KODO™ Drone

USB

Charger

Blade Guards

Spare Blades
(2 black, 2 yellow)

CONTROLLER SETUP

Rudder

Throttle/Rudder

NOTE: For Mode 1 operation, slide the mode switch to the MD1 position


Trim

Button

Stick

and flip the controller so the throttle is on the right side.

Mode 1/ Mode 2

Throttle

Trim

Switch

ON/OFF Elevator

Video

Button

Trim

Aileron

Trim

Aileron/Elevator

Stick

CHARGING the FLIGHT BATTERY

Plug charger into USB port or AC adapter (DIDP1125 not included)
as shown and connect the battery. The red LED will flash slowly
while the battery is charging. The LED will be steady when the
battery is fully charged.

• NEVER leave the battery unattended while charging.

• DO NOT allow the USB port to power down while the charger
is connected to the battery.

• ALWAYS unplug the charger from the USB port and the
battery when charging is complete.

• The battery connector will only fit in one way.

Controller

AAA Batteries

USB Card

2G Memory Card

Reader

SENSITIVITY ADJUSTMENT

Push down on the left stick to

change the sensitivity

of the controls.

LED

Lowest (Default)

Moderate

Remove the screw on
the battery compartment
cover. Take the cover off
and insert 2 AAA batteries.
Replace cover securing
with the screw.

Maximum

• Do not mix old and new batteries

• Do not mix alkaline, standard, or
rechargeable batteries.

LINKING

Your KODO comes with a Power-On failsafe. This is designed to
ensure that the motors will not start until the KODO has detected
the controller.

1. Turn on the controller with the throttle
at its lowest position.

2. Connect the battery to the Kodo HD
and place it on a level surface. Listen
for two beeps. The red LED at the
back of the quadcopter will start
 ashing slowly.

x2
x3

3. Move the throttle to its highest position. Listen for a beep

4. Move the throttle back to its lowest position. Listen for three
beeps.

The Kodo’s motors are now armed and the quad is ready to  y. The

red LED on the Kodo HD will become steady.

HOW to FLY

D

BB

CC

A

CORRECTING DRIFT

It is normal for the KODO to drift slightly. However, if it drifts in any direction
consistently, press the trim button that is opposite the movement as many times
as needed to eliminate the drift.

D

A

Basic Flight Advance the throttle slowly until your Kodo HD rises into the air.

The controls are very sensitive and small stick movements should be used to the

control the quadcopter. If you get into trouble and see that the Kodo HD is going to
crash, move the throttle to its lowest position immediately.

The LED on the Kodo HD will flash slowly when the battery voltage is getting

low. Land as soon as possible and unplug the battery. Always recharge the
battery or batteries before storing the Kodo HD.

E

Use Left Trim

CAMERA OPERATION

Photo Button Video Button

Press the photo button to capture a
photo.

Press the video button to start a video.

The video button must be pressed again to stop and save the video on the card.
The photo button will not operate while the camera is recording a video.

Flips Push down on the right stick. Move the right stick in any direction and

release when the flip is completed. The controller will beep until the right stick
is released.

The red LED on the Kodo HD will flash when the battery voltage is getting low. Land

as soon as possible and charge the battery. The battery must be charged before
it is stored. The battery must not be connected to the Kodo HD or the charger
when stored.

Only insert and remove the memory card when the battery is not connected to the

Kodo HD. When the memory card is installed, there will be a steady blue LED just
above the card slot.

The camera lens angle can be adjusted from straight ahead to 70 degrees down.

To view the photos or videos, remove the memory card and install it in the card

reader. Install the card reader in a USB port on your computer

BLADE GUARD REPLACEMENT

1. Carefully pry off the blade using a flat
head screwdriver. NOTE: Do one corner
at a time so you don’t accidentally mix
up the blades.

2. Pull blade guard up
and off the motor
housing. Install
the new guard
and replace the
rotor blade.
