Hitachi L26D205 User Manual
Model Number L26D205
26” Class (26.01” Diagonal)
P E LI H
Thank you for purchasing this Hitachi product.
Please read these instructions carefully.
For additional assistance please Call Toll Free
1-800-289-0981 (USA), 01-800-703-0885 (MEXICO)
or visit our website at www.hitachi.us/tv.
Keep this owner’s guide for future reference.
Record the model name and serial number of your LCD
Television for future reference.This information is located
on the back of the television.
MODEL NAME. ________________________ SERIAL NO. ___________________________
L26D205
TABLE OF CONTENTS
2-6 IMPORTANT SAFETY INSTRUCTIONS
7 HOW TO ATTACH/REMOVE THE STAND
9-14 FIRST TIME USE
16-23 TV OPERATION
24-32 DVD OPERATION
33-35 CONNECTIONS TO OTHER EQUIPMENT
36-38 TROUBLE SHOOTING
39 SPECIFICATIONS
40 LIMITED WARRANTY
2
CAUTION:
THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ
THIS OWNER'S MANUAL CAREFULLY AND RETAIN FOR FUTURE
REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE, CONTACT
AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO THE LASER BEAM, DO NOT TRY
TO OPEN THE ENCLOSURE. RADIATION MAY BE PRESENT WHEN THE
ENCLOSURE IS OPENED. DO NOT STARE INTO THE BEAM.
Location of the required Marking
The rating sheet and the safety caution are on the rear of
the unit.
CERTIFICATION: COMPLIES WITH FDA RADIATION
PERFORMANCE STANDARDS, 21 CFR SUBCHAPTER J.
Complies with FDA performance standards for laser
products except for deviations pursuant to Laser Notice
No. 50, dated June 24, 2007.
The lightning flash with arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY FROM THIS PRODUCT AT
ALL TIMES.
CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED PLUG WITH AN EXTENSION CORD,
RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE
EXPOSURE.
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance with the FCC Rules could void the user’s
authority to operate this equipment.
ENGLISH
Lead/Mercury Notice
This product contains lead and one or more non-replaceable mercury backlights. Do not put in trash. Recycle or dispose
of according to applicable laws. For product recycling and disposal information, contact your local government agency or
visit www.eiae.org (in USA) or www.epsc.ca (in Canada). FOR MORE INFORMATION, CALL 1-800-289-0981 (USA),
01-800-703-0885 (MEXICO).
CLASS 1
LASER PRODUCT
Hg
56P5021A_eng.indd 256P5021A_eng.indd 2 5/21/11 3:20:24 PM5/21/11 3:20:24 PM
3
ENGLISH
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such as vases, should not
be placed on the apparatus.
16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power
circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits, as contact with them might be fatal.
17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts
that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.
19) If an outside antenna or cable system is connected to the unit, be sure
the antenna or cable system is grounded to provide some protection
against voltage surges and built-up static charges, Section 810 of the
National Electrical Code, ANSI/NFPA 70, provides information with
respect to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna discharge unit, connection
to grounding electrodes, and requirements for the grounding
electrode.
20) When replacement parts are required, be sure the service technician
uses replacement parts specified by the manufacturer or those that
have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
22) Keep your fingers clear of the disc slot as it is closing. It may cause injury.
23) When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall
outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of the other
equipment carefully and follow the instructions when making any connections.
24) Reduce the volume to the minimum level before you turn off the product. Otherwise, sudden high volume sound may
cause hearing or speaker damage.
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA
LEAD IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL
ELECTRICAL CODE
S2898A
EXAMPLE OF ANTENNA GROUNDING AS PER THE
NATIONAL ELECTRICAL CODE
IMPORTANT SAFETY INSTRUCTIONS
56P5021A_eng.indd 356P5021A_eng.indd 3 5/21/11 3:20:29 PM5/21/11 3:20:29 PM
4
25) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker overheating.
26) When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously with
high volume sound, it may cause hearing damage.
27) Do not look into the opening of the disc slot or ventilation opening of the product to see the source of the laser beam.
It may cause eye damage.
28) Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal
injury and product malfunction.
29) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
30) The socket-outlet must be installed near the unit and easily accessible.
31) The mains plug is used as the disconnect device and shall remain readily operable.
CONDENSATION
Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm room or if the temperature
of the room rises suddenly. When this happens, player's performance will be impaired.
To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or make sure that the room
temperature rises gradually.
Condensation may also form during the summer if the player is exposed to the breeze from an air conditioner. In such cases, change the
location of the player.
HOW TO HANDLE THE LCD PANEL
Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.
If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause skin inflammation.
If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your eyes or touches your
skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.
•
•
Power source
This LCD television is designed to operate on 120 volts 60 Hz, AC current. Insert the power cord into a 120 volt 60 Hz outlet.
To prevent electric shock, do not use the LCD television’s (polarized) plug with an extension cord, receptacle, or other outlet unless
the blades and ground terminal can be fully inserted to prevent blade exposure.
Never connect the LCD television to 50 Hz, direct current, or anything other than the specified voltage.
Warning
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
Caution
Never remove the back cover of the LCD television as this can expose you to very high voltages and other hazards. If the television
does not operate properly, unplug the LCD television and call your authorized dealer or service center.
Adjust only those controls that are covered in the instructions, as improper changes or modifications not expressly approved by
Hitachi could void the user’s warranty.
Declaration of Conformity
This device compiles with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and (2)This device must accept any interference received, including interference that
may cause undesired operation.
For questions regarding this declaration, contact:
Hitachi America, Ltd.
900 Hitachi Way
Chula Vista, CA 91914-3556
ATTN: Customer Relations
IMPORTANT SAFETY INSTRUCTIONS (continued)
56P5021A_eng.indd 456P5021A_eng.indd 4 5/21/11 3:20:30 PM5/21/11 3:20:30 PM
5
ENGLISH
CHILD SAFETY NOTICE
56P5021A_eng.indd 556P5021A_eng.indd 5 5/21/11 3:20:30 PM5/21/11 3:20:30 PM
6
The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block
ventilation holes, or set up near radiators. Do not place in direct sunlight. When placing on a shelf leave 4 inches (10 cm) free space
around the entire unit.
4 inches
4 inches
Notes when mounting the LCD TV/DVD on a wall
If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV/DVD for advice, and have the equipment
professionally installed. Incomplete or improper installation may cause injury to you, and/or damage to the LCD TV/DVD.
The screws ISO M4 thread type should be used. The insertion length must be within 12 - 16mm.
If the insertion length is less than 12mm, the weight can not be maintained.
If the insertion length is more than 16mm, a space is created between the Wall Mount Bracket and the Television.
(Insertion Length) = (Screw Length) - (Washers Thickness) - (Mounting Bracket Thickness)
Securing to a Wall
1. Using metallic wire fasten the set to the clamping screw on the rear of the LCD TV/DVD as shown below.
2. Keep the LCD TV/DVD 4 inches away from the wall except when mounted using the wall mount bracket and secure to the wall as
shown below:
Wire
Clamp
Screw
Wire
4 inches
Wire
NOTICE FOR TV CABINET
If the unit is to be mounted on a cabinet smaller than length of the unit, it could result in an unstable location and the unit may tumble
over, making a risk of personal, possibly fatal injury. Also, this would damage the product seriously. Accordingly, Hitachi accepts no
responsibility or liability for any injuries or property damage resulting from the improper installation.
IMPORTANT NOTICE
The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim any responsibility for
these symptoms.
LCD Panels are manufactured using an extremely high level of precision technology, however sometimes parts of the screen may be
missing picture elements or have luminous spots.
This is not a sign of a malfunction.
Do not install the LCD Panel near electronic equipment that is susceptible to electromagnetic waves. Some equipment placed too
near this unit may cause interference.
Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless headphones.
•
•
•
SAFETY PRECAUTIONS
YES !!
NO !!
56P5021A_eng.indd 656P5021A_eng.indd 6 5/21/11 3:20:34 PM5/21/11 3:20:34 PM
7
ENGLISH
How to attach the stand
NOTE:
• Unplug the AC cord from the AC INPUT terminal.
• Before beginning this process, assure that the TV is laid on a clean, safe, and cushioned surface to avoid any damage to the unit.
• Do not touch or press the TV-screen, glass might break under pressure.
Place the TV on its front onto a table.
Align the stand’s bottom-plate (supplied) as seen here.
It will fit in only one direction.
Hold the unit and attach the stand frame (a) slowly and secure the stand frame (a) with the 2 screws (supplied). (M4x35mm), as shown
in Figure 1.
Finally secure the bottom-plate (b) with 3 screws (supplied) (M4x16mm) as indicated by the arrows in Figure 2.
Be sure to follow the instructions. Insufficient tightening or incorrect installation of the stand will not support your unit correctly, and
could result in damage or injury from tip-over.
•
How to remove the stand
When you transport this product, remove the stand and pack fl at against the back of the unit in the carton. To remove the stand,
perform these steps in reverse order.
For wall mounting, the base must be removed. To disconnect the base/stand remove the 2 screws from the back.
LCD PANEL SIDE
Figure 1
Figure 2
(a)
(b)
(b)
56P5021A_eng.indd 756P5021A_eng.indd 7 5/21/11 3:20:46 PM5/21/11 3:20:46 PM
8
Features
LCD color TV With DVD/CD player
Unique space saving design combines a 26” class LCD color TV and a DVD/CD player.
A DVD disc has much more capacity, but is the same size as an audio CD disc. The Picture/Audio quality of a DVD is very good.
The audio quality is higher than an audio CD. The DVD also has special options; audio language selection, subtitle language selection,
or multi-angle, etc.
The DVD PLAYER can play back both audio CDs and MP3/WMA/JPEG CDs.
Compatible with a wide range of DVD audio outputs
Digital Audio Jack (Coaxial)
When a component with a built-in Dolby Digital decoder is connected, Dolby Digital sound can produce the effect of being in a movie
theater or a concert hall.
Surround standard is different from Dolby Digital. This format is already in use in many theaters. By connecting this unit to a DTS
decoder or an AV amplifier with a built-in DTS decoder, the DTS audio of DVD discs recorded in this format can be enjoyed. However,
audio will not be output from the TV speakers and the analog audio output jacks.
By connecting this unit to an AV amplifier with a built-in MPEG decoder, the MPEG audio of DVD discs recorded in this format can be
enjoyed.
The Linear PCM sound of a 48 kHz/24 bit through 96 kHz/24 bit exceeds audio CD sound.
Convenience Features
Direct selection of your desired scenes using Title/Chapter/Time/Track - You can play back from the desired scene.
Recalling Up to 12 Scenes -
You can program up to 12 scenes in memory and recall the marked scenes.
Frame Advance - The PAUSE moves one frame at a time.
Slow Motion - The SLOW moves you back and forth through the program by 4 steps of 1/16-1/2 times.
Repeat Playback - You can repeat chapter, track, title, sides or material between two selected points.
Program Playback (Audio CD/MP3/WMA CD) - You can play back tracks in programmed sequences.
Zoom - You can zoom in the selected subject on the screen during playback.
Note: Make sure that discs are suitable for the following functions.
Multi-Language - Maximum 32 language subtitles and maximum 8 language soundtracks can be played back for movies or programs.
Multi-Angle - Pictures of Sports or a Live Concert are recorded with many cameras. When you play such a disc, you can change the
angles during playback.
Parental Control - You can limit the play back of scenes or sounds of DVD discs that have a rating level encoded on the disc.
Video Aspect Ratio - You can change the aspect ratio of the screen.
TV Features
Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box.
Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for hearing impaired viewers.
Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control adjustment of
BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.
Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed for up to 120 minutes to turn off
automatically.
On-Screen 3 Languages Display - You can select one of 3 languages, English, Spanish or French for on-screen programming.
V-Chip - The V-Chip function can read the rating of a TV program or movie content if the program is encoded
with this information. V-chip will allow you to set a restriction level.
This LCD Television receiver will display television closed captioning, (
or ), in accordance with paragraph 15.119 and 15.122 of
the FCC rules.
•
•
•
•
* HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.
* This product incorporates copy protection technology that is protected by U.S. and other intellectual property rights. The use of
Rovi Corporation’s copy protection technology in the product must be authorized by Rovi Corporation. Reverse engineering or
disassembly are prohibited.
*
is a trademark of DVD Format/Logo Licensing Corporation.
* Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
* This product is protected by certain intellectual property rights of Microsoft. Use or distribution of such technology outside of this
product is prohibited without a license from Microsoft.
* VGA and XGA are trademarks of International Business Machines Corporation.
* VESA is a registered trademark of the Video Electronics Standard Association.
56P5021A_eng.indd 856P5021A_eng.indd 8 5/21/11 3:20:55 PM5/21/11 3:20:55 PM
9
ENGLISH
Contents
Before using your unit
IMPORTANT SAFETY INSTRUCTIONS ............................3
CHILD SAFETY NOTICE ...................................................5
SAFETY PRECAUTIONS ..................................................6
IMPORTANT NOTICE ........................................................6
How to attach the stand .....................................................7
How to remove the stand ...................................................7
Features .............................................................................8
Contents ............................................................................9
Disc..................................................................................10
Parts and functions .......................................................... 12
Remote control ................................................................13
Power source ...................................................................14
Antenna connections .......................................................15
Cable TV connections ...................................................... 15
TV operation
Starting setup ..................................................................16
TV operation ....................................................................16
Quick guide for menu operation .......................................17
Convenience functions ....................................................18
Memorizing channels .......................................................19
Checking the digital signal strength .................................20
Labeling channels ............................................................20
Labeling video inputs .......................................................20
Setting the Parental Control .............................................20
Closed Captions ..............................................................22
CC advanced ...................................................................23
Aspect Switching .............................................................23
DVD operation
Preparation ......................................................................24
Status display of disc .......................................................24
Playback procedure .........................................................24
Special playback ..............................................................25
Zooming ...........................................................................25
Locating desired scene ....................................................25
A-B Repeat playback .......................................................25
Marking desired scenes ...................................................26
Changing angles ..............................................................26
Changing soundtrack language .......................................26
Subtitles ...........................................................................26
Using HOME MENU ........................................................27
Play mode ........................................................................27
Audio Settings menu ........................................................28
Video Adjust menu ...........................................................29
Quick guide for DVD menu operation ...............................29
Function Setup .................................................................30
Parental Control ...............................................................31
Additional information
Language Code List .........................................................32
Country/Area Code List ...................................................32
Connections to other equipment ......................................33
Reception disturbances ...................................................36
Problems and troubleshooting .........................................37
Specifications ..................................................................39
LIMITED WARRANTY .....................................................40
56P5021A_eng.indd 956P5021A_eng.indd 9 5/21/11 3:20:57 PM5/21/11 3:20:57 PM
10
Disc
Playable discs
Disc type and logo mark content
DVD Video
Audio
+
Video
CD-DA
Audio
The following discs are also available.
DVD-R/RW discs of DVD video format and MP3/WMA/JPEG.
CD-R/RW discs of MP3/WMA/JPEG.
•
•
CAUTION:
Only the discs types, on the table to the left, can be played on
this unit. DVD-ROM (for PC), CD-ROM (for PC), SVCD, CVD,
VCD, etc. cannot be played.
This unit cannot play an 8 cm disc. It cannot also be played even
using a disc adapter.
If you insert an irregular shaped disc, it may get stuck and cause
a malfunction.
The use of a ring protector or other disc accessories will cause
errors.
This unit is to be used exclusively with the NTSC color system.
PAL and SECAM system discs cannot be used with this unit.
Some discs cannot be played back depending on the recording
conditions.
•
•
•
•
•
•
Region Number
Region number (Regional restriction code) is built-in to the unit and DVD video discs.
Region number “1” or “ALL” of DVD video discs can be used on this unit.
Title
When two or more movies are recorded on a disc, the disc is divided into two
or more sections. Each section is called a “TITLE”.
Chapter
The titles can be subdivided into many sections.
Each section is called a “CHAPTER”.
Track
An Audio CD can contain several items.
These are assigned to the tracks.
Removing Disc from Case
Be sure to hold the edge of disc. Do not touch the surface of the disc.
Pick up the disc gently from the case.
Do not scratch the disc.
Do not get dirt on the surface of the disc.
Do not stick a label or adhesive tape on the disc.
Do not drop or bend the disc.
Storing Disc
Store the disc in the case to avoid risk of scratches, dirt or damage.
Do not leave disc exposed to direct sunlight or in hot or humid places.
Cleaning Disc
Wipe the disc with a clean, dry cloth from center to edge.
Do not wipe the disc in a circular motion.
Do not use liquid or aerosol cleaners.
•
•
•
•
•
•
•
•
TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5
Audio CD
ALL
1
DVD DISC
TITLE 1 TITLE 2
CHAPTER 1
CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1
56P5021A_eng.indd 1056P5021A_eng.indd 10 5/21/11 3:20:57 PM5/21/11 3:20:57 PM
11
ENGLISH
■ Title/Chapter/Track PC-created disc
• You may not be able to play discs recorded using a personal
computer or recorder for disc compatibilities, scratches or
marks on the disc, dirty lenses of the unit or condensation and
so on.
• Discs recorded using a personal computer may not be playable
in this unit due to the setting of the application software used
to create the disc. In these particular instances, check with the
software publisher for more detailed information.
■ Playable files
• ISO 9660 Level 1 or 2 compliant.
Romeo and Joliet file systems are both compatible with this
player.
• DRM (Digital Rights Management) protected files will not play in
this player.
For detailed information, please see the instruction manuals or
help files that came with your PC and/or software.
• File structure (may differ): Up to 299 folders on a disc; up to 648
files within each folder
• Folder and file names can be displayed as long as they are
typed in alphabets and numbers. If folder and file names are
other than alphabets and numbers, they may be replaced and
displayed like as “_”. Garbled characters may also be displayed
in this case.
■ Playing image files
JPEG files recorded in DVD-R/-RW/-R DL and CD-R/-RW can be
played.
■ JPEG file compatibility
• Image files should be saved in JPEG format.
• Files recorded in Fuji Color CD, Kodak Picture CD or CD-R/RW can be played.
• Compatible formats: Baseline JPEG and EXIF 2.2* still image
files up to a resolution of 3072 x 2048.
*File format used by digital still cameras.
• Files with extensions .jpg or .JPG can be played.
• Progressive JPEG formatted files do not work.
• It may take some more time to start to play larger files than
usual.
• JPEG files with different aspect ratio may be displayed with
black bands (either vertical or horizontal).
■ Playing Audio files
WMA and MP3 files recoded in DVD-R/-RW/-R DL, CD-R/-RW
can be played.
■ Windows Media Audio (WMA) compatibility
• WMA is an acronym for Windows Media Audio and refers to
an audio compression technology developed by Microsoft
Corporation.
• You can encode your files by using Windows Media Player
Ver.7, 7.1, Windows Media Player for Windows XP or Windows
Media Player 9 Series.
• When encoding your files, use only applications approved by
Microsoft Corporation. If you use a non-approved application, it
may not work properly.
• This unit is compatible with audio files recorded with the
following sampling frequency: 32 kHz, 44.1 kHz and 48 kHz.
• It is not compatible with loss-less encoding.
• Files with extensions .wma or .WMA can be played.
■ Playing MP3 (MPEG-1 Audio Layer-3) files
• This unit is compatible with audio files recorded with the
following sampling frequency: 32 kHz, 44.1 kHz and 48 kHz.
• Files with extensions .mp3 or .MP3 can be played.
• For the best quality of sound, 128 kbps or higher bit rate is
recommended.
■ Copy Control CD (CCCD)
This product is designed to conform to CD-DA (Compact Disc
Digital Audio). Any other discs than CD-DA are not guaranteed
with their operation and performance in this product.
Note on copyright
• Unauthorized recording of copyrighted television programs,
films, video cassettes and other materials may infringe the rights
of copyright owners and be contrary to copyright laws.
Disc (continued)
56P5021A_eng.indd 1156P5021A_eng.indd 11 5/21/11 3:20:59 PM5/21/11 3:20:59 PM
12
Parts and functions
Front
Press and hold both VOL (VOLUME) +/– at the
same time for 1 second to display the menu screen.
CH (CHANNEL) / buttons, VOL (VOLUME)
+/– buttons and INPUT/ENTER button can be
used to select the desired setting during the
menu screen operations.
INPUT/ENTER button
VOL (VOLUME)
+/– buttons
CH (CHANNEL)
/1 (PLAY) button
MENU button
Power Indicator
Red : Standby
Green : On
EJECT button
Left side
CH (CHANNEL)
/3 (STOP) button
DISC slot
Remote sensor
POWER button
FOR SERVICE PERSONNEL USE ONLY
Do NOT insert ANY USB device into
this port. Use of this port by other than
Service Personnel may void this products
warranty.
HDMI 2 IN jack
HDMI 1/DVI IN jack
PC/DVI AUDIO IN jack
AUDIO (L (MONO)/R) jacks
(for COMPONENT IN and VIDEO2 IN)
COMPONENT IN jacks
ANT. (RF) IN jack
DIGITAL AUDIO
COAXIAL OUT jack
VAR. (VARIABLE)
AUDIO (L/R) OUT jacks
PC MONITOR IN jack
Rear side
VIDEO1 IN jacks
(VIDEO/AUDIO (L (MONO)/R))
VIDEO2 IN jack
AC INPUT jack
56P5021A_eng.indd 1256P5021A_eng.indd 12 5/21/11 3:21:00 PM5/21/11 3:21:00 PM
13
ENGLISH
Remote control
POWER Power On/Off
INPUT Display source selection menu
TV/DVD Switch between TV and DVD
(EJECT) Eject a disc
0-9 Direct channel selection of TV
Input setting
Enter a password
– Input “–” for digital channels
SLEEP Sleep timer
SETUP/
TV MENU
DVD mode - Call up initial setup mode
TV mode - Display menu of TV
ASPECT Display ASPECT menu
▲▼◀▶ Cursor buttons
ENTER Enter information in the menu
EXIT/
CANCEL
Exit from On-Screen menu
Reset information in the menu
DISPLAY Call TV information
Call DVD information
VOL +/– Adjust volume of TV/DVD
LAST CH/
ZOOM
Switch between present/last channel
Zoom
MUTE Switch off the sound
CH
/
Select channel of TV
DVD MENU Display DVD menu
TOP MENU Select title
C.C./
SUBTITLE
Closed Caption
Set subtitle
RETURN Remove DVD setup menu
AUDIO Change sound track language
JUMP Locating desired scene
ANGLE Change playback angle
PLAY MODE Select playback mode
SLOW Forward/Reverse- slow motion
MARKER Index
REPEAT A-B Repeat playback between A and B
SEARCH Fast Forward/Review playback
PLAY Playback
SKIP Skip chapter to forward or reverse direction
PAUSE Pause CD sound
Still picture of DVD
STOP Stop
ATTENTION
If you purchase a universal remote from a local retailer, please contact the remote manufacturer for the correct programming code.
56P5021A_eng.indd 1356P5021A_eng.indd 13 5/21/11 3:21:12 PM5/21/11 3:21:12 PM
Loading...
