HOLUX GPSlim236 Wireless Bluetooth GPS Receiver Manual
Table of Contents
TABLE OF CONTENTS ..............................................................................................................2
1. OVERVIEW..........................................................................................................................3
2. PACKING LIST....................................................................................................................4
3. MAIN FUNCTIONS.............................................................................................................4
4. TECHNICAL SPECIFICATION ........................................................................................5
4.1. BASIC SPECIFICATION ....................................................................................................5
4.2. ACQUISITION TIME (AVERAGED)....................................................................................5
4.3. RECEIVER ACCURACY....................................................................................................5
4.4. USE LIMITATION .............................................................................................................5
4.5. POWER SUPPLY...............................................................................................................5
4.6. OUTPUT AND INTERFACE................................................................................................6
4.7. PHYSICAL........................................................................................................................6
4.8. OTHER FUNCTIONS.........................................................................................................6
5. GETTING STARTED...........................................................................................................8
5.1. HARDWARE D ESCRIPTION ..............................................................................................9
5.2. SOFTWARE INSTALLATION............................................................................................12
5.3. INSTALLATION OF TESTI NG PROGRAM.........................................................................13
6. OPTIONAL ACCESSORIES.............................................................................................15
7. DRIVER INSTALLATION................................................................................................16
7.1 SYSTEM R EQUIREMENT................................................................................................16
7.2 INSTALLATION...............................................................................................................16
7.3 IMPORTANT...................................................................................................................16
8. WARRANTY.......................................................................................................................17
9. TROUBLE SHOOTING.....................................................................................................17
2
HOLUX GPSlim236 Wireless Bluetooth GPS Receiver Manual
1. Overview
(Fig.1)
The HOLUX Wireless Bluetooth GPS Receiver (Fig. 1) is a total
solution GPS receiver with Bluetooth, UART interface and built-in rechargeable battery
for high sensitivity to tracking signal. design is based on SiRF Star III low
power Architecture.
is a dual-function GPS receiver. Not only transmit satellite information
through the PDA or Notebook with Bluetooth interfaces but also is a G-Mouse GPS
receiver through a data cable to deliver satellite signal to the device without Bluetooth
interface.
This positioning application meets strict needs such as car navigation, mapping,
surveying, security, agriculture and so on. Only clear view of sky and certain power
supply are necessary to the unit. contacts to other device through Bluetooth
device, compatible interface of RS -232 or USB, and built-in recharge battery to save
satellite information such as the status of satellite signal, the last location, date and time
of last use.
With low power consumption, the tracks up to 20 satellites at a time,
re-acquires satellite signals in 100 ms and updates position data every second.
Trickle-Power allows the unit operates a fraction of the time and Push-to-Fix permits
user to have a quick position fix even though the receiver usually stays off.
3
HOLUX GPSlim236 Wireless Bluetooth GPS Receiver Manual
2. Packing List
Congratulations on your purchase of the GPSlim236 GPS Receiver. We hope it will
be useful to you for a long time. Before you begin, make sure that your package includes
the following items. If any of these items are missing, please contact your local HOLUX
dealer or distributor.
l HOLUX Wireless Bluetooth GPS receiver 1 Set
l Travel power supply / Cigarette adapter 1 Set
l Manual and Driver CD 1 Piece
l Quick guide 1 Piece
l Warranty card 1 Piece
3. Main functions
provides a series of functions. It is well suited to system integration and
users who use PDA, Notebook PC with Bluetooth device.
l Built in SiRF Star III Low power consumption chipset.
l 20 parallel satellite-tracking channels for fast acquisition and reacquisition.
l High speed signal acquisition using 200,000 time/frequency search channels.
l Built-in WAAS/EGNOS Demodulator without additional any hardware. Or use
the high-sensitive software to get the fast acquisition and reacquisition in the
urban, canyon and foliage environments.
l Compatible with Bluetooth Serial Port Profile (SPP) completely.
l Low power consumption. Built-in rechargeable and changeable Lithium-ion
battery without external power supply, and the working time lasts at least 10
hours.
l Provide Continue mode and Power saving mode for user’s requirement .
l Provide expand terminal contact to other system without Bluetooth device.
l Built-in rechargeable battery for memory and RTC backup and for fast Time To
First Fix (TTFF).
l Support NMEA0183 v2.2 data protocol and SiRF binary code.
l 4 colors LED to show the status of device.
l Active antenna connector for getting better satellites signal .
l FLASH based program memory. New software revisions upgradeable through
serial interface.
4
HOLUX GPSlim236 Wireless Bluetooth GPS Receiver Manual
l Small, sleek, and lightweight design easily fits in your hand.
l Over-Temperature protection
l Enhanced algorithms -SnapLock and SnapStart provide superior navigation,
performance in urban, canyon and foliage environments.
l For Car navigation, Marine navigation, Fleet management, AVL, Personal
navigation, Tracking System, and Mapping device application.
4. Technical Specification
4.1. Basic Specification
l Chipset：SiRF Star III chipset.
l Channels： 20 parallel satellite-tracking channels.
l Frequency： 1575.42 MHZ.
l Receiver： L1, C/A code.
4.2. Acquisition Time (averaged)
l Reacquisition： 0.1sec.
l Cold start： < 42 seconds.
l Warm start：< 38 seconds .
l Hot start： < 1 seconds
4.3. Receiver Accuracy
l Normal： 5-25 meters CEP without SA.
l Enable EGNOS or WAAS：
Position: < 2.2 meters, horizontal 95% of time
< 5 meters, Vertical 95% of time
l Velocity： within 0.1 meters / second
l Time： 1 microsecond synchronized GPS time
4.4. Use Limitation
l Altitude： < 18,000 meters (60,000 feet)
l Velocity: ：< 736 meters/ second ( 1000Knots)
l Acceleration： 4 G.
l Jerk： 20 meters / second, max
4.5. Power Supply
l External Voltage: 5VDC +/- 10%
l Batteries：
Main Power: Built -in rechargeable Lithium-ion for system power.
Backup Power: Rechargeable Lithium-ion battery for memory & RTC backup.
l Working voltage: 75-85mA (Normal mode).
30mA (Power Saving).
5
HOLUX GPSlim236 Wireless Bluetooth GPS Receiver Manual
l Working period (In Battery full power status):
> 10 hours on Continue mode.
> 16 hours on Power Saving mode.
l Protection circuit on should stop charging the cell when
over-temperature condition --50 occurs.
4.6. Output and Interface
l Output
I. Output protocol
Baud Rate： 38400 bps
Data bit ： 8
Parity： No
Stop bit ： 1
II. Format. NMEA0183 V2.2： GPGGA (1time/1 sec), GPGSA (1 time/ 5 sec.),
GPGSV (1time /5 sec.), GPRMC (1time /1 sec.), GPVTG (1 time/1 sec), (GLL,
or SiRF binary format for optional).
III. Datum： WGS84.
l Input/ Output Interface:
I. Compatible Bluetooth Serial Port Profile (SPP) , Version1.1 and class 2(up
to 10 meter range).
II. In/Out Port. GPS signal (Out)/Command(In) with CMOS/TTL Level 。Mini
USB Type B Connector and Cable option：
(a) GR230-A1(RS232 data cable)
(b) GR230-A2 (USB data cable)
(c) GR230-A3 (Mini USB port to PS2 port ).
l External Antenna interface:
3.0V input MMCX type active antenna connector
4.7. Physical
l Size： 46.3 × 67 × 19 mm
l Weight： < 56 g
l Operating Temperature ： -10 to + 60 (under the un-charging condition);
Charging Temperature 0 to + 45
l Storage Temperature： -20 to + 85
l Operating humidity： 5% to 95% No condensing
4.8. Other Functions
l Bluetooth frequency: 2.4 ~2.48GHZ
l Bluetooth Input Sensitivity: -80dbm
6
