ECO-SHOWER™
Heavy-Duty Cleaner & Degreaser

1500

Introduction

Powerful degreaser in the tradition of Techspray’s Blue Shower® cleaners. Innovative
formula uses naturally-based ingredients like citrus and soy oils to soak in and quickly cut
through oil and grease.

Use full strength for heavy grease or dilute with water for general cleaning (see below for
dilution instructions). Ideal for cleaning tools, parts, shop equipment, motors, and
industrial working surfaces. Leaves high-gloss finish, so ideal for stainless steel.

Convenient pre-saturated wipes available in a pop-up dispenser. Wipe material is low
linting with patented dual-texture that has scrubbing surface on one side, wiping surface
on the other.

One quart (with a trigger sprayer) and one gallon containers are ideal for surface and tool cleaning.
Packaging is selected to be easily recyclable. Quart labels made of recycled paper, and cartons
made of 40% recycled material. Trigger pump on quart eliminates the need for propellants, which
can have a global warming impact.

Eco-ShowerTM Cleaner is fully compliant with CARB (California Air Resource Board) requirements.
Also compliant with European REACH (Registration, Evaluation, Authorization & Restriction of

Chemicals) and WEEE (Waste Electrical and Electronic Equipment Directive) initiatives. It does not
contain RoHS (Restriction of Hazardous Substances) restricted substances, SVHC (Substances of
Very High Concern) list substances, or halides.

Features / Benefits

• Clean heavy oil & grease

• Concentrated and dilutable

• Non-flammable

• Non-corrosive, moderate pH

• Safe on most plastics and painted surfaces

• Biodegradable

• Low VOC, zero GWP

• Non-ozone depleting

Specifications

• Daimler / Mercedes Benz – MSC# 3104 (1500 bulk)

Product Information

Documentation Provided By HMC Electronics

33 Springdale Ave. Canton, MA 02021

http://www.hmcelectronics.com

[phone]

2 Copyright 2009 Techspray.

For Commercial Use Only

Applications

• Removal of heavy greases and oils

• Cleaning on and around heavy machinery

• Cleaning shelves and other surfaces

Application

Suggestions

Heavy degreasing Leave on 30-60 sec
Light degreasing 2:1 to 10:1
Batch degreasing Can be used in ultrasonic tank full strength or

diluted, depending on soil
Power washer 10:1 to 30:1
Concrete spot cleaning Hose off after 15 min
Adhesive cleaning Leave on 30-60 sec
Stainless steel cleaning (polished) Wipe until dry
Carpet/upholstery spot remover 1:1 to 3:1 to avoid foaming

e.g. oil, paint
Telecomm cable lube “ickypic” Use full strength
Adhesive cleaning (dry) Let soak

Dilution Instructions

• Full strength – Caked-on grease (e.g. compressors, engines, etc.), grills*, oil stains*

• 10 parts water : 1 part Eco-Shower – Greasy tools, floor (e.g. concrete) stains*, vents,

heavily stained (food) appliances*, scuff marks on doors, heavy grease on wheels

• 30-50 parts water : 1 part Eco-Shower – Chrome fittings, stainless steel, very light general
cleaning

* If on food processing equipment or walking surfaces, must be washed/mopped thoroughly to

avoid slippery surface and undesirable residues.

About TECHSPRAY RENEW

TM

TECHSPRAY RENEWTM is a brand that represents High Performance Eco-CleaningTM.

Techspray

®

has applied our expertise in solvent cleaning to formulate some of the most effective
eco-friendly cleaners on the market. Performance is our top priority, using the best “green”
solutions as they become available. We all are at the cusp of the ongoing movement toward
sustainable products, packaging, and processes. It is Techspray’s intention to stay at the cutting­edge while keeping our products powerful and cost effective.

Directions

• Spray and saturate the soiled area. Let soak for 30-60 seconds depending on thickness of the

grease.

• Using a lint-free wipe (we recommend Techspray 2364-50 or 2365-300 wipes), wipe lightly at

first to allow cleaning agent to break down residues.

• Continue to wipe in a circular motion until the grease or oil is fully removed.

• For thick greases, reapplication may be needed.

• On walking surfaces, mop thoroughly after cleaning.

• Material is easily rinsed by wiping with water dampened cloth.

• Dispose of soiled wipe as appropriate depending on the type of material removed.

Chemical Components

Component CAS#

Alcohols,C10-14, ethoxylated .......................................................................... 66455-15-0

d-Limonene...................................................................................................... 5989-27-5

Alkyl C16-C18 Methyl Esters ........................................................................... 67784-80-9

Includes other hazardous components in non-reportable quantities.

Documentation Provided By HMC Electronics

33 Springdale Ave. Canton, MA 02021

http://www.hmcelectronics.com

[phone]

3 Copyright 2009 Techspray.

For Commercial Use Only

Chemical Properties (MSDS available on request)

• EXPOSURE LIMIT: Limits on components not established.

Manufacturer’s recommendation 1000 ppm.

• PHYSICAL STATE: Liquid

• ODOR: Citrus odor

• APPEARANCE: Clear, mobile liquid

• pH: 6-7

• PERCENT VOLATILE: 99% at 104°C

• VAPOR PRESSURE: < 0.014 mmHg@20°C (VOC Composite Vapor Pressure)

• BOILING POINT : 203°F (95°C)

• FLASHPOINT AND METHOD (TAG Closed Cup): None to boiling point

• SOLUBILITY IN WATER: Dispersible

• DENSITY: ~1.00 at 25°C

• VOC (by wt): 3.24%, 32.4 g/l

Performance

Tested according to modified MIL-PRF-29608 4.59 standards:
Soil is applied to cleaning coupons, sprayed with cleaning fluid, allowed to sit 10-seconds, then a poly-cellulose wipe
(saturated with same cleaning fluid) is dragged across one time using a dowel to maintain consistent pressure.
Percentage refers to the amount of soil (by weight) removed from stainless steel test coupon.

* Composition of lube/soil blend: 2 parts Mystik #2, 2 parts Lubriplate #1242, 2 parts Slick 50 #1, 1 part Lubriplate

80W-140, 1 part Silicone TBF9-350, 1 part soil.

SAMPLE ID SOIL

CLEANING

EFFICIENCY

1500 Eco-Shower

Lube/Soil Blend*

94%

Simple Green

Lube/Soil Blend*

89%

Hydroforce

Lube/Soil Blend*

90%

Control dry wipe

Lube/Soil Blend*

29%

Control H2O wet wipe

Lube/Soil Blend*

42%

SAMPLE ID SOIL

CLEANING

EFFICIENCY

1500 Eco-Shower

Mystik #2

90%

Simple Green

Mystik #2

79%

Hydroforce

Mystik #2

79%

Control dry wipe

Mystik #2

17%

Control H2O wet wipe

Mystik #2

16%

Documentation Provided By HMC Electronics

33 Springdale Ave. Canton, MA 02021

http://www.hmcelectronics.com

[phone]

4 Copyright 2009 Techspray.

For Commercial Use Only

Compatibility

Metals

Test method: 15 minute immersion at room temperature in sealed jar, remove, wipe dry, and make observations.
Observations made immediately after removal and drying, and 1 hour later.

Material

Compatibility

Brassfoil

Excellent

Copperfoil

Excellent

Nickel200

Excellent

Aluminum6061

Excellent

Aluminum2024

Excellent

Anodizedaluminum

Excellent

StainlessSteel316

Excellent

StainlessSteel304

Excellent

Mildcarbonsteel

Excellent

GalvanizedSteel

Excellent

Note: Eco-Shower™ is a water-based formula, so will encourage oxidation with prolonged exposure to iron, steel,
and other susceptible metals.

Plastics

Test method: Tested as bulk unstressed coupons, and the following immersion times for the base chemistry:
1 minute, 5 minutes, and 15 minutes.

Material Compatibility

Material Compatibility

ABS

Excellent

PMMA

Good (1)

Nylon

Excellent

POM

Excellent

Lexan

Excellent

PP

Excellent

HDPE

Excellent

PS

Good (1)

LDPE

Excellent

PTFE

Excellent

C. E. Phenolic

Excellent

PVC

Excellent

1 = Slight softening after 15 minutes of exposure.

Environmental Policy

Techspray® is committed to developing products to ensure a safer and cleaner environment. We
will continue to meet and sustain the regulations of all federal, state and local government
agencies.

Documentation Provided By HMC Electronics

33 Springdale Ave. Canton, MA 02021

http://www.hmcelectronics.com

[phone]

5 Copyright 2009 Techspray.

For Commercial Use Only

Packaging and Availability

Eco-ShowerTM Cleaner available in the following sizes:

1500-72DSP 72 count pre-saturated wipes, 6" x 10.5" (15cm x 26.7cm)
1500-100PK 100 count individually wrapped pre-saturated wipes, 8” x 12.25” (20.3cm x 31.1cm)
1500-QT 1 quart (0.95L) w/ trigger sprayer
1500-G 1 gallon (3.8L)

Available as special order, call for pricing:
1500-5G 5 gallon (19L)
1500-54G 54 gallon (205L)
1500-275G 275 gallon (1,045L)

Resources

Techspray® products are supported by global sales, technical and customer services resources.
For additional technical information on this product or other Techspray® products in the United

States, call the technical sales department at 800-858-4043, email [e-mail] or visit
our web site at: www.techspray.com.

North America Europe Countries Outside US

Techspray ITW Contamination Control Call to locate a distributor
P.O. Box 949 Skejby Nordlandsvej 307 in your country.
Amarillo, TX 79105 DK-8200 Aarhus N
800-858-4043 [phone]
email: [e-mail] email: [e-mail]

Important Notice to Purchaser/User: The information in this publication is based on tests that we believe are reliable. The
results may vary due to differences in tests type and conditions. We recommend that each user evaluate the product to
determine its suitability for the intended application. Conditions of use are outside our control and vary widely. Techspray’s
only obligation and your only solution is replacement of product that is shown to be defective when you receive it. In no
case will Techspray

®

be liable for any special, incidental, or consequential damages based on breach of warranty,

negligence or any other theory.
Techspray

®

and Blue Shower® are registered trademarks of Techspray. Techspray RenewTM, Eco-ShowerTM, and “High

Performance Eco-Cleaning

TM

” are trademarks of Techspray.
