Hit Music PPC-081, PPC-082B OPERATION MANUAL

ENGLISH OPERATION MANUAL

JB SYSTEMS® 1/6 PPC-081 / PPC-082B

OPERATION MANUAL

Thank you for buying this JB Systems® product. To take full advantage of all possibilities, please read these
operating instructions very carefully.

FEATURES

• A compact portable column speaker system with internal media player + Bluetooth™

• The PPC-082B has a battery on board for mobile use. (battery included)

• 8” woofer with a surprisingly deep bass sound and separate bass level control

• 2 Extra microphone inputs with individual level control + build-in sound effect control

• Both microphone inputs can also be used as mono Line inputs

• Stereo mini jack input to connect an external player

• The media player accepts both USB-sticks and SD-HC memory cards up to 32GB

• Plays MP3, WAV, WMA, APE and FLAC files.

• Modulable column speaker for 3 different heights.

• No more speaker stand needed !

• Balanced line output to connect extra speakers

• Bluetooth TWS function for wireless stereo when 2 speakers are used

• Transport bag sets are optionally available

BEFORE USE

• Before you start using this unit, please check if there’s no transportation damage. Should there be any, do
not use the device and consult your dealer first.

• Important: This device left our factory in perfect condition and well packaged. It is absolutely necessary
for the user to strictly follow the safety instructions and warnings in this user manual. Any damage caused
by mishandling is not subject to warranty. The dealer will not accept responsibility for any resulting
defects or problems caused by disregarding this user manual.

• Keep this booklet in a safe place for future consultation. If you sell the fixture, be sure to add this user
manual.

• To protect the environment, please try to recycle the packing material as much as possible.

Check the contents:

Check that the carton contains the following items:

• User manual

• 1 Bass speaker

• 1 Column speaker

• 2 Column extension modules

• Power cable

• The PPC-082B has a Battery already installed in the unit

VERY IMPORTANT: RECHARGING THE BATTERY -

To extend the lifetime of the battery it is very important to NEVER store the unit with an empty
battery! So keep in mind to ALWAYS store the unit with a fully charged battery. If the unit is stored
for a long time, recharge it every 3 months! NO guarantee is offered on the rechargeable battery!

ENGLISH OPERATION MANUAL

JB SYSTEMS® 2/6 PPC-081 / PPC-082B

SAFETY INSTRUCTIONS:

• Even if the speaker cabinet is made of water resistant material, the woofer and tweeter are not protected
against humid and rain. Therefore this speaker is intended for indoor use only, use of this product
outdoors, in humid conditions, voids all warranties.

• Always mount this speaker in safe and stable matter.

• Take special care when the cabinets are suspended. This is potentially dangerous and should only be

carried out by technicians who have knowledge of the techniques and regulations of rigging speakers!

• To prevent fire or shock hazard, do not expose this appliance to rain or moisture.

• To avoid condensation to be formed inside, allow the unit to adapt to the surrounding temperatures when

bringing it into a warm room after transport. Condense sometimes prevents the unit from working at full
performance or may even cause damages.

• Don’t place metal objects or spill liquid inside the unit. No objects filled with liquids, such as vases, shall
be placed on this appliance. Electric shock or malfunction may result. If a foreign object enters the unit,
immediately disconnect the mains power.

• No naked flame sources, such as lighted candles, should be placed on the appliance.

• Don’t cover any ventilation openings as this may result in overheating.

• Prevent use in dusty environments and clean the unit regularly.

• Keep the unit away from children.

• Inexperienced persons should not operate this device.

• Maximum save ambient temperature is 40°C. Don’t use this unit at higher ambient temperatures.

• Always unplug the unit when it is not used for a longer time or before you start servicing.

• The electrical installation should be carried out by qualified personal only, according to the regulations for

electrical and mechanical safety in your country.

• Check that the available voltage is not higher than the one stated on the rear panel of the unit.

• The socket inlet shall remain operable for disconnection from the mains.

• The power cord should always be in perfect condition. Switch the unit immediately off when the power

cord is squashed or damaged. It must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.

• Never let the power-cord come into contact with other cables!

• When the power switch is in OFF position, this unit is not completely disconnected from the mains!

• This appliance must be earthed to in order comply with safety regulations.

• In order to prevent electric shock, do not open. There are no user serviceable parts inside.

• Never repair a fuse or bypass the fuse holder. Always replace a damaged fuse with a fuse of the same

type and electrical specifications!

• In the event of serious operating problems, stop using the appliance and contact your dealer immediately.

• Please use the original packing when the device is to be transported.

• Due to safety reasons it is prohibited to make unauthorized modifications to the unit.

CAUTION: To reduce the risk of electric shock, do not open. No
user-serviceable parts inside. Refer servicing to qualified service
personnel only.

The lightning flash with arrowhead symbol within the equilateral triangle is intended to alert the
use or the presence of un-insulated “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock.

The exclamation point within the equilateral triangle is intended to alert the user to the presence
of important operation and maintenance (servicing) instructions in the literature accompanying
this appliance.

This symbol means: indoor use only

This symbol means: Read instructions

This speaker can easily reproduce sound pressure levels (SPL) sufficient enough to
cause severe and permanent hearing damage. Always protect your ears when you are
exposed for a longer period to SPL in excess of 85dB!
