Homedics PA-200H Instruction Manual

Dirección postal:

HoMedics Service Center Dept. 168 3000 Pontiac Trail Commerce Township, MI 48390

Correo electrónico: cservice@homedics.com

GARANTÍA LIMITADA POR DOS AÑOS

(Válida únicamente en los EE.UU.) HoMedics, Inc., garantiza este producto contra defectos en material y

mano de obra durante el período de dos años a partir de la fecha original de compra con las excepciones que se detallan a continuación.

Esta garantía de producto de HoMedics no cubre daños causados por un uso inadecuado, abuso, accidente, la conexión de accesorios no autorizados, la alteración del producto o cualquier otra condición sin importar cual sea que se encuentre fuera del control de HoMedics. Esta garantía es válida sólo si el producto es comprado y usado en los EE.UU. Esta garantía no cubre un producto que requiera modificación o alteración para que pueda usarse en cualquier otro país distinto del país por el cual fue diseñado, fabricado, aprobado y/o autorizado, o la reparación de productos dañados a causa de estas modificaciones. HoMedics no será responsable de ningún tipo de daños incidentales, consecuentes o especiales. Todas las garantías implícitas, incluyendo entre otras aquellas garantías implícitas de idoneidad y comerciabilidad, están limitadas a la duración total de dos años a partir de la fecha de compra original.

Para obtener un servicio cubierto por la garantía para su producto HoMedics, puede entregar la unidad personalmente o enviarla por correo junto con su recibo de compra fechado (como prueba de la compra), el franqueo pagado, junto con un cheque o una orden de pago por el monto de $5.00, pagadero a HoMedics, Inc. para cubrir los gastos de manipulación.

Una vez recibido, HoMedics reparará o reemplazará su producto, según lo que sea apropiado y se lo enviará con el franqueo pagado. Si es apropiado reemplazar su producto, HoMedics lo reemplazará con uno igual o comparable, a opción de Homedics. La garantía es válida únicamente a través del Centro de servicio HoMedics. El servicio realizado a este producto por cualquier otro diferente al Centro de servicio HoMedics anulará la garantía.

Esta garantía le proporciona derechos legales específicos. Es posible que usted tenga derechos adicionales que pueden variar de un estado a otro. Debido a las regulaciones de los diferentes estados, es posible que algunas de las limitaciones y exclusiones no se apliquen en su caso.

Therapist Select™Deluxe

Programmable Percussion Massager

Por más información con respecto a nuestra línea de productos en los EE.UU., visítenos en: www.homedics.com

es una marca registrada de HoMedics, Inc. y sus compañías afiliadas. Therapist Select™ y The

beauty of living well.™ son marcas registradas de HoMedics, Inc. y sus compañías afiliadas.

Reservados todos los derechos.

IB-PA200H-B

Instruction Manual and Warranty Information

El manual en español empieza a la página 9

PA-200H

IMPORTANT SAFEGUARDS

WHEN USING ELECTRICAL PRODUCTS, ESPECIALLY WHEN CHILDREN ARE PRESENT, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:

READ ALL INSTRUCTIONS BEFORE USING.

DANGER

- TO REDUCE THE RISK OF

ELECTROCUTION:

• ALWAYS unplug the appliance from the electrical outlet immediately after using and before cleaning.

• DO NOT reach for an appliance that has fallen into water. Unplug it immediately.

•DONOT use while bathing or showering.

•DONOT place or store appliance where it can fall or be pulled into a tub or sink. DO NOT place in or drop into water or other liquid.

SAVE THESE INSTRUCTIONS WARNING

BURNS, ELECTROCUTION, FIRE OR INJURY TO PERSONS:

• An appliance should NEVER be left unattended when plugged in. Unplug from outlet when not in use and before putting on or taking off parts or attachments.

• Close supervision is necessary when this appliance is used by, on or near children, invalids or disabled persons.

•DONOT use outdoors.

• Use this appliance only for its intended use as described in this manual. DO NOT use attachments not recommended by HoMedics; specifically any attachments not provided with the unit.

- TO REDUCE THE RISK OF

Caution: In case of pregnancy, diabetes or illness, consult your doctor before using massager.

Caution: All servicing of this unit must be performed by authorized HoMedics service personnel only.

• NEVER operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return it to HoMedics Service Center for examination and repair.

• Use heated surfaces carefully. May cause serious burns. DO NOT use over sensitive skin areas or in the presence of poor circulation. The unattended use of heat by children or incapacitated persons may be dangerous.

• Keep cord away from heated surfaces.

• NEVER block the air openings of the appliance or place it on a soft surface, such as a bed or couch, where the air openings may be blocked. Keep air openings free of lint, hair, etc.

• NEVER use while sleeping or fall asleep while using the massager.

• NEVER drop or insert any object into any opening.

• DO NOT operate where aerosol (spray) products are being used or where oxygen is being administered.

•DONOT use on or near eyes or other highly sensitive areas.

• DO NOT operate under a blanket or pillow. Excessive heating can occur and cause fire, electrocution or injury to persons.

• DO NOT carry this appliance by supply cord or use cord as handle.

• DO NOT use the percussion action massager directly on one concentrated area of the body. Percussion action massagers are designed to be used in a continuous motion, constantly changing the massage area.

•To disconnect, turn all controls to the “OFF” position, then remove plug from outlet.

• This appliance is designed for household use only.

Caution — Please read all instructions carefully before operating.

• If you have any concerns regarding your health consult your doctor before using this product.

• Individuals with pacemakers should consult a doctor before use. NEVER leave the appliance unattended, especially if children are

• present.

• NEVER cover the appliance when it is in operation.

• DO NOT use this product for more than 15 minutes at a time. Extensive use could lead to the product’s excessive heating and shorter life. Should this occur, discontinue use and allow the unit to cool before operating.

• NEVER use this product directly on swollen or inflamed areas or skin eruptions.

2 3

Caution: Never use the heat feature without the proper attachment.

Figure 1

• This product is a non-professional appliance designed to provide soothing massage to worn muscles. DO NOT use this product as a substitute for medical attention.

• DO NOT use this product before bed. The massage has a stimulating effect and can delay sleep.

• NEVER use this product while in bed.

• This product should NEVER be used by any individual suffering from any physical ailment that would limit the user’s capacity to operate the controls.

• This unit should not be used by children or invalids without adult supervision.

Instructions for Use

To reduse the risk of electric shock, this appliance has a polarized

plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. DO NOT change the plug in any way.

1. This unit is powered by and comes with a UL-approved cord. Untie

cord strap, extend cord and insert plug into 120-volt household electrical outlet to power unit.

2. To turn unit on, press POWER button located above handle.

A corresponding LED light will illuminate to indicate all selections. (See Figure 1).

3. Choose the desired massage option: steady or program.

4. For steady massage, press MASSAGE button. To increase or

decrease the massage intensity level, press the up or down arrows on each side of the PROGRAM button. The intensity level is indicated by the LED lights in the center of the program panel.

5. For a programmed massage, press the PROGRAM button on the

upper left side. Choose any of the three program options:

• P1 provides slow, steady percussion action to relax and revitalize.

• P2 provides intense massage action to penetrate and soothe.

• P3 provides short, quick bursts for energizing stimulation. An interval level may be chosen by pressing the INTERVAL button on the upper right side. There are three interval options: I1 (low), I2 (moderate) and I3 (high).

6. Gently apply massage heads to the area you wish to treat, and move

slowly in a circular motion.

Programs:

Figure 2

Button

Figure 3

Figure 4

7. Treat the target area for a short period of time, and then move to another area. NEVER treat the same area longer than 3 minutes. CAUTION: As stated in the “IMPORTANT SAFEGUARDS” section of this manual, NEVER use this appliance on or near the eyes, temples or other highly sensitive areas.

8. A massage session of longer than 15 minutes is not recommended.

9. When treatment is completed, turn the unit off and unplug the power supply. Store the unit properly in a cool, dry place.

NOTE: For added protection of your unit, when the power is on but no function is selected or the HEAT function is chosen with no massage function selected, the unit will automatically shut off after 15 minutes.

Auto-Spacing Features

The spacing between the massage heads can be adjusted to fit various body frames and areas (See Figure 2). Turn the unit on and simply push the button on the underside of the massager to adjust the spacing between the massage heads (See Figure 3). They will continue to cycle in and out as a long as the button is held down. As soon as you find your desired spacing for maximum comfort, release the button.

To Change Attachments

Your massager comes with 4 custom massage head attachments. Each set is a different firmness:

• Hard (light grey) • Medium (medium grey)

• Soft (black) • Heat (red)

To remove the massage heads from the unit, rotate each counterclockwise. Rotate clockwise to fasten the massage heads. (See Figure 4.)
