2SK1566, 2SK1567
Silicon N-Channel MOS FET
Application
High speed power switching
Features
• Low on-resistance
• High speed switching
• Low drive current
• No secondary breakdown
• Suitable for switching regulator and DC-DC converter
Outline
TO-220FM
G
D
S
1
2
3
1. Gate
2. Drain
3. Source

2SK1566, 2SK1567
Absolute Maximum Ratings (Ta = 25°C)
Item Symbol Ratings Unit
Drain to source voltage 2SK1566 V
DSS
2SK1567 500
Gate to source voltage V
Drain current I
Drain peak current I
Body to drain diode reverse drain current I
Channel dissipation Pch*
GSS
D
D(pulse)
DR
1
*
2
Channel temperature Tch 150 °C
Storage temperature Tstg –55 to +150 °C
Note 1. PW ≤ 10 µs, duty cycle ≤ 1%
2. Value at T
= 25°C
C
450 V
±30 V
7A
28 A
7A
35 W
2

2SK1566, 2SK1567
Electrical Characteristics (Ta = 25°C)
Item Symbol Min Typ Max Unit Test conditions
Drain to source 2SK1566 V
(BR)DSS
breakdown voltage 2SK1567 500
Gate to source breakdown
V
(BR)GSS
voltage
Gate to source leak current I
Zero gate voltage 2SK1566 I
GSS
DSS
drain current 2SK1567 VDS = 400 V, VGS = 0
Gate to source cutoff voltage V
Static Drain to source 2SK1566 R
GS(off)
DS(on)
on state resistance 2SK1567 — 0.7 0.9
Forward transfer admittance |yfs| 4.0 6.5 — S ID = 4 A, VDS = 10 V *
Input capacitance Ciss — 1050 — pF VDS = 10 V, VGS = 0,
Output capacitance Coss — 280 — pF f = 1 MHz
Reverse transfer capacitance Crss — 40 — pF
Turn-on delay time t
Rise time t
Turn-off delay time t
Fall time t
Body to drain diode forward
V
d(on)
r
d(off)
f
DF
voltage
Body to drain diode reverse
t
rr
recovery time
Note 1. Pulse test
450 — — V ID = 10 mA, VGS = 0
±30——V I
= ±100 µA, VDS = 0
G
——±10 µAVGS = ±25 V, VDS = 0
— — 250 µAVDS = 360 V, VGS = 0
2.0 — 3.0 V ID = 1 mA, VDS = 10 V
— 0.6 0.8 Ω ID = 4 A, VGS = 10 V *
— 15 — ns ID = 4 A, VGS = 10 V,
— 55 — ns RL = 7.5 Ω
—95—ns
—40—ns
— 0.95 — V IF = 7 A, VGS = 0
— 320 — ns IF = 7 A, VGS = 0,
di
/dt = 100 A/µs
F
1
1
See characteristic curves of 2SK1157, 2SK1158.
3

2SK1566, 2SK1567
Power vs. Temperature Derating
60
40
20
Channel Dissipation Pch (W)
0 50 100 150
Case Temperature T
(°C)
C
Maximum Safe Operation Area
50
20
(A)
D
10
5
PW = 10 ms (1 Shot)
DC Operation (T
2
1
0.5
Operation in this Area
is Limited by R
Drain Current I
0.2
0.1
Ta = 25°C
0.05
1 3 30 300
DS (on)
2SK1567
2SK1566
10 100 1,000
Drain to Source Voltage V
100 µs
1 ms
C
= 25°C)
DS
10 µs
(V)
(t)
S
Normalized Transient Thermal Impedance γ
1.0
0.3
0.1
0.03
0.01
3
10 µ
D=1
0.5
0.2
0.1
0.05
0.02
0.01
1 Shot Pulse
Normalized Transient Thermal Impedance vs. Pulse Width
100 µ 10 m 100 m 1 101 m
Pulse Width PW (s)
θch–c (t) = γ
θch–c = 3.57°C/W, T
P
DM
PW
T
(t) · θch–c
S
TC = 25°C
= 25°C
C
PW
D =
T
4

10.0 ± 0.3
7.0 ± 0.3
φ
3.2 ± 0.2
0.6
2.8 ± 0.2
2.5 ± 0.2
Unit: mm
1.2 ± 0.2
1.4 ± 0.2
2.0 ± 0.3
0.7 ± 0.1
2.54 ± 0.52.54 ± 0.5
12.0 ± 0.3
5.0 ± 0.3
4.45 ± 0.3
2.5
Hitachi Code
JEDEC
EIAJ
Weight
17.0 ± 0.3
14.0 ± 1.0
0.5 ± 0.1
(reference value)
TO-220FM
—
Conforms
1.8 g
