Technical Sheet
Easily adjust lights, audio, spa, and
much more with the OmniTouch 5.7
The OmniTouch 5.7 (HAI part number
53A00-1) is a colorful “plug and play”
Touchscreen with large icons to control lights
and small appliances, monitor and adjust security
and temperatures, pool and spa temperatures,
ventilation, decorative lighting, Whole Home
Audio Systems, surveillance video, and other items
under the control of an HAI Home Control system.
• Large 5.7” LCD display using TFT technology
for rich colors and improved viewing angles.
• Displays full screen video. Compatible with any
CCTV camera. (Touchscreen Hub and Video
Encoder necessary for video.)
The OmniTouch 5.7 is compatible with all HAI
controllers, including the Omni LT, Omni IIe, OmniPro
II, Lumina and Lumina Pro. The OmniTouch 5.7 comes
in White, with color change kits available in Almond,
Black, Ivory, Light Almond, and Silver.
www.homeauto.com
• Speaker instead of beeper for more pleasing
audible tones.
• A built-in USB connector that allows you to
update to the newest version of firmware at
any time easily and for free!
1
Security
Energy Management
(Omni family
controllers
only.) Easily
adjust security
functions with
one touch.
Arm, Disarm, set to Vacation or Away.
View an event log to see who accessed
the security system and at what time.
Lighting Control
Adjust the lighting in
any room.
Easily dim, setup timing
sequences, or turn all
lights on/off by switch,
by room, or by house.
View indoor and outdoor
temperatures and humidity.
Adjust the heating or cooling
within a room or whole house.
View humidors or wine cellar
temperatures and monitor water
temperature sensors.
sleek, clutter-free appearance with full functionality. (See HAI
Connectivity Partners for exact models.)
www.homeauto.com
Whole Home Audio
Control Hi-Fi by HAI or an
audio system from one of HAI’s
Connectivity Partners.
OmniTouch 5.7 emulates the NuVo,
Russound, Speakercraft, Proficient,
and Xantech audio keypads for a
2
Status
One touch gives you the status of the
home’s security, temperatures, lighting,
and energy usage.
Surveillance Video
View full screen video feed from cameras
directed at the front door, the pool, the
nursery, etc.
Press the camera selection button to release
a door strike and let your visitor inside!
Buttons
Buttons are a way to quickly initiate a chain of commands, or
to initiate a function that is not already assigned an icon.
Have a “Water Lawn” button to turn on the sprinkler system.
Or have a “Romantic Evening” button to drop the shades, turn
on the whole home audio system, dim the lights, and activate
other features controlled by an HAI home control system.
www.homeauto.com
3
OMNITOUCH 5.7 PARTS LIST
Touchscreens:
Description Part #
OmniTouch 5.7 53A00-1
OmniTouch 5.7 Spanish 53A00-5
Accessories:
Description Part #
Touchscreen Hub with Video, for
32A30-2
Structured Wiring Enclosures
Touchscreen Hub, No Video,
32A30-3
in Enclosure
Touchscreen Hub, No Video, for
32A30-4
Structured Wiring Enclosure
Touchscreen Hub Board Only 32A31-2
Video Encoder 32A32-1
Touchscreen Hub Replacement
106080
Power Supply
Touchscreen Hub with
32A30-1
Video in Enclosure
OmniTouch 5.7 Color Change Kit
53A05-AL
Almond
OmniTouch 5.7 Color Change Kit
53A05-LTA
Light Almond
OmniTouch 5.7 Color Change Kit
53A05-BL
Black
OmniTouch 5.7 Color Change Kit
53A05-IV
Ivory
OmniTouch 5.7 Color Change Kit
53A05-SL
Silver
OmniTouch 5.7 Color Change Kit
53A05-WH
White
HAI recommends Touchscreen Hub for installations with more than two
Touchscreens. Touchscreen Hub with video encoder required for video capabilities.
