Hitachi 32CX11B, 32TX78B, 32TX79K, 35CX30B, 35TX88B Operating Instruction

SOLID STATE COLOR TV

OPERATING GUIDE

S

IMPORTANT SAFEGUARDS

FIRST TIME USE

THE REMOTE CONTROL

COLOR GRAPHIC GUIDE

USEFUL INFORMATION

2-5

6-24

25-37

38-55

56-63

INDEX

Follow all warnings and instructions marked on this television receiver.

The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the

presence of uninsulated "dangerous voltage" within the

RISK OF ELECTRIC SHOCK

DO NOT OPEN

product's enclosure that may be of a sufficient magnitude

IMPORTANT

constitute a dsk of electdc shock to persons.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

A The exclamation point within an equilateral tdangle is

• IL. intended to alert the user to the presence of important

J _. operating and maintenance (servicing) Instructions In the

_ _, literature accompanying the appliance.

i

WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT

EXPOSE THIS TELEVISION SYSTEM TO RAIN OR MOISTURE.

NOTE: There are no user serviceable parts inside the receiver.

Model Number and Serial Number are indicated on back side of the set.

POWER SOURCE

This HITACHI COLOR TV is designed to operate on 120 volts 60Hz, AC household current.
Insert power cord into a 120 volt 60Hz outlet.

TO PREVENT ELECTRIC SHOCK, DO NOT USE THE TELEVISION'S PLUG WITH AN EXTENSION
CORD, RECEPTACLE, OR OTHER OUTLET UNLESS THE BLADES AND GROUND TERMINAL CAN

BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

NEVER CONNECT THE TV TO 50 Hz, DIRECT CURRENT, OR ANYTHING OTHER THAN THE SPECI-
FIED VOLTAGE.

This television receiver will display television Closed Captioning, ( B or I_ ), in accor-

I NOTE:

dance with paragraph 15.119 of the FCC rules.

Never remove the back cover of the set as this can expose you to very high voltages
and other hazards. If the set does not operate properly, unplug the set and call your

I _CAUTION:

dealer or service shop.

2

IMPORTANT

iMPORTANT SAFEGUARDS

CAUTION: SAFETY POINTS YOU SHOULD KNOW ABOUT

* Read all of these instructions YOUR HITACHI TELEVISION RECEIVER

* Save these instructions for later use.

* Follow all warnings and instructions marked

on the television receiver.

)ur reputation has been built on the quality,performance, and ease of service of HITACHI television receivers.

Safety is also foremost in our minds in the design of these units. To help you operate these products properly,this section illustrates safety tips which will be of
benefit to you. Please read it carefully and apply the knowledge you obtainfrom it to the proper operationof your HITACHI television receiver.

Please fill out your warranty card at once and mail it to HITACHI. This will enable HITACHI to notifyyou promptly inthe improbable event that a safety problem
should be discovered in your model of product.

FORYOUR PERSONAL SAFETY 7.

1. This television set is equipped with a polarized

alternating-current line plug (a plug having
one blade wider that the other.) This plug will

fit into the power outlet only one way. This is a

safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug.

If the plug should still fail to flt, contact your
electrician to replace your obsofete outlet. Do

not defeat the safety purpose or the polarized
plug.

2. When the power cord or plug is damaged or

frayed, unplug this television set from the well
outlet and refer servicing to qualified service

personnel.

3. DO not overload wall outlets and extension

cords as this can result in fire or electric shock.

4. Do not allow anything to real on or roll over the
power cord, and do not place the TV where the

power cord Issubjecttotrafficor abuse. This
may resultina shock or firehazard.

5. DO not attempt to service this television set
youraeff as opening or removing covers may
expose you to dangerous voltage or other haz-

ards. Refer all servicing to qualified service

personnel.

6. Never push objects of any kind into this televi-

alin set through cabinet slits as they may

touch dangerous voltage points or short out
parts that could result in a fire or electric
shock. Never spill liquid of any kind on the
television set.

If the television set has been dropped or the
cabinet has been damaged, unplug this tele-

vision sat from the well outlet and refer ser-
vicing to qualified service personnel.

If liquid has been spilled into this television
set, unplug It from the wall outlet end refer
service to qualified service personnel.

9. Do not subject your television set to impact of
any kind. Be careful not to damage the pic-

ture tube surface.

10. Unplug this television set from the wall outlet
before cleaning. Do not use liquid cleaners or

aerosol cleaners. Use a damp cloth for
cleaning.

11-1.

Do not place this television set on an unsta-
ble cart, stand, or table. The television set

may fall, causing serious Injury to a child or

an adult, and serious damage to the appli-
ance. Use only with a cart or stand recom-
mended by the manufacturer, or sold with the
television set. Wall or shelf mounting should
follow the manufacturer's Instructions, and
should use a mounting kit approved by the

manufacturer.

11-2. An appliance and cart combination should be

moved with care. Quick stops, excessive
force, and uneven surfaces may cause the

appliance and cart combination to overturn.

PROTECTION AND LOCATION OFYOUR SET

12. Do not use this television set near water, for
example, near a bathtub, washbowl, kitchen

sink, or laundry tub, in a wet basement, or
near a swimming pool, etc.

,, Never expose the set to rain or water. If the

set has been exposed to rain or water, unplug
the set from wall outlet and refer to qualified

servicepersonnel.

13. Choose a place where light (artificial or sun-

light) does not shine directly on the screen.

14. Avoid dusty places, since accumulated dust
inside the chassis may cause failure of the set
when high humidity persists,

15. The set has slots, or openings in the cabinet

for ventilation purposes, to provide reliable
operation of the receiver, and to protect from

overheating. These openings must not be
blocked orcovered.

• Never cover the slots or openings with cloth or
other material.

• Never block the bottom ventilation slots of the
set by placing it on a bed, sofa, rug, etc.

• Never place the set near or over a radiator or

heat register.

• Never place the set in a "built-in" enclosure,
unless proper ventilation is provided.

PROTECTION AND LOCATION OF YOUR SET

16-1. If an outside antenna is connected to the television set, be sure the

antenna system is grounded so as to provide some protection
against voltage surges and built up static charges, Section 810 of
the National Electrical Code, NFPA No. 70-1975, provides informa-
tion with respect to proper grounding of the mast and supporting
structure, grounding of the lead-wire to an antenna discharge unit,
size of grounding conductors, location of antenna discharge, con-
nection to grounding electrode, and requirements for the grounding

electrode,

,,.=

UNIt

(t,IECSEC'rlO_a10-20)

16-2.

Note to CATV system Installer:

(Only for the television set with CATV reception)
This reminder is provided to call CATV system

installer's attention to Article 820-40 of the NEC
that provides guidelines for proper grounding

and, In particular, specifies that the cable ground
shall be connected to the grounding system of
the building, as close to the point of cable entry

as practical.

17. An outside antenna system should not be located
in the vicinity of overhead power lines or other
electrical lights or power circuits, or where it can
fall into such power lines or circuits. When
installing an outside antenna system, extreme

care should be taken to keep from touching such
power lines or circuits as contact with them might

be fatal.

IMPORTANT

_r:Ct,_:CTrON8_0211

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL

CODE INSTRUCTIONS.

OPERATION OFYOUR SET

19.This television set should be operated only from the
power source Indicated on the marking label. If you
are not sure of the type of power supply at your

home, consult your television dealer or local power
company. For television sets designed to operate

from battery power, refer to the operating instruc-
tions.

IF THE SET DOES NOT OPERATE PROPERLY

22. If you are unable to restore normal operation by fol-

lowing the detailed procedure in your operating
instructions, do not attempt any further adjust-
ments. Unplug the set and call your dealer or ser-

vice technician.

18. For adeed protection for this television set during
a lightning storm, or when It is left unattended

and unused for long periods of time, unplug it
from the well outlet and disconnect antenna. This

will prevent damage due to lightning and power-

line surges.

20. If the television set does not operate normally by
following the operating instructions, unplug this

television set from the well outlet and refer servic-
ing to qualified service personnel. Adjust only
those controls that are covered in the operating
instructions and Improper adjustment of other con-
trols may result In damage and will often require
extensive work by a qualified technician to restore
the television set to normal operation.

21. When going on a holiday: If your television set is to
remain unused for a period of time, turn the televi-

sion set "OFF" and unplug it from the well outlet.

23. Whenever the television set Is damaged or falls, or
a distinct change in performance indicates a need
for service, unplug the set end have It checked by

a professional service technician.

24. It is normal for soma TV sets to make occasional
snapping or popping sounds, particularly when

being turned on _ off., If the snapping or popping
Is continuous or frequent, unplug the set and con-

sult your dealer or service technician.

FOR SERVICING AND MODIFICATION

25. Do not use attachments not recommended by the

television set manufacturer as they may cause haz-
ards.

26. When replacement parts are required, be sure the

service technician has used replacement parts
specified by the manufacturer that have the ssme

characteristics as the original part, Unauthorized

substitutions may result in fire, electric shock, or
other hazards.

27. Upon completion of any service or repairs to the
television set. ask the service technician to perform

routine safety checks to determine that the televi-
sion is in sate operating condition.

4

PI!31UHE CAUTIONS

Continuous On-Screen Displays such as
video games, stock market quotations,

computer generated graphics, and other
fixed (non-moving) patterns can cause per-

manent damage to Color Television

WARNING

Receivers. Such "PATTERN BURNS" con-

stitute misuse and are NOT COVERED by
your Hitachi Factory Warranty.

When using the Picture-in-Picture function, the sub-picture should not be left permanently

in one corner of the screen or a "PATTERN BURN" may develop over a long period of time.

This Color Television Receiver was intended mainly for the private viewing of programs

broadcast by TV stations, cable companies, and programs from other video sources. Public
viewing may require prior authorization from the broadcaster or owner of the video program.

5

ACCESSORIES

Check that you have the following accessories before disposing 0f the packing material.

1. Remote Control Unit (See Part No. below.)

2. Two "AA" size, 1.5V batteries (For Remote Control Unit).

For information regarding how to obtain these accessories, please call TOLL FREE 1-800-448-2244 for your nearest
HITACHI Authorized Parts Distributor in the continental United States. For Alaska and Hawaii, please contact your

nearest HITACHI regional office.

PART NAME PART NO. ILLUSTRATION

35CX30B

CLU-418U

REMOTE TRANSMITTER

32CXl 1B
32TX78B/79K
35TX88B/89K

CLU-419UI

REMOTE TRANSMITTER

32V TELEVISION STAND

SP316B

'Not included, order separately}

HL00234

HL00229

H530022

B

(3_r€3 [E)

(Z) (_ (_
(3DQD (3D
(D (3D(Z)

I_UT _EEP

OQO

• J

CLU418U

"B

(2£)_E_(ED

(_ r-cq lEE)

QD (3D(Z)

O_)QD

CLU-419UI

CUSTOM HITACHI

TELEVISION STAND

32V TELEVISION STAND

SP317B

'Not included, order separately)

35V TELEVISION STAND

SP351B

Not included, order separately]

The television stand models SP316B, SP317B, and SP351B are designed for use only with

CAUTION:

HITACHI TV models 32CXl 1B and 35CX30B. Use with other television equipment may result
in instability, causing possible injury.

H530023

(upgrade)

H530024

Excellent for VCR and

videotape storage. Special

r-

Features: curved smoke

glass doors, adjustable

shelf. Available in black.

I

6

REMUI'E CONTROL I ERY INSTALLATION

AND REPLACEMENT

1. Open the battery cover of the Remote Transmitter by
pushing the notched part ofthe cover with your fingers.

2. Insert two new "AA" size batteries in the remote.

When replacing old batteries, push them towards the

sprir_gsand ti_tthem out.

3. Match the batteries to the (+) and (-) marks in the
battery compartment.

4. Replace the cover.

BOTTOM VIEW

lIl:

CAUTIONS

1. Ifyour television set is to remain unused for a long period of time, for instance, when you go on vacation, unplug
the television from the wall outlet.

2. Do not subject the Remote Transmitter to shocks such as dropping it on the floor, etc. Precision parts may be

damaged.

3. Do notallowthe RemoteTransmitterto become wet andavoidplacingit in areas of high humidity.Don't leave

iton or neara heater. Excessheator moisturemaycausethe unitto ceaseoperation.

4. If the batteries become exhausted, remote control operation may become erratic or stop altogether. Replace

the old batteries with fresh "AA" (SUM-3) types.

1. The CHANNEL NO. indication, VOLUME indication and OFF TIMER indication are not displayed simultaneously.

NOTES: I

2. To operate your TV, point the Remote Transmitter at the remote sensor of the TV.

HUW TO SET UP YOUR NEW HITACHI COLOR TV

ANTENNA

Unless your TV is connected to a cable TV system or to a centralized antenna system, a good outdoor colorTV anten-

na is recommended for best performance. However, if you are located in an exceptionally good signal area that is free

from interference and multiple image ghosts, an indoor antenna may be sufficient.

LOCATION

Select an area where sunlight or bright indoor illumination will not fall directly on the picture screen. Also, be sure that

the location selected allows a free flow of air to and from the back cover of the set.
To avoid cabinet warping, cabinet color changes, and increased chance of set failure, do not place the TV where tem-

peratures can become excessively hot. For example, in direct sunlight or near a heating appliance, etc.

VIEWING

The major benefit of the HITACHIColorTelevisionis its largeviewingscreen.Tosee thisscreenat itsbest, test vari-
ouslocationsinthe roomtofind thebestspotfor viewing.The drawingsgiveseveralsuggestions.

The best picture is seen by sitting directly in front of the TV and about 6 to 9 feet from the screen. During daylight
hours, reflections from outside light may appear on the screen. If so, drapes or screens can be used to reduce the

reflection or the TV can be located in a different section of the room.

If the TV's audio output will be connected to a Hi-Fi system's external speakers, the best audio performance will be
obtained by placing the speakers equidistant from each side of the receiver cabinet and as close as possible to the

height of the picture screen center. For best stereo separation, place the external speakers at least 4 feet from the
side of the TV. Place the surround speakers to the side or behind the viewing area. Differences in room sizes and

acoustical environments will require some experimentation with speaker placement for best performance.

I ,_CAUTION:

_IMUM

,

3' 6' 9'

The magnetic field of external speakers may cause the picture to distort if the speakers are I
placed too close to the television. Move the speakers away from the TV until there is no

picture distortion.

4' MI_NII_UM

8

I

HOW TO SET UP YOUR NEW HITACHI COLOR TV

I

Before installing (Geomagnetism Correction) 35 inch CTV only.

ThisTV hasa super-largecolorpicturetube. The effectsof geomagnetismmay causean uneven(partially)colored
picturedependingonthe directionwhichtheTV isfacing. AdjusttheTV as followsfor best performance:

1. Turnthepower"OFF".

2. Decideon theinstallationpositionanddirectionoftheTV. Checkthe directiontheTV isfacingatthis time.

3. Set the DIRECTION and STRENGTH switches(on back ofthe TV) accordingto the direction of thescreen as

showninthe table.

i

TV

DIRECTION

>

FACING

SCREEN DIRECTION

North

Northeast

East

Southeast

South

Southwest

West

Northwest

* If the Screen is facing a
**If the

Screen is facing a Southerly directionr set to "S",

DI RECTION STR ENGTH

* E/W WEAK

E/W WEAK

* * E/W WEAK

* * E/W WEAK

E/W WEAK

*E/W WEAK

Northerly direction, set to "N".

SWITCH

N STRONG

S STRONG

4. Aftersettingthe switches, placetheTV inthe decidedlocation.

5. AfterrelocatingtheTV,turnthepower"ON" andcheckto makesurethatthe screencolor(especiallyat the cor-
ners) is even. Dependingon the installationlocation(especiallywhereit is susceptibleto geomagnetism,for

example,ina reinforcedconcretebuilding.),inthiscase,settheDIRECTIONand STRENGTHswitchestosetthe
optimumpicture.

6. In certainareas, if the screenpointsNorthor South,colorunevennessmay be reducedwhen the STRENGTH
switchissetto STRONG ratherthanWEAK.

NOTE: IfyoumoveyourTV,the DIRECTION andSTRENGTH switchesmay needto be reset. I

.

I

V_EO I VIDEO

I

VHF/UHF

O

O"

/gJ040

011©1

iAUOIO I AUDIO

i

I

HOOKUP CABLES AND CONNECTORS

Most video/audio connections between components can be made with shielded video and audio cables that have
phono connectors. For best performance, video cables should use 75-Ohm coaxial shielded wire. Cables can be pur-
chased from most stores that sell audio/video products. Below are illustrations and names of common connectors.
Before purchasing any cables, be sure of the output and input connector types required by the various components.

Also make sure the cabtes are the correct length.

300-OhmTwin Lead Connector
This outdoorantenna cable must be connectedto an

antennaadapter (300-Ohmto 75-Ohm).

"F" Type 75-Ohm Coaxial Antenna Connector
For connecting RF signals (antenna or cable TV) to the

antenna jack on the television.

@

Phono Connector
Used on all standard video and audio cables whichcon-

nect to inputs and outputs located on the Television's
rear jack panel and front control panel.

ANTENNA CONNECTIONS
These sets are equipped with one VHF/UHF antenna terminal. The VHF/UHF terminal can be used for normal TV,

cable TV (CATV), a TV game, etc.

_. VHF (75 OHM) ANTENNA/CATV
When using a 75 Ohm coaxial cable system, disconnect

the VHF adaptor from the VHF 75 Ohm receptacle and
connect the outdoor antenna or CATV cable to a VHF

75 Ohm receptacle.

To outdoor antenna or CATV cable

VHF/UHF

7sOh,. I I _. _L (disconnect)

C°axlal CabJ-_ L_I_ P

t _ _ (_,_._y._FAdapter

S-Video (SuperVideo) Connector
Thisconnectoris usedoncamcorders,VCR's andlaser
disc players with an S-Video feature in place of the
standardvideocableto producea highqualitypicture.

3. When both VHF and UHF antennas are connected
Attach an optional ANTENNA MIXER to the TV antenna

terminal and connect the cables to the ANTENNA MIXER.

(RearofI"VSet) VHF/UHF

ToUHFAntenna VHF antenna

t_) To outdoor

t t

ANTENNA_ '{"_'J_ _='_//
MIXER

i

2. VHF (300 Ohm) antenna/UHF antenna
When usinga 300 Ohm twin lead from an outdoor

antenna disconnectthe (VHF or UHF) indoorantenna leads
from screwsof the (VHF or UHF) adaptor, and connect
outdoor(VHF or UHF) antenna leads to these screwsof a

VHF or UHF) adaptor.

_'_,,. U (connect)

t To outdoor VHF

or UHF Antenna

(_,_F Adapter

Notes:

1. If an outdoor antenna/CATV is to be used, disconnect

the indoorantenna. Do not leave both the indoorand

outdoorantennas/CATV connectedat the same time,

sinceghostingand poor receptionmay result.

2. Consult your dealer or service store for the ANTENNA
MIXER and (VHF or UHF) adaptor.

3. The specialconverter(decoder) willbe suppliedby the

cablecompany.

10

FRONT PANEL CONTROLS FOR 32CX11B

FRONT VIEW

I I _ l looooo_o I • I I II

I o' .... II

HOW TO OPEN THE DOOR

1. Push on "_"

2. Pull the door toward the front to open it.

FRONT INPUT JACKS

I INPUT3 I

© 0 ©

Vl0EO LII_ONO -- R -- _UOIO

J

©

I

'_ V @ RemoteControl

' InfraredSensor

® @ @

InputButton VolumeButtes Channel Buttons

O00O 0

MENU • I_ • • See page 28 and 30 for

J I I I I I

EXIT-_ I I I I MENU, CURSOR, and EXIT

CURSOR buttonoperation

Powsr

Button

A detailed explanation of the circled numbers is on the following pages. (example: @)

11

I

FRONT PANEL GONTROL,'5 I=OR 32TX78B AND 32TX79K

FRONT VIEW

DOOR

HOW TO OPEN THE DOOR

1. Push letters "PUSH OPEN' on the door.

Q RemoteControl

InfraredSensor

2. Pull the door toward the front to open it.

INDOOR CONTROLS

© ® ®

FRONT INPUT JACKS

I INPUT3 I

© O ©

Vl0EO tl_ -- _-- _u_o

(_) Video:3Input--j

A detailed explanation of the circled numbers is on the following pages. (example: (_))

I

MENU • D, • • See page 28 and 30 for

J I I I I I

EXIT-----J I I I I MENU, CURSOR, and EXIT

CURSOR button operation

12

FRONT PANEL CONTROLS FOR 35CX30B

FRONT VIEW

I

\!;- t__l_=ooo......oooo_.It- -_

....i

-j

N=UT V_.Ul_ CV_N_L

000000 o o

A detailed explanation of the circled numbers is on the following pages. (example: @)

I NOTE: Model 35CX30B does not have a front panel control for MENU, EXIT, and CURSOR buttons.

_T_ _

L_)_INPUT3 I _1

® wdoo:31._t--I

13

I

FRONT PANEL CONTROLS FOR 35TX88B AND 35TX89K

FRONT VIEW

DOOR

A detailed explanation of the circled numbers is on the following pages. (example: (_))

I NOTE" Models 35TX88B and 35TX89K do not have a front panel control for MENU, EXIT, and CURSOR buttons. I

14

FRONT PANEL CONTROLS

INPUT Selector

Press this button to select the current antenna source or VIDEO: 1, 2, 3. Your selection is shown in the top right

corner of the screen.

(_) VOLUME Level

Press these buttons for your desired sound level. The volume level will be displayed on the TV screen.

(_ CHANNEL Selector

Pressthese buttons untilthe desired channelappearsinthetoprightcornerof theTV screen.

(_) POWER Button

Pressthisbutton to turntheTV on oroff.

NOTE: Your HITACHI TV will appear to be turned "OFF" if there is no video input when VIDEO: 1, 2, or 3 is

selected. If you have no input to VIDEO: 1, 2, or 3, press the INPUT button until the normal broadcast
picture appears. (See page 28.) If the picture does not appear, the power is "OFF".

(_ REMOTE CONTROL INFRARED Sensor

Pointyour Remote Transmitter at this area when selecting channels, adjusting volume, etc.

(_) FRONT INPUT JACKS

Usethese audio/videojacksfora "quick" hook-upfroma camcorderor VCRtoinstantlyviewyourfavoriteshow
or new recording,(Pressthe INPUT buttonuntilVIDEO: 3 appearsinthe toprightcornerof the screen.)

I NOTE: Front panel control CURSOR operation will not operate the FAMILY FAVORITES channel function. I

15

FRONT PANEL JACKS AND CONNECTIONS

The front panel jacks are provided as a convenience to allow you to easily connect a camcorder or VCR as shown in
the following examples:

Video Camera

_ OUTPUT

INPUT INPUT

Insert audio cable
into left channel

for mono sound

Video Camera

OUTPUT

000 0

wo_o L/l_o_o 1 RIAL_ Vt0EO AU0tO

/ / /

NOTE:

_o

NPUT

(BackofVCR)

Completely insert the connection cord plugs when connecting to front panel jacks. If you do not, the

picture that is played back may be abnormal.

16

I

I

REAR PANEL JACKS

-- AUDIO to HI-FI OUTPUT _3)

AIJ_O INPUT;t IN_T I

rOHIR

TERMINALS

INPUT TERMINALS Q

VIDEO _O_O

@©

S-VIDEO

VHF/UHF s_,uo_o AUOIO AUDIO

I

Q VHF/UHF ANTENNA TERMINAL

(_ S-VIDEO INPUT

(_ Antenna Inputs

The VHF/UHF terminal can be used for normal TV, cable TV (CATV), a TV game, etc.

(_ AudioNideo Input

The "INPUT" buttonwillstepthrough each videosourceand antennasourceinputeach time it is pressed. Use
the audio and video inputsto connectexternaldevices,suchas VCR's, camcorders,laserdiscplayers,video

games,etc. If your devicehasonlyone audiooutput(monosound),connectitto theleftaudiojack on theTV.

Audio to HI-Fi

These jacks provide variable audio output to a separate stereo system amplifier. With this connection, the audio

to the stereo can be controlled by the televisions remote control. Use these jacks for the SURROUND Left and
Right channels. (See pages 21 and 24.)

(_ S-Video

INPUT 1 provides S-Video (Super Video) jacks for connecting equipment with S-Video output capability.

The S-Video connection is provided for high performance laser discs,VCR's etc., that have this feature. Use this
connection in place of the standard video connection if your device has this feature.

the operating guide of your other etectronic equipment for additional information on connect-

to

Refer

NOTE:

ing your hookup cabtes.

/

_1

17

32CX11B

32TX78B

32TX79K

REAR VIEW

AUDIO to HI-FI OUTPUT Q
TERMINALS

INPUT TERMINALS O

REAR PANEL JACKS

O VHF/U'HF ANTENNA TERM INAL

(_ S-VIDEO INPUT

I

VHF/UHF ANTENNA TERMINAL

18

AUDIO to HI-FI OUTPUT _ 35TX89K
TERMINALS

w_ _o_ EJw

INPUT TERMINALS _'_

(_ S-VIDEO INPUT

35CX30B

35TX88B

STORAGE COMPARTMENT FOR THE 32TX78B, 32TX79K,
35TX88B, AND 35TX89K

ThisTV is equipped with a VCR storage compartment. Followinstructions below for door operation and VCR installation.

®

! i!

DOOR

®

I !

Push door to rear.

Press lower right corner
of door to release

magnetic latch. Gently
lift door from bottom.

®

Gently push door to

full back position.

\

I

Raise door to full
horizontal position.

®

Install VCR into VCR
storage compartment. Feed

power cord and AN wires
through opening in back of

VCR storage compartment.

TO CLOSE DOOR

Gently pull door to full forward horizontal position. Lower door to vertical position and gently press lower right corner

of door to engage magnetic latch.

19

REAR PANEL CONNECTIONS

!_.__ ...... Outside antenna or

_ _------ 2-way signal splitter

cable TV coaxial cable

V L R

OUTPUT

Optional,seetips
onpage17.

Laserdiscplayer,VCR,

camcorder,etc.

$-VHS V L R

OUTPUT

Stereo System Amplifier

Typical full feature set-up. Follow connections that pertain to your personal entertainment system.

20

EXTERNAL CONNECTIONS

CONNECTING EXTERNAL AUDIO AMPLIFIER

To control the audio level of an external audio amplifier with the Remote Transmitter, connect the system as shown
below in Fig. 1.

I NOTE:

(REAROFTV SET) AUDIO

u

AUDIOTO HI-FITERMINAL ITOHI-FI

TO AUDIO INPUT TERMINA._(
OF EXTERNAL AMPLIFIER

w

EXTERNAL

SPEAKERS

| ....... I

AUDIO AMPLIFIER

EXTERNAL

SPEAKERS

To prevent damage to the speaker and distorted sound, set the volume control of the audio amplifier
lower and adjust the sound using the Remote Transmitter of the TV set.

21

CONNECTING EXTERNAL VIDEO SOURCES

The exact arrangement you use to connect the Video Cassette Recorder, Video Disc Player and Video Camera to your
TV set is dependent on the model and features of each component. Check the Owner's Manual of each component

for the location of its video and audio inputs and outputs. The following connection diagrams are offered as sugges-
tions. However, you may need to modify them to accommodate your particular assortment of components and fea-
tures. For best performance, video and audio cables should be made from coaxial shielded wire.

Before Operating External Video Source
The input mode is changed every time the INPUT button is pressed as shown below. Connect external source to the

INPUT terminal, then press the INPUT button as necessary to view the input source. (See page 28.)

INPUT MODE SELECTION ORDER

{Antenna) !lnput)

121 _I VIDEO

NOTE: When the TV is set to "VIDEO" and a video signal is not received from VIDEO INPUT JACK on the jack

panel of the TV (i.e., VCRNideo Disc Player, etc. is not connected or the video device is OFF), the
screen will be grey-blue.

CONNECTING MONAURAL AUDIO VCR OR VIDEO DISC PLAYER

1. Connect the cable from the VIDEO OUT of the VCR or the Video Disc Player to the INPUT (VIDEO) jack on the TV
set. (Fig. 1)

2. Connect the cable from the AUDIO OUT of the VCR or the Video Disc Player to the INPUT (MONO)/L(AUDIO) jack.

3. Press the INPUT button to view the program from the VCR or Video Disc Player. The mode "VIDEO" disappears

automatically after approximately 8 seconds.

4. Press the INPUT button to return to the previous channel.

5. See below.

Video Cassette Recorder

f ",,,,

TV INPUT

'ERMINAL

INPUT

VIDEO

MQNO)

VIDEO OUT AUDIO OUT

II I I

AU DIO

FIG. 1

22

CONNECTING EXTERNAL VIDEO SOURCES

I II

CONNECTING STEREO VCR OR STEREO VIDEO DISC PLAYER

1. Connect the cable from the VIDEO OUT of the VCR or the Video Disc Player to the "INPUT (VIDEO)" jack on the

TV set. (Fig. 1)

2. Connect the cable from the AUDIO OUT "R" of the VCR or the Video Disc Player to the "INPUT(AUDIO/R)" jack.

3. Connectthe cablefrom theAUDIO OUT "L" oftheVCR orthe VideoDiscPlayer to the "INPUT(AUDIO/L)"jack.

4. Press the INPUT buttontoview the programfrom theVCR orVideo DiscPlayer.The mode "VIDEO" disappears

automaticallyafterapproximately8 seconds.

5. Press the INPUT button to return to the previous channel.

Video Cassette Recorder

J' : '.,='" -'L

TV INPUT

TERMINAL

INPU..._I

VIDEO

rMONO_

% , , /

VIDEO OUT AUDIO OUT

NOTE:

AUDIO

FIG. 1

•rv INPUT

tti,

8-VH8 V L R

@ ®®

OUTPUT

BACK OF VCR

HITACHI MODEL VT-S7G1A
or dmlw modal

TERMINAL

Completely insertthe connectioncordplugswhenconnectingto REARpanel jacks. If you do not the

picturethatis playedbackwillbe abnormal.

If you have an S-VHS VCR, use the S-INPUT cable in place ofthe standard video cable.

A s_,ngteVCP, can be used forVCR #1 and VCR #2, but note that a VCR cannot record its own video or
line output. (INPUT: 1 in example on page 20.) Refer to your VCR operating guide for more information

on "line" input-output connections.

23

AUDIO SYSTEM SET-UP

Match the numbers below to the diagram lor speaker placement and refer to the table for the different surround sound
requirements. (See page 54 for SURROUND functions.)

(_) The television's internal speakers.

(_ These speakers are connected to a separate audio amplifier. Use the "Audio to Hi-Fi" output on the TV.

LR
OUT IN

STEREO SYSTEM I

AMPLIFIER

SURROUND

FEATURE

OFF

SIMULATE

MUSIC

MOVIE

REQUIRED

CONNECTION

(b
(D

OPTIONAL

CONNECTION

Q

(b

EFFECT

Receive mono and stereo sound.

At mono input, sound will be louder.

At stereo input, sound of music will be louder.

Surround channel added to left and right audio
amplifier speakers.

Movie theater reproduction, surround channel
added to left and right audio amplifier speakers.

24

THE REMOTE CONTROL (CLU-418U)

In addition to controlling all the functions on your HITACHI Color TV, the new remote is designed to operate different

types of VCR's, CATV (Cable TV), and satellite converters with one touch. Basic operation keys are grouped togeth-

er in one area.

To operateyourTV, point the remote at the remotesensorof theTV and press theTV button on the remote. The

remotewillnow controlyourTV.

To operate your VCR, point the remote at the remote sensor of the VCR and press the VCR button. The remote will

now control your VCR. (See page 34 for instructions on how to program the remote to control your VCR.)

To operateyourcable/satellitebox,point the remoteat the remotesensorof the cable/satelliteboxand pressthe
CABLEbutton.The remotewillnowcontrolyourcable/satellitebox. (See page36 forinstructionsonhowto program

the remoteto controlyourcable/satellitebox.)

"

®

HELP THEATER TV/VCR

®
®

HOME

®

@

Thesebuttonsallowthe remoteto controlyourTV,
VCR, or cable/sateUitebox dependingon which

modeischosen,as explainedabove.
TV/VCR Button

®

Whenthe remoteis intheTV orVCR mode,thisis
the TVNCR button. When the remote is in the
CABLE/SATELLITEmode,thisIsthe A/Bbutton.

VOL CH

03(!3(i)

(X) (D

(X) (X) (D

INPUT SLEEP

OCDO

HITACHI

CLU-418U

(_ PRECODEDVCR Buttons

Thesebuttonsalwaystransmitthe chosenprecod-
edVCR codes.

HELP Button

®

Hitachi'snew remotecontrolsnow have a HELP

button.Simplypressthisbuttonifhelpisneededto
changemenusettings,andour new contextsensi-
tive Help systemwillprovideexplanationsand/or

directionsfor whateverfunction yourcursorisonat
thattime.

HOME THEATER Button

This button allows direct access to the SUR-

ROUND functions.

J

25

THE REMOTE CONTROL (CLU-419UI)

In addition to controlling all the functions on your HITACHI Color TV, the new remote is designed to operate different

types of VCR's, CATV (Cable TV), and satellite converters with one touch. Basic operation keys are grouped togeth-
er in one area.

To operate yourTV, pointthe remoteat the remote sensorof the TV and press the TV buttonon the remote. The

remotewillnowcontrolyourTV.

To operateyourVCR, pointthe remote at the remotesensoroftheVCR andpressthe VCR button. The remotewill
nowcontrolyourVCR. (See page34 for instructionsonhowto programtheremotetocontrolyourVCR.)

To operate your cable/satellite box, point the remote at the remote sensor of the cable/satellite box and press the
CABLE button. The remote will now control your cable/satellite box. (See page 36 for instructionson how to program
the remote to control your cable/satellite box.)

(_ These buttons allow the remote to control your TV,

VCR, or cable/satellite box depending on which
mode is chosen, as explained above.

TV/VCR Button

®

When the remote Is In the TV or VCR mode, this is

the TVNCR button. When the remote is in the
CABLE/SATELLITE mode, this is the A/B button.

®

.... -HOME

HELP THEATER "FVNGR

®
®

®

I !

I REC I'_ PAUSE_l

C) Q

CDGD

OO( )

INPUT SLEEP

(_ PRECODED VCR Buttons

These buttons always transmit the chosen precod-
ed VCR codes.

®

HELP Button

®

Hitachi'snew remotecontrolsnow have a HELP

button.Simplypressthisbuttonifhelpisneededto
changemenusettings,andour new contextsensi-
tive Help systemwill provideexplanationsand/or
directionsfor whateverfunction yourcursorison at

®

(_(_ LIGHT Button

L

T

thattime.

When you are in a dark room, press this button on
the side of the remote to light up the buttonsshown
in (_). The light will stay on for about 8 seconds if
the light button is not pressed again. These buttons
will not appear to light ifthe room is too bright.

(_ HOME THEATER Button

This button allows direct access to the SUR-

ROUND functions.

HITACHI

CLU-419UI

26

HOW TO USE THE REMOTE TO CONTROL YOUR TV

A detailed explanation of the circled numbers is on the following pages. (example: @)

HELP THEATER TVNCR

REC _ PAUSE

t

INPUT l I SLEEP

HOME

LST-CH

I

f(_),

I I

®

h8

I/Q oH

iJ_"___.©_11

®
@

-_Q

®

®

t

®

t

',(!) G) (D

!

',(2)(!)0

INPUT I I SLEEP

I0 (D (D

®

0 ',_Q_',0

T

®

HITACHI

CLU-418U

HITACHI

CLU-419UI

27

HOW TO USE THE REMOTE TO CONTROL YOUR TV

(_TV POWER Button

Press this button to turn the TV set on or off.
turned on. (See page 48.)

(_) SLEEP Button

Press this button to displaythe SLEEPTIMER in the lowerleftcornerofthe screen. Everysubsequentpressof

thisbutton will add 15 minutes tothe timer,upto a maximumof3 hours.

(_) MENU, CURSOR

All the On-Screen Display features can be set or adjusted by using these buttons.

The "MENU" button willstartthe On-ScreenDisplay.
The "CURSOR" buttonswillhighlightfunctionsor adjustandsetdifferentfeatures. Pressingthecursorbuttonwill

alsogiveyouaccessto the FAMILYFAVORITESCHANNELS On-ScreenDisplay.

(_ CHANNEL SELECTOR Buttons

Enter two or three numbers to select channels. Enter "0" first for channels 1 to 9.
For channels 100 and above, press the 1 buttonand wait for 2 seconds before pressing the last two digits of the

channel.

Channel selectionmayalsobe performedbypressing CH up(&) or down(V).

You may also use these buttons for channel scanning. Press and hold the CH up (A) or down (V) button and

the'IV will start quickly scanning through the channels. Release the CH up (A) or down (V) button when the TV

scans to the channel you wish to watch and the TV will tune to that channel.

If ON/OFF TIMER is set, it will be displayed when the TV is first

I NOTE" The TV may n°t receive s°me channels if Y°U are n°t in the c°rrect SIGNAL SOURCE m°de' (SeeIpage 41.)

(_ INPUT Button

The INPUT button will select between the antenna signal and the video input jacks each time the button is

pressed. If the Picture-in-Picture (PinP) is on, the INPUT will not select any source signal on the main picture.
However, if the PinP is on, the INPUT will alternate between the main signal source and the input source on the

sub-picture. (See graphic below.) (See page 31.)

INPUT

f _IDEO:I

t

INPUT

t VIDEO:2

INPUT

I

INPUT

(S-IN)

28

HOW TO USE THE REMOTE TO CONTROL YOUR TV

(_ VOLUME, MUTE Buttons

Press the "VOLUME" up (A) or down (Y) button untilyou obtain the desired sound level.

To turn the sound off instantly to answer the telephone, etc., press the "MUTE" button. Press the "MUTE" button

again or press the "VOLUME" up (A) button to restore the sound.

STE _EO 28

4sllllllllllllllllll_l_"""""m

The word "MUTE" will remain displayed ifthe CLOSED CAPTION feature isturned off.

The word "MUTE" will not be displayed if the CLOSED CAPTION feature is on.

M'rv

UME

O LAST CHANNEL (LST-CH)button

Usethisbutton to selectbetweenthe lasttwochannelsviewed. (Goodforwatchingtwosportingevents,etc.)

STEREO

LST-CH

STEREO 39

(D

(_ PICTURE-IN-PICTURE

See separate section on page 31 for a description.

29

HOW TO USE THE REMOTE TO CONTROL YOUR TV

(_ LIGHT Button (CLU-418U does not have a light button.)

When you are in a dark room, press this button to light up the volume and channel buttons. The lightwill stay on
for about 8 seconds if no buttons are pressed. The buttons will not appear to light if the room is too bright.

(_) HOME THEATER Button

Press the HOME THEATER button to directly access the SURROUND function. (See page 54.)

(_ EXIT/RECALIJCOMMERCIAL SKIP Button

Press this button when no menu is displayed when you want to check the channel being received, or if it has

stereo (ST) or second audio (SAP).

Youcan alsocheckthe time,CHANNEL ID,and ifthe SLEEPTIME has beenset.
Whenin MENU mode,this buttonwillexitall On ScreenDisplays.

Pressthisbuttontwicequickly,whennomenuisdisplayed,to enabletheCOMMERCIALSKIP (CS)function.This

willtune theTV tothe lastchannelviewedand after30 seconds,tunebacktothe originalchannel.

AudioSelected

,//Antenna Source

/ Channeland

STEREO sN.l_/V_/_ I

Audio
Broadcast

ON TIMER'_:

='ON 7:00 AM TIME

,OFF 9:00 PM 10:1511:

OFF TIMER" I I oooooooI J

If a video input is used:

VideoInput

J

VIDEO:I

(S-IN)

WhenanS-Video
inputisconnected

You can also use the RECALL button to quickly clear many of the other On-Screen Displays.

3O

PICTURE-IN-PICTURE

The Picture-in-Picture feature is convenient when you want to watch more than one program at the same time. You

can watch a TV program while viewing a VCR program (TV or tape) on the video inputs.

m

Back of

"IV

-- AUDIO/VIDEO INPUT

,I_EO

o

@1
O"

_uoqo

w

,®

(_ P-IN-P Button

Pressthe "PIP" button anda sub-pictureappearsinonecornerofthescreen. Pressthebutton a secondtimeto

removethesub-picturefrom thescreen.TheTV channelwillalwaysbeeitherthe mainpictureorthe sub-picture.

Main Picture

J PIP STEREO_

SWAP Button

If you wish to switch what is being shown on the main picture to the sub-picture, press the "SWAP" button.

PIP STEREO 31

V NEWS

STISA

_-"'="--'-"- _ _ _1PIP VIDEO:I

PIP

Sub-Picture

31

PICTU RE-IN-PICTURE

(_) MOVE Button

To move the sub-picture to any location ofthe screen, press the "MOVE" button once and quickly press the CUR-
SOR buttons.

MOVE CURSOR

To move thesub-picturetoanothercorner,pressthe"MOVE" buttontwicequickly.The sub-picturemovesone
stepcounterclockwiseeverytimethe"MOVE" buttonispressedtwice.

MOVE

_) FREEZE (FRZ) Button

If youwishto freeze the sub-picture,pressthe "FRZ" button.This is convenientwhentryingtowrite downthe

addressfor a mail ordercompany,recordingstatisticsfor a sportingevent,etc. To returnthe picturetomotion,
pressthesame buttonagain.

(_) FREEZE (FRZ) Button (without a sub-picture (PIP OFF))

Press this button without a sub-picture to freeze the picture you are currently viewing. Press this button again to

return to normal viewing. The SWAP button will not work with this FREEZE function.

kEREO 31

FRZ

I ,_CAUTION: A pattern burn maydevelopifthe sub-pictureisleft inthesamecorner permanently.If the PIP

feature is usedfrequently,occasionallymovethesub-picturetoa differentcorner.

1. Onlysoundfromthemainpicturecan beheard.

2. P-IN-P will notworkwitha CHILD LOCKchannelasthe mainpicturebutwillbe displayedasa sub-picture.
NOTE: I

3. Whenthe"PIP" buttonis pressed,thesub-picturewillappearinthesame positionas previouslyset.

32

USING THE REMOTE TO CONTROL VCR FUNCTIONS

A detailed explanation of the circled numbers is on the following pages. (example: @)

f

®

®

®

®

HELP THF.ATt=R ]

PIP 5WA_ MOV_--F'RZ _ I

OOO&'

®

I

J

®

®

HITACHI

CLU-q18U

® ®

33

®

HITACHI

CLLI-419UI

USING THE REMOTE TO CONTROL VCR FUNCTIONS

Operating the pre-coded function for your VCR

This remote is designed to operate different types of VCR's. You must first program the remote to match the remote

system of your VCR. (Refer to page 37.)

1. Turn on your VCR.

2. Aim the remote control at the front of your VCR.

3. Press the VCR button to switch to the VCR pre-coded mode.

4. While holding down the VCR button on the remote, enter the 2 digit preset code that matches your VCR as shown
on page 37. The remote will turn off your VCR when the correct 2 digit preset code is entered. When this occurs,

the remote control is programmed for your VCR. If the VCR does not turn off after 5 seconds, try a different 2
digit preset code.

5. The remote will now control your VCR.

NOTES:

1. Ifyour VCR cannot be operated after performing the above procedures, this means that your VCR code has not

been precoded into the remote.

2. In the unlikely eventthat yourVCR cannotbe operatedafterperformingthe aboveprocedures,pleaseconsult

yourVCR operatingguide.

3. The remotecontrolwillrememberthe codesyouhaveprogrammedin untilthe batteriesareremoved fromthe

remotecontrol. Afterreplacingthe batteriesrepeattheentireprogrammingprocedurestated above.

4. If your VCR does not have a power function, the remote will issue the CHANNEL UP function.

(_) VCR Button

This allowstheremoteto controlyour VCR by settingittoVCR mode.

(_) PRECODEDVCR buttons

These buttons transmit the chosenprecoded VCR codes. ForsomeVCR's,you mustpressthe RECORD button
twiceto recorda program.

(_) EXCLUSIVE TV buttons

These buttons are for operating the TV.

I NOTE: Refer to the instruction manual of the VCR for operation of the buttons exclusively for the VCR. I

34

USING THE REMOTE TO CONTROL CABLE/SATELLITE
BOX FUNCTIONS

A detailed exr.'anation of the circled numbers is on the following pages. (example: @)

®

®

f

®-®i

I

:Q,Q Q

INPUT r SLEEP

O' '

®

®

® Q---

®
®

®

L

f

®

I

:0 (!) (i),'--

f I

:Q_,G_ CZ)

INPUT SLEEP

®

O: ',

!(_)j0

HITACHI

CLU-418U

HITACHI

CLU-419UI

J

35

USING THE REMOTE TO CONTROL CABLE/SATELLITE

Operating the pre-coded function for your cable/satellite box.

This remote is designed to operate different types of cable boxes and Digital Satellite Systems. You must first program
the remote to match the remote system in your cable/satellite box. (Refer to page 37.)

1. Turn on your cable/satellite box.

2. Aim the remote control at the front of your cable/satellite box.

3. Press the CABLE button to switch to cable/satellite boxmode.

4. While holding down the CABLE button, enter the 2 digit preset code that matches your cable/satellite box as
shown on page 37. The remote willturn off your cable/satellite box when the correct 2 digit preset code is entered.

When this occurs, the remote control is programmed for your cable/satellite box. If the cable/satellite box does
not turn off after 5 seconds, try another 2 digit preset code.

5. The remote will now control your cable/satellite box.

NOTES:

1. If your cable/satellite box cannot be operated after performing the above procedures, this means that your

cable/satellite box code has not been precoded into the remote.

2. In the unlikely event that your cable/satellite box cannot be operated after performing the above procedures,
please consult your cable/satellite box operating guide.

BOX FUNCTIONS

3. The remotecontrol will rememberthecodesyou haveprogrammed in untilthebatteries are removedfrom the
remotecontrol. Afterreplacingthebatteries,repeattheentireprogrammingprocedurestatedabove.

4. If your cable/satellite box does not have a power function, the remote will issue the CHANNEL UP function.

(_ CABLE Button

This button allows the remote to control your cable/satellite box by setting itto CABLE/SATELLITE mode.

(_ PRECODED CABLE/SATELLITE BOX Buttons

These buttonstransmit the chosen precoded CATV and satellite codes.

(_ TVNCR Button

When the remote is in CABLE/SATELLITE mode, this is the NB button.

_ LST-CHButton

Ifyour cable/satellite box has an enter function, this buttonwill sendthe cable/satellitebox enter code.

(_ CS/EXIT/RECALL Button

if yourcable/satellite boxdoes nothave a last channelfunction, this buttonwillsendtheTV channelrecall code.

(_) EXCLUSIVETV Buttons

These buttons are for operatingtheTV.

36

CABLE/SATELLITE AND VCR CODES

CABLE BRAND CODES SATELLITE BRAND CODES

ABC . .01,03, 05, 06, 09, 11, 12, 14, 30

Antronlx ....................... 44

Archer .................. 28, 40, 44

Belcor ........................ 31

Cable Star ..................... 31

Century ....................... 40

Citizen ........................ 40

Colour Voice ................ 19, 25

Comtronlcs ................. 29, 34

Contec ....................... 15

Dae Ryung .................... 06

Eastern ....................... 02

Electricord ..................... 37

Everquest ..................... 13

Focus ........................ 57

Garrard ....................... 40

GO Electronics ............... 31, 44

Gemini ............... 13, 32, 36, 46

General Instrument ........... 09, 51

GoldStar ................... 29, 39

Hamlin ............ 08, 16, 27, 49, 50

Hitachi ........................ 09

Hytex ......................... 05

Jasco ........................ 40

Jerrold ...... 03, 09, 10, 12, 13, 30, 51

Macom ....................... 26

Magnavox ..................... 21

Memorex ...................... 00

Movie Time .............. 35, 37, 42

NSC ................... 35, 37, 42

Oak .................... 05, 15, 47

Panasonic ............... 00, 17, 38

Paragon ....................... 00

Philips ............ 19, 21, 22, 23, 24,

................... 25, 40, 46, 54

Pioneer ................. 18, 39, 65

Popular Mechanics .............. 57

Pulsar ........................ 00

RCA ......................... 17

Realistic ...................... 44

Recoton ....................... 57

Regal ................ 16, 49, 50, 53

Regency ...................... 02

Rembrandt .................. 09, 36

Runco ........................ 00

Samsung ................... 29, 39

Scientific Atlanta ....... 04, 06, 14, 52

Signal ..................... 13, 29

Signature ...................... 09

SL Marx ....................... 29

Sprucer .................... 17, 55

Starcom ................. 03, 13, 30

Stargate .................... 13, 29

Starquest ...................... 13

StarSight ................... 58, 59

Sylvania ...................... 01

Teleview ...................... 29

Texscan ....................... 01

Tocom .................. 10, 11, 33

Toshiba ....................... 00

Tusa ......................... 13

TV86 ......................... 35

Unika ...................... 40, 44

United Artists ................... 05

United Cable ................... 03

Universal ....... 28, 31, 37, 40, 43, 44

Videoway ...................... 48

Viewstar .............. 21, 34, 35, 45

Zenith ..................... 00, 64

Zentek ......................... 57

General Instrument .............. 61

Jarrold ..................... 61, 62

Primestar ................... 61, 62

RCA ......................... 60

Sony ......................... 63

TELEVISION BRAND CODES

Hitachi ........................ 00

Megatron ...................... 00

VCR BRAND CODES

Adventura ..................... 00

Aiko .......................... 50

Aiwa ......................... 00

Akai .................... 14, 23, 49

American High .................. 09

Asha ......................... 48

Audiovox ...................... 10

Beaumark ..................... 48

Bell & Howell ................... 30

Brandt ........................ 38

Broksonlc .......... 33, 37, 43, 51, 52

Calix ......................... 10

Canon ........................ 09

Capehart ...................... 05

Carver ........................ 28

CCE ...................... 27, 50

Citizen ..................... 10, 50

Colt .......................... 27

Craig ................ 10, 19, 27, 48

Curtis Mathes ............ 09, 14, 22

Cybernex ...................... 48

Daewoo ........... 03, 05, t7, 29, 50

Daytron ....................... 05

Dynatech ...................... 00

Electrohoma ................... 10

Electrophonlc ................... 10

Emerex .... •................... 06

Emerson .... 00, 01, 10, 16, 23, 33, 37,

........... 40, 41,43, 44, 50, 51, 52

Fisher ............... 19, 21, 25, 30

Fuji ....................... 07, 09

Funai ......................... 00

Garrad ........................ 00

GE .................. 09, 22, 24, 39

Goldstar ................. 04, 10, 11

Gradiente ..................... 00

Harley Davidson ................ 00

Harman/Kardon ................. 11

Harwood ...................... 27

Headquarter ................... 18

HI-Q ......................... 19

Hitachi ............... 14, 15, 24, 31

Jensen ....................... 14

JVC .................... 02, 14, 26

KEG ...................... 10, 50

Kenwood ................ 11, 14, 26

KLH .......................... 27

Kodak ...................... 9, 10

Lloyd ......................... O0

Lloyd's ........................ 40

Logik ......................... 27

LXI .......................... 10

Magnovox .......... 09, 12, 28,32, 34

Magnln ....................... 48

Marantz .................... 09, 28

Marta .......................

Matsushita ..................... 09

VCR BRAND CODES
(Cont.)

MEI .......................... 09

Memorex .......... 00, 09, 10, 12, 18,

................... 19, 20, 30, 48

MGA ...................... 16, 23

MGN Technology ................ 48

Minolta .................... 15, 31

Mitsubishi .......... 16, 23, 26, 36, 49

Motorola ................... 09, 20

MTC ...................... 00, 48

Multitech ................... 00, 27

NEC .............. 11, 13, 14, 26, 30

Nikko ......................... 10

Noblex ........................ 48

Olympus ................... 09, 47

Optimus ................. 10, 20, 30

Orion ......................... 51

Panasonic ......... 09, 35, 46, 47, 53

Penney ...... 09, 10, 11, 13, 15, 21, 48

Pentax .................. 15, 24, 31

Philco ........................ 09

Philips ................ ...09, 28, 32

Pilot .......................... 10

Pioneer ....................... 26

Portland ....................... 05

Protec ........................ 27

Pulsar ........................ 12

Quarter ....................... 18

Quartz ........................ 18

Quasar ....................... 09

Radio Shack ................ 00, 10

Radix ......................... 10

Randex ....................... t 0

RCA ........... 15, 22, 24, 31, 34, 39

Realistic .......... 00, 09, 10, 18, 19,

................... 20, 25, 30, 48

Ricoh ......................... 08

Runco ........................ 12

Samsung ................... 17, 48

Sanky ..................... 12, 20

Sansui ..................... 14, 26

Sanyo ............... 18, 19, 30, 48

Scott .......... 16, 17, 33, 37, 43, 44

Sears ............ 09, 10, 15, 18, 19,

................... 21, 25, 30, 31

Sharp ........................ 20

Shintom ....................... 27

Shogun ....................... 48

Singer ........................ 27

Sony ................ 06, 07, 08, 09

STS .......................... 15

Sylvania ........... 00, 09, 16, 28, 32

Symphonic .................... 00

Tatung ........................ 14

Teac ...................... 00, 14

Technics ................... 09, 35

Teknika ................. 00, 09, 10

Telefunken ..................... 38

TMK ...................... 40, 48

Toshiba .............. 16, 17, 25, 44

Totevision .................. 10, 48

Unitech ....................... 48

Vector ........................ 17

Vector Research ............. 11, 13

Video Concepts ........... 13, 17, 23

Videosonic ..................... 48

Wards ......... 00, 09, 15, 19, 20, 22,

................... 27, 34, 44, 48

XR-1000 ................ 00, 09, 27

Yamaha ....................... 11

Zenith .................. 07, 08, 12

.10

37

COLOR GRAPHIC GUIDE

With Hitachi's new On-Screen Display, each category has it'sown color and Icon. This new semitransparent system
incudes SET-UP, CUSTOMIZE, VIDEO, AUDIO, and INFO CENTER categories. Using the four cursor buttons, you

can easily access and control all of the TV's functions. We also have computer-like check boxes so that you always

know which function you've chosen. You can even choose to access the menu in English, French, or Spanish.

1. Press MENU on the remote control to display the different features on

your HITACHI TV.

2. Press the CURSOR buttons to highlight and select different features.

3. Press EXIT on the remote control to quickly exit from a menu.

4. PressHELP onthe remotecontrolwhena menuis displayed,andtext

willappeargivinga descriptionof thatmenu.

This part of the screen shows

what selections are available.

sETup

I_ CUSTOMIZE

[_ VIDEO
[_ AUDIO

INFO.

CENTER

• EXIT

This part of the screen shows which
remote control buttons to use.

TO JI,.SELECT

MOVE

• (QUIT MENU

CURSOR

cs

RECALL

HELP

1

AUTOMATIC DEMONSTRATION

This feature will demonstrate how to use and set up your HITACHI television. To perform this feature, press the front
panel POWER button and hold for 5 seconds. The On-Screen Display will appear on your TV set demonstrating the

settings of your TV feature.

To exit AUTOMATIC DEMONSTRATION, press the power button on the front panel of the TV, which will turn the TV

off. Press the power button again to turn your TV set on and resume normal operation.

On some televisions, the "SHIFT" and "EXCHNG" that appear during the Automatic Demonstration are
equivalent to the "MOVE" and "SWAP" button respectively on your remote control.

NOTE:

In most cases, the MENU button is used to enter and exit the On-Screen Display.

38

I 000000 I

COLOR GRAPHIC GUIDE

MENULANGUAGE
SlGNALSOURCE

AUTO CHANNEL SET

f

CHANNELADD/DEL
CHANNELLIST

CLOCK SET

CUSTOMIZE _ ICHILDLOCK

I

ION/OFF TIMER
ICLOSED CAPTION

CONTRAST
BRIGHTNESS
COLOR

v'°'° I

"_ TINT

SHARPNESS
COLOR TEMP.
RESET

BASS
TREBLE

BALANCE
RESET

ADVANCED
SETTINGS
VOLUME

CORRECTION
SURROUND

Choose English,French,or Spanish language.

Select Antenna or cable TV.
First time set up for channel buttons.

Add or delete channel.

Check channel name, scan, and child lock.
Set before using timer features.

Label channels PAY1, ABC, etc.

Store family favorites channels.

Block channel picture and sound.

Turn TV on or off once, daily, or weekly.

Feature todisplay dialogue/text.

Adjust contrast.

Adjustbrightness.
Adjustcolor.
Adjusttint.

Adjust sharpness.
Adjust warm (red tones) or cool (blue tones).

Set VIDEO to factory preset condition.

Adjust bass.
Adjust treble.
Adjust balance.

Set AUDIO settings to factory preset condition.
Improve sound performance.

Lower volume on selected channels.

Special sound effects.

J_ INFO.

CENTER

I MESSAGES 1

39

Used to leave message or daily reminder.

tons on the remote to highlight the function desired.
Select SET-UP when setting your TV up for the first time.

SET-UP

Use the CURSOR A,V but-

I MENU LANGUAGE I This feature will allow you to select any one of 3 different languages for all On-Screen

I

Displays.

__TSET-UP

[_ CUSTOMIZE

[_ VIDEO

auo,o

[_ INFO.

CENTER

• TO •SELECT ' _ )1

• MOVE (QUIT MENU

SET-UP 1

MENU LANGUAGE ___
SIGNAL SOURCE |

AUTO CHANNEL SET |
CHANNEL ADD/DEL |
CHANNEL LIST |
CLOCK SET |

t_ to ,SE'ECT _xiT I

MOVE • BACK (QUIT MENU)J

CURSOR

ENGLISH

FRANCAIS

MENU LANGUAGE /

D ESPANOL

TO EXIT

MOVE • BACK (QUIT MENU)

UseCURSOR • or • to selectthe MENU LANGUAGEofyourchoice.

PressEXIT toquitmenuorCURSOR • to returntopreviousmenu.

40

SET-UP

SlGNALSOURCE

ICURSOR

I Select ANTENNA if you are using an indoor or outdoor antenna. Select CATV if you have

cable TV.

I _'SET-UP

_ CUSTOMIZE
!_ VIDEO :

_-] AUDIO
_] INFO:

CENTER

• TO _SELECT _T _

• MOVE (QUI'I" MENU

MENU lANGUAGE
SIGNAL SOURCE

AUTO CHANNEL SET

CHANNEL ADD/DEL

I ET.UP t

CHANNEL LIST
CLOCK SET

[€ MovETO _I,_SELECT (QUITMENUI:,_BACK

EXIT

CURSOR

_I_IANTENNA

SIGNAL SOURCE 1

: nCATV1[]CA:W2 ::.:

t,= To exrr ]
[• MOvE < BACK (QUIT MENU)]

Press CURSOR • or • to highlight and select the correct SIGNAL SOURCE mode.
Press EXIT to quit MENU or CURSOR ,q to return to previous menu.

RECEPTION BAND

CATV 1 OR CATV 2

ANTENNA

CATV CHANNEL Indicated on

Reception channels for each mode are shown at the
left.

the screen

VHF 2 ~ 13ch

UHF 14 ~ 69ch

VHF 2 ~ 13

Mid band A - I

A-5 ~ A-1

Super Band J ~ W

Hyper band

W+I -W+28

Ultra band

2-13

14 - 22

95 ~ 99

23 ~ 36

37 - 64

65 -125

Refer to your cable or TV guide for channel identifi-

cation standards.

If certain CATV channels are poor or not possible in
CATV1 mode, set SIGNAL SOURCE to CATM2.

W+29~W+B4

41

SET-UP

i i

I AUTO CHANNEL SET I This feature will automatically store active TV channels in CHANNEL ADD/DEL. This will

I

allow you to skip over unused channels when using the CHANNEL UP (A) or DOWN (V)
buttons.

SET-UP 1

MENU LANGUAGE J
SIGNAL SOURCE I._..

AUTO CHANNEL SET
CHANNEL ADD/DEL |
CHANNEL LIST |
CLOCK SET J

I A TO _1_SELECT EXIT )}

• MOVE • BACK (QUIT MENU

AUTO CHANNEL SET

_I_r'IBEOIN

SELECT EXIT 1

BACK (QUIT MENU)]

CURSOR

AUTO CHANNEL SET

[] INSTALLING

CHANNELS 100

50% COMPLETE

(QUIT MENU) I

EXIT 1

If the EXIT button is pressed while the AUTO CHANNEL SET function is engaged, programming will stop.

Remember to select the correct SIGNAL SOURCE mode before using AUTO CHANNEL SET.
See CHANNEL ADD/DEL to add or erase additional channels.

42

SET-UP

I CHANNEL ADDJDEL I

I CURSOR

Use this function after AUTO CHANNEL SET to add or erase additional channels to the
remote control CHANNEL • or • buttons.

MEN

SIGNAL SOURCE
AUTO CHANNEL SET
CHANNEL ADD/DEL

I sET-uP " 1

CHANNEL LIST
CLOCK SET

• TO _SELECT EXIT
MOVE '_BACK (QUITMENU) 1

CHANNEL ADD/DELETE -}

CHANNEL03 /

aADD _DELETE /

NEXT CHANNEL CHkCHy/

CURSOR

CHANNEL ADD/DELETE

CHANNEL 03

DADD I_IDELETE

NEXT CHANNEL CH A CH_p'

I€ NEXT •SELECT EX_

CH _ BACK (QUITMENU)

NEXT •SELECT EXIT 1

CH _ BACK (QU_

Add or erase additional channels while still in CHANNEL ADD/DEL using CURSOR • or •, CHANNEL • or •, and
number buttons and then add or erase using the CURSOR • button.

Press EXIT to quit menu or CURSOR • to return to previous menu.

43

SET-UP

I CHANNEL LIST

This function allows you to view which channels are labeled in CHANNEL ID (NAME), which

have been added to CHANNEL ADD/DEL (SCAN), and which are protected by CHILD
LOCK (LOCK).

M-ENU_QUAQE _!

S#GNALSOURCE!

CURSOR

AUTOCHANNELSEt!

CHANNEL ADD/DEL
CHANNEL LIST _J

CLOCK SET J

_-MoTOE _ SELECT EXIT

Press CURSOR • or • to view more channels.

Press EXIT to quit menu or CURSOR • to return to previous menu.

CLOCK SET

• BACK (QUIT MENU_j

JUse this feature for all time related functions. The time must be set before you can use the

ON/OFF TIMER or MESSAGE.

CHANNEL LIST

CH NAME SCAN LOCK

01 USA ON -

02 ROLY ON -

03 TESS - ON

.... JAYB .,., ON

05JEK0 ,-,,, i "t"

t O EXiT J

MOVE •eACK (aUrrMe.u)J

-- SET-UP -- 1
MENU LANGUAGE |

SIGNAL SOURCE

/

CURSOR

AUTOCHANNELSET I
CHANNELADD/DEL[
CHANNELLIST I_
CLOCKSET I_l

[A, TO _SELECT _

MOVE •BACK (QUITMENU1

LT

Use CURSOR • or • buttons to set the time and AM or PM.
Press CURSOR • to change position.

Press EXIT to quit menu or CURSOR • to return to previous menu.

I CLOCK SET }

TIME 12 : O0 PM

It TO I_SELECT EXIT ]

SET • BACK (QUITMENU)!

44

CUSTOMIZE

CUSTOMIZE

This selection contains advanced features which will make TV viewing easier and
more enjoyable.

CHANNEL ID

I

Use this feature to give up to 25 channels a name.

CHANNEL ID
FAMILY

FAVORITES

CHILD LOCK

OPTIONS

ON/OFF TIMER

CusTOMIzE l

CLOSED

CAPTION

A TO _I, SELECT EXIT

• MOVE • BACK (QUIT MENU)

CURSOR

CHANNEL ID B

Ib'B * * * D ERASE IO

i 66

NEXT CHANNEL CHA CH•

f NEXT _'$ELECT EXIT

CH • BACK (QUIT MENU)

Press CURSOR • or • to select letters.
Press CURSOR • to change character position.

Press CHANNEL • or • to select and label additional channels.
Press EXIT to quit menu or CURSOR • to return to previous menu,

The CHANNEL ID will appear in the top right corner of the screen when the RECALL button is pressed.

The (*) represents a blank space.
Select ERASE ID to erase a CHANNEL ID. An "ARE YOU SURE?" display will appear on the screen to confirm your

choice.

I NOTE: CHANNEL ID will be displayed only when channel is displayed as main picture.

45

CUSTOMIZE

JFAMILY

FAVORITES

I With Family Favorites, you can easily access your favorite Movie, Sports, News, and Custom

stations by registering any of your favorite stations into one of 4 categories. Once you have
input your four favorite stations in each category, you simply press any of the cursor buttons

and the Family Favorite's screen appears. Now you can easily switch between your 16
favorite stations.

CHANNEL ID
FAMILY

FAVORITES

CHILD LOCK

OPTIONS

ONIOFF TIMER

CUSTOMIZE 1

CLOSED

CAPTION

€ To ExrrI

MOVE (QUIT MENU)I

CURSOR

FAMILY FAVORITES 66

SPORTS

NEWS
CUSTOM

MENU EXIT(SET) (QUIT MENU)

Use CURSOR • or • buttons to highlight the categoryyou wishto registerthechannelunder.
PressCURSOR • to selectthecolumn youwishtoregisterthechannelunder.

PressCHANNEL• or • or the numberbuttonsto enterthe desiredchannel.The channelto be added is displayed
inthetop rightcornerof the screen.

PressMENU buttontoregisteryourfavoritechannel.
Repeat untilthe categoryhasbeen registeredwithyourfavoritechannels.

To erase a FAMILYFAVORITESchannel,enterO0as channelthenpressMENU button.
Once yourfavorite channelsare registeredin the FAMILYFAVORITESmenu,yourTV set willchange to thatstation

whenselected.

Press EXIT to remove FAMILY FAVORITES OSD from the SCREEN.

Afterall of yourfavorite channelsareregistered,theCURSOR buttonscan be usedfor quickaccessto

I NOTE:

the FAVORITECHANNELSmenu.

46

CUSTOMIZE

I

I CHILD LOCK

OPTIONS

I This feature allows you to block out the picture and sound of the selected channel or video

input of any channel that you feel may be inappropriate for your children. With Hitachi, there
_sno limit to the number of channels that can be locked. Your secret code allows you to rein-

state these channels any time you wish. It can also be used to schedule an amount of time
that the TV cannot be viewed.

FAMILY

FAVORITES

CHILD LOCK

OPTIONS

ON/OFF TIMER

" CUSTOMiZe

CLOSED

CAPTION

,& TO _SELECT EXIT

• MOVE _ BACK (QUIT MENU)

CURSOR

I CHILD LOCK OPTIONS ._

* * * SECRET CODE ..

l ACHANGE "SELECT EXiT ]

• NUMBER 4 BACK QU_Uff_MEN_

The code to enter CHILD LOCK is a three digit key number. The factory preset code is 000.
Use CURSOR • or • to select number or CURSOR • to change position.

CHILD LOCK OPTIONS ]

* * * SECRETCODE

I ACHANGE ,SELECT (QUIT MENU)]

IVNUMBER '_ BACK

EXIT

(Z)

I

ICURSOR

CHILD LOCK OPTIONS

ON OFF

CHAN"E V,DEO

[] [] QUICK LOCK
I-3 [] TM TIME OUT

.. : - - AM BEGIN

-- : - - AM END

* * * CHANGE SECRET CODE

CURSOR

I CHILD LOCK ON t

I¢N r .EL,CTEXIT)]CH. :_ BACK (QUIT MENU

Use CURSOR • or • to highlight function and CURSOR • to set ON or OFF.

When CHANNEL is turned on, the picture and sound for the chosen channel will be blocked out.

When VIDEO is turned on, the picture and sound for the video input will be blocked out.
When QUICK LOCK isturned on, the picture and sound for channels 3, 4 and all video input will be blocked out.

When TV TIME OUT is turned on, you can set the BEGIN and END times and the TV cannot be viewed during that

time period.

To change the key number, select CHANGE CODE. Enter a new three digit key number you prefer.

If you forget your key number, use the factory code 777 to erase your key number. This will reset the key number back

to the factory preset 000. 47

• I

I I I I

CUSTOMIZE

I ON/OFF TIMER

J Th_s functfon will automatically turn the TV set on or off one time only, every day, or once a

week. It can also be set to turn on to your favorite program, or as a reminder, to turn to your
favorite program when the TV is already on.

CHANNEL ID
FAMILY

FAVORITES

CHILD LOCK

OPTIONS

ONIOFF TIMER

CUSTOMIZ I-= t

CLOSED

CAPTION

[_ MovETO _I_;_SELECTBAcK(Qu_'X_Nu)

CURSOR

[;.ov,'O °o..o.o,j

ON/OFF TIMER

_ o-,--AM TVON

--: --AMTV OFF
CHANNEL 03

[] ONCE

[3 DAILY

[q WEEKLY
[] OFF

EXIT

Press CURSOR • or • to select either the ON or OFF TIMER.
Press CURSOR • to highlight selection to be changed.

Press CURSOR • or • to select the time the TV will turn on and off and to choose AM or PM.
Press CURSOR • to exit time setting.

Select CHANNEL and press CHANNEL • or • to set the channel the TV will tune to when it automatically turns on.
Press CURSOR • to exit channel setting.

Press CURSOR • or • to highlight then CURSOR • to select mode: ONCE(one time only), DAILY(every day), or

WEEKLY(once a week).

NOTE:

You can set either on time only or off time only, or both. The mode will be the same for both.

If the TV is turned on due to ON TIMER and there is no remote control operation in 3 hours or more,
the TV will automatically turn off.

Oo not use your TV as a deterrent when away from home by using both the ON TIMER and

I A CAUTION:

OFF TIMERS. For safety, the TV shoutd be turned ott when you are away from home.

48

CUSTOMIZE

I CLOSED

CAPTION

I Closed captions are the dialogue, narration, and/or sound effects of a television program or

home video which are displayed on the TV screen allowing you to read the dialog being
spoken (when broadcast). Your localTV program guide denotes these programs as [] or

13

CUSTOMIZE I

CHA_

FAMILY I

FAVORITES I

CHILDLOCK . J

OPTIONS

ON/OFF TIMER L_

CLOSED _,|

CAPTION

sxrr

€ TO _I_SELECT (QU EX_

MOVE _ BACK .....

DISPLAY: ON/OFF willturnthe[] displayon oroff.

MODE: C.C. (ClosedCaption)isforthe programyouareviewing.
MODE: TEXT is foradditionalinformationsuchas newsreportsor a TV programguide. Thisinformation

coversthe entirescreenand viewingtheTV programisnot possible.TEXT may notbe available
withevery[] program.

CURSOR

MOVE BACK (QUrr MENU)I

CHANNEL: 1 isusedfor theprimarylanguage(usuallyEnglish).
CHANNEL: 2 issometimesusedfor a secondlanguage(mayvaryby region).

Use CURSOR & or• to highlightthefunction tobe changed;pressCURSORI_ to changethefunction.
PressEXIT to quitmenuor CURSOR • to returntopreviousmenu.

Wueather Today

nny 70

Weather To mgrrow

A bit cooler 3
Wind Chill -55"

Text Setected

NOTE:

C.C. Setected

will not

MUTE

word

The

make sure MUTE is not set.

be

displayed

Closed Caption Display is ON. If you do not have soun_l,

if the

l

49

VIDEO

VIDEO

Select VIDEO to adjust picture settings and improve picture quality.

I

i_ [_SET-UP

I cu..o.,z

t =,EO .u)

A TO •SELECT .......

• MOVE

Use the CURSOR • or • to highlightthe function to be adjusted.
Press CURSOR • or • to adjust the function.

Press EXIT to quit menu or CURSOR • to return to previous menu.

CONTRAST
Use this function to change the contrast between black and white levels in the picture.

BRIGHTNESS
Use this function to adjust overall picture brightness.

CENTER

(Qurr

CONTRAST •".=m._-
BRIGHTNESS "'""""'"'1""",'.,..,

COLOR "".".".1"......,,

TINT i'"""iili""H""'"
SHARPNESS ,i!,,,,..,,,,I,,,,.,,,,,,..
COLOR TEMP. I_IWARM

RESET []

• MOVe 4ADJUST(QUrrMENU)

DCOOL

COLOR
Use this function to adjust the level of color in the picture.

TINT
Use this function to adjust flesh tones so they appear natural.

SHARPNESS
Use this function to adjust the amount of fine detail in the picture.

COLOR TEMP.
Use this function to adjust the white balance (hue) of the picture to your own color preference.

When shipped from the factory, this is set to "COOL". If you prefer a reddish screen, set to "WARM".

RESET
When RESET is selected, the "ARE YOU SURE?" display will appear on the screen to confirm your choice.

CURSOR.• to return VIDEO adjustments to factory preset conditions.

If CONTRAST is selected you are adjusting CONTRAST, the additional menu items COLOR, TINT,

BRIGHTNESS, SHARPNESS, and RESET can be viewed on the screen and can also be adjusted by

I NOTE:

scrolling through them using the CURSOR • orV. This is also true for all of the menu items in VIDEO.

50

Press

AUDIO

Select AUDIO to adjust the TV to your preference and to improve the sound quality.

J

1

I_ °'-'+"°'+"=I
II_ v'°'=° L_,

CURSOR

BASS _ _,

TREBLE ...........m,l,.,.m,,......

BALANCE .".m..,l,,.,.",,m,,

RESET '1"3

_vA.cE

SE'B'INGS

tI_ ,.o,o

SURROUND :i

I[_ '0";%. i

€ MovETO _SELECT (QUITMENU) I

Use the CURSOR • or • to highlight the function to be adjusted.

Press CURSOR • or • to adjust the function.
Press EXIT to quit menu or CURSOR • to return to previous menu.

BASS
This function controlsthe low frequency audioto allspeakers.

TREBLE

This function controls the high frequency audioto all speakers.

BALANCE

Thisfunction will controlthe left to right balanceofthe TV internalspeakersandthe AUDIOTO HI FI output.

EXIT

J¢

TO _ TO (QUIT MENU)JMOVE ADJ.

RESET
When RESET is selected, the "ARE YOU SURE?" display will appear on the screen to confirm your choice. Press
CURSOR • to return AUDIO adjustments to factory preset conditions.

i

NOTE:

If BASS is selected you are adjusting BASS, the additional menu items TREBLE, BALANCE, and
RESET can be viewed on the screen and can also be adjusted by scrolling through them using the

CURSOR • or •. This is also true for all of the menu items in AUDIO.

51

AUDIO

I ADVANCED

SETTINGS

I se ADVANCED SEI-rlNGS to improve the sound performance of your TV depending on

listening conditions.

BASS "_""'"_l""""'"_"_

TREBLE "'" ..........I'""""".....

BALANCE "'"'""'" "'1""'""""
RESET []

ADVANCE

SEI"rlNGS

VOLUME

CORRECTION

SURROUND

; To ; ,o ,°U-%NU,

MOVE ADJ.

CURSOR

MULTI-CHANNEL SOUND
I_STEREO MODE

I-'JMONO
I-ISECOND AUDIO PROGRAM

ON OFF

[] NOISE CANCELER

[] LOUDNESS
O INT. SPEAKERS

IA To I_SELECr F.xrr

• MOVE _ BACK (QUIT MENU)

Press CURSOR • or • to highlight a function.
Press CURSOR I_ to change the function setting.

Press EXIT to quit menu or CURSOR • to return to previous menu.

MTS MODE
Multi-Channel Television Sound (MTS) will allow you to select STEREO (Stereo Broadcast), SAP (Second Audio

Program) which may be a secondary language, weather report, etc. or MONO (Monaural Sound) used when receiv-
ing a weak stereo broadcast.

The sources received will be displayed below the channel number. The MTS mode you selected will be displayed to
the left of the channel number. See example below foreach selection when both stereo and second audio are received

(monaural is always received).

STEREO SELECTED SAP SELECTED MONOSELECTED

STEREO 31 SAP 31 31

NEWS NEWS
ST/SA

NOISE CANCELER
This function eliminates the noise in between stations. If a channel is tuned and is noisy, this function will automati-

cally eliminate the audio and video for that channel.

LOUDNESS

This function will improve the quality of both low and high frequency sounds when listening at low volume levels.

INT. SPEAKERS
This function is useful when first setting up the external speakers, or if you prefer to use only speakers from a sepa-

rate stereo system.

52

AUDIO

IVOLUME

CORRECTION

Use this function to reduce the volume level of up to four channels that sound loud com-

I

pared to other channels.

BASS IIIIIIltllllflltllllllflfltllllll

TREBLE .,.............I................

BALANCE "..............I'..........'....

RESET
ADVANCE

SETTINGS

VOLUME •

CORRECTION

SURROUND

[VA TO •SELECT eXrtMOVE • BACK (QUIT MENU)!

VOLUME CORRECTION

CH LEVEL

lOO%
lOO%

NEXTCHANNELCHA CHy

lOO%

10

CURSOR

VOLUME CORRECTION

• 80%

NEXT CHANNEL CH• CHV

lOO%

LEVEL

lOO%

1oo%

10

IA TO •SELECT EXIT

I JIi= TO _BELECT EXIT

T MOVE _ BACK (QUIT MENU)

IT ,=uiTME.U)MOVE ;_ BACK

Press CURSOR • or • to highlight one of the four volume corrections, then CURSOR _ to select.
Press CHANNEL • or • and number buttons to select a channel.

Press MENU to set the channel to be volume corrected.
Press CURSOR • or • to adjust volume level in 5% increments.

Press EXIT to quit menu or CURSOR • to return to previous menu.

NOTE:

1. Volume Correction adjustment is for the channel display in the top right corner of the screen. To
adjust a different channel, you must select the channel with the channel or number buttons and
press CURSOR _'.

2. If the channel has been corrected before, use the CURSOR • or • to highlight and CURSOR I> to
select that channel, then use the CURSOR • or • to change the level.

3. To erase a channel from volume correction, select channel 00 and press MENU.

4. The volume level will change from 50% to 100% in increments of 5%.

53

iii ii

AUDIO

I SURROUND

I

CURSOR

I he following surround sound settings will reproduce the "live" sound you would hear in

concert halls, movie theaters, etc. when you set up your speaker system as shown in the
section on rear panel connections on pages 20, 21 and 24. The surround system is most

effective with movies played on a stereo VCR.

Surround sound allows the viewer to enjoy sound which provides a feeling of "Presence"
from stereo broadcasts and VCR tapes recorded with stereo sound. Also a mono input,

simulating a stereo, will increase the sound giving the listener simulated surround sound.

B_SB . ilnltlllllllOilllliai_ll_lll

TREBLE ................I,.,..,,,,,m

BALANCE ...............'l...........m.

RESET D
ADVANCE

SETTINGS . .

VOLUME

CORRECTION

SURROUND _,

TO _ TO '_iTMOVE ADJ. (QUIT MENU)

CURSOR

_1>_1 OFF

I SURROUN°' 1

D MUS C
F-I MOVIE

r-'l SIMULATE

_ SURROUND ]

I:11 OFF I

D MUSIC l
D MOVIE I

D SIMULATE J

A TO _SELECT EXIT n

• MOVE _ BACK (QUIT MENU)I

SURROUND OFF
Use this for normal stereo/mono broadcasts.

If sound is noisy when a stereo broadcast is received, and the TV is set to the SURROUND mode,

I NOTE:

MOVIE SURROUND
Listener is surrounded by many sound sources such as a movie theater reproduction.

I NOTE: Some TV systems do not transmit optimum audio channel separation which can reduce the effective- I

MUSIC SURROUND
Resonant Sound- listener has the feeling of being in a concert hall.

At stereo input, the sound of music increases.

decrease the "TREBLE" control or turn the Surround "OFF".

ness of the MOVIE SURROUND function.

•_ TO _SELECT
MOVE • BACK (QUITMENU)I

SIMULATE SURROUND

At monoinput,soundisincreased,simulatinga stereolikeSurround.

Your VCR must be a Hi-Fi or stereo unit. See page 23 for stereo VCR connection.
Set must be outputting stereo. (See MTS Mode: STEREO on page 52.)

I

54

INFO CENTER

I_ INFO.

CENTER

MESSAGE1

I

Press CURSOR • to select MESSAGE 1 or MESSAGE 2.
Press CURSOR • or • to highlight your selections.
Press CURSOR • to select your choice.

Press CURSOR • or • to select letters or other characters.

The asterisk (*) represents a blank space.
To erase the message, use CURSOR • or • until ERASE MESSAGE is highlighted, then press CURSOR • to erase
message.

I This function allows the user to program messages in the TV.

maximum of 31 characters. The user can program the message to appear one time only or

I Use this function to program one or two personal messages in your TV's memory up to a

every day.

I [_'SET-UP

AUD,Ol_

INFO •

t[_ CENTER •1

• TO )'SELECT EXIT

• MOVE , (QUITMENU) 1

nMESSAGE 1 [7 MESSAGE 2

CURSOR

OERASE MESSAGE 1

MODE (ARE YOU SURE?)

[] ONCE
[] DAILY

I_1 OFF

- - :- -AM

l; ,o.'O °o....o,!

Press CURSOR • or • to choose MODE orTIME.
Press CURSOR • to set MODE when it is highlighted.

Press CURSOR • or • to set the time.

Press EXIT to quit menu or CURSOR • to return to previous menu.

NOTE:

At the selected time, the message will be displayed until a remote control button is pressed.

Message 2 works in the same way as Message1.

EXIT

55

[] MESSAGE t [] MESSAGE2

DERASE MESSAGE 1

MODE

I_ ONCE

[] DAILY
[] OFF

--:--AM

• CHANGE _lpSELECT EXIT /

• LE'n'ER • BACK (QUIT MENU_

USEFUL INFO

DO

Make sure the TV is turned off when cleaning the screen.

Dust the screen and cabinet with a soft cloth.

Clean the screen with a soft cloth moistened inwarm water. Dry with a soft cloth ( A mild soap may be used if the
screen is extremely dirty).

PlaceyourTV and remotecontrolawayfromextreme heat,humidityand extremelydusty places.

Remove the plug from the wall outlet if your television will not be used for a long period of time, for instance, when

you go on vacation.

DO NOT

Do not clean your screen or cabinet with strong cleaners, polishes, or chemically treated cloth.

Do notplace rubber or vinylproductsor cellophanetape on yourset.

Do not touch the screen too often.

Do notsubjectthe remotecontroltoshockssuchasdroppingitonthe floor, etc. Physicaldamage to the precision

parts may result.

Avoidplacingthe remote controlin a highhumidityplace or gettingit wet. Don't leave it on or near a heater.
Excessiveheator moisturemaycausetheunittocease operation.

Whenthe batteriesrundown,remotecontroloperationwillbecomeerraticorpossiblystopaltogether.Replacethe

oldbatterieswithtwofresh "AA" sizebatteries.

56

USEFUL INFO

• ".-':.-'.'_-:'i_ _'. '_":iii=f.___.:._I " BlaGcNITIpOtN NrOhSorE:zontalstreaks may appear, picture may flutter or drift.

...... :i_i!....... _'-.'-.".."-.

"."---_ _iiiiii;il Usually caused by interference from automobile ignition systems, neon

lamps, etectricat drills, and other electrical appliances.

• GHOSTS:
Ghosts are caused by the television signal following two paths. One is the

direct path and the other is reflected from tall buildings, hillsor some other

objects. Changing the direction or position of the antenna may improve

reception. Ghosting may also be caused bydefects in the antenna system
such as unshielded leads or committing several sets to the same antenna
without using multiple antenna couplers.

• SNOW:

If your receiver is located in the fringe area of a television station where the

signal is weak, your picture may be marred by the appearance of small

dots. When the signal isextremely weak, it may be necessary to install a

special antenna to improve the picture.

• RADIO FREQUENCY INTERFERENCE

The interference produces moving ripples or diagonal streaks, and in some

cases, causes loss of contrast in the picture.

57

SYMPTOMS

NO Picture, no sound • • • • •i• •

Sound OK, picture poor • • • • • • • •

Picture OK, sound poor • • • • • • •

Picture blurred • •: •i • • •

Lines or streaks in picture • • • •

Poor reception on some channels • • • •

No color • • • • • •

USEFUL INFO

Poor color • • • • • • •

ii

This Color Television incorporates advanced power surge protection technology designed to protect against com-
ponent or circuit damage due to internal voltage or power surges.

IF YOUR SET SHOULD APPEAR TO HAVE A LOSS OF POWER, PLEASE FOLLOW THIS PROCEDURE:

1) Pushthepower switch(ON/OFFswitch)once.

2) If there isstillno power,wait30 secondsandpushthepowerswitchagain.

3) If thereis stillnopower,unplugthepowercordfrom thewall.Waitthirtysecondsandplugthepowercord

backin.Pushthe powerswitchagain.

This protective technology should provide for years of lasting entertainment from your Color Television.

58

USEFUL INFO

Featu res:

• Superfine Picture Quality
700 Line Horizontal Resolution

• Dark Tint CPT with Self Dynamic Focus Gun except 35V (Dark Tint CPT)

• Remote Transmitter

(Controls many VCR, Cable Box, and Satellite Brands)

• P-in-P Functions

• ICONS: Color Graphic Guide

• Full set of Input Jacks, including S-Video

• Closed Caption Decoder

• Comb Filter, Wide-Band Video-Amp and Temperature Control

• MTS (Multi-ChanneITelevision Sound) Stereo Broadcast Reception

• 3D Surround Sound (3 Way)

Screen Size:

Inputs: Dimensions:

• Power Input .................. AC 120V, 60Hz

• Power Consumption (operating) .......... 135W

• Power Consumption (Maximum) .......... 180W

Antenna input impedance ............. 75 Ohm • Width (in.) 311/16

Channel coverage ................... 181 ch.

VHF-Band .......................... 2 ~ 13

UHF-Band ......................... 14 ~ 69

CATV Mid Band ................... A-5 ~ A-1

................................. A-I • Weight (Ibs.) 132

Super Band ........................... J-W

Hyper Band .................... W+I - W+28 35CX30B

Ultra Band .................... W+29 - W+84

• Video ..................... 1.0Vp-p, 75 Ohm • Height (in.) 301/16

• S-Video

Luminance (Y) ............... 1.0Vp-p, 75 Ohm • Width (in.) 3531/32

Chrominance (C) ............. 1.0Vp-p, 75 Ohm

• Audio input level ................... 47k Ohm • Depth (in.) 2413/16

• Average input level ................ 470mVrms

• Maximum input level ............... 940mVrms

32V (32 inches measured diagonally) 32CXl 1B, 32TX78B, and 32TX79K
35V (35 inches measures diagonally) 35CX30B, 35TX78B, and 35TX89K

32CX11 B

• Height (in.) 2611/lS

• Depth (in,) 2233/64

• Weight (Ibs.) 184

32TX78B

32TX79K

447/8

323/8

2231/64

230

35TX88B
35TX89K

5O

3715/32

25

284

I NOTE: Due to improvements, specifications in this operating guide are subject to change without notice. 1

59

HITACHI

USEFULINFO

To locate an authorized
HITACHI service facility

in the continental U.S.A.
and Canada,

DIAL TOLL FREE

7 days a week, 24 hours a day

1-800-448-2244

Hitachi Home Electronics (America), Inc.

Hitachi has made every effort to assure you hours of trouble free operation from your unit. However, should you
require service, a network of Hitachi Authorized Service Facilities has been established in all 50 states and Puerto
Rico. Each facility will provide you with convenient and expedient assistance. Our service "Hotline" operator will

direct you to the Hitachi Authorized Service Facility nearest you. Just present proof of purchase and/or delivery
receipts to the Hitachi Authorized Service Facility,and service will be rendered in accordance with the terms of the
limited warranty as stated on your warranty card or operating guide.

Should you have any questions regarding in-warranty service, operation or technical assistance,
please contact:

Hitachi Home Electronics (America), Inc.
3890 Steve Reynolds Blvd.

Nomross, GA 30093
Tel: [phone]

For TV'$ purchased in (_nada only, please contact one of the Hitachi offices below, should you
have any questions regarding service, operation or technical assistance.

MONTREAL

9425 Trans Canada

Saint-Laurent, Quebec

H4S 1V3

Tel: [phone]

Fax: [phone]

TORONTO

6740 Campobello Road

Mississauga, Ontario

L5N 2L8

Tel: [phone]

Fax: [phone]

Hitachi Sales Corporation of Hawaii
3219 Koapaka St.

Honolulu, HI 96819
Tel: [phone]

VANCOUVER

54 Humber Place, Annacia Industrial Estate

New Westminister, B.C.

V3M 6A6

Tel: [phone]

Fx: [phone]

60

NOTES

61

NOTES

62

NOIES

63

HITACHI

QR05931
