Holmes HAOF12R User Manual

Owner ’s Guide

PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS

HAOF12R

Table Fan

PLEASE READ AND SAVE

THESE IMPORTANT

SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and
injury to persons, including the following:

1) Read all instructions before using the appliance.

2) To avoid fire or shock hazard, plug the appliance directly into a
120 V AC electrical outlet.

3) Keep the cord out of heavy traffic areas. DO NOT let the cord
hang over the edge of a table or counter. To avoid fire hazard,
NEVER put the cord under rugs, near heat registers, radiator,
stoves, or heaters.

4) To protect against electrical hazards, DO NOT immerse in water
or other liquids. Do not use near water.

5) Close supervision is necessary when any appliance is used by or
near children, or by disabled people.

6) Always unplug the fan before moving it, putting on or taking off
parts, cleaning, or whenever the fan is not in use. Be sure to
pull by the plug and not the cord.

7) Avoid contact with moving parts. DO NOT operate without fan
grills properly in place.

8) DO NOT operate any appliance with a damaged cord or plug,
if motor fan fails to rotate, after the appliance malfunctions,
or if it has been dropped or damaged in any manner. Return
appliance to manufacturer for examination, electrical or
mechanical adjustment, or repair.

9) DO NOT operate in the presence of explosive and/or flammable
fumes.

10) Use appliance only for intended household use as described in this
manual. Any other use not recommended by the manufacturer
may cause fire, electric shock, or injury to persons. The use of
attachments not recommended or sold by The Holmes Group may
cause hazards.

11) DO NOT use outdoors.

12) Always use on a dry, level surface.

13) Keep unit away from heated surfaces and open flames.

14) WARNING: To reduce the risk of fire or electric shock, DO NOT
use this fan with any solid-state speed control device.

15) DO NOT attempt to repair or adjust any electrical or mechanical
functions on this unit. Doing so will void your warranty. The
inside of the unit contains no user serviceable parts. All servicing
should be performed by qualified personnel only.

PLEASE READ AND SAVE

THESE IMPORTANT

SAFETY INSTRUCTIONS

ASSEMBLY INSTRUCTIONS

Your table fan comes completely assembled and is ready for
immediate use. Carefully unpack your fan, plug it in and enjoy.

A. FRONT GRILL
B. REAR GRILL (SEE FIGURE 2)
C. LOGO PLATE
D.FAN BLADE
E. CARRY HANDLE

(SEE FIGURE 2)

F. SPEED CONTROL KNOB

(SEE FIGURE 2)

G.OSCILATION CONTROL

KNOB (SEE FIGURE 2)

H.TILT ADJUSTMENT KNOB

(SEE FIGURE 2)

I. BASE

FIGURE 1

A

C

D

I

THIS PRODUCT IS EQUIPPED WITH A POLARIZED AC
(Alternating Current) PLUG (a plug having one blade
wider than the other). This plug will fit into the power
outlet only one way. If the plug does not fit fully into the
outlet, reverse the plug. If it still does not fit, contact
qualified personnel to install the proper outlet.

DO NOT DEFEAT THE SAFETY PURPOSE OF THIS

POLARIZED PLUG IN ANY WAY

OPERATING INSTRUCTIONS

Step 1: Set the fan base on a dry, level surface.
Step 2: Please make sure the speed control knob is in the off posi-

tion. Plug cord into any standard 120 volt A/C outlet.

Step 3: The SPEED is adjusted by moving the knob left or right to

one of the 3 desired settings (High, Med., and Low).

Step 4: The OSCILLATION control knob is located on the top of the

fan motor housing. To start oscillation, push control knob
down. To stop oscillation, pull control knob up.

ADJUSTMENT INSTRUCTIONS

Tilt Adjustment:

Step 1: Loosen the tilt-adjustment knob and move the fan head to the

desired angle. Once your fan is at the appropriate angle, tighten
the knob by turning clockwise.

CLEANING/MAINTENANCE INSTRUCTIONS

Follow these instructions to correctly and safely care for your Holmes
table fan. Please remember:

• Always unplug the fan before cleaning or disassembling.

• Do not allow water to drip on or into the fan motor housing.

• Do not use any of the following as a cleaner: gasoline, thinner,
or benzine.

Step 1: To access the fan blade, remove the front grill and then

unscrew the securing screw on the fan blade.

Step 2: Clean the fan blade, both front and rear grills with a soft

cloth moistened with a mild soap solution.

Step 3: Replace blade, tighten the fan blade by screwing the fan

blade back on, and securely fasten the front grill.

Fan Head and Base Cleaning

Using a soft, moist cloth, with or without a mild soap solution, care­fully clean the fan base and head. Please use caution around the
motor housing area. Do not allow the motor or other electrical com­ponents to be exposed to water.

FAN STORAGE

Your fan should be stored in the off-season fully assembled and we
recommend using the original (or appropriately sized) box. It is
important to keep it in a safe, dry location.

• Remember to protect the fan head from dust or moisture.

FIGURE 2

B

E

F

G

H

SERVICE INSTRUCTIONS

1. Do NOT attempt to repair or adjust any electrical or mechanical
functions on this unit. Doing so will void the warranty.

2. If you have any questions regarding this unit’s operation or believe
any repair is necessary, write to our Consumer Service Department.

3. If you need to exchange the unit, please return it in it’s original carton,
with a sales receipt, to the store you purchased it. If you are returning
the unit more than 30 days after the date of purchase, please see the
enclosed warranty.

4. If you have any other questions or comments, please write:

TheHolmesGroup Inc.
CONSUMER SERVICE DEPARTMENT
P.O. Box 769
Milford, MA 01757-0769

or visit our website at www.holmesproducts.com

For your own records, staple or attach your sales receipt to this manual.
Also, please take a moment to write the store name/location and date
purchased below.

STORE NAME:
LOCATION:
DATE PURCHASED:

(Staple Receipt Here)

THREE (3) YEAR LIMITED WARRANTY

SAVE THIS WARRANTY INFORMATION

A. The quality controls used in the manufacture of this Holmes product are to

ensure your satisfaction.
B. This Warranty applies only to the original purchaser of this product.
C. This Warranty applies ONLY to repair or replacement of any supplied or

manufactured parts of this product that, upon inspection by Holmes

authorized personnel, proves to have failed in normal use due to defects

in material or workmanship. Holmes will determine whether to repair or

replace the unit. This Warranty does not apply to installation expenses.
D. Operating this unit under conditions other than those recommended or at

voltages other than the voltage indicated on the unit, or attempting to

service or modify the unit, will render this WARRANTY VOID.

E. Unless otherwise proscribed by law, Holmes shall not be liable for

any personal injury, property or any incidental or consequential

damages of any kind (including water damage) resulting from

malfunctions, defects, misuse, improper installation or alteration

of this product.

F. All parts of this Holmes product are guaranteed for a period of 3 years as

follows:

1. Within the first 30 days from date of purchase, the store from which
you purchased your Holmes product should replace this product if it is
defective in material or workmanship (provided the store has in-stock
replacement.)

2. Within the first 3 years from date of purchase, subject to the conditions in
paragraph H, Holmes will repair or replace the product if it is defective in
material or workmanship providing it is returned to Holmes, freight
prepaid, with PROOF OF PURCHASE date, together with $7.50 for handling
and return packing/shipping charges.

G. If you have any problem with this product, please write our Consumer

Service Dept.

H. IMPORTANT Return INSTRUCTIONS Your warranty depends on your following

these instructions if you are returning the unit more than 30 days after the
date of purchase:

1. Carefully pack the item in its original carton or other suitable box to
avoid damage in shipping.

2. Before packing your unit for return; be sure to enclose:
a) your name, full address with zip code and telephone number,
b) a dated sales receipt or PROOF OF PURCHASE,
c) your $7.50 check for return packaging, and
d) the model number of the unit and the problem you are having.
(Enclose in an envelope and tape directly to the unit before the box is sealed.)

3. Holmes recommends you insure the package (as damage in shipment is
not covered by your warranty).

4. All shipping charges must be prepaid by you (as noted in paragraph F).

5. Mark the outside of your package:

HOLMES
THE HOLMES GROUP, INC.
CONSUMER RETURNS
32B SPUR DRIVE
ELPASO, TX 79906

SHIPPING AND HANDLING CHARGES: $7.50

This warranty gives you specific legal rights, and you may have other rights
which vary from state to state. The provisions of this warranty are in addition
to, and not a modification of, or subtraction from, the statutory warranties
and other rights and remedies contained in any applicable legislation. To the
extent that any provision of this warranty is inconsistent with any applicable
law, such provision shall be deemed voided or amended, as necessary, to
comply with such law.

Printed in ChinaHAOF12R01UM3
