Page 1

FT1000 ENERGY RECOVERY

701 S Ridge Avenue, Troy, OH 45374

1-888-4HOBART • www.hobartcorp.com

Item # _____________________________________

Quantity ___________________________________

C.S.I. Section 11400

WITH BLOWER DRYER

FLIGHT-TYPE DISHWASHER

STANDARD FEATURES

■ Pumped rinse system (pressure gauge not required)

■ Water usage 58 gph

■ Digital controls with machine diagnostics

■ Low temperature alert

■ Single point vent location

■ 31" access on prewash, power wash and power

rinse chambers; 20" access on dual rinse and ASR chambers

■ Start and stop switches at both ends

■ Doors open indicator

■ Drains open indicator

■ Door interlocks

■ 31⁄2 H.P. prewash, 5 H.P. power wash and power

rinse pump motors, all TEFC

■ Capless Auto Clean wash arms

■ Easy to remove stainless steel scrap pans and

baskets

■ 30" wide conveyor belt

■ Dual Rinse

■ Automatic Soil Removal system (ASR)

■ Auto Clean

■ Auto Delime

■ Energy Recovery

■ Front and rear panels

■ Variable speed conveyor

MODEL

❑ FT1000 Energy Recovery with Blower Dryer

Flight-Type Dishwasher

FT1000 ENERGY RECOVERY WITH BLOWER DRYER FLIGHT-TYPE DISHWASHER

OPTIONS AT EXTRA COST

❑ Electric Tank Heat

❑ Steam Tank Heat

❑ Booster Heater ❑ Electric ❑ Steam

❑ Blower Dryer ❑ Electric ❑ Steam

❑ 6" higher than standard chamber

❑ Multiple conveyor choices

❑ Circuit breakers

❑ Security package

❑ Other options available, consult factory

ACCESSORIES

❑ Flanged feet

❑ Water hammer arrestor/PRV (installed by others)

❑ Drain water tempering kit (installed by others)

❑ Vent connection kit

Specications, Details and Dimensions on Inside and Back.

DIRECTION OF OPERATION

❑ Right to Left

❑ Left to Right

• LA Research Report M660004

• Complies with EPA Reduction of Lead in Drinking Water Act 2014

• Meets requirements of ASSE Standard No. 1004

VOLTAGE

❑ 208/60/3

❑ 240/60/3

❑ 480/60/3

❑ Other voltages available – consult factory

F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher Page 1 of 12

Page 2

FT1000 ENERGY RECOVERY WITH BLOWER DRYER FLIGHT-TYPE DISHWASHER

701 S Ridge Avenue, Troy, OH 45374

1-888-4HOBART • www.hobartcorp.com

DESIGN: Fully automatic, ight-type dish machine consisting of a load section with Automatic Soil Removal system, power recirculating prewash, power wash, power rinse and dual rinse/nal rinse section. Included with each machine will be exible plastic strip curtains to control overspray.

CONSTRUCTION: Stainless steel tank and chambers with No. 3 polish on appearance surfaces. Frame, legs and feet to be constructed of stainless steel. Inspection doors to be chamber width.

PUMPS: Recirculating stainless steel pumps with stainless steel impellers. Pump housing has easy to remove coverplate for access to impeller. Wash pumps are self-draining.

MOTORS: Totally enclosed fan cooled (TEFC) design with overload protection. Pump motors to be 31⁄2 H.P. for prewash, 5 H.P. for power wash and power rinse, and conveyor motor to be 1⁄3 H.P. Available in electrical specications of 208/60/3, 240/60/3 and 480/60/3.

CONTROLS: A stainless steel control center with electronic digital controls mounted at eye level. Power “On/Off” and “Start/Stop” switches integrated into keypad. Digital display indicates door(s) open, low temperature alert, tanks/nal rinse temperatures, Auto Clean and Auto Delime instructions and notications, and other pertinent operating data. Additional “Start/Stop” switches are located at each end of machine. Conveyor speed button included on the control center to provide for the adjustable speed conveyor.

FLIGHT-TYPE CONVEYOR: Stainless steel side links, tie rods and conveyor tracks. Injection molded, resilient Duraex ight links.

VENT: Indirect vent connection with integral powered fan.

AUTOMATIC SOIL REMOVAL SYSTEM (ASR): Two foot section with specialized soil removal wash arms which removes food soil from the ware before it reaches the prewash tank. System will pump food soil from the ASR tank into an external collector located under the load section, minimizing the need to pre-scrap dishes and reducing detergent consumption. Operator can easily remove and clean external collector without interruption of machine operation.

RECIRCULATING PREWASH SECTION: Prewash compartment is tted with upper and lower wash arms. Large removable one piece perforated stainless steel screen sloped downward to deep stainless steel scrap basket.

TANK HEAT: Power wash, power rinse and dual rinse tank water temperatures are thermostatically controlled. Low water protection is provided. Specify either electric or steam heat.

FINAL RINSE: Easily removed nal rinse arms.

ENERGY RECOVERY: Energy Recovery system

operates with a cold water line, capturing energy from exhaust air, and using it to elevate the temperature of the water entering the booster heater. The result is savings – both in hot water and in energy.

CONVEYOR DRIVE UNIT: Powered by a 1⁄3 H.P. motor. Trip mechanism provided on unload section. Jam protection is provided by load sensing switch at drive platform. Conveyor speed adjustment of 4.0 feet per minute to 8.5 feet per minute is provided on the digital display keypad.

DRAINS: Manual, hand-operated, located at each tank. One manual and automatic master drain to be used for Auto Clean and Auto Delime.

BLOWER DRYER: Includes (2) 2 H.P. fan motors with sealed ball bearings and overload protection. Available in electric or steam heat.

Page 2 of 12 F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher

Page 3

701 S Ridge Avenue, Troy, OH 45374

1-888-4HOBART • www.hobartcorp.com

FT1000 ENERGY RECOVERY

WITH BLOWER DRYER

FLIGHT-TYPE DISHWASHER

No other control system allows easier monitoring.

The digital controls are placed in a convenient panel that lets operators verify proper operation and temperatures at a glance. Digital display indicates the unit is on, and conrms that the doors are closed. Automatic door interlocks prevent the pump and conveyor from operating if the doors are open. Easy-to-read digital display indicates accurate temperatures of the 150°F wash, 160°F power rinse, 160°F dual rinse and 180°F nal rinse — critical for proper HACCP system record-keeping.

Stainless steel pump is built for long life.

The stainless steel pump housing and impeller offer greater durability and long life. The pump motor is totally enclosed and fan cooled (TEFC) to protect it from water spray during dishroom clean-up.

Scrap baskets capture food particles and are easy to clean.

The sloped screens that carry scraps to the scrap baskets are steeper, so less soil gets into the tanks. The basket opening is larger for easy cleaning and basket handles have been designed for easy lift-out access. The load section also features a removable scrap basket which contains soil that is pumped from the ASR section. All scrap baskets and strainers are stainless steel for strength and durability.

The FT1000 Series saves water and energy.

The unit has the lowest water and energy consumption in

the industry, yet provides effective cleaning and sanitizing that meets NSF International requirements.

This is achieved through a carefully balanced ratio of water ow to pressure. Insulated doors and thermal layered curtains also reduce heat loss. The unit’s 58 gallons per hour rinse ow rate saves both water and the energy to heat it.

Variable speed conveyor offers increased throughput.

The conveyor on the FT1000 Series is wider so it can handle more ware. Result: more volume and versatility, quicker work. Its speed is easily adjustable for the type of ware, soiled condition, or workforce requirements. It runs at 4.0 -

8.5 feet per minute.

Energy Recovery system reclaims heat for energy.

The Energy Recovery system’s heat exchanger captures escaping heat and steam from the exhaust air in the dish machine, and uses it to preheat the incoming cold water supply to 120°F before it enters the booster heater. In addition to energy savings, the Energy Recovery system provides a viable use for this otherwise exhausted heat.

Self-draining wash pumps help keep water clean.

Pumps are self-draining when the machine is shut down, so there is no residual water left in the pumps.

Installation is quick and easy with modular design, minimal wiring connections, and single point vent.

Modular design means the FT1000 installs quickly and reliably. The control panel is already in place, premounted to the dual rinse/nal rinse section.

Wiring connections are minimal, and there is only a single vent, saving time and expense. The control box uses a “single plane” circuitry design for easy accessibility during installation and service. The FT1000 is ready to run quickly.

F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher Page 3 of 12

Page 4

6" MINIMUM

ON THE TOP

FLOOR LINE

NOTE: REFER TO LATEST

FT1000 ENERGY RECOVERY

37 1/2"

63 3/8"

62 3/4"

FLOOR LINE

7 3/16"

3 15/16"

OVER FRAME "A"

)

WITH BLOWER DRYER, ELECTRIC L-R

701 S Ridge Avenue, Troy, OH 45374

1-888-4HOBART • www.hobartcorp.com

18 3/4"

P1 P3

52"

44 9/16"

60"

P2 P1

23 3/4"

V1 P3

9 15/16"

25 9/16"

LOAD "B"

35 7/16"

160 1/16"

35 7/16"

8' 7/16"

35 7/16"

5 3/4"

E6E7

11 13/16"

25 9/16"

43 5/16"

23 3/4"

6" AIR

GAP

UNLOAD "C"

EXHAUST HOOD SUPPLIED BY OTHERS

55 11/16"

36 1/2"

EDITION OF NATIONAL

ELECTRICAL CODE AND

LOCAL BUILDING CODES

FOR PROPER CLEARANCE

NOTE: STRAINER PANS REQUIRE 35" TO BE REMOVED. EXTRA CLEARANCE SHOULD BE PROVIDED.

LOAD

END

35"

ASR

40 3/8"

44 13/16"

SEE NOTE (a)

PRE-

WASH

POWER

WASH

DIRECTION OF OPERATION

22" HIGH X 29-13/16" WIDE OPENING WILL HANDLE 18" X 26" BUN PANS

NOTE: CLEARANCE FROM WALL 24" RECOMMENDED, WITH DETERGENT DISPENSER

POWER

RINSE

BLOWER/

AUX RNS

FNL RNS

DRYER

UNLOAD

END

MODEL NO.

FT1023 (7.5'-8'-7.5') FT1024 (8.5'-8'-7.5') FT1025 (9.5'-8'-7.5') FT1025 (7.5'-8'-9') FT1026 (8.5'-8'-9') FT1027 (9.5'-8'-9') FT1027 (7.5'-8'-11') FT1028 (8.5'-8'-11') FT1029 (9.5'-8'-11') FT1030 (7.5'-8'-15') FT1031 (8.5'-8'-15') FT1032 (9.5'-8'-15') FT1032 (7.5'-8'-17') FT1033 (8.5'-8'-17') FT1034 (9.5'-8'-17')

"A""B"

23' 3-1/2" 24' 3-1/4" 25' 3-3/32" 24' 11-1/4" 25' 11" 26' 10-27/32" 26' 10-7/8" 27' 10-5/8" 28' 10-15/32" 30' 6-3/16" 31' 5-15/16" 32' 5-25/32" 32' 5-3/4" 33' 5-1/2" 34' 5-11/32"

7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32"

TE: OVERALL LENGTH OF MACHINE IS DIMENSION "A" + 11 13/16"

36 1/4"

81 7/8"

89 3/8"

SEE NOTE (e

"C"

7' 6-1/2" 7' 6-1/2" 7' 6-1/2" 9' 2-1/4" 9' 2-1/4"

9' 2-1/4" 11' 1-7/8" 11' 1-7/8" 11' 1-7/8" 14' 9-3/16" 14' 9-3/16" 14' 9-3/16" 16' 8-3/4" 16' 8-3/4" 16' 8-3/4"

Page 4 of 12 F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher

Page 5

701 S Ridge Avenue, Troy, OH 45374

480/60/3

35 35

25.0

GENERAL NOTES:

(a)

Y INCREASE 3-1/4"

ELECTRICAL WARNING:

SERVICE WIRE TEMPERATURE RATING: 90C.

PLUMBING NOTES:

G (b)

(c)

HAN 55°F

(d)

WATER SUPPLY LINES AT SERVICE CONNECTION.

VENTILATION NOTES:

ELECTRICAL CONNECTIONS COMMON ON

E2 ELECTRIC CONNECTION (SWITCH CONTACTS) 1/2" CONDUIT. 79-1/8" AFF

ELECTRICAL CONNECTIONS W/O CIRCUIT BREAKERS:

E6 B

E7 1" CONDUIT. 79-1/8" AFF

ELECTRICAL CONNECTIONS

2" CONDUIT, 79-1/8" AFF

PLUMBING CONNECTIONS:

P1 M

P2 COMMON COLD

2" FPT. 7" AFF

VENTILATION REQUIREMENTS:

THERS).

95-3/8" AFF

MODEL: FT1000 ENERGY RECO

ELECTRIC L-R OPER 00-949507 REV A2

08 08 04

ELECTRIC BOOSTER

Electrical and grounding connections must comply with the applicable portions of the National Electrical Code and/or other local electrical codes.

Plumbing connections must comply with applicable sanitar codes. vary, some methods are shown on this drawing.

Pressure gauge not required on pumped rinse machines.

MOTORS AND CONTROLS

32.1 40 40

1-888-4HOBART • www.hobartcorp.com

SERVICE CONNECTION WITH CIRCUIT BREAKERS

(2) SERVICE CONNECTIONS AS SHOWN BELOW

MOTORS,CONTROLS,POWER RINSE & BOOSTER HEAT (TB1)

(1) SERVICE CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3 480/60/3

WASH, DUAL RINSE HEAT, B/D HEAT & BLOWERS (TB2)

(1) SERVICE CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3 480/60/3

SERVICE CONNECTION W/O CIRCUIT BREAKERS (5) SERVICE CONNECTIONS AS SHOWN BELOW

ELECTRIC TANK HEAT, DUAL RINSE 9 KW, BLOWER DRYER HEAT 7 KW & BLOWERS

(1) SERVICE CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3

(1) 20 KW CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3 480/60/3

(1) 22 KW CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3 480/60/3

(1) 18 KW CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3 480/60/3

(1) SERVICE CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208-240/60/3

480/60/3

F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher Page 5 of 12

Drain and ﬁll line conﬁgurations

RATED

AMPS

161.3

156.0

86.5

RATED

AMPS

119.1

113.0

56.5

RATED

AMPS

53.1

50.0

ELECTRIC TANK HEAT, POWER RINSE

RATED

AMPS

60.08

57.38

28.64

ELECTRIC TANK HEAT, WASH

RATED

AMPS

66.0 80 80

63.0 80 80

31.5 45 45

RATED

AMPS

54.0 70 70

51.5 70 70

25.8 35 35

RATED

AMPS

47.2 60 60

y, safety and plumbing

CONDUCTOR

MINIMUM

SUPPLY

AMPACITY

200 200 200 200 125 125

MINIMUM

SUPPLY

AMPACITY

150 150 150 150

70 70

MINIMUM

SUPPLY

AMPACITY

70 70 70 70

MINIMUM

SUPPLY

AMPACITY

MINIMUM

SUPPLY

AMPACITY

MINIMUM

SUPPLY

AMPACITY

MINIMUM

SUPPLY

AMPACITY

FT1000 ENERGY RECOVERY

WITH BLOWER DRYER,

ELECTRIC L-R

THE CONTROL BOX IS ATTACHED TO THE CENTER SECTION AND IS ROTATED 90 DEGREES FOR SHIPPING.

MAXIMUM

PROTECTIVE

DEVICES

MAXIMUM

PROTECTIVE

DEVICE

MAXIMUM

PROTECTIVE

DEVICES

MAXIMUM

PROTECTIVE

DEVICES

0 0 0

MAXIMUM

PROTECTIVE

DEVICES

MAXIMUM

PROTECTIVE

DEVICES

MAXIMUM

PROTECTIVE

DEVICE

AFF = ABOVE FINISHED FLOOR

LL DIMENSIONS TAKEN FROM THE FLOOR LINE MA

WITH LEG ADJUSTMENT. FOR CONVENIENCE WHEN CLEANING, CUSTOMER SHOULD INSTALL

WATER TAP NEAR MACHINE WITH 30 FT. OF HEAVY DUTY HOSE WITH SQUEEZE VALVE.

THIS DRAWING IS SUPPLIED AS A REFERENCE FOR CONNECTION

NFORMATION ONLY. IT WILL NOT BE UTILIZED FOR MANUFACTURING

OF UNIT.

RECOMMENDED WATER HARDNESS TO BE 3 GRAINS OR LESS PER

ALLON FOR BEST RESULTS.

RECOMMENDED BUILDING FLOWING HOT WATER PRESSURE TO THE DISHWASHER IS 40-45 PSI.

RECOMMENDED BUILDING FLOWING COLD WATER PRESSURE TO THE DISHWASHER IS 30-35 PSI. IF COLD WATER IS LESS T CONTACT SALES ENGINEERING.

WATER HAMMER ARRESTOR (MEETING ASSE-1010 STANDARD OR EQUIVALENT) TO BE SUPPLIED (BY OTHERS) IN HOT AND COLD

(e) THE VENT STACK AND ITS ENCLOSURE CAN BE TEMPORARILY REMOVED FROM THE ENERGY RECOVERY UNIT TO YIELD 81-7/8" CLEARANCE FOR DOORWAYS.

ALL MODELS:

ELECTRIC CONNECTION, DETERGENT AND RINSE FEEDER (MACHINE SERVICE VOLTAGE), 1/2" CONDUIT. 79-1/8" AFF

ELECTRIC CONNECTION, MOTORS & CONTROLS, 1" CONDUIT. 79-1/8" AFF

ELECTRIC TANK HEAT CONNECTION, POWER RINSE TANK, 20KW 1" CONDUIT. 79-1/8" AFF

ELECTRIC TANK HEAT CONNECTION, WASH TANK, 22KW. 1" CONDUIT. 79-1/8" AFF

ELECTRIC TANK HEAT CONNECTION, DUAL RINSE TANK, 9KW.

LOWER DRYER HEAT, 7KW & BLOWERS.

1" CONDUIT. 79-1/8" AFF ELECTRIC CONNECTION, BOOSTER, 18KW.

, VENT FAN CONTROL.

WITH CIRCUIT BREAKERS:

E8 ELECTRIC CONNECTION, M OTORS, CONTROLS, POWER RINSE HEAT BOOSTER HEAT (WHEN CIRCUIT BREAKER OPTION IS SPECIFIED). (TB1) 2" CONDUIT, 79-1/8" AFF

E9 ELECTRIC CONNECTION, WASH HEAT, DUAL RINSE HEAT, BLOWER DRYER HEAT & BLOWERS (TB2).

COMMON HOT WATER CONNECTION (AUTOMATIC FILL) 110°F WATER

INIMUM, 1" FPT, 5-1/2" AFF see notes (b) AND (d).

1" FPT, 5-1/2" AFF see notes (c) and (d). COMMON DRAIN CONNECTION.

TWO CONNECTION LOCATIONS; MAY BE DRAINED TO EITHER END OF UNIT, PLUG OPPOSITE END.

MINIMUM OF 24" SQUARE VENT HOOD WITH 6 INCH AIR GAP CAPABLE OF PROVIDING 750 CFM EXHAUST AT STANDARD AIR CONDITIONS (VENT HOOD SUPPLIED AND INSTALLED BY O

BACK DRAFT PREVENTER REQUIRED (SUPPLIED AND INSTALLED BY OTHERS).

WATER CONNECTION, 55°F WATER MINIMUM,

W/BLOWER DRYER

VER

ATION

Page 6

FT1000 ENERGY RECOVERY

FLOOR LINE

7 7/8"

OVER FRAME "A"

3 15/16"

62 3/4"

63 3/8"

6" MINIMUM

ON THE TOP

FLOOR LINE

NOTE: REFER TO LATEST

WITH BLOWER DRYER, ELECTRIC R-L

701 S Ridge Avenue, Troy, OH 45374

1-888-4HOBART • www.hobartcorp.com

55 11/16"

P2 P1

23 3/4"

60"

44 9/16"

UNLOAD "C"

EXHAUST HOOD SUPPLIED BY OTHERS

52"

25 9/16"

43 5/16"

23 3/4"

6" AIR

GAP

9 15/16"

11 13/16"

E6 E7

5 3/4"

8' 7/16"

160 1/16"

18 3/4"

37 1/2"

LOAD "B"

35 7/16"35 7/16"35 7/16"

25 9/16"

89 3/8"

EE NOTE (e)

81 7/8"

EDITION OF NATIONAL

ELECTRICAL CODE AND

LOCAL BUILDING CODES

FOR PROPER CLEARANCE

NOTE: STRAINER PANS REQUIRE 35" TO BE REMOVED. EXTRA CLEARANCE SHOULD BE PROVIDED.

36 1/4"

35"

UNLOAD

END

40 3/8"

44 13/16"

SEE NOTE (a)

BLOWER/

DRYER

22" HIGH X 29-13/16" WIDE OPENING WILL HANDLE 18" X 26" BUN PANS

NOTE: CLEARANCE FROM WALL 24" RECOMMENDED, WITH DETERGENT DISPENSER

FNL

RNS

AUX

POWER

RNS

RINSE

POWER

WASH

PRE-

WASH

ASR

LOAD

END

DIRECTION OF OPERATION

MODEL NO.

"A""B"

23' 3-1/2" 24' 3-1/4" 25' 3-3/32" 24' 11-1/4" 25' 11" 26' 10-27/32" 26' 10-7/8" 27' 10-5/8" 28' 10-15/32" 30' 6-3/16" 31' 5-15/16" 32' 5-25/32" 32' 5-3/4" 33' 5-1/2" 34' 5-11/32"

7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32"

TE: OVERALL LENGTH OF MACHINE IS DIMENSION "A" + 11 13/16"

36 1/2"

"C"

7' 6-1/2"

9' 2-1/4"

9' 2-1/4" 11' 1-7/8" 11' 1-7/8" 11' 1-7/8" 14' 9-3/16" 14' 9-3/16" 14' 9-3/16" 16' 8-3/4" 16' 8-3/4" 16' 8-3/4"

Page 6 of 12 F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher

Page 7

701 S Ridge Avenue, Troy, OH 45374

480/60/3

35 35

25.0

GENERAL NOTES:

(a)

Y INCREASE 3-1/4"

ELECTRICAL WARNING:

SERVICE WIRE TEMPERATURE RATING: 90C.

PLUMBING NOTES:

G (b)

(c)

HAN 55°F

(d)

WATER SUPPLY LINES AT SERVICE CONNECTION.

VENTILATION NOTES:

ELECTRICAL CONNECTIONS COMMON ON

E2 ELECTRIC CONNECTION (SWITCH CONTACTS) 1/2" CONDUIT. 79-1/8" AFF

ELECTRICAL CONNECTIONS W/O CIRCUIT BREAKERS:

E6 B

E7 1" CONDUIT. 79-1/8" AFF

ELECTRICAL CONNECTIONS

2" CONDUIT, 79-1/8" AFF

PLUMBING CONNECTIONS:

P1 M

P2 COMMON COLD

2" FPT. 7" AFF

VENTILATION REQUIREMENTS:

THERS).

95-3/8" AFF

MODEL: FT1000 ENERGY RECO

ELECTRIC R-L OPER 00-949506 REV A2

08 08 04

ELECTRIC BOOSTER

Electrical and grounding connections must comply with the applicable portions of the National Electrical Code and/or other local electrical codes.

Plumbing connections must comply with applicable sanitar codes. vary, some methods are shown on this drawing.

Pressure gauge not required on pumped rinse machines.

MOTORS AND CONTROLS

1-888-4HOBART • www.hobartcorp.com

SERVICE CONNECTION WITH CIRCUIT BREAKERS

(2) SERVICE CONNECTIONS AS SHOWN BELOW

MOTORS,CONTROLS,POWER RINSE & BOOSTER HEAT (TB1)

(1) SERVICE CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3 480/60/3

WASH, DUAL RINSE HEAT, B/D HEAT & BLOWERS (TB2)

(1) SERVICE CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3 480/60/3

SERVICE CONNECTION W/O CIRCUIT BREAKERS (5) SERVICE CONNECTIONS AS SHOWN BELOW

ELECTRIC TANK HEAT, DUAL RINSE 9 KW, BLOWER DRYER HEAT 7 KW & BLOWERS

(1) SERVICE CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3

(1) 20 KW CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3 480/60/3

(1) 22 KW CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3 480/60/3

(1) 18 KW CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208/60/3 240/60/3 480/60/3

(1) SERVICE CONNECTION AS SHOWN BELOW

ELEC.

SPECS.

208-240/60/3

480/60/3

F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher Page 7 of 12

Drain and ﬁll line conﬁgurations

RATED

AMPS

161.3

156.0

86.5

RATED

AMPS

119.1

113.0

56.5

RATED

AMPS

53.1

50.0

ELECTRIC TANK HEAT, POWER RINSE

RATED

AMPS

60.08

57.38

28.64

ELECTRIC TANK HEAT, WASH

RATED

AMPS

66.0 80 80

63.0 80 80

31.5 45 45

RATED

AMPS

54.0 70 70

51.5 70 70

25.8 35 35

RATED

AMPS

47.2 60 60

32.1 40 40

y, safety and plumbing

CONDUCTOR

MINIMUM

SUPPLY

AMPACITY

200 200 200 200 125 125

MINIMUM

SUPPLY

AMPACITY

150 150 150 150

70 70

MINIMUM

SUPPLY

AMPACITY

70 70 70 70

MINIMUM

SUPPLY

AMPACITY

MINIMUM

SUPPLY

AMPACITY

MINIMUM

SUPPLY

AMPACITY

MINIMUM

SUPPLY

AMPACITY

FT1000 ENERGY RECOVERY

WITH BLOWER DRYER,

ELECTRIC R-L

THE CONTROL BOX IS ATTACHED TO THE CENTER SECTION AND IS ROTATED 90 DEGREES FOR SHIPPING.

MAXIMUM

PROTECTIVE

DEVICES

MAXIMUM

PROTECTIVE

DEVICE

MAXIMUM

PROTECTIVE

DEVICES

MAXIMUM

PROTECTIVE

DEVICES

0 0 0

MAXIMUM

PROTECTIVE

DEVICES

MAXIMUM

PROTECTIVE

DEVICES

MAXIMUM

PROTECTIVE

DEVICE

AFF = ABOVE FINISHED FLOOR

LL DIMENSIONS TAKEN FROM THE FLOOR LINE MA

WITH LEG ADJUSTMENT. FOR CONVENIENCE WHEN CLEANING, CUSTOMER SHOULD INSTALL

WATER TAP NEAR MACHINE WITH 30 FT. OF HEAVY DUTY HOSE WITH SQUEEZE VALVE.

THIS DRAWING IS SUPPLIED AS A REFERENCE FOR CONNECTION

NFORMATION ONLY. IT WILL NOT BE UTILIZED FOR MANUFACTURING

OF UNIT.

RECOMMENDED WATER HARDNESS TO BE 3 GRAINS OR LESS PER

ALLON FOR BEST RESULTS.

RECOMMENDED BUILDING FLOWING HOT WATER PRESSURE TO THE DISHWASHER IS 40-45 PSI.

RECOMMENDED BUILDING FLOWING COLD WATER PRESSURE TO THE DISHWASHER IS 30-35 PSI. IF COLD WATER IS LESS T CONTACT SALES ENGINEERING.

WATER HAMMER ARRESTOR (MEETING ASSE-1010 STANDARD OR EQUIVALENT) TO BE SUPPLIED (BY OTHERS) IN HOT AND COLD

(e) THE VENT STACK AND ITS ENCLOSURE CAN BE TEMPORARILY REMOVED FROM THE ENERGY RECOVERY UNIT TO YIELD 81-7/8" CLEARANCE FOR DOORWAYS.

ALL MODELS:

ELECTRIC CONNECTION, DETERGENT AND RINSE FEEDER (MACHINE SERVICE VOLTAGE), 1/2" CONDUIT. 79-1/8" AFF

ELECTRIC CONNECTION, MOTORS & CONTROLS, 1" CONDUIT. 79-1/8" AFF

ELECTRIC TANK HEAT CONNECTION, POWER RINSE TANK, 20KW 1" CONDUIT. 79-1/8" AFF

ELECTRIC TANK HEAT CONNECTION, WASH TANK, 22KW. 1" CONDUIT. 79-1/8" AFF

ELECTRIC TANK HEAT CONNECTION, DUAL RINSE TANK, 9KW.

LOWER DRYER HEAT, 7KW & BLOWERS.

1" CONDUIT. 79-1/8" AFF ELECTRIC CONNECTION, BOOSTER, 18KW.

, VENT FAN CONTROL.

WITH CIRCUIT BREAKERS:

E8 ELECTRIC CONNECTION, M OTORS, CONTROLS, POWER RINSE HEAT BOOSTER HEAT (WHEN CIRCUIT BREAKER OPTION IS SPECIFIED). (TB1) 2" CONDUIT, 79-1/8" AFF

E9 ELECTRIC CONNECTION, WASH HEAT, DUAL RINSE HEAT, BLOWER DRYER HEAT & BLOWERS (TB2).

COMMON HOT WATER CONNECTION (AUTOMATIC FILL) 110°F WATER

INIMUM, 1" FPT, 5-1/2" AFF see notes (b) AND (d).

1" FPT, 5-1/2" AFF see notes (c) and (d). COMMON DRAIN CONNECTION.

TWO CONNECTION LOCATIONS; MAY BE DRAINED TO EITHER END OF UNIT, PLUG OPPOSITE END.

MINIMUM OF 24" SQUARE VENT HOOD WITH 6 INCH AIR GAP CAPABLE OF PROVIDING 750 CFM EXHAUST AT STANDARD AIR CONDITIONS (VENT HOOD SUPPLIED AND INSTALLED BY O

BACK DRAFT PREVENTER REQUIRED (SUPPLIED AND INSTALLED BY OTHERS).

WATER CONNECTION, 55°F WATER MINIMUM,

W/BLOWER DRYER

VER

ATION

Page 8

FT1000 ENERGY RECOVERY

63 3/8"

Electrical and grounding connections must comply with the applicable portions of the National Electrical Code and/or other local electrical codes.

Plumbing connections must comply with applicable sanitar codes. vary, some methods are shown on this drawing.

Pressure gauge not required on pumped rinse machines.

62 3/4"

FLOOR LINE

3 15/16"

OVER FRAME "A"

7 7/8"

MODEL: FT1000 ENERGY RECO

STEAM L-R OPER 00-949507 REV A2

WITH BLOWER DRYER, STEAM L-R

15 11/16"

701 S Ridge Avenue, Troy, OH 45374

1-888-4HOBART • www.hobartcorp.com

55 3/16"

51 15/16"

44 9/16"

33"

14 11/16"

5 15/16"

68 13/16"

33 3/8"

2 15/16"

6 3/4"

11 9/16"

21 3/4"

23"

23 1/8"

37 1/2"

18 3/4"

25 9/16"

LOAD

END

LOAD "B"

ASR

35 7/16"

WASH

PRE-

160 1/16"

35 7/16" 35 7/16"

POWER

WASH

8' 7/16"

5 3/4"

POWER

9 15/16"

11 13/16"

28 7/16"

38 1/4"

RINSE

AUX RNS

FNL RNS

25 9/16"

EXHAUST HOOD SUPPLIED BY OTHERS

43 5/16"

23 3/4"

6" AIR

GAP

UNLOAD "C"

BLOWER/

DRYER

UNLOAD

END

23 3/4"

81 7/8"

28 15/16"

55 11/16"

89 3/8"

SEE NOTE (f)

36 1/2"

Page 8 of 12 F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher

Drain and ﬁll line conﬁgurations

y, safety and plumbing

DIRECTION OF OPERATION

36 1/4"

W/BLOWER DRYER

ATION

VER

Page 9

701 S Ridge Avenue, Troy, OH 45374

6" MINIMUM

ON THE TOP

FLOOR LINE

NOTE: REFER TO LATEST

GENERAL NOTES:

(a)

Y INCREASE 3-1/4"

ELECTRICAL WARNING:

SERVICE WIRE TEMPERATURE RATING: 90C.

VENTILATION NOTES:

(f)

PLUMBING NOTES:

G (b)

(c)

THE

(d)

(e) AT THE DISHWASHER, CONTACT SALES ENGINEERING.

ELECTRICAL CONNECTIONS COMMON ON

E2 ELECTRIC CONNECTION (SWITCH CONTACTS) 1/2" CONDUIT. 79-1/8" AFF

ELECTRICAL CONNECTIONS WITH &

1" CONDUIT. 79-1/8" AFF

PLUMBING CONNECTIONS:

)

(WHEN STEAM BOOSTER OPTION IS SPECIFIED)

3/4" FPT, 13" AFF

VENTILATION REQUIREMENTS:

THERS).

95-3/8" AFF

1-888-4HOBART • www.hobartcorp.com

FT1000 ENERGY RECOVERY

WITH BLOWER DRYER,

STEAM L-R

SERVICE CONNECTION WITH & W/O CIRCUIT BREAKERS

(1) SERVICE CONNECTION AS SHOWN BELOW

MOTORS AND CONTROLS

ELEC.

SPECS.

208-240/60/3

480/60/3

MODEL NO.

TE: OVERALL LENGTH OF MACHINE IS DIMENSION "A" + 11 13/16"

RATED

AMPS

54.5 70 70

36.4 45 45

MINIMUM

SUPPLY

CONDUCTOR

AMPACITY

"A""B"

23' 3-1/2" 24' 3-1/4" 25' 3-3/32" 24' 11-1/4" 25' 11" 26' 10-27/32" 26' 10-7/8" 27' 10-5/8" 28' 10-15/32" 30' 6-3/16" 31' 5-15/16" 32' 5-25/32" 32' 5-3/4" 33' 5-1/2" 34' 5-11/32"

MAXIMUM

PROTECTIVE

DEVICE

7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32"

"C"

7' 6-1/2" 7' 6-1/2" 7' 6-1/2" 9' 2-1/4" 9' 2-1/4"

9' 2-1/4" 11' 1-7/8" 11' 1-7/8" 11' 1-7/8" 14' 9-3/16" 14' 9-3/16" 14' 9-3/16" 16' 8-3/4" 16' 8-3/4" 16' 8-3/4"

THE CONTROL BOX IS ATTACHED TO THE CENTER SECTION AND IS ROTATED 90 DEGREES FOR SHIPPING.

AFF = ABOVE FINISHED FLOOR

LL DIMENSIONS TAKEN FROM THE FLOOR LINE MA

WITH LEG ADJUSTMENT. FOR CONVENIENCE WHEN CLEANING, CUSTOMER SHOULD INSTALL

WATER TAP NEAR MACHINE WITH 30 FT. OF HEAVY DUTY HOSE WITH SQUEEZE VALVE.

THIS DRAWING IS SUPPLIED AS A REFERENCE FOR CONNECTION

NFORMATION ONLY. IT WILL NOT BE UTILIZED FOR MANUFACTURING

OF UNIT.

RECOMMENDED WATER HARDNESS TO BE 3 GRAINS OR LESS PER

ALLON FOR BEST RESULTS.

RECOMMENDED BUILDING FLOWING HOT WATER PRESSURE TO THE DISHWASHER IS 40-45 PSI.

RECOMMENDED BUILDING FLOWING COLD WATER PRESSURE TO DISHWASHER IS 30-35 PSI. IF COLD WATER IS LESS THAN 55°F CONTACT SALES ENGINEERING.

WATER HAMMER ARRESTOR (MEETING ASSE-1010 STANDARD OR EQUIVALENT) TO BE SUPPLIED (BY OTHERS) IN HOT AND COLD WATER SUPPLY LINES AT SERVICE CONNECTION.

IF STEAM PRESSURE IS UNDER 10 PSI FLOWING PRESSURE

THE VENT STACK AND ITS ENCLOSURE CAN BE TEMPORARILY REMOVED FROM THE ENERGY RECOVERY UNIT TO YIELD 81-7/8" CLEARANCE FOR DOORWAYS.

EDITION OF NATIONAL

ELECTRICAL CODE AND

LOCAL BUILDING CODES

FOR PROPER CLEARANCE

NOTE: STRAINER PANS REQUIRE 35" TO BE REMOVED. EXTRA CLEARANCE SHOULD BE PROVIDED.

35"

MINIMUM OF 24" SQUARE VENT HOOD WITH 6 INCH AIR GAP CAPABLE OF PROVIDING 750 CFM EXHAUST AT STANDARD AIR CONDITIONS (VENT HOOD SUPPLIED AND INSTALLED BY O

BACK DRAFT PREVENTER REQUIRED (SUPPLIED AND INSTALLED BY OTHERS).

F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher Page 9 of 12

40 3/8"

44 13/16"

SEE NOTE (a)

22" HIGH X 29-13/16" WIDE OPENING WILL HANDLE 18" X 26" BUN PANS

NOTE: CLEARANCE FROM WALL 24" RECOMMENDED, WITH DETERGENT DISPENSER

ALL MODELS:

ELECTRIC CONNECTION, DETERGENT AND RINSE FEEDERS (MACHINE SERVICE VOLTAGE), 1/2" CONDUIT. 79-1/8" AFF

, VENT FAN CONTROL.

W/O CIRCUIT BREAKERS:

ELECTRIC CONNECTION, MOTORS & CONTROLS

P1 COMMON HOT WATER CONNECTION (AUTOMATIC FILL) 110°F WATER MINIMUM, 1" FPT, 5-1/2" AFF see notes (b) AND (d).

P2 COMMON COLD WATER CONNECTION, 55°F WATER MINIMUM, 1" FPT, 5-1/2" AFF see notes (c) and (d).

P3 COMMON DRAIN CONNECTION. TWO CONNECTION LOCATIONS; MAY BE DRAINED TO EITHER END OF UNIT, PLUG OPPOSITE END. 2" FPT. 7" AFF

P4 COMMON STEAM CONNECTION (TANK HEAT, STEAM BOOSTER &

BLOWER DRYER). 1-1/2" FPT, 4-3/8" AFF (10-45 PSI FLOWING PRESSURE see note (e).

P5 STEAM RELIEF VALVE, (WHEN STEAM BOOSTER OPTION IS SPECIFIED) 1" FPT, MUST BE PIPED TO OPEN DRAIN RECEIVER IN THE FLOOR. 16-15/16" AFF

P6 HOT WATER RELIEF VALVE, 3/4" FPT, MUST BE PIPED TO OPEN DRAIN RECEIVER IN THE FLOOR. 15-9/16" AFF

P7 CONDENSATE RETURN, GRAVITY CONNECTION (TANK HEAT), BUCKET TYPE TRAPS FURNISHED, 3 CONNECTIONS. 3/4" FPT, 11" AFF

P8 CONDENSATE RETURN, GRAVITY CONNECTION (WHEN STEAM BOOSTER OPTION IS SPECIFIED), BUCKET TYPE TRAP FURNISHED. 3/4" FPT, 4-3/4" AFF

P9 CONDENSATE RETURN, GRAVITY CONNECTION (STEAM BLOWER DRYER), BUCKET TYPE TRAP FURNISHED.

Page 10

FT1000 ENERGY RECOVERY

37 1/2"

63 3/8"

FLOOR LINE

7 3/16"

3 15/16"

OVER FRAME "A"

62 3/4"

SEE NO

MODEL: FT1000 ENERGY RECO

STEAM R-L OPER 00-949506 REV A2

Electrical and grounding connections must comply with the applicable portions of the National Electrical Code and/or other local electrical codes.

Plumbing connections must comply with applicable sanitar codes. vary, some methods are shown on this drawing.

Pressure gauge not required on pumped rinse machines.

WITH BLOWER DRYER, STEAM R-L

701 S Ridge Avenue, Troy, OH 45374

1-888-4HOBART • www.hobartcorp.com

28 15/16"

55 11/16"

P2 P1

23 3/4"

23 1/8"

23 1/16"

11 5/8"

6 3/4"

60"

52"

44 9/16"

32 15/16"

14 5/8"

5 7/8"

11 13/16"

28 7/16"

38 1/4"

53 3/8"

22 5/8"

9 15/16"

88 3/4"

15 11/16"

18 3/4"

160 1/16"

UNLOAD "C"

UNLOAD

89 3/8"

TE (f)

81 7/8"

36 1/4"

Page 10 of 12 F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher

Drain and ﬁll line conﬁgurations

y, safety and plumbing

END

25 9/16"

EXHAUST HOOD SUPPLIED BY OTHERS

43 5/16"

BLOWER/

DRYER

23 3/4" 6" AIR

GAP

FNL RNS

5 3/4"

POWER

AUX

RINSE

RNS

8' 7/16"

POWER

WASH

DIRECTION OF OPERATION

35 7/16"35 7/16"35 7/16"

PRE-

WASH

LOAD "B"

ASR

25 9/16"

LOAD

END

W/BLOWER DRYER

ATION

36 1/2"

VER

Page 11

701 S Ridge Avenue, Troy, OH 45374

6" MINIMUM

ON THE TOP

FLOOR LINE

NOTE: REFER TO LATEST

VENTILATION REQUIREMENTS:

THERS).

95-3/8" AFF

GENERAL NOTES:

(a)

Y INCREASE 3-1/4"

ELECTRICAL WARNING:

SERVICE WIRE TEMPERATURE RATING: 90C.

PLUMBING NOTES:

G (b)

(c)

THE

(d)

(e) AT THE DISHWASHER, CONTACT SALES ENGINEERING.

VENTILATION NOTES:

(f)

ELECTRICAL CONNECTIONS COMMON ON

E2 ELECTRIC CONNECTION (SWITCH CONTACTS) 1/2" CONDUIT. 79-1/8" AFF

ELECTRICAL CONNECTIONS WITH &

1" CONDUIT. 79-1/8" AFF

PLUMBING CONNECTIONS:

P1 M

P3 COMMON DRAIN CONNECTION

)

1 P6

(WHEN STEAM BOOSTER OPTION IS SPECIFIED) 3 1

3 P8

3 P9

3/4" FPT, 13" AFF

1-888-4HOBART • www.hobartcorp.com

FT1000 ENERGY RECOVERY

WITH BLOWER DRYER,

STEAM R-L

SERVICE CONNECTION WITH & W/O CIRCUIT BREAKERS

(1) SERVICE CONNECTION AS SHOWN BELOW

MOTORS AND CONTROLS

ELEC.

SPECS.

208-240/60/3

480/60/3

MODEL NO.

TE: OVERALL LENGTH OF MACHINE IS DIMENSION "A" + 11 13/16"

RATED

AMPS

54.5 70 70

36.4 45 45

MINIMUM

SUPPLY

CONDUCTOR

AMPACITY

"A""B"

23' 3-1/2" 24' 3-1/4" 25' 3-3/32" 24' 11-1/4" 25' 11" 26' 10-27/32" 26' 10-7/8" 27' 10-5/8" 28' 10-15/32" 30' 6-3/16" 31' 5-15/16" 32' 5-25/32" 32' 5-3/4" 33' 5-1/2" 34' 5-11/32"

MAXIMUM

PROTECTIVE

DEVICE

7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32" 7' 8-1/2" 8' 8-1/4" 9' 8-3/32"

"C"

7' 6-1/2" 7' 6-1/2" 7' 6-1/2" 9' 2-1/4" 9' 2-1/4"

9' 2-1/4" 11' 1-7/8" 11' 1-7/8" 11' 1-7/8" 14' 9-3/16" 14' 9-3/16" 14' 9-3/16" 16' 8-3/4" 16' 8-3/4" 16' 8-3/4"

THE CONTROL BOX IS ATTACHED TO THE CENTER SECTION AND IS

ROTATED 90 DEGREES FOR SHIPPING. AFF = ABOVE FINISHED FLOOR

LL DIMENSIONS TAKEN FROM THE FLOOR LINE MA

WITH LEG ADJUSTMENT. FOR CONVENIENCE WHEN CLEANING, CUSTOMER SHOULD INSTALL

WATER TAP NEAR MACHINE WITH 30 FT. OF HEAVY DUTY HOSE WITH SQUEEZE VALVE.

THIS DRAWING IS SUPPLIED AS A REFERENCE FOR CONNECTION

NFORMATION ONLY. IT WILL NOT BE UTILIZED FOR MANUFACTURING

OF UNIT.

RECOMMENDED WATER HARDNESS TO BE 3 GRAINS OR LESS PER

ALLON FOR BEST RESULTS.

RECOMMENDED BUILDING FLOWING HOT WATER PRESSURE TO THE DISHWASHER IS 40-45 PSI.

RECOMMENDED BUILDING FLOWING COLD WATER PRESSURE TO DISHWASHER IS 30-35 PSI. IF COLD WATER IS LESS THAN 55°F CONTACT SALES ENGINEERING.

WATER HAMMER ARRESTOR (MEETING ASSE-1010 STANDARD OR EQUIVALENT) TO BE SUPPLIED (BY OTHERS) IN HOT AND COLD WATER SUPPLY LINES AT SERVICE CONNECTION.

IF STEAM PRESSURE IS UNDER 10 PSI FLOWING PRESSURE

THE VENT STACK AND ITS ENCLOSURE CAN BE TEMPORARILY REMOV FROM THE ENERGY RECOVERY UNIT TO YIELD 81-7/8" CLEARANCE FOR DOORWAYS.

EDITION OF NATIONAL

ELECTRICAL CODE AND

LOCAL BUILDING CODES

FOR PROPER CLEARANCE

NOTE: STRAINER PANS REQUIRE 35" TO BE REMOVED. EXTRA CLEARANCE SHOULD BE PROVIDED.

F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher Page 11 of 12

35"

MINIMUM OF 24" SQUARE VENT HOOD WITH 6 INCH AIR GAP CAPABLE OF PROVIDING 750 CFM EXHAUST AT STANDARD AIR CONDITIONS (VENT HOOD SUPPLIED AND INSTALLED BY O

BACK DRAFT PREVENTER REQUIRED (SUPPLIED AND INSTALLED BY OTHERS).

40 3/8"

44 13/16"

SEE NOTE (a)

22" HIGH X 29-13/16" WIDE OPENING WILL HANDLE 18" X 26" BUN PANS

NOTE: CLEARANCE FROM WALL 24" RECOMMENDED, WITH DETERGENT DISPENSER

ALL MODELS:

ELECTRIC CONNECTION, DETERGENT AND RINSE FEEDER (MACHINE SERVICE VOLTAGE), 1/2" CONDUIT. 79-1/8" AFF

, VENT FAN CONTROL.

W/O CIRCUIT BREAKERS:

ELECTRIC CONNECTION, MOTORS & CONTROLS

COMMON HOT WATER CONNECTION (AUTOMATIC FILL) 110°F WATER

INIMUM, 1" FPT, 5-1/2" AFF see notes (b) AND (d).

COMMON COLD WATER CONNECTION, 55°F WATER MINIMUM,

1" FPT, 5-1/2" AFF see notes (c) and (d).

TWO CONNECTION LOCATIONS; MAY BE DRAINED TO EITHER END OF UNIT, PLUG OPPOSITE END. 2" FPT. 7" AFF

COMMON STEAM CONNECTION (TANK HEAT, STEAM BOOSTER & BLOWER DRYER). 1-1/2" FPT, 4-3/8" AFF (10-45 PSI FLOWING PRESSURE see note (e).

STEAM RELIEF VALVE, (WHEN STEAM BOOSTER OPTION IS SPECIFIED) 1" FPT, MUST BE PIPED TO OPEN DRAIN RECEIVER IN THE FLOOR.

6-15/16" AFF

HOT WATER RELIEF VALV E,

/4" FPT, MUST BE PIPED TO OPEN DRAIN RECEIVER IN THE FLOOR. 5-9/16" AFF

CONDENSATE RETURN, GRAVITY CONNECTION (TANK HEAT), BUCKET TYPE TRAPS FURNISHED, 3 CONNECTIONS.

/4" FPT, 11" AFF

CONDENSATE RETURN, GRAVITY CONNECTION (WHEN STEAM BOOSTER OPTION IS SPECIFIED), BUCKET TYPE TRAP FURNISHED.

/4" FPT, 4-3/4" AFF

CONDENSATE RETURN, GRAVITY CONNECTION (STEAM BLOWER DRYER), BUCKET TYPE TRAP FURNISHED.

Page 12

FT1000 ENERGY RECOVERY WITH BLOWER DRYER FLIGHT-TYPE DISHWASHER

701 S Ridge Avenue, Troy, OH 45374

1-888-4HOBART • www.hobartcorp.com

FT (ight type) Models—many additional variations of these model specications are available. Engineering data furnished on request. Numbers in parentheses,

in feet of the following respectively; Loading section, Washing and Power Rinsing sections, Unloading section.

after model number from left to right, represent length

FT1000 Energy Recovery with Blower Dryer Series

(7.5, 9 Load / 8 Center / 7.5, 9, 11 Unload)

Machine Ratings (Mechanical)

Conveyor Speed — Feet per minute 4.0 - 8.5

Dishes per Hour 14,316

Motor — Horsepower ASR Soil - 1⁄4; ASR Wash - 1⁄3; Pre-Wash - 31⁄2; Wash - 5; Rinse - 5;

Tank Capacity — Gallons ASR - 7.2; Pre-Wash - 40; Wash - 40; Rinse - 40; Dual Rinse - 7.2

Rate of Final Rinse — Gallons per minute

(Pumped rinse) .97

Final Rinse Consumption — Gallons per hour (Pumped rinse) 58

Exhaust Requirements — Cubic feet per minute 750 (at standard air conditions)

Latent/Sensible Heat — BTU per hour Electric - Latent: 87,400 / Sensible: 37,400

Electric Heat Requirements —

Tank Heat - Kilowatt (Regulated)

Optional Electric Booster - Kilowatt

Optional Blower Dryer - Kilowatt

Steam Heat Requirements —

Steam Consumption

Tank Heat - Pounds per hour - maximum (Regulated) - based on 10 to 45 PSI steam at the machine

Optional Steam Booster - Pounds per hour - maximum

- based on 20 PSI steam, 110°F incoming water raised to 185°F (75°F rise) (180°F minimum)

Optional Steam Blower Dryer - Pounds per hour maximum - based on 20 PSI steam

Peak Rate of Drain Flow — Gallons per minute Initial rate with full tanks 38

Shipping Weight Crated Varies by individual model - consult your Hobart representative

Dual Rinse - 1⁄6; Final Rinse - 1⁄2; Conveyor - 1⁄3; Blower Dryer (2) 2

Steam - Latent: 103,900 / Sensible: 44,500

Disconnect switches are recommended for each power circuit connected

to dishwasher. These disconnect switches are NOT furnished by Hobart

and should be installed by the electrical contractor at the time of installation.

Circuit breakers optional at extra cost.

Total tank heat - 51KW (Wash, Rinse, Dual Rinse)

18KW - 110°F incoming water raised to 185°F (75°F rise) (180°F minimum)

7.0 KW

213 lbs./150°F Wash minimum - 160°F Rinse minimum -

160°F Dual Rinse minimum

42 lbs./180°F Final Rinse minimum

30 lbs.

As continued product improvement is a policy of Hobart, specications are subject to change without notice.

Page 12 of 12 F40392 – FT1000 Energy Recovery with Blower Dryer Flight-Type Dishwasher

F40392 (REV. 09/14) LITHO IN U.S.A. (H-01)

Hobart Food Machines FT1000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
