Holman Q2 Specifications

®

®

®

®

®

CONVEYOR

TOASTER

MODEL

QCS2, QCSe2, RCS2 SERIES

QCS3, QCSe3 SERIES

Installation and

Operation

Instructions

2M-Z10651 Rev. D 12/2/2010

Q2-600H-208V

1

2

These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual
accompanying the appliance.

RETAIN THIS MANUAL FOR FUTURE REFERENCE

NOTICE

Using any part other than genuine Star factory supplied parts relieves the
manufacturer of all liability.

Star reserves the right to change specications and product design without

notice. Such revisions do not entitle the buyer to corresponding changes,
improvements, additions or replacements for previously purchased
equipment.

Due to periodic changes in designs, methods, procedures, policies and

regulations, the specications contained in this sheet are subject to change
without notice. While Star International Holdings Inc., Company exercises
good faith efforts to provide information that is accurate, we are not

responsible for errors or omissions in information provided or conclusions

reached as a result of using the specications. By using the information
provided, the user assumes all risks in connection with such use.

MAINTENANCE AND REPAIRS

Contact your local authorized service agent for service or required maintenance.
Please record the model number, serial number, voltage and purchase date in the area below and have it ready when

you call to ensure a faster service.

SAFETY SYMBOL

Model No.

Serial No.

Voltage

Purchase Date

Business

8:00 am to 4:30 p.m. Central Standard Time

Hours:
Telephone: [phone] Local [phone]
Fax: [phone] Local [phone]

E-mail [e-mail]

[e-mail]

[e-mail]

Website: www.star-mfg.com

Service Help Desk

Authorized Service Agent Listing

Reference the listing provided with the unit

or
for an updated listing go to:

Website: www.star-mfg.com
E-mail [e-mail]
Telephone: [phone] Local [phone]

Mailing Address: Star International Holdings Inc., Company

10 Sunnen Drive
St. Louis, MO 63143
U.S.A

2

TABLE OF CONTENTS

General Installation Data ......................................................4

Uncrating & Inspection .........................................................4

Assembly & Installation .......................................................4

Electrical Connection ............................................................4

QCS & RCS

Operation .............................................................................5

Cooking Procedures ............................................................5

Toaster Components ............................................................5

Daily Operation ...................................................................6

Operating Hints & Safety ....................................................6

QCSe & RCSe

QCSe Operation ..................................................................7

Start-up ................................................................................8

Daily Operation ...................................................................8

Operating Hints & Safety ....................................................8

Toaster Components ............................................................8

Programing

Conveyor Speed .................................................................9

Programing Values for Menu Items ...................................9

Cleaning ...............................................................................1

Maintenance Procedures ......................................................11

Trouble Shooting Guide .......................................................12

Warranty ...............................................................................13

Wiring Diagrams

QCS2 & 3, RCS2 & 3, wired series ...................................14

QCS2 & 3, RCS2 & 3, wired parallel ................................15

QCS2 & 3, RCS2 &3, 3 wired in series .............................16

QCS2, RCS2 w/fan switch series .......................................17

QCS2 & 3, RCS2 & 3, 3 wired in series w/bun mode .......18

QCSe, 4 wired in series ......................................................19

QCSe, 6 wired in series ......................................................20

QCSe, 6 wired in parallel ...................................................21

QCS3, 6 wired in series, with fuses ....................................22

Exploded View ....................................................................24

Parts List

QCS2, QCSe2 & RCS2, RCSe2 .....................................25 - 28

QCS3 & QCSe3 ..............................................................29 - 31

0

3

CAUTION

GENERAL INSTALLATION DATA

This equipment is designed and sold for commercial use only by personnel trained and experienced
in its operation and is not sold for consumer use in and around the home nor for use directly by the
general public in food service locations.

Before using your new equipment, read and understand all the instructions & labels associated with
the unit prior to putting it into operation. Make sure all people associated with its use understand the
units operation & safety before they use the unit.

All shipping containers should be checked for freight damage both visible and concealed. This
unit has been tested and carefully packaged to insure delivery of your unit in perfect condition. If
equipment is received in damaged condition, either apparent or concealed, a claim must be made
with the delivering carrier.

Concealed damage or loss - if damage or loss is not apparent until after equipment is unpacked, a
request for inspection of concealed damage must be made with carrier within 15 days. Be certain to
retain all contents plus external and internal packaging materials for inspection. The carrier will make
an inspection and will supply necessary claim forms.

INSPECTION & ASSEMBLY

UNCRATING AND INSPECTING

Unpack the unit and components from the shipping container. Remove all visible packing

material and those from inside the cooking chamber. If damage is discovered, le a claim

immediately with the carrier that handled the shipment. Do not operate the unit if it was
damaged during shipping.

CAUTION

WARNING

ASSEMBLY AND INSTALLATION

The unit was shipped fully assembled and ready to plug into a standard outlet specied for its voltage
and amp draw. If improper electrical supply is determined, contact a qualied electrician prior to using

the unit. Removal and replacement of the power cord and plug will void the warranty. For assistance,
contact your local authorized service agent for service or required maintenance.

Level unit using the adjustable feet under the unit (approximately 1/2" adjustment).

Before using the unit for the rst time, wipe down the exterior with a damp cloth.

Allow enough space around the toaster for adequate ventilation. Do not operate the unit without the
crumb tray properly positioned. Overheating and poor toasting may occur. Read all labels on the unit
and follow their instructions.

ELECTRICAL CONNECTION

Before making any electrical connection to this unit, check that the power supply is adequate for the
voltage, amperage and requirements stated on the rating plate.
A wiring diagram is included herewith.

Disconnect the unit from the power source before installing or removing any parts.
Be absolutely sure that the ground connection for the receptacle is properly wired. Do not connect

equipment to power without proper ground connections. Improper grounding may result in personal
injury or fatality.

DO NOT CUT OR REMOVE THIS PLUG OR GROUNDING PRONG FROM THE

PLUG.

WARNING

CONNECT/PLUG UNIT INTO DEDICATED A.C. LINE ONLY SPECIFIED ON THE

DATA PLATE OF THE UNIT.

4

CAUTION

Q

C

S

®

e

LOAD UP

CRUMB TRAY

POWER SAVER SWITCH

HEAT CONTROLS

SPEED CONTROL

FRONT

AIR INTAKE FAN

HIGH LIMIT RESET

POWER CORD

IL1386

OPERATION

ROTARY POWER SAVER SWITCH

For toasters equipped with a Rotary Power Saver Switch, turn clockwise or counterclockwise to get

in the following positions.

FULL POWER

When in this position your equipment is at full power and ready to use.

OFF ROTARY

Two off positions are provided, a single rotation to either direction will shut the unit off.

STANDBY

The standby position reduces the power consumption by 75%. Using this position during the quiet

times will save electricity, and keep the toaster warm. When needed, turn the switch to FULL
POWER. Recovery time is about 30 seconds.

CERTAIN SURFACES ARE EXTREMELY HOT DURING OPERATION AND CARE

SHOULD BE TAKEN WHILE USING THIS UNIT.

COOKING PROCEDURES

BREAD TOASTING

Some toasters are equipped with a swinging heat shutter at the toaster entrance. This shutter will
move out of the way as the product passes under it.

1) Turn the power saver to FULL POWER.

2) Set the conveyor speed to HIGH.

3) If your toaster is equipped with separate top and bottom heat controls set them both
at HIGH.

4) Allow warm up time of 5 to 10 minutes.

5) Place a sample product on the conveyor belt to test the settings.

•If toasting is too light, turn conveyor speed control counterclockwise to a slower speed.

•If toasting is too dark, turn heat control to a lower heat.

(NOTE: Some products may require adjustment of the top and bottom heat controls

in order to achieve the desired results)

TOASTER COMPONENTS

5

DAILY OPERATION

Q

C

S

®

e

Check the power cord to insure that it is plugged into a proper outlet.
Set the heat control knobs to desired temperature.

Always allow 10 minutes of preheat time before loading the unit with product. Failure to allow sufcient

preheat time will result in unsatisfactory cooking until the unit reaches operating temperature.

OPERATING HINTS AND SAFETY

Disconnect power to the unit with the switch at the end of each day of operation.

Do not leave the unit in operation without an attendant.

CAUTION

Turn Power Saver Switch to Standby during idle periods. It will take only a few minutes to
regain operating temperature.

Do not leave the unit at high temperature when not in use or during idle periods.

This will cause food particles and grease lm to carbonize.

6

QCSe & RCSe OPERATION

Q

C

S

®

e

The Holman QCSe conveyor toaster comes with pre-programmed factory default settings for TOAST,
MUFFINS, and BAGELS. The operator may change these setting at any time. A button labeled
OTHER is provided to allow the operator to program settings for additional product(s).

Press TOAST and TST will appear in the display.
Press MUFFIN and MUF will appear in the display.
Press BAGEL and BGL will appear in the display.
Press OTHER and OTH will appear in the display.
LIGHT and DARK buttons are used to change the conveyor

speeds when in toast, mufn, or bagel modes.

Pressing the (LIGHT) button once will increase the conveyor
speed by 15%. Pressing twice (XLIGHT) will increase the
conveyor speed by 30%.

Pressing the (DARK) button once will decrease the conveyor
speed by 10%. Pressing twice (XDARK) will decrease the
conveyor speed by 20%.

Note: After 60 seconds the conveyor speed will return to the pre­programmed setting.

The factory default settings are as follow:

TOAST AND OTHER BAGEL:

TOP HEAT 9 TOP HEAT 9
BOTTOM HEAT 9 BOTTOM HEAT 9

CONVEYOR 59 CONVEYOR 24

OTHER: POWER SAVER:

TOP HEAT 9 TIME (minutes) 60
BOTTOM HEAT 9 HEAT 5
CONVEYOR 59

The QCSe toaster is equipped with a Power Saver Switch
(SAVER) that reduces the power used by the toaster after a pre­programmed period of time. This Power Saver Switch has three
modes:

Unit is in pre-programmed power saving setting.

ON:
OFF: Power Saver mode is turned off.

O ON: Power Saver turns on when there has been no

AUT

activity for a programmed length of time.
The operator may adjust the level of power reduction for the saver

mode. (Note: conveyor may move slowly when in saver mode.)
Two buttons (+) and (-) are used when increasing or decreasing

the value of each programmable setting.
A red LED light located at the lower portion of the control panel

label will indicate if the value for top heat, bottom heat or conveyor
speed is being adjusted.

7

LOAD UP

CRUMB TRAY

CONTROLS

LCD DISPLAY

FRONT

AIR INTAKE FAN

HIGH LIMIT RESET

POWER CORD

IL1385

CAUTION

Q

C

S

®

e

CERTAIN SURFACES ARE EXTREMELY HOT DURING OPERATION AND CARE

SHOULD BE TAKEN WHILE USING THIS UNIT.

START UP

When the toaster has been plugged into a suitable outlet and power supply, the word OFF will be
displayed on the L.E.D. read out.

A. Press the ON/OFF button once to turn on the toaster. The toaster will now enter into pre-heat

and PREHT will be displayed (the elements will begin to glow but the conveyor and fan motor
will not turn on).

B. After one minute, the fan motor will turn on and the conveyor will begin turning at the

previously saved setting (for initial start up, the drive motor will operate at the factory default
setting).

C. After four minutes, the display will show the last used program selection i.e. TOAST,

BAGEL, MUFFIN or OTHER (for initial startup, TOAST will be the last program selected).

DAILY OPERATION

Check the power cord to insure that it is plugged into a proper outlet.
Press the ON/OFF button once to turn the toaster on.

Press the button a second time to turn the toaster off.

NOTE: When the toaster is turned off, the fan and conveyor motors will continue to run for ve

minutes. The words COOL and DOWN will be alternately displayed during that time. After ve
minutes, the word OFF will be displayed until the ON/OFF button is pressed again.

For units equipped with a POWER SAVER feature, the three operating modes are:

Unit has entered the pre-programmed level of power savings.

ON
OFF Power Saver feature is turned off.
AUTO If the toaster has been idle for a pre-set period of time, the unit enters Power Saver

mode until one of the menu buttons has been pressed.

Once the toaster has been pre-heated, the menu buttons can be pressed to change to TOAST,

BAGEL, MUFFIN, or OTHER.

OPERATING HINTS AND SAFETY

Disconnect power to the unit with the ON/OFF button at the end of each day of operation.
Do not leave the unit in operation without an attendant.
Do not leave the unit at high temperature when not in use or during idle periods. This will cause food

particles and grease lm to carbonize.

TOASTER COMPONENTS

8

PROGRAMING

Q

C

S

®

e

A. CONVEYOR SPEED (temporary setting)

The conveyor speed is programmable with a range from 0 to 99 with 0 being the slowest and 99

being the fastest. Each menu item can have independent conveyor speed settings.

The LIGHT and DARK buttons can be used to temporarily change the conveyor speed.

Pressing the LIGHT button once will increase the conveyor speed by 15%. The word

LIGHT will be displayed. Pressing twice will increase the conveyor speed by 30% and
XLIGHT will now be displayed.

Pressing the DARK button once will decrease the conveyor speed by 15%. The word

DARK will be displayed. Pressing twice will decrease the conveyor speed by 30% and

XDARK will now be displayed.
NOTE: After 60 seconds, the conveyor speed will return to the pre-programmed setting.
WHEN USING THE LIGHT AND DARK BUTTONS TO ADJUST THE CONVEYOR

SPEED FOR A SINGLE ORDER OF PRODUCT, IT IS IMPORTANT TO REMEMBER

TO ALLOW THE PRODUCT ALREADY IN THE TOASTER TO EXIT BEFORE

CHANGING THE SPEED SETTING.

B.

PROGRAMING VALUES FOR MENU ITEMS

To make a program change to the top heat, bottom heat, or conveyor speed, you must rst be in the

menu item you want changed. Example: to change the programmed conveyor speed for bagels, the
display must read BAGEL. To change the programmed conveyor speed for TOAST, the display must
read TOAST and so on for each menu item.

1) Select the menu item you want to change i.e. TOAST, MUFFIN, BAGEL or OTHER.

2) Press and hold both ( + ) AND ( - ) buttons for 3 seconds until the display goes
blank, release the buttons and the display will show three characters for the menu
item elected and the last two characters for the current value setting, i.e. TST, MUF,
BGL and OTH. The red L.E.D. light for top heat at the bottom of the label will ash.

3) Press the ( + ) or ( - ) buttons to increase or decrease the setting for the top heat.

4) Press the button for the menu button again and the red L.E.D. for the bottom heat

will ash.

5) Press the ( + ) or ( - ) buttons to increase or decrease the setting for the bottom heat.

6) Press the button for the menu button again and the red L.E.D. for the conveyor

speed will ash.

7) Press the ( + ) or ( - ) buttons to increase or decrease the setting for the conveyor
speed.

8) To skip one feature setting with out making any changes, press the menu item button

one time and the red L.E.D. light for the next item will now ash.

9) To change the POWER SAVER values press the SAVER button or to save your new
setting(s), and exit the program mode press the menu button.

10) The last two characters in the display will show MN for minutes.

11) The rst three characters will be numerical to represent the time setting.

12) Press the ( + ) or ( - ) buttons to increase or decrease the setting for the savor mode
time. The minimum value is 15 minutes to maximum value of 480 minutes.

13) Press the SAVER button to change the power reduction using the ( + ) or ( - ) buttons
to increase or decrease the setting.

14) Press the POWER SAVER button to save changes and to exit.

9

CLEAN

OPERATE

WARNING

Q

C

S

®

e

Q

C

S

®

e

CLEANING

Preventive maintenance for your Holman toaster consists of the following recommended cleaning
procedures. To keep your toaster in its top operating condition, these steps should be performed on a
daily or weekly as indicated.

A. Clean air intake on bottom of unit.
B. For lightly soiled conveyor belts, turn conveyor speed control to fastest setting (100) and

wipe with a damp cloth (daily) For heavily soiled conveyors, turn conveyor speed control to
fastest setting and wipe with a light abrasive pad (as needed).

C. Turn main power saver switch to the OFF position. Disconnect unit from power source.
D. After the unit cools, remove interior crumb tray (as shown below) and clean.

Slide crumb tray back into position.

E. Wipe exterior surface of unit.

DO NOT IMMERSE OR LET THE UNIT

STAND IN WATER.

DO NOT HOSE DOWN THE UNIT OR THE

TABLE/COUNTER IF THE UNIT IS ON THE
TABLE/COUNTER.

KEEP AWAY FROM RUNNING WATER.

CRUMB TRAY REMOVAL

10

MAINTENANCE PROCEDURES

1/4”

A. REPLACING HEATER TUBES

1) DISCONNECT UNIT FROM POWER SOURCE.

2) Remove the enclosure.

3) Remove heater tube wire from terminal block connection, keeping top and
bottom wires separate.

4) Lift heater tube retainers by loosening retaining screws and sliding the retainer plate up.
Hand tighten the plate to hold it up so the heater tubes will slide out freely.

5) Gently, pull defective heater tube out of unit.

6) Gently, put new heater tube into unit.

7) Loosen retainer screws and slide the retainer back into place. Tighten the screw to
secure the retainer in place over the ends of the heater tubes.

B. REPLACING FAN MOTOR

1) DISCONNECT UNIT FROM POWER SOURCE.

2) Remove screws from the enclosure and the back panel at rear of unit.

3) Remove the enclosure and the back panel.

4) Unplug power supply cord from fan motor.

5) Remove (4) screws, which hold fan motor and grill to bottom of unit and remove fan.

6) Put replacement motor and grill in place and secure to the bottom of unit with screws.

7) Reconnect power supply cord to fan motor.

8) Replace back panel and enclosure. Fasten with screws removed in step 2.

C. REPLACING BELT DRIVE MOTOR

1) DISCONNECT UNIT FROM POWER SOURCE.

2) Remove enclosure and back panel.

3) Remove sprocket from motor shaft, using an Allen wrench and loosening the set-screw.

4) Remove the wire from terminal block connecting the drive motor to internal wiring.
On units rated 208 or 240 volts, note which color leads are being used for these connections
and which lead is capped with white tape. The new motor should use the same arrangement.

5) Remove screws holding motor in place and remove motor from unit.

6) Put new motor in place and attach loosely with mounting screws.

7) Replace sprocket on motor shaft.

NOTE: The two sprockets should line up parallel with each other, so the chain does not twist
any during operation. Also the hub gets installed closets to the motor.

8) Slide motor until the drive chain has about 1/4” slack when lightly pushed at the center of its top
open run. See chain tensioning illustration.

9) Tighten screws to secure motor.

10) Rewire leads same as removed in step 4.

11) Replace side panel and control box cover.

D. CLEANING AIR INTAKE ONCE A WEEK

1) DISCONNECT UNIT FROM POWER SOURCE.

2) Place unit on its backside.

3) Use a vacuum cleaner and or a damp cloth to clean
the air intake. This procedure should be done at least once a week.

E. LUBRICATE THE CHAIN & SPROCKETS EVERY 6 MONTHS

1) DISCONNECT UNIT FROM POWER SOURCE.

2) Remove enclosure exposing chain drive.

3) Using an extreme pressure, synthetic chain lubricant with a
temperature range up to 400°F. Apply liberally onto chain
and sprockets. This grease is available as part no. 1P-Z8914.

4) Replace enclosure, Reconnect power source and test unit.

11

QCS/RCS Chain Tension

TROUBLESHOOTING GUIDE

A. UNIT WILL NOT HEAT, CONVEYOR BELT WILL NOT MOVE.

1) Be sure the main circuit breaker is switched to the ON position.

2) Check to see if the toaster is plugged in and all controls are turned to the ON position.

B. UNIT HAS HEAT ONLY ON ONE SIDE, CONVEYOR BELT TURNS FREELY.

1) Call the Star Service Help Desk at 1-800-807-9054, as heating element may need replacing.

C. CONVEYOR WILL NOT TURN, UNIT HEATS PROPERLY.

To check for mechanical binding:

1) DISCONNECT UNIT FROM POWER SOURCE.

2) Remove 2 screws holding enclosure to the bottom of the unit.

3) Set unit on the legs and remove 4 screws on the back of the toaster.

4) Slide the enclosure off the unit and remove the back panel.

5) Loosen the four screws that hold the drive motor in place.

6) Slide the motor up allowing the drive chain to be removed from the sprockets.

7) Move the conveyor belt by hand to check for mechanical binding. If conveyor moves freely,
call the Star Service Help Desk at 1-800-807-9054, as the drive motor and/or speed control
may need replacing.

8) Replace the enclosure by sliding it forward towards the front of the unit.
The front edge of the enclosure will slide beneath the toaster front.

D. HEAT LIMIT SWITCH (RESET)

Your Holman conveyor toaster is equipped with an automatically activated heat limit switch that
interrupts the heater tube connections if the ambient temperature in the control box exceeds
190°F (88C). This switch can be reset manually by pushing the red button under the toaster as
shown in the Toaster Components Illustration on Page 5 & 8.

1) DISCONNECT UNIT FROM POWER SOURCE.

2) Check to see if air intake area in the bottom center of the control box cover is free of dust,
grease or other obstructions.

3) Check if crumb tray is in place. NEVER OPERATE UNIT WITHOUT CRUMB TRAY IN PLACE
AS THIS CAUSES OVERHEATING IN THE CONTROL BOX.

4) If no obstructions to the airow can be found and if the crumb tray is in place,
call the Star Service Help Desk at 1-800-807-9054 for assistance.

E. CONVEYOR TURNS AT ONE SPEED REGARDLESS OF SPEED
CONTROL SETTING.

1) Call the Star Service Help Desk at 1-800-807-9054, as speed control should be replaced.

F. PRODUCT STICKING TO CONVEYOR OR SLIDE

Your Holman conveyor toaster is designed to toast product that is at current room temperature.
DO NOT attempt to put frozen, refrigerated, or any butter or a butter substitute material in the
toaster. Doing so may cause it to come out doughy or very moist, as well as possibly sticking to
parts of the unit.

1) Follow the cleaning procedures listed on page 10.

12

2M-4497-2 10/2010

The foregoing warranty is in lieu of any and all other warranties expressed or implied and constitutes the entire warranty.

FOR ASSISTANCE

Should you need any assistance regarding the Operation or Maintenance of any Star equipment; write, phone, fax or email our Service Department.

In all correspondence mention the Model number and the Serial number of your unit, and the voltage or type of gas you are using.

ALL:
* Pop-Up Toasters
* Butter Dispensers
* Pretzel Merchandisers

(Model 16PD-A Only)

* Pastry Display Cabinets
* Nacho Chip Merchandisers
* Accessories of any kind
* Sneeze Guards
* Pizza Ovens

(Model PO12 Only)

* Heat Lamps
* Pumps-Manual

Visit our Website at: www.star-mfg.com Email: [e-mail]

THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL

This unit has been tested for proper operation before leaving our plant to insure delivery of your unit in perfect condition. However, there are instances in
which the unit may be damaged in transit. In the event you discover any type of damage to your product upon receipt, you must immediately contact the
transportation company who delivered the item to you and initiate your claim with same. If this procedure is not followed, it may affect the warranty status of
the unit.

LIMITED EQUIPMENT WARRANTY

All workmanship and material in Star products have a one (

1) year limited warranty on parts & labor in the United States and Canada. Such warranty is limited

to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited to the repair
of defects without charge, by the factory authorized service agency or one of its sub-agencies. Models that are considered portable (see below) should be taken
to the closest Star service agency, transportation prepaid.

> Star will not assume any responsibility for loss of revenue.
> On all shipments outside the United States and Canada, see International Warranty.
* The warranty period for the JetStar six (6) ounce & Super JetStar eight (8) ounce series popcorn machines is two (2) years.
* The warranty period for the Chrome-Max Griddles is ve (5) years on the griddle surface. See detailed warranty provided with unit.
* The warranty period for Teon/Dura-Tec coatings is one year under normal use and reasonable care. This warranty does not apply if damage occurs to

Teon/Dura-Tec coatings from improper cleaning, maintenance, use of metallic utensils, or abrasive cleaners, abrasive pads, product identiers and

point-of-sale attachments, or any other non-food object tha comes in continuous contact with the roller coating. This warranty does not apply to the
“non-stick” properties of such materials.

> This warranty does not apply to "Special Products" but to regular catalog items only. Star's warranty on "Special Products" is six (6) months on parts

and ninety (90) days on labor.

> This warranty does not apply to any item that is disassembled or tampered with for any purpose other than repair by a Star Authorized Service Center or

the Service Center's sub-agency.

> This warranty does not apply if damage occurs from improper installation, misuse, wrong voltage, wrong gas or operated contrary to the Installation and

Operating instructions.

> This warranty is not valid on Conveyor Ovens unless a "start-up/check-out" has been performed by a Factory Authorized Technician.

PARTS WARRANTY

Parts that are sold to repair out of warranty equipment are warranted for ninety (90) days. The part only is warranted. Labor to replace the part is chargeable to
the customer.

SERVICES NOT COVERED BY WARRANTY

PORTABLE EQUIPMENT

Star will not honor service bills that include travel time and mileage charges for servicing any products considered "Portable" including items listed below.
These products should be taken to the Service Agency for repair:

1. Travel time and mileage rendered beyond the 50 mile radius limit

2. Mileage and travel time on portable equipment (see below)

3. Labor to replace such items that can be replaced easily during a daily cleaning
routine, ie; removable kettles on fryers, knobs, grease drawers on griddles, etc.

4. Installation of equipment

5. Damages due to improper installation

6. Damages from abuse or misuse

7. Operated contrary to the Operating and Installation Instructions

8. Cleaning of equipment

9. Seasoning of griddle plates

1

0. Voltage conversions

1

1. Gas conversions

12

. Pilot light adjustment

13

. Miscellaneous adjustments

1

4. Thermostat calibration and by-pass adjustment

15. Resetting of circuit breakers or safety controls or reset buttons

16. Replacement of bulbs

17. Replacement of fuses

18. Repair of damage created during transit, delivery, &
installation OR created by acts of God

* The Model 510FD Fryer.
* The Model 526TOA Toaster Oven.
* The Model J4R, 4 oz. Popcorn Machine.
* The Model 518CMA & 526CMA Cheese Melter.
* The Model 12MC & 15MC & 18MCP Hot Food Merchandisers.
* The Model 12NCPW & 15NCPW Nacho Chip/Popcorn Warmer.
* All Hot Dog Equipment except Roller Grills & Drawer Bun Warmers.
* All Nacho Cheese Warmers except Model 11WLA Series Nacho Cheese Warmer.
* All Condiment Dispensers except the Model HPD & SPD Series Dispenser.
* All Specialty Food Warmers except Model 130R, 11RW Series, and 11WSA Series.
* All QCS/RCS Series Toasters except Model QCS3 & RCS3 Series.
* All Fast Steamer Models except Direct Connect Series.

13

FAN MOTOR

POWER SAVER

3

1

RESET/HIGH LIMIT

BOTTOM

4

2

HEAT

MOTOR

DRIVE

H1

PILOT

L1

H2

L2

14GA CORD

POWER SUPPLY

PILOT

H1

L1

H2

L2

CONTROL

SPEED

CONTROL SIDE

LEFT SIDE

BOTTOM HEAT

TOP
HEAT

WHITE

3 BLACK

BLACK

WHITE

BLACK

BLUE FOR 120 & 240V

1 BLACK

WHITE

BLACK

8 WHITE

6

11

12

13

10

WHITE FOR 208V

5 BLACK

7 BLACK

MOTOR WIRE

IS 18GA

GND

BLUE

2

4

WHITE

9

BLACK

BLACK

WHITE

14
WHITE

WHITE

BLACK

TOP HEAT

(OPTIONAL ELEMENTS ARE SHOWN HIDDEN)

15
BLACK

®

MODEL:

QCS2 & 3 Wired Series

RCS2 & 3 Wired Series

THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.

NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.

SK2240 Rev - 7/2007

14

FAN MOTOR

POWER SAVER

3

1

RESET/HIGH LIMIT

BOTTOM

4

2

HEAT

MOTOR

DRIVE

H1

PILOT

L1

H2

L2

14GA CORD

POWER SUPPLY

PILOT

H1

L1

H2

L2

CONTROL

SPEED

CONTROL SIDE

LEFT SIDE

2E-Z10406

BOTTOM HEAT

TOP HEAT

TOP
HEAT

WHITE

3 BLACK

WHITE

BLACK

BLUE FOR 120 & 240V

1 BLACK

WHITE

BLACK

8 WHITE

6

11 BLACK

13 BLACK

12

10

ALL WIRES ARE 12 CA UOS

WHITE FOR 208V

1N-E2010 12GA 150C BLACK
1N-E2011 12GA 150C WHITE

5 BLACK

7 BLACK

MOTOR WIRE

IS 18GA

GND

BLUE

2

4

WHITE

9

BLACK

WHITE

WHITE

15 BLACK

14
WHITE

2E-Z10406

(OPTIONAL ELEMENTS ARE SHOWN HIDDEN)

(OPTIONAL ELEMENTS ARE SHOWN HIDDEN)

®

MODEL:

QCS2 & 3 Wired Parallel

RCS2 & 3 Wired Parallel

THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.

NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.

SK2241 Rev - 7/2007

15

®

FAN MOTOR

POWER SAVER

3

1

RESET/HIGH LIMIT

BOTTOM

4

2

HEAT

MOTOR

DRIVE

H1

PILOT

L1

H2

L2

14GA CORD

POWER SUPPLY

PILOT

H1

L1

H2

L2

CONTROL

SPEED

CONTROL SIDE

LEFT SIDE

2E-Z10406

BOTTOM HEAT

TOP HEAT

TOP
HEAT

WHITE

3 BLACK

WHITE

BLACK

BLUE FOR 120 & 240V

1 BLACK

WHITE

BLACK

8 WHITE

6

11 BLACK

13 BLACK

12

10

ALL WIRES ARE 12 CA UOS

WHITE FOR 208V

1N-E2010 12GA 150C BLACK
1N-E2011 12GA 150C WHITE

5 BLACK

7 BLACK

MOTOR WIRE

IS 18GA

GND

BLUE

2

4

WHITE

9

BLACK

WHITE

WHITE

15 BLACK

14
WHITE

2E-Z10406

Ref: SOW# 2E-Z10380

MODEL:

QCS2 & 3, 3 Wired in Series

RCS2 & 3, 3 Wired in Series

THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.

NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.

SK2242 Rev - 7/2007

16

FAN MOTOR

POWER SAVER

3

1

RESET/HIGH LIMIT

4

2

MOTOR

DRIVE

14GA CORD

POWER SUPPLY

CONTROL

SPEED

CONTROL SIDE

LEFT SIDE

2E-Z1O406

BOTTOM HEAT

WHITE

3 BLACK

12 BLACK

WHITE

BLACK

BLUE FOR 120 & 240V

1 BLACK

WHITE

BLACK

9 BLACK

11

8

10

ALL WIRES ARE 14 CA UOS

WHITE FOR 208V

1N-E2020 14GA 150C BLACK
1N-E2021 14GA 150C WHITE

5 WHITE

MOTOR WIRE

IS 18GA

GND

BLUE

2

4

WHITE

WHITE

2E-Z10406

BLACK

FRONT HEAT

MIDDLE HEAT

FAN SWITCH

7 BLACK

6 WHITE

®

MODEL:

QCS2 & w/Fan Switch, Series

RCS2 & w/Fan Switch, Series

THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.

NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.

SK2243 Rev - 7/2007

17

®

SERIES HEATER TUBES

ALL WIRES ARE 12 CA UOS
1N-E2010 12GA 150C BLACK
1N-E2011 12GA 150C WHITE

MODEL:

QCS2 & 3, Wired Series w/ Bun Mode & Fuses

RCS2 & 3 Wired Series w/ Bun Mode & Fuses

THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.

NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.

SK2244 Rev A 4/14/08

FAN MOTOR

POWER SAVER

3

1

RESET/HIGH LIMIT

BOTTOM

4

2

HEAT

MOTOR

DRIVE

H1

PILOT

L1

H2

L2

14GA CORD

POWER SUPPLY

PILOT

H1

L1

H2

L2

CONTROL

SPEED

LEFT SIDE

BOTTOM HEAT

TOP HEAT

TOP
HEAT

MOTOR WIRE

IS 18GA

BUN MODE

CONTROL SIDE

3 BLACK

4 WHITE

BLUE FOR 120 & 240V

1 BLACK

WHITE

BLACK

8 WHITE

6

13 BLACK

12 WHITE

10

WHITE FOR 208V

5 BLACK

GND

WHITE

9

BLACK

WHITE

14 WHITE

2E-Z10406

11 BLACK

BLACK

17

BLACK

18

WHITE

15

BLACK

16

WHITE

BLACK

7

FUSE

FUSE

20 BLACK

3 BLACK

14 WHITE

2 WHITE

BLACK

4 WHITE

2 WHITE

WHITE OR BLUE

18

®

MODEL:

QCSe 4 Tube wired Series

THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.

NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.

SK2282 Rev - 7/2007

4

WHITE

3

BLACK

2

BLACK

1

BLACK

5

BLACK

7

BLACK

8 WHITE

6

WHITE

QCSe

OT1

HT1

HB1

F1

M1

L1

120V

OT2

F2

L2

M2

120V

240V

240V

HT2

HB2

TOP HEAT

BOTTOM HEAT

19

MODEL:

QCSe 6 Tube wired Series

THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.

NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.

®

SK2283 Rev - 7/2007

4

WHITE

3

BLACK

2

BLACK

1

BLACK

5

BLACK

7

BLACK

8 WHITE

6

WHITE

TOP HEAT

BOTTOM HEAT

QCSe

OT1

HT1

HB1

F1

M1

L1

120V

OT2

F2

L2

M2

120V

240V

240V

HT2

HB2

20

4

WHITE

3

BLACK

2

WHITE

1

BLACK

5

BLACK

7

BLACK

8 WHITE

6

WHITE

QCSe

OT1

HT1

HB1

F1

M1

L1

120V

OT2

F2

L2

M2

120V

240V

240V

HT2

HB2

BOTTOM HEAT

TOP HEAT

MODEL:

QCSe 6 Tube wired Parallel

THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.

NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.

®

SK2284 Rev - 7/2007

21

®

SK2365 REV. - 4-14-08

CERTAIN INSTANCES MAY NOT BE AVAILABLE

ILLUSTRATIVE PURPOSES ONLY AND IN

SOME ITEMS ARE INCLUDED FOR

QCS-3, 6 ELEMENTS
WIRED SERIES WITH
FUSES

FAN MOTOR

RESET/HIGH LIMIT

BOTTOM

4

2

HEAT

MOTOR

DRIVE

H1

PILOT

L1

H2

L2

14GA CORD

POWER SUPPLY

PILOT

H1

L1

H2

L2

CONTROL

SPEED

CONTROL SIDE

LEFT SIDE

BOTTOM HEAT

TOP HEAT

TOP
HEAT

3 BLACK

4 WHITE

BLACK

1 BLACK

WHITE

BLACK

6

11 BLACK

13 BLACK

12

10

WHITE FOR 208V

5 BLACK

7 BLACK

MOTOR WIRE

IS 18GA

GND

WHITE OR BLUE

WHITE

9

BLACK

WHITE

WHITE

15 BLACK

FUSE

FUSE

2 WHITE

4 WHITE

14 WHITE

BLACK

16 WHITE

1

3

8 WHITE

22

4645

1

2

3

4

5

6

7

18

17

8

9

10

12

13

14

24

15

16

19

20

21

43

44

22
23

25

26

27

Certain Models or

Q2-3KL-KIT

28

29

30

31

32

33

34

35

36

37

40

14

15

41

42

8

38

39

11

®

SK2297

Rev.B 4/24/08

Model

:

Q2/Q2E/RCS2/Q3/Q3E Conveyor Toaster

This drawing contains information confidential
to Star Manufacturing International, Inc.
No reproduction or disclosure of its

CERTAIN INSTANCES MAY NOT BE AVAILABLE

ILLUSTRATIVE PURPOSES ONLY AND IN

SOME ITEMS ARE INCLUDED FOR

contents is permitted.

23

PARTS LIST January 11, 2011, Rev. D

Models: Q2-500-120V, Q2E-500-120V, Q2-500-CUL20, Q2-600H-CE, Q2-600H-UK, Q2-600HF-208, Q2-600H-208/220/240V,

Q2-600HS-208, Q2E-600H-208/240V, Q2-800-208/220/240V, Q2-800-240UK, Q2-800-230CE, Q2E-800-208/240V,
Q2-1200B-208/240V, R2-12BSZ-208/240V, R2--1200-208/240V, R2-600HJ-208/240V, R2-800-208V

Fig No Part No. Qty Description Application

1 HC-120258 1 ENCLOSURE ASSY - QCS-2 ALL

Q2-800-208/220/240V, Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-

HB-120270

2

HB-120280 BAFFLE ASSEMBLY, HIGH

3 2R-Z8879 1 2-5/8” DIA. FAN BLACK CW ALL

HA-120243
HB-120240 MOTOR ASSY 120V

4

HB-120262 MOTOR ASSY 208-240V

2U-200559

5

2U-200560 FAN 240V

2U-200561 MOTOR, FAN240V 23BTM Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-1200B-208/240V
6 HC-Z10412 1 BACK PANEL QCS-2 ALL
7 2A-202900 1 SHAFT, T710 DRIVE ALL

HA-112261
8

HA-112263 BEARING ASSY, PTFE/BRONZE Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-1200B-208/240V
9 2P-Z8779 1 SPROCKET, 25P-11T .313 ID ALL

2P-150013

10

2P-150015 CHAIN DRIVE #25 Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-1200B-208/240V

TOP BAFFLE ASSY QCS-2 LOW

1

MTR, ASSY QCS, 220/230/240 Q2-600H-CE, Q2-600H-UK, Q2-800-240UK, Q2-800-230CE

1

FAN 120V Q2E-500-120V, Q2E-500CUL20

1

BEARING ASSY, 5/16 TEFLON

2

DRIVE CHAIN #25

1

1200B-208/240V, R2-600HJ-208/240V, Q2-500-120V, Q2-500-CUL20, Q2E­500-120V, Q2E-500CUL20, Q2-800-240UK

Q2-600H-208/220/240V , Q2E-600H-208/240V, Q2E-800-208/240V, Q2­600H-CE

Q2-500-120V, Q2-500-CUL20, Q2E-500-120V, Q2E-500CUL20, R2E-500­120V

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-1200B-208/240V,
R2-12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ-208/240V, Q2E-600H­208V, Q2-800-240UK, R2E-800-208V

Q2-600H-208/220/240V, Q2-800-208/220/240V, R2-600HJ-208/240V, Q2E­600H-208V, Q2E-800-208/240V, Q2-500-120V, Q2-500-CUL20, Q2E-500­120V, Q2-600H-CE, Q2-600H-UK

Q2-600H-208/220/240V, Q2-800-208/220/240V, R2-600HJ-208/240V, Q2E­600H-208V, Q2E-800-208/240V, Q2-500-120V, Q2-500-CUL20, Q2E-500­120V, Q2E-500CUL20, Q2-600H-CE, Q2-600H-UK

Q2-600H-208/220/240V, Q2-800-208/220/240V, R2-600HJ-208/240V, Q2E­600H-208V, Q2E-800-208/240V, Q2-500-120V, Q2-500-CUL20, Q2E-500­120V, Q2E-500CUL20

CONVEYOR TOASTERS

Q2-600H-208/220/240V, Q2-800-208/220/240V, R2-600HJ-208/240V, Q2E-

2P-200645

11

2P-200648 SPROCKET, 25B32 X 5/16 Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-1200B-208/240V

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF

Some items are included for illustrative purposes only and in certain instances may not be available.

SPROCKET, 25B17 X 5/16”

1

600H-208V, Q2E-800-208/240V, Q2-500-120V, Q2-500-CUL20, Q2E-500­120V, Q2E-500CUL20, Q2-600H-CE, Q2-600H-UK

24

1
4

PARTS LIST January 11, 2011, Rev. D

Models: Q2-500-120V, Q2E-500-120V, Q2-500-CUL20, Q2-600H-CE, Q2-600H-UK, Q2-600HF-208, Q2-600H-208/220/240V,

Q2-600HS-208, Q2E-600H-208/240V, Q2-800-208/220/240V, Q2-800-240UK, Q2-800-230CE, Q2E-800-208/240V,
Q2-1200B-208/240V, R2-12BSZ-208/240V, R2--1200-208/240V, R2-600HJ-208/240V, R2-800-208V

Fig No Part No. Qty Description Application

2N-209100 4 ELEMENT, METAL 120V 430W R2E-500-120V

2N-209112

2N-209114 SERPENTINE ELEMENT RCS R2-12BSZ-208V, R2-1200B-208V

2N-209194 ELEMENT METAL, 200W/120V R2-12BSZ-240V, R2-1200B-240V

2N-209198 ELEMENT METAL, 200W/104V R2-12BSZ-208V, R2-1200B-208V

2N-209199

2N-209216 ELEMENT, METAL, 500W, 120V R2-600HJ-240V

2N-209197 ELEMENT METAL, 700W/104V R2-800-208V, R2-800H-208V, R2E-800-208V

12

HO-197842 HEATERTUBE, QUARTZ

HO-197842 6 HEATERTUBE, QUARTZ Q2-500-120V, Q2E-500-120V, Q2E-500CUL20

HG-198062

HG-198064 HEATERTUBE, QCS-2-1200B Q2-1200B-240V

HO-197841 HEATERTUBE, QUARTZ

HO-197844 HEATERTUBE, QUARTZ Q2-600H-220V, Q2-800-220V, Q2E-600H-208V, Q2-600H-CE

HC-Z10390

HC-Z10440 ELEMENT RETAINER, RIGHT Q2-1200B-208/240V

13

HC-Z10443 HEATER TUBE RETAINER R2-12BSZ-208/240V, R2-1200B-208/240V

HC-Z11288
HB-Z10857
HC-Z10388 ELEMENT GUIDE PLATE

14

HC-Z10439 ELEMENT GUIDE PLATE 1200 Q2-1200B-208/240V
HC-Z10442 ELEMENT GUIDE PLATE SERP R2-12BSZ-208/240V, R2-1200B-208/240V,

15 2E-Z10406

16 2E-Z9736 1 TERMINAL BLOCK - POWER

ELEMENT, SERPENTINE, RCS R2-12BSZ-240V, R2-1200B-240V

2

METAL ELEMENT, 500W, 104V R2-600HJ-208V

4

Q2-600H-240V, Q2-800-240V, Q2E-600H-208V, Q2E-600H-240V, Q2-600H­UK, Q2-800-240UK

HEATERTUBE, QCS-2-1200B Q2-1200B-208V

4

ELEMENT RETAINER, RIGHT
QCS

1

1

RETAINER, RCS ELEMENT

2 R2-800, R2E-500, R2E-800

ELEMENT GUIDE PLATE Q2-500-120V, Q2-500-CUL20, Q2E-500-120V, Q2E-500CUL20

2

2

TERMINAL BLOCK 4 POS.

1 Q2E-600H-208/240V, Q2E-800-208/240V

Q2-600H-208V, Q2-800-208V, Q2E-600H-208V, Q2E-600H-208V, Q2E-800­208V, Q2-500-120V, Q2-500-CUL20

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2E-600H-208V, Q2E-800­208/240V, R2-600H, R2-800

R2-600H, R2-600HJ

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2E-600H-208V, Q2E-800­208/240V, Q2-600H-CE, Q2-600H-UK, R2-800

Q2E-300H-120, Q2E-500-120V, Q2E-500CUL20, Q2-600H-208/220/240V,
Q2-800-208/220/240V, Q2-1200B-208/240V, R2-12BSZ-208/240V,
R2-1200B-208/240V, Q2-500-120V, Q2-500-CUL20, Q2E-500-120V, Q2E­500CUL20, Q2-600H-CE, Q2-600H-UK, R2E-500-120V

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-1200B-208/240V,
R2-12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ-208/240V, Q2E-600H­208V, Q2E-800-208/240, Q2-500-120V, Q2-600H-CE, Q2-600H-UK

CONVEYOR TOASTERS

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2E-600H-208V, Q2E-800-

2

17 2K-200464

18 2E-200566 1 SWITCH, RESET ALL
19 2R-200562 1 FAN GUARD ALL

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF

Some items are included for illustrative purposes only and in certain instances may not be available.

BUSHING WIRE RING 7/8”

1

208/240V, Q2-500-120V, Q2-500-CUL20, Q2E-500-120V, Q2E-500CUL20,
Q2-600H-CE, Q2-600H-UK

Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ­208/240V

25

2
4

PARTS LIST January 11, 2011, Rev. D

Models: Q2-500-120V, Q2E-500-120V, Q2-500-CUL20, Q2-600H-CE, Q2-600H-UK, Q2-600HF-208, Q2-600H-208/220/240V,

Q2-600HS-208, Q2E-600H-208/240V, Q2-800-208/220/240V, Q2-800-240UK, Q2-800-230CE, Q2E-800-208/240V,
Q2-1200B-208/240V, R2-12BSZ-208/240V, R2--1200-208/240V, R2-600HJ-208/240V, R2-800-208V

Fig No Part No. Qty Description Application

CONVEYOR TOASTERS

HA-120239
HB-120259 SPEED CONTROL ASSY 250 Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-1200B-208/240V

20

HB-120261 SPEED CONTROL ASSY 500

21 2P-402728 1 POT, ANTI SPIN PLATE ALL NON-ELECTRONIC

2J-200538

22

2J-200539 SWITCH, EGO 120V INFINITE Q2-500-120V, Q2-500KL-120, Q2-500-CUL20

23 2E-200551 1 SWITCH ROTARY

24 2R-200709 4 LEG 1” CHOME PLASTIC

2M-200864
2M-200894 LABEL, QCS-2&3 BAGEL CONT Q2-1200B-208/240V

25

2M-201810 LABEL, RCS-2&3 BAGEL CONT
2M-201813 LABEL, QCSE Q2E-600H-208V, Q2E-500-120V, Q2E-500CUL20

2M-Z13358 LABEL - CONTROL Q2E-600HW Q2E-600HW
2M-Z13864 LABEL - CONTROL PANEL R2E R2E-500-120V, R2E-800-208V

2R-200768 1

26

2R-200769

27 2R-200708

28 HA-100560 1 TRAY, PULL OUT QCS, 10” ALL
29 2R-200787 1 QCS 1&2 CRUMB TRAY GUARD ALL

HC-402457

30

HF-100656 SECURITY CRUMB TRAY, QCS Q2-600HS-208

31 2B-200763 1 LOADUP, 10 EURO, WIRE ALL
32 HF-101115 1 TRAY, CRUMB TRAY ASSEMBLY ALL
33 2B-Z10675 2 MASTERLINK 10” CONV ALL
34 SP-160027 1 BELT, CONVEYOR 10” ALL
35 2A-202904 1 SHAFT, 210HX IDLER ALL

36 2P-200700 2
37 2P-200736 2 2” INCH BEARING SPRING ALL

SPEED CONTROL ASSEMBLY Q2-500-120V, Q2-500-CUL20

1

SWITCH, EGO 240V INFINITE

2

LABEL, QCS-2 & 3 CONTROLS

1

KNOB, CNTRL Q SERIES,
SPEED

KNOB, POWERSAVER Q

3

SERIES
KNOB, POWERSAVER Q

1

SERIES
4 KNOB, CONTROL CAP
2 KNOB, CONTROL CAP R2-12BSZ-208/240V, R2-1200B-208/240V

CRUMB TRAY, QCS-2 ALL
1

SPRING LOAD BEARING

TEFLON

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-600H-CE, Q2-600H-UK,
R2-600HJ-208/240V, R2-800-208V

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-1200B-208/240V, R2­12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ-208/240V, Q2-500-120V,

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-1200B-208/240V, R2­12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ-208/240V, Q2-500-120V,
Q2-500-CUL20

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-1200B-208/240V,
R2-12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ-208/240V, Q2E-600H­208V

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-500-120V, Q2-500­CUL20, Q2-600H-CE, Q2-600H-UK

R2-12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ-208/240V, R2-800­208V

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2-500-120V, Q2-500­CUL20, Q2-600H-CE, Q2-600H-UK

Q2-600H-208/220/240V, Q2-800-208/220/240V, R2-600HJ-208V, Q2-500­120V, Q2-600H-CE, Q2-600H-UK

Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-1200B-208/240V, R2-600HJ­208/240V

Q2-600H-208/220/240V, Q2-800-208/220/240V, R2-600HJ-208/240V, Q2­500-120V, Q2-500-CUL20, Q2-600H-CE, Q2-600H-UK

ALL

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF

Some items are included for illustrative purposes only and in certain instances may not be available.

26

3
4

PARTS LIST January 11, 2011, Rev. D

Models: Q2-500-120V, Q2E-500-120V, Q2-500-CUL20, Q2-600H-CE, Q2-600H-UK, Q2-600HF-208, Q2-600H-208/220/240V,

Q2-600HS-208, Q2E-600H-208/240V, Q2-800-208/220/240V, Q2-800-240UK, Q2-800-230CE, Q2E-800-208/240V,
Q2-1200B-208/240V, R2-12BSZ-208/240V, R2--1200-208/240V, R2-600HJ-208/240V, R2-800-208V

Fig No Part No. Qty Description Application

38 HC-402134 1 NC10H SHUTTER ROD Q2-600H-208/220/240V, R2-600HJ-208V/240V, Q2E-600H-208V
39 HC-402206 1 HEAT SHUTTER, SWINGING Q2-600H-208/220/240V, R2-600HJ-208V/240V, Q2E-600H-208V

HC-Z10389

40

HC-Z10441

41 2A-200284 1 E-CLIP 5/16” ALL
42 2E-200574 1 SWITCH, FAN CERAMIC Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-1200B-208/240V

2U-200591 1 QCSE CONTROL BOARD

43

2E-Z13360 1 CONTROL BOARD Q2E-600HW Q2E-600HW
2U-200592 1 QCSE POWER BOARD Q2E-600H-208/240V, Q2E-800-208/240V, Q2E-500-120V

44

HD-Z13861 1 POWER BOARD 120V R2E-500-120V

45 HF-402536 1 SECURITY LOCKING COVER Q2-50KL, Q2-50S, Q2-60HAKL, Q2-60HSA, Q2-AKL, Q2-80SA

2R-200752 1

46

HA-Z11222 1 KEYLOCK - DRILLED Q2-600HS-208
2K-200463 1 BUSHING CORD HEYCO 1247 Q2-600H-208/220/240V, Q2-800-208/220/240V, R2-600HJ-208V
2K-200465 1 BUSHING CORD HEYCO12/3 BL Q2-1200B-208/240V, R2-12BSZ-208/240V, R2-1200B-208/240V

NI

2K-Y2968 1 BUSHING - HEYCO 7W-2

NI 2P-200267 1 WIRE BRUSH R2-1200B-208V
NI D9-GR0216 1 POWER CORD ASSY-UK Q2-800-240UK

2E-200375 1 CORD SET, 14/3 120V EZ10 R2E-500-120V
2E-Z13364 1 CORD SET 14GA. 6-20P 80” Q2E-600HW208, Q2E-600HW240
HA-120241 1 CORD SET ASSEMBLY QCS-1 Q2-500-120V
HA-120242 1 CORDSET ASSY QCS-1-CUL20 Q2-500-CUL20
HB-120267 1 CORD SET R2-1200B Q2-600H-220V, R2-1200B-208V, Q2-600H-CE

NI

HB-120268 1 CORD SET ASSY R2-12BSZ R2-12BSZ-208/240V, R2-1200B-208/240V
HB-120269 1 CORD ASSY 6-20P W/3 #10R
HB-120274 1 CORD ASSY 6-20 QCSE Q2E-600H-208/240V, Q2E-800-208/240V

HB-120279 1 CORD ASSEMBLY CEE7-7 Q2-800-230CE
HD-140078 1 CORD SET, QCSE 2, 120V Q2E-500CUL20

NI HG-402144 1 FAN SWITCH BRACKET R2-12BSZ-208/240V, R2-1200B-208V

ELEMENT RETAINER, LEFT

QCS
1

ELEMENT RETAINER, LEFT

QCS

KEYLOCKING SPEC KEYED

ALIKE

Q2-600H-208/220/240V, Q2-800-208/220/240V, Q2E-600H-208V, Q2E-800­208/240V, Q2-500-120V, Q2-500-CUL20, Q2E-500-120V, Q2E-500CUL20,
Q2-600H-CE, R2-600H, R2-800

Q2-1200B-208/240V

Q2E-600H-208/240V, Q2E-800-208/240V, Q2E-500-120V, R2-800-208V,
R2E-500-120V

Q2-500KL-120, Q2-800S-208V

Q2E-600H-208/240V, Q2E-800-208/240V, Q2E-500-120V, R2-800-208V,
R2E-500-120V

Q2-600H-208/240V, Q2-800-208/220V, Q2-1200B-208V, R2-600HJ­208/240V

CONVEYOR TOASTERS

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF

Some items are included for illustrative purposes only and in certain instances may not be available.

27

4
4

PARTS LIST January 11, 2011, Rev. D

Models: Q3-950H-208/220/240V/CE/UK, Q3-1000-208/220/240/CE/UK, Q3-1300-208/240V, Q3-1400BH-208/240/CE,

Q3-1600B-208/240, Q3E-950H-208/240, Q3E-1000-208/240, Q3E-1300-208/240

Fig No Part No. Qty Description Application

1 HC-120283 1 CHASSIS ENCLOSURE ASSY ALL

HC-120284

2

HC-120285 ASSY, AIR BAFFLE QCS-3 HI Q3-1400BH

3 2R-Z8879 1 2-5/8 DIA FAN BLACK CW ALL

HA-120243
HB-120262 MOTOR ASSY 208-240V Q3-950H, Q3-1000-208V, Q3-1300-240V, Q3-1400BH208

4

HC-120289 MOTOR ASSEMBLY QCS3 Q3-1300-208V

HI-115071 MOTOR, RMS72, W/TERMINALS Q3E-1300-208
5 2U-200561 1 MOTOR,FAN240V 23BTM ALL
6 HC-Z11212 1 BACK PANEL,QCS-3 ALL
7 2A-202902 1 SHAFT, T714 DRIVE ALL

HA-112261
8

HA-112263 BEARING ASSY PTFE/BRONZE Q3-1300, Q3-1400BH,
9 2P-Z8779 1 SPROCKET 25P-11T .313 ID ALL

10 2P-150013 1 DRIVE CHAIN #25 ROLLER Q3-950H-208/220/240V, Q3-1000-208V

2P-200645

11

2P-200648 SPROCKET, 25B32 X 5/16 Q3-1600B

ASSY, AIR BAFFLE QCS-3 LO Q3-950H-208/240

1

MTR,ASSY,QCS,220,230,240V Q3-950H-CE, Q3-1000-CE, Q3-1000-UK, Q3-1400BH-CE

1

BEARING ASSY, 5/16 TEFLON Q3-950H, Q3-1000

2

SPROCKET, 25B17 X 5/16 Q3-950H, Q3-1000, Q3-1400BH

1

CONVEYOR TOASTERS

GB-197847

HL-197862 HEATERTUBE, QCS-3-1600B Q3-1600B-208

HL-197863 HEATERTUBE, QUARTZ Q3-1600B-240

HT-197845 HEATERTUBE, QUARTZ, 208V Q3-950H-208V, Q3-1000-208V, Q3E-1000-208V, Q3E-950H-208V

HT-197846 HEATERTUBE, QUARTZ, 220V

12

2N-209130 ELEMENT, METAL 208V 800W R3-950H-208V

2N-209160 ELEMENT, METAL 240V 800W R3-950H-CE

GB-197847

HJ-198054 HEATERTUBE, QCS-3-1300 Q3-1300-240V, Q3E-1300-240V

HJ-198060 HEATERTUBE, QCS-3-1300 Q3-1300-208V, Q3E-1300-208V

HK-198066 HEATERTUBE, QCS-3-1400BH Q3-1400BH-CE

HT-197860 HEATERTUBE, QUARTZ Q3-1400BH-CE

HC-Z10390

13

HC-Z11287 ELEMENT REATINER-RH, RCS-2 R3-950H

HC-Z10440 ELEMENT RETAINER, RIGHT Q3-1400BH, Q3-1600B

HB-Z10858

14

HC-Z10388 ELEMENT GUIDE PLATE Q3-1000, Q3-1300, Q3E-1000, Q3E-950H-208

HC-Z10439 ELEMENT GUIDE PLATE 1200 Q3-1400BH, Q3-1600B

15 2E-Z10406 2 TERMINAL BLOCK 4 POS Q3-950H, Q3-1000, Q3-1600B,
16 2E-Z9736

17 2K-200464
18 2E-200566 1 SWITCH, RESET, 0796 ALL

19 2R-200562 1 FAN GUARD ALL

HEATERTUBE, QUARTZ, 240V Q3-950H-240V, Q3-1000-240V, Q3E-950H-240V, Q3E-1000-240V

4

Q3-950H-220V, Q3-950H-CE, Q3-1000-220V, Q3-1000-CE,
Q3-1000-UK

HEATERTUBE, QUARTZ, 240V Q3-1400BH240

6

ELEMENT RETAINER,RHT,QCS- Q3-950H, Q3-1000, Q3E-950H, Q3E-1000, Q3E-1300

1

ELEMENT GUIDE PLATE QCS2 Q3-950H

2

1

TERMINAL BLOCK - POWER

2 Q3-1000
1

BUSHING, WIRE RING 7/8”

2 Q3-950H, Q3-1000

Q3-950H, Q3-1600B,

Q3-1400BH

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF

Some items are included for illustrative purposes only and in certain instances may not be available.

28

1
3

PARTS LIST January 11, 2011, Rev. D

Models: Q3-950H-208/220/240V/CE/UK, Q3-1000-208/220/240/CE/UK, Q3-1300-208/240V, Q3-1400BH-208/240/CE,

Q3-1600B-208/240, Q3E-950H-208/240, Q3E-1000-208/240, Q3E-1300-208/240

Fig No Part No. Qty Description Application

HB-120261

20

HC-120278 SPEED CONTROL ASSEMBLY Q3-1300-208V, Q3-1400BH

21 2P-402728 1 POT, ANTI SPIN PLATE ALL
22 2J-200538 2 SWITCH, EGO 240V INFINITE Q3-950H, Q3-1000, Q3-1300, Q3-1400BH
23 2E-200551 1 SWITCH ROTARY ALL

2R-200709

24

HP-402209 BRACKET, SECURITY LEG TT Q3-950HS-208

2M-200864

25

2M-201813 LABEL, QCSE Q3E-950H, Q3E-1000, Q3E-1300

2M-200899 LABEL, RCS-2, RCS-3 CONTR R3-950H

2R-200768 1 KNOB, CONTROL Q SERIES Q3-950H, Q3-1000, Q3-1300, Q3-1400BH, Q3-1600B

26

2R-200769

27 2R-200708

HH-100561

28

HI-100563 SECURITY PULL OUT TRAY Q3-950HS-208

29 2R-200788 1 QCS-3 CRUMB TRAY GUARD ALL

HC-Z11261

30

HI-100566 SECURITY CRUMB TRAY, QCS Q3-950HS-208, Q3-1300S-208/240

31 2B-200764 1 LOADUP, 14 EURO, WIRE ALL
32 HI-101116 1 TRAY, CRUMB ASSEMBLY Q3-950H, Q3-1000, Q3-1300, Q3-1400BG, Q3-1600B
33 2B-200603 3 BELT LINK 14IN SPACECLIP ALL
34 SP-160028 1 CONVEYOR BELT (14” X 35”) ALL
35 2A-202905 1 SHAFT, 214HX IDLER ALL
36 2P-200700 2 BEARING-PTFE SPRING LOAD ALL
37 2P-200736 2 2 INCH BEARING SPRING ALL
38 HH-402135 1 NC14H SHUTTER ROD Q3-950H, Q3-1400BH, Q3E-950H
39 HH-401698 1 HEAT SHUTTER, SWINGING Q3-950H, Q3-1400BH

HC-Z10389

40

HC-Z11288 2 RETAINER, RCS, ELEMENT R3-950H

HC-Z10441

41 2A-200284 1 E-CLIP 5/16 ALL
42 2E-200574 1 SWITCH, FAN, CERAMIC Q3-1600B

2U-200591

43

HC-Z13815 CONTROL - PROGRAMMED Q3E-950HP208

44 2U-200592 1 QCSE POWER BOARD Q3E
45 HB-Z11456 1 SECURITY LOCKING COVER Q3-950HS-208, Q3-1300S-208/240, 9H-Q2-3KL-KIT

46 2R-200752 1

NI 2E-Z5680 2 FUSE, 5A - CLASS G Q3-1300-208V, Q3-1400BH
NI 2E-Z5680 4 FUSE, 5A - CLASS G Q3E-1300-208/240V

SPEED CONTROL ASSY 500 Q3-950H, Q3-1000, Q3-1300-240V, Q3-1600B

1

LEG 1 INCH CHROME PLASTIC Q3-950H, Q3-1000, Q3-1300, Q3-1400BG, Q3-1600B

4

LABEL, QCS-2 & 3 CONTROL Q3-950H, Q3-1000, Q3-1300, Q3-1400BG, Q3-1600B

1

1 KNOB, POWERSAVER Q SERIES Q3-1600B
3 KNOB, POWERSAVER Q SERIES Q3-950H, Q3-1000, Q3-1300, Q3-1400BH
2

KNOB, CONTROL CAP

4 Q3-950H, Q3-1000, Q3-1300, Q3-1400BH

TRAY, PULL OUT, QCS, 14 ALL

1

CRUMB TRAY,QCS3 Q3-950H, Q3-1000, Q3-1300, Q3-1400BG, Q3-1600B

1

ELEMENT RETAINER,LFT,QCS- Q3-950H, Q3-1000, Q3-1300, Q3E-950H, Q3E-1000, Q3E-1300

1

1

ELEMENT RETAINER, LEFT Q3-1400BH, Q3-1600B

QCSE CONTROL BOARD Q3E

1

KEYLOCKING SPEC KEYED
ALIKE

Q3-1600B

Q3-950HS-208, Q3-1300S-208/240, 9H-Q2-3KL-KIT

CONVEYOR TOASTERS

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF

Some items are included for illustrative purposes only and in certain instances may not be available.

29

2
3

PARTS LIST January 11, 2011, Rev. D

Models: Q3-950H-208/220/240V/CE/UK, Q3-1000-208/220/240/CE/UK, Q3-1300-208/240V, Q3-1400BH-208/240/CE,

Q3-1600B-208/240, Q3E-950H-208/240, Q3E-1000-208/240, Q3E-1300-208/240

Fig No Part No. Qty Description Application

NI 2E-Z5681 1 FUSEHOLDER, CLASS G Q3-1300-208V, Q3-1400BH
NI 2E-Z5681 2 FUSEHOLDER, CLASS G Q3E-1300-208/240V
NI 2K-200465 1 BUSHING,CORD HEYCO12/3 BL Q3-950H, Q3-1400BH208
NI 2K-Y2968 1 BUSHING - HEYCO Q3-950H-CE, Q3-1400BH-CE
NI 2P-200267 1 WIRE BRUSH
NI HB-120269 1 CORD ASSY 6-20P W/3 #10R Q3-950H-208/220/240V
NI HB-120272 1 ASSY, CORD SET, 6-30P Q3-1300-208V, Q3-1400BH208, Q3-1600B-208
NI HB-120276 1 CORD ASSEMBLY CEE7-7 Q3-950H-CE, Q3-1000-CE, Q3-1400BH-CE
NI HG-402144 1 FAN SWITCH BRACKET Q3-1600B

CONVEYOR TOASTERS

IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF

Some items are included for illustrative purposes only and in certain instances may not be available.

30

3
3
