DARK
TOAST
TOAS
T
BUN
BUN
LIGHT
LIGH
T
DARK
5
21
22
24
25
1
4
6
7
8
9
10
12
27
31
33
15
36
37
38
39
40
41
14
13
19
32
20
26
29
30
2
3
11
28
15
16
17
18
23
34
34
35
34
35
SOME ITEMS ARE INCLUDED FOR
ILLUSTRATIVE PURPOSES ONLY AND IN
CERTAIN INSTANCES MAY NOT BE AVAILABLE
STAR MANUFACTURING INTERNATIONAL, INC.
MODEL: ST04 & ST02 TOASTER
SK1622 REV. D 7/20/2006
9
PARTS LIST September 9, 2008, Rev. F
MODEL STO2 and STO4 TOASTER
Key
Number
1 2I-H7685 4 FEET
2 2C-08-07-0230 8 SCREW 8-32x17/32 ACHD
3 2P-9564 4 RUBBER BUTTON
4 A9-Z2084 (ST04) 1 BOTTOM PLATE
A9-Z2085 (ST02) 1 BOTTOM PLATE
A9-Z2240 (ST04G) 1 BTM PLT
A9-Z2241 (ST02G) 1 BTM PLT
5 A9-Z2101 (ST04) 1 CRUMB TRAY
A9-Z2102 (ST02) 1 CRUMB TRAY
6,7 2R-Z2055 (ST02/ST04) 1/2 KNOB – TIMER CONTROL WITH CAP INSERT
8 2E-Z2059 (ST02/ST04) 1/2 SWITCH S.P./S.T. 120V
2E-Z2139 (ST02/ST04) 1/2 SWITCH S.P./S.T.240V
9 2M-Z2507 (ST04) 1 FRONT LOGO DECAL
2M-Z2508 (ST02) 1 FRONT LOGO DECAL
10 2R-Z2506 (ST02/ST04) 1/2 KNOB CARRIAGE ARM
11 2C-Z2044 (STO2) 1 SCREW 6-20x1/2" PHIL PAN
2C-Z2044 (STO4) 2 SCREW 6-20x1/2" PHIL PAN
12 A9-Z2091 (ST04) 1 FRONT PLATE
A9-Z2092 (ST02) 1 FRONT PLATE
13 2E-Z2828 (ST02/ST04) 1/2 ELECT. TIMER 120V
2E-Z2125 (ST02/ST04) 1/2 ELECT. TIMER 240V
2E-Z2748 (ST04H) 2 ELECT. TIMER 240V
2E-Z4269 (ST04H-208V) 2 ELECT. TIMER 208V
14 2E-Z3007 (ST02/ST04) 1/2 MICRO SWITCH 20 AMP
15 2C-08-07-0240 (STO2) 2 SCREW 6-32x1/4" RHP STL NP
2C-08-07-0240 (STO4) 4 SCREW 6-32x1/4" RHP STL NP
16 2C-H8669 (STO2) 2 WASHER #6
2C-H8669 (STO4) 4 WASHER #6
17 2C-2553 (STO2) 2 NUT 6-32 HEX
2C-2553 (STO4) 4 NUT 6-32 HEX
18 2A-Z2072 (STO2) 1 SPACER
2A-Z2072 (STO4) 2 SPACER
19 2C-Z2054 1 CLAMP-THERMISTER
20 2E-Z2045 (ST02/ST04) 1/2 SOLENOID 120V
2E-Z2129 (ST02/ST04/ST04H) 1/2 SOLENOID 280/240V
21 A9-TO4015 (ST02/ST04) 1/2 TRIP LINK ASSY.
22 A9-TO4022 2 END PLATE ASSY.
23 2C-6349 12 SCREW #8X3/8 B THP STL NP
24 A9-Z2288 (ST04) 1 BARRIER BRCKT
25 A9-Z2082 (ST04) 1 BOTTOM
A9-Z2083 (ST02) 1 BOTTOM
26 2A-Z2073 (ST02/ST04) 2/4 GUIDE ROD ¼” DIA.
27 A9-TO4017 (ST02/ST04) 1/2 CARRIAGE ASSY.
28 2K-Z3039 (STO2) 4 BUSHING GUIDE
2K-Z3039 (STO4) 8 BUSHING GUIDE
Part
Number
Per
Unit
Description
Number
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Star Manufacturing International, Inc.
10
1
2
PARTS LIST September 9, 2008, Rev. F
MODELS STO2 and STO4 TOASTER
Key
Number
29 2P-Z2062 (ST02/ST04) 2/4 CARRIAGE RETURN SPRING
30 2P-Z2052 (ST02/ST04) 2/4 RETAINER RING
31 A9-Z2098 (ST02/ST04) 2/4 BREAD HOLDER
32 2P-Z2105 (ST02/ST04 1/2 SPRING LIFT CARRIAGE
33 A9-Z2086 (ST04) 1 FRNT. ELE. PLATE
A9-Z2087 (ST02) 1 FRNT. ELE. PLATE
34 2N-Z2051 (ST02/ST04) 2/4 HTG. ELEMENT (1 SIDE) (120V, 240V) & CUL
2N-Z2750 (ST04H-240V) 4 HTG. ELEMENT (1 SIDE) (120V)
2N-Z4271 (ST04H-208V) 4 HTG. ELEMENT (1SIDE) (104V)
35 2N-Z2050 (ST02/ST04) 1/2 HTG. ELEMENT (2 SIDE) (120V) & CUL
2N-Z2126 (ST02/ST04) 1/2 HTG. ELEMENT (2 SIDE) (240V)
2N-Z2749 (ST04H-240V) 2 HTG. ELEMENT (2 SIDE) (240V)
2N-Z4270 (ST04H-208V) 2 HTG. ELEMENT (2 SIDE) (208V)
36 2P-6475 1 CLIP-TY
37 A9-Z2095 (ST04) 1 WRAPPER
A9-Z2096 (ST02) 1 WRAPPER
38 A9-Z2088 (ST04) 1 BACK-ELE. PLATE
A9-Z2089 (ST02) 1 BACK-ELE. PLATE
39 A9-Z2093 (ST04) 1 BACK PLATE-ST04
A9-Z2094 (ST02) 1 BACK PLATE-ST02
40 2K-Y2968 1 STRAIN RELIEF-CORDSET
41 A9-TO4023 1 CORDSET 14/3 NEMA 5-15P 120V (UL MODEL)
A9-TO4024 1 CORDSET 14/3 NEMA 6-15P 208V & 240V
A9-TO4019 1 CORDSET 14/3 NEMA 5-20P 120V (CUL MODEL)
Part
Number
Description
Unit
Per
Number
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
2
2
Star Manufacturing International, Inc.
