Home Automation 68A00-1 User Manual
HOME AUTOMATION, INC.
Model 68A00-1
Network Digital Video Recorder (DVR)
Installation and User Guide
Document Number 68I00-1 Rev. A
January, 2008
CONTENT VERIFICATION
Before installing the Network Digital Video Recorder, please make sure that the
following items are included in the box:
1. Network Digital Video Recorder
2. Crossover LAN cable
3. DC 5V / 1.5 A Power Adapter
4. Terminal Block
5. Client Software CD
6. This Instruction Manual
1
68A00-1 NETWORK DIGITAL VIDEO RECORDER
DISCLAIMER
• While every effort has been made to ensure that the information contained in this guide is
accurate and complete, no liability can be accepted for any errors or omissions.
• HAI reserves the right to change the specifications of the hardware and software described
herein at any time without prior notice.
• No part of this guide may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form, by any means, without prior written
permission of HAI.
• HAI makes no warranties for damages resulting from corrupted or lost data due to mistaken
operation or malfunction of the Network Digital Video Recorder, the software, the hard
drives, personal computers, peripheral devices, or unapproved/unsupported devices.
Trademark Acknowledgements
• DiamondMax Plus 9, DiamondMax 16, MaxLine II and MaxLine Plus II are a trademark of
Maxtor Corporation.
• Barracuda series HDDs are a trademark of Seagate Corporation.
• Microsoft, Windows98, Windows ME, Windows NT, Windows XP, Internet Explorer are
either registered trademarks or trademarks of Microsoft Corporation in the United States
and/or other countries.
• Other names and products not mentioned above may be registered trademarks or
trademarks of their respective companies.
2
68A00-1 NETWORK DIGITAL VIDEO RECORDER
FCC NOTICE
Network Digital Video Recorder, Model 68A00-1:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions;
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits for Class B digital
devices, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experience radio/TV technician for help.
Do not make any changes or modifications to the equipment unless otherwise specified in the
manual. If such changes or modifications should be made, you could be required to stop
operation of the equipment.
Home Automation, Inc.
4330 Michoud Blvd.
New Orleans, LA 70129
Tel: (504) 736-9810
Canadian Radio Interference Regulations
THIS CLASS B DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN
INTERFERENCE CAUSING EQUIPMENT REGULATIONS.
3
68A00-1 NETWORK DIGITAL VIDEO RECORDER
Read this First
Test Sessions
Before you try to record important subjects, we highly recommend that you make several test
recording and playback sessions to ensure that the Network Digital Video Recorder is operating
and being operated correctly. Please note that HAI, its subsidiaries and affiliates, and its
distributors are not liable for any consequential damages arising from any malfunction of a
Network Digital Video Recorder or its accessories, including the hard disk drive, compact flash,
and USB thumbnail drive, which result in the failure of an image to be recorded or to be
recorded in a format that is machine sensible.
The Privacy act of 1974 (5 U.S.C. § 552a)
Please note that HAI Network Digital Video Recorders are intended for monitoring and
surveillance use and should never be used in a manner that invades other people’s privacy or
contravenes international or domestic privacy act and its regulations. Please be advised that in
certain cases the recording of individuals, private properties, or commercial properties by means
of camera or other devices may contravene legal rights of such individuals even if the images
were recorded for personal use.
Warranty Limitations
This Network Digital Video Recorder’s warranty is only effective in the country of sale. If a
problem arises while the VIDEO SERVER is in use abroad, please convey it back to the country
of sale before proceeding with a warranty claim to HAI customer help desk.
4
68A00-1 NETWORK DIGITAL VIDEO RECORDER
SAFETY PRECAUTIONS
• Before using the Network Digital Video Recorder, please ensure that you read and
understand the safety precautions described below. Always ensure that the Network Digital
Video Recorder is operated correctly.
• The safety precautions noted on the following pages are intended to instruct you in the safe
and correct operation of the Network Digital Video Recorder and its accessories to prevent
injuries or damage to the self, other persons and equipment.
• In this Instruction Manual, the term “Network Digital Video Recorder”, “68A00-1”,
“equipment”, and “device” refers primarily to the Network Digital Video Recorder and its
accessories such as power supply.
WARNING
• Do not cover the ventilation opening or slots on the outer casing. To prevent the Network
Digital Video Recorder from overheating, provide at least two inches of air space around the
vent and the slots.
• Do not drop metallic parts through slots. This could permanently damage the Network
Digital Video Recorder. Immediately turn the device’s power off or unplug the power cord
from the power outlet. Contact a qualified service personnel authorized by the equipment
distributor or a HAI customer help desk.
• Do not attempt to disassemble or alter any part of the equipment that is not expressly
described in this guide. Disassembly or alteration may result in high voltage electrical
shock. Internal inspections, alterations and repairs should be conducted by qualified
service personnel authorized by the equipment distributor or HAI customer help desk.
• Stop operating the equipment immediately if it emits smoke or noxious fumes. Failure to
do so may result in fire or electrical shock. Immediately turn off power to the equipment
and remove the power cable from the power outlet. Confirm that smoke and fume
emissions have ceased. Please consult the Network Digital Video Recorder distributor or
the closest HAI customer help desk.
• Stop operating the equipment if a heavy object is dropped or the casing is damaged. Do
not strike or shake. Failure to do so may result in fire or electrical shock. Immediately
turn the Network Digital Video Recorder’s power off or unplug the power cord from the
power outlet. Please consult the Network Digital Video Recorder distributor or the closest
HAI customer help desk.
5
68A00-1 NETWORK DIGITAL VIDEO RECORDER
• Do not allow the equipment to come into contact with, or become immersed in, water or
other liquids. Do not allow liquids to enter the interior. The Network Digital Video
Recorder has not been waterproofed. If the exterior comes into contact with liquids or salt
air, wipe it dry with a soft, absorbent cloth. In the event that the water or other foreign
substances enter the interior, immediately turn the Network Digital Video Recorder’s Power
off or unplug the power cord from the power outlet. Continued use of the equipment may
result in fire or electrical shock. Please consult the Network Digital Video Recorder
distributor or the HAI customer help desk.
• Do not use substances containing alcohol, benzene, thinners or other flammable
substances to clean or maintain the equipment. The use of these substances may lead to
fire. Use a dry cloth on a regular periodic basis and wipe away the dust and dirt that
collects on the device. In dusty, humid or greasy environments, the dust that collects
around the ventilation or the slots on the outer casing over long periods of time may
become saturated with humidity and short-circuit, leading to fire.
• Do not cut, damage, alter or place heavy items on the power cord. Any of these actions
may cause an electrical short circuit, which may lead to fire or electrical shock.
• Do not handle the device or power cord if the hands are wet. Handling it with wet hands
may lead to electrical shock. When unplugging the cord, ensure that you hold the solid
portion of the plug. Pulling on the flexible portion of the cord may damage or expose the
wire and insulation, creating the potential for fires or electrical shocks.
• Use only the recommended power accessories. Use of power sources not expressly
recommended for this equipment may lead to overheating, distortion of the equipment, fire,
electrical shock or other hazards.
• Do not place the battery near a heat source or expose it to direct flame or heat. Neither
should you immerse them in water. Such exposure may damage the battery and lead to
the leakage of corrosive liquids, fire, electrical shock, explosion or serious injury.
• Do not attempt to disassemble, alter or apply heat to the battery. There is serious risk of
injury due to an explosion. Immediately flush with water any area of the body, or clothing
that comes into contact with the inner contents of the battery. If the eyes or mouth contact
these substances, immediately flush with water and seek medical assistance from a medical
professional.
• Avoid dropping or subjecting the battery to severe impacts that could damage the casings.
It could lead to leakage and injury.
• Do not short-circuit the battery terminals with metallic objects, such as key holders. It
could lead to overheating, burns and other injuries.
6
68A00-1 NETWORK DIGITAL VIDEO RECORDER
• The supplied power supply and power cord are designed for exclusive use with the Network
Digital Video Recorder. Do not use it with other products or battery. There is a risk of fire
and other hazards.
CAUTION
• Avoid using, placing or storing the equipment in places subject to strong sunlight or high
temperatures, such as the greenhouse or trunk of a car. Exposure to intense sunlight and
heat may cause the battery to leak, overheat or explode, resulting in fire, burns or other
injuries. High temperatures may also cause deformation of the casing. Ensure that there
is good ventilation when using the equipment.
• Do not store the equipment in humid or dusty areas. Storage in such areas could lead to
fire, electrical shock or other damage.
• Do not operate the Network Digital Video Recorder beyond its specified temperature,
humidity or power source ratings. Do not use the Network Digital Video Recorder in an
extreme environment such as in high temperature or high humidity. Use the device at
temperatures within 41°F - 104°F and humidity below 90 %. The normal operating power
source for this device is 110V-220V AC 50/60Hz.
PREVENTING MALFUNCTION
• Avoid Strong Magnetic Fields. Never place the Network Digital Video Recorder in close
proximity to electric motors or other equipment generating strong electromagnetic fields.
Exposures to strong magnetic fields may cause malfunctions or corrupt image data.
• Avoid Condensation Related Problems. Moving the equipment rapidly between hot and
cold temperatures may cause condensation (water droplets) to form on its external and
internal surfaces. You can avoid this by placing the equipment in an airtight, resealable
plastic bag and letting it adjust to temperature changes slowly before removing it from the
bag.
• If Condensation forms inside the Network Digital Video Recorder, stop using the equipment
immediately. Continued use may damage the equipment. Remove the power cord from
the power outlet and wait until the moisture evaporates completely before resuming use.
7
68A00-1 NETWORK DIGITAL VIDEO RECORDER
Warnings
Open the cover at your own discretion. Doing so can cause system damage
or electric shock. Contact a qualified technician or your dealer for repair of this
product. Manufacturer is not responsible for any damage or injury sustained
by opening and/or assembling/disassembling the unit.
Electric shock or fire may result when foreign liquids or substances are
introduced into the unit. If this occurs, discontinue use, power down the unit
and contact your dealer immediately.
This equipment is susceptible to electric surge damage. Use of a conditioned
power supply is recommended.
Avoid installing the unit in locations where severe vibration, high humidity or
direct sunlight exists.
Do not place a heavy load on top of this unit.
Danger of explosion if battery is incorrectly replaced. Replace the battery only
with the same type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer's instructions.
8
68A00-1 NETWORK DIGITAL VIDEO RECORDER
Table of Contents
CONTENT VERIFICATION ........................................................................................................... 1
DISCLAIMER ................................................................................................................................ 2
FCC NOTICE................................................................................................................................. 3
Canadian Radio Interference Regulations................................................................................ 3
Read this First.............................................................................................................................. 4
Test Sessions..................................................................................................................... 4
The Privacy act of 1974 (5 U.S.C. § 552a)........................................................................ 4
Warranty Limitations ......................................................................................................... 4
SAFETY PRECAUTIONS ............................................................................................................. 5
WARNING ..................................................................................................................................... 5
CAUTION ...................................................................................................................................... 7
PREVENTING MALFUNCTION.................................................................................................... 7
1. FRONT LAYOUT ........................................................................................................... 11
2. REAR LAYOUT.............................................................................................................. 12
3. INSTALLATION AND CONNECTION............................................................................ 13
3.1 One-way monitoring using a PC ............................................................................. 14
I. Introduction............................................................................................................................. 15
1. Network Digital Video Recorder .................................................................................... 15
2. About the 68A00-1......................................................................................................... 15
3. Main Features................................................................................................................ 16
II. Installation.............................................................................................................................. 18
1. Connect the 68A00-1 to a configuration PC:................................................................. 18
1.1 Select a PC or laptop running any Microsoft Windows OS, with:........................... 18
1.2 Connecting the 68A00-1 to a configuration PC: ..................................................... 18
2. Assign an IP address to the 68A00-1 using IP Setup wizard ........................................ 18
2.1 Run IP Setup wizard ............................................................................................... 18
2.2 Browsing the 68A00-1 unit...................................................................................... 19
2.3. Confirm communications ....................................................................................... 21
3. Setup of the 68A00-1..................................................................................................... 21
III. Real-time Video Monitoring................................................................................................. 22
1. Accessing the 68A00-1 Server ...................................................................................... 22
1.1 Auto-installation of the Client Viewer Program ....................................................... 22
1.2 User Login............................................................................................................... 23
9
68A00-1 NETWORK DIGITAL VIDEO RECORDER
2. The 68A00-1 Viewer...................................................................................................... 25
2.1 Image Display Panel............................................................................................... 25
2.2 Video Control Panel................................................................................................ 26
2.4 Go to Admin page ................................................................................................... 29
2.5 Audio mute .............................................................................................................. 29
2.6 Transfer to 68A00-1 Player..................................................................................... 29
IV. Search and Playback ........................................................................................................... 30
1. Remote Playback .......................................................................................................... 30
2. Login .............................................................................................................................. 30
3. 68A00-1 Player.............................................................................................................. 31
3.1 Image Display Panel............................................................................................... 31
3.2 The time-map Panel and intelligent playback......................................................... 32
3.3 Playback Control Panel .......................................................................................... 33
3.4 Calendar Panel ....................................................................................................... 33
3.5 Storage gauge......................................................................................................... 34
3.6 Search, Backup, and Print ...................................................................................... 34
3.7 File List Panel ......................................................................................................... 35
3.8 View Channel Mode Selection Panel...................................................................... 36
3.9 Configuration........................................................................................................... 36
3.10 Go to the Administrator’s Page............................................................................. 37
3.11 Go to the 68A00-1 Viewer..................................................................................... 37
V. Setup ...................................................................................................................................... 38
1. Connect to the Administration Page.............................................................................. 38
2. Management of System Setup ...................................................................................... 39
2.1 General Settings ..................................................................................................... 39
2.2 Video Settings......................................................................................................... 42
2.3 Audio Settings ......................................................................................................... 45
2.4 Pan/Tilt/Zoom (PTZ) Setup..................................................................................... 46
2.5 Schedule ................................................................................................................. 48
2.6 Network Settings..................................................................................................... 52
2.7 Registration (to directory server) ............................................................................ 55
2.8 D/O control (Relay Control) .................................................................................... 57
2.10 Configuration Import/Export.................................................................................. 58
2.11 Software Update ................................................................................................... 59
2.12 Restart................................................................................................................... 60
Appendix 1: Troubleshooting................................................................................................... 61
10
68A00-1 NETWORK DIGITAL VIDEO RECORDER
NETWORK DIGITAL VIDEO RECORDER LAYOUT
1. FRONT LAYOUT
⑤ ④ ③ ① ②
① Ready LED
Indicates the unit is completed initialized and is ready to be accessed.
② On Air LED
Indicates that one or more users are connected to the unit.
③ Audio Input/Output Connector
Connect a speaker to the output.
Input allows connecting an audio device with audio input level of 0.2-2V (line-in
level normally).
④ RS-232 port
The RS-232 port is used as console monitoring or can be used as an external
signal input port.
⑤ USB port
The USB port is used for flash-type external storage.
11
68A00-1 NETWORK DIGITAL VIDEO RECORDER
2. REAR LAYOUT
⑤ ④ ③ ② ①
① Power Input connector (DC 5V)
* Please check the voltage of your connecting adapter.
② Ethernet port (10/100 Base-T Ethernet)
③ Data I/O connector
Sensor Input connector (S1, G, S2): Connect up to 2 dry contact input sensors.
Data Output (DO) connector (NC, NO, COM): Normally Open (NO) type or Normally
Close (NC) type may be used.
RS-485(+, -): Connect pan, tilt, and zoom available camera or unit.
④ Video Out
One channel composite video output is supported.
⑤ Input connectors
Camera signal inputs:
Camera signal type (NTSC or PAL) can be adjusted on administrator’s page.
12
68A00-1 NETWORK DIGITAL VIDEO RECORDER
Warning:
Ensure that you are using the right adapter for the power.
Otherwise, fatal damage will be caused to the unit.
In such case, HAI is NOT responsible for the damage.
3. INSTALLATION AND CONNECTION
13
68A00-1 NETWORK DIGITAL VIDEO RECORDER
3.1 One-way monitoring using a PC
Transmitter: 68A00-1
Receiver: PC
14
68A00-1 NETWORK DIGITAL VIDEO RECORDER
I. Introduction
1. Network Digital Video Recorder
The 68A00-1 Network Digital Video Recorder is a device that transmits video and
audio data via network in real-time. The server converts the analog video signals
and audio signals into digital data and compresses them for on-line transmission.
Since the server has a built-in web server and network interface, it may not require
additional hardware, software, or programming (besides configuring IP address) to
view live video transmissions. After connecting all the cameras to the Network
Digital Video Recorder and configuring its IP address, the Network Digital Video
Recorder can be accessed from anywhere with an Internet connection.
2. About the 68A00-1
The 68A00-1 is a 4 channel Network Digital Video Recorder that transmits video in
high resolution with bi-directional audio in real-time via the network. The 68A00-1
supports various network environments such as high-speed Internet, cable, DSL,
LAN, or WAN.
The 68A00-1 compresses video in MPEG4, which is 4 to 5 times more than still
image compression algorithms such as JPEG or Wavelet. This allows more
efficient monitoring through low bandwidth networks such as DSL, DHCP, and
Cable network.
The 68A00-1 provides the high-performance interactive audio transmission
capability using an ADPCM Codec. The 68A00-1 can transmit audio using a
microphone or PC headset.
15
68A00-1 NETWORK DIGITAL VIDEO RECORDER
3. Main Features
The 68A00-1 is designed for various applications, such as IT related applications,
remote monitoring, and Internet broadcasting with the user friendly interface.
Highly Efficient MPEG4 Video Compression
The 68A00-1 support a 4 to 5 times more efficient transmission compared to
similar products based on the existing still image compression methods (JPEG
and Wavelet). Under the same conditions, if the size of motion pictures and
audio by still image compression method is 7.0 - 8.0 Kbytes, the 68A00-1 based
on MPEG4, compresses images up to 1.5 – 2.0 Kbytes (320 x 240) per frame.
It is transmitted at 15 - 20 frames per second via 256Kbps bandwidth, and 30
frames per second via 512Kbps bandwidth or higher. However, the image
sizes can vary depending on actual field conditions.
Interactive Audio
In addition to the real-time motion picture and audio transmission, the 68A00-1
provides an interactive audio transmission function. To provide more precise
information at the location, the 68A00-1 Network Server allows users to hear
audio and to watch video images simultaneously from the remote location
where the 68A00-1 server is installed.
Interface to External Equipment
The 68A00-1 Network Digital Video Recorder supports pan/tilt/zoom camera
devices, alarm sensors, as well as other security equipment to customize the
monitoring system.
Various Network Environments
The 68A00-1 supports various network connections (such as LAN, WAN, Cable,
DSL, etc.) that are utilizing either Static IP or Dynamic IP address services.
16
68A00-1 NETWORK DIGITAL VIDEO RECORDER
Local Recording and Playback
The internal hard drive provides the total security solution via network. The
68A00-1 stores live video and audio on its local drive. You can search and
playback files at any time and anywhere network access is available. The
features of Local recording and playback are as follows:
- Simultaneous recording, search, playback, and backup operation of 16 channels
- Weekly schedule
- Audio synchronized recording
- Continuous, Motion, Sensor, Video loss, and Network disconnection recordings
- Thumbnail playback
- User friendly full web environment
17
68A00-1 NETWORK DIGITAL VIDEO RECORDER
II. Installation
This chapter covers installation of the 68A00-1 Network Digital Video Recorder on
Static IP environments. Refer to Chapter 5 for more information about the installation
on Dynamic IP environments.
1. Connect the 68A00-1 to a configuration PC:
1.1 Select a PC or laptop running any Microsoft Windows OS, with:
• A 10baseT Ethernet adapter or PCMCIA card
• A crossover LAN cable (to direct connect to the 68A00-1), or
2 network patch cables (for connection via a router or switch)
• Microsoft Internet Explorer 4.0 or higher with Active-X Control Plug-In
1.2 Connecting the 68A00-1 to a configuration PC:
•
Connect the crossover cable between the PC and the Ethernet port on 68A00-1,
or
• Connect the PC and the 68A00-1 to a router or switch
2. Assign an IP address to the 68A00-1 using IP Setup wizard
2.1 Run IP Setup wizard
Run the ‘IPSetup.exe’ utility, which can be found on supplied Surveillance Utilities CD
(68A07-1), on a PC that is on THE SAME SUBNET
.
18
68A00-1 NETWORK DIGITAL VIDEO RECORDER
2.2 Browsing the 68A00-1 unit
Click the ‘Search’ button to detect the 68A00-1 unit on the same subnet. The 68A00-1
will be shown with its MAC Address, the factory default IP Address, Subnet Mask, and
Gateway, as seen below:
IP Address: 192.168.1.2
Subnet Mask: 255.255.255.0
Gateway: 192.168.1.1
Select the 68A00-1 to be installed and set the IP address, subnet mask, default
gateway and administrator’s password (that is set as ‘pass’ for factory default) followed
by clicking the ‘Set’ button.
19
68A00-1 NETWORK DIGITAL VIDEO RECORDER
Loading...
