Hisense Electric LCDF0005 User Manual
55T770DW
www.hisense-usa.com
service@hisense-usa.com
ES-G120902
English
The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product's enclosure that may be of sufcient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
FCC Statement Energy Star
NOTE:
This equipment has been tested and found to comply with
the limits for a class B digital Device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio Communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
FCC ID Number WiFi Module: WWMMN421V1
Your Hisense TV is ENERGY STAR
qualified in the “Home” mode. It meets
strict energy efficiency guidelines set
by the U.S. Environmental Protection
Agency and Department of Energy.
ENERGY STAR is a joint program of
these government agencies, designed
to promote energy efficient products
and practices. Changes to certain features, settings, and
functionalities of this TV (i.e. TV Guide, Picture, Sound) can
increase or change the power consumption. Depending upon
such changed settings, the power consumption may exceed
the limits required for the ENERGY STAR qualification in the
“Home” mode.
NOTE
Where the MAINS plug or an appliance coupler is used
as the disconnect device, the disconnect device shall
remain readily operable.
WARNING
The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to
this equipment. Such modifications could void the user's
authority.
This TV incorporates High-Denition Multimedia Interface (HDMI
HDMI, the HDMI logo and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
Hisense and associated logos where applicable are registered trademarks of Hisense Group in the United States and/or other
countries. All other trademarks are property of their respective owners. 2011 Hisense USA, Corporation. All Rights Reserved.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
* Specications subject to change without notice. All other trademarks, logos and copyrights are the property of their respective
owners.
TM
) technology.
I
II
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories
specified by the manufacturer.
12. Use only with cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used,
use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
15. Apparatus should not be exposed to dripping or
splashing, and objects filled with liquids, such as vases,
should not be placed on the apparatus.
16. An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines
or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching
such power lines or circuits, as contact with them might
be fatal.
17. Do not overload wall outlets and extension cords, as this
can result in a risk of fire or electric shock.
18. Do not push objects through any openings in this unit,
as they may touch dangerous voltage points or short out
parts that could result in fire or electric shock. Never spill
or spray any type of liquid into the unit.
19. If an outside antenna or cable system is connected to the
unit, be sure the antenna or cable system is grounded to
provide some protection against voltage surges and builtup static charges, Section 810 of the National Electrical
Code, ANSI/NFPA 70, provides information with respect
to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location of antenna
discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
20. When replacement parts are required, be sure the service
technician uses replacement parts specified by the
manufacturer or those that have the same characteristics
as the original part. Unauthorized substitutions may result
in fire, electric shock or other hazards.
21. Upon completion of any service or repairs to this unit,
ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
22. When you connect the product to other equipment, turn
off the power and unplug all of the equipment from the
wall outlet. Failure to do so may cause an electric shock
and serious personal injury. Read the owner's manual of
the other equipment carefully and follow the instructions
when making any connections.
23. Sudden high volume sound may cause hearing or
speaker damage. When you use headphones, (if the unit
is equipped with a headphone jack) keep the volume at a
moderate level. If you use headphones continuously with
high volume sound, it may cause hearing damage.
CONDENSATION:
Moisture will form in the operating section of the unit if the
unit is brought from cool surroundings into a warm room or
if the temperature of the room rises suddenly. When this
happens, unit's performance will be impaired. To prevent
this, let the unit stand in its new surroundings for about an
hour before switching it on, or make sure that the room
temperature rises gradually.
Condensation may also form during the summer if the unit is
exposed to the breeze from an air conditioner. In such cases,
change the location of the unit.
III
Important Safety Instructions
HOW TO HANDLE THE LCD PANEL:
Do not press hard or jolt the LCD panel. It may cause the
LCD panel glass to break and injury may occur.
If the LCD panel is broken, make absolutely sure that you
do not touch the liquid in the panel. This may cause skin
inflammation.
If the liquid gets in your mouth, immediately gargle and
consult with your doctor. Also, if the liquid gets in your eyes
or touches your skin, consult with your doctor after rinsing
for at least 15 minutes or longer in clean water.
Possible Adverse Effects on LCD Panel:
If a fixed (non-moving) pattern remains on the LCD Panel
for long periods of time, the image can become permanently
engrained in the LCD Panel and cause subtle but permanent
ghost images. This type of damage is NOT COVERED BY
YOUR WARRANTY. Never leave your LCD Panel on for long
periods of time while it is displaying the following formats or
images:
Fixed Images, such as stock tickers, video game patterns,
TV station logos, and websites.
Special Formats that do not use the entire screen. For
example, viewing letterbox style (16:9) media on a normal
(4:3) display (black bars at top and bottom of screen); or
viewing normal style (4:3) media on a widescreen (16:9)
display (black bars on left and right sides of screen).
The following symptoms are not signs of malfunction
but technical limitation. Therefore we disclaim any
responsibility for these symptoms.
LCD Panels are manufactured using an extremely high
level of precision technology, however sometimes parts
of the screen may be missing picture elements or have
luminous spots.
This is not a sign of a malfunction.
Do not install the LCD Panel near electronic equipment that
produces electromagnetic waves. Some equipment placed
too near this unit may cause interference.
Effect on infrared devices - There may be interference
while using infrared devices such as infrared cordless
headphones.
End of life directives
Your TV also contains material that can be recycled and
reused. For disposal or recycling information, contact your
local authorities or the Electronic Industries Alliance at
www.eia.org to find a recycler in your area.
Non-active pixels
The LCD panel contains almost 3 million thin film transistors,
which provide exceptionally sharp video quality. Occasionally,
a few non-active pixels may appear on the screen as a
fixed black (in the case of a dead pixel), blue, green, or red
point. These non-active pixels do not adversely affect the
performance of your TV, and are not considered defects.
Power source
TO USE AC POWER
1. The power cord is attached to the TV at the factory.
2. Connect the AC cord into an AC outlet.
WARNING
Do not connect this unit to the power using any device
other than the supplied AC cord. This could cause fire,
electrical shock, or damage.
Do not use with a voltage other than the power voltage
specified. This could cause fire, electrical shock, or
damage.
CAUTION
When this unit is not used for a long time, (e.g., away on
a trip) in the interest of safety, be sure to unplug it from
the AC outlet.
Do not plug/unplug the AC cord when your hands are
wet. This may cause electrical shock.
Declaration of Conformity
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and (2)
This device must accept any interference received, including
interference that may cause undesired operation.
IV
Important Safety Instructions
Disclaimer: Hisense USA companies ("Hisense"). A wired
or wireless Internet connection is required for certain features
and is not included with the television; please contact a
local Internet Service Provider for assistance. Content
suppliers may require a subscription to activate or use their
services which is not included with the television and is sold
separately. The Hisense TV web browser supports a variety
of multimedia platforms however it does not support all
players nor does it support every player version, therefore,
access to certain web content may be limited or unavailable.
INTERNET CONNECTION, ACCEPTANCE OF END USER
LICENSE AGREEMENT (EULA) AND REGISTRATION
OF YOUR HISENSE TELEVISION SERIAL NUMBER IS
REQUIRED. YOU MUST BE AT LEAST 13 YEARS OF AGE
TO REGISTER ONLINE. HISENSE MAY ADD, DELETE,
MODIFY, OR TERMINATE ONLINE SERVICES WITHOUT
NOTICE.
Consent to Use of Data: To facilitate the provision of
software updates, any dynamically served content, product
support and other services you agree that Hisense and its
affiliates may collect, use, store and transmit technical and
related information that identifies your television (including an
Internet Protocol Address), its operating system, application
software and any connected devices. Hisense and its
affiliates may also use this information in the aggregate, in
a form which does not personally identify you, to improve
our products and services and we may share anonymous
aggregate data with our third party service providers.
Internet Performance Issues: A broadband Internet
connection is required for access to Internet Apps and
Content. To avoid poor performance while accessing Internet
Apps and Content, be sure other devices on the same
Internet connection are not running file sharing applications,
streaming audio or video content and are not logged in
to chat-rooms. These applications may consume your
connection’s bandwidth, causing lag or other undesirable
effects. This television uses TCP and UDP port(s) to access
Internet Apps and Content. Please consult your router or
personal firewall documentation for information on how to
allow access to these ports. If you are installing this television
on a corporate Internet connection, contact your network
administrator for information and assistance.
Liability: The Hi-Smart portal may be linked to other
sites on the World Wide Web or Internet which are not
under the control of or maintained by Hisense. Such
links do not constitute an endorsement by Hisense. You
acknowledge that Hisense is providing these links to you
only as a convenience; you further agree that Hisense is not
responsible for the content of such sites.
INFORMATION ACCESSED OR OBTAINED VIA HiSmart IS PROVIDED "AS IS" WITHOUT WARRANTY
OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR
A PARTICULAR PURPOSE, OF NON INFRINGEMENT.
SOME JURISDICTIONS DO NOT ALLOW FOR THE
EXCLUSION OF IMPLIED WARRANTIES, SO THE ABOVE
EXCLUSIONS MAY NOT APPLY TO YOU.
Access to certain areas of the Hi-Smart portal is restricted
and requires a password for entry. If you are an authorized
password holder, you agree that you are entirely responsible
for the confidentiality of your password and account
information, and agree to notify Hisense immediately if your
password is lost, stolen, disclosed to an unauthorized third
party, or other wise may have been compromised. You agree
that you are entirely responsible for any and all activities
which occur under your account, including any fees which
may be incurred under your password protected account
whether or not you are the individual who undertakes such
activities. You agree to immediately notify Hisense of any
unauthorized use of your account or any other breach of
security in relation thereof known to you.
You acknowledge that Hi-Smart may include certain
inaccuracies or typographical errors which may affect the
quality of materials and third-party content. You acknowledge
that the materials or any third-party content have not been
independently verified or authenticated in whole or in part
by Hisense, and agree that Hisense does not warrant the
accuracy or timeliness of materials or the third-party content,
and further agree that Hisense has no liability for any
omissions in the materials and content, whether provided by
Hisense or any third-party.
To the maximum extent permitted by applicable law, Hisense
shall not be liable to you or a third-party claiming through
you for any damage suffered as a result of your displaying,
copying or downloading information or material accessed or
obtained via Hi-Smart. In no event shall Hisense be liable
to you or any third-party for any indirect, extraordinary,
exemplary, punitive, special incidental or consequential
damages (including loss of data, revenue, profits or other
economic advantage) however arising, whether for breach
or in tort even if HISENSE has previously advised of the
possibility of such possible damage.
Technical Support: If you have questions regarding
installation, configuration or operation of this product, please
telephone a Hisense Customer Care representative who
will be happy to assist you with any difficulties you may be
experiencing.
Dial: 1-888-935-8880 (Toll Free)
Email: service@hisense-usa.com
V
Contents
Getting Started
Accessories List...............................................................................................3
Installing the Stand .......................................................................................... 3
Installing a Wall-Mount Bracket .......................................................................4
When Installing the TV Against a Wall or Enclosed Area ................................5
Viewing the Control Panel ...............................................................................6
Viewing the Remote Control ............................................................................ 7
Installing Batteries in the Remote Control ....................................................... 8
Match the Remote Control with TV ..................................................................8
Making Connections ........................................................................................ 9
Basic Features
Turning the TV on or off .................................................................................. 13
Turning the TV On for the First Time .............................................................. 13
Selecting the Input Source .............................................................................13
Changing Channels / Volume .........................................................................14
Shortcuts Instructions ..................................................................................... 14
To Use the Menu ............................................................................................15
Using the Picture Menu ..................................................................................15
Using the Audio Menu ....................................................................................16
Using the Screen Menu .................................................................................. 17
Using the Channels Menu .............................................................................. 17
Using the Settings Menu ................................................................................18
Using the Lock Menu ...................................................................................... 19
Advanced Features
Network Connection .......................................................................................20
DLNA Settings ................................................................................................23
Media Share Settings in Computer.................................................................24
Settings to Share Files ...................................................................................24
1
Contents
Advanced Features
Network Function............................................................................................25
Enter the Network Applications.......................................................................26
VUDU HD Movies ........................................................................................... 27
VUDU Apps ....................................................................................................28
Netix..............................................................................................................28
Opera..............................................................................................................29
YouTube .........................................................................................................31
Other Apps......................................................................................................32
Other Information............................................................................................33
Digital Media Play ........................................................................................... 34
Enjoy Video Files ............................................................................................ 34
Enjoy Music Files............................................................................................35
Browse the Pictures........................................................................................35
Browse the Text Files .....................................................................................36
Other Information
Trouble Shooting ............................................................................................37
General ........................................................................................................... 39
Illustrations are for your reference only!
2
Loading...
