USER GUIDE
H10512 / H11070 / H11071 - Version 2 / 02-2020
English AMP480/4120MKII/4240MKII - 1x480/4x120/4x240W PA amplifiers with 1 or 4 x 100V outputs
1 - Safety information
Important safety information
This unit is intended for indoor use only. Do not use it in a wet,
or extremely cold/hot locations. Failure to follow these safety instructions could result in fire, electric shock, injury, or damage to
this product or other property.
Any maintenance procedure must be performed by a CONTEST
authorised technical service. Basic cleaning operations must thoroughly follow our safety instructions.
WARNING :
housing or attempt any maintenance by yourself. In the unlikely even your unit
may require service, please contact your nearest dealer.
In order to avoid any electrical malfunction, please do not use any multi-socket,
power cord extension or connecting system without making sure they are
perfectly isolated and present no defect.
Risk of electrocution
To prevent the hazard of electric shocks, do not use
extension cords, multi-socket or any other connection
system without making sure metal parts completely are
out of reach.
This product contains non-isolated electrical components. Do not
undertake any maintenance operation when it is switched on as
it may result in electric shock.
This unit contains no user-serviceable parts. Do not open the
Sound levels
Our audio solutions deliver important sound
pressure levels (SPL) that can be harmful
to human health when exposed during long
periods. Please do not stay in close proximity
of operating speakers.
Recycling your device
• As HITMUSIC is really involved in the environmental cause, we only commercialise clean, ROHS compliant products.
• When this product reaches its end of life, take it to a collection point designated by local authorities. The separate collection and recycling of your
product at the time of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects human health and the
environment.
Symbols used
This symbol signals an important safety
precaution.
The CAUTION symbol signals a risk of product deterioration.
The WARNING symbol signals a risk to the user’s physical integrity.
The product may also be damaged.
Page 12
Instructions and recommendations
EnglishAMP480/4120MKII/4240MKII - 1x480/4x120/4x240W PA amplifiers with 1 or 4 x 100V outputs
1 - Please read carefully :
We strongly recommend to read carefully and understand
the safety instructions before attempting to operate this unit.
2 - Please keep this manual :
We strongly recommend to keep this manual with the unit for
future reference.
3 - Operate carefully this product :
We strongly recommend to take into consideration every
safety instruction.
4 - Follow the instructions:
Please carefully follow each safety instruction to avoid any
physical harm or property damage.
5 - Avoid water and wet locations :
Do not use this product in rain, or near washbasins or other
wet locations.
6 - Installation :
We strongly encourage you to only use a
fixation system or support recommended by
the manufacturer or supplied with this product.
Carefully follow the installation instructions and
use the adequate tools.
Always ensure this unit is firmly fixed to avoid
vibration and slipping while operating as it may result in
physical injury.
7 - Ceiling or wall installation :
Please contact your local dealer before attempting any ceiling
or wall installation.
8 - Ventilation :
The cooling vents ensure a safe use of this product,
and avoid any overheating risk.
Do not obstruct or cover these vents as it may
result in overheating and potential physical injury or
product damage. This product should never been
operated in a closed non-ventilated area such as a flight case
or a rack, unless cooling vents are provided for the purpose .
12 - Cleaning precautions :
Unplug the product before attempting any cleaning
operation. This product should be cleaned only with
accessories recommended by the manufacturer.
Use a damp cloth to clean the surface. Do not
wash this product.
13 - Long periods of non use :
Disconnect the unit’s main power during long periods of
non use.
14 - Liquids or objects penetration :
Do not let any object penetrate this product as it may result
in electric shock or fire.
Never spill any liquid on this product as it may infiltrate the
electronic components and result in electric shock or fire.
15 - This product should be serviced when :
Please contact the qualified service personnel if :
- The power cord or the plug has been damaged.
- Objects have fallen or liquid has been spilled into
the appliance.
- The appliance has been exposed to rain or water.
- The product does not appear to operate normally.
- The product has been damaged.
16 - Inspection/maintenance :
Please do not attempt any inspection or
maintenance by yourself. Refer all servicing to
qualified personnel.
17 - Operating environment :
Ambient temperature and humidity: +5 - +35°C,
relative humidity must be less than 85% (when
cooling vents are not obstructed).
Do not operate this product in a non-ventilated,
very humid or warm place.
9 - Heat exposure :
Sustained contact or proximity with warm surfaces may cause
overheating and product damages. Please keep this product
away from any heat source such as a heaters, amplifiers, hot
plates, etc...
10 - Electric power supply :
This product can only be operated according to a very specific
voltage. These information are specified on the label located
at the rear of the product.
11 - Power cords protection:
Power-supply cords should be routed so that they are not
likely to be walked on or pinched by items placed
upon or against them, paying particular attention
to cords at lugs, convenience receptacles and the
point where they exit from the fixture.
Page 13
English AMP480/4120MKII/4240MKII - 1x480/4x120/4x240W PA amplifiers with 1 or 4 x 100V outputs
2 - Introduction
Our new AMP amplifiers series dedicated to installations combine sound quality, easy installation and
handiness.
The AMP480, AMP4120 MKII and AMP4240 MKII operate at 100V, and have been designed to fit any
installation.
Their high-pass filter allow them to limit basses, allowing more subtle ambient music without compromising
on power.
3 - Presentation
1
3 4
2
65
7
Page 14
EnglishAMP480/4120MKII/4240MKII - 1x480/4x120/4x240W PA amplifiers with 1 or 4 x 100V outputs
1
LED indicators
These LEDs indicate the current status of your device:
- SIGNAL: Indicates that an incoming signal has been
detected.
- -10 dB: Indicates that the incoming signal is within the
best range possible to get a perfect audio output.
- CLIP: Indicates that signal levels are too high.
- PROTECT: Indicates that the protection has been
activated because your device of short-circuits or
overheating.
Notes :
-The PROTECT LED usually lights up when turning on
your device.
-If the PROTECT LED remains lit, please turn off your
amplifier, wait for it to cool down, and check the
cables.
-If this LED remains lit upon activation of your device,
and the aforementioned steps have already been
tried, please ask for a qualified technician.
2
Power button
Allows you to turn you device ON/OFF.
The POWER LED is lit when your device is activated.
4
Output terminals
Connect here your speakers or ceiling speakers.
The terminals might be used differently depending on
the installation.
Please refer to next chapter for more details about each
type of installation.
5
HPF Switch
Allows you to activate or deactivate the high-pass filter.
This filter can be activated of loud noises or interferences
can be heard.
6
INPUT and LINK sockets
INPUT : Connect here a line-level source.
LINK : Allows you to send the signal to another device.
7
INPUT ADJUST control knob
Allows you to adjust the incoming signal level from
-12dB to 0dB.
3
Power input with fuse
Connect here the supplied IEC cord then connect it to
the mains after making sure the voltages are compatible.
Fuse values
AMP480 T4 AL / 250V
AMP4120 MKII T4 AL / 250V
AMP4240 MKII T6.3AL / 250V
Page 15
English AMP480/4120MKII/4240MKII - 1x480/4x120/4x240W PA amplifiers with 1 or 4 x 100V outputs
4 - Using your amplifier
CAUTION: Please make sure your amplifier is not plugged in and is OFF when checking cables.
Input connectors
The line-level plug (INPUT) and LINK output are balanced.
However, they can still receive unbalanced signals.
You can also send the incoming signal from one way to another one as described below:
Output terminals
Please use high-quality cables to connect your speakers.
In order to prevent short-circuits, please tin the cables before connecting them to the output terminal.
You will find below a table of correspondence between the amplifier/speakers distance and cable sections in
order to prevent signal quality losses.
Distance Section
Up to 8 m 1,5 mm²
Between 8 and 12 m 2 mm²
Between 12 and 18 m 3,5 mm²
Between 18 and 30 m 5 mm²
Between 30 and 45 m 8,5 mm²
Between 45 and 60 m 13 mm²
Note: Never use screened cable to carry amplified signal.
Page 16
Wiring
Please make sure to respect the polarities when connecting your speakers to your amplifier.
Connect the speakers equipped with transformers to COM and 100V terminals.
EnglishAMP480/4120MKII/4240MKII - 1x480/4x120/4x240W PA amplifiers with 1 or 4 x 100V outputs
Transformer
Transformer
100V speaker or ceiling speakers
Dangerous voltage
Speakers must be connected last to
the amplifier.
Turn the amplifier on when the
installation is over and has been
checked thoroughly.
Caution: The sum of all
connected speakers must not
exceed the maximum power of
your amplifier
Page 17
English AMP480/4120MKII/4240MKII - 1x480/4x120/4x240W PA amplifiers with 1 or 4 x 100V outputs
5 - Synoptic
Note AMP480 is a mono-channel amplifier yet the synoptic is identical.
Page 18
7 - Technical specifications
ELECTRICAL SPECIFICATIONS
EnglishAMP480/4120MKII/4240MKII - 1x480/4x120/4x240W PA amplifiers with 1 or 4 x 100V outputs
AMP480 AMP4120 AMP4240
Power
(T.H.D 1,0%, 1KHz)
Input sensitivity (INPUT andf LINK)
(Balanced input)
Cross-over distortion higher than 70 dB
Frequency response 50 Hz - 15 KHz
Signal to noise ratio higher than 90dB
T.H.D at 1 KHz (nominal power) less than 0,1%
Output voltages and impedances
Power supply 230V AC, 50Hz
PHYSICAL CHARACTERISTICS
Cooling system Fans
Operating temperature and humidity 0°~40° with 95% humidity max.
Dimensions (W x D x H) 483 x 380 x 88 mm
Net weight 6,6 Kg 7,2 Kg 7,5 Kg
1 x 480 Watts 4 x 120 Watts 4 x 240 Watts
0 dB
42Ω / 100V 83Ω / 100V 42Ω / 100V
Page 19
Because AUDIOPHONY® takes the utmost care in its products to make sure you only get the best possible quality, our products are
subjects to modifications without prior notice. That is why technical specifications and the products physical configuration might differ
from the illustrations.
