Hitachi CP-DX351 User Manual

Projector CP-DX351 User Manual

Thank you for purchasing this product. Please read this manual before you operate your projector. Save it for future reference.

Important safety

instructions .......................2

Introduction......................4

Projector features .................................4

Shipping contents................................. 5

Projector exterior view......................... 6

Controls and functions ......................... 7

Positioning your

projector..........................10

Choosing a location............................10

Projection dimensions........................11

Connection ......................12

Connecting a computer or monitor ....13

Connecting Video source devices ...... 14

Operation ........................17

Starting up the projector..................... 17

Using the menus................................. 18

Utilizing the password function ......... 19

Switching input signal........................ 21

Adjusting the projected image ........... 22

Magnifying and searching for details. 23

Selecting the aspect ratio ...................24

Optimizing the image......................... 26

Setting the presentation timer ............29

Hiding the image................................ 30

Locking control keys.......................... 30

Freezing the image............................. 30

Operating in a high altitude

environment ....................................... 31

Shutting down the projector...............31

Menu operation .................................. 32

Maintenance ...................41

Care of the projector .......................... 41

Lamp information.............................. 42

Troubleshooting .............47

Specifications ..................48

Projector specifications...................... 48

Dimensions ........................................ 49

........................................................... 49

Timing chart ...................................... 50

Regulation Statements ...54

FCC statement ................................... 54

ICES-003 ........................................... 54

WEEE ................................................ 54

Warranty and after-

service..............................57

Entries and graphical symbols explanation

The following entries and graphical symbols are used for the manuals and the product as follows, for safety purpose. Please know their meanings beforehand, and heed them.

WARNING: This entry warns of a risk of

serious personal injury or even death.

CAUTION: This entry warns of a risk of

personal injury or physical damage.

Important safety instructions

Do not look straight at the projector lens during operation. The intense light beam may damage your eyes.

Do not block the projection lens with any objects when the projector is under operation as this could cause the objects to become heated and deformed or even cause a fire. To temporarily turn off the display, press BLANK on the remote control.

Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product.

Safety Instructions

WARNING

1. Please read this manual before you operate your projector. Save it for future reference.

3. Refer servicing to qualified service personnel.

4. In some countries, the line voltage is NOT stable. This projector is designed to operate safely within a mains voltage between 100 to 240 volts AC, but could fail if power cuts or surges of ±10 volts occur. In areas where the mains voltage may fluctuate

or cut out, it is recommended that you connect your projector through a power stabilizer, surge protector or uninterruptible power supply (UPS).

6. The lamp becomes extremely hot during operation. Allow the projector to cool for approximately 45 minutes prior to removing the lamp assembly for replacement.

7. Never replace the lamp assembly or any electronic components unless the projector is unplugged.

8. Do not place this product on an unstable cart, stand, or table. The product may fall, sustaining serious damage.

9. Do not attempt to disassemble this projector. There are dangerous high voltages inside which may cause death if you should come into contact with live parts. The only user serviceable part is the lamp which has its own removable cover.

Under no circumstances should you ever undo or remove any other covers. Refer servicing only to suitably qualified professional service personnel.

10. Do not place this projector in any of the following environments.

- Space that is poorly ventilated or confined. Allow at least 50 cm clearance from walls and free flow of air around the projector.

- Locations where temperatures may become excessively high, such as the inside of a car with all windows rolled up.

- Locations where excessive humidity, dust, or cigarette smoke may contaminate optical components, shortening the projector's life span and darkening the picture.

- Locations near fire alarms

- Locations with an ambient temperature above 35°C / 95°F (The altitude is 1500 m~3050 m : Ambient temperature above 30°C / 86°F)

- Locations where the altitudes are higher than 3050 m (10007 feet).

11. Do not block the ventilation holes. Otherwise the components inside the projector will become overheated and result in a fire or malfunction. In addition, do not place the

projector in locations near an air conditioner, fan or dryer because direct contact with constant heat or warm air may cause deformation to the outer casing of the projector.

- Do not place this projector on a blanket, bedding or any other soft surface.

- Do not cover this projector with a cloth or any other item.

- Do not place inflammables near the projector.

12. Always place the projector on a level, horizontal surface during operation.

- Do not use if tilted at an angle of more than 10 degrees left to right, nor at angle of more than 15 degrees front to back. Using the projector when it is not fully horizontal may cause a malfunction of, or damage to, the lamp.

13. Do not stand the projector on end vertically. Doing so may cause the projector to fall over, causing injury or resulting in damage to the projector.

14. Do not step on the projector or place any objects upon it. Besides probable physical damage to the projector, doing so may result in accidents and possible injury.

15. Do not place liquids near or on the projector. Liquids spilled into the projector may cause it to fail. If the projector does become wet, disconnect it from the power supply's wall socket and call your local service center to have the projector serviced.

16. When the projector is under operation, you may sense some heated air and odor from its ventilation grill. It is a normal phenomenon and not a product defect.

17. Do not use the security lock slot for transporting or installation. It should be used with a commercially available theft prevention cable.

Introduction

Projector features

The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use.

The projector offers the following features.

• Presentation timer for better control of time during presentations

• Supports 3D display

• Color Management allowing color adjustments to your liking

• Less than 0.5W power consumption when standby mode is saving

• Wall Color correction allowing projection on surfaces of several predefined colors

• Quick auto search speeding up the signal detecting process

• Multiple sets of preset modes providing choices for different projection purposes

• One-key auto-adjustment to display the best picture quality

• Digital keystone correction to correct distorted images

• Adjustable color management control for data/video display

• High brightness projection lamp

• Ability to display 1.07 billion colors

• Multi-language On-Screen Display (OSD) menus

• Switchable normal and economic modes to reduce the power consumption

• Component HDTV compatibility (YP

• The apparent brightness of the projected image will vary depending on the ambient

lighting conditions, selected input signal contrast/brightness settings, and is directly proportional to projection distance.

• The lamp brightness will decline over time and may vary within the lamp manufacturers

specifications. This is normal and expected behavior.

bPr)

Shipping contents

Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase.

Standard accessories

The supplied accessories will be suitable for your region, and may differ from those illustrated.

Projector Power Cord VGA Cable

Multi-language user

manual CD

CU-TR Declaration

Optional accessories

1. Replacement lamp: DT01853

2. Ceiling mount: HAS-DX301

User manual Remote Control & Battery

Projector exterior view

1 2

6 7

9 10

Front/upper side

AUDIO IN

AUDIO OUT

S-VIDEO

VIDEO

HDMI

COMPUTER IN2

COMPUTER IN1

SERVICE

CONTROL

MONITOR OUT(1 ONLY)

12 141517 181920 21 22

13 16

Rear/lower side

1. Control panel (See "Control panel" on page 7 for details.)

2. Lamp cover

3. Vent (heated air exhaust)

4. Projection lens

5. Front elevator foot

6. Zoom ring

7. Focus ring

8. Vent (cool air intake)

9. Speaker

10. Front IR remote sensor

11. AC power cord inlet

12. AUDIO OUT port

13. AUDIO IN port

14. S-VIDEO port

15. VIDEO port

16. HDMI port

17. COMPUTER IN2 port

18. COMPUTER IN1 port

19. MONITOR OUT port

20. SERVICE port

21. CONTROL port

22. Security lock slot

23. Rear elevator foot

24. Name tag bar

WARNING

• THIS APPARATUS MUST BE EARTHED.

• When installing the unit, incorporate a readily accessible disconnect device in the fixed wiring, or connect the power plug to an easily accessible socket-outlet near the unit. If a fault should occur during operation of the unit, operate the disconnect device to switch the power supply off, or disconnect the power plug.

Controls and functions

Control panel

1. TEMPerature indicator light

Lights up red if the projector's temperature becomes too high.

2. LAMP indicator light

Indicates the status of the lamp. Lights up or flashes when the lamp has developed a problem.

3. Keystone/Arrow keys ( Up,

Down)

Manually corrects distorted images resulting from an angled projection.

4. Left

Used to hide the screen picture.

5. MODE/ENTER

Selects an available picture setup mode. Enacts the selected On-Screen Display

(OSD) menu item.

6. SOURCE

Displays the source selection bar.

7. POWER indicator light

Lights up or flashes when the projector is under operation.

Toggles the projector between standby mode and on.

9. Right

Activates panel key lock. When the On-Screen Display (OSD)

menu is activated, the #3, #4, and #9 keys are used as directional arrows to select the desired menu items and to make adjustments.

10. MENU

Turns on the On-Screen Display (OSD) menu. Goes back to previous OSD menu, exits and saves menu settings.

Remote control

2 3

4 5 6

Toggles the projector between standby mode and on.

2. MENU/EXIT

Turns on the On-Screen Display (OSD) menu. Goes back to previous OSD menu, exits and saves menu settings.

3. FREEZE

Freezes the projected image.

4. Left

5. MODE/ENTER

Selects an available picture setup mode. Enacts the selected On-Screen Display (OSD) menu item.

6. BLANK

Used to hide the screen picture.

7. Keystone/Arrow keys ( Up,

Down)

Manually corrects distorted images resulting from an angled projection.

8. VOLUME (+, -)

Adjusts the sound level.

7 9

9. AUTO

Automatically determines the best picture timings for the displayed image.

10. Right

Activates panel key lock. When the On-Screen Display (OSD)

menu is activated, the #4, #7, and #10 keys are used as directional arrows to select the desired menu items and to make adjustments.

11. SOURCE

Displays the source selection bar.

12. MAGNIFY (+, -)

Magnifies or reduces the projected picture size.

13. TIMER ON

Activates or displays an on-screen timer based on your own timer setting.

14. TIMER SET UP

Enters presentation timer setting directly.

15. Battery cover

Remote control effective range

(approx.)

The Infra-Red (IR) remote control is located on the front of the projector. The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensor to function correctly. The distance between the remote control and the sensor should not exceed 4 meters (~ 13 feet).

Make sure that there are no obstacles between the remote control and the IR sensor on the projector that might obstruct the infra-red beam.

Remote control function may not work correctly, if the strong light or light from the inverter fluorescent lamp hits sensor window.

15º

Replacing the remote control battery

1. Pull out the battery holder.

Please follow the illustrated instructions. Push and hold the locking arm while pulling out the battery holder.

2. Insert the new battery in the holder. Note the positive polarity should face outward.

3. Push the holder into the remote control.

WA RN I N G

Improper use may result in battery explosion, cracking or leakage, which could result in fire, injury and/or pollution of the surrounding environment. If you observe battery leakage, wipe out the leakage and then replace a battery. If the leakage adheres to your body or clothes, rinse well with water immediately.

• Keep the battery away from children and pets. Be careful for them not to swallow a battery.

• Avoid leaving the remote control and battery in an excessive heat or humid environment

like the kitchen, bathroom, sauna, sunroom or in a closed car.

• Replace only with the same or equivalent type recommended by the battery

manufacturer: [type: CR2025]

• Dispose of the used battery according to the manufacturer's instructions and local

environment regulations for your region.

• Never throw the battery into a fire. There may be danger of an explosion.

• If the battery is dead or if you will not be using the remote control for an extended period

of time, remove the battery to avoid damage to the remote control from possible battery leakage.

• Do not recharge, short circuit, solder or disassemble a battery.

Positioning your projector

Choosing a location

Your room layout or personal preference will dictate which installation location you select. Take into consideration the size and position of your screen, the location of a suitable power outlet, as well as the location and distance between the projector and the rest of your equipment.

Your projector is designed to be installed in one of following possible installation locations:

1. Normal

Select this location with the projector placed near the floor in front of the screen. This is the most common way to position the projector for quick setup and portability.

2. H Invert

Select this location with the projector placed near the floor behind the screen.

Note that a special rear projection screen is required.

Set H Invert in the SYSTEM SETTING: BASIC > Mirror menu after you turn the projector on.

3. V Invert

Select this location with the projector suspended upside-down from the ceiling behind the screen.

Note that a special rear projection screen is required.

Set V Invert in the SYSTEM SETTING: BASIC > Mirror menu after you turn the projector on.

4. H & V Invert

Select this location with the projector suspended upside-down from the ceiling in front of the screen.

Set H & V Invert in the SYSTEM SETTING: BASIC > Mirror menu after you turn the projector on.

Projection dimensions

Refer to "Dimensions" on page 49 for the center of lens dimensions of this projector before calculating the appropriate position.

The "screen" mentioned below refers to the projection screen usually consisting of a surface and a support structure.

Zoom Ratio: 1.1 x

Screen size

(Diagonal)

type

(inch)

60 1.5 2.4 94 2.6 103 91 36 -9 -4

70 1.8 2.8 110 3.1 120 107 42 -11 -4

80 2.0 3.2 125 3.5 138 122 48 -12 -5

90 2.3 3.6 141 3.9 155 137 54 -14 -5

100 2.5 4.0 156 4.4 172 152 60 -15 -6

120 3.0 4.8 188 5.2 207 183 72 -18 -7

150 3.8 6.0 235 6.6 258 229 90 -23 -9

200 5.1 7.9 313 8.7 344 305 120 -30 -12

250 6.4 9.9 391 10.9 430 381 150 -38 -15

b: Projection distance

min. max.

m inch m inch cm inch cm inch

4:3 screen

c1:

Screen height

c2:

Screen height

Screen size

(Diagonal)

type

(inch)

60 1.5 2.6 102 2.9 113 100 39 -25 -10

70 1.8 3.0 119 3.3 131 116 46 -29 -11

80 2.0 3.5 136 3.8 150 133 52 -33 -13

90 2.3 3.9 153 4.3 169 150 59 -37 -15

100 2.5 4.3 171 4.8 188 166 65 -42 -16

120 3.0 5.2 205 5.7 225 199 78 -50 -20

150 3.8 6.5 256 7.1 281 249 98 -62 -25

200 5.1 8.7 341 9.5 375 332 131 -83 -33

250 6.4 10.8 426 11.9 469 415 164 -104 -41

• There is 3% tolerance among these numbers due to optical component variations. It is

recommended that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics. This will help you determine the exact mounting position so that it best suits your installation location.

• To obtain the clearest image possible, we suggest that you keep the desired image size

within 60" to 180".

b: Projection distance

min. max.

m inch m inch cm inch cm inch

16:9 screen

Screen height

c1:

c2:

Screen height

Connection

AUDIO IN

AUDIO OUT

S-VIDEO

VIDEO

HDMI

COMPUTER IN2

COMPUTER IN1

SERVICE

CONTROL

MONITOR OUT(1 ONLY)

HDMI

AUDIO

OUT

RGB IN

RGB OUT

AUDIO IN

AUDIO OUT

S-VIDEO

VIDEO

HDMI

COMPUTER IN2

COMPUTER IN1

SERVICE

CONTROL

MONITOR OUT(1 ONLY)

COMPONENT

Cb/Pb

Cr/Pr

AUDIO

OUT

VIDEO

S-VIDEO

AUDIO

OUT

AUDIO

OUT

HDMI

Computer

Monitor

Speakers

(with an amplifier)

VCR/DVD/Blu-ray DiscTM player

When connecting a signal source to the projector, be sure to:

1. Turn all equipment off before making any connections.

2. Use the correct signal cables for each source.

3. Ensure the cables are firmly inserted.

• In the connections shown below, some cables may not be included with the projector (see

"Shipping contents" on page 5). They are commercially available from electronics stores.

• The connection illustrations below are for reference only. The rear connecting ports

available on the projector vary with each projector model.

• For detailed connection methods, see pages 13-16.

Connecting a computer or monitor

Connecting a computer

The projector provides two VGA input sockets that allow you to connect them to both IBM® compatibles and Macintosh® computers. A Mac adapter is needed if you are connecting legacy version Macintosh computers.

To connect the projector to a notebook or desktop computer:

1. Take the supplied VGA cable and connect one end to the D-Sub output socket of the computer.

2. Connect the other end of the VGA cable to the COMPUTER IN1 or COMPUTER IN2 signal input socket on the projector.

Many notebooks do not turn on their external video ports when connected to a projector. Usually a key combo like FN + F3 or CRT/LCD key turns the external display on/off. Locate a function key labeled CRT/LCD or a function key with a monitor symbol on the notebook. Press FN and the labeled function key simultaneously. Refer to your notebook's documentation to find your notebook's key combination.

Connecting a monitor

If you want to view your presentation close-up on a monitor as well as on the screen, you can connect the MONITOR OUT signal output socket on the projector to an external monitor with a VGA cable following the instructions below:

To connect the projector to a monitor:

1. Connect the projector to a computer as described in "Connecting a computer" on page

13.

2. Take a suitable VGA cable (only one supplied) and connect one end of the cable to the D-Sub input socket of the video monitor.

Or if your monitor is equipped with a DVI input socket, take a VGA to DVI-A cable and connect the DVI end of the cable to the DVI input socket of the video monitor.

3. Connect the other end of the cable to the MONITOR OUT socket on the projector.

The MONITOR OUT output only works when COMPUTER IN1 connection is made to the projector.

Connecting Video source devices

You can connect your projector to various Video source devices that provide any one of the following output sockets:

• HDMI

• Component Video

•S-Video

• Video (composite)

You need only connect the projector to a Video source device using just one of the above connecting methods, however each provides a different level of video quality. The method you choose will most likely depend upon the availability of matching terminals on both the projector and the Video source device as described below:

Best video quality

The best available video connection method is HDMI. If your source device is equipped with a HDMI socket, you can enjoy uncompressed digital video quality.

See "Connecting an HDMI device" on page 15 for how to connect the projector to a HDMI source device and other details.

If no HDMI source is available, the next best video signal is Component video (not to be confused with composite video). Digital TV tuner and DVD players output Component video natively, so if available on your devices, this should be your connection method of choice in preference to (composite) video.

See "Connecting a Component Video source device" on page 15 for how to connect the projector to a component video device.

Better video quality

The S-Video method provides a better quality analog video than standard composite Video. If you have both composite Video and S-Video output terminals on your Video source device, you should elect to use the S-Video option.

See "Connecting an S-Video source device" on page 16 for how to connect the projector to an S-Video device.

Least video quality

Composite Video is an analog video and will result in a perfectly acceptable, but less than optimal result from your projector, being the least video quality of the available methods described here.

See "Connecting a composite Video source device" on page 16 for how to connect the projector to a composite Video device.

Connecting audio

The projector has one built-in mono speaker which is designed to provide basic audio functionality accompanying data presentations for business purposes only. It is not designed for, nor intended for stereo audio reproduction use as might be expected in home theater or home cinema applications. Any stereo audio input (if provided), is mixed into a common mono audio output through the projector speaker.

If you wish, you can make use of the projector (mixed mono) speaker in your presentations, and also connect separate amplified speakers to the Audio Out socket of the projector. The audio output is a mixed mono signal and controlled by the projector Volume and Mute settings.

If you have a separate sound system, you will most likely want to connect the audio output of your Video source device to that sound system, instead of to the mono audio projector.

• The audio output only works when a signal source is connected to the projector.

• When an audio cable is connected to the AUDIO OUT port, the projector’s speaker will be

muted.

Connecting an HDMI device

You should use an HDMI cable when making connection between the projector and HDMI devices.

To connect the projector to an HDMI device:

1. Take an HDMI cable and connect one end to the HDMI output port of the video device.

2. Connect the other end of the cable to the HDMI input port on the projector.

The projector is only capable of playing mixed mono audio. See "Connecting audio" on page

14 for details.

Connecting a Component Video source device

Examine your Video source device to determine if it has a set of unused Component Video output sockets available:

• If so, you can continue with this procedure.

• If not, you will need to reassess which method you can use to connect to the device.

To connect the projector to a Component Video source device:

1. Take a VGA (D-Sub)-Component adaptor cable and connect the end with 3 RCA type connectors to the Component Video output sockets of the Video source device. Match the color of the plugs to the color of the sockets; green to green, blue to blue, and red to red.

2. Connect the other end of the VGA (D-Sub)-Component adaptor cable (with a D-Sub type connector) to the COMPUTER IN1 or COMPUTER IN2 socket on the projector.

• The projector is only capable of playing mixed mono audio, even if a stereo audio input is

connected. See "Connecting audio" on page 14 for details.

• If the selected video image is not displayed after the projector is turned on and the correct

video source has been selected, check that the Video source device is turned on and operating correctly. Also check that the signal cables have been connected correctly.

Connecting an S-Video source device

Examine your Video source device to determine if it has an unused S-Video output socket available:

• If so, you can continue with this procedure.

• If not, you will need to reassess which method you can use to connect to the device.

To connect the projector to an S-Video source device:

1. Take an S-Video cable and connect one end to the S-Video output socket of the Video source device.

2. Connect the other end of the S-Video cable to the S-VIDEO socket on the projector.

• The projector is only capable of playing mixed mono audio, even if a stereo audio input is

connected. See "Connecting audio" on page 14 for details.

• If the selected video image is not displayed after the projector is turned on and the correct

video source has been selected, check that the Video source device is turned on and operating correctly. Also check that the signal cables have been connected correctly.

• If you have already made a Component Video connection between the projector and this

S-Video source device using Component Video connections, you need not connect to this device using an S-Video connection as this makes an unnecessary second connection of poorer picture quality. See "Connecting Video source devices" on page 14 for details.

Connecting a composite Video source device

Examine your Video source device to determine if it has a set of unused composite Video output sockets available:

• If so, you can continue with this procedure.

• If not, you will need to reassess which method you can use to connect to the device.

To connect the projector to a composite Video source device:

1. Take a Video cable and connect one end to the composite Video output socket of the Video source device.

2. Connect the other end of the Video cable to the VIDEO socket on the projector.

• The projector is only capable of playing mixed mono audio, even if a stereo audio input is

connected. See "Connecting audio" on page 14 for details.

• If the selected video image is not displayed after the projector is turned on and the correct

video source has been selected, check that the Video source device is turned on and operating correctly. Also check that the signal cables have been connected correctly.

• You need only connect to this device using a composite Video connection if Component

Video and S-Video inputs are unavailable for use. See "Connecting Video source devices"

on page 14 for details.

Operation

AUDIO IN

S-VIDE

AUDIO OUT

VIDEO

Starting up the projector

1. Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted).

2. Press on the projector or remote control to start the projector. The POWER indicator light stays blue when the projector is on.

(If necessary) Rotate the focus ring to adjust the image clearness.

• If the projector is still hot from previous activity, it

will run the cooling fan for approximately 60 seconds before energizing the lamp.

• To maintain the lamp life, once you turn the

projector on, wait at least 5 minutes before turning it off.

• Also, do not turn the projector on for about 10

minutes or more after turning off.

3. If the projector is activated for the first time, select your OSD language and High Altitude

Mode following the on-screen instructions.

Language

See "Using the menus" on page 18 for details.

High Altitude Mode

See "Operating in a high altitude environment" on page 31 for details.

4. Switch all of the connected equipment on.

5. The projector will start to search for input signals. The current input signal being scanned appears in the upper left corner of the screen. If the projector doesn't detect a valid signal, the message 'No Signal' will continue to be displayed until an input signal is found.

You can also press SOURCE on the projector or remote control to select your desired input signal. See "Switching input signal" on page 21 for details.

• If the frequency/resolution of the input signal exceeds the projector's operating range, you

will see the message 'Out of Range' displayed on a blank screen. Please change to an input signal which is compatible with the projector's resolution or set the input signal to a lower setting. See "Timing chart" on page 50 for details.

• OSD languages and user manual languages may not match.

Using the menus

Current input signal

Main menu icon

Sub-menu

Highlight

Go to the previous page or to exit.

Status

Wall Color

3D Sync Invert

3D Sync

Magnify

H. Size

Phase

Position

Keystone

Aspect Ratio

Analog RGB

Off

Auto

Disable

15 15

Exit

Wall Color

3D Sync Invert

3D Sync

Magnify

H. Size

Phase

Position

Keystone

Aspect Ratio

Analog RGB

Off

Auto

Disable

Exit

Presentation Timer

Background Color

Sleep Timer

Panel Key Lock

Blank Timer

Auto Power Off

Mirror

Language

Analog RGB

Original

Disable

Normal 30 min Disable

Off

Exit

ENTER

Presentation Timer

Background Color

Sleep Timer

Panel Key Lock

Blank Timer

Auto Power Off

Mirror

Language

Analog RGB

English

Original

Disable

Normal 30 min Disable

Off

Exit

The projector is equipped with On-Screen Display (OSD) menus for making various adjustments and settings.

The OSD screenshots below are for reference only, and may differ from the actual design.

Below is the overview of the OSD menu.

To use the OSD menus, please set them to your familiar language first.

1. Press MENU on the projector or MENU/EXIT on the remote control to turn the OSD menu on.

2. Use / to highlight the SYSTEM

SETTING: Basic menu.

: DISPLAY

: PICTURE

: SOURCE

3. Press to highlight Language

and press MODE/ENTER.

4. Press / / / to select a

preferred language and press MODE/ENTER.

5. Press MENU on the projector or MENU/EXIT on the remote control to leave and save the settings.

: SYSTEM SETTING: Basic

: SYSTEM SETTING: Advanced

: INFORMATION

Utilizing the password function

INPUT NEW PASSWORD

Back

Password Error

Please try again.

For security purposes and to help prevent unauthorized use, the projector includes an option for setting up password security. The password can be set through the On-Screen Display (OSD) menu. For details of the OSD menu operation, please refer to "Using the menus" on

page 18.

You will be inconvenienced if you activate the password functionality and subsequently forget the password. Print this user manual (if necessary) and write the password you used in this manual, and keep it in a safe place for later use.

Setting a password

1. Open the OSD menu and go to the SYSTEM SETTING: Advanced > Security Settings menu. Press MODE/ENTER on the projector or remote control. The Security Settings page is displayed.

2. Highlight Change Password and press MODE/ENTER.

3. As pictured to the right, the four arrow keys

( , , , ) respectively represent 4 digits (1,

2, 3, 4). According to the password you desire to set, press the arrow keys to enter six digits for the password.

4. Confirm the new password by re-entering the new password. Once the password is set, the OSD menu returns to the Security Settings page.

5. To activate the Power on Lock function, press / to highlight Power on Lock and

press / to select On. When the Power on Lock function is activated, you have to

enter the correct password to turn on the projector.

6. To leave the OSD menu, press MENU on the projector or MENU/EXIT on the remote control.

• Once a password has been set, the projector cannot be used unless the correct password

is entered every time the projector is started.

• The digits being input will be displayed as asterisks on-screen. Write your selected

password down here in this user manual in advance or right after the password is entered so that it is available to you should you ever forget it. Password: __ __ __ __ __ __ Keep this user manual in a safe place.

If you forget the password

If the password function is activated, you will be asked to enter the six-digit password every time you turn on the projector. If you enter the wrong password, the password error message as pictured to the right is displayed lasting for three seconds, and the message 'INPUT PASSWORD' follows. You can retry by entering another six-digit password, or if you did not record the password in this user manual, and you absolutely do not remember it, you can use the password recall procedure. See "Entering the password recall procedure" on page 20 for details.

If you enter an incorrect password 5 times in succession, the projector will automatically shut down in a short time.

Entering the password recall procedure

Please write down the recall code, and contact the dealer.

Recall Code:

XXX XXX XXX XXX

RECALL PASSWORD

Exit

1. Press and hold AUTO on the remote control for 3 seconds. The projector will display a coded number on the screen.

2. Write down the number and turn off your projector.

3. Seek help from the local dealer to decode the number. You may be required to provide proof of purchase documentation to verify that you are an authorized user of the projector.

Changing the password

1. Open the OSD menu and go to the SYSTEM SETTING: Advanced > Security Settings > Change Password menu.

2. Press MODE/ENTER on the projector or remote control. The message 'INPUT CURRENT PASSWORD' is displayed.

3. Enter the old password.

• If the password is correct, another message 'INPUT NEW PASSWORD' is

displayed.

• If the password is incorrect, the password error message is displayed lasting for

three seconds, and the message 'INPUT CURRENT PASSWORD' is displayed for your retry. You can press MENU on the projector or MENU/ EXIT on the remote control to cancel the change or try another password.

4. Enter a new password.

5. Confirm the new password by re-entering the new password.

6. You have successfully assigned a new password to the projector. Remember to enter the new password next time the projector is started.

7. To leave the OSD menu, press MENU on the projector or MENU/EXIT on the remote control.

The digits being input will be displayed as asterisks on-screen. Write your selected password down here in this user manual in advance or right after the password is entered so that it is available to you should you ever forget it.

Password: __ __ __ __ __ __

Keep this user manual in a safe place.

Disabling the password function

To disable password protection, go back to the SYSTEM SETTING: Advanced > Security Settings > Power on Lock menu after opening the OSD menu system. Select Off

by pressing / . The message 'INPUT PASSWORD' is displayed. Enter the current password.

• If the password is correct, the OSD menu returns to the Security Settings page

with 'Off' shown in the row of Power on Lock. You will not have to enter the password next time you turn on the projector.

• If the password is incorrect, the password error message is displayed lasting for

three seconds, and the message 'INPUT PASSWORD' is displayed for your retry. You can press MENU on the projector or MENU/EXIT on the remote control to cancel the change or try another password.

Though the password function is disabled, you need to keep the old password in hand should you ever need to re-activate the password function by entering the old password.

Switching input signal

The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time.

Be sure the Quick Auto Search function in the SOURCE menu is On if you want the projector to automatically search for the signals.

You can also manually select the desired signal by pressing one of the source selection keys on the remote control, or cycle through the available input signals. Once you have done this, the Quick Auto Search function will be turned off automatically.

1. Press SOURCE on the projector or remote control. A source selection bar is displayed.

2. Press / until your desired signal is selected and press MODE/ENTER on the

projector or remote control. Once detected, the selected source information will be displayed on the screen for

seconds. If there are multiple devices connected to the projector, repeat steps 1-2 to search for another signal.

• The brightness level of the projected image will change accordingly when you switch

between different input signals. Data (graphic) "computer" presentations using mostly static images are generally brighter than "Video" using mostly moving images (movies).

• The input signal type effects the options available for the Preset Mode. See "Selecting a

preset mode" on page 26 for details.

• Please see "Projector specifications" on page 48 for the native display resolution of this

projector. For best display picture results, you should select and use an input signal which outputs at this resolution. Any other resolutions will be scaled by the projector depending upon the 'aspect ratio' setting, which may cause some image distortion or loss of picture clarity. See "Selecting the aspect ratio" on page 24 for details.

Adjusting the projected image

FOCUS ring

ZOOM ring

Adjusting the projection angle

The projector is equipped with two adjuster feet. They change the image height and vertical projection angle. Screw the adjuster feet to fine tune the angle until the image is positioned where you want it.

If the projector is not placed on a flat surface or the screen and the projector are not perpendicular to each other, the projected image becomes trapezoidal. To correct this situation, see "Correcting keystone" on page 23 for details.

CAUTION

Do not look into the lens while the lamp is on. The strong light from the lamp may cause damage to your eyes.

Be careful when you screw the front adjuster foot as it is close to the exhaust vent where hot air comes from.

Auto-adjusting the image

In some cases, you may need to optimize the picture quality. To do this, press AUTO on the remote control or activate the Auto Adjustment function in the SOURCE menu. Within 3 seconds, the built-in Intelligent Auto Adjustment function will re-adjust the values of Frequency and Clock to provide the best picture quality.

The current source information will be displayed in the upper left corner of the screen for 3 seconds.

• The screen will be blank while AUTO is functioning.

• This function is only available when computer signal (analog RGB) is selected.

Fine-tuning the image clarity

1. Adjust the projected image to the size that you need using the zoom ring.

2. If necessary, sharpen the image by rotating the focus ring.

Correcting keystone

Press /

Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen.

To correct this, besides adjusting the height of the projector, you will need to manually correct it following one of these steps.

• Press / on the projector or remote control to display the Keystone correction page. Press

to correct keystoning at the top of the image. Press to correct keystoning at the bottom of the image.

• Using the OSD menu

1. Press MENU on the projector or MENU/EXIT on the remote control and then press

/ until the

2. Press to highlight Keystone and press MODE/ENTER on the projector or remote

control. The Keystone correction page is displayed.

3. Press to correct keystoning at the top of the image or press to correct keystoning at the bottom of the image.

DISPLAY menu is highlighted.

Magnifying and searching for details

If you need to find the details on the projected picture, magnify the picture. Use the direction arrow keys for navigating the picture.

• Using the remote control

1. Press Magnify + /Magnify - on the remote control to display the Zoom bar.

2. Press Magnify + on the remote control or on the projector repeatedly to magnify

the picture to a desired size.

3. To navigate the picture, press the directional arrows ( , , , ).

4. To reduce size of the picture, press Magnify - on the remote control, or on the

projector. You can also restore the picture to its original size by pressing the AUTO button on the remote control.

• Using the OSD menu

1. Press MENU on the projector or MENU/EXIT on the remote control and then press

/ until the DISPLAY menu is highlighted.

2. Press

3. Repeat steps 2-4 in the section of Using the remote control above.

The picture can only be navigated after the picture is magnified. You can further magnify the picture while searching for details.

to highlight Magnify and press MODE/ENTER on the projector remote

control. The Zoom bar is displayed.

Selecting the aspect ratio

The 'aspect ratio' is the ratio of the image width to the image height. Most analog TV and computers are in 4:3 ratio, and digital TV and DVDs are usually in 16:9 ratio.

With the advent of digital signal processing, digital display devices like this projector can dynamically stretch and scale the image output to a different aspect than that of the image input signal.

To change the projected image ratio (no matter what aspect the source is):

1. Press MENU on the projector or MENU/EXIT on the remote control and then press

/ until the DISPLAY menu is highlighted.

2. Press

3. Press / to select an aspect ratio to suit the format of the video signal and your

to highlight Aspect Ratio.

display requirements.

About the aspect ratio

16:10 picture

15:9 picture

4:3 picture

16:9 picture

4:3 picture

16:9 picture

In the pictures below, the black portions are inactive areas and the white portions are active areas. OSD menus can be displayed on those unused black areas.

1. Auto: Scales an image proportionally to fit the projector's native resolution in its horizontal width. This is suitable for the incoming image which is neither in 4:3 nor 16:9 and you want to make most use of the screen without altering the image's aspect ratio.

Real: The image is projected as its original

resolution, and resized to fit within the display area. For input signals with lower resolutions, the projected image will display smaller than if resized to full screen. You could adjust the zoom setting or move the projector towards the screen to increase the image size if necessary. You may also need to refocus the projector after making these adjustments.

3. 4:3: Scales an image so that it is displayed in the center of the screen with a 4:3 aspect ratio. This is most suitable for 4:3 images like computer monitors, standard definition TV and 4:3 aspect DVD movies, as it displays them without aspect alteration.

4. 16:9: Scales an image so that it is displayed in the center of the screen with a 16:9 aspect ratio. This is most suitable for images which are already in a 16:9 aspect, like high definition TV, as it displays them without aspect alteration.

Optimizing the image

+50

+100

Selecting a preset mode

The projector is preset with several predefined preset modes so that you can choose one to suit your operating environment and input signal picture type.

To select an operation mode that suits your need, you can follow one of the following steps.

• Press MODE/ENTER on the projector or remote control repeatedly until your desired

mode is selected.

•Go to the PICTURE > Preset Mode menu and press / to select a desired mode.

The preset modes available for different types of signals are listed below.

1. Bright mode: Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms.

2. Presentation mode: Is designed for presentations under daylight environment to match computer and notebook computer coloring.

3. sRGB mode: Maximizes the purity of RGB colors to provide true-to-life images regardless of brightness setting. It is most suitable for viewing photos taken with an sRGB compatible and properly calibrated camera, and for viewing computer graphic and drawing applications.

4. Cinema mode: Is appropriate for playing colorful movies, video clips from digital cameras or DVs through the computer input for best viewing in a blackened (little light) environment.

5. Game mode: Suitable for all types of entertainment media, including gaming and movies.

6. User mode: Recalls the settings customized based on the current available preset modes. See "Setting the User mode" on page 26 for details.

Setting the User mode

1. Press MENU on the projector or MENU/EXIT on the remote control to open the OnScreen Display (OSD) menu.

2. Go to the PICTURE > Preset Mode menu.

3. Press / to select User. The adjustments you make in the Brightness, Contrast,

Color, Tint, Sharpness, Brilliant Color, Color Temperature and 3D Color Management will automatically be saved as the User mode.

Fine-tuning the image quality in user modes

According to the detected signal type, there are some user-definable functions available when User mode is selected. You can make adjustments to these functions based on your needs.

Adjusting Brightness

Highlight the PICTURE > Brightness menu and press / .

The higher the value, the brighter the image. And the lower the setting, the darker the image. Adjust this control so the black areas of the image appear just as black and that detail in the dark areas is visible.

Adjusting Contrast

-50

+50

Highlight the PICTURE > Contrast menu and press / .

The higher the value, the greater the contrast. Use this to set the peak white level after you have previously adjusted the Brightness setting to suit your selected input and viewing environment.

Adjusting Color

Highlight the PICTURE > Color menu and press / .

Lower setting produces less saturated colors. If the setting is too high, colors on the image will be overpowering, which makes the image unrealistic.

This function is only available when a Video, S-Video or Component Video signal is selected.

Adjusting Tint

Highlight the PICTURE > Tint menu and press / .

The higher the value, the more reddish the picture becomes. The lower the value, the more greenish the picture becomes.

This function is only available when a Video, S-Video with NTSC signal is selected.

Adjusting Sharpness

Highlight the PICTURE > Sharpness menu and press / .

The higher the value, the sharper the picture becomes. The lower the value, the softer the picture becomes.

This function is only available when a Video, S-Video or Component Video signal is selected.

Adjusting Brilliant Color

Highlight the PICTURE > Brilliant Color menu and press / .

This feature utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing truer, more vibrant colors in the projected picture. It enables a greater than 50% brightness increase in mid-tone images, which are common in video and natural scenes, so the projector reproduces images in realistic and true colors. If you prefer images with that quality, select On. If you don’t need it, select Off.

When Off is selected, the Color Temperature and 3D Color Management functions are not available.

Selecting a Color Temperature

Highlight the PICTURE > Color Temperature menu and press / .

The options available for color temperature* settings vary according to the signal type selected.

1. Cool: Makes images appear bluish white.

2. Normal: Maintains normal colorings for white.

3. Warm: Makes images appear reddish white.

*About color temperatures:

There are many different shades that are considered to be "white" for various purposes. One

RED

BLUE

GREEN

Yellow

Cyan

Magenta

of the common methods of representing white color is known as the “color temperature”. A white color with a low color temperature appears to be reddish white. A white color with a high color temperature appears to have more blue in it.

Color Management

Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered. Color management provides fine color control adjustment to allow for more accurate color reproduction, should you require it.

If you have purchased a test disc which contains various color test patterns and can be used to test the color presentation on monitors, TVs, projectors, etc., you can project any image from the disc on the screen and enter the 3D Color Management menu to make adjustments.

To adjust the settings:

1. Go to the DISPLAY menu and highlight 3D Color Management.

2. Press MODE/ENTER on the projector or remote control and the 3D Color Management page is displayed.

3. Highlight Primary Color and press / to select a color from among Red, Yellow,

Green, Cyan, Blue, or Magenta.

4. Press to highlight Hue and press / to select its range. Increase in the range will

include colors consisted of more proportions of its two adjacent colors. Please refer to the illustration to the right for

how the colors relate to each other. For example, if you select Red and set its

range at 0, only pure red in the projected picture will be selected. Increasing its range will include red close to yellow and red close to magenta.

5. Press to highlight Saturation and adjust

its values to your preference by pressing /

. Every adjustment made will reflect to the

image immediately. For example, if you select Red and set its value at 0, only the saturation of pure red will be affected.

Saturation is the amount of that color in a video picture. Lower settings produce less saturated colors; a setting of “0” removes that color from the image entirely. If the saturation is too high, that color will be overpowering and unrealistic.

6. Press to highlight Gain and adjust its values to your preference by pressing / .

The contrast level of the primary color you select will be affected. Every adjustment made will reflect to the image immediately.

7. Repeat steps 3 to 6 for other color adjustments.

8. Make sure you have made all of the desired adjustments.

9. Press MENU on the projector or MENU/EXIT on the remote control to exit and save the settings.

Setting the presentation timer

This function is only available when an input signal is selected and active.

Presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Follow these steps to utilize this function:

1. Press TIMER SET UP on the remote control to access the Presentation Timer menu or go to the SYSTEM SETTING: Basic > Presentation Timer menu and press MODE/ENTER to display the Presentation Timer page.

2. Highlight Timer Period and decide the time period by pressing / . The length of

time can be set from 1 to 5 minutes in 1-minute increments and 5 to 240 minutes in 5minute increments.

If the timer is already on, the timer will restart whenever the Timer Period is reset.

3. Press to highlight Timer Display and choose if you want the timer to show up on

the screen by pressing

Selection Description

Always

1 min/2 min/3 min Displays the timer on screen in the last 1/2/3 minute(s). Never Hides the timer throughout the presentation time.

4. Press to highlight Timer Position and set the timer position by pressing / .

Top-Left Bottom-Left Top-Right Bottom-Right

/ .

Displays the timer on screen throughout the presentation time.

5. Press to highlight Timer Counting Direction and select your desired counting

direction by pressing / .

Selection Description Count Up Increases from 0 to the preset time. Count Down Decreases from the preset time to 0.

6. Press to highlight Sound Reminder and decide if you want to activate sound

reminder by pressing / . If you select On, a double beep sound will be heard at the

last 30 seconds of counting down/up, and a triple beep sound will be produced when the timer is up.

7. To activate the presentation timer, press and press / to highlight On and press

MODE/ENTER.

8. A confirmation message displays. Highlight Yes and press MODE/ENTER on the projector or remote control to confirm. You will see the message “Timer is On” displaying on the screen. The timer starts counting when the timer is on.

To cancel the timer, perform the following steps:

1. Go to the SYSTEM SETTING: Basic > Presentation Timer menu and highlight Off. Press MODE/ENTER. A confirmation message displays.

2. Highlight Ye s and press MODE/ENTER to confirm. You will see the message “Timer is Off” displaying on the screen.

Hiding the image

In order to draw the audience's full attention to the presenter, you can use on the projector or BLANK on the remote control to hide the screen image. Press any key on the projector

or remote control to restore the image.

You can set the blank time in the let the projector return the image automatically after a period of time when there is no action taken on the blank screen.

CAUTION

Do not block the projection lens from projecting as this could cause the blocking object to become heated and deformed or even cause a fire.

SYSTEM SETTING: Basic > Blank Timer menu to

Locking control keys

With the control keys on the projector locked, you can prevent your projector settings from being changed accidentally (by children, for example). When the Panel Key Lock is on, no

control keys on the projector will operate except .

1. Press on the projector or Lock on the remote control, or go to the

SETTING: Basic > Panel Key Lock menu

projector or remote control.

2. A confirmation message is displayed. Select Yes to confirm.

To release panel key lock, press and hold on the projector or Lock on the remote control for 3 seconds.

You can also use the remote control to enter the SYSTEM SETTING: Basic > Panel Key

Lock menu and press / to select Off.

• Keys on the remote control are still functional when panel key lock is enabled.

• If you press to turn off the projector without disabling panel key lock, the projector will

still be in locked status the next time it is turned on.

, and select On by pressing / on the

Freezing the image

Press FREEZE on the remote control to freeze the image. The word 'FREEZE' will be displayed in the upper left corner of the screen. To release the function, press any key on the projector or remote control.

Even if an image is frozen on the screen, the pictures are running on the video or other device. If the connected devices have active audio output, you will still hear the audio even though the image is frozen on screen.

SYSTEM

Operating in a high altitude environment

Select 1 or 2

1. (High) Equal or higher than 1500m

2. (Normal) Lower than 1500m

High Altitude Mode

AUDIO IN

AUDIO OUT

We recommend you use the High Altitude Mode when your environment is between 1500 m–3050 m above sea level, and temperature is between 0°C–30°C.

CAUTION

Do not use the High Altitude Mode if your altitude is between 0 m and 1499 m and temperature is between 0°C and 35°C. The projector will be over cooled, if you turn the mode on under such a condition.

To activate the High Altitude Mode:

1. Press MENU on the projector or MENU/EXIT

on the remote control and then press / until

the SYSTEM SETTING: Advanced menu is highlighted.

2. Press to highlight High Altitude Mode and

press / to select 1 or 2.

3. A confirmation message is displayed.

4. Highlight 1 and press MODE/ENTER on the projector or remote control.

Operation under "High Altitude Mode" may cause a higher decibel operating noise level because of increased fan speed necessary to improve overall system cooling and performance.

If you use this projector under other extreme conditions excluding the above, it may display auto shut-down symptoms, which is designed to protect your projector from over-heating. In cases like this, you should switch to High Altitude Mode to solve these symptoms. However, this is not to state that this projector can operate under any and all harsh or extreme conditions.

Shutting down the projector

1. Press and a confirmation message is displayed prompting you.

If you don't respond in a few seconds, the message will disappear.

2. Press a second time.

3. Disconnect the power cord from the wall socket if the projector will not be used in an extended period of time.

CAUTION

• To protect the lamp, the projector will not respond

to any commands during the cooling process.

• Do not unplug the power cord before the projector

shutdown sequence is complete.

Menu operation

Menu system

Please note that the on-screen display (OSD) menus vary according to the signal type selected.

The menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible.

Main menu Sub-menu Options

Off/Light Yellow/Pink/Light Green/Blue/Blackboard

Auto/Frame Sequential/Frame Packing/Top-Bottom/Side-bySide/Off

1. DISPLAY

2. PICTURE

Wall Color

Aspect Ratio Auto/Real/4:3/16:9 Keystone Position Phase H. Size Magnify

3D Sync

3D Sync Invert Disable/Invert Preset Mode Bright/Presentation/sRGB/Cinema/Game/User Brightness Contrast Color Tint Sharpness Brilliant Color On/Off Color Temperature Cool/Normal/Warm

Primary Color R/G/B/C/M/Y

3D Color Management

Hue Saturation Gain

Main menu Sub-menu Options

3. SOURCE

4. SYSTEM SETTING: Basic

Quick Auto Search Off/On

Auto Adjustment

Timer Period 1~240 minutes

Timer Display

Presentation Timer

Language Multi-language OSD selection

Mirror

Auto Power Off

Blank Timer

Panel Key Lock On/Off

Sleep Timer

Background Color Black/Blue/Original

Timer Position

Timer Counting Direction

Sound Reminder On/Off On/Off

Always/1 min/2 min/3 min/ Never

Top-Left/Bottom-Left/TopRight/Bottom-Right

Count Down/Count Up

Normal/H Invert/V Invert/H & V Invert

Disable/5 min/10 min/15 min/ 20 min/25 min/30 min

Disable/30 min/1 hr/2 hr/3 hr/4 hr/8 hr/12 hr

Main menu Sub-menu Options

Quick Cooling On/Off

1 (High) Equal or higher than 1500 m 2 (Normal) Lower than 1500 m

5 sec/10 sec/15 sec/20 sec/25 sec/30 sec

Center/Top-Left/TopRight/Bottom-Right/ Bottom-Left

Normal/Economic/ Intelligent Eco

On/Off

• Source

• Preset Mode

• Color System

• Resolution

• Equivalent Lamp Hour

• Serial Number

5. SYSTEM SETTING: Advanced

6. INFORMATION

High Altitude Mode

Audio Settings

Menu Settings

Standby Mode Normal/Saving

Lamp Settings

Security Settings

Closed Caption

Reset All Settings Reset/Cancel

Current System Status

Mute On/Off Volume

Menu Display Time

Menu Position

Lamp Mode

Reset Lamp Timer Equivalent Lamp

Hour Change Password Power on Lock On/Off Closed Caption

Enable Caption Version CC1/CC2/CC3/CC4

Description of each menu

1. DISPLAY menu

Function Description

In the situation where you are projecting onto a colored surface such as a painted wall which may not be white, the Wall Color feature can help correct the projected picture' colors to prevent possible color difference between the source and projected pictures.

Wall Color

Aspect Ratio

Keystone

Position

Phase

H. Size

Magnify

Use the / buttons to select a color which is closest to the color of the projection surface.

This function is only available when a computer signal (analog RGB) is selected.

There are three options to set the image's aspect ratio depending on your input signal source. See "Selecting the aspect ratio" on page 24 for details.

Corrects any keystoning of the image. See "Correcting keystone" on

page 23 for details.

Displays the position adjustment page. To move the projected image, use the directional arrow keys. The values shown on the lower position of the page change with every key press you made until they reach their maximum or minimum.

This function is only available when a computer signal (analog RGB) is selected.

Adjusts the clock phase to reduce image distortion.

This function is only available when a computer signal (analog RGB) is selected.

Adjusts the horizontal width of the image.

This function is only available when a computer signal (analog RGB) is selected.

Magnifies or reduces the projected image. See "Magnifying and

searching for details" on page 23 for details.

Function Description

1. DISPLAY menu

This projector features 3D function which enables you to enjoy 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images. You need to wear a pair of 3D glasses to view 3D images.

1. Press the MODE/ENTER button to display the 3D Sync menu.

2. Use the / buttons to select a 3D sync mode.

- When Auto is selected, the projector detects the input signal and determines a suitable 3D sync mode automatically. In case

3D Sync

the 3D sync mode is not detected correctly and the 3D image is not displayed properly, select another 3D sync mode until the image is displayed correctly.

- If Off is selected, the 3D function will be turned off.

The 3D function is only available when the refresh rate of the Video source is 60Hz and computer source is 120Hz.

When the 3D Sync function is on:

• The brightness level of the projected image will decrease.

• The Preset Mode cannot be adjusted.

• Images cannot be magnified.

3D Sync Invert

When you discover the inversion of the image depth, enable this function to correct the problem.

Function Description

2. PICTURE menu

3. SOURCE menu

Pre-defined preset modes are provided so you can optimize your

Preset Mode

Brightness

Contrast

Color

Tint

Sharpness

Brilliant Color

Color Temperature

projector image set-up to suit your program type. See "Selecting a

preset mode" on page 26 for details.

Adjusts the brightness of the image. See "Adjusting Brightness" on

page 26 for details.

Adjusts the degree of difference between dark and light in the image. See "Adjusting Contrast" on page 27 for details.

Adjusts the color saturation level -- the amount of each color in a video image. See "Adjusting Color" on page 27 for details.

This function is only available when a Video, S-Video or Component Video signal is selected.

Adjusts the red and green color tones of the image. See "Adjusting

Tint" on page 27 for details.

The function is only available when a Video or S-Video signal with NTSC system is selected.

Adjusts the image to make it look sharper or softer. See "Adjusting

Sharpness" on page 27 for details.

This function is only available when a Video, S-Video or Component Video signal is selected.

Adjusts white peaking while maintaining correct color presentation. See "Adjusting Brilliant Color" on page 27 for details.

See "Selecting a Color Temperature" on page 27 for details.

3D Color Management

Quick Auto Search

Auto Adjustment

See "Color Management" on page 28 for details.

See "Switching input signal" on page 21 for details.

See "Auto-adjusting the image" on page 22 for details.

Function Description

4. SYSTEM SETTING: Basic menu

5. SYSTEM SETTING: Advanced menu

Presentation Timer

Language

Mirror

Auto Power Off

Blank Timer

Panel Key Lock

Sleep Timer

Background Color

Quick Cooling

High Altitude Mode

Audio Settings

Menu Settings

Reminds the presenter to finish the presentation within a certain time frame. See "Setting the presentation timer" on page 29 for details.

Sets the language for the On-Screen Display (OSD) menus. See

"Using the menus" on page 18 for details.

See "Choosing a location" on page 10 for details.

Allows the projector to turn off automatically if no input signal is detected after a set period of time. See "Setting Auto Power Off" on

page 42 for details.

Sets the image blank time when the Blank feature is activated, once elapsed the image will return to the screen. See "Hiding the image"

on page 30 for details.

Disables or enables all panel key functions except POWER on the projector and keys on the remote control. See "Locking control keys"

on page 30 for details.

This function allows the projector to turn off automatically if there is no user operation after a set period of time.

Use the / to select the period of time.

Allows you to select which logo screen will be displayed during projector start-up.

Enables or disables the Quick Cooling function. Use the / buttons to select On or Off.

Selecting On enables the function and projector cooling time will be shortened from a normal 70-second duration to approximately 13 seconds.

A mode for operation in high altitude areas. See "Operating in a high

altitude environment" on page 31 for details.

The sound adjustments made as below will have an effect on the projector speaker. Be sure you have made a correct connection to the projector audio input/output ports. See "Connection" on page 12 for more details.

Mute Mutes the sound received from AUDIO IN and HDMI.

Volume Adjusts the sound level received from AUDIO IN and HDMI.

Menu Display Time

Sets the length of time the OSD will remain active after your last key press. The range is from 5 to 30 seconds in 5-second increments.

Menu Position

Sets the On-Screen Display (OSD) menu position.

Function Description

5. SYSTEM SETTING: Advanced menu

Use / to select a standby mode.

Normal

The projector is able to provide the following functions when it is in standby mode.

• The projector can output a VGA signal when it is in standby mode and the COMPUTER IN 1 port is correctly connected to

Standby Mode

Lamp Settings

Security Settings

Closed Caption

Reset All Settings

devices.

• The projector can output audio signals when it is in standby mode and the corresponding ports are correctly connected to devices. Speaker is disabled in standby mode.

See "Connection" on page 12 for how to make the connections.

Saving

The projector consumes less than 0.5W power during standby when this mode is selected. The Monitor out and Audio out functions are disabled.

Lamp Mode

See "Setting Lamp Mode as Economic or Intelligent Eco" on page 42 for details.

Reset Lamp Timer

See "Resetting the lamp timer" on page 45 for details.

Equivalent Lamp Hour

See "Getting to know the lamp hour" on page 42 for details on how the total lamp hour is calculated.

See "Utilizing the password function" on page 19 for details.

Closed Caption Enable

Activates the function by selecting On when the selected input signal carries closed captions.

• Captions: An on-screen display of the dialogue, narration, and sound effects of TV programs and videos that are closed captioned (usually marked as "CC" in TV listings).

This function is only available when a Composite video or SVideo input signal is selected and its system format is NTSC.

Caption Version

Selects a preferred closed captioning mode. To view captions, select CC1, CC2, CC3, or CC4 (CC1 displays captions in the primary language in your area).

Returns all settings to the factory preset values.

The following settings will still remain: Language, Mirror, High Altitude Mode, Security Settings.

Function Description

6. INFORMATION menu

Source

Shows the current signal source.

Preset Mode Shows the selected mode in the PICTURE menu.

Color System

Current System Status

Shows input system format, NTSC, PAL, SECAM, or RGB.

Resolution

Shows the native resolution of the input signal.

Equivalent Lamp Hour

Displays the number of hours the lamp has been used.

Serial Number

Shows the serial number of the projector.

Maintenance

Care of the projector

Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean.

Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.

Cleaning the lens

Clean the lens whenever you notice dirt or dust on the surface.

• Use a canister of compressed air to remove dust.

• If there is dirt or smears, use lens-cleaning paper or moisten a soft cloth with lens cleaner and gently wipe the lens surface.

CAUTION

Never rub the lens with abrasive materials.

Cleaning the projector case

Before you clean the case, turn the projector off using the proper shutdown procedure as described in "Shutting down the projector" on page 31 and unplug the power cord.

• To remove dirt or dust, wipe the case with a soft, lint-free cloth.

• To remove stubborn dirt or stains, moisten a soft cloth with water and a neutral pH detergent. Then wipe the case.

CAUTION

Never use wax, alcohol, benzene, thinner or other chemical detergents. These can damage the case.

Storing the projector

If you need to store the projector for an extended time, please follow the instructions below:

• Make sure the temperature and humidity of the storage area are within the recommended range for the projector. Please refer to "Specifications" on page 48 or consult your dealer about the range.

• Retract the adjuster feet.

• Remove the battery from the remote control.

• Pack the projector in its original packing or equivalent.

Transporting the projector

It is recommended that you ship the projector with its original packing or equivalent.

Lamp information

Getting to know the lamp hour

When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. The method of calculating the equivalent lamp hour is as follows:

Total lamp hour = (hours used in Normal mode) + (hours used in Economic mode) + (hours used in Intelligent Eco mode)

To obtain the lamp hour information:

1. Press MENU on the projector or MENU/EXIT on the remote control and then press

/ until the SYSTEM SETTING: ADVANCED menu is highlighted.

2. Press to highlight Lamp Settings and press MODE/ENTER on the projector or

remote control. The Lamp Settings page is displayed.

3. You will see the Equivalent lamp hour information on the menu.

4. To leave the menu, press MENU on the projector or MENU/EXIT on the remote

control.

You can also get the lamp hour information on the INFORMATION menu.

Extending lamp life

The projection lamp is a consumable item. To keep the lamp life as long as possible, you can do the following settings via the OSD menu.

Setting Lamp Mode as Economic or Intelligent Eco

Using Economic/Intelligent Eco mode reduces system noise and power consumption. If the Economic/Intelligent Eco mode is selected, the light output will be reduced and result in darker projected pictures.

Setting the projector in Economic/Intelligent Eco mode also extends the lamp operation life. To set Intelligent Eco mode, go into the SYSTEM SETTING: ADVANCED > Lamp

Settings > Lamp Mode menu and press / .

Setting Auto Power Off

This function allows the projector to turn off automatically if no input source is detected after a set period of time to prevent unnecessary waste of lamp life.

To s et Auto Power Off, go into the SYSTEM SETTING: BASIC > Auto Power Off

menu and press / . If the preset time lengths are not suitable for your presentation, select Disable. The projector will not automatically shut down in a certain time period.

Replacing the lamp

To prepare a new lamp, contact your dealer and tell the lamp type number.

Type number: DT01853

WARNING

• The projector uses a high-pressure mercury glass lamp.

• The lamp can break with a loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them.

Hg - Lamp contains mercury. Manage in accordance with local disposal laws. See www.lamprecycle.org

• To reduce the risk of electrical shock, always turn the projector off and disconnect the power cord before changing the lamp.

• To reduce the risk of severe burns, allow the projector to cool for at least 45 minutes before replacing the lamp.

• To reduce the risk of injuries to fingers and damage to internal components, use caution when removing lamp glass that has shattered into sharp pieces. Before replacing the lamp, clean the lamp compartment and dispose of cleaning materials. Be careful of sharp edges in the lamp compartment. Wash hands after lamp replacement.

• If the lamp should break (it will make a loud bang when it does), ventilate the room well, and make sure not to inhale the gas or fine particles that come out from the projector's vent holes, and not to get them into your eyes or mouth.

• Only certified lamps are tested with this projector. Use of other lamps may cause electrical shock and fire.

• Be sure to place the projector on a flat surface to replace the lamp.

1. Turn the power off and disconnect the

power cord from the wall socket. If the lamp is hot, avoid burns by waiting for approximately 45 minutes until the lamp has cooled.

2. Prepare a new lamp. If the projector is

mounted in a high position, or if the lamp has broken, also ask the dealer to replace the lamp.

3. Loosen the screw of the lamp cover. Refer

to the right figure to identify the screw.

4. Remove the lamp cover from the projector.

WARNING

• Do not turn the power on with the lamp cover removed.

• Do not insert your fingers between the lamp and the projector. It may cause injuries.

5. Remove the protection film. Loosen the

screw that secures the lamp. Refer to the right figure to identify the screw.

6. Disconnect the lamp's wire connector from

the projector, and then slowly pick up the lamp by the handle.

CAUTION

• Pulling it too quickly may cause the lamp to break and scatter broken glass in the projector.

• Do not place the lamp in locations where water might splash on it, children can reach it, or near flammable materials.

• Do not insert your hands into the projector after the lamp is removed. If you touch the optical components inside, it could cause color unevenness and distortion of the projected images.

7. Insert the new lamp into the lamp

compartment and make sure it fits in the projector. Connect the new lamp’s wire connector to the projector.

8. Tighten the screw that secures the lamp.

CAUTION

• Loose screw may cause a bad connection, which could result in malfunction.

• Do not over tighten the screw.

9. Ensure the handle is fully laid flat and

locked in place.

10. Replace the new protection film that comes

with the new lamp.

11. Replace the lamp cover on the projector.

Reset Lamp Timer?

Reset

Cancel

Notice

12. Tighten the screw that secures the lamp

cover.

CAUTION

• Loose screw may cause a bad connection, which could result in malfunction.

• Do not over tighten the screws.

13. Restart the projector.

CAUTION

Do not turn the power on with the lamp cover removed.

Resetting the lamp timer

14. After the startup logo, open the On-Screen

Display (OSD) menu.

15. Go to the SYSTEM SETTING:

ADVANCED > Lamp Settings menu. Press MODE/ENTER on the projector or remote

control. The Lamp Settings page is displayed.

16. Press to highlight Reset lamp timer and

press MODE/ENTER on the projector or remote control. A warning message is displayed asking if you want to reset the lamp timer.

17. Highlight Reset and press MODE/ENTER

on the projector or remote control. The lamp time will be reset to '0'.

CAUTION

Do not reset if the lamp is not new or replaced as this could cause damage.

Indicators

Light Status & Description

POWER TEMP LAMP

Purple Off Off

Blue

Flashing

Blue Off Off

Purple

Flashing

Blue Off Red

Red

Flashing

Off Off Red

Off Off

Red Off

Red Red Off

Red

Blue Red Off

Off Off

Red

Flashing

System Messages

Stand-by

Powering up

Normal operation

Power-down cooling

CW start fail. Please contact your dealer for assistance.

Scaler shutdown fail. Please contact your dealer for assistance.

Lamp Error Messages

Lamp error. Please contact your dealer for assistance.

Red

Lamp is not lit up. Please contact your dealer for

Flashing

assistance.

Red

Lamp door is open.

Thermal Error Messages

Fan 1 error. Please contact your dealer for assistance.

Off

Fan 2 error. Please contact your dealer for assistance.

Over heated. Please contact your dealer for assistance.

Troubleshooting

The projector does not turn on.

Cause Remedy

There is no power from the power cord.

Attempting to turn the projector on again during the cooling process.

No picture

Cause Remedy

The video source is not turned on or connected correctly.

The projector is not correctly connected to the input signal device.

The input signal has not been correctly selected.

Blurred image

Cause Remedy

The projection lens is not correctly focused.

The projector and the screen are not aligned properly.

Plug the power cord into the AC inlet on the projector, and plug the power cord into the power outlet. If the power outlet has a switch, make sure that it is switched on.

Wait until the cooling down process has completed.

Turn the video source on and check that the signal cable is connected correctly.

Check the connection.

Select the correct input signal with the SOURCE key on the projector or remote control.

Adjust the focus of the lens using the focus ring.

Adjust the projection angle and direction as well as the height of the projector if necessary.

Remote control does not work

Cause Remedy

The battery is out of power. Replace the battery with a new one.

There is an obstacle between the remote control and the projector.

You are too far away from the projector.

Remove the obstacle.

Stand within 4 meters (~13 feet) of the projector.

Specifications

Projector specifications

• All specifications are subject to change without notice.

• Not all models can be purchased in your region.

General

Product name Projector

Optical

Resolution 1024 x 768 XGA Display system 1-CHIP DMD Lamp 220 W lamp

Electrical

Power supply AC 100-120V: 3.2 A, AC 220-240V: 1.5 A Power consumption AC 100-120V: 310W, AC 220-240V: 300W

Mechanical

Weight Approx. 2.4 kg

Input terminal

Computer input COMPUTER IN1 port

COMPUTER IN2 port Video signal input S-VIDEO port Mini DIN 4-pin x 1 VIDEO port RCA x 1 SD/HDTV signal input

Analog – D-Sub <–> Component RCA x 3

Digital – HDMI x 1

Audio signal input AUDIO IN port Stereo mini x 1

D-Sub 15-pin (female) x 2

(through COMPUTER IN1/COMPUTER IN2 input port)

Output terminal

Unit: mm

MONITOR OUT port D-Sub 15-pin (female) x 1 AUDIO OUT port Stereo mini x 1

Speaker 2 watt x 1

Control terminal

CONTROL port RS-232 serial control 9 pin x 1 IR receiver x 1 (Front)

Service terminal

SERVICE port USB mini B x 1

Environmental Requirements

Operating temperature • 0°C–35°C at 0–1499 m above sea level

• 0°C–30°C at 1500–3050 m above sea level

Operating relative humidity

Operating altitude • 0–1499 m (with High Altitude Mode 2 (Normal))

10%–90% (without condensation)

• 1500–3050 m (with High Altitude Mode 1 (High))

Dimensions

Max. size 314.6 mm (W) x 91.2 mm (H) x 218.8 mm (D)

Min. size 314.6 mm (W) x 89.1 mm (H) x 208 mm (D)

314.6

208

218.8

89.1

91.2

Timing chart

Supported timing for PC input

Resolution Mode

VGA_60*** 59.940 31.469 25.175

640 x 480

800 x 600

1024 x 768

1152 x 864 1152 x 864_75 75.00 67.500 108.000

1280x720 1280 x 720_60*** 60 45.000 74.250

1280 x 768 1280 x 768_60*** 59.870 47.776 79.5

1280 x 800

1280 x 1024

1280 x 960

1360 x 768 1360 x 768_60** 60.015 47.712 85.500 1440 x 900 WXGA+_60** 59.887 55.935 106.500 1400X1050 SXGA+_60** 59.978 65.317 121.750 1600x1200 UXGA** 60.000 75.000 162.000

1680 x 1050

640 x 480@67Hz MAC13 66.667 35.000 30.240

832 x 624@75Hz MAC16 74.546 49.722 57.280 1024 x 768@75Hz MAC19 74.93 60.241 80.000 1152 x 870@75Hz MAC21 75.06 68.68 100.00

• *Supported timing for 3D signal in Frame Sequential format.

VGA_72 72.809 37.861 31.500 VGA_75 75.000 37.500 31.500 VGA_85 85.008 43.269 36.000

SVGA_60*** 60.317 37.879 40.000

SVGA_72 72.188 48.077 50.000 SVGA_75 75.000 46.875 49.500 SVGA_85 85.061 53.674 56.250

SVGA_120*

(Reduce

Blanking)

XGA_60*** 60.004 48.363 65.000

XGA_70 70.069 56.476 75.000 XGA_75 75.029 60.023 78.750 XGA_85 84.997 68.667 94.500

XGA_120*

(Reduce

Blanking)

WXGA_60*** 59.810 49.702 83.500

WXGA_75 74.934 62.795 106.500 WXGA_85 84.880 71.554 122.500

WXGA_120*

(Reduce

Blanking)

SXGA_60** 60.020 63.981 108.000

SXGA_75 75.025 79.976 135.000 SXGA_85 85.024 91.146 157.500

1280 x 960_60** 60.000 60.000 108

1280 x 960_85 85.002 85.938 148.500

1680 x

1050_60**

Refresh rate

(Hz)

119.854 77.425 83.000

119.989 97.551 115.500

119.909 101.563 146.25

59.954 65.290 146.250

H-frequency

(kHz)

Clock

(MHz)

• **Supported timing for 3D signal in Top-Bottom and Side-by-Side formats.

• ***Supported timing for 3D signal in Frame Sequential, Top-Bottom and Side-by-Side formats.

Supported timing for HDMI input

Resolution Mode

VGA_60*** 59.940 31.469 25.175

640 x 480

800 x 600

1024 x 768

1152 x 864 1152 x 864_75 75.00 67.500 108.000 1280 x 720 1280x720_60*** 60 45.000 74.250 1280 x 768 1280 x 768_60*** 59.870 47.776 79.5

1280 x 800

1280 x 1024

1280 x 960

1360 x 768 1360 x 768_60** 60.015 47.712 85.500

1440 x 900 WXGA+_60** 59.887 55.935 106.500 1400 x 1050 SXGA+_60** 59.978 65.317 121.750 1600 x 1200 UXGA** 60.000 75.000 162.000 1680 x 1050 1680x1050_60** 59.954 65.290 146.250

640x480@67Hz MAC13 66.667 35.000 30.240

832x624@75Hz MAC16 74.546 49.722 57.280 1024x768@75Hz MAC19 75.020 60.241 80.000 1152x870@75Hz MAC21 75.06 68.68 100.00

• *Supported timing for 3D signal in Frame Sequential format.

VGA_72 72.809 37.861 31.500 VGA_75 75.000 37.500 31.500 VGA_85 85.008 43.269 36.000

SVGA_60*** 60.317 37.879 40.000

SVGA_72 72.188 48.077 50.000 SVGA_75 75.000 46.875 49.500 SVGA_85 85.061 53.674 56.250

SVGA_120*

(Reduce

Blanking)

XGA_60*** 60.004 48.363 65.000

XGA_70 70.069 56.476 75.000 XGA_75 75.029 60.023 78.750 XGA_85 84.997 68.667 94.500

XGA_120*

(Reduce

Blanking)

WXGA_60*** 59.810 49.702 83.500

WXGA_75 74.934 62.795 106.500 WXGA_85 84.880 71.554 122.500

WXGA_120*

(Reduce

Blanking)

SXGA_60** 60.020 63.981 108.000

SXGA_75 75.025 79.976 135.000 SXGA_85 85.024 91.146 157.500

1280 x 960_60** 60.000 60.000 108

1280 x 960_85 85.002 85.938 148.500

Refresh rate

(Hz)

119.854 77.425 83.000

119.989 97.551 115.500

119.909 101.563 146.25

H-frequency

(kHz)

Clock (MHz)

• **Supported timing for 3D signal in Top-Bottom and Side-by-Side formats.

• ***Supported timing for 3D signal in Frame Sequential, Top-Bottom and Side-by-Side formats.

Dot Clock

Frequency

(MHz)

Timing Resolution

Horizontal frequency

(KHz)

Ver tical

frequency

(Hz) 480i* 720 (1440) x 480 15.73 59.94 27 480p 720 x 480 31.47 59.94 27

576i 720 (1440) x 576 15.63 50 27

576p 720 x 576 31.25 50 27

720/50p** 1280 x 720 37.5 50 74.25 720/60p** 1280 x 720 45.00 60 74.25

1080/24P** 1920 x 1080 27 24 74.25

1080/30P 1920 x 1080 33.75 30 74.25 1080/50i*** 1920 x 1080 28.13 50 74.25 1080/60i*** 1920 x 1080 33.75 60 74.25

1080/50P 1920 x 1080 56.25 50 148.5

1080/60P 1920 x 1080 67.5 60 148.5

• *Supported timing for 3D signal in Frame Sequential format.

• **Supported timing for 3D signal in Frame Packing and Top-Bottom formats.

• ***Supported timing for 3D signal in Side-by-Side format.

Supported timing for Component-YPbPr input

Timing Resolution

Horizontal frequency

(KHz)

Ver tical

Frequency

(Hz)

Dot Clock

Frequency

(MHz)

480i 720 x 480 15.73 59.94 13.5

480p 720 x 480 31.47 59.94 27

576i 720 x 576 15.63 50 13.5

576p 720 x 576 31.25 50 27 720/50p 1280 x 720 37.5 50 74.25 720/60p 1280 x 720 45.00 60 74.25 1080/50i 1920 x 1080 28.13 50 74.25 1080/60i 1920 x 1080 33.75 60 74.25

1080/24P 1920 x 1080 27 24 74.25 1080/30P 1920 x 1080 33.75 30 74.25 1080/50P 1920 x 1080 56.25 50 148.5 1080/60P 1920 x 1080 67.5 60 148.5

Displaying a 1080i(1125i)@60Hz or 1080i(1125i)@50Hz signal may result in slight image vibration.

Supported timing for Video and S-Video inputs

Video mode

NTSC 15.73 60 3.58

PAL 15.63 50 4.43

SECAM 15.63 50 4.25 or 4.41

PAL-M 15.73 60 3.58

PAL-N 15.63 50 3.58

PAL-60 15.73 60 4.43

NTSC4.43 15.73 60 4.43

Horizontal

Frequency (kHz)

Vertical Frequency

(Hz)

Color sub-carrier

Frequency (MHz)

Regulation Statements

FCC statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modifications not expressly approved by the manufacturer void the user's authority to operate the equipment.

ICES-003

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.

WEEE

Disposing of this product correctly will help save valuable resources and prevent any potential negative effects on human health and the environment, which could otherwise arise from inappropriate waste handling.

Please contact your local authority for further details of your nearest designated collection point.

Penalties may be applicable for incorrect disposal of this waste, in accordance with you national legislation.

For business users in the European Union

If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.

Information on Disposal in other Countries outside the European Union

This symbol is only valid in the European Union. If you wish to discard this product please contact your local authorities or dealer and ask for the correct method of disposal.

Copyright information

Copyright 2015. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company.

Disclaimer

This company makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Further, this company reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes.

The illustrations in this manual are for illustrative purposes. They may differ slightly from your projector.

The reproduction, transfer or copy of all or any part of this document is not permitted without express written consent.

*DLP and Digital Micromirror Device (DMD) are trademarks of Texas Instruments. Others are copyrights of their respective companies or organizations.

*Registered trademarks of HDMI Licensing LLC in the United States and other countries.

*Mac

and Macintosh® are registered trademarks of Apple Inc.

*Microsoft U.S. and/or other countries.

All other trademarks are the properties of their respective owners.

and PowerPoint® are registered trademarks of Microsoft Corporation in the

Warranty and after-service

If an abnormal operation (such as smoke, strange odor or excessive sound) should occur, stop using the projector immediately.

Otherwise if a problem occurs with the projector, first refer to “Troubleshooting”, and run through the suggested checks.

If this does not resolve the problem, please consult your dealer or service company. They will tell you what warranty condition is applied.

Hitachi America, Ltd.

Business Solutions Group 2420 Fenton Street, Suite 200 Chula Vista,CA 91914 USA CANADA Tel: +1 -800-448-2244 ► http://www.hitachi-america.us/projectors

Hitachi Europe Ltd., Digital Media Group Consumer Affairs Department

Whitebrook Park, Lower Cookham Road, Maidenhead Berkshire SL6 8YA UNITED KINGDOM Tel: 0844 481 0297 (international call is NOT available for this number) Email: tech.assist@hitachi-eu.com ► http://www.equinox.co.uk/hitachi/

Hitachi Europe S.A.S., Digital Media Group

31 bis rue du 35ème Régiment de l’aviation ZAC DU CHENE, 69500 BRON FRANCE Tel: 0 478 262135 +33 Email: france.consommateur@hitachi-eu.com

Hitachi Europe GmbH

Am Seestern 18 40547 Düsseldorf GERMANY Tel: 0 40 73353 468 +49 (0) 40 73353 468 Email: Service.germany@hitachi-eu.com

Hitachi Europe S.A.

364, Kifissias Ave. & 1, Delfon Str. 152 33 Chalandri Athens GREECE Tel: +30 210 921 0800 Email: dmgservice.gr@hitachi-eu.com

Hitachi Europe S.r.l.

Via T. Gulli, 39 20147 MILANO ITALY Tel: +39 2 257 12355 Email: Aerta_bsd@iol.it

Hitachi Europe S.A.

Gran Via Carles III, 86 Planta 5ª Edificios Trade - Torre Este 08028 Barcelona SPAIN Tel: 0 93 266 4747 +34 93 266 4747 Email: Atencion.Cliente@hitachi-eu.com

478 262135

Hitachi Europe AB

Frösundaviks Alle 15 169 29 Solna SWEDEN Sweden Tel: +46 36 16 16 90 Finland Tel: +358 9 8494 133 Norway Tel: +47 2290 1930 Denmark Tel: +45 7562 4577 ► http://www.hitachidigitalmedia.com

Hitachi Australia Pty Ltd.

Suite 801, Level 8, 123 Epping Road North Ryde N.S.W 2113 AUSTRALIA Tel: +61 -2-9888-4100 ► http://www.hitachi.com.au

Hitachi (Hong Kong), Ltd.

18/F., Ever Gain Centre, 28 On Muk Street., Shatin, N.T. HONG KONG Tel: +852 -2113-8883 ► http://www.hitachi-hk.com.hk

Hitachi Sales (Malaysia) Sdn. Bhd.

Lot 12, Jalan Kamajuan, Bangi Industrial Estate, 43650 Bandar Baru Bangi, Selangor Darul Ehsan MALAYSIA

Tel: +60 -3-8911-2670

► http://www.hitachiconsumer.com.my

Hitachi Home Electronics Asia (S) Pte. Ltd.

438A Alexandra Road #01-01/02/03 Alexandra Technopark, 119967 SINGAPORE Tel: +65 -6536-2520 ► http://www.hitachiconsumer.com.sg

Hitachi Sales Corp. of Taiwan

2nd Floor, No.65, Nanking East Road, Section 3, Taipei 104 TAIWAN Tel: +886-2-2516-0500 ► http://www.hsct.com.tw

Hitachi Sales (Thailand), Ltd.

994, 996 Soi Thonglor, Sukhumvit 55 Rd., Klongtonnua, Vadhana, Bangkok 10110

Tel: +66 -2381-8381-98 ► http://www.hitachi-th.com

THAILAND

Hitachi Maxell, Ltd.

JAPAN

► http://www.hitachi.co.jp/proj/

( :Country/Region)

Hitachi CP-DX351 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of contents

Important safety instructions

Safety Instructions

Introduction

Projector features

Shipping contents

Standard accessories

Optional accessories

Projector exterior view

Controls and functions

Control panel

Remote control

Positioning your projector

Choosing a location

Projection dimensions

Connection

Connecting a computer or monitor

Connecting a computer

Connecting a monitor

Connecting Video source devices

Connecting an HDMI device

Connecting a Component Video source device

Connecting an S-Video source device

Connecting a composite Video source device

Operation

Starting up the projector

Using the menus

Utilizing the password function

Setting a password

If you forget the password

Entering the password recall procedure

Changing the password

Disabling the password function

Switching input signal

Adjusting the projected image

Adjusting the projection angle

Auto-adjusting the image

Fine-tuning the image clarity

Correcting keystone

Magnifying and searching for details

Selecting the aspect ratio

Optimizing the image

Selecting a preset mode

Fine-tuning the image quality in user modes

Setting the presentation timer

Hiding the image

Locking control keys

Freezing the image

Operating in a high altitude environment

Shutting down the projector

Menu operation

Menu system

Description of each menu

Maintenance

Care of the projector

Cleaning the lens

Cleaning the projector case

Storing the projector

Transporting the projector

Lamp information

Getting to know the lamp hour

Extending lamp life

Replacing the lamp

Indicators

Troubleshooting

Specifications

Projector specifications

Dimensions

Timing chart

Regulation Statements

FCC statement

ICES-003

WEEE

Copyright information

Warranty and after-service
