
� The wide sweeper nozzle allows for large areas to be
covered during blowing operation.
CRUISE CONTROL (THROTTLE LOCK)
See Figure 7.
The cruise control (throttle lock) can be used to operate the
blower without continuously holding the throttle trigger.
To engage the cruise control:
� For full throttle, depress the throttle trigger fully and slide
the cruise control selector as far forward as possible.
To reduce engine speed, slide the cruise control selector
toward the back of the blower until the desired speed is
reached.
To release the cruise control, return the cruise control
selector to the off position.
WIDE SWEEPER
NOZZLE
Fig. 6
THROTTLE TRIGGER
CRUISE CONTROL
(THROTTLE LOCK)
Page 11
Fig. 7
MAINTENANCE
WARNING:
When servicing, use only identical replacement parts.
Use of any other parts may create a hazard or cause
product damage.
WARNING:
Always wear safety goggles or safety glasses with side
shields during power tool operation or when blowing
dust. If operation is dusty, also wear a dust mask.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use
clean cloths to remove dirt, dust, oil, grease, etc.
WARNING:
REPLACING AND CLEANING THE AIR FILTER
See Figure 8.
For proper performance and long life, keep air filter clean.
Loosen the knob on the air filter cover.
Remove the cover.
Remove the air filter and clean it in warm soapy water.
Rinse and let dry completely.
Work two drops of oil into the air filter.
Reinstall the air filter into the air filter base.
Reinstall the cover.
Tighten knob to secure.
NOTE: For best performance, the air filter should be
replaced annually.
BASE
AIR FILTER
COVER
Do not at any time let brake fluids, gasoline, petroleumbased products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic which may result in serious personal
injury.
LUBRICATION
All of the bearings in this tool are lubricated with a sufficient
amount of high grade lubricant for the life of the unit under
normal operating conditions. Therefore, no further lubrication
is required.
KNOB
AIR FILTER
Fig. 8
Page 12
MAINTENANCE
SPARK ARRESTOR
The muffler is equipped with a spark arrestor screen inside
muffler body. After extended use the screen can become
dirty and you may need to have the muffler replaced by an
authorized servicing dealer.
WARNING:
Never run the blower without the spark arrestor in place.
Failure to do so could result in a fire that could cause
serious personal injury.
CLEANING THE EXHAUST PORT AND
MUFFLER
Depending on the type of fuel used, the type and amount
of oil used, and/or your operating conditions, the exhaust
port and muffler may become blocked with carbon deposits.
If you notice low power from the blower, have a qualified
service technician check the exhaust port and muffler for
carbon deposits. Removing the carbon deposits should
restore performance to the blower.
FUEL CAP
WARNING:
A leaking fuel cap is a fire hazard and must be replaced
immediately. Failure to do so could result in a fire that
could cause serious personal injury.
The fuel cap contains a non-serviceable filter and a check
valve. A clogged fuel filter will cause poor engine performance.
If performance improves when the fuel cap is loosened, the
check valve may be faulty or filter clogged. Replace the fuel
cap if required.
SPARK PLUG
This engine uses a Champion RCJ-6Y with 0.63 mm (0.025
in.) electrode gap. Use an exact replacement and replace
annually.
WARNING:
Be careful not to cross-thread the spark plug. Crossthreading will seriously damage the product.
STORAGE (1 MONTH OR LONGER)
� Drain all fuel from the tank into a container approved for
gasoline. Run engine until it stops.
� Clean all foreign material from the blower. Store it in a
well-ventilated place that is inaccessible to children. Keep
away from corrosive agents such as garden chemicals
and de-icing salts.
� Abide by all Federal and local regulations for the safe
storage and handling of gasoline. Excess fuel should be
used up in other 2-cycle engine powered equipment.
ACCESSORIES
The following recommended accessories are currently available at retail stores.
Air Filter (Power Care) ............................................................................................................................................... AP04107
Spark Plug (Champion) .............................................................................................................................................. RCJ-6Y
2-Cycle Oil (Homelite) .............................................................................................................................................. AH99G01
Fuel Cap (Power Care) ............................................................................................................................................. AP04108
WARNING:
Current attachments and accessories available for use with this product are listed above. Do not use any attachments or
accessories not recommended by the manufacturer of this product. The use of attachments or accessories not recommended can result in serious personal injury.
Page 13
TROUBLESHOOTING
IF THESE SOLUTIONS DO NOT SOLVE THE PROBLEM CONTACT YOUR AUTHORIZED SERVICE DEALER.
PROBLEM POSSIBLE CAUSE SOLUTION
Engine will not start
Engine does not reach full
speed and emits excessive
smoke
Engine starts, runs, and
accelerates but will not idle
1. No spark.
2. No fuel.
3. Engine is flooded.
1. Incorrect oil/fuel mixture.
2. Air filter is dirty.
3. Spark arrestor screen is dirty.
4. Spark plug fouled.
1. Idle speed screw on carburetor
needs adjustment.
1. Check spark. Remove spark plug. Reattach
the spark plug cap and lay spark plug on metal
cylinder. Pull the rope and watch for spark at
spark plug tip. If there is no spark, repeat test
with a new spark plug.
2. Push primer bulb until bulb is full of fuel. If bulb
does not fill, primary fuel delivery system is
blocked. Contact a service dealer. If primer bulb
fills, engine may be flooded, proceed to next
item.
3. Set the start lever to the FULL position. Squeeze
the trigger and pull the rope repeatedly until the
engine starts and runs.
NOTE: Depending on the severity of the flooding,
this may require numerous pulls of the rope.
1. Use fresh fuel and the correct 2-cycle oil mix.
(50:1).
2. Clean air filter. Refer to Replacing and Cleaning
Air Filter
3. Contact a servicing dealer.
4. Clean or replace spark plug. Reset spark plug
gap. Refer to Spark Plug Replacement.
1. Turn idle speed screw clockwise to increase idle
speed. See Figure 9.
.
Page 14
Fig. 9
WARRANTY
LIMITED WARRANTY STATEMENT
Homelite Consumer Products, Inc., (“Homelite”) warrants
to the original retail purchaser that this HOMELITE brand
outdoor product is free from defect in material and
workmanship and agrees to repair or replace, at Homelite’s,
discretion, any defective product free of charge within these
time periods from the date of purchase.
� One year for the following units: all Yard Broom, Trimlite,
and Bandit models;
� Two years if the product is used for personal, family or
household use;
� 90 days if used for any other purpose, such as
commercial or rental.
This warranty extends to the original retail purchaser
only and commences on the date of the original retail
purchase.
Any part of the this product manufactured or supplied
by Homelite and found in the reasonable judgment of
Homelite to be defective in material or workmanship will
be repaired or replaced without charge for parts and labor
by a Homelite authorized service center.
The product, including any defective part, must be returned
to an authorized service dealer within the warranty period.
The expense of delivering the product to the dealer for
warranty work and the expense of returning it back to the
owner after repair or replacement will be paid by the owner.
Homelite’s responsibility in respect to claims is limited to
making the required repairs or replacements and no claim
of breach of warranty shall be cause for cancellation or
rescission of the contract of sale of any HOMELITE brand
product. Proof of purchase will be required by the dealer
to substantiate any warranty claim. All warranty work must
be performed by a Homelite authorized service center.
This warranty is limited to ninety (90) days from the date of
original retail purchase for any HOMELITE brand product
that is used for rental or commercial purposes, or any other
income-producing purpose.
This warranty does not cover any HOMELITE brand product
that has been subject to misuse, neglect, negligence, or
accident, or that has been operated in any way contrary
to the operating instructions as specified in this operator’s
manual. This warranty does not apply to any damage to
the product that is the result of improper maintenance or
to any product that has been altered or modified. The
warranty does not extend to repairs made necessary
by normal wear or by the use of parts or accessories
which are either incompatible with the HOMELITE
brand product or adversely affect its operation,
performance, or durability. In addition, this warranty does
not cover:
A. Tune-ups – Spark Plugs, Carburetor, Carburetor
Adjustments, Ignition, Filters
B. Wear items – Bump Knobs, Outer Spools, Cutting
Lines, Inner Reels, Starter Pulleys, Starter Ropes, Drive
Belts, Tines, Felt Washers, Hitch Pins, Mulching Blades,
Blower Fans, Blower and Vacuum Tubes, Vacuum Bags
and Straps, Guide Bars, Saw Chains
Homelite reserves the right to change or improve
the design of any HOMELITE brand product without
assuming any obligation to modify any product previously
manufactured.
ALL IMPLIED WARRANTIES ARE LIMITED IN DURATION
TO THE STATED WARRANTY PERIOD. ACCORDINGLY,
ANY SUCH IMPLIED WARRANTIES INCLUDING
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, OR OTHERWISE, ARE DISCLAIMED IN
THEIR ENTIRETY AFTER THE EXPIRATION OF THE
APPROPRIATE TWO-YEAR, ONE-YEAR, OR NINETY-DAY
WARRANTY PERIOD. HOMELITE’S OBLIGATION UNDER
THIS WARRANTY IS STRICTLY AND EXCLUSIVELY
LIMITED TO THE REPAIR OR REPLACEMENT OF
DEFECTIVE PARTS AND HOMELITE DOES NOT ASSUME
OR AUTHORIZE ANYONE TO ASSUME FOR THEM ANY
OTHER OBLIGATION. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY
TO YOU. HOMELITE ASSUMES NO RESPONSIBILITY
FOR INCIDENTAL, CONSEQUENTIAL, OR OTHER
DAMAGES INCLUDING, BUT NOT LIMITED TO, EXPENSE
OF RETURNING THE PRODUCT TO AN AUTHORIZED
HOMELITE SERVICE CENTER AND EXPENSE OF
DELIVERING IT BACK TO THE OWNER, MECHANIC’S
TRAVEL TIME, TELEPHONE OR TELEGRAM CHARGES,
RENTAL OF A LIKE PRODUCT DURING THE TIME
WARRANTY SERVICE IS BEING PERFORMED, TRAVEL,
LOSS OR DAMAGE TO PERSONAL PROPERTY, LOSS
OF REVENUE, LOSS OF USE OF THE PRODUCT,
LOSS OF TIME, OR INCONVENIENCE. SOME STATES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY
TO YOU.
This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
This warranty applies to all HOMELITE brand products
manufactured by or for Homelite and sold in the United
States and Canada.
To locate your nearest Homelite authorized service
center, dial 1-800-242-4672 or log on to our website at
www.homelite.com.
Page 15
WARRANTY
THE FOLLOWING CALIFORNIA AIR RESOURCES BOARD (CARB) STATEMENT ONLY APPLIES
TO MODEL NUMBERS REQUIRED TO MEET THE CARB REQUIREMENTS.
HOMELITE CONSUMER PRODUCTS, INC., LIMITED WARRANTY
FEDERAL AND CALIFORNIA EMISSION CONTROL SYSTEMS
NONROAD AND SMALL OFF-ROAD ENGINES
The U.S. Environmental Protection Agency (EPA), the California Air Resources Board (CARB), and Homelite Consumer Products, Inc., are
pleased to explain the Emission Control System Warranty on your nonroad or small off-road engine. In California, new small off-road engines
must be designed, built, and equipped to meet the state’s stringent anti-smog standards. In other states, new 2000 and later model year
nonroad engines must be designed, built and equipped, at the time of sale, to meet the U.S. EPA regulations for small nonroad engines. The
nonroad engine must be free from defects in materials and workmanship which cause it to fail to conform with U.S. EPA standards for the
first two years of engine use from the date of sale to the ultimate purchaser. Homelite Consumer Products, Inc., must warrant the emission
control system on your nonroad or small off-road engine for the period of time listed above provided there has been no abuse, neglect, or
improper maintenance of your nonroad or small off-road engine.
Your emission control system may include parts such as the carburetor or fuel injection system, the ignition system, and the catalytic con
verter. Also included may be hoses, belts, and connectors and other emission-related assemblies.
Where a warrantable condition exists, Homelite Consumer Products, Inc., will repair your nonroad or small off-road engine at no cost to you,
including diagnosis (if the diagnostic work is performed at an authorized service center for HOMELITE brand products), parts, and labor.
MANUFACTURER’S WARRANTY COVERAGE:
The 1995 and later small off-road engines are warranted for two years in California. In other states, 1997 and later model year nonroad
engines are also warranted for two years. If any emission-related part on your engine is defective, the part will be repaired or replaced by
Homelite Consumer Products, Inc., free of charge.
OWNER’S WARRANTY RESPONSIBILITIES
(a) As the nonroad or small off-road engine owner, you are responsible for the performance of required maintenance listed in your operator's
manual. Homelite Consumer Products, Inc., recommends that you retain all receipts covering maintenance on your nonroad or small
off-road engine, but Homelite Consumer Products, Inc., cannot deny warranty solely for the lack of receipts or for your failure to ensure
the performance of all scheduled maintenance. Any replacement part or service that is equivalent in performance and durability may be
used in non-warranty maintenance or repairs, and shall not reduce the warranty obligations of the engine manufacturer.
(b) As the nonroad or small off-road engine owner, you should be aware, however, that Homelite Consumer Products, Inc., may deny you
warranty coverage if your nonroad or small off-road engine or a part has failed due to abuse, neglect, improper maintenance, or unap
proved modifications.
(c) You are responsible for presenting your nonroad or small off-road engine to an authorized service center for
as soon as a problem exists. The warranty repairs should be completed in a reasonable amount of time, not to exceed 30 days.
If you have any questions regarding your warranty rights and responsibilities, you should contact a Homelite Consumer Products, Inc.,
Customer Representative at 1-800-242-4672.
HOMELITE brand products
COVERAGE:
Homelite Consumer Products, Inc., warrants to the ultimate purchaser and each subsequent purchaser that your nonroad or small off-road
engine will be designed, built, and equipped, at the time of sale, to meet all applicable regulations. Homelite Consumer Products, Inc., also
warrants to the initial purchaser and each subsequent purchaser that your nonroad or small off-road engine is free from defects in materials
and workmanship which cause the engine to fail to conform with applicable regulations for a period of two years. The 1995 and later small
off road engines are warranted for two years in California. In all other states for 1997 and later model years, EPA requires manufacturers to
warrant non-road engines for two years. These warranty periods will begin on the date the nonroad or small off-road engine is purchased
by the initial purchaser. If any emission-related part on your engine is defective, the part will be replaced by Homelite Consumer Products,
Inc., at no cost to the owner.
Homelite Consumer Products, Inc., shall remedy warranty defects at any Homelite authorized service center. Any authorized work done at
a Homelite authorized service center shall be free of charge to the owner if such work determines that a warranted part is defective. Any
manufacturer-approved or equivalent replacement part may be used for any warranty maintenance or repairs on emission-related parts, and
must be provided free of charge to the owner if the part is still under warranty. Homelite Consumer Products, Inc., is liable for damages to
other engine components caused by the failure of a warranted part still under warranty.
The California Air Resources Board’s Emission Warranty Parts List specifically defines the emission-related warranted parts. (EPA’s regula
tions do not include a parts list, but EPA considers emission-related warranted parts to include all the parts listed below.)
These warranted parts are: Carburetor, Spark Plug, Ignition, Air Filter, and Fuel Filter.
MAINTENANCE REQUIREMENTS
The owner is responsible for the performance of the required maintenance as defined by Homelite Consumer Products, Inc., in the operator’s
manual.
LIMITATIONS
The Emission Control Systems Warranty shall not cover any of the following:
(a) repair or replacement required because of misuse or neglect, lack of required maintenance, repairs improperly performed, or
replacements not conforming to Homelite Consumer Products, Inc., specifications that adversely affect performance and/or
durability, and alterations or modifications not recommended or approved in writing by Homelite Consumer Products, Inc., and
(b) replacement of parts and other services and adjustments necessary for required maintenance at and after the first scheduled replace
ment point.
The Emissions Compliance Period referred to on the Emissions Compliance label indicates the number of operating hours for which the
engine has been shown to meet Federal emission requirements. Category C=50 hours, B=125 hours, and A=300 hours.
-
-
-
-
Page 16
WARRANTY
1-800-242-4672
CAL
L
THIS PRODUCT WAS MANUFACTURED WITH A CATALYST MUFFLER
Congratulations! You have made an investment toward protecting the environment. In order to maintain this product’s
original emission level, please refer to the maintenance section below.
EMISSIONS MAINTENANCE SCHEDULE AND WARRANTED PARTS LIST
Emissions Parts Inspect Before Clean Every Replace Clean Every Replace Every
Each Use 5 Hours Every 25 Hours 25 Hours 50 Hours
or Yearly or Yearly
CATALYTIC MUFFLER ASSEMBLY ................................................................................................................... X
AIR FILTER ASSY
includes:
Filter .................................................................
SPARK SCREEN ..................................................................................................................
CARBURETOR ASSY
includes:
Heat Dam
Gaskets
FUEL TANK ASSY
includes:
Fuel Lines ........................
Fuel Cap ..........................
Fuel Filter
IGNITION ASSY
includes:
Spark Plug ........................................................................................
ALL EMISSIONS-RELATED PARTS ARE WARRANTED FOR TWO YEARS OR FOR THE PERIOD OF TIME PRIOR TO
THE PARTS FIRST SCHEDULED REPLACEMENT WHICHEVER COMES FIRST.
X
X
X ............................. X
X
X
CALL US FIRST
For any questions about operating or maintaining your product,
call the Homelite® Help Line!
Your product has been fully tested prior to shipment to ensure
your complete satisfaction.
Page 17
OPERATOR’S MANUAL
YARD BROOM II
UT08514
WARNING:
The engine exhaust from this product contains chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.
CALIFORNIA PROPOSITION 65
SERVICE
For parts or service, contact your nearest Homelite authorized service dealer. Be sure to provide all
relevant information when you call or visit. For the location of the authorized service dealer nearest
you, please call 1-800-242-4672 or visit us online at www.homelite.com.
REPAIR PARTS
The model number of this product is found on a plate or label attached to the housing. Please record
the serial number in the space provided below.
MODEL NUMBER ________________________
SERIAL NUMBER ________________________
UT08514
HOMELITE CONSUMER PRODUCTS, INC.
1428 Pearman Dairy Road
Anderson, SC 29625
Phone 1-800-242-4672
www.homelite.com
983000-927
1-17-06 (REV:00)
Loading...
