Important Information – English
• If this equipment is used in a manner not specied by
Hoefer, Inc. the protection provided by the equipment
may be impaired.
• This instrument is designed for indoor laboratory
useonly.
• Only accessories and parts approved or supplied by
Hoefer, Inc. may be used for operating, maintaining,
and servicing this product.
• Warning! Because this instrument can develop sucient voltage and current to produce a lethal shock,
care must be exercised in its operation.
• This instrument is designed in accordance with the
EN61010-1:2001 electrical safety standard. Nevertheless, it should be used only by properly trained
operators. Read this entire manual before using the
instrument and use only according to the instructions.
• The instrument must always be used with the earth
lead of the power cord correctly grounded to earth at
the mains outlet.
• Use only undamaged electrical wire and equipment
specic for the voltages you will use. All equipment
connected to high voltage should be in accordance
with EN61010-1:2001.
• Keep the instrument as dry and clean as possible.
Wipe regularly with a soft, damp cloth. Let the instrument dry completely before use.
• Do not operate the instrument in extreme humidity
(above 80%). Avoid condensation by letting the unit
equilibrate to ambient temperature when taking the
instrument from a colder to a warmer environment.
• To permit sucient cooling, ensure that the vents of
the instrument are not covered.
Duležité Informace – Czech
• Pokud by toto zařízení je použito způsobem, kter ý není
podle Hoefer, ochrana poskytovaná na základě Inc.
zařízení může být narušena.
• Tento nástroj je určen pro vnitřní použití v
laboratořipouze.
• Pouze příslušenství a části schválen, nebo poskytnutých Hoefer, Inc. mohou být použity pro provoz,
údržbu, a údržbě tohoto výrobku.
• Pozor! Protože tento nástroj může vyvinout dostatečný
napětí a proud, který má vyrábět a smrtiacej šok, péče
musí být vykonávána v jeho provoz.
• Tento nástroj je určen v souladu s EN61010-1:2001
elektrické bezpečnostní normy. Přesto, že by měly být
použity pouze řádně vyškolený operátorů. Číst celé
toto ruční před použitím nástroje a použití pouze v
souladu s pokyny.
• Přístroj musí být vždy používají se na výkonu zemi vést
šňůra správně zemněny k zemi na síti v ýústce.
• Využití pouze nepoškozené elektrické dráty a vybavení
pro napětí budete používat. Všechna zařízení spojené
s vysokým napětím by měla být v souladu s EN610101:2001.
• Si ponechá nástroje jako suchý a čistý jako možné.
Otřete pravidelně s a měkké, vlhk ým hadříkem. Nechť
je nástroj nenastavený úplně před použitím.
• Nejsou provozována na nástroj v extrémní vlhkost (nad
80%). Předešlo kondenzaci o pronájmu jednotky na
okolní teplotu nechá při přijímání nástroj z chladnější
do teplého prostředí.
• Pro umožnění dostatečné chlazení, zajistit, aby otvory
nástroje jsou nevztahuje.
Vigtig Information – Danish
• Hvis dette udstyr bruges i en måde ikke speciceret
ved Hoefer, Inc. den beskyttelse, som er blevet forsynet
af udstyret kan måske svæk kes.
• Dette instrument er designet for indendørs laboratoriumbrug bare.
• Bare tilbehør og del godkendede eller forsynede ved
Hoefer, Inc. kan måske bruges for drive, funktionsfejl,
og betjening dette produkt.
• Advare! Fordi dette instrument kan udvikle tilstrækkelig spænding og strøm at fremstille et dødbringende
chok, skal pleje bruges i dets drift.
• Dette instrument er designet i overensstemmelse med
EN61010-1:2001 elektrisk sikkerhedstandard. Alligevel,
skulle det bruges bare af passende trænede operatører.
Læs denne hel håndbog før bruging instrumentet og
brug bare i henhold til instruktionerne.
• Instrumentet skal altid bruges med jordblyet af
netledningen rigtigt jordede til jord på hovedledningsudløbet.
• Bruger bare uskadt elektrisk tråd og udstyr, som være
specik for spændingerne du vil bruge. Alt udstyr
forbundet til høj spænding skulle være i overensstemmelse med EN61010-1:2001.
• Beholder instrumentet så tør og ren som mulig. Tør
regulært med et blødt, fugtigt stof. Lad instrumenttørken komplet før brug.
• Driver ikke instrumentet i yderst fugtighed (ovenfor
pii
•
80%). Undgå kondensation ved lade enheden equilibrate til omgivende temperatur ved tageen instrumentets fra et koldere til et varmere miljø.
• At tillade tilstrækkelig afkøling, forsikrer, at lufthullerne
af instrumentet er ikke dækket.
Belangrijke Informatie – Dutch
• Indien deze uitrusting in een manier wordt gebruikt
die niet door Hoefer is gespeciceerd, Nv. de
bescherming die door de uitrusting is verzorgd kan
worden geschaad.
• Dit instrument is voor binnenlaboratoriumgebruik
enkel ontworpen.
• Enkel onderdelen en delen keurden goed of leverden
door Hoefer, Nv. kan voor het bedienen worden
gebruikt, handhavend en onderhouden van ditproduct.
• Waarschuwend! Omdat dit instrument voldoende
spanning en stroom kan ontwik kelen om een dodelijke schok te produceren, moet zorg in zijn operatie
worden geoefend.
• Dit instrument is in overeenstemming met de
EN61010-1:2001 elektrische veiligheidsstandaard
ontworpen. Niettemin zou het enkel door goed
getrainde bedieningslieden moeten worden gebruikt.
Lees dit volledige handboek voor het gebruik het
instrument en gebruik enkel volgens de instructies.
• Het instrument moet altijd met de aardeleiding van
het stroomsnoer correct grondde naar aarde aan het
hoofdafzetgebied worden gebruikt.
• Gebruik enkel onbeschadigde elektrische draad
en uitrustings speciek voor de spanningen u zult
gebruiken. Alle uitrustingen sloten aan aan hoogspanning zou in overeenstemming met EN61010-1:2001
moetenzijn.
• Houd het instrument zo droge en schone zoals
mogelijk Bij. Wis regelmatig met een zacht, temper
doek. Verhuur het instrument droogt volledig voor
hetgebruik.
• Bedien niet het instrument in extreme vochtigheid
(bovenstaande 80%). Vermijd condensatie door het
verhuren van de eenheid in evenwicht brengt naar
omgevingstemperatuur wanneer nemen het instrument van een kouder naar een lievere omgeving.
• Om toe te staan voldoende afkoelen, verzeker dat de
luchtopeningen van het instrument niet bedektzijn.
Tärkeää Tietoa – Finnish
• Jos tätä varusteita käytetään tavassa ei määritetty
Hoeferille, Inc. suojelu ehkäisty varusteille saattaa
ollaavuton.
• Tämä väline suunnitellaan sisälaboratoriokäytölle vain.
• Vain lisävarusteet ja osat hyväksyivät tai toimitti
Hoeferin oheen, Inc.:ää voi käyttää k äyttämiselle,
valvoalle, ja servicing tämä tuote.
• Varoittaminen! Koska tämä väline voi kehittää riittävä
jännitteen ja virran tuottaa kuolettavan järkytyksen,
huolta täytyy harjoittaa toiminnossaan.
• Tämä väline suunnitellaan EN61010-1:2001 sähköturvallisuusstandardin mukaisesti. Silti pitäisi käyttää vain ohi oikeasti koulutetut k äyttäjät. Lue tämä
kokonainen manuaalinen ennen välinettä ja k äyttö
vain ohjeidenmukaan.
• Välinettä täytyy käyttää aina valtanuoran maalyijystä
perusti oikein maadoittaa sähköverkkoaukossa.
• Käyttää vain undamaged sähkömetallilankaa ja varusteita, täsmällinen jännitteille käyttää. Kaik ki varusteet
yhdistetty korkeaan jännitteeseen pitäisi olla EN610101:2001IN mukaisesti.
• Pitää välineen yhtä kuiva ja puhdas kuin mahdollinen.
Pyyhi säännöllisesti pehmeällä, kostealla k ankaalla.
Anna väline kuivua täysin ennen käyttöä.
• Ei käytä välinettä extreme-ilmankosteudessa (80%)n
yläpuolella. Vältä tiivistymistä antamalla yksikön equilibrate ympäröivään lämpötilaan kun ottaminen väline
kylmempi lämpimämpään ympäristöön.
• Sallia riittävän jäähdyttäminen, varmistaa että välineen
ilmareiät peitetään.
Information Importante – French
• Si cet équipement est utilisé dans une manière pas
spécié par Hoefer, Inc. la protection fourni par
l’équipement pourrait être diminuée.
• Cet instrument est conçu pour l’usage de laboratoire
intérieur seulement.
• Seulement les accessoires et les parties ont approuvé
ou ont fourni par Hoefer, Inc. pourrait être utilisé pour
fonctionner, maintenir, et entretenir ce produit.
• Avertissant! Parce que cet instrument peut développer
la tension et le courant susants pour produire un
choc mortel, le soin doit être exercé dans son opération.
• Cet instrument est conformément conçu à l’EN610101:2001 norme de sécurité électrique. Néanmoins,
piii
•
il devrait être seulement utilisé par les opérateurs
convenablement entraînés. Lire ce manuel entier avant
utiliser l’instrument et l’usage seulement selon les
instructions.
• L’instrument toujours doit être utilisé avec l’avance de
terre du cordon d’alimentation correctement a fondé à
la terre à la sortie principale.
• Utiliser le l et l’équipement électriques seulement intacts spéciques pour les tensions que vous
utiliserez. Tout équipement connecté à haute tension
devrait être conformément à EN61010-1:2001.
• Garder l’instrument aussi sec et propre comme possible. Essuyer régulièrement avec un doux, étouer du
tissu. Laisser l’instrument sèche complètement avant
l’usage.
• Ne pas fonctionner l’instrument dans l’extrême
humidité (au-dessus de 80%). Eviter la condensation en laissant l’equilibrate d’unité à la température
ambiante en prenant l’instrument d’un plus froid à un
environnement plus chaud.
• Permettre le refroidissement susant, garantir que les
conduits de l’instrument ne sont pas couverts.
Wichtige Informationen – German
• Wenn diese Ausrüstung gewissermaßen nicht angegeben durch Hoefer, Inc verwendet wird, kann der
durch die Ausrüstung zur Verfügung gestellte Schutz
verschlechtert werden.
• Dieses Instrument wird für den I nnenlaborgebrauch
nur dafür entworfen.
• Nur Zusätze und Teile genehmigten oder lieferten
durch Hoefer, Inc kann für das Funktionieren, das
Aufrechterhalten, und die Wartung dieses Produktes
verwendet werden.
• Die Warnung! Weil dieses Instrument genügend Stromspannung und Strom entwickeln kann, um einen tödlichen Stoß zu erzeugen, muss Sorge in seiner Operation
ausgeübt werden.
• Dieses Instrument wird in Übereinstimmung mit dem
EN61010-1:2001 elektrischen Sicherheitsstandard dafür
entworfen. Dennoch sollte es nur von richtig erzogenen Maschinenbedienern verwendet werden. Lesen
Sie dieses komplette Handbuch vor dem Verwenden
des Instrumentes und verwenden Sie nur gemäß den
Instruktionen.
• Das Instrument muss immer mit der Erdleitung
der Macht-Schnur richtig niedergelegt zur Erde am
Hauptausgang verwendet werden.
• Nur unbeschädigte elektrische Leitung und Ausrüstung spezisch für die Stromspannungen verwenden,
die Sie verwenden werden. Die ganze mit der Hochspannung verbundene Ausrüstung sollte in Übereinstimmung mit EN61010-1:2001 sein.
• Das Instrument ebenso trocken halten und reinigen
wie möglich. Wischen Sie regelmäßig mit einem
weichen, befeuchten Sie Sto. Lassen Sie das Instrument trocken völlig vor dem Gebrauch.
• Das Instrument in der äußersten Feuchtigkeit (über 80
%) nicht bedienen. Vermeiden Sie Kondensation, die
Einheit equilibrate zur Umgebungstemperatur laßend,
wenn Sie das Instrument von einem kälteren bis eine
wärmere Umgebung nehmen.
• Um das genügend Abkühlen zu erlauben, stellen Sie
sicher, dass die Önungen des Instrumentes nicht
bedeckt werden.
Informazioni Importanti – Italiano
• Se quest’apparecchiatura è usata in un modo
specicato da Hoefer, Inc. la protezione fornito
dall’apparecchiatura potrebbe essere indebolita.
• Questo strumento è disegnato per l’uso di laboratorio
interno solo.
• Solo gli accessori e le parti hanno approvato o hanno
fornito da Hoefer, Inc. potrebbe essere usato per operare, per mantenere, e per revisionare questo prodotto.
• Avvertendo! Perché questo strumento può sviluppare
il voltaggio suciente e la corrente di produrre una
scossa letale, la cura deve essere esercitata nella sua
operazione. Questo strumento è disegnato conformemente all’EN61010-1:2001 la norma di sicurezza
elettrica. Tuttavia, dovrebbe essere usato degli operatori solo correttamente addestrati. Leggere questo
manuale intero prima di usare lo strumento e l’uso solo
secondo le istruzioni.
• Lo strumento deve essere sempre usato col piombo di
terra della spina di alimentazione correttamente hanno
messo a terra alla terra alla presa di corrente principale.
• Usa il lo metallico e l’apparecchiatura solo intatti
elettrici specici per i voltaggi che lei userà. Tutta
l’apparecchiatura collegata all’alto voltaggio dovrebbe
essere conformemente a EN61010-1:2001.
• Tiene lo strumento come secco e pulito come possibile.
Pulire regolarmente con un morbido, per spegnere il
panno. Lasciare lo strumento asciuga completamente
prima dell’uso.
• Non opera lo strumento nell’umidità estrema (al di
sopra di 80%). Evitare la condensazione lasciando
piv
•
l’unità equilibra alla temperatura ambiente quando
portare lo strumento da un più freddo a un ambiente
più caldo.
• Di permettere rareddare suciente, assicura che gli
sbocchi dello strumento non sono coperti.
Viktig Informasjon – Norwegian
• Hvis dette utstyret blir brukt i en måte ikke spesisert
ved Hoefer, Inc. beskyttelsen som ha blitt git av utstyret kan bli svekket.
• Dette instrumentet er utformet for innendørs laboratoriumbruk bare.
• Bare tilbehør og deler godkjente eller forsynte ved
Hoefer, Inc. kan bli brukt for drive, vedlikeholde, og
betjene dette produktet.
• Varsler ! Fordi dette instrumentet kan utvikle tilstrekkelig spenning og strøm til å produsere et dødelig
sjokk, må bli øvd bek ymring i dets drift.
• Dette instrumentet er utformet i samsvar med
EN61010-1:2001 elektrisk sikkerhetsstandard. Likevel
burde bli brukt det bare av sk ikkelig utdannede operatører. Les denne hele håndboken før bruking instrumentet og bruken bare gi til instruksjonene.
• Instrumentet må alltid bli brukt med jorden blyet
av kraftkabelen som riktig ha blitt jordet til jord på
hovedledningen utløp.
• Bruker bare uskadd elektrisk ledningsfremføring og
utstyr som er spesikk for spenningene du vil bruke.
All utstyr koplet til høyspenning burde være i samsvar
med EN61010-1:2001.
• Beholder instrumentet som tørker og rengjør som
mulig. Visk regulært med et mykt, fuktig sto. La instrumentet tørker komplett før bruk.
• Driver instrumentet i ekstrem fuktighet ikke (ovenfor
80%). Unngå kondensasjon ved å la enheten equilibrate til omgivelsestemperatur ved taen instrumentets
fra et kaldere til et varmere miljø.
• Til å tillate tilstrekkelig kjølig, sikrer at ventilasjonsåpningene av instrumentet er ikke dekket.
Wazne Informacje – Polish
• Jeżeli ten sprzęt jest wykorz ystywany w sposób nie
określone przez Hoefer, Inc. do ochrony przewidzianej
przez urządzenie może zostać obniżony.
• Instrument ten jest przeznaczony do uż ytku w laboratoriach kryty tylko.
• Tylko akcesoriów i części zatwierdzone lub dostarczone
przez Hoefer, Inc. mogą być wykorzystane do eksploatacji, utrzymania i obsługi tego produktu.
• Uwaga! Ponieważ ten akt prawny może być rozwinięcie
odpowiednich napięcie i bieżących do wyprodukowania śmiertelnego szoku, opiekę musi być wykonywane w działaniu.
• Ten instrument został zaprojektowany zgodnie z
tym EN61010-1: 2001 Bezpieczeństwo elektr yczne
standard. Niemniej jednak, należy stosować jedynie
przez odpowiednio przeszkoleni operatorów. Znajdą
państwo to cały podręcznika przed zastosowaniem
instrumentu i stosować jedynie zgodnie z instrukcjami.
• Instrument musi zawsze być wykorz ystane z ziemi
doprowadzić do zasilania detonującego właściwie
uzasadnione na ziemię w sieci wodociągowej
rynkuzbytu.
• Wykorzystanie tylko nieuszkodzona elektr ycznych
drutów i urządzenia specjalne do napięć zapłacą
wykorzystania. Wszystkie urządzenia podłączone do
wysokiego napięcia powinny być zgodne z EN61010-1:
2001.
• Kontrolować instrumentu jako suche i czyste jak to
możliwe. Wytrzeć regularnie przy pomocy miękk iego
wilgotnej szmatki. Niech się instrumentem całkowicie
wysuszyć przed użyciem.
• Nie prowadzą do instrumentu w skrajnych wilgotności
(powyżej 80%). Zapobiec kondensacji najmu przez
jednostkę równoważyć do temperatury pokojowej
przy podejmowaniu instrumentu z chłodniejsze w
cieplejszych środowiska.
• Aby umożliwić wystarczające chłodzenia, zapewniają, że
rozcięcia of the instrument nie objęte ubezpieczeniem.
Informações Importantes –
Portuguese
• Se este equipamento é usado numa maneira não especicada por Hoefer, Inc. que a protecção fornecida pelo
equipamento pode ser comprometida.
• Este instrumento é projectado para uso de interior de
laboratório só. Só acessórios e partes aprovaram ou
forneceu por Hoefer, Inc. pode ser usada para operar,
manter, e servicing este produto.
• Advertindo! Porque este instrumento pode desenvolver voltagem suciente e corrente produzir
um choque letal, cuidado deve ser exercitado em
suaoperação.
• Este instrumento é projectado de acordo com o
EN61010-1:2001 condição de segurança eléctrica. Não
pv
•
obstante, deve ser usado só por operadores adequadamente treinados. Leia este manual inteiro antes de usar
o instrumento e use só de acordo com as instrucções.
• O instrumento sempre deve ser usado com o chumbo
de terra do cordão de poder corretamente baseou a
terra nos canos saída principais.
• Usa o eléctrico só intacto e equipamento especíco
para as voltagens que você usará. Todo equipamento
conectado a voltagem alta deve ser de acordo com
EN61010-1:2001.
• Mantem o instrumento tão seco e limpo como
possível. Limpe regularmente com um pano húmido
macio. Deixe o instrumento secar completamente
antes de uso.
• Não opera o instrumento em humidade extrema
(acima de 80%). Evite condensação deixando o equilibrate de unidade a temperatura ambiental quando
tomar o instrumento de um mais frio a um ambiente
mais quente.
• Permitir esfriar suciente, assegura que as aberturas do
instrumento não são cobertas.
Información Importante –
Spanish
• Si este equipo es utilizado en una manera no especicado por Hoefer, S.a. la protección proporcionado por
el equipo puede ser dañada.
• Este instrumento es diseñado para el uso interior del
laboratorio sólo. Sólo accesorios y partes aprobaron o
suministraron por Hoefer, S.a. puede ser utilizado para
operar, para mantener, y para atender a este producto.
• Advirtiendo! Porque este instrumento puede desarrollar voltaje y corriente sucientes para producir
un golpe mortal, el cuidado debe ser ejercitado en
suoperación.
• Este instrumento es diseñado de acuerdo con el
EN61010-1:2001 estándar eléctrico de seguridad.
No obstante, debe ser utilizado sólo por operarios
adecuadamente capacitados. Lea este manual entero
antes de utilizar el instrumento y el uso sólo según las
instrucciones.
• El instrumento siempre debe ser utilizado con el plomo
de la tierra del cable de alimentación molió correctamente a la tierra en la salida de red.
• Utiliza alambre y equipo eléctricos sólo ilesos especícos para los voltajes que usted utilizará. Todo equipo
conectado al voltaje alto debe ser de acuerdo con
EN61010-1:2001.
• Mantiene el instrumento tan seco y limpio como
posible. Enjugue regularmente con un suave, el trapo
húmedo. Permita que el instrumento seque completamente antes de uso.
• No opera el instrumento en la humedad extrema
(encima de 80%). Evite condensación permitiendo la
unidad equilibra a la temperatura ambiente al tomar el
instrumento de un más frío a un ambiente más tibio.
• Permitir refrigeración suciente, asegure que las
aberturas del
Viktig Information – Swedish
• om denna utrustning används i ett sätt som inte har
speciceras av Hoefer, Inc. skyddet tillhandahöll vid
utrustningen kan skadas.
• Detta instrument formges för inomhuslaboratorium
användning bara.
• Bara medhjälpare och delar godkände eller levererade
vid Hoefer, Inc. kan användas för fungera, underhålla,
och servicing denna produkt.
• varna! Därför att detta instrument kan utveckla tillräcklig spänning och ström att producera en dödlig stöt,
måste övas omsorg i dess funktion.
• Detta instrument formges i överensstämmelse med
EN61010-1:2001 elektriska säkerheten standarden.
Icke desto mindre, bör det användas bara av riktigt
utbildade operatörer. Läs denna hela handbok före
använda instrumentet och använd bara enligt undervisningarna.
• Instrumentet måste alltid användas med jorden blyet
av kraften repet riktigt grounded till jorden på det
huvudutloppet.
• Använder bara undamaged elektrisk tråd och utrustning specik för spänningarna du sk a använda. All
utrustning kopplats som till hög spänning skulle vara i
överensstämmelse med EN61010-1:2001.
• Håller instrumentet då torkar och rengör som möjlig.
Torka regelbundet med en mjuk, fuktig trasa. Låt
instrumentet torka fullständigt före användningen.
• Fungerar inte instrumentet i extrem fuktighet (över
80%). Undvik kondensering vid låta enheten equilibrate till omgivande temperatur när ta instrumentet
från en kallare till en varmare miljö.
• Att tillåta tillräcklig kyla, ser till att hålen av instrumentet inte täcks.
pvi
•
Waste Electrical and
Electronic Equipment (WEEE)
English
French
German
Italian
Spanish
This symbol indicates that the waste of electrical and
electronic equipment must not be disposed as unsorted
municipal waste and must be collected separately. Please
contact an authorized representative of the manufacturer
for information concerning the decommissioning of
your equipment.
Ce symbole indique que les déchets relatifs à l’équipement
électrique et électronique ne doivent pas être jetés comme
les ordures ménagères non-triées et doivent être collectés
séparément. Contactez un représentant agréé du fabricant
pour obtenir des informations sur la mise au rebut de
votre équipement.
Dieses Symbol kennzeichnet elektrische und elektronische
Geräte, die nicht mit dem gewöhnlichen, unsortierten
Hausmüll entsorgt werden dürfen, sondern separat
behandelt werden müssen. Bitte nehmen Sie Kontakt mit
einem autorisierten Beauftragten des Herstellers auf, um
Informationen hinsichtlich der Entsorgung Ihres Gerätes
zu erhalten.
Questo simbolo indica che i rifiuti derivanti da
apparecchiature elettriche ed elettroniche non devono essere
smaltiti come rifiuti municipali indifferenziati e devono invece
essere raccolti separatamente. Per informazioni relative alle
modalità di smantellamento delle apparecchiature fuori uso,
contattare un rappresentante autorizzato del fabbricante.
Este símbolo indica que el equipo eléctrico y electrónico no
debe tirarse con los desechos domésticos y debe tratarse por
separado. Contacte con el representante local del fabricante
para obtener más información sobre la forma de desechar
el equipo.
Swedish
Denna symbol anger att elektriska och elektroniska
utrustningar inte får avyttras som osorterat hushållsavfall och
måste samlas in separat. Var god kontakta en auktoriserad
tillverkarrepresentant för information angående avyttring
av utrustningen.
pvii
•
Fig 1. MacroVue UV-20
Transilluminator main
components.
UV transilluminator
function
The Hoefer® MacroVue Dual-intensity UV
transilluminator provides a uniform and intense
source of 302 nm ultraviolet light to backilluminate transparent fluorescent materials.
Nucleic acids stained with fluorescent dyes
such as ethidium bromide and acridine orange
can be detected under UV illumination. This
visualization method is especially suitable for
double-stranded nucleic acids, but is less sensitive
for visualizing single-stranded nucleic acids.
The MacroVue UV-20 filter surface is 20 ×
20 cm. The light intensity level can be set to
either high or low. The transilluminator can be
converted from 302 nm (medium wavelength) to
254 nm (short wavelength) by replacing the UV
lamps as described on page 6.
Illumination
Hinged UV-blocking
safety cover
area (filter)
Dual intensity switch
(high and low)
Mains power
switch
•
p1
Note: Swirl patterns in the
UV filter, if present, do not
interfere with viewing or photo
documentation of gels.
Unpacking
Unwrap all packages carefully and compare
contents with the packing list, making sure all
items arrived. If any part is missing, contact
your local Hoefer, Inc. sales office. Inspect all
components for damage that may have occurred
while the unit was in transit. If any part appears
damaged, contact the carrier immediately. Be
sure to keep all packing material for damage
claims or to use should it become necessary to
return the unit.
Specifications
Ultraviolet lamps
• UV-20: Five 8-W 302 nm UV dual bi-pin discharge
type tubes
Filter
• The factory-installed filter is for 254 nm and 302 nm
lamps only. Do not use with 365 nm lamps.
• The expected life of the filter is 5000 hours.
Input fuses
• 115 V: T 1A/250V 5 × 20 mm (2 fuses)
• 230 V: T 1A/250V 5 × 20 mm (2 fuses)
Dimensions (h × d × w)
External: 12.1 × 24.1 × 33.7 cm
(4.75 × 9.50 × 13.25 in.)
Safety
• All electric components are HYPOT tested to 1500 V.
• The filter is covered by a 3 mm (1/8")-thick UV
blocking safety shield
• CE certified
• EN 61010–1, UL 3101–1, CSA C22.2 1010.1,
EN 50082-1
Features
• The dual-intensity switch toggles to a lower UV
intensity for preparative work.
• Removable power cord
• Lighted power switch
p2
•
Important safety
information
• When working near UV radiation, always
wear at least a UV-blocking face shield
and cover all exposed skin. For added eye
protection, wear goggles. Make sure all
persons in the area are also properly protected.
• Lower the UV-blocking safety cover before
switching the UV lamps on. Always wear
protective clothing even with the cover
closed to prevent accidental exposure to UV
radiation. If the cover has been removed,
you must wear a safety shield and gloves to
prevent damage to eyes and skin.
• If possible, locate the transilluminator in a
controlled environment such as a darkroom.
• Always disconnect the mains power cord
before cleaning the unit or replacing fuses
or lamps.
p3
•
Operating instructions
1
Place the unit on a stable and level surface. Allow
space around the unit for air to circulate freely.
Note: To protect the filter from
cuts and corrosive buffers, cover
it with a protective surface such
as the Hoefer UV transmitting
work surface before placing the
sample.
Note: To remove the safety
cover for photography, lift the
lid into the up position and pull
out both inserts in the hinge
assembly. Take extra precautions
to prevent skin and eye exposure
if the protective cover is
removed.
2
Plug the power cord into the receptacle at the back of
the unit and into a properly-grounded electrical outlet
of the proper voltage rating. (The voltage rating of the
unit is indicated on the label above the power cord
receptacle.)
3
Wear goggles, a UV-blocking face shield, gloves and
cover all exposed skin.
4
Place the sample on the filter and lower the
UV-blocking clear protective cover.
5
Set the dual intensity switch to high and switch the
power to on (I). The indicator lamp in the ON/OFF
switch should light, and after a momentary flickering,
the UV lamps should light and be visible beneath the
protective cover.
The high-intensity setting is for analytical documentation
and the low setting is for preparative work (the lower
setting reduces photonicking and photobleaching).
6
To reduce the UV intensity, set the dual intensity
switch to low. The drop in intensity will diminish the
level of sample fluorescence.
7
After viewing the sample, turn the unit off and
clean according to the instructions in the Care and
maintenance section on page 5.
p4
•
Caution! Always unplug unit
from electrical supply before
cleaning or drying the unit.
Care and maintenance
Cleaning
• Clean the filter surface after each use.
• Use a mild detergent and water on a soft cloth
or sponge to clean the unit exterior.
• Never use abrasive cleaners, solvents, or
chloroform on any part.
p5
•
Replacing UV lamps
The transilluminator is originally equipped with
302 nm UV lamps. If 254 nm wavelength is
required, replace all lamps with 254 nm lamps
of the specified wattage.
Visually check that all lamps are illuminated.
If one or more lamps are burned out, it is
recommended that all lamps be replaced at the
same time to ensure even light intensity. To
replace each lamp:
1
Caution! Turn the unit offand disconnect the power
cord from the mains power.
2
Remove the filter/cover by unscrewing the four
retainer screws located on the sides of the cover.
3
If present, remove the tape that secures the lamps
during shipping. Remove each lamp by carefully
rotating it ¼ turn and then carefully pulling it upward.
4
To insert the new lamp, hold it so that the metal pins
at the end are vertical. Place the lamp in the socket
and lightly push it up into place. Rotate the tube ¼
turn until it locks into place.
5
Replace the filter/cover and screw in the
retainer screws.
p6
•
Replacing fuses
Fuses protect equipment by disconnecting loads
too large for the instrument’s circuit design. For
continued protection, only replace fuses with the
specified voltage and current ratings.
Each of two round modules on the left side of
the control panel (above the mains power cord
receptacle) holds one T 1A/250V 5 × 20 mm
(Slow blo) fuse.
1
Caution! Set the power switch to OFF and detach the
power cord before replacing fuses.
2
Insert a small flat-blade screwdriver into the slot on
the fuse module and turn it ¼ turn counterclockwise.
The spring-loaded module cap will loosen. Pull the
cap/fuse holder out.
3
Pull the fuse out of its holder and inspect. If the fuse
element is burned or broken, replace the fuse with an
identical type. If the fuse appears to be intact, check
it with an ohmmeter.
4
Insert a good fuse into the holder and then insert
this assembly back into the unit. Seat the module by
inserting the screwdriver into the slot, pressing gently,
and turning the cap ¼ turn clockwise.
p7
•
Troubleshooting
Unit does not operate when power is turned on
• Check that the power cord is plugged into a
working electrical outlet.
• Remove and inspect the fuses.
• Check that the lamps are properly installed.
Lamps flicker excessively
• Check that the dual intensity switch is in the
“high” position.
• Check for proper line voltage.
UV filter surface feels warmer than usual
• Ensure that there is enough space around the
unit so that air can freely circulate.
p8
•
Bibliography
DNA crosslinking
Church, M. C. and G. Gilbert. (1984) Genomic
sequencing. Proc Natl. Acad. Sci., USA. 81,
1991–1995.
