Hitachi CP-D10 User Manual

Projector
CP-D10
User's Manual (detailed) Operating Guide – Technical
Example of PC signal
Resolution (H x V) H. frequency (kHz) V. frequency (Hz) Rating Signal mode
720 x 400 640 x 480 31.5 59.9 VESA VGA (60Hz) 640 x 480 37.9 72.8 VESA VGA (72Hz) 640 x 480 37.5 75.0 VESA VGA (75Hz) 640 x 480 43.3 85.0 VESA VGA (85Hz) 800 x 600 35.2 56.3 VESA SVGA (56Hz) 800 x 600 37.9 60.3 VESA SVGA (60Hz) 800 x 600 48.1 72.2 VESA SVGA (72Hz) 800 x 600 46.9 75.0 VESA SVGA (75Hz) 800 x 600 53.7 85.1 VESA SVGA (85Hz)
832 x 624 49.7 74.5 Mac 16” mode 1024 x 768 48.4 60.0 VESA XGA (60Hz) 1024 x 768 56.5 70.1 VESA XGA (70Hz) 1024 x 768 60.0 75.0 VESA XGA (75Hz) 1024 x 768 68.7 85.0 VESA XGA (85Hz) 1152 x 864 67.5 75.0 VESA 1280 x 768 47.7 60.0 VESA W-XGA (60Hz) 1280 x 800 49.7 60.0 VESA 1280 x 960 60.0 60.0 VESA
1280 x 1024 64.0 60.0 VESA SXGA (60Hz) 1280 x 1024 80.0 75.0 VESA SXGA (75Hz) 1280 x 1024 91.1 85.0 VESA SXGA (85Hz) 1400 x 1050 65.2 60.0 VESA SXGA+ (60Hz) 1600 x 1200 75.0 60.0 VESA UXGA (60Hz)
37.9 85.0 VESA TEXT
1152 x 864 (75Hz)
1280 x 800 (60Hz) 1280 x 960 (60Hz)
NOTE • Be sure to check jack type, signal level, timing and resolution
before connecting this projector to a PC.
• Some PCs may have multiple display screen modes. Use of some of these modes will not be possible with this projector.
• Depending on the input signal, full-size display may not be possible in some cases. Refer to the number of display pixels above.
• Although the projector can display signals with resolution up to UXGA (1600x1200), the signal will be converted to the projector’s panel resolution before being displayed. The best display performance will be achieved if the resolutions of the input signal and projector panel are identical.
• Automatic adjustment may not function correctly with some input signals.
• The image may not be displayed correctly when the input sync signal is a composite sync or a sync on G.
1
Initial set signals
Initial set signals
The following signals are used for the initial settings. The signal timing of some PC models may be different. In such case, adjust the items V POSITION and H POSITION in IMAGE menu.
Back porch (B) Front porch (D) Back porch (b) Front porch (d)
Data Data
H. Sync. V. Sync.
Sync (A) Sync (a)
Computer signal
720 x 400 / TEXT 2.0 3.0 20.3 1.0 3 42 400 1 640 x 480 / VGA (60Hz) 3.8 1.9 25.4 0.6 2 33 480 10 640 x 480 / VGA (72Hz) 1.3 4.1 20.3 0.8 3 28 480 9 640 x 480 / VGA (75Hz) 2.0 3.8 20.3 0.5 3 16 480 1 640 x 480 / VGA (85Hz) 1.6 2.2 17.8 1.6 3 25 480 1 800 x 600 / SVGA (56Hz) 2.0 3.6 22.2 0.7 2 22 600 1 800 x 600 / SVGA (60Hz) 3.2 2.2 20.0 1.0 4 23 600 1 800 x 600 / SVGA (72Hz) 2.4 1.3 16.0 1.1 6 23 600 37 800 x 600 / SVGA (75Hz) 1.6 3.2 16.2 0.3 3 21 600 1 800 x 600/SVGA (85Hz) 1.1 2.7 14.2 0.6 3 27 600 1 832 x 624 / Mac 16" mode 1.1 3.9 14.5 0.6 3 39 624 1 1024 x 768 / XGA (60Hz) 2.1 2.5 15.8 0.4 6 29 768 3 1024 x 768 / XGA (70Hz) 1.8 1.9 13.7 0.3 6 29 768 3 1024 x 768 / XGA (75Hz) 1.2 2.2 13.0 0.2 3 28 768 1 1024 x 768 / XGA (85Hz) 1.0 2.2 10.8 0.5 3 36 768 1 1152 x 864 (75Hz) 1.2 2.4 10.7 0.6 3 32 864 1 1280 x 768 / W-XGA (60Hz) 1.7 2.5 16.0 0.8 3 23 768 1 1280 x 800 (60Hz) 1.6 2.4 15.3 0.8 3 24 800 1 1280 x 960 (60Hz) 1.0 2.9 11.9 0.9 3 36 960 1 1280 x 1024 / SXGA (60Hz) 1.0 2.3 11.9 0.4 3 38 1024 1 1280 x 1024 / SXGA (75Hz) 1.1 1.8 9.5 0.1 3 38 1024 1 1280 x 1024 / SXGA (85Hz) 1.0 1.4 8.1 0.4 3 44 1024 1 1400 x 1050 / SXGA+ (60Hz) 1.2 2.0 11.4 0.7 3 33 1050 1 1600 x 1200 / UXGA (60Hz) 1.2 1.9 9.9 0.4 3 46 1200 1
Active video (C)
Active video (c)
Horizontal signal timing (μs) Vertical signal timing (lines)
(A) (B) (C) (D) (a) (b) (c) (d)
2
Connection to the ports
Connection to the ports
NOTICE
►Use the cables with straight plugs, not L-shaped ones, as the
input ports of the projector are recessed.
A
A
COMPUTER IN1, BCOMPUTER IN2, CMONITOR OUT
B
D-sub 15pin mini shrink jack
(1) for PC signal
• Video signal: RGB separate, Analog, 0.7Vp-p, 75Ω terminated (positive)
• H/V. sync. Signal: TTL level (positive/negative)
• Composite sync. Signal: TTL level
C
 


Pin Signal Pin Signal
1
Video Red 10 Ground 2 Video Green 11 (No connection) 3 Video Blue 4 (No connection) 5 Ground 13 H. sync / Composite sync. 6 Ground Red 14 V. sync. 7 Ground Green 8 Ground Blue 9 (No connection) - -
12
15
A
: SDA (DDC data)
B
C
,
: (No connection)
A
: SCL (DDC clock)
B
C
,
: (No connection)
(2) for Component signal
• Y : Component video Y with composite sync, 1.0±0.1 Vp-p, 75 Ω terminator
• Cr/Pr : Component video Cr/Pr, 0.7±0.1 Vp-p, 75 Ω terminator
• Cb/Pb : Component video Cb/Pb, 0.7±0.1 Vp-p, 75 Ω terminator System:480i@60,480p@60,576i@50,576p@50,720p@50/60,1080i@50/60,1080p@50/60
Pin Signal Pin Signal
1
Cr/Pr 9 (No connection) 2 Y 10 Ground 3 Cb/Pb 11 (No connection) 4 (No connection) 12 (No connection) 5 Ground 13 (No connection) 6 Ground Cr/Pr 14 (No connection) 7 Ground Y 15 (No connection) 8 Ground Cb/Pb - -
3
Connection to the ports (continued)
To input component video signal to COMPUTER IN ports
ex.
D-sub plug
RCA plugs
Y CB/PB CR/PR
COMPONENT VIDEO OUT
VCR/DVD player
RCA connectors
To input component video signal to the COMPUTER IN1 or IN2 port of the projector, use a RCA to D-sub cable or adapter. For about the pin description of the required cable or adapter, refer to the descriptions about COMPUTER IN1 and IN2 port (
3).
4
D
S-VIDEO
Mini DIN 4pin jack
D
E
Connection to the ports (continued)
4
3
1
2
Pin Signal
Color signal 0.286Vp-p (NTSC, burst), 75Ω terminator
1
Color signal 0.300Vp-p (PAL/SECAM, burst) 75Ω terminator
2 Brightness signal, 1.0Vp-p, 75Ω terminator
3 Ground
4 Ground
E
VIDEO
RCA jack
• System: NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43, PAL60
• 1.0±0.1Vp-p, 75Ω terminator
5
Connection to the ports (continued)
F
AUDIO IN1, GAUDIO IN2
Ø3.5 stereo mini jack
F
G
H
I
J
K
• 200 mVrms 47kΩ terminator
AUDIO IN3 HR, IL
RCA jack x2
• 200 mVrms 47kΩ terminator
AUDIO OUT JR, KL
RCA jack x2
• 200 mVrms 1kΩ output impedance
6
L
CONTROL
Connection to the ports (continued)
L
D-sub 9pin plug
• About the details of RS-232C communication,
9
54321
6
8
7
please refer to the following page.
Pin Signal Pin Signal Pin Signal
1 (No connection) 4 (No connection) 7 RTS
2 RD 5 Ground 8 CTS
3 TD 6 (No connection) 9 (No connection)
7
