QUICK START GUIDE
User name:
XXXXX
Password:
XXXXXXXXX
P/N:1234567890AB
Model :ABCDEFGH
Web address:
Check the contents of the packaging
HITRON
CGNV5
Connect to the Internet
Connect phone
0440010341N0
Connect the cable port
Configure wireless network
Read me
First!
STEP
Look into the box and make sure you have the followings:
1
CGNV5
Turn on the power
POWER ADAPTOR
ETHERNET CABLE
QUICK ST AR T GUIDE
STEP
Connect the coaxial cable from the cable outlet to the CABLE port.
2
Connect the phone to the voice port
STEP
Connect the power adapter to the POWER port.
3
Connect your computer to the device
STEP
Use the telephone cable to connect your telephone to the
TELEPHONE port and wait for dial tone before using.
4
User comfigurations (optional)
STEP
Use the Ethernet cable that came with the device to connect your
computer to one of the LAN ports.
5
Connect your computer to wireless network
STEP
6
Your device has a configuration interface that allows you to
completely control the behavior of the device. In a web browser,
enter the IP of the device in the address bar and make sure your PC
is on the same subnet as the device. On the screen that appears,
enter username and password.
Device IP:
Modo Router: 192.168.0.1
Mode Bridge: 192.168.100.1
STEP
7
Connect your wireless devices by WPS. Access the configuration interface (see
step 6), go to the Wireless page to enable WPS and set AES encryption mode,
then press Save changes.
Connect the wireless devices with SSID and correct password. If
you have not changed them, the default values are indicated on
the sticker at the bottom of the device.
2.4G SSID:YZ1234567890
5G SSID:YZ1234567890
PassPhrase: 9876543210YZ
2.4G 5G
Press this button to start the procedure for setting
up WPS (PBC). Press PBC button of your wireless
clients within coverage area in two minutes to
allow joining the wireless network.
Installation complete
STEP
Congratulations!
You have successfully setup your CGNV5. If you have any problem, see the next section for help to identify the cause.
8
IP addresses
If the CGNV5 is correctly connected to the network (see LED Display) but connected computer cannot access to the Internet, the IP address of your
computer may not be configured correctly. In the network configuration of the equipment, make sure it is configured to receive IP address
automatically (recommended) or it has a static IP address in the range 192.168.0.2-192.168.0.253.
For more information, please consult your system operator for help.
LED lights display
Green
Power
Dark
Green-Blinking
The device is power-on.
Power off.
The modem is searching for the downstream
LAN
Green-Blinking
Green-Steady
Dark
There is traffic on LAN interface.
LAN interface is activated.
LAN interface is disabled.
Downsteam
Upsteam
Green-Steady
Blue-Steady
Dark
Green-Blinking
Green-Steady
Blue-Steady
Dark
frequency.
Downstream frequency is locked.
The modem is successfully engaged in Channel
Bonding on the downstream connection.
The modem is not scanning.
The modem is searching for the upstream
frequency.
Upstream frequency is locked.
The modem is successfully engaged in Channel
Bonding on the upstream connection.
The modem is not scanning.
WiFi
(2.4GHz)
WiFi
(5GHz)
Green-Blinking
Green-Steady
Dark
Green-Blinking
Green-Steady
Dark
There is traffic on 2.4 Ghz WiFi interface.
2.4 Ghz WiFi interface is activated.
2.4 Ghz WiFi interface is disabled.
There is traffic on 5 Ghz WiFi interface.
5 Ghz WiFi interface is activated.
5 Ghz WiFi interface is disabled.
Registration in progress (cable interface
acquires IP, time, cable modem configuration)
Registration success.
Not registered.
LINE
Green
Green-Blinking
Dark
Phone is online.
Phone is in use.
Phone is offline.
Status
Green-Blinking
Green-Steady
Dark
Safety Warnings
WARNING
Risk of electrical shock. Do not expose the device to water or moisture.
The device is a high-performance communications device designed for home and office environments. Do not use the device outdoors.
Keep the device in an environment between 0°C ~ 40°C (32°F ~104°F).
To avoid overheating, do NOT place any object on top of the device.
Do not restrict the flow of air around the device.
The manufacturer assumes no liabilities for damage caused by any improper use of the device.
DISCLAIMER
The manufacturer assumes no liabilities with respect to the contents of this document. The manufacturer also reserves the right to revise this document or update the
content thereof without any obligation to notify any person of such re visions or amendments. Specifications subject to change without notice.
CAUTION
The cable distribution system should be grounded (earthed) in a accordance with ANS/NFPA 70, the National Electrical Code (NEC), in particular Section 820.93,
Grounding of Outer Conductive Shield of a Coaxial Cable.
COPYRIGHT © 2019 HITRON TECHNOLOGIES, INC.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
● Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This device is restricted for indoor use.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
