Page 1
Liquid Crystal Display Television
Service Manual
Chassis： MT5330
Product Type：
LHD19W57EU
LHD22W57EU
Ver 1.0
Hisense Electric Co.，Ltd.
June, 2008
Page 2
LCD TV Service Manual
Contents
Contents................................................................................................................................................ .. ... .. ......... - 2 -
Service Manual .............................................................................................................................................. .. ... .- 3 -
1. Precautions and notices........................................................................................................................ .. ... .- 3 -
1.1 WARNING ................................................................................................................................ .. ....- 4 -
1.2 NOTES ...................................................................................................................................... .. ... .- 7 -
2. Product Function Specifications..............................................................................................................- 10 -
2.1 Product Function............................................................................................................................- 10 -
2.2 Specifications............................................................................................................................. ....- 12 -
3. LCD Panel ...................................................................................................................................... .. ... ....- 13 -
General Features........................................................................................................................... ... .. ..- 14 -
4. Chassis Layout and Overall Wiring Diagrams ........................................................................................- 15 -
4.1 Chassis Layout................................................................................................................. .. ... ......... - 15 -
4.2 Overall Wiring Diagrams...............................................................................................................- 16 -
5. Factory/Service OSD Menu.. .. ... .. ............................... .. ... .............................. .. ............................ ............- 18 -
5.1 To enter the Factory OSD Menu....................................................................................................- 18 -
5.2 Factory OSD Menu........................................................................................................................- 18 -
6. Software Upgrading........................................................................................................... ......................- 22 -
6.1 Get ready for upgrading..................................................................................................... ............- 22 -
6.2 Upgrading with the MtkTool.........................................................................................................- 24 -
7. Troubleshooting......................................................................................................................... .. ... ......... - 2 8 -
7.1 Troubleshooting for Remote Control.............................................................................................- 28 -
7.2 Troubleshooting for Function Key......................... .............................. .. ... .............................. ....... - 2 9 -
7.3 TV won’t Power On.......................................................................................................................- 30 -
7.4 Troubleshooting for Audio.............................................................................................................- 31 -
7.5 Troubleshooting for TV/VGA/HDMI input................................. ... .. ... .............................. ............- 32 -
7.6 Troubleshooting for YPbPr input............................................................................................... .. ..- 33 -
7.7 Troubleshooting for Video/S-Video/ SCART input.............. .. ... .............................. ... ...................- 34 -
7.8 Other problems ................................................................................................................ .. ............- 35 -
8. Explode View.................................................................................................................................. .. ... ....- 37 -
9. Schematic circuit diagram .......................................................................................................................- 37 -
Hisense Confidential
- 2 -
Page 3
LCD TV Service Manual
Service Manual
1. Precautions and notices
BEFORE SERVICING THE LCD TV, READ THE SAFETY PRECAUTIONS IN
THIS MANUAL.
WHEN REPLACEMENT PARTS ARE REQUIRED, BE SURE TO USE
REPLACEMENT PARTS SPECIFIED BY THE MANUFACTURER.
Proper service and repair is important to the safe, reliable operation of all Hisense
Electric Co., Ltd Equipment. The service procedures recommended by Hisense and
described in this Service Guide are effective methods of performing service
operations. Some of these service operations require the use of tools specially
designed for the purpose. The special tools should be used when and as
recommended.
It is important to note that this manual contains various CAUTIONS and NOTICES
which should be carefully read in order to minimize the risk of personal injury to
service personnel. The possibility exists that improper service methods may damage
the equipment. It is also important to understand that these CAUTIONS and
NOTICES ARE NOT EXHAUSTIVE. Hisense could not possibly know, evaluate
and advise the service trade of all conceivable ways in which service might be done
or of the possible hazardous consequences of each way. Consequently, Hisense has
Hisense Confidential
- 3 -
Page 4
LCD TV Service Manual
not undertaken any such broad evaluation. Accordingly, a serviceman that uses a
service procedure or tools, which are not recommended by Hisense, must first satisfy
himself thoroughly that neither his safety nor the safe of the equipment will be
jeopardized by the service method selected.
Hereafter throughout this manual, Hisense Electric Co., Ltd will be referred to as
Hisense.
1.1 WARNING
1.1.1
Critical components having special safety characteristics are identified with a
by
the Ref. No. in the parts list. Use of substitute replacement parts, which do not have
the same specified safety characteristics, may create shock, fire, or other hazards.
Under no circumstances should the original design be modified or altered without
written permission from Hisense. Hisense assumes no liability, express or implied,
arising out of any unauthorized modification of design. Serviceman assumes all
liability.
DANGERCAUTION CAUTION
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY
ORIGINAL MANUFACTURER'S REPLACEMENT PARTS, WHICH ARE LISTED WITH
THEIR PART NUMBERS IN THE PARTS LIST SECTION OF THIS SERVICE GUIDE.
Hisense Confidential
- 4 -
Page 5
1.1.2.
All ICs and many other semiconductors are susceptible to electrostatic discharges
(ESD). Careless handling during repair can reduce life drastically. When repairing,
make sure that you are connected with the same potential as the mass of the set by a
wristband with resistance. Keep components and tools also at this same potential.
1. Never replace modules or other components while the unit is switched on.
2. When making settings, use plastic rather than metal tools. This will prevent
any short circuits and the danger of a circuit becoming unstable.
1.1.3
LCD TV Service Manual
To prevent electrical shock, do not use this polarized ac plug with an extension cord,
receptacle, or the outlet unless the blades can be fully inserted to prevent blade
exposure.
To prevent electrical shock, match wide blade or plug to wide slot, fully insert.
1.1.4
When replacement parts are required, be sure to use replacement parts specified by
the manufacturer or have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
1.1.5
Safety regulations require that after a repair the set must be returned in its original
condition. In particular attention should be paid to the following points.
-Note: The wire trees should be routed correctly and fixed with the mounted
Hisense Confidential
- 5 -
Page 6
cable clamps.
-The insulation of the mains lead should be checked for external damage.
1.1.6
(1) Do not touch Signal and Power Connector while this product operates. Do not
touch EMI ground part and Heat Sink of Film Filter.
(2) Do not supply a voltage higher than that specified to this product. This may
damage the product and may cause a fire.
(3) Do not use this product in locations where the humidity is extremely high,
where it may be splashed with water, or where flammable materials surround it. Do
LCD TV Service Manual
not install or use the product in a location that does no satisfy the specified
environmental conditions. This may damage the product and may cause a fire.
(4) If a foreign substance (such as water, metal, or liquid) gets inside the panel
module, immediately turn off the power. Continuing to use the product may cause
fire or electric shock.
(5) If the product emits smoke, and abnormal smell, or makes an abnormal sound,
immediately turn off the power. Continuing to use the product, it may cause fire or
electric shock.
(6) Do not disconnect or connect the connector while power to the product is on. It
takes some time for the voltage to drop to a sufficiently low level after the power
has been turned off. Confirm that the voltage has dropped to a safe level before
disconnecting or connecting the connector.
Hisense Confidential
- 6 -
Page 7
(7) Do not pull out or insert the power cable from/to an outlet with wet hands. It
may cause electric shock.
(8) Do not damage or modify the power cable. It may cause fire or electric shock.
(9) If the power cable is damaged, or if the connector is loose, do not use the
product: otherwise, this can lead to fire or electric shock.
(10) If the power connector or the connector of the power cable becomes dirty or
dusty, wipe it with a dry cloth. Otherwise, this can lead to fire.
(11) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution when
LCD TV Service Manual
moving the cart/apparatus combination to avoid injury from tip-over.
1.2 NOTES
Notes on Safe Handling of the LCD panel and during service
The work procedures shown with the Note indication are important for ensuring the
safety of the product and the servicing work. Be sure to follow these instructions.
• Before starting the work, secure a sufficient working space.
• At all times other than when adjusting and checking the product, be sure to turn
OFF the POWER Button and disconnect the power cable from the power source of
the TV during servicing.
• To prevent electric shock and breakage of PC board, start the servicing work at least
30 seconds after the main power has been turned off. Especially when installing and
removing the power board, start servicing at least 2 minutes after the main power has
Hisense Confidential
- 7 -
Page 8
been turned off.
• While the main power is on, do not touch any parts or circuits other than the ones
specified. If any connection other than the one specified is made between the
measuring equipment and the high voltage power supply block, it can result in
electric shock or activation of the leakage-detection circuit breaker.
• When installing the LCD module in, and removing it from the packing carton, be
sure to have at least two persons perform the work.
• When the surface of the panel comes into contact with the cushioning materials, be
sure to confirm that there is no foreign matter on top of the cushioning materials
LCD TV Service Manual
before the surface of the panel comes into contact with the cushioning materials.
Failure to observe this precaution may result in, the surface of the panel being
scratched by foreign matter.
• When handling the circuit board, be sure to remove static electricity from your body
before handling the circuit board.
• Be sure to handle the circuit board by holding the large parts as the heat sink or
transformer. Failure to observe this precaution may result in the occurrence of an
abnormality in the soldered areas.
• Do not stack the circuit boards. Failure to observe this precaution may result in
problems resulting from scratches on the parts, the deformation of parts, and
short-circuits due to residual electric charge.
• Routing of the wires and fixing them in position must be done in accordance with
Hisense Confidential
- 8 -
Page 9
the original routing and fixing configuration when servicing is completed. All the
wires are routed far away from the areas that become hot (such as the heat sink).
These wires are fixed in position with the wire clamps so that the wires do not move,
thereby ensuring that they are not damaged and their materials do not deteriorate over
long periods of time. Therefore, route the cables and fix the cables to the original
position and states using the wire clamps.
• Perform a safety check when servicing is completed. Verify that the peripherals of
the serviced points have not undergone any deterioration during servicing. Also
verify that the screws, parts and cables removed for servicing purposes have all been
LCD TV Service Manual
returned to their proper locations in accordance with the original setup.
The lightning flash with arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the products enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the set.
Hisense Confidential
- 9 -
Page 10
LCD TV Service Manual
2. Product Function Specifications
2.1 Product Function
Hisense Confidential
- 10 -
Page 11
LCD TV Service Manual
Hisense Confidential
- 11 -
Page 12
2.2 Specifications
LCD TV Service Manual
Allowable temperature of operation environment 0℃ to 40℃
ACCESSORIES
User′s Manual 1
Remote Control Unit 1
Dry Cell Battery 2
Hisense Confidential
- 12 -
Page 13
LCD TV Service Manual
3. LCD Panel
3.1 HT190WG1-101 (PN: 1042399) BOE
BLOCK DIAGRAM
Hisense Confidential
- 13 -
Page 14
General Features
GENERAL SPECIFICATI0NS
LCD TV Service Manual
3.2 LTM220M1-L01 (PN: 1041814)
GENERAL SPECIFICATI0NS
Hisense Confidential
- 14 -
Page 15
LCD TV Service Manual
4. Chassis Layout and Overall Wiring Diagrams
4.1 Chassis Layout
LHD19W57EU
No
(1) Main Board
(2) Inverter Board
(3) Keypad Board
(4) IR&Led Board
Description
Part No
116016
1041467
114552
114175
Type/Model PCB
RSAG2.908.1171-3\ROH RSAG7.820.1188\VER.B\ROH
JSI-190411B\ROH Outsourcing
RSAG2.908.1168-2\ROH RSAG7.820.1214\ROH
RSAG2.908.1169 RSAG7.820.1213\ROH
LHD22W57EU
No
(1) Main Board 116538 RSAG2.908.1171-4\ROH RSAG7.820.1188\VER.B\ROH
(2) Inverter Board 1043506 JSI-220402\ROH\JK
Description
Part No
Type/Model PCB
(3) Keypad Board 114552 RSAG2.908.1168-2\ROH RSAG7.820.1214\VER.A\ROH
(4) IR&Led Board 114175 RSAG2.908.1169 RSAG7.820.1213\VER.A\ROH
Hisense Confidential
- 15 -
Page 16
LCD TV Service Manual
4.2 Overall Wiring Diagrams
LHD19W57EU
No DESCRIPTION SPECIPICATION NOTE
Main Power TJC2-3Y-250-2\ROH
1
Back light power to panel the connectors on the panels
2
12V power and communication
3-1
between Main BD and power BD
5V power and communication
3-2
between Main BD and power BD
Audio output (L/R) TJC3H-4Y-800-600\ROH Main BD J29<-->Speaker L/R
4
Buttons TJC10T-3Y-650\ROH Main BD J11<--> Keypad BD XPK01
5
LED & IR TJC10T-5Y-700\ROH Main BD J27<--> Led &IR BD XPR01
6
LVDS signal HX2-2X15NLB150-BOE\ROH Main BD J6<-->Panel
7
TJC10T-6Y-150\ROH Inverter BD CN3F<-->Main BD J20
TJC3T-4Y-100\ROH Inverter BD CN2F<-->Main BD J26
Power Inlet-->
Inverter BD CN2、CN3、CN4、CN5<-->Panel
Hisense Confidential
- 16 -
Inverter BD CN1F
Page 17
LHD22W57EU
LCD TV Service Manual
No DESCRIPTION SPECIPICATION NOTE
Main Power TJC2-3Y-250-2\ROH
1
Back light power to panel the connectors on the panels
2
12V power and communication
3
between Main BD and power BD
Buttons TJC10T-3Y-650\ROH Main BD J11<--> Keypad BD XPK01
4
LED & IR TJC10T-5Y-700\ROH Main BD J27<--> LED&IR BD XPR01
5
Audio output (L/R) TJC3H-4Y-800-600\ROH Main BD J29<-->Speaker L/R
6
LVDS signal HX2-2X15NLB150-BOE\ROH Main BD J6<-->Panel
7
TJC10T-6Y-150\ROH
Power Inlet-->
Inverter BD CN2、CN3、CN4、CN5<-->Panel
Inverter BD CN4F<-->Main BD J21
Inverter BD CN1F
Hisense Confidential
- 17 -
Page 18
LCD TV Service Manual
5. Factory/Service OSD Menu
5.1 To enter the Factory OSD Menu
a. With factory RC (remote control)
1. Press “M” button and enter factory mode.
2. Press “Menu” button and enter factory OSD menu.
3. Press “CH+”/“CH-” button select the function menu, press “VOL+”/“VOL-” enter the
selected function menu. Press “VOL+”/“VOL-” button adjust values in the menu.
b. With user’s RC
1. Power TV On
2. Press Menu button and call up User OSD Menu
3. Select Sound-> Balance
4. Enter 0->5->3 ->2 in sequence.
Note: If necessary, re-do number keys.
5. Factory OSD appears.
5.2 Factory OSD Menu
5.2.1 Factory Menu
Item 0 Item 1 Note
R Gain High Brightness Red.
G Gain High Brightness Green
B Gain High Brightness Blue
R Offset Low Brightness Red.
G Offset Low Brightness Green
B Offset Low Brightness Blue
WBH Brightness
White Balance
WBH Contrast
WBH Color Adjust high color temporarily
WBL Brightness
WBL Contrast
WBL Color
Note: Before adjusting, please change to desired source. Different source has different WB
values.
Adjust low color temporarily
Adjust high brightness
temporarily
Adjust high contrast
temporarily
Adjust low brightness
temporarily
Adjust low contrast
temporarily
Hisense Confidential
- 18 -
Page 19
Set Channel
Auto Color
Factory Option
MODE “M” is only used for factory production.
Version Info
Note: Software version info of the TV, readable only.
Clean Protected
Clean All
Note: The factory menu date varies according to different sources. Incase changing the
factory data by error, you can choose to “clear the EEPROM”, by which you can resume the
default value.
To clear the EEPROM:
a. Select the button “Clear All”.
b. Press VOL+ button to clear the EEPROM data.
c. When the “Clear All” button becomes white, turn off the power.
d. Restart the TV.
LCD TV Service Manual
Zhong Shi Qingdao Jiangxi Road factory
Huang Dao Huangdao Industrial Park
Gui Yang Gui Yang Industrial Park
Liao Ning Liao Ning Industrial Park
Hungary Hisense Hungary
Australia Hisense Australia
France Hisense France
To FAC
Logo Option Logo Selection
Test Time 1~30 (default 5)
Communication ON/OFF (default ON)
EDID Write OFF/ON(default OFF)
Hotel Mode OFF/ON(default OFF)
VOL MAX
Version Software version
Date The date of current version
Available only in component
and VGA source
M-Can enter factory mode
with factory RC or user RC.
U-Can enter factory mode
only with user’s RC.
0~100(default 50)
Set the max sound value
when TV working in hotel
mode.
WB data、Auto Color data
Hisense Confidential
- 19 -
Page 20
5.2.1 Design Menu
Item 0 Item 1 Item 2 Note
Color Temp Cool (default)/Warm
Color T emP
Video
Sound
R Gain
G Gain
B Gain
Video Curve Brightness Min Min Brightness
Brightness Mid Mid Brightness
Picture Mode SOURCE The current program
VIVID Brightness Brightness of VIVID
VIVID Contrast Contrast of VIVID
VIVID Saturation Saturation of VIVID
STD Brightness Brightness of STD
STD Contrast Contrast of STD
STD Saturation Saturation of STD
MOVIE Brightness Brightness of Movie
MOVIE Contrast Contrast of Movie
MOVIE Saturation Saturation of Movie
Volume Curve
LCD TV Service Manual
Brightness Max Max Brightness
Contrast Min Min Contrast
Contrast Mid Mid Contrast
Contrast Max Max Contrast s
Saturation Min Min Saturation
Saturation Mid Mid Saturation
Saturation Max Max Saturation
source
mode
mode
mode
mode
mode
mode
mode
mode
mode
When value is 1
Volume Min
Volume 20
Think about the
Audio out power
before adjusting
When value is 20
Think about the
Hisense Confidential
- 20 -
Page 21
LCD TV Service Manual
Audio out power
before adjusting
Volume Mid
When value is 50
Think about the
Audio out power
before adjusting
Volume 80
When value is 70
Think about the
Audio out power
before adjusting
Volume Ma x
When value is 90
Think about the
Audio out power
before adjusting
Audio Mode
Audio Mode
120HZ
500HZ
1.5kHZ
Standard, Speech,
Music
Different frequencies
for different Audio
Mode
5kHZ
10kHZ
NOTE：
The above “Factory/Service OSD Menu” are reference only, please refer to the actual
units to determine the appearances
Hisense Confidential
- 21 -
Page 22
LCD TV Service Manual
6. Software Upgrading
The software is upgraded by a burning tool-MtkTool, which can burn the program file *.bin to
the main board of the unit.
6.1 Get ready for upgrading
6.1.1 Install the driver
Double click the icon
Select the default value, the driver will be installed step by step.
6.1.2 Hardware connecting
Connect the unit to your pc with a USB-to-jack (4 pin) port cable. USB port connects to your pc,
and the 4 pin-jack to the J3 of the main board.
.
, install the driver.
USB connects to pc
Connect to the TV’s
J3(
4pin)
For the first connecting, the pc will recogniz e and automatically install the USB device. The
process is just like the installation of a mini disk, see the following picture.
Hisense Confidential
- 22 -
Page 23
LCD TV Service Manual
Hisense Confidential
- 23 -
Page 24
LCD TV Service Manual
6.2 Upgrading with the MtkTool
MTKtool is a green program needing no installation. It is saved in the fold er
. There are five folders/files in this folder altergether.
The MtkTool using log is restored in the MtkLog folder. It records the runnin g time and date
whenever the tool is used. The log will be a txt file named by the date and time.
After connecting the TV with your PC, double click
MtkTool.
If following error appears, it means the related port is not be set properly.
Ignore these errors, click “Confirm” and enter the MtkTool main interface, see the
following picture.
1—Flash chip model
2—The port through which the PC communicate with the chip.
Hisense Confidential
- 24 -
icon, open the
Page 25
3—The communicating baud rate
4—The new program file (*.bin) for upgrading.
5—Click this button can select the *.bin file to be used for upgrading.
6—Click to start upgrading.
LCD TV Service Manual
Hisense Confidential
- 25 -
Page 26
Open “Device Manager” and find which port is connected with the TV. In above picture,
COM2 is connected to the TV; so, select “COM2” in the MtkTool main interface. Select the righ t
baud rate according to chip model. For this unit( chip model is MT537X), select 115200*2.
Note: Where or not click the “Auto Set Flash Baud Rate” in the “window” menu
depends on the chip type. If the flash chip does not support high speed transport, do not select
this option; otherwise, reserve the selected mood.
LCD TV Service Manual
Click “Browse” button (5), find the upgrading program file, select it. Press “Upgrade”
button and start upgrading.
The following interface appears on the screen, indicating upgrading successfully.
Hisense Confidential
- 26 -
Page 27
LCD TV Service Manual
Hisense Confidential
- 27 -
Page 28
LCD TV Service Manual
7. Troubleshooting
7.1 Troubleshooting for Remote Control
Remote control does not work
YES
Try new batteries
Replace battery
NO
Replace RC
YES
Replace remote control
NO
Check IR receiver
Change Led & IR board
NO
Change Led & IR cable
YES
YES
Replace Led & IR BD
Replace Led & IR cable
NO
Replace main board
Hisense Confidential
- 28 -
Page 29
LCD TV Service Manual
7.2 Troubleshooting for Function Key
Buttons does not work
Check switches
YES
Replace tact switch
NO
Check key board
YES
Replace Key BD
NO
Check Key BD cable
Change Key BD cable
YES
OK
NO
Replace main board
Hisense Confidential
- 29 -
Page 30
7.3 TV won’t Power On
LCD TV Service Manual
TV won’t power on
Is LED light?
NO
Check Power
Inlet
YES
Make Sure Power
source is live
YES
NO
BLUE
RED
OSD?
NO
YES
Check signal
Source
YES
NO
Check Power
Cord
NO
Try Power on by
RC and Button
Neither
works
Replace Main
BD
YES
Only
one works
Both
Work
Replace
Power Cord
Check/replace IR
BD or Keypad
PCA
NO
Replace Panel
Replace Main BD
OK
YES
Power on
NO
Replace Power BD
YES
OK
Hisense Confidential
- 30 -
Page 31
LCD TV Service Manual
7.4 Troubleshooting for Audio
No sound
Check connecter
YES
Reconnect
NO
Check speaker wire
NO
Check speaker set
YES
YES
Replace speaker wir e
Replace speaker set
NO
Replace main board
YES
OK
Hisense Confidential
- 31 -
Page 32
LCD TV Service Manual
7.5 Troubleshooting for TV/VGA/HDMI input
No picture on the screen
Check Signal Source
NO
Make sure signal
source is available
Check connect
YES
Reconnect
NO
Check cable
YES
Replace cable
NO
Replace main board
Hisense Confidential
- 32 -
Page 33
LCD TV Service Manual
7.6 Troubleshooting for YPbPr input
No picture on the sc reen
Check Source work or not
YES
Check connect
NO
Check Wires (Green Blue, Red)
NO
Replace main board
NO
YES
YES
Check Source Device
Reconnect
Replace wires
Hisense Confidential
- 33 -
Page 34
LCD TV Service Manual
7.7 Troubleshooting for Video/S-Video/ SCART input
No picture on the screen
Check Source work or not
YES
NO
Check Signal Source
Check connect
YES
Reconnect
NO
Check Cable/ Wires
YES
Replace Cable/Wires
NO
Check SCA RT BD
YES
Replace SCART BD
NO
Replace main board
Hisense Confidential
- 34 -
Page 35
LCD TV Service Manual
7.8 Other problems
Please check the following list prior to calling The Electronics Service Centre for
assistance.
Hisense Confidential
- 35 -
Page 36
LCD TV Service Manual
Hisense Confidential
- 36 -
Page 37
8. Explode View
9. Schematic circuit diagram
LCD TV Service Manual
Hisense Confidential
- 37 -
Page 38
Page 39
A
B
C
D
E
MT5331RAV1.7
MT5330 (PBGA) REFERENCE DESIGN - 2 LAYERS
Rev DATEHistory
RA-V1 INITIAL VERSION 2006/07/05
2006/09/20RA-V1.2 ADDED DVB-CI INTERFACE
4 4
REMOVE POWER-ON STATUS CIRCUIT (PAGE7)
CHANGE AUDIO CODEC CIRCUIT (PAGE16)
CHANGE AUDIO AMP CIRCUIT (PAGE17)
2006/10/15RA-V1.3 REMOVE RF SWITCH (PAGE3)
+12VPOWER
IROIRI
R1793
R1793
10
10
R-RESC1608N-HX
R-RESC1608N-HX
IR
MODIFY MUTE CIRCUIT FOR MT8291 (PAGE16)RA-V1.4 2006/10/28
RA-V1.7 2007/01/01CHANGE NOTE IS STATE ON THE DOCUMENT
RA-V1.8 ADDED DVB-CI INTERFACE(PAGE4/PAGE5/PAGE14) 2007/06/23
MODIFY SCART INPUT(PAGE10)
MODIFY YPBPR AUDIO INPUT(PAGE9)
MODIFY VGA AUDIO INPUT(PAGE11 PAGE12)
MODIFY KEY PAD CIRCUIT,CHANGE I/O PORT TO ADIN2 AND ADIN3(PAGE1)
MODIFY VGA HSYNC AND VSYNC CIRCUIT(PAGE12)
ADDED 12V-5V CIRCUIT(PAGE1) 2007/06/27
2007/06/25
C1333
C1333
LMK212BJ106
LMK212BJ106
01. INDEX
02. POWER
3 3
03. TUNER
04. MT5131 ASIC
05. MT5331 ASIC
06. MT5331 BYPASS CAP.
07. MT5331 PERIPHERAL
08. DDR1 MEMORY
09. AV/S_VDIEO/YPBPR INPUT
10. SCART INPUT AND OUTPUT
OPWRSB
R1742
R1742
15K/NC
15K/NC
R-RESC1608N-HX
R-RESC1608N-HX
R1285 1KR1285 1K
R1741
R1741
15K
15K
R-RESC1608N-HX
R-RESC1608N-HX
1
R1794
R1794
15K
15K
R-RESC1608N-HX
R-RESC1608N-HX
Q36
Q36
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
+12VPOWER
1
R1776 10KR1776 10K
C1327
C1327
0.1UF
0.1UF
C1328 1UFC1328 1UF
R1777 4.7KR1777 4.7K
This circuit just be apply to 22INCH (TONY 2007-07-03)
U14
U14
1
S1
2
G1
3
S2
4
PWR_SW
Q37
Q37
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
G2
IRF7316
IRF7316
R-SOIC08N-1.270-6.00-HX
R-SOIC08N-1.270-6.00-HX
11. VGA\HDMI INPUT
12. AUDIO CODEC
13. AMP
14. CI CARD
2 2
OPWRSB
HIGH = > OPEN FRAME POWER OFF
LOW = > OPEN FRAME POWER ON
+5V
DEVICETYPENAME
+24V
+12V
+5V
+5VSB
DV33SB
+5V_TUENR
DV33_DM
DV18_DM
DV33
AV33
DV18_DDR
AV15
DV12
1 1
AV12
GND
AGND_PLL
AGND_AFE
AGND_HDMI
AGND_LVDS
POWER +24V
POWER +12V
POWER +5V
POWER +5V
POWER +3.3V
POWER +5V
POWER +3.3V
POWER +1.6V
POWER +3.3V
POWER +3.3V
POWER +1.8V
POWER +1.5V
POWER +1.2V
POWER +1.2V
GROUND
GROUND
GROUND
GROUND
GROUND
A
POWER SUPPLY
POWER SUPPLY
POWER SUPPLY
POWER SUPPLY
STANDBY POWER
TUNER POWER
MT5131 POWER AND ITS PERIPHERAL
MT5131 POWER
MT5331 POWER AND ITS PERIPHERAL
MT5331 ANALOG POWER
MT5331 DDR POWER
MT5331 VIDEO FRONT-END POWER
MT5331 POWER
MT5331 ANALOG POWER
DIGITAL GROUND
ANALOG GROUND
ANALOG GROUND
ANALOG GROUND
ANALOG GROUND
+5V
DV33SB
B
5VCC
PWR_SW
or instead of FDS9435A(with CI)
AV33
R1601 1KR1601 1K
R1599 1KR1599 1K
4.7k
4.7k
R1797
R1797
OPWM1
OPCTRL4
R1743 10KR1743 10K
R1604 10KR1604 10K
1
R1798 4.7kR1798 4.7k
1
panel_power
2
4
AGND_LVDS
6
A0N A0P
8
A1N
10
A2N
12
AGND_LVDS
14
CK1N
16
A3N
18
A4N
20
A5N
22
A6N
24
AGND_LVDS
26
CK2N
28
A7N
30
M-2P30-2.00X2.00-180-HX
M-2P30-2.00X2.00-180-HX
U138
U138
1
S1
2
G1
3
S2
4
G2
IRF7316
IRF7316
R-SOIC08N-1.270-6.00-HX
R-SOIC08N-1.270-6.00-HX
2 3
2 3
J6
J6
15x2
15x2
5VCC
R1792
R1792
10
10
R-RESC1608N-HX
R-RESC1608N-HX
PWR_IR
CB1098
CB1098
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
U449
U449
8
IN
6
PG
3
VCC
7
EN/SYNC
MP2380
MP2380
+12V
8
D1
7
D1
6
D2
5
D2
P-CH
P-CH
+5V
8
D1
7
D1
6
D2
5
D2
P-CH
P-CH
R1600
R1600
10k
10k
Q82
Q82
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
Q83
Q83
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
Back Light circuit
1
AGND_LVDS
3
AGND_LVDS
5
7
A1P
9
A2P
11
AGND_LVDS
13
CK1P
15
A3P
17
A4P
19
A5P
21
A6P
23
AGND_LVDS
25
CK2P
27
A7P
29
C
+
CE611
+
CE611
22uF/25v
22uF/25v
R-CAPAE-D4.0X5.4-HX
R-CAPAE-D4.0X5.4-HX
R1778
R1778
39K 1%
39K 1%
CB555
CB555
0.1uF
0.1uF
时要口向外。
R1775 13K 1%R1775 13K 1%
C1325
C1325
0.1UF
0.1UF
+12VPOWER
220uF/16V
220uF/16V
DIMMING
BL_ON/OFF
CE204
CE204
2007-09-04 by
2
BST
MP2380
MP2380
1
SW
5
FB
GND
GND
4
9
R-CAPC1608N-HX
R-CAPC1608N-HX
J20 for 19inch, J21 for 22inch.J22
layout
Tony
DIMMING
CB1014
CB1014
0.1uF
0.1uF
BL_ON/OFF
OPCTRL5
22uH/POWER CHOKE
22uH/POWER CHOKE
1 2
+
+
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
change I/O PORT to ADIN2 AND ADIN3(BY TONY 2007-06-26)
+5V
+12V
OPCTRL3
5VCC
R15
R15
470
470
R-RESC1608N-HX
R-RESC1608N-HX
L6
L6
R-SLG12080-HX
R-SLG12080-HX
D44
D44
B540C
B540C
6
5
4
3
2
1
BL_ON/OFF
DIMMING
CB1 1000pFCB1 1000pF
CB3 1000pFCB3 1000pF
R-INDC2012N-HX
R-INDC2012N-HX
FB
FB
L560
L560
L558FBL558
FB
100uF/16V
100uF/16V
R1816 4.7kR1816 4.7k
1
M-TJC10-6A-HX
M-TJC10-6A-HX
6x1 W/HOUSING
6x1 W/HOUSING
DV33SB
CE16
CE16
1
PW_LED
Q104
Q104
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
5VCC
C1330
C1330
0.1UF
0.1UF
J20
J20
M-TJC10-6A-HX
M-TJC10-6A-HX
6x1 W/HOUSING
6x1 W/HOUSING
6
5
4
3
2
1
J21
J21
TO KEY BOARD
R1608 10KR1608 10K
ADIN2
R1795 10R1795 10
ADIN3
R1745 10KR1745 10K
PWR_IR
PW_LED
IR
R1796 10R1796 10
TO IR/LED BOARD
+
+
CB1015
CB1015
R1818
R1818
0.1uF
0.1uF
47k
47k
Q84
Q84
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
+
+
CE14
CE14
470uF/16V
470uF/16V
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
5VCC
220uF/16v
220uF/16v
M-TJC10-5A-HX
M-TJC10-5A-HX
5x1 W/HOUSING
5x1 W/HOUSING
5
4
3
2
1
J27
J27
U139
U139
1
S1
2
G1
3
S2
4
G2
IRF7316
IRF7316
R-SOIC08N-1.270-6.00-HX
R-SOIC08N-1.270-6.00-HX
5VCC
+
+
CE207
CE207
D1
D1
D2
D2
P-CH
P-CH
J11
J11
1
2
3
3x1 W/HOUSING
3x1 W/HOUSING
M-TJC10-3A-HX
M-TJC10-3A-HX
8
7
6
5
J26
J26
1
2
3
4
4x1 W/HOUSING
4x1 W/HOUSING
M-TJC3-4A-HX
M-TJC3-4A-HX
L559FBL559
FB
CE13
CE13
100uF/16V
100uF/16V
lvds power circuit(by tony 2007-07-17)
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
Size
Size
Size
Custom
Custom
Custom
Date: Sheet
Date: Sheet
D
Date: Sheet
panel_power
CB1016
CB1016
+
+
0.1uF
0.1uF
INDEX
INDEX
INDEX
Document Number
Document Number
Document Number
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
+12V2,10,12,13
+5V2,3,7,11,14
+5VCC2,7
DV33SB2,5,6,7
AV332,5,6
GND2,3,4,5,6,7,8,9,10,11,12,13,14
AGND_PLL2,3,4,5,6,7,8,9,10,11,12,13,14
AGND_AFE2,3,4,5,6,7,8,9,10,11,12,13,14
AGND_HDMI2,3,4,5,6,7,8,9,10,11,12,13,14
AGND_LVDS2,3,4,5,6,7,8,9,10,11,12,13,14
GLOBAL POWER
OPWRSB5
OPCTRL55
OIRI5
OPCTRL35
ADIN25
ADIN35
GND
AGND_AFE
A0P5
A0N5
A1P5
A1N5
A2P5
A2N5
CK1P5
CK1N5
A3P5
A3N5
A4P5
A4N5
A5P5
A5N5
A6P5
A6N5
CK2P5
CK2N5
A7P5
A7N5
OPWM15
OPCTRL45
OPCTRL4
AGND_LVDS2,3,4,5,6,7,8,9,10,11,12,13,14
LVDS SIGNAL
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
E
+12V
+5V
5VCC
DV33SB
AV33
GND
AGND_PLL
AGND_AFE
AGND_HDMI
AGND_LVDS
OPWRSB
OPCTRL5
OIRI
OPCTRL3
ADIN2
ADIN3
OPWM1
A0P
A0N
A1P
A1N
A2P
A2N
CK1P
CK1N
A3P
A3N
A4P
A4N
A5P
A5N
A6P
A6N
CK2P
CK2N
A7P
A7N
Drawn
Drawn
Drawn
Terry
Terry
Terry
AGND_LVDS
114Wednesday, September 05, 2007
114Wednesday, September 05, 2007
114Wednesday, September 05, 2007
Rev
Rev
Rev
1
1
1
of
of
of
Page 40
A
R1799 150/2WR1799 150/2W
U44
U44
IN
GND
3
MC7808
MC7808
R-TO3N-2.54-15.24-HX
R-TO3N-2.54-15.24-HX
OUT
2
CB225
CB225
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
1
+
+
CB1099
CE62
CE62
220uF/16V
220uF/16V
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
4 4
CB1099
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
8V +5V_TUNER+12V
CE612
CE612
220uF/16V
220uF/16V
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
R1800 5.1/1WR1800 5.1/1W
+
+
CB211
CB211
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
POWER SUPPLY +5V FOR TUNER
DV33_DM
510mA
U1
U1
IN3OUT
VOUT
ADJ
1
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
LT1117
LT1117
R-SOT4N-2.30-7.00-HX
R-SOT4N-2.30-7.00-HX
80mA
L3
L3
FB
FB
R-INDC2012N-HX
R-INDC2012N-HX
CB13
CB13
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
2
4
CE6
CE6
220uF/16V
220uF/16V
+3V3_TUNER
1.25 x (1+180/110) = 3.3V
POWER SUPPLY +3V3 FOR THOMSON TUNER
CHANGE THE PACKAGE OF U6 TO TO252-3L(2007-06-29)
+5V DV33_DM
+
CE19
+
CE19
3 3
220uF/16V
220uF/16V
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
DV33_DM DV18_DM
2 2
U6
U6
2
IN
CB18
CB18
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
U8
U8
3
CB22
CB22
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
U10
U10
3
CB26
CB26
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
ADJ/GND
1
IN
ADJ/GND
1
IN
ADJ/GND
1
3
OUT
LT1084 TO-252-3
LT1084 TO-252-3
R-TO3N-2.28-9.91-HX
R-TO3N-2.28-9.91-HX
2
OUT
4
out
AZ1117/adj
AZ1117/adj
R-SOT4N-2.30-7.00-HX
R-SOT4N-2.30-7.00-HX
2
OUT
4
out
AZ1117/adj
AZ1117/adj
R-SOT4N-2.30-7.00-HX
R-SOT4N-2.30-7.00-HX
600mA+CI
+
CE20
+
CE20
220uF/16V
220uF/16V
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
CB19
CB19
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
1.25 x (1+180/110) = 3.3V
POWER SUPPLY +3V3 FOR MT5131
+
+
CE27
CE27
R32
R32
270
270
R-RESC1608N-HX
R-RESC1608N-HX
R34
R34
120
120
R-RESC1608N-HX
R-RESC1608N-HX
220uF/16V
220uF/16V
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
1.25 x (1+120/270) = 1.8V
CB23
CB23
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
POWER SUPPLY +3V3 FOR MT5131
L10
L10
FB
FB
R-INDC2012N-HX
+
+
CE34
CE34
R36
R36
100uF/16V
100uF/16V
110
110
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
R-RESC1608N-HX
R-RESC1608N-HX
R38
R38
180
180
R-RESC1608N-HX
R-RESC1608N-HX
1.25 x (1+180/110) = 3.3V
R-INDC2012N-HX
CB27
CB27
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
STANDBY POWER +3V3 FOR MT5331
DV33SB5VCC
L1 FB
L1 FB
R-INDC2012N-HX
R-INDC2012N-HX
+
+
CB8
CB8
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
+
CE12
+
CE12
100uF/16V
100uF/16V
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
B
or +12V
+
+
CE8
CE8
470uF/16V
470uF/16V
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
CB9
CB9
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R19
R19
3K
3K
R-RESC1608N-HX
R-RESC1608N-HX
R21
R21
100K
100K
R-RESC1608N-HX
R-RESC1608N-HX
U5
U5
2
IN
CB16
CB16
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
C
U2
U2
AP1513/SOP-8
AP1513/SOP-8
R-SOIC08N-1.270-6.00-HX
R-SOIC08N-1.270-6.00-HX
4
C1
C1
NS/100nF
NS/100nF
R-CAPC1608N-HX
R-CAPC1608N-HX
3
Vcc
OCSET
EN
Vss7Vss
2
8
CB11
CB11
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
O/P
O/P
FB
6
27uH/POWER CHOKE
27uH/POWER CHOKE
5
R-SLF10145-HX
R-SLF10145-HX
1
D1
D1
SCHOTTKY DIODE/B340A
SCHOTTKY DIODE/B340A
R-SOD8162N-HX
R-SOD8162N-HX
POWER +1V2 FOR MT5331 (ANALOG)
DV33_DM
R-INDC2012N-HX
R-INDC2012N-HX
1.25 x (1+180/110) = 3.3V
L4
L4
FB
FB
300mA+CI
+
CE15
+
CE15
220uF/16V
220uF/16V
R-CAPAE-D8.0X10.2-HX
R-CAPAE-D8.0X10.2-HX
POWER SUPPLY +3V3 (DIGITAL) FOR MT5331
3
OUT
ADJ/GND
LT1084 TO-252-3
LT1084 TO-252-3
1
R-TO3N-2.28-9.91-HX
R-TO3N-2.28-9.91-HX
+
+
CE17
CE17
100uF/16V
100uF/16V
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
CB17
CB17
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
D
L2
L2
C2
C2
R20
R20
NS/100nF
NS/100nF
R-CAPC1608N-HX
R-CAPC1608N-HX
1.2K_1%
1.2K_1%
R-RESC1608N-HX
R-RESC1608N-HX
R22
R22
2K_1%
2K_1%
R-RESC1608N-HX
R-RESC1608N-HX
+
+
CE9
CE9
470uF/16V
470uF/16V
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
0.8 x (1+1.2K/2K) = 1.28V
POWER +1V2 FOR MT5331 (DIGITAL)
0.8 x (1+1.2K/2K) = 1.28V
DV33
CB15
CB15
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
AV33+5V
L5
L5
FB
FB
R-INDC2012N-HX
R-INDC2012N-HX
+
+
CE18
CE18
100uF/16V/ns
100uF/16V/ns
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
DV12+5V
CB10
CB10
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
L57
L57
R-INDC2012N-HX
R-INDC2012N-HX
10uH
10uH
CB202
CB202
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB131
CB131
CB25
CB25
4.7uF
4.7uF
0.1uF
0.1uF
R-CAPC2012N-HX
R-CAPC2012N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
CB201
CB201
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
AV12
+
CE98
+
CE98
100uF/16V
100uF/16V
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
E
+12V1,10,12,13
+5V1,3,7,11,14
+5VCC1,7
+5V_TUNER3
+3V3_TUNER3
DV33_DM4
DV18_DM4
DV335,6,7,12,14
AV331,5,6
DV26_DDR5,6,8
AV156
AV125,6
DV33SB1,5,6,7
GLOBAL POWER
GND1,3,4,5,6,7,8,9,10,11,12,13,14
AGND_AFE1,3,4,5,6,7,8,9,10,11,12,13,14
AGND_LVDS1,3,4,5,6,7,8,9,10,11,12,13,14
AGND_PLL1,3,4,5,6,7,8,9,10,11,12,13,14
+12V
+5V
5VCC
+5V_TUNER
+3V3_TUNER
DV33_DM
DV18_DM
DV33
AV33
DV26_DDR
AV15
AV12
DV33SB
GND
AGND_AFE
AGND_LVDS
AGND_PLL
1.25 x (1+180/110) = 3.3V
POWER SUPPLY +3V3 (ANALOG) FOR MT5331
CHANGE THE PACKAGE OF U5 TO TO252-3L(2007-06-29)
U7
U7
2
IN
CB20
CB20
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
3
OUT
ADJ/GND
LT1084 TO-252-3
LT1084 TO-252-3
1
R-TO3N-2.28-9.91-HX
R-TO3N-2.28-9.91-HX
R31
R31
+
+
110
110
R-RESC1608N-HX
R-RESC1608N-HX
R33
R33
120
120
R-RESC1608N-HX
R-RESC1608N-HX
CE24
CE24
100uF/16V
100uF/16V
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
1.25 x (1+120/110) = 2.6V
CB21
CB21
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
L7
L7
FB
FB
R-INDC2012N-HX
R-INDC2012N-HX
DV26_DDR+5V
+
CE25
+
CE25
100uF/16V
100uF/16V
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
POWER +2V6 FOR MT5331 / DDRI
AV33
1 1
U11
U11
3
IN
CB28
CB28
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
2
OUT
4
out
ADJ/GND
AZ1117/adj
AZ1117/adj
1
R-SOT4N-2.30-7.00-HX
R-SOT4N-2.30-7.00-HX
+
+
R39
R39
CE37
CE37
220uF/16V
220uF/16V
110
110
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
R-RESC1608N-HX
R-RESC1608N-HX
R40
R40
22
22
R-RESC1608N-HX
R-RESC1608N-HX
1.25 x (1+22/110) = 1.5V
CB29
CB29
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
AV15
POWER +1V5 FOR VIDEO FRONT-END1
A
B
CHANGE THE PACKAGE OF U7 TO TO252-3L(2007-06-29)
C
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
POWER
POWER
POWER
Document Number
Document Number
Document Number
Size
Size
Size
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
Custom
Custom
Custom
Date: Sheet
Date: Sheet
D
Date: Sheet
TEL:(03)567-0766 FAX:(03)578-7610
Drawn
Drawn
Drawn
E
Terry
Terry
Terry
Rev
Rev
Rev
1
1
1
of
214Wednesday, September 05, 2007
of
214Wednesday, September 05, 2007
of
214Wednesday, September 05, 2007
Page 41
A
B
C
D
E
+5V_TUNER
+3V3_TUNER
+5V
GND
IF_AGC
FAT_IN+
FAT_INTUNER_SCL1
TUNER_SDA1
CVBS0
MPX1
MPX2
AGND_AFE
SCT1_AV_OUT
CB207
CB207
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
GPIO_4
TUNER_SDAO
TUNER_SCLO
R45
R45
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
AV5
R41
R41
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
C48
C48
15pF/NS
15pF/NS
R-CAPC1608N-HX
R-CAPC1608N-HX
R1826 NS/0R
R1826 NS/0R
R-RESC1608N-HX
R-RESC1608N-HX
R1828 39K
R1828 39K
R-RESC1608N-HX
R-RESC1608N-HX
C949
C949
15pF
15pF
R-CAPC1608N-HX
R-CAPC1608N-HX
R1801
R1801
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
C6
C6
47nF
47nF
R-CAPC1608N-HX
R-CAPC1608N-HX
NTSC CVBS
C12
C12
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
SIF (4.5MHz)
CE619 47uF/16V
CE619 47uF/16V
C950
C950
15pF
15pF
R-CAPC1608N-HX
R-CAPC1608N-HX
TUNER_SDA1
TUNER_SCL1
CVBS0
MPX1
+
+
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
+5V AV5
L552
L552
FB
MPX2MONO
FB
R-INDC2012N-HX
R-INDC2012N-HX
+
CE613
+
CE613
100uF/16V
100uF/16V
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
+5V_TUNER
L12
L12
120-0805/NC
120-0805/NC
+
C15
+
C15
R-INDC2012N-HX
C3
C3
0.1uF/NC
0.1uF/NC
R-CAPC1608N-HX
R-CAPC1608N-HX
C4
R-RESC1608N-HX0/NC
R-RESC1608N-HX0/NC
C4
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
C7
C7
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
C13
C13
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R49
R49
0
0
R-RESC1608N-HX
R-RESC1608N-HX
R53
R53
0
0
R-RESC1608N-HX
R-RESC1608N-HX
4 4
3 3
U12
U12
Thomson 6640
Thomson 6640
V-ANT
V_Loop
AGC_OUT
RESET
CVBS
4MHz
IF_AGC
22
TH1
23
TH2
V_ANT
1
2
NC
V_1
3
4
NC
5
V_2
6
VCC
7
NC
8
VT
R47
R47
9
AS
SCL_1
10
SCL
SDA_1
11
SDA
12
NC
13
TUNER_SIF
14
SIF
15
V3.3
16
IF
TUNER_CVBS
17
18
IF_AGC_OUT
19
DIF1
20
DIF
DIF2
21
DIF
24
TH3
25
TH4
R-INDC2012N-HX
10uF/16V/NC
10uF/16V/NC
R-CAPC2012N-HX
R-CAPC2012N-HX
+5V_TUNER
L13
L13
120-0805
120-0805
C16
C16
R-INDC2012N-HX
R-INDC2012N-HX
+
+
10uF/16V
10uF/16V
R-CAPC2012N-HX
R-CAPC2012N-HX
+5V_TUNER
L14
L14
120-0805
120-0805
C17
C17
R-INDC2012N-HX
R-INDC2012N-HX
+
+
10uF/16V
10uF/16V
R-CAPC2012N-HX
R-CAPC2012N-HX
L15 2.2uH R-INDC2012N-HXL15 2.2uH R-INDC2012N-HX
L16 2.2uH R-INDC2012N-HXL16 2.2uH R-INDC2012N-HX
+3V3_TUNER
L17
L17
120-0805
120-0805
C18
C18
R-INDC2012N-HX
R-INDC2012N-HX
+
+
10uF/16V
10uF/16V
R-CAPC2012N-HX
R-CAPC2012N-HX
FAT_IN+
FAT_IN-
R-CAPC1608N-HX
R-CAPC1608N-HX
R48
R48
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
C14
C14
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C10
C10
10pF/NC
10pF/NC
TUNER_SCLO
TUNER_SDAO
C11
C11
10pF/NC
10pF/NC
R-CAPC1608N-HX
R-CAPC1608N-HX
IF_AGC
AVCVBS0
330pF/NCC8330pF/NC
C8
NEARLY TUNER NEARLY MT5331
R44
R44
75
75
R-RESC1608N-HX
R-RESC1608N-HX
TUNER_SIF
MONO
PHILIPS ONLY
R46
R46
75
75
R-RESC1608N-HX
R-RESC1608N-HX
CE618
CE618
+
+
22uF/10v
22uF/10v
R-CAPAE-D4.0X5.4-HX
R-CAPAE-D4.0X5.4-HX
C9
C9
47pF
47pF
R-CAPC1608N-HX
R-CAPC1608N-HX
R1835 0
R1835 0
R1827 39K
R1827 39K
R-RESC1608N-HX
R-RESC1608N-HX
+5V_TUNER2
+3V3_TUNER2
+5V1,2,7,11,14
GND1,2,4,5,6,7,8,9,10,11,12,13,14
IF_AGC4
FAT_IN+4
FAT_IN-4
TUNER_SCL14
TUNER_SDA14
TUNER INTERFACE
CVBS05
MPX15
MPX25
AGND_AFE1,2,4,5,6,7,8,9,10,11,12,13,14
TUNER - ANALOG OUTPUT
SCT1_AV_OUT10
SCART1 VIDEO OUTPUT
GPIO_45
+
CE614
+
CE614
100uF/16V
100uF/16V
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
THOMSON COMBO-TUNER
U9U9
AV5
P26
P26
16
GND
17
GND
15
2 2
Philips FQD1216ME MK5
Philips FQD1216ME MK5
M-PHILIPS-FQ1216LME(MK5)-F-HX
M-PHILIPS-FQ1216LME(MK5)-F-HX
1 1
AGC MONITOR (NC)
ANT SUPPLY (+5V)
IF AGC
AS TUNER
AS IF
2ND IF SOUND
CVBS
+5V IF
AF/MPX
gnd
+5V
SCL
SDA
DIF
DIF
GND
GND
GND21GND22GND
20
RFAGC_OUT
1
2
3
4
5
6
7
8
R800 NS
R800 NS
9
R801 NS
R801 NS
10
11
TUNER_CVBS
12
13
14
18
19
SCL_1
SDA_1
IF_AGC_OUT
TUNER_SIF
MONO
V_ANT
V_2
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
TP61TP61
DIF2
DIF1
C705
C705
NS/0.1uF
NS/0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
Philips COMBO-TUNER
A
L107
L107
NS/120
NS/120
R-INDC2012N-HX
R-INDC2012N-HX
CE91
CE91
+
+
NS/100uF/16V
NS/100uF/16V
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
+5V_TUNER
+5V_TUNER
GPIO_4
DC-Block
Q45
Q45
NS/PMOS
1
NS/PMOS
2 3
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
R1829
R1829
NS/10K
NS/10K
R1831
R1831
NS/470
NS/470
Q111
Q111
NS/2N3904
NS/2N3904
2 3
1
L562 NS/FBL562 NS/FB
C953
C953
NS/10nF
NS/10nF
R1832 NS/10KR1832 NS/10K
R1834
R1834
NS/10K
NS/10K
C191
C191
NS/10uF/10v
NS/10uF/10v
C955
C955
NS/0.1u
NS/0.1u
MODIFY THIS CIRCUIT (TONY 2007-07-03)
B
+5V_TUNER_TEST
C954
C954
NS/10nF
NS/10nF
R1830
R1830
NS/6.8
NS/6.8
V_ANT
C
TUNER_CVBS
L18
L18
2.2uH/0R
2.2uH/0R
R-INDC2012N-HX
R-INDC2012N-HX
3
C
NPN
MMBT3904
1
C19 220uF/25V
C19 220uF/25V
EB
2
+
+
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
R56
R56
3.3K
3.3K
R-RESC1608N-HX
R-RESC1608N-HX
R59
R59
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R66R66
R91R91
R98R98
R110R110
R112R112
Q4
Q4
R57
R57
1
10
10
R-RESC1608N-HX
R-RESC1608N-HX
R61
R61
1
Q5
Q5
10
10
R-RESC1608N-HX
R-RESC1608N-HX
DIff98+58
DIff98-58
DIff98+612
DIff98-612
single56
D
AV5
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
CB24 470uF/16V
CB24 470uF/16V
R60
R60
75
75
R-RESC1608N-HX
R-RESC1608N-HX
AV5
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
R62
R62
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R67R67
R68R68
R92R92
R94R94
R111R111
+
+
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
R54
R54
0/NC
0/NC
R-RESC1608N-HX
R-RESC1608N-HX
R58
R58
75
75
R-RESC1608N-HX
R-RESC1608N-HX
AVCVBS0
R55
R55
0/NC
0/NC
R-RESC1608N-HX
R-RESC1608N-HX
SCT1_AV_OUT
MediaTek Confidential
MediaTek Confidential
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
TUNER
TUNER
TUNER
Document Number
Document Number
Document Number
Size
Size
Size
Custom
Custom
Custom
Date: Sheet
Date: Sheet
Date: Sheet
MediaTek Confidential
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
U20U20
U4U4
U21U21
U22U22
U26U26
U25U25
U24U24
U38U38
S5
S5
S4
S4
S1
S1
S3
S3
S6
S6
1
1
1
1
1
2
2
2
2
2
3
3
3
3
3
4
4
4
4
4
5
5
5
5
5
6
6
6
6
6
7
7
7
7
7
8
8
8
8
8
9
9
9
9
9
CONN TRBLK 9
CONN TRBLK 9
CONN TRBLK 9
CONN TRBLK 9
CONN TRBLK 9
CONN TRBLK 9
CONN TRBLK 9
CONN TRBLK 9
CONN TRBLK 9
CONN TRBLK 9
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
E
Drawn
Drawn
Drawn
1
2
3
4
Terry
Terry
Terry
FM1FM1
FM2FM2
FM3FM3
FM4FM4
FM5FM5
FM6FM6
FM7FM7
MM
11
22
U27
U27
4x1 W/HOUSING
4x1 W/HOUSING
PCBCOMPONENT_1
PCBCOMPONENT_1
314Wednesday, September 05, 2007
314Wednesday, September 05, 2007
314Wednesday, September 05, 2007
of
of
of
M1M1
33
44
Rev
Rev
Rev
1
1
1
Page 42
A
4 4
R64
Y1
Y1
27MHz
27MHz
R-CRYC1405N-HX
3 3
DV18_DM
L21FBR-INDC2012N-HX
L21FBR-INDC2012N-HX
CB1100
CB1100
0.1uF
0.1uF
CB1102
CB1102
0.1uF
0.1uF
CB1104
CB1104
0.1uF
0.1uF
DV33_DM
DV33_DM
2 2
CB1101
CB1101
0.1uF
0.1uF
L22FBR-INDC2012N-HX
L22FBR-INDC2012N-HX
CB1103
CB1103
0.1uF
0.1uF
L23FBR-INDC2012N-HX
L23FBR-INDC2012N-HX
CB1105
CB1105
0.1uF
0.1uF
+
+
+
+
+
+
DVDD18
CE39
CE39
10uF/16V
10uF/16V
R-CAPC2012N-HX
R-CAPC2012N-HX
CE40
CE40
10uF/16V
10uF/16V
R-CAPC2012N-HX
R-CAPC2012N-HX
CE41
CE41
10uF/16V
10uF/16V
R-CAPC2012N-HX
R-CAPC2012N-HX
CB33
CB33
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DVDD33
CB38
CB38
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
AVDD33 ADVDD33_1AVDD33
CB44
CB44
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CRYC1405N-HX
DVDD18
CB34
CB34
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
Digital 1.8V Bypass Caps
DVDD33
CB39
CB39
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
Digital 3.3V Bypass Caps
AVDD33
CB45
CB45
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R64
1M
1M
R-RESC1608N-HX
R-RESC1608N-HX
CB35
CB35
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB40
CB40
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB46
CB46
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
B
CB36
CB36
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB41
CB41
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB47
CB47
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
C28
C28
27pF
27pF
R-CAPC1608N-HX
R-CAPC1608N-HX
C29
C29
27pF
27pF
R-CAPC1608N-HX
R-CAPC1608N-HX
TP45TP45
TS0INDATA7
TS0INDATA6
TS0INDATA5
TS0INDATA4
CB37
CB37
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB42
CB42
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB1106
CB1106
CB48
CB48
0.1uF
0.1uF
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
RN1
RN1
33x4
33x4
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
CB43
CB43
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
L24
L24
FB
FB
R-INDC1608N-HX
R-INDC1608N-HX
45
36
27
18
AVDD33
AVDD33
DVDD18
DVDD33
CB49
CB49
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
FAT_IN-
FAT_IN+
C27
C27
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
C20 1nF
C20 1nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C21 1nF
C21 1nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C23
C23
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
C25
C25
10uF
10uF
R-CAPC2012N-HX
R-CAPC2012N-HX
U13
U13
1
AVDD4
2
AVSS4
3
LOOUT+
4
AVSS1
5
XTALI
6
XTALO
7
AVDD1
8
ALC_IN
9
VDD1.8
10
DGND1.8
11
TSDATA7
12
TSDATA6
13
TSDATA5
14
VDD3.3
15
DGND3.3
16
TSDATA4
RN2
RN2
33x4
33x4
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
C
L20
L20
NS/220nH
NS/220nH
R-INDC2012N-HX
R-INDC2012N-HX
C22
C22
NS/47pF
NS/47pF
C24
C24
R-CAPC1608N-HX
R-CAPC1608N-HX
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
AVDD33
AVDD33
DVDD18
ADVDD33_1
TUNER_SCL
TUNER_SDA
55
54
VDD1.8
ADVDD3.3
DVDD33
52
53
DGND1.8
TUNER_SCL
SIF_SCL_DM
DVDD18
MT5131_IF_AGC
49
51
50
IF_AGC
RF_AGC
TUNER_SDA
CLK_OUT
TESTMODE1
TESTMODE0
XTAL_SEL
32
SIF_SDA_DM
DVDD33
REFTOP
REFBOT
VCMEXT
64
63
VCMEXT
REF_TOP
TSDATA317TSDATA218TSDATA119TSDATA020TSERR21TSVAL22TSSYNC23TSCLK24/IRQ25VDD3.326DGND3.327DGND1.828VDD1.829HOST_SCL30HOST_SDA31VDD3.3
45
TS0INDATA2
TS0INDATA3
61
60
62
AVSS2
AVDD2
REFBOT
MT5131_64-PIN
MT5131_64-PIN
45
182736
GPIO_18
TS0INDATA0
TS0INDATA1
56
57
58
59
IN-
IN+
AVSS3
AVDD3
182736
RN3
RN3
33x4
33x4
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
TS0INVALID
TS0INSYNC
TS0INCLK
VDD3.3
CLK_SEL
SLEEP
/RESET
DGND3.3
VDD3.3
DGND1.8
VDD1.8
LOCK
D
R63
R63
1K
1K
R-RESC1608N-HX
R-RESC1608N-HX
CLOSE TO MT5131
IF_AGCMT5131_IF_AGC
C26
C26
47nF
47nF
R-CAPC1608N-HX
R-CAPC1608N-HX
+5V_TUNER2,3
DV33_DM2
DV18_DM2
GND1,2,3,5,6,7,8,9,10,11,12,13,14
IF_AGC3
FAT_IN+3
FAT_IN-3
TUNER_SCL13
TUNER_SDA13
E
GLOBAL SIGNAL
+5V_TUNER
DV33_DM
DV18_DM
GND
IF_AGC
FAT_IN+
FAT_INTUNER_SCL1
TUNER_SDA1
TUNER INTERFACE
TS0INDATA[0..7]14
DVDD33
CB32
CB32
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R69
R69
0
0
R-RESC1608N-HX
R-RESC1608N-HX
R70
R70
0
0
R-RESC1608N-HX
R-RESC1608N-HX
R396 22R396 22
R397 22R397 22
CB30
CB30
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
TUNER_SDA1
TUNER_SCL1
SIF_SDASIF_SDA_DM
SIF_SCL
R65 4.7K
R65 4.7K
SLEEP
GPIO_0
DVDD33
DVDD33
DVDD18
R1802
R1802
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
TUNER_SDA
TUNER_SCL
C133
C133
22pF
22pF
R-RESC1608N-HX
R-RESC1608N-HX
TP9TP9
DVDD33
SIF_SCL_DM
C134
C134
22pF
22pF
48
47
SA2
46
SA1
45
SA0
44
43
42
41
40
39
38
37
36
35
34
33
TS0INSYNC14
TS0INVALID14
TS0INCLK14
GPIO_185
TS INPUT(modify by tony 2007-06-23)
SIF_SDA7,12
SIF_SCL7,12
GPIO_05,7,12
DVDD3313
TS0INDATA[0..7]
TS0INSYNC
TS0INVALID
TS0INCLK
GPIO_18
SIF_SDA
SIF_SCL
GPIO_0
DVDD33
Analog 3.3V Bypass Caps
1 1
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
MT5131 ASIC
MT5131 ASIC
MT5131 ASIC
Document Number
Document Number
Document Number
Size
Size
Size
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
Custom
Custom
Custom
Date: Sheet
Date: Sheet
A
B
C
D
Date: Sheet of
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
Drawn
Drawn
Drawn
Terry
Terry
Terry
of
of
414Wednesday, September 05, 2007
414Wednesday, September 05, 2007
E
414Wednesday, September 05, 2007
Rev
Rev
Rev
1
1
1
Page 43
5
TP54TP54
TP12TP12
TP16TP16
GPIO_0
GPIO_1
GPIO_6
GPIO_4
GPIO_8
B12
C12
D12
A13
B13
C13
D13
U15
U15
D D
RA0
D1
RA0
RA1
A2
RA1
RA2
D2
RA2
RA3
B4
RA3
RA4
C1
RA4
RA5
A3
RA5
RA6
C2
RA6
RA7
B5
RA7
RA8
B1
RA8
RA9
A4
RA9
RA10
B3
RA10
RA11
B2
RA11
RA12
A5
RA12
RA13
A1
RA13
RWE#
D3
RWE_
RCAS#
C5
RCAS_
RRAS#
C4
RRAS_
RCS#
D5
RCS_
RCKE
E1
RCKE
RCLK0
L1
RCLK0
RCLK0#
L2
RCLK0_
A11
RCLK1
B11
RCLK1_
RBA0
D4
RBA0
RBA1
C3
RBA1
E2
RODT
RVREF
D8
RVREF
RVREF
F4
RVREF
RESTUP
L4
REXTUP
RESTDN
M1
REXTDN
RDQS0
G1
RDQS0
G2
RDQS0_
RDQM0
F3
RDQM0
RDQ0
G4
RDQ0
RDQ1
F1
RDQ1
RDQ2
H1
RDQ2
RDQ3
E4
RDQ3
RDQ4
E3
RDQ4
RDQ5
H2
RDQ5
RDQ6
F2
RDQ6
RDQ7
C C
B B
A A
G3
RDQ7
RDQS1
J4
RDQS1
J3
RDQS1_
RDQM1
K1
RDQM1
RDQ8
K3
RDQ8
RDQ9
J1
RDQ9
RDQ10
K4
RDQ10
RDQ11
H4
RDQ11
RDQ12
H3
RDQ12
RDQ13
L3
RDQ13
RDQ14
J2
RDQ14
RDQ15
K2
RDQ15
B10
RDQS2
A10
RDQS2_
C10
RDQM2
C9
RDQ16
C11
RDQ17
B9
RDQ18
D11
RDQ19
A12
RDQ20
A9
RDQ21
D10
RDQ22
D9
RDQ23
B7
RDQS3
A7
RDQS3_
C7
RDQM3
C6
RDQ24
A8
RDQ25
B6
RDQ26
B8
RDQ27
C8
RDQ28
A6
RDQ29
D7
RDQ30
D6
RDQ31
POCE0#
U3
POCE0_
U1
POCE1_
T4
POCE2_
POOE0#
U2
POOE0_
POWE#
AC1
POWE_
PDD0
V1
PDD0
PDD1
V2
PDD1
PDD2
V3
PDD2
PDD3
V4
PDD3
PDD4
W1
PDD4
PDD5
W2
PDD5
PDD6
W3
PDD6
PDD7
W4
PDD7
PDA0
Y1
PDA0
PDA1
U4
PDA1
PDA2
AE3
PDA2
PDA3
AE2
PDA3
PDA4
AE1
PDA4
PDA5
AD4
PDA5
PDA6
AD3
PDA6
PDA7
AD2
PDA7
PDA8
AD1
PDA8
PDA9
AB2
PDA9
PDA10
AB1
PDA10
PDA11
AA4
PDA11
PDA12
AA3
PDA12
PDA13
AA2
PDA13
PDA14
AA1
PDA14
PDA15
Y4
PDA15
PDA16
Y3
PDA16
PDA17
Y2
PDA17
PDA18
AC4
PDA18
PDA19
AC3
PDA19
PDA20
AB3
PDA20
PDA21
AB4
PDA21
PDA22
AC2
PDA22
PDCTRLVPP
P3
PDCTRLVPP
PDVS1#
N1
PDVS1
PDVS2#
P4
PDVS2
PDENPOD
T3
PDENPOD
PDCE1#
M3
PDCE1_
PDCE2#
M4
PDCE2_
PDOE#
N2
PDOE_
PDWE#
P1
PDWE_
PDIREQ#
P2
PDIREQ_
PDIOIS16#
T1
PDIOIS16_
PDCD1#
M2
PDCD1_
PDCD2#
T2
PDCD2_
PDIORD#
N3
PDIORD_
PDIOWR#
N4
PDIOWR_
PDRESET
R1
PDREST
PDWAIT#
R2
PDWAIT_
PDINPACK#
R3
PDINPACK_
PDREG#
R4
PDREG_
MT5331 R-BGA588(488+100)-31.0X31.0-1.00-0.60-HX
MT5331 R-BGA588(488+100)-31.0X31.0-1.00-0.60-HX
A14
GPIO_0
GPIO_1
GPIO_2
GPIO_3
GPIO_4
GPIO_5
GPIO_6
GPIO_7
DDR DRAM NAND FLASH/NOR FLASH POD
DDR DRAM NAND FLASH/NOR FLASH POD
ATA/CF/MS/SD/XD SDIO SIF
ATA/CF/MS/SD/XD SDIO SIF
IDD8
IIORDY
IDD9
IDD10
IDD11
IINTRQ
AJ2
AF1
AF2
AF3
AF4
AE4
GPIO_19
GPIO_18
GPIO_17
GPIO_16
JTAG_TDI
JTAG_TMS
JTAG_RST#
JTAG_TDO
JTAG_TCK
JTAG_RTCK
GPIO_12
B14
C14
D14
A15
B15
N27
M27
M28
M29
U27
T27
R27
GPIO_8
GPIO_9
GPIO_10
GPIO_11
GPIO_12
GPIO_13
GPIO_14
GPIO_15
GPIO_16
GPIO_17
GPIO_18
GPIO_19
GPIO JTAG LVDS
GPIO JTAG LVDS
IDD12
IDD13
IDIOW_
IDA1
IDD14
IDD15
IDIOR_
IDA2
IDA0
ICS1_
ICS0_
IRESET_
AJ1
AJ3
AK3
AK2
AK1
AH2
AH1
AH3
AG1
AG2
AG3
AG4
5
A0N
B16
D16
D15
A16
C16
C15
P27
JTDI
JTCK
JTDO
JTMS
JRTCK
JTRST_
GPIO_20
SMCE_
SDIOCMD
SDIOD0
SDIOCLK
MDATA1
MDATA0
DCLK
MCLK
AJ4
AJ5
AK5
AK4
AK6
AH4
AH5
AG5
SMCE#
DCLK
MCLK
A4P
A4N
A1P
A1N
A2P
A5N
A5P
A2N
CK1P
CK1N
A3P
A0P
A3N
B20
B17
D17
B18
D18
B19
B21
A20
A17
C17
A18
C18
A19
A21
A0P
A4P
A1P
A5P
A2P
A3P
A0N
A4N
A1N
A5N
A2N
A3N
CK1P
CK1N
SDIOD1
SDIOD2
SDIOD3
OSCL1
OSDA1
OSDA0
OSCL0
OWRP2
OSCL2
OSDA2
AJ8
AJ9
AK7
AK9
AH6
AH8
AH9
AG6
AG8
AG9
OSCL1
OSDA1
OSCL0
OSDA0
A6N
A6P
TP3
AVCC_VPLL
LVDDA
TN3
CK2N
CK2P
A7P
A7N
D20
D19
D21
A23
B24
D24
C23
D23
C20
C19
C21
B23
TP3
A6P
A7P
TN3
A6N
A7N
CK2P
CK2N
LVDDA
AVSS_VPLL
AVCC_VPLL
PWM
IR
PWM
IR
OIRO
OPWM2
OPWM1
OPWM0
PWR5V
EXT_RES
RXCB
OIRI
AJ6
AJ7
AK8
AH7
AG7
AJ11
AJ17
AK10
AK11
OIRI
PWR5V
OPWM0
OPWM1
RXCB
RXC
EXT_RES
TP28TP28
4
TP10TP10
DACVREF
DACFS
DACVDD
DACVDD
A24
DACVREF
HDMI RX
HDMI RX
RX2B
RX2
AJ14
AK14
RX2B
RX2
DACVDD
A26
A25
B27
B28
A28
D25
C25
B25
A27
C24
B
R
G
FS
SVM
DACVSSB
DACVSSA
DACVSSC
DACVDDB
DACVDDA
VIDEO DAC
VIDEO DAC
OUT
OUT
MT5331
MT5331
PGND
PVCC
AVSS_HC
AVCC_HC
AVSS_H0
AVCC_H0
AVSS_H1
AVCC_H1
AVCC_H2
AH10
AH11
AH12
AH13
AH14
AG10
AG11
AG12
AG13
PVCC
AVCC_H
AVCC_H
AVCC_H
AVCC_H
4
LVDDB
LVDDC
A22
C22
B22
D22
LVSSA
LVSSB
LVSSC
LVDDB
LVDDC
RXC
RX0B
RX0
RX1B
RX1
AJ12
AJ13
AK12
AK13
RX1B
RX1
RX0B
RX0
I2SIN_DATA
ASPDIF
AO1LRCK
AO1BCK
AO1MCLK
U0TX
C27
AG17
D27
AG18
B26
C26
D26
U2TX
U0TX
U2RX
U0RX
U2CTS
U2RTS
DACVDDC
UART AUDIO OUTPUT TS INPUT IEEE 1394 PHY I/O
UART AUDIO OUTPUT TS INPUT IEEE 1394 PHY I/O
PWR
PWR
CVCC12
AVSS_H2
OPCTRL4
OPCTRL5
OPCTRL0
OPCTRL1
OPCTRL2
OPCTRL3
OPWRSB
AJ10
AJ16
AK16
AK17
AH15
AH16
AG14
AG15
AG16
OPCTRL4
OPCTRL3
OPCTRL0
OPCTRL2
OPCTRL6
OPCTRL5
OPWRSB U0RX
CVCC12
OPCTRL1
TP56TP56
TP55TP55
AO1SDATA3
J28
J29
L28
H27
K30
J27
L30
L29
J30
ALIN
AOBCK
ASPDIF
AOLRCK
AOMCLK
AOSDATA0
AOSDATA1
AOSDATA2
AOSDATA3
SERVO ADC
SERVO ADC
INPUT
INPUT
OPCTRL6
OPCTRL7
ORESET_
PWM2VREF
ADIN0
C_XREG
XREGVSS
XREGVDD
AJ15
AJ18
AF18
AK15
AK19
AH17
AH19
AH18
OPCTRL7
ORESET#
XREGVDD
PWM2VREF
C_XREG
ADIN0
TS0DATA1
TS0DATA2
TS0DATA3
TS0DATA4
TS0DATA5
TS0DATA6
TS0DATA7
TS0VALID
TS0CLK
TS0SYNC
TS0DATA0
AO1SDATA4
H29
H28
F30
G30
F27
F28
F29
T0CLK
T0VALID
T0DATA0
T0DATA1
T0DATA2
T0DATA3
DIGITAL VIDEO
DIGITAL VIDEO
INPUT
INPUT
XTALI
XTALO
AVSS_XTAL
AVCC_XTAL
VID0
VIVCLK
AJ21
AJ23
AK20
AK21
AH23
AG23
OXTALO
AVCC_XTAL
G29
H30
G27
G28
T0SYNC
T0DATA4
T0DATA5
T0DATA6
T0DATA7
VID3
VID4
VID5
VID6
VID1
VID2
AJ22
AK22
AK23
AH22
AG21
AG22
L27
M30
K28
K29
K27
AO2BCK
AO2LRCK
AO2MCLK
AOSDATA4
AO2SDATA0
AVCC_SRV
ADIN2
ADIN1
ADIN4
ADIN3
AVSS_SRV
AJ19
AJ20
AK18
AH20
AH21
AG19
AG20
OXTALI
AVCC_SRV
ADIN2
ADIN3
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
EDATA1
EDATA2
EDATA0
B29
B30
C29
EDATA0
EDATA1
EDATA2
AVSS_HDMIPLL
VID7
AG24
3
R9310K
R9310K
10K
10K
R50
R50
GPIO_79 14
GPIO_80 14
EDATA4
EDATA5
EDATA3
C30
D29
EDATA3
EDATA4
AVCC_HDMIPLL
AVCC_PSCANPLL
AJ24
AH24
AVCC_HDMIPLL
AVCC_DMPLL
AVCC_PSCANPLL
AV33
EDATA7
GPIO_79
EDATA6
GPIO_80
C28
A29
D28
E28
A30
E27
D30
E29
E30
ELPS
ECLK
ELREQ
ECNTL0
ECNTL1
EDATA5
EDATA6
EDATA7
ELINKON
AVCC_DMPLL
AVCC_CPUPLL
AVSS_PSCANPLL
AVSS_DMPLL
AVSS_SYSPLL
TN0
TP0
AVSS_ADCPLL
AVSS_B2RPLL
AJ25
AF27
AE27
AK24
AK25
AH25
AD27
AG25
AG26
AG27
TP0
TN0
AVCC_CPUPLL
3
AVCC_ADCPLL
AVSS_CPUPLL
AVSS_APLL
AH27
AD28
AVCC_APLL
AVSS_APLL
AVCC_ADCPLL
E6
VCC2IOE5VCC2IO
FB_IN
AVCC_APLL
AVCC_B2RPLL
AVCC_SYSPLL
AF28
AH26
AH28
AG28
FB_INGNSOGRPRN
AVCC_B2RPLL
AVCC_SYSPLL
E10
VCC2IOE7VCC2IOE8VCC2IOE9VCC2IO
VSYNC
HSYNC
AJ26
AK26
VSYNC
HSYNCBNGP
BP
E11
VCC2IO
E12
VCC2IO
VCC2IOF5VCC2IOF6VCC2IOF8VCC2IOF9VCC2IO
SOG
AJ29
VCC2IOF7VCC2IO
GN
RP
AJ28BNAJ27
AK29
AK30GPAK28BPAK27
F10
F11
F12
G6
VCC2IO
VCC2IO
VCC2IOG5VCC2IOH5VCC2IOH6VCC2IOJ5VCC2IOJ6VCC2IOK5VCC2IOK6VCC2IOL5VCC2IOL6VCC2IOM5VCC2IO
ANALOG VIDEO INPUT
ANALOG VIDEO INPUT
SOY0
Y0N
RN
Y0P
SOY1
PR0N
PR0P
PB0N
PB0P
AJ30
AF29
AF30
AE28
AE30
AH29
AH30
AG29
AG30
Y1P
SOY1
Y0P
PR0P
Y0N
PB0P
PB0N
SOY0
PR0N
Y1P
AE29
Y1N
RESERVE HEAT-SINK SPACE
DV26_DDR DV33
M6
VCC3ION5VCC3ION6VCC3IOP5VCC3IOP6VCC3IOR5VCC3IOR6VCC3IO
CVBS1
CVBS0
CVBS3
CVBS2
SC0
SY0
SC1
SY1
SC2
SY2
TN1
PR1N
PR1P
PB1N
PB1P
Y1N
AB29
AB30
AC29
AC30
AD29
AD30
PB1N
PB1P
PR1P
PR1N
TP1
V29
V30
Y29
Y30
W29
W30
AA29
AA30
AC27
AC28
CVBS0
CVBS1
SC0
SY0
SC1
TP1
TN1
CVBS2
SY1
2
DV332,6,7,12,14
AV331,2,6
DV26_DDR2,6,8
AV122,6
E16
E17
E18
F16
F17
F18
L26
M26
N26
P26
AF6
AF7
AF8
AF9
VCC3IO
VCC3IO
VCC3IO
VCC3IO
VCC3IO
VCC3IO
VCC3IO
VCC3IO
VCC3IO
VCC3IO
VCC3IO
VCC3IO
VCC3IO
DV12
E13
VCCK
E14
VCCK
E15
VCCK
F13
VCCK
F14
VCCK
F15
VCCK
T5
VCCK
T6
VCCK
U5
VCCK
U6
VCCK
V5
VCCK
V6
VCCK
F26
VCCK
G26
VCCK
H26
VCCK
J26
VCCK
K26
VCCK
AF15
VCCK
AF16
VCCK
AF17
VCCK
AF19
VCCK
AF20
VCCK
L11
GND
L12
GND
L13
GND
L14
GND
L15
GND
L16
GND
L17
GND
L18
GND
L19
GND
L20
GND
M11
GND
M12
GND
M13
GND
M14
GND
M15
GND
M16
GND
M17
GND
M18
GND
M19
GND
M20
GND
N11
GND
N12
GND
N13
GND
N14
GND
N15
GND
N16
GND
N17
GND
N18
GND
N19
GND
N20
GND
P11
GND
P12
GND
P13
GND
P14
GND
P15
GND
P16
GND
P17
GND
P18
GND
P19
GND
P20
GND
R11
GND
R12
GND
R13
GND
R14
GND
R15
GND
R16
GND
R17
GND
R18
GND
R19
GND
R20
GND
T11
GND
T12
GND
T13
GND
T14
GND
T15
GND
T16
GND
T17
GND
T18
GND
T19
GND
T20
GND
U11
GND
U12
GND
U13
GND
U14
GND
U15
GND
U16
GND
U17
GND
U18
GND
U19
GND
U20
GND
V11
GND
V12
GND
V13
GND
V14
GND
V15
GND
V16
GND
V17
GND
V18
GND
V19
GND
V20
GND
W11
GND
W12
GND
W13
GND
W14
GND
W15
GND
W16
GND
W17
GND
W18
GND
W19
GND
W20
GND
Y11
GND
Y12
GND
Y13
GND
Y14
GND
Y15
GND
Y16
GND
Y17
GND
Y18
GND
Y19
GND
Y20
GND
AL1
R30
AL1
AR1
R29
AR1
P30
AL2
P29
AR2
AVCC_ADAC
R28
AVCC0_ADAC
N28
AVSS0_ADAC
AVCC_ADAC
N30
AVCC1_ADAC
N29
AVSS1_ADAC
ADAC_VCM
P28
DAC
DAC
ADAC_VCM
AUDIO
AUDIO
AVCC_DV33
ADC
ADC
AUDIO
AUDIO
AVCC_VFE0
AVCC_VAD0
AVCC_VAD1
AVCC_VFE1
AVCC_AV33
AVSS_VFE0
AVSS_VAD0
AVSS_VAD1
AVSS_VFE1
TN2
TP2
U29
U30
TP2
TN2
AVSS_AV33
V27
Y27
V28
Y28
W27
W28
AA27
AA28
AB28
AB27
AVCC_VAD0
AVCC_VAD0
AVCC_VAD1
AVCC_VAD1
AVCC_AV33
2
MPX1
T30
MPX1
MPX2
T29
MPX2
AVCC_AADC
U28
AVCC _AADC
T28
AVSS_AADC
R26
DV33SB1,2,6,7
GND1,2,3,4,6,7,8,9,10,11,12,13,14
GLOBAL POWER
TS0DATA[0..7]14
TS0SYNC14
TS0VALID14
TS0CLK14
TS INPUT(modify by tony 2007-06-23)
AVCC_HDMIPLL2,6
AVCC_PSCANPLL2,6
AVCC_DMPLL2,6
AVCC_CPUPLL2,6
AVCC_ADCPLL2,6
AVCC_SYSPLL2,6
AVCC_B2RPLL2,6
AVCC_APLL2,6
TP06
TN06
AGND_PLL1,2,3,4,6,7,8,9,10,11,12,13,14
PLL POWER
AVCC_VAD06
AVCC_VAD16
AVCC_AV336
AVCC_AADC6
AVCC_ADAC6
ADAC_VCM6
TP16
TN16
TP26
TN26
AGND_AFE1,2,3,4,6,7,8,9,10,11,12,13,14
ANALOG FRONT-END POWER
AVCC_H6
PVCC6
CVCC126
EXT_RES6
AGND_HDMI1,2,3,4,6,7,8,9,10,11,12,13,14
HDMI POWER
LVDDA6
LVDDB6
LVDDC6
AVCC_VPLL6
TP36
TN36
AGND_LVDS1,2,3,4,6,7,8,9,10,11,12,13,14
LVDS POWER
DACVDD6
DACFS6
DACVREF6
AGND_LVDS1,2,3,4,6,7,8,9,10,11,12,13,14
VIDEO DAC POWER
AVCC_SRV1,2,6,7
XREGVDD1,2,6,7
AVCC_XTAL1,2,6,7
C_XREG6
PWM2VREF6
POOE0#7
POCE0#7
POWE#7
PDD[0..7]7,14
PDA[0..22]7,14
NOR FLASH(modify by tony,2007-06-23)
JTAG_RST#7
JTAG_TDI7
JTAG_TMS7
JTAG_TCK7
JTAG_RTCK7
JTAG_TDO7
JTAG
A0P1
A0N1
A1P1
A1N1
A2P1
A2N1
CK1P1
CK1N1
A3P1
A3N1
A4P1
A4N1
A5P1
A5N1
A6P1
A6N1
CK2P1
CK2N1
A7P1
A7N1
LVDS SIGNAL
ADIN010
ADIN21
ADIN31
DV33
EDATA[0..7]14
PDCTRLVPP14
PDVS1#14
PDVS2#14
PDENPOD14
PDCE1#14
PDCE2#14
PDOE#14
PDWE#14
PDIREQ#14
PDIOIS16#14
PDCD1#14
PDCD2#14
PDIORD#14
PDIOWR#14
PDRESET14
PDWAIT#14
PDINPACK#14
PDREG#14
PCMCIA INTERFACE( added by tony 2007-06-23)
DV33
AV33
DV26_DDR
AV12
DV33SB
GND
TS0DATA[0..7]
TS0SYNC
TS0VALID
TS0CLK
AVCC_HDMIPLL
AVCC_PSCANPLL
AVCC_DMPLL
AVCC_CPUPLL
AVCC_ADCPLL
AVCC_SYSPLL
AVCC_B2RPLL
AVCC_APLL
TP0
TN0
AGND_PLL
AVCC_VAD0
AVCC_VAD1
AVCC_AV33
AVCC_AADC
AVCC_ADAC
ADAC_VCM
TP1
TN1
TP2
TN2
AGND_AFE
AVCC_H
PVCC
CVCC12
EXT_RES
AGND_HDMI
LVDDA
LVDDB
LVDDC
AVCC_VPLL
TP3
TN3
AGND_LVDS
DACVDD
DACFS
DACVREF
AGND_LVDS
AVCC_SRV
XREGVDD
AVCC_XTAL
C_XREG
PWM2VREF
POOE0#
POCE0#
POWE#
PDD[0..7]
PDA[0..22]
JTAG_RST#
JTAG_TDI
JTAG_TMS
JTAG_TCK
JTAG_RTCK
JTAG_TDO
A0P
A0N
A1P
A1N
A2P
A2N
CK1P
CK1N
A3P
A3N
A4P
A4N
A5P
A5N
A6P
A6N
CK2P
CK2N
A7P
A7N
ADIN0
ADIN2
ADIN3
EDATA[0..7]
PDCTRLVPP
PDVS1#
PDVS2#
PDENPOD
PDCE1#
PDCE2#
PDOE#
PDWE#
PDIREQ#
PDIOIS16#
PDCD1#
PDCD2#
PDIORD#
PDIOWR#
PDRESET
PDWAIT#
PDINPACK#
PDREG#
1
AO1SDATA312
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
1
OPWRSB
ORESET#
OPCTRL0
OPCTRL1
OPCTRL2
OPCTRL3
OPCTRL4
OPCTRL5
OPCTRL7
OXTALI
OXTALO
OPWM1
OIRI
U0RX
U0TX
SMCE#
DCLK
MCLK
OSDA0
OSCL0
OSDA1
OSCL1
ASPDIF
GPIO_0
GPIO_1
GPIO_4
GPIO_8
GPIO_18
GPIO_19
GPIO_6
GPIO_12
GPIO_79
GPIO_80
RA[0..13]
RBA[0..1]
RCS#
RRAS#
RCAS#
RWE#
RCKE
RCLK0
RCLK0#
RDQS[0..1]
RDQ[0..15]
RDQM[0..1]
RVREF
RESTUP
RESTDN
MPX1
MPX2
CVBS0
CVBS1
CVBS2
SY0
SC0
SY1
SC1
SOY0
Y0P
Y0N
PB0P
PB0N
PR0P
PR0N
SOY1
Y1P
Y1N
PB1P
PB1N
PR1P
PR1N
SOG
GP
GN
BP
BN
RP
RN
HSYNC
VSYNC
FB_IN
RXC
RXCB
RX0
RX0B
RX1
RX1B
RX2
RX2B
PWR5V
I2SIN_DATA
AO1SDATA4
AO1MCLK
AO1BCK
AO1LRCK
AO1SDATA3
AL1
AR1
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
OPWRSB1
ORESET#7
OPCTRL011
OPCTRL112
OPCTRL213
OPCTRL31
OPCTRL41
OPCTRL51
OPCTRL712
OXTALI7
OXTALO7
OPWM11
OIRI1
U0RX7,11
U0TX7,11
SMCE#7,14
DCLK7,14
MCLK7,14
OSDA07
OSCL07
OSDA111,14
OSCL111,14
ASPDIF7
GPIO_04,7,12
GPIO_17
GPIO_43
GPIO_811
GPIO_184
GPIO_1912
GPIO_614
GPIO_1214
GPIO_7914
GPIO_8014
used to CI card 2007-06-23 by tony
RA[0..13]8
RBA[0..1]8
RCS#8
RRAS#8
RCAS#8
RWE#8
RCKE8
RCLK08
RCLK0#8
RDQS[0..1]8
RDQ[0..15]8
RDQM[0..1]8
RVREF6
RESTUP6
RESTDN6
DDR SIGNAL
MPX13
MPX23
CVBS03
CVBS110
CVBS29
SY09
SC09
SY110
SC110
AV / SV VIDEO INPUT
SOY09
Y0P9
Y0N9
PB0P9
PB0N9
PR0P9
PR0N9
SOY110
Y1P10
Y1N10
PB1P10
PB1N10
PR1P10
PR1N10
YPBPR VIDEO INPUT
SOG11
GP11
GN11
BP11
BN11
RP11
RN11
HSYNC11
VSYNC11
FB_IN10
VGA VIDEO INPUT
RXC11
RXCB11
RX011
RX0B11
RX111
RX1B11
RX211
RX2B11
PWR5V11
HDMI VIDEO INPUT
I2SIN_DATA12
AO1SDATA412
AO1MCLK12
AO1BCK12
AO1LRCK12
AUDIO I2S INTERFACE
AL110
AR110
INTERNAL AUDIO DAC OUTPUT
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
MT5331 ASIC
MT5331 ASIC
MT5331 ASIC
Document Number
Document Number
Document Number
Size
Size
Size
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
Custom
Custom
Custom
Date: Sheet
Date: Sheet
Date: Sheet
Rev
Rev
Rev
Drawn
Drawn
Drawn
Terry
Terry
Terry
514Wednesday, September 05, 2007
514Wednesday, September 05, 2007
514Wednesday, September 05, 2007
of
of
of
1
1
1
Page 44
5
4
3
2
1
DV33SB
AVCC_SRV
CB50
CB50
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33SB
D D
C C
XREGVDD
DV33SB
AVCC_XTAL
PWM2VREF
CE43
CE43
+
+
47uF/16V
47uF/16V
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
C_XREG
CB70
CB70
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB58
CB58
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB65
CB65
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
C35
C35
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
AV12
AVCC_HDMIPLL
AVCC_PSCANPLL
AVCC_DMPLL
AVCC_CPUPLL
TP0 AVCC_SYSPLL TN0 AVCC_SYSPLL
R71
R71
NS/50
NS/50
R-RESC1608N-HX
R-RESC1608N-HX
STANDBY POWER
AV33
D2
D2
LVDDA
LVDDA
CB71
LVDDB
LVDDC
AVCC_VPLL
R74
R74
NS/50
NS/50
R-RESC1608N-HX
R-RESC1608N-HX
R75
R75
NS/50
NS/50
R-RESC1608N-HX
R-RESC1608N-HX
CB71
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB83
CB83
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB96
CB96
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB105
CB105
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
1N4148
1N4148
R-SOD3718N-HX
R-SOD3718N-HX
B B
DV12
L33
L33
FB
FB
R-INDC1608N-HX
R-INDC1608N-HX
TP3 AVCC_VPLL
TN3 AVCC_VPLL
AV15
L30
L30
NS/FB
NS/FB
R-INDC1608N-HX
R-INDC1608N-HX
DACVDD
DACVDD
DACVDD
DACFS
R73
R73
560
560
R-RESC1608N-HX
R-RESC1608N-HX
DACVREF
CB108
CB108
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
LVDS POWER VIDEO DAC POWER
A A
5
AV12
CB51
CB51
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB67
CB67
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
PLL POWER
CB72
CB72
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB82
CB82
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB95
CB95
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
AVCC_ADCPLL
AVCC_SYSPLL
AVCC_B2RPLL
AVCC_APLL
AV33
CB52
CB52
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB68
CB68
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R72
R72
NS/50
NS/50
R-RESC1608N-HX
R-RESC1608N-HX
L31
L31
FB
FB
R-INDC1608N-HX
R-INDC1608N-HX
CB84
CB84
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
AV33
L32
L32
FB
FB
R-INDC1608N-HX
R-INDC1608N-HX
AV12
L34
L34
FB
FB
R-INDC1608N-HX
R-INDC1608N-HX
EXT_RES
HDMI POWER
4
AVCC_H
C37
C37
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
CB85
CB85
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
PVCC
CVCC12
CB109
CB109
NS/0.1uF
NS/0.1uF
AV33
L25
L25
FB
FB
R-INDC1608N-HX
R-INDC1608N-HX
L27
L27
FB
FB
R-INDC1608N-HX
R-INDC1608N-HX
CB73
CB73
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB86
CB86
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB97
CB97
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB106
CB106
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
AV33
L26
L26
AVCC_VAD0
C30
C30
4.7uF
4.7uF
R-CAPC2012N-HX
R-CAPC2012N-HX
AVCC_VAD1 AVCC_ADAC
C32
C32
4.7uF
4.7uF
R-CAPC2012N-HX
R-CAPC2012N-HX
CB53
CB53
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB59
CB59
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB54
CB54
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB60
CB60
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-INDC1608N-HX
R-INDC1608N-HX
AV33AV15
R-INDC3216N-HX
R-INDC3216N-HX
ANALOG FRONT-END POWER
DV33SB
L29
L29
AVCC_AV33
FB
FB
R-INDC1608N-HX
R-INDC1608N-HX
DV33
C38
C38
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
DV12
C39
C39
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
DV26_DDR
C40
C40
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
MEM_VREF RVREF
C36
C36
4.7uF
4.7uF
R-CAPC2012N-HX
R-CAPC2012N-HX
CB74
CB74
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB87
CB87
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB98
CB98
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
L35
L35
FB
FB
R-INDC1608N-HX
R-INDC1608N-HX
CB69
CB69
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB75
CB75
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB88
CB88
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB99
CB99
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB76
CB76
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB89
CB89
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
C41
C41
4.7uF
4.7uF
R-CAPC2012N-HX
R-CAPC2012N-HX
150uH
150uH
L28
L28
150uH
150uH
+
+
CB77
CB77
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB90
CB90
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB104
CB104
0.1uF
0.1uF
CB121
CB121
R-CAPC1608N-HX
R-CAPC1608N-HX
0.1uF
0.1uF
R-CAPC2012N-HX
R-CAPC2012N-HX
CB107
CB107
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
AVCC_AADC
C31
C31
4.7uF
4.7uF
R-CAPC2012N-HX
R-CAPC2012N-HX
CE42
CE42
470uF/16V
470uF/16V
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
ADAC_VCM
C34
C34
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
CB78
CB78
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB91
CB91
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DIGITAL POWER
DV26_DDR
RESTUP
R76
R76
NS/33
NS/33
R-CAPC1608N-HX
R-CAPC1608N-HX
3
RESTDN
R77
R77
NS/33
NS/33
R-CAPC1608N-HX
R-CAPC1608N-HX
CB55
CB55
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB66
CB66
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
TOP SIDE BOTTOM SIDELEFT SIDE RIGHT SIDE
TOP SIDE BOTTOM SIDELEFT SIDE RIGHT SIDE
DV33
DV33
DV33
C33
C33
4.7uF
4.7uF
R-CAPC2012N-HX
R-CAPC2012N-HX
CB79
CB79
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB92
CB92
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33
DV33
CB7
CB7
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB56
CB56
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB57
CB57
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB140
CB140
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB61
CB61
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB80
CB80
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB93
CB93
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33
CB6
CB6
CB5
CB5
0.1uF
0.1uF
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33
CB138
CB138
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33
CB139
CB139
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33
CB63
CB63
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB62
CB62
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB81
CB81
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB94
CB94
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33
CB2
CB2
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33
CB4
CB4
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33
2
CB129
CB129
10uF
10uF
R-CAPC2012N-HX
R-CAPC2012N-HX
DV332,5,7,12,14
AV331,2,5
DV26_DDR2,5,8
AV152
AV122,5
DV33SB1,2,5,7
GND1,2,3,4,5,7,8,9,10,11,12,13,14
GLOBAL POWER
AVCC_HDMIPLL2,5
AVCC_PSCANPLL2,5
AVCC_DMPLL2,5
AVCC_CPUPLL2,5
AVCC_ADCPLL2,5
AVCC_SYSPLL2,5
AVCC_B2RPLL2,5
AVCC_APLL2,5
TP05
TN05
AGND_PLL1,2,3,4,5,7,8,9,10,11,12,13,14
PLL POWER
AVCC_VAD05
AVCC_VAD15
AVCC_AV335
AVCC_AADC5
AVCC_ADAC5
ADAC_VCM5
TP15
TN15
TP25
TN25
AGND_AFE1,2,3,4,5,7,8,9,10,11,12,13,14
ANALOG FRONT-END POWER
AVCC_H5
PVCC5
CVCC125
EXT_RES5
AGND_HDMI1,2,3,4,5,7,8,9,10,11,12,13,14
HDMI POWER
LVDDA5
LVDDB5
LVDDC5
AVCC_VPLL5
TP35
TN35
AGND_LVDS1,2,3,4,5,7,8,9,10,11,12,13,14
LVDS POWER
DACVDD5
DACFS5
DACVREF5
AGND_LVDS1,2,3,4,5,7,8,9,10,11,12,13,14
VIDEO DAC POWER
AVCC_SRV1,2,5,7
XREGVDD1,2,5,7
AVCC_XTAL1,2,5,7
C_XREG5
PWM2VREF5
RESTUP5
RESTDN5
MEM_VREF8
RVREF5
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
MT5331 BYPASS CAP.
MT5331 BYPASS CAP.
MT5331 BYPASS CAP.
Document Number
Document Number
Document Number
Size
Size
Size
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
Custom
Custom
Custom
Date: Sheet
Date: Sheet
Date: Sheet
TEL:(03)567-0766 FAX:(03)578-7610
1
DV33
AV33
DV26_DDR
AV15
AV12
DV33SB
GND
AVCC_HDMIPLL
AVCC_PSCANPLL
AVCC_DMPLL
AVCC_CPUPLL
AVCC_ADCPLL
AVCC_SYSPLL
AVCC_B2RPLL
AVCC_APLL
TP0
TN0
AGND_PLL
AVCC_VAD0
AVCC_VAD1
AVCC_AV33
AVCC_AADC
AVCC_ADAC
ADAC_VCM
TP1
TN1
TP2
TN2
AGND_AFE
AVCC_H
PVCC
CVCC12
EXT_RES
AGND_HDMI
LVDDA
LVDDB
LVDDC
AVCC_VPLL
TP3
TN3
AGND_LVDS
DACVDD
DACFS
DACVREF
AGND_LVDS
AVCC_SRV
XREGVDD
AVCC_XTAL
C_XREG
PWM2VREF
RESTUP
RESTDN
MEM_VREF
RVREF
Drawn
Drawn
Drawn
Terry
Terry
Terry
614Wednesday, September 05, 2007
614Wednesday, September 05, 2007
614Wednesday, September 05, 2007
TP35TP35
TP36TP36
TP37TP37
TP38TP38
Rev
Rev
Rev
1
1
1
of
of
of
Page 45
5
4
3
2
1
DV33SB
R78
R79
1
2 3
DV33
1
2 3
R79
1K
1K
R-RESC1608N-HX
R-RESC1608N-HX
Q6
Q6
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
R107
R107
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
NOR_ORESET#
Q7
Q7
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
ORESET#
C44
C44
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
PDA1
PDA2
PDA3
PDA4
PDA5
PDA6
PDA7
PDA8
PDA9
PDA10
PDA11
PDA12
PDA13
PDA14
PDA15
PDA16
PDA17
PDA18
PDA19
PDA20
PDA21
PDA22
POCE0#
POOE0#
POWE#
C45
C45
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
U16
U16
25
A0
24
A1
23
A2
22
A3
21
A4
20
A5
19
A6
18
A7
8
A8
7
A9
6
A10
5
A11
4
A12
3
A13
2
A14
1
A15
48
A16
17
A17
16
A18
9
A19
10
A20
13
A21
26
CE
28
OE
11
WE
12
RESET
IC FLASH MX29LV320 32Mb TSOP-48
IC FLASH MX29LV320 32Mb TSOP-48
R-TSSOP48N-0.500-20.00-HX
R-TSSOP48N-0.500-20.00-HX
NOR FLASH
D15/A-1
WP/ACC
RY/BY
BYTE
GND1
GND2
29
D0
31
D1
33
D2
35
D3
38
D4
40
D5
42
D6
44
D7
30
D8
32
D9
34
D10
36
D11
39
D12
41
D13
43
D14
45
14
15
47
37
VCC
27
46
CE44
CE44
+
+
220uF/16V
220uF/16V
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
R83
R83
220
220
R-RESC1608N-HX
R-RESC1608N-HX
R85
D D
C C
B B
D3
D3
1N4148
1N4148
R-SOD3718N-HX
R-SOD3718N-HX
D4
D4
1N4148
1N4148
R-SOD3718N-HX
R-SOD3718N-HX
R85
47K
47K
R-RESC1608N-HX
R-RESC1608N-HX
CE46
CE46
+
+
10uF/16V
10uF/16V
R-CAPC2012N-HX
R-CAPC2012N-HX
R108
R108
220
220
R-RESC1608N-HX
R-RESC1608N-HX
R109
R109
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
R78
820K
820K
R-RESC1608N-HX
R-RESC1608N-HX
Y2
Y2
27MHz
27MHz
R-CRYC1405N-HX
R-CRYC1405N-HX
C42
C42
22pF
22pF
R-CAPC1608N-HX
R-CAPC1608N-HX
PDD0
PDD1
PDD2
PDD3
PDD4
PDD5
PDD6
PDD7
PDA0
NOR_ORESET#
OXTALOOXTALI
C43
C43
27pF
27pF
R-CAPC1608N-HX
R-CAPC1608N-HX
R106
R106
NS/0
NS/0
R-RESC1608N-HX
R-RESC1608N-HX
CB113
CB113
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CE45
CE45
+
+
10uF/16V
10uF/16V
R-CAPC2012N-HX
R-CAPC2012N-HX
R-INDC1608N-HX
R-INDC1608N-HX
DV33
R80
R80
NS/4.7K
NS/4.7K
R-RESC1608N-HX
GPIO_0
R-RESC1608N-HX
R84
R84
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
JTAG_RTCK
JTAG_TDO
R86 33
R86 33
R87 33
R87 33
R81
R81
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
JTAG_RST#
JTAG_TDI
JTAG_TMS
JTAG_TCK
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
JTAG INTERFACE
MCLK
DV33
CB112
CB112
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33
L37
L37
FB
FB
MT5372 SYSTEM EEPROM
DV33 DV33
R96
R95
R95
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
R96
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
DCLK SMCE#
TRAP-MODE CIRCUIT
SHOULD BE REMOVED IN MP
U17
U17
1
NC
VCC
2
NC
WP
3
NC
SCL
GND4SDA
EEPROM 24C16
EEPROM 24C16
R-SOIC08N-1.270-6.00-HX
R-SOIC08N-1.270-6.00-HX
1 8
R97
R97
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
R102
R102
33
33
R-RESC1608N-HX
R-RESC1608N-HX
8
7
6
5
DV33
RN4
RN4
10Kx4
10Kx4
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
2 7
3 6
4 5
R88
R88
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R89
R89
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R99
R99
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
GPIO_1
R104
R104
NS/4.7K
NS/4.7K
R-RESC1608N-HX
R-RESC1608N-HX
R82
R82
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
TVTREF#1
JTAG_DBGRQ
JTAG_DBGACK
R90
R90
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
OSDA0 SIF_SDA
OSCL0
GENERAL PURPOSE SIF
C135
C135
22pF
22pF
DV33 DV33
R398 22R398 22
C136
C136
22pF
22pF
J2
J2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
10x2 W/HOUSING
10x2 W/HOUSING
M-2P20-2.54X2.54-180-HX
M-2P20-2.54X2.54-180-HX
R100
R100
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
SIF_SCL
R399 22R399 22
R101
R101
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
R103
R103
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R105
R105
75
75
R-RESC1608N-HX
R-RESC1608N-HX
SIF_SDA
SIF_SCL
+5V1,2,3,11,14
+5VCC1,2
DV332,5,6,12,14
DV33SB1,2,5,6
GND1,2,3,4,5,6,8,9,10,11,12,13,14
AGND_PLL1,2,3,4,5,6,8,9,10,11,12,13,14
AGND_AFE1,2,3,4,5,6,8,9,10,11,12,13,14
ORESET#5
OXTALI5
OXTALO5
POOE0#5
POCE0#5
POWE#5
PDD[0..7]5,14
PDA[0..22]5,14
NOR FLASH(modify by tony 2007-06-23)
JTAG_RST#5
JTAG_TDI5
JTAG_TMS5
JTAG_TCK5
JTAG_RTCK5
JTAG_TDO5
JTAG
U0RX5,11
U0TX5,11
ASPDIF5
SMCE#5,14
DCLK5,14
MCLK5,14
OSDA05
OSCL05
SIF_SDA4,12
SIF_SCL4,12
GPIO_04,5,12
GPIO_15
+5V
5VCC
DV33
DV33SB
GND
AGND_PLL
AGND_AFE
ORESET#
OXTALI
OXTALO
POOE0#
POCE0#
POWE#
PDD[0..7]
PDA[0..22]
JTAG_RST#
JTAG_TDI
JTAG_TMS
JTAG_TCK
JTAG_RTCK
JTAG_TDO
U0RX
U0TX
ASPDIF
SMCE#
DCLK
MCLK
OSDA0
OSCL0
SIF_SDA
SIF_SCL
GPIO_0
GPIO_1
SPDIF CIRCUIT
+5V
L553
L553
FB
U0RX
FB
R-INDC1608N-HX
R-INDC1608N-HX
R114
R114
33
33
R-RESC1608N-HX
R-RESC1608N-HX
R1808
R1808
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
U0TX
CB114
CB114
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33SB
R113
R113
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
R400 10R400 10
R401 10R401 10
5VCC
L68
L68
5VCC
FB
FB
R-INDC1608N-HX
16
15
14
13
12
11
10
9
R-INDC1608N-HX
CB244
CB244
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R1807
R1807
100R
100R
R-RESC1608N-HX
R-RESC1608N-HX
+
+
CE57
CE57
10uF/16V
10uF/16V
R-CAPC2012N-HX
R-CAPC2012N-HX
R1803
R1803
1k
1k
R-RESC1608N-HX
R-RESC1608N-HX
R1806
R1806
100R
100R
R-RESC1608N-HX
R-RESC1608N-HX
CB245
CB245
47pF
47pF
R-CAPC1608N-HX
R-CAPC1608N-HX
R1824
R1824
100R
100R
U0TX
R-RESC1608N-HX
R-RESC1608N-HX
RS232_TXDRS232_TXD
RS232_RXDRS232_RXD
U0RX
CB248
CB248
47pF
47pF
R-CAPC1608N-HX
R-CAPC1608N-HX
NS/4.7K
NS/4.7K
R1804
R1804
R-RESC1608N-HX
R-RESC1608N-HX
R1805
R1805
NS/4.7K
NS/4.7K
R-RESC1608N-HX
R-RESC1608N-HX
2/4 modify
RS232_TXD
RS232_RXD
M-CK3-3.5-02-HX
M-CK3-3.5-02-HX
4x1 W/HOUSING
4x1 W/HOUSING
5
4
3
2
1
J4
J4
ASPDIF
CB227
CB227
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB228
CB228
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB229
CB229
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB230
CB230
0.1uF
0.1uF
R-CAPC1608N-HX
A A
R-CAPC1608N-HX
U45
U45
1
C1+
2
V+
3
C1-
4
C2+
5
C2-
6
V-
7
T2OUT
R2IN8R2OUT
MAX232A
MAX232A
VCC
GND
T1OUT
R1IN
R1OUT
T1IN
T2IN
FOR CODE DOWNLOAD AND DEBUGGING
FOR CODE DOWNLOAD AND DEBUGGING
5
4
3
J3
J3
1
2
3
4
4x1 W/HOUSING
4x1 W/HOUSING
M-TJC10-4A-HX
M-TJC10-4A-HX
3
2
1
12
2
G
VCC
IN
D171
D171
MVS0603E10
MVS0603E10
P1
P1
S/PDIF OUT
S/PDIF OUT
M-KFO-TX13C-HX
M-KFO-TX13C-HX
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
MT5331 PERIPHERAL
MT5331 PERIPHERAL
MT5331 PERIPHERAL
Document Number
Document Number
Document Number
Size
Size
Size
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
Custom
Custom
Custom
Date: Sheet
Date: Sheet
Date: Sheet
TEL:(03)567-0766 FAX:(03)578-7610
1
Drawn
Drawn
Drawn
Terry
Terry
Terry
Rev
Rev
Rev
1
1
1
714Wednesday, September 05, 2007
714Wednesday, September 05, 2007
714Wednesday, September 05, 2007
of
of
of
Page 46
5
4
3
2
1
DV13_DDRDV13_DDR
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
45
36
27
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
18
45
36
27
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
18
RN1947x4
RN1947x4
MEM_ADDR13
CB127
CB127
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
MEM_DQ0
MEM_DQ1
MEM_DQ2
MEM_DQ3
MEM_DQ4
MEM_DQ5
MEM_DQ6
MEM_DQ7
MEM_DQS0
MEM_DQM0
MEM_DQM1
MEM_DQS1
MEM_DQ8
MEM_DQ9
MEM_DQ10
MEM_DQ11
MEM_DQ12
MEM_DQ13
MEM_DQ14
MEM_DQ15
CB128
CB128
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
RN875x4
RN875x4
RN1275x4
RN1275x4
R116 75
R116 75
R120 75
R120 75
R122 75
R122 75
RN1675x4
RN1675x4
RN2075x4
RN2075x4
R118 75
R118 75
CB101
CB101
CB102
CB102
0.1uF
0.1uF
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
DV26_DDR
C51
C51
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
45
36
27
18
45
36
27
18
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
45
36
27
18
45
36
27
18
R-RESC1608N-HX
R-RESC1608N-HX
CB103
CB103
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB146
CB146
4.7uF
4.7uF
R-CAPC2012N-HX
R-CAPC2012N-HX
CB147
CB147
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
RRAS#
RCAS#
RWE#
RA13
RA3
D D
RA2
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
RA1
RA0 MEM_ADDR0
RA4
RA5
RA6
RA7
RCKE
RA12
RA11
RA8 MEM_ADDR8
RCS# MEM_CS#
RBA0
RBA1
RA10
C C
DV13_DDR
CB115
CB115
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV13_DDR
CB136
CB136
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
B B
BYPASS CAP. FOR TERMINATOR
(EVERY 2 RESISTOR PUT 1 BYPASS CAP.)
RN522x4
RN522x4
RN9 22x4
RN9 22x4
4 5
3 6
2 7
1 8
RN1322x4
RN1322x4
R123 22
R123 22
RN1722x4
RN1722x4
RN21 22x4
RN21 22x4
1 8
2 7
3 6
4 5
RCLK0
RCLK0#
CB116
CB116
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB137
CB137
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
18
27
36
45
18
27
36
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
45
45
36
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
27
18
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
MEM_ADDR13
R-RESC1608N-HX
R-RESC1608N-HX
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R125
R125
22
22
R-RESC1608N-HX
R-RESC1608N-HX
R127
R127
22
22
R-RESC1608N-HX
R-RESC1608N-HX
CB118
CB118
CB117
CB117
0.1uF
0.1uF
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
MEM_RAS#
MEM_CAS#
MEM_WE#
MEM_ADDR3
MEM_ADDR2
MEM_ADDR1
MEM_ADDR4
MEM_ADDR5
MEM_ADDR6
MEM_ADDR7
MEM_CLKEN
MEM_ADDR12
MEM_ADDR11
MEM_ADDR9RA9
MEM_BA0
MEM_BA1
MEM_ADDR10
MEM_CLKA
R126
R126
100
100
R-RESC1608N-HX
R-RESC1608N-HX
MEM_CLKA#
MEM_DQM0
RN6 75x4
RN6 75x4
1 8
R-RESCA3216-8N-HX
2 7
3 6
4 5
1 8
2 7
3 6
4 5
RN1475x4
RN1475x4
R124 NS/75
R124 NS/75
RN1875x4
RN1875x4
RN22 75x4
RN22 75x4
1 8
2 7
3 6
4 5
CB122
CB122
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
45
36
27
18
R-RESC1608N-HX
R-RESC1608N-HX
18
27
36
45
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
CB123
CB123
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB145
CB145
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
MEM_WE#
MEM_CAS#
MEM_RAS#
MEM_CS#
RN10 75x4
RN10 75x4
MEM_BA0
MEM_BA1 DV26_DDR
MEM_ADDR10
MEM_ADDR4
MEM_ADDR5
MEM_ADDR6
MEM_ADDR7
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
MEM_CLKEN
MEM_ADDR12
MEM_ADDR11
MEM_ADDR9
MEM_ADDR8
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
MEM_ADDR0
MEM_ADDR1
MEM_ADDR2
MEM_ADDR3
CB144
CB144
CB143
CB143
0.1uF
0.1uF
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
RDQ0
RN7 47x4
RN7 47x4
4 5
RDQ1
3 6
RDQ2
2 7
RDQ3
1 8
RDQ4
RN11 47x4
RN11 47x4
4 5
RDQ5
3 6
RDQ6
2 7
RDQ7
1 8
RDQS0
R115 47
R115 47
RDQM0
R117 47
R117 47
RDQM1
R119 47
R119 47
RDQS1
R121 47
R121 47
RDQ8
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
RDQ9
RDQ10
RDQ11
RDQ12
RDQ13
RDQ14
RDQ15 MEM_VREF
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
CB124
CB124
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV26_DDR
CB126
CB126
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
RN1547x4
RN1547x4
DV26_DDR DV26_DDR
U18
U18
1
MEM_DQ0 MEM_DQ15
MEM_DQ1 MEM_DQ14
MEM_DQ2
MEM_DQ3
MEM_DQ4
MEM_DQ5
MEM_DQ6
MEM_DQ7
MEM_DQS0
MEM_ADDR13
MEM_DQM0
MEM_WE#
MEM_CAS#
MEM_RAS#
MEM_CS#
MEM_BA0
MEM_BA1
MEM_ADDR10
MEM_ADDR0
MEM_ADDR1
MEM_ADDR2
MEM_ADDR3
CB132
CB132
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB64
CB64
0.1uF
0.1uF
+
+
R-CAPC1608N-HX
R-CAPC1608N-HX
VDD
2
DQ0
3
VDDQ
4
DQ1
5
DQ2
6
VSSQ
7
DQ3
8
DQ4
9
VDDQ
10
DQ5
11
DQ6
12
VSSQ
13
DQ7
14
NC
15
VDDQ
16
LDQS
17
NC
18
VDD
19
NC
20
LDM
21
WE
22
CAS
23
RAS
24
CS
25
NC
26
BS0
27
BS1
28
A10/AP
29
A0
30
A1
31
A2
32
A3
33
VDD
16M x 16 DDR TSOP-66
16M x 16 DDR TSOP-66
R-TSOP66N-0.650-11.76-HX
R-TSOP66N-0.650-11.76-HX
CB133
CB133
CB134
CB134
0.1uF
0.1uF
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
CE50
CE50
220uF/16v
220uF/16v
R-CAPAE-D8.0X10.2-HX
R-CAPAE-D8.0X10.2-HX
DDR#1
VSS
DQ15
VSSQ
DQ14
DQ13
VDDQ
DQ12
DQ11
VSSQ
DQ10
DQ9
VDDQ
DQ8
NC
VSSQ
UDQS
NC
VREF
VSS
UDM
CLK
CLK
CKE
NC
A12
A11
A9
A8
A7
A6
A5
A4
VSS
CB100
CB100
CB135
CB135
4.7uF
4.7uF
0.1uF
0.1uF
R-CAPC2012N-HX
R-CAPC2012N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
66
65
64
63
MEM_DQ13
62
61
MEM_DQ12
60
MEM_DQ11
59
58
MEM_DQ10
57
MEM_DQ9
56
55
MEM_DQ8
54
53
52
MEM_DQS1
51
50
49
48
MEM_DQM1
47
MEM_CLKA#
46
MEM_CLKA
45
MEM_CLKEN
44
43
MEM_ADDR12
42
MEM_ADDR11
41
MEM_ADDR9
40
MEM_ADDR8
39
MEM_ADDR7
38
MEM_ADDR6
37
MEM_ADDR5
36
MEM_ADDR4
35
34
+
CE47
+
CE47
100uF/16v
100uF/16v
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
CB125
CB125
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
MEM_VREF
DV13_DDR
+
CE48
+
CE48
220uF/16V
220uF/16V
R-CAPAE-D8.0X10.2-HX
R-CAPAE-D8.0X10.2-HX
R128
R128
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
U19
U19
1
GND
2
SD
3
VSENSE
VREF4VDDQ
IC LP2996 DDR Termination SOP-8
IC LP2996 DDR Termination SOP-8
R-SOIC08N-1.270-6.00-HX
R-SOIC08N-1.270-6.00-HX
8
VTT
7
PVIN
6
AVIN
5
DV26_DDR2,5,6
MEM_VREF6
RDQ[0..15]5
RDQS[0..1]5
RDQM[0..1]5
RA[0..13]5
RBA[0..1]5
RCLK05
RCLK0#5
RCS#5
RRAS#5
RCAS#5
RWE#5
RCKE5
DV26_DDR
+
CE49
+
CE49
47uF/16V
47uF/16V
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
DDR MEMORY
MEM_VREF
GND
GND 1,2,3,4,5,6,7,9,10,11,12,13,14
RDQ[0..15]
RDQS[0..1]
RDQM[0..1]
RA[0..13]
RBA[0..1]
RCLK0
RCLK0#
RCS#
RRAS#
RCAS#
RWE#
RCKE
MEM_VREF
CB148
CB148
CB149
CB149
0.1uF
0.1uF
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
A A
5
4
3
2
C52
C52
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
DDR MEMORY
DDR MEMORY
DDR MEMORY
Document Number
Document Number
Document Number
Size
Size
Size
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
Custom
Custom
Custom
Date: Sheet
Date: Sheet
Date: Sheet
TEL:(03)567-0766 FAX:(03)578-7610
1
Drawn
Drawn
Drawn
Terry
Terry
Terry
Rev
Rev
Rev
1
1
1
of
814Wednesday, September 05, 2007
of
814Wednesday, September 05, 2007
of
814Wednesday, September 05, 2007
Page 47
A
M-AV6-W-AVY-HX
M-AV6-W-AVY-HX
AV_IN
1
V
2
P5
P5
P27
P27
WHITE
RED
GND
M-AV2-90-HX
M-AV2-90-HX
GND
GND
GND
GND
GND
GND
1
2
3
AVL_IN
3
L
4
AVR_IN
5
R
6
7
R
Y0_IN
8
Y
9
PB0_IN
10
PB
11
12
PR
PR0_IN
14
PR
13
YPBPR0L_IN
YPBPR0R_IN
AUDIO INPUT FOR YPBPR by tony 2007-06-25
A A
1 3
YC
YC
2 4
GG
GG
657
P25
P25
S-VIDEO
S-VIDEO
M-S4-HX
M-S4-HX
SC0_INSY0_IN
NEARLY YPBPR CONNECTOR NEARLY MT5331
R171
Y0_IN
PB0_IN
PR0_IN
L39
L39
FB/80OHM
FB/80OHM
12
R-INDC1608N-HX
R-INDC1608N-HX
D188
D188
NS/EZJZ0V800AA
NS/EZJZ0V800AA
R-INDC1608N-HX
R-INDC1608N-HX
L554
L554
FB/80OHM
FB/80OHM
12
R-INDC1608N-HX
R-INDC1608N-HX
D14
D14
NS/EZJZ0V800AA
NS/EZJZ0V800AA
R-INDC1608N-HX
R-INDC1608N-HX
L41
L41
FB/80OHM
FB/80OHM
12
R-INDC1608N-HX
R-INDC1608N-HX
D15
D15
NS/EZJZ0V800AA
NS/EZJZ0V800AA
R-INDC1608N-HX
R-INDC1608N-HX
R173
R173
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R178
R178
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R181
R181
75
75
R-RESC1608N-HX
R-RESC1608N-HX
C67
C67
15pF
15pF
R-CAPC1608N-HX
R-CAPC1608N-HX
C72
C72
15pF
15pF
R-CAPC1608N-HX
R-CAPC1608N-HX
C75
C75
15pF
15pF
R-CAPC1608N-HX
R-CAPC1608N-HX
R171
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R172
R172
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R176
R176
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R1809
R1809
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R1810
R1810
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R180
R180
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R182
R182
100
100
R-RESC1608N-HX
R-RESC1608N-HX
C65
C65
1nF
1nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C66
C66
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C70
C70
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C71
C71
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C73
C73
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C74
C74
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C76
C76
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
NEARLY AV CONNECTOR NEARLY MT5370
AV_IN
SY0_IN
12
D146
D146
MVS0603E10
MVS0603E10
12
D145
D145
MVS0603E10
MVS0603E10
12
D147
D147
MVS0603E10
MVS0603E10
R1524
R1524
0
0
R-RESC1608N-HX
R-RESC1608N-HX
R1825
R1825
0
0
R-RESC1608N-HX
R-RESC1608N-HX
R1588
R1588
0
0
R-RESC1608N-HX
R-RESC1608N-HX
R1525
R1525
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R1562
R1562
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R1591
R1591
75
75
R-RESC1608N-HX
R-RESC1608N-HX
C460
C460
47pF
47pF
R-CAPC1608N-HX
R-CAPC1608N-HX
C459
C459
47pF
47pF
R-CAPC1608N-HX
R-CAPC1608N-HX
C565
C565
47pF
47pF
R-CAPC1608N-HX
R-CAPC1608N-HX
R1587
R1587
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R1560
R1560
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R1592
R1592
100
100
R-RESC1608N-HX
R-RESC1608N-HX
C535
C535
47nF
47nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C534
C534
47nF
47nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C561
C561
47nF
47nF
R-CAPC1608N-HX
R-CAPC1608N-HX
CVBS2
SY0
SC0SC0_IN
SOY0
Y0P
Y0N
PB0P
PB0N
PR0P
PR0N
AVR_IN
12
D104
D104
MVS0603E10
MVS0603E10
AVL_IN
12
D148
D148
MVS0603E10
MVS0603E10
YPBPR0R_IN
12
D12
D12
NS/EZJZ0V800AA
NS/EZJZ0V800AA
R-INDC1608N-HX
R-INDC1608N-HX
YPBPR0L_IN
12
D13
D13
NS/EZJZ0V800AA
NS/EZJZ0V800AA
R-INDC1608N-HX
R-INDC1608N-HX
R1303
R1303
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R1593
R1593
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
C68
C68
NS/10nF
NS/10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C69
C69
NS/10nF
NS/10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
R174
R174
NS/10K
NS/10K
R-RESC1608N-HX
R-RESC1608N-HX
R175
R175
NS/10K
NS/10K
R-RESC1608N-HX
R-RESC1608N-HX
AGND_AFE1,2,3,4,5,6,7,8,10,11,12,13,14
SOY05
Y0P5
Y0N5
PB0P5
PB0N5
PR0P5
PR0N5
SOY0
Y0P
Y0N
PB0P
PB0N
PR0P
PR0N
YPBPR VIDEO INPUT
YPBPR0R_IN12
YPBPR0L_IN12
YPBPR0R_IN
YPBPR0L_IN
YPBPR AUDIO INPUT
CVBS25
SY05
SC05
CVBS2
SY0
SC0
S/AV INPUT
AVR_IN12
AVL_IN12
AVR_IN
AVL_IN
AV/S_VIDEO AUDIO INPUT
AGND_AFE
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
AV / SV / YPBPR INPUT
AV / SV / YPBPR INPUT
AV / SV / YPBPR INPUT
Document Number
Document Number
Document Number
Size
Size
Size
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
Custom
Custom
Custom
Date: Sheet
Date: Sheet
A
Date: Sheet
TEL:(03)567-0766 FAX:(03)578-7610
Drawn
Drawn
Drawn
Terry
Terry
Terry
914Wednesday, September 05, 2007
914Wednesday, September 05, 2007
914Wednesday, September 05, 2007
Rev
Rev
Rev
1
1
1
of
of
of
Page 48
A
P28
P28
SCT1_AUR_OUT
1
1
SCT1_AUR_IN
2
2
SCT1_AUL_OUT
3
3
4
4
5
5
SCT1_AUL_IN
6
6
SCT1_B_IN
7
7
SCT1_FS_IN
8
8
9
9
10
10
SCT1_G_IN
11
11
12
12
13
13
14
14
SCT1_R_IN
15
15
SCT1_FB_IN
16
16
17
17
18
18
SCT1_AV_OUT
19
19
SCT1_AV_IN
20
20
21
21
22
22
23
23
M-CS104-PB-HX
M-CS104-PB-HX
SCART INPUT(ADDED BY TONY 2007-06-25)
SCT1_AV_IN
SCT1_AVI_GND
SCT1_FB_IN
A A
AL1
AR1
12
D24
D24
ECVAL160805E20100
ECVAL160805E20100
R-INDC1608N-HX
R-INDC1608N-HX
R339
R339
0
0
R-RESC1608N-HX
R-RESC1608N-HX
R343
R343
NS/10K
NS/10K
R-CAPC1608N-HX
R-CAPC1608N-HX
R351
R351
0
0
R-RESC1608N-HX
R-RESC1608N-HX
R356
R356
NS/10K
NS/10K
R-RESC1608N-HX
R-RESC1608N-HX
12
D25
D25
NS/EZJZ0V800AA
NS/EZJZ0V800AA
R-INDC1608N-HX
R-INDC1608N-HX
+
+
CE85
CE85
10uF/25V
10uF/25V
R-CAPAE-D4.0X5.4-HX
R-CAPAE-D4.0X5.4-HX
+
+
CE87
CE87
10uF/25V
10uF/25V
R-CAPAE-D4.0X5.4-HX
R-CAPAE-D4.0X5.4-HX
R215
R215
75
75
R-RESC1608N-HX
R-RESC1608N-HX
12
D21
D21
LOPIVA16G05A
LOPIVA16G05A
R-INDC1608N-HX
12
SCT1_AV SCT1_SOY
R14
R14
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R271
R271
0
0
R-RESC1608N-HX
R-RESC1608N-HX
R340
R340
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
C122
C122
820pF
820pF
R-CAPC1608N-HX
R-CAPC1608N-HX
R352
R352
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
C124
C124
820pF
820pF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-INDC1608N-HX
D23
D23
LOPIVA16G05A
LOPIVA16G05A
R-INDC1608N-HX
R-INDC1608N-HX
C948
C948
15pF
15pF
R-CAPC1608N-HX
R-CAPC1608N-HX
FB_IN
R337
R337
27K
27K
R-RESC1608N-HX
R-RESC1608N-HX
R341
R341
5.1K
5.1K
R-RESC1608N-HX
R-RESC1608N-HX
R348
R348
27K
27K
R-RESC1608N-HX
R-RESC1608N-HX
R353
R353
5.1K
5.1K
R-RESC1608N-HX
R-RESC1608N-HX
SCT1_G_GND SCT1_R_GND
SCT1_B_IN
SCT1_B_GND
R1821
R1821
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R210
R210
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R1833
R1833
100
100
R-RESC1608N-HX
R-RESC1608N-HX
NEARLY MT5331
R1822
R1822
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R169
R169
100
100
R-RESC1608N-HX
R-RESC1608N-HX
C121
C121
120pF
120pF
2
3
OPAVREF
C123
C123
120pF
120pF
R-CAPC1608N-HX
R-CAPC1608N-HX
6
5
OPAVREF
SCT1_G_INSCT1_G_IN
C81
C81
15pF
15pF
R-CAPC1608N-HX
R-CAPC1608N-HX
SCT1_B_IN
C83
C83
15pF
15pF
R-CAPC1608N-HX
R-CAPC1608N-HX
12
R-CAPC1608N-HX
R-CAPC1608N-HX
-
-
U36A
U36A
1
+
+
CO4558 OPA
CO4558 OPA
R-SOIC08N-1.270-6.00-HX
R-SOIC08N-1.270-6.00-HX
8 4
OPAV120
-
-
U36B
U36B
7
+
+
CO4558 OPA
CO4558 OPA
R-SOIC08N-1.270-6.00-HX
R-SOIC08N-1.270-6.00-HX
8 4
OPAV120
C951
C951
47nF
47nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C947
C947
47nF
47nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C63
C63
47nF
47nF
R-CAPC1608N-HX
R-CAPC1608N-HX
D26
D26
ECVAL160805E20100
ECVAL160805E20100
R-INDC1608N-HX
R-INDC1608N-HX
SCT1_R_IN
CVBS1
SY1
SC1SCT1_R_IN
R1823
R1823
33K
33K
R-RESC1608N-HX
R-RESC1608N-HX
2X GAIN
+
+
CE86
CE86
10uF/25V
10uF/25V
R-CAPAE-D4.0X5.4-HX
R-CAPAE-D4.0X5.4-HX
2X GAIN
+
+
CE88
CE88
10uF/25V
10uF/25V
R-CAPAE-D4.0X5.4-HX
R-CAPAE-D4.0X5.4-HX
ADIN0SCT1_FS_IN
( Max=2.8V )
R223
R223
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
AO1AUXR
R342
R342
51
51
R-RESC1608N-HX
R-RESC1608N-HX
R344
R344
NS/10K
NS/10K
R-RESC1608N-HX
R-RESC1608N-HX
AO1AUXL
R354
R354
51
51
R-RESC1608N-HX
R-RESC1608N-HX
R357
R357
NS/10K
NS/10K
R-RESC1608N-HX
R-RESC1608N-HX
12
D22
D22
LOPIVA16G05A
LOPIVA16G05A
R-INDC1608N-HX
R-INDC1608N-HX
R338
R338
NS/0
NS/0
R-RESC1608N-HX
R-RESC1608N-HX
MUTE
MUTE
R345
R345
1K
1K
R-RESC1608N-HX
R-RESC1608N-HX
R349
R349
NS/0
NS/0
R-RESC1608N-HX
R-RESC1608N-HX
R358
R358
1K
1K
R-RESC1608N-HX
R-RESC1608N-HX
SCT1_R_IN
C82
C82
R1820
R1820
15pF
15pF
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
12
D27
D27
ECVAL160805E20100
ECVAL160805E20100
R-INDC1608N-HX
R-INDC1608N-HX
SCT1_AV_OUT SCT1_AUR_OUT SCT1_AUL_OUT
12
D29
D29
ECVAL160805E20100
ECVAL160805E20100
R-INDC1608N-HX
R-INDC1608N-HX
SCT1_AVO_GND
SCT1_AUL_OUT
Q28
Q28
1
2SD2653K
2SD2653K
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
SCT1_AUR_OUT
Q31
Q31
1
2SD2653K
2SD2653K
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
C87
C87
NS/10nF
NS/10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
+12V
+12V OPAV120
R228
R228
NS/10K
NS/10K
R-RESC1608N-HX
R-RESC1608N-HX
12
D30
D30
ECVAL160805E20100
ECVAL160805E20100
R-INDC1608N-HX
R-INDC1608N-HX
R334
R334
47K
47K
R-RESC1608N-HX
R-RESC1608N-HX
+
+
R335
R335
47K
47K
R-RESC1608N-HX
R-RESC1608N-HX
R336
R336
10
10
R-RESC1608N-HX
R-RESC1608N-HX
SCT1_SOY
SCT1_G_IN
SCT1_B_IN
SCT1_R_IN
CE81
CE81
470uF/16V
470uF/16V
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
+
+
CE83
CE83
1000uF/25V
1000uF/25V
M-ED10-05.0-HX
M-ED10-05.0-HX
NEARLY MT5331
SCT1_AUL_INSCT1_AUR_IN
12
D28
D28
ECVAL160805E20100
ECVAL160805E20100
R-INDC1608N-HX
R-INDC1608N-HX
R-INDC1608N-HX
R-INDC1608N-HX
D73
D73
NS/ZENER/6.2V
NS/ZENER/6.2V
R-SOD2514N-HX
R-SOD2514N-HX
L52
L52
4.7uH
4.7uH
R-INDC2012N-HX
R-INDC2012N-HX
R269
R269
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R273
R273
0_NC
0_NC
R-RESC1608N-HX
R-RESC1608N-HX
R286
R286
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R285
R285
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R284
R284
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R287
R287
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R288
R288
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R290
R290
100
100
R-RESC1608N-HX
R-RESC1608N-HX
C88
C88
NS/10nF
NS/10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
12
D31
D31
ECVAL160805E20100
ECVAL160805E20100
R-INDC1608N-HX
R-INDC1608N-HX
L51
L51
FB
FB
+
+
CE84
CE84
10uF/25V
10uF/25V
R-CAPAE-D4.0X5.4-HX
R-CAPAE-D4.0X5.4-HX
SOY1SOY1
C144
C144
1nF
1nF
R-CAPC1608N-HX
R-CAPC1608N-HX
Y1P
C145
C145
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
Y1N
C139
C139
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
PB1P
C146
C146
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
PB1N
C143
C143
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
PR1P
C138
C138
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
PR1N
C142
C142
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
R229
R229
NS/10K
NS/10K
R-RESC1608N-HX
R-RESC1608N-HX
OPAVREF
OPAVREF
C120
C120
1uF
1uF
R-CAPC2012N-HX
R-CAPC2012N-HX
+
CE82
+
CE82
10uF/25V
10uF/25V
R-CAPAE-D4.0X5.4-HX
R-CAPAE-D4.0X5.4-HX
CB194
CB194
CB193
CB193
0.1uF
0.1uF
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
AGND_AFE1,2,3,4,5,6,7,8,9,11,12,13,14
SCT1_AUR_IN12
SCT1_AUL_IN12
SCT1_AV_OUT3
AGND_AFE
SCT1_AUR_IN
SCT1_AUL_IN
SCART1 AUDIO INPUT
SCT1_AV_OUT
SCART1 VIDEO OUTPUT
SOY15
Y1P5
Y1N5
PB1P5
PB1N5
PR1P5
PR1N5
SCART RGB INPUT (TO MT5331)
ADIN05
SOY1
Y1P
Y1N
PB1P
PB1N
PR1P
PR1N
ADIN0
SCART1 DETECT
FB_IN5
SY15
SC15
Scart_S INPUT
CVBS15
Scart_AV INPUT
AL15
AR15
INTERNAL AUDIO DAC OUTPUT
MUTE12,13
AO1AUXR12,13
AO1AUXL12,13
+12V1,2,12,13
FB_IN
SY1
SC1
CVBS1
AL1
AR1
MUTE
AO1AUXR
AO1AUXL
+12V
INTERNAL AUDIO DAC OUTPUT
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
SCART1 INPUT
SCART1 INPUT
SCART1 INPUT
Document Number
Document Number
Document Number
Size
Size
Size
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
C
C
C
Date: Sheet
Date: Sheet
A
Date: Sheet
TEL:(03)567-0766 FAX:(03)578-7610
Drawn
Drawn
Drawn
Terry
Terry
Terry
Rev
Rev
Rev
1
1
1
of
of
of
10 14Wednesday, September 05, 2007
10 14Wednesday, September 05, 2007
10 14Wednesday, September 05, 2007
Page 49
A
+5V1,2,3,7,14
NEARLY VGA CONNECTOR NEARLY MT5370
C99
C99
1nF
1nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C100
C100
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C102
C102
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C103
C103
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C105
C105
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C106
C106
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
C108
C108
10nF
10nF
R-CAPC1608N-HX
R-CAPC1608N-HX
VGA_PLUGPWR
8
VGAROMWP
7
VGASCL
6
VGASDA
5
D38
D38
MVS0603E10
MVS0603E10
SOG
GP
GN
BP
BN
RP
RN
1 2
R222
R222
20K
20K
R-RESC1608N-HX
R-RESC1608N-HX
VGAR_IN
VGAL_INVGAL_INVGAL_INVGAL_INVGAL_INVGAL_IN
D39
D39
MVS0603E10
MVS0603E10
1 2
1
Q105
Q105
2N3904
2N3904
2 3
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
GPIO_8
R1811
R1811
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
Size
Size
Size
C
C
C
Date: Sheet
Date: Sheet
Date: Sheet
R200
1617
RED_GND
6
RED
1
11
VGASDA_IN
12
HSYNC#
13
VSYNC#
14
VGASCL_IN
15
VGASCL_IN VGASCL
VGASDA_IN VGASDA
A A
HDMIDDCSCL
HDMIDDCSDA
HDMI_PLUGPWR
HDMI_PLUGPWR
OPCTRL0
12
D42
D42
R-INDC1608N-HX
R-INDC1608N-HX
12
D43
D43
R-INDC1608N-HX
R-INDC1608N-HX
D181
D181
1 2
MVS0603E10
MVS0603E10
R5531KR553
1K
R219
R219
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R220
R220
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R572 100R572 100
R571 100R571 100
D54
D54
SCHOTTKY DIODE/B240A
SCHOTTKY DIODE/B240A
R-SOD3718N-HX
R-SOD3718N-HX
1
7
2
8
3
9
4
10
5
P10
P10
D-SUB15/FEMALE
D-SUB15/FEMALE
M-DSUB-15A-HX
M-DSUB-15A-HX
VGA_PLUGPWR
R214
R214
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
C113
C113
33pF
33pF
R-CAPC1608N-HX
R-CAPC1608N-HX
VGA_PLUGPWR
R216
R216
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
C114
C114
33pF
33pF
R-CAPC1608N-HX
R-CAPC1608N-HX
0603ESDA-MLP
0603ESDA-MLP
HDMICAB
Q106
Q106
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
GRN_GND
GRN
BLU_GND
BLU
D34
D34
1N4148
1N4148
R-SOD3718N-HX
R-SOD3718N-HX
12
D35
D35
R-INDC1608N-HX
R-INDC1608N-HX
P23
P23
HDMI/TYPE-A
HDMI/TYPE-A
R-DC1R019JD1-HX
R-DC1R019JD1-HX
RX2
D1720603ESDA-MLP D1720603ESDA-MLP
1 2
RX2B
D173
D173
1 2
RX1
D1740603ESDA-MLP D1740603ESDA-MLP
1 2
RX1B
D1750603ESDA-MLP D1750603ESDA-MLP
1 2
RX0
D1760603ESDA-MLP D1760603ESDA-MLP
1 2
RX0B
D1770603ESDA-MLP D1770603ESDA-MLP
1 2
RXC
D1780603ESDA-MLP D1780603ESDA-MLP
1 2
RXCB
D1790603ESDA-MLP D1790603ESDA-MLP
1 2
R573 10K/NCR573 10K/NC
PWR5V
R5701KR570
1K
R1771
R1771
D52
D52
1 2
D182 MVS0603E10D182 MVS0603E10
100K
100K
MVS0603E10
MVS0603E10
1 2
1 2
VGA_PLUGPWR
D53 MVS0603E10D53 MVS0603E10
+5V
2221
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 23
GND
GRN
GRN_GND
BLU
BLU_GND
RED
RED_GND
R310
R310
510
510
R-RESC1608N-HX
R-RESC1608N-HX
R327
R327
510
510
R-RESC1608N-HX
R-RESC1608N-HX
12
D33
D33
R-INDC1608N-HX
R-INDC1608N-HX
12
D36
D36
R-INDC1608N-HX
R-INDC1608N-HX
12
D37
D37
R-INDC1608N-HX
R-INDC1608N-HX
L556
L556
2.2uH
2.2uH
R-INDC2012N-HX
R-INDC2012N-HX
R311
R311
2K
2K
R-RESC1608N-HX
R-RESC1608N-HX
L557
L557
2.2uH
2.2uH
R-INDC2012N-HX
R-INDC2012N-HX
R326
R326
2K
2K
R-RESC1608N-HX
R-RESC1608N-HX
D32
D32
1N4148
1N4148
R-SOD3718N-HX
R-SOD3718N-HX
HSYNC# HSYNC
12
D40
D40
R-INDC1608N-HX
R-INDC1608N-HX
VSYNC# VSYNC
12
D41
D41
R-INDC1608N-HX
R-INDC1608N-HX
MODIFY BY TONY(2007-06-26)
HDMI_PLUGPWR HDMI_PLUGPWR
R4962KR496
2K
HDMIDDCSCL HDMIDDCSDA
HDMIDDCSCL OSCL1
+5V
D180
D180
SCHOTTKY DIODE/B240A
SCHOTTKY DIODE/B240A
R-SOD3718N-HX
R-SOD3718N-HX
CB968
CB968
0.1uF
0.1uF
R4952KR495
2K
OSDA1HDMIDDCSDA
HDMI_PLUGPWR
HDMI_PLUGPWR
U56
U56
1
NC
2
NC
3
NC
GND4SDA
EEPROM/24C02
EEPROM/24C02
VCC
WP
SCL
R202
R202
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R205
R205
75
75
R-RESC1608N-HX
R-RESC1608N-HX
R208
R208
75
75
R-RESC1608N-HX
R-RESC1608N-HX
C111
C111
5pF
5pF
R-CAPC1608N-HX
R-CAPC1608N-HX
C112
C112
5pF
5pF
R-CAPC1608N-HX
R-CAPC1608N-HX
HDMI_PLUGPWR
8
HDMIDDCWP
7
HDMIDDCSCL
6
HDMIDDCSDA
5
C101
C101
5pF
5pF
R-CAPC1608N-HX
R-CAPC1608N-HX
R226
R226
0
0
R-RESC1608N-HX
R-RESC1608N-HX
C104
C104
5pF
5pF
R-CAPC1608N-HX
R-CAPC1608N-HX
R227
R227
0
0
R-RESC1608N-HX
R-RESC1608N-HX
C107
C107
5pF
5pF
R-CAPC1608N-HX
R-CAPC1608N-HX
R233
R233
0
0
R-RESC1608N-HX
R-RESC1608N-HX
P12
P12
PHONEJACK STEREO
PHONEJACK STEREO
M-CK3-3.5-02-HX
M-CK3-3.5-02-HX
R505
R505
20K
20K
1
Q16
Q16
2N3904
2N3904
2 3
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
R200
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R201
R201
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R203
R203
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R204
R204
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R206
R206
100
100
R-RESC1608N-HX
R-RESC1608N-HX
R207
R207
68
68
R-RESC1608N-HX
R-RESC1608N-HX
R209
R209
100
100
R-RESC1608N-HX
R-RESC1608N-HX
VGA_PLUGPWR
CB198
CB198
U23
U23
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
1
NC
VCC
2
NC
WP
3
NC
SCL
GND4SDA
EEPROM/24C02
EEPROM/24C02
R-SOIC08N-1.270-6.00-HX
R-SOIC08N-1.270-6.00-HX
R
R
3
4
2
L
L
1
5
VGA AUDIO INPUT(BY TONY 2007-06-25)
GPIO_8
R299
R299
4.7K
4.7K
R-RESC1608N-HX
R-RESC1608N-HX
A
AGND_AFE1,2,3,4,5,6,7,8,9,10,12,13,14
SOG5
GP5
GN5
BP5
BN5
RP5
RN5
HSYNC5
VSYNC5
VGAL_IN12
VGAR_IN12
GPIO_85
OPCTRL05
VGA\HDMI INPUT
VGA\HDMI INPUT
VGA\HDMI INPUT
Document Number
Document Number
Document Number
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
VGA VIDEO INPUT
VGA AUDIO INPUT
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
+5V
AGND_AFE
SOG
GP
GN
BP
BN
RP
RN
HSYNC
VSYNC
VGAL_IN
VGAR_IN
GPIO_8
RXCB5
RXC5
RX0B5
RX05
RX1B5
RX15
RX2B5
RX25
PWR5V5
OSDA15,14
OSCL15,14
GND1,2,3,4,5,6,7,8,9,10,12,13,14
RXCB
RX0B
RX1B
RX2B
PWR5V
OSDA1
OSCL1
OPCTRL0
GND
RXC
RX0
RX1
RX2
HDMI INPUT
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
Drawn
Drawn
Drawn
Terry
Terry
Terry
11 14Wednesday, September 05, 2007
11 14Wednesday, September 05, 2007
11 14Wednesday, September 05, 2007
Rev
Rev
Rev
1
1
1
of
of
of
Page 50
A
R1815
R1815
OPCTRL1
NS/1K
NS/1K
R-RESC1608N-HX
R458
MUTE
DV33_CODEC
VMIDADC
DV33_CODEC
DV33_CODEC
VMIDDAC
R458
470
470
R-RESC1608N-HX
R-RESC1608N-HX
R367
R367
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
HPVDD
C945
C945
1uF
1uF
SIF_SDA
SIF_SCL
R370
R370
MUTE#
100
100
Q33
Q33
R-RESC1608N-HX
1
C944
C944
1uF
1uF
R-RESC1608N-HX
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
VMIDADC DV33_CODEC
+
CE68
+
CE68
100uF/10v
100uF/10v
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
+
VO0R AO1AUXR
VO0L
MUTE
HPOR
HPOL
+
CE72
CE72
10uF/16v R-CAPC2012N-HX
10uF/16v R-CAPC2012N-HX
+
+
CE73
CE73
10uF/16v R-CAPC2012N-HX
10uF/16v R-CAPC2012N-HX
R1814
R1814
1
NC/1K
NC/1K
R-RESC1608N-HX
R-RESC1608N-HX
+
+
CE77
CE77
330uF/25v M-ED8.0-05.0-HX
330uF/25v M-ED8.0-05.0-HX
+
+
CE78
CE78
330uF/25v M-ED8.0-05.0-HX
330uF/25v M-ED8.0-05.0-HX
C115 1uFC115 1uF
C116
C116
1uF
+
VGAR_IN
VGAL_IN
YPBPR0R_IN
YPBPR0L_IN
SCT1_AUR_IN
SCT1_AUL_IN
AVR_IN
AVL_IN
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33
L49
L49
FB
FB
R-INDC1608N-HX
R-INDC1608N-HX
A A
+12V
L50
L50
FB
FB
R-INDC1608N-HX
R-INDC1608N-HX
+
CE59
CE59
10uF/16V R-CAPC2012N-HX
10uF/16V R-CAPC2012N-HX
+
+
CE615
CE615
10uF/16V R-CAPC2012N-HX
10uF/16V R-CAPC2012N-HX
+
+
CE61
CE61
10uF/16V R-CAPC2012N-HX
10uF/16V R-CAPC2012N-HX
+
+
CE63
CE63
10uF/16V R-CAPC2012N-HX
10uF/16V R-CAPC2012N-HX
+
+
CE66
CE66
10uF/16V R-CAPC2012N-HX
10uF/16V R-CAPC2012N-HX
+
+
CE67
CE67
10uF/16V R-CAPC2012N-HX
10uF/16V R-CAPC2012N-HX
+
+
CE616
CE616
10uF/16V R-CAPC2012N-HX
10uF/16V R-CAPC2012N-HX
+
+
CE617
CE617
10uF/16V R-CAPC2012N-HX
10uF/16V R-CAPC2012N-HX
AO1BCK
AO1LRCK
AO1MCLK
AO1SDATA4
AO1SDATA3
C119
C119
NS/22pF
NS/22pF
I2SIN_DATA
DV33_CODEC
+
CE76
+
CE76
10uF/16V
10uF/16V
R-CAPC2012N-HX
R-CAPC2012N-HX
HPVDD
+
CE79
+
CE79
10uF/16V
10uF/16V
R-CAPC2012N-HX
R-CAPC2012N-HX
1uF
R289
R289
33K
R-RESC1608N-HX
33K
R-RESC1608N-HX
R292
R292
33K
R-RESC1608N-HX
33K
R-RESC1608N-HX
R295
R295
33K
R-RESC1608N-HX
33K
R-RESC1608N-HX
R296
R296
33K
R-RESC1608N-HX
33K
R-RESC1608N-HX
C942 1uFC942 1uF
C943 1uFC943 1uF
R300
R300
33K
R-RESC1608N-HX
33K
R-RESC1608N-HX
R301
R301
33K
R-RESC1608N-HX
33K
R-RESC1608N-HX
C1171uFC1171uF
C1181uFC1181uF
R302
R302
33K
R-RESC1608N-HX
33K
R-RESC1608N-HX
R303
R303
33K
R-RESC1608N-HX
33K
R-RESC1608N-HX
RN26 33x4
RN26 33x4
1 8
2 7
3 6
4 5
R308 33
R308 33
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R309 33
R309 33
R-RESC1608N-HX
R-RESC1608N-HX
TWO WIRE SERIAL CONTROL
DEVICE ADDRESS 0x34H
CB189
CB189
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R1819 470
R1819 470
R-RESC1608N-HX
R-RESC1608N-HX
CB192
CB192
CB191
CB191
0.1uF
0.1uF
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
U35
U35
1
AIN6L
2
AIN7R
3
AIN7L
4
BCLK0
5
LRCK0
6
MCLK0
7
DIN0
8
DIN1
9
BCLK1
10
LRCK1
11
MCLK1
12
DOUT
MT8291_ResetGPIO_0
R-CAPC1608N-HX
R-CAPC1608N-HX
45
47
44
46
48
AIN4L
AIN5L
AIN5R
AIN6R
MT8291
MT8291
DGND13DVDD14RESET#15MUTE#16DI17CL18HPOUTL19HPGND20HPVDD21HPOUTR22VOUT0L23VOUTOR
MUTE#
DV33_CODEC
CB190
CB190
0.1uF
0.1uF
DV33_CODEC
37
39
41
43
38
40
42
AIN1L
AIN2L
AIN3L
AIN1R
AIN2R
AIN3R
AIN4R
ADCV33
ADCGND
ADCREFP
ADCREFN
VIMDADC
DAV33
DACREFP
DACREFN
DACGND
VMIDDAC
AVDD
VOUT1R
VOUT1L
24
VO0L
VO0R
HPOL
HPOR
HPVDD
R314
R314
10K
10K
C946
C946
C137
C137
22pF
22pF
22pF
22pF
36
35
34
33
32
31
30
29
28
27
26
25
DV33_CODEC
R-RESC1608N-HX
R-RESC1608N-HX
R402 22R402 22
R403 22R403 22
OPCTRL7
R-RESC1608N-HX
R1812
R1812
GPIO_19
NS/1K
NS/1K
R-RESC1608N-HX
R-RESC1608N-HX
R313
R313
OFF_MUTE
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
CB183
CB183
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R304 470
R304 470
R305 470
R305 470
MT8291_Reset
Q108
Q108
2SD2653K/NS
2SD2653K/NS
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
R315 20
R315 20
R316 20
R316 20
Q107
Q107
1
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
+
CE69
+
CE69
100uF/10v
100uF/10v
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
CB185
CB185
4.7nF
4.7nF
R-CAPC1608N-HX
R-CAPC1608N-HX
R8
R8
NC/4.7K
NC/4.7K
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R317
R317
47K
47K
R-RESC1608N-HX
R-RESC1608N-HX
R1813
R1813
200
200
R-RESC1608N-HX
R-RESC1608N-HX
+
+
CB184
CB184
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
CB186
CB186
4.7nF
4.7nF
R-CAPC1608N-HX
R-CAPC1608N-HX
HPOR_OUT
HPOL_OUT
R318
R318
47K
47K
R-RESC1608N-HX
R-RESC1608N-HX
VMIDDAC
CB231
CE183
CE183
33uF/16v
33uF/16v
R-CAPAE-D5.0X5.4-HX
R-CAPAE-D5.0X5.4-HX
CB231
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R306
R306
47K
47K
R-RESC1608N-HX
R-RESC1608N-HX
HPOR_OUT 13
HPOL_OUT 13
AO1AUXL
R307
R307
47K
47K
R-RESC1608N-HX
R-RESC1608N-HX
+12V1,2,10,13
DV332,5,6,7,14
GND1,2,3,4,5,6,7,8,9,10,11,13,14
AGND_AFE1,2,3,4,5,6,7,8,9,10,11,13,14
OPCTRL75
OPCTRL15
SCT1_AUR_IN10
SCT1_AUL_IN10
SCART1 AUDIO INPUT
AVR_IN9
AVL_IN9
AV/S_VIDEO AUDIO INPUT
YPBPR0R_IN9
YPBPR0L_IN9
YPBPR AUDIO INPUT
VGAL_IN11
VGAR_IN11
VGA AUDIO INPUT
AO1SDATA35
I2SIN_DATA5
AO1SDATA45
AO1MCLK5
AO1BCK5
AO1LRCK5
AUDIO I2S INTERFACE
AO1AUXR10,13
AO1AUXL10,13
+12V
DV33
GND
AGND_AFE
OPCTRL7
OPCTRL1
SCT1_AUR_IN
SCT1_AUL_IN
YPBPR0R_IN
YPBPR0L_IN
AO1SDATA3
I2SIN_DATA
AO1SDATA4
AO1MCLK
AO1BCK
AO1LRCK
AO1AUXR
AO1AUXL
AVR_IN
AVL_IN
VGAL_IN
VGAR_IN
OPCTRL1
GPIO_19
OPAV120
R346
R346
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
D71
D71
1N4148
1N4148
R-SOD3718N-HX
R-SOD3718N-HX
R331
R331
1
NC/10K
NC/10K
R-RESC1608N-HX
R-RESC1608N-HX
C
B
E
R406
R406
0
0
R-RESC1608N-HX
R-RESC1608N-HX
R320
R320
5.1K
5.1K
R-RESC1608N-HX
R-RESC1608N-HX
R324
R324
1k
1k
R-RESC1608N-HX
R-RESC1608N-HX
R328
R328
0/1k
0/1k
R-RESC1608N-HX
R-RESC1608N-HX
Q25
Q25
2SD2653K
2SD2653K
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
2 3
1
3906
1
23
Q21
Q21
2N3906
2N3906
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
R4070R407
0
Q24
Q24
2N3906
2N3906
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
R329
R329
100K
100K
R-RESC1608N-HX
R-RESC1608N-HX
R319
R319
1K
1K
R-RESC1608N-HX
R-RESC1608N-HX
R321
R321
2K
2K
R-RESC1608N-HX
R-RESC1608N-HX
R347
R347
100K
100K
OFF_MUTE MUTE
MUTE CIRCUIT
Modify by tony(2007-07-18)
+
CE80
+
CE80
330uF/25v
330uF/25v
D72
D72
1N4148
1N4148
R-SOD3718N-HX
R-SOD3718N-HX
R330
R330
100K
100K
R-RESC1608N-HX
R-RESC1608N-HX
MUTE
MUTE
R322
R322
1
1K
1K
R-RESC1608N-HX
R-RESC1608N-HX
R332
R332
1
1K
1K
R-RESC1608N-HX
R-RESC1608N-HX
AO1AUXR
Q22
Q22
2SD2653K/NS
2SD2653K/NS
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
AO1AUXL
Q26
Q26
2SD2653K/NS
2SD2653K/NS
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
MUTE
MUTE
A
R323
R323
1
1K
1K
R-RESC1608N-HX
R-RESC1608N-HX
R333
R333
1
1K
1K
R-RESC1608N-HX
R-RESC1608N-HX
HPOR_OUT
Q23
Q23
2SD2653K
2SD2653K
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
HPOL_OUT
Q27
Q27
2SD2653K
2SD2653K
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
SIF_SDA4,7
SIF_SCL4,7
GPIO_04,5,7
GPIO_195
MUTE10,13
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
AUDIO CODEC
AUDIO CODEC
AUDIO CODEC
Document Number
Document Number
Document Number
Size
Size
Size
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
Custom
Custom
Custom
Date: Sheet
Date: Sheet
Date: Sheet
SIF_SDA
SIF_SCL
GPIO_0
GPIO_19
MUTE
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
Drawn
Drawn
Drawn
Terry
Terry
Terry
Rev
Rev
Rev
1
1
1
of
of
of
12 14Wednesday, September 05, 2007
12 14Wednesday, September 05, 2007
12 14Wednesday, September 05, 2007
Page 51
A
+12VAMP+12V
R1782
R1782
10K
10K
MUTE_Audio
R1784
MUTE
R1785 1KR1785 1K
MUTE
MUTEC
R1 10K/NCR1 10K/NC
R1784
1
8.2K
8.2K
2 3
MUTE_Pop
2N3904
2N3904
Q102
Q102
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
Q1
Q1
1
2SD2653K/NC
2SD2653K/NC
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
MUTE
L_1517
1N4148
1N4148
1 2
D187
D187
Reserve to solve POP noise when POWER ON/OFF
+12V
R1791
R1791
R-SOD3718N-HX
R-SOD3718N-HX
100
100
D74 1N4148
D74 1N4148
1000uF/16v
1000uF/16v
CE585
CE585
D751N4148
D751N4148
R-SOD3718N-HX
R-SOD3718N-HX
A A
R1790 47KR1790 47K
A-E8.0-R-HX
A-E8.0-R-HX
+
+
Q30 2N3906
Q30 2N3906
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
R1786 1KR1786 1K
MUTE_Pop
1
R17890R1789
0
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
+
+
CE586
CE586
47uF/16v/NC
47uF/16v/NC
MUTE
R1783
R1783
1
10K
10K
MUTE_AUDIO
2N3904
2N3904
Q103
Q103
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
R2 10K/NCR2 10K/NC
1
2 3
R_1517
Q2
Q2
2SD2653K/NC
2SD2653K/NC
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
Connect to a Headphone Socket with switch
HPOL_OUT12
HPOR_OUT12
HPOL_OUTHPOL_OUT
HPOR_OUT
MVS0603E10
MVS0603E10
HPDET#
D189
D189
1 2
DVDD33
D11
D11
MVS0603E10
MVS0603E10
1 2
R3
R3
47K
47K
R-RESC1608N-HX
R-RESC1608N-HX
R5 4.7K
R5 4.7K
R-RESC1608N-HX
R-RESC1608N-HX
HPDET#
D10
D10
MVS0603E10
MVS0603E10
1 2
DVDD33
1
2 3
R4
R4
47K
47K
R-RESC1608N-HX
R-RESC1608N-HX
R6 4.7K
R6 4.7K
R-RESC1608N-HX
R-RESC1608N-HX
Q3
Q3
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
HEAD PHONE OUTPUT
MUTEC
M-AV6-W-AVY-HX
M-AV6-W-AVY-HX
1
V
2
GND
3
L
4
GND
5
R
6
GND
7
R
8
Y
9
GND
10
PB
11
GND
12
PR
14
PR
13
GND
J32
J32
+12V1,2,10,12
DV332,5,6,7,12,14
GND1,2,3,4,5,6,7,8,9,10,11,12,14
AGND_AFE1,2,3,4,5,6,7,8,9,10,11,12,14
AV331,2,5,6
OPCTRL25
AO1AUXR10,12
AO1AUXL10,12
MUTE10,12
GPIO_195,12
+12V
DV33
GND
AGND_AFE
AV33
OPCTRL2
DVDD33
DVDD334
AO1AUXR
AO1AUXL
MUTE
GPIO_19
Reserve to solve Pop Noise when 12V Noise POWER ON/OFF
PANISHE 2007-07-27
AUDIO - ANALOG AMPLIFIER
GPIO19 H
ON
L
LGPIO20
8.5-18V
MUTE
L
3.3-6.4V
SB
H
H
0-2V
Audio AMP
TPA1517/TDA1517P
TPA1517/TDA1517P
R1693 470R1693 470
AO1AUXR R_1517
R1722 470R1722 470
R1721
R1721
10K NC
10K NC
R1723
R1723
10K NC
10K NC
C938 10uFC938 10uF
C939 10uFC939 10uF
L_1517AO1AUXL
C940
C940
3.3nF
3.3nF
MUTE_AUDIO
C941
C941
3.3nF
3.3nF
U129
U129
18
IN11SGND2SVRR3OUT14GND5OUT26VPP7MUTE8IN2
R325 100R325 100
A
GND10GND11GND12GND13GND14GND15GND16GND17GND
9
C647
C647
0.1uF
0.1uF
0.1uF
0.1uF
R1787
R1787
10K
10K
CE584
CE584
+
+
1uF/25v
1uF/25v
R-CAPAE-D6.3X5.4-HX
R-CAPAE-D6.3X5.4-HX
L549FBL549
+12V
FB
+12VAMP
C603
C603
0.1uF
0.1uF
+
+
CE135 470uF/16v
CE135 470uF/16v
+
+
CE136 470uF/16v
CE136 470uF/16v
C648
C648
R1788
R1788
10K
10K
OPCTRL2
+12VAMP
R26 1KR26 1K
+
+
CE583
CE583
470uF/16V
470uF/16V
1
将
CE582
M-TJC3-4A-HX
M-TJC3-4A-HX
4x1 W/HOUSING
4x1 W/HOUSING
4
3
2
1
J29
J29
SVRR
R181747R1817
47
2N3904
2N3904
Q8
Q8
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
封装更改为插件封装。
CE582
CE582
+
+
470uF/16v
470uF/16v
M-ED8.0-05.0-HX
M-ED8.0-05.0-HX
2007-09-04
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
SCART AUDIO OUT AND AMP
SCART AUDIO OUT AND AMP
SCART AUDIO OUT AND AMP
Document Number
Document Number
Document Number
Size
Size
Size
MT5330_SZ_V1.8
MT5330_SZ_V1.8
MT5330_SZ_V1.8
C
C
C
Date: Sheet
Date: Sheet
Date: Sheet
TEL:(03)567-0766 FAX:(03)578-7610
Drawn
Drawn
Drawn
Terry
Terry
Terry
Rev
Rev
Rev
1
1
1
of
of
of
13 14Wednesday, September 05, 2007
13 14Wednesday, September 05, 2007
13 14Wednesday, September 05, 2007
Page 52
5
P2
P2
1
+5V
DV33
+5V
5
GND
2
D3
3
D4
4
D5
5
D6
6
D7
7
CE1#
8
A10
9
OE#
10
A11
11
A9
12
A8
13
A13
14
A14
15
WE#
16
RDY/BSY
17
VCC
18
VPP1
19
A16
20
A15
21
A12
22
A7
23
A6
24
A5
25
A4
26
A3
27
A2
28
A1
29
A0
30
D0
31
D1
32
D2
33
WP
34
GND
GND
70
OE#
PORT PCMCIA 68-PIN
PORT PCMCIA 68-PIN
71
M-PCMCIA-RSD-HX
M-PCMCIA-RSD-HX
C58
C58
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
R211
R211
CB253
CB253
0.1uF
0.1uF
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
C53
C53
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
R150
R150
CB196
CB196
0.1uF
0.1uF
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
R162
R162
CB199
CB199
0.1uF
0.1uF
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
C54
C54
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
CB205
CB205
R168
R168
0.1uF
0.1uF
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
PCMCIA
PCMCIA
CB252
CB252
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
1
CB195
CB195
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
1
DV33
1
CB206
CB206
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
1
PDD3
PDD4
PDD5
PDD6
PDD7
PDCE1#
PDA10
PDOE#
PDA11
PODOUTCLK
R-RESC1608N-HX
R-RESC1608N-HX
POD_VCC POD_VCC
D D
POD_VPP
PDIOIS16#
C C
GPIO_65
B B
A A
R138
R138
0/NS
0/NS
GPIO_12
GPIO_6
PDCTRLVPP
PDCTRLVPP#
PDA9
PDA8
PDA13
PDA14POD
PDWE#
PDIREQ#
PODINVALID
PODINCLK
PDA12
PDA7
PDA6
PDA5
PDA4
PDA3
PDA2
PDA1
PDA0
PDD0
PDD1
PDD2
R177
R177
0/NS
0/NS
R-RESC1608N-HX
R-RESC1608N-HX
R212
R212
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R149
R149
10K/NS
10K/NS
R-RESC1608N-HX
R-RESC1608N-HX
R161
R161
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R167
R167
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
35
GND
36
CD1#
37
D11
38
D12
39
D13
40
D14
41
D15
42
CE2#
43
RFSH
44
RFU
45
RFU
46
A17
47
A18
48
A19
49
A20
50
A21
51
VCC
52
VPP2
53
A22
54
A23
55
A24
56
A25
57
RFU
58
RESET
59
WAIT#
60
RFU
61
REG#
62
BVD2
63
BVD1
64
D8
65
D9
66
D10
67
CD2#
68
GND
GND
69
OE#
72
R190
R190
CB251
CB251
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R-CAPC2012N-HX
R-CAPC2012N-HX
Q29
Q29
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
D16
D16
CB197
CB197
R146
R146
SCHOTTKY DIODE/B240A
SCHOTTKY DIODE/B240A
1uF
1uF
10K
10K
R-DIOM5326N-HX
R-DIOM5326N-HX
R-CAPC2012N-HX
R-CAPC2012N-HX
R-RESC1608N-HX
R-RESC1608N-HX
Q9
Q9
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
R156
R156
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
Q10
Q10
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
CB204
CB204
1uF
1uF
R163
R163
R-CAPC2012N-HX
R-CAPC2012N-HX
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
Q11
Q11
2N3904
2N3904
R-SOT3N-0.95-2.80-HX
R-SOT3N-0.95-2.80-HX
2 3
PDCD1#
PODOUTDATA3
PODOUTDATA4
PODOUTDATA5
PODOUTDATA6
PODOUTDATA7
PDCE2#
PDVS1#
PDIORD#
PDIOWR#
PODINSYNC
PODINDATA0
PODINDATA1
PODINDATA2
PODINDATA3
PODINDATA4
PODINDATA5
PODINDATA6
PODINDATA7
PDVS2#
PDRESET
PDWAIT#
PDINPACK#
PDREG#
PODOUTVALID
PODOUTSYNC
PODOUTDATA0
PODOUTDATA1
PODOUTDATA2
PDCD2#
1uF
1uF
U48
U48
1
S1
2
G1
3
S2
4
G2
IRF7314
IRF7314
R-SOIC08N-1.270-6.00-HX
R-SOIC08N-1.270-6.00-HX
CB200
CB200
1uF
1uF
R-CAPC2012N-HX
R-CAPC2012N-HX
8
D1
7
D1
6
D2
5
D2
P-CH
P-CH
POD_VPP
D17
D17
R158
R158
SCHOTTKY DIODE/B240A
SCHOTTKY DIODE/B240A
100K
100K
R-RESC1608N-HX
R-RESC1608N-HX
R-DIOM5326N-HX
R-DIOM5326N-HX
U47
U47
1
S1
D1
2
G1
D1
3
S2
D2
4
D2
G2
P-CH
P-CH
IRF7314
IRF7314
R-SOIC08N-1.270-6.00-HX
R-SOIC08N-1.270-6.00-HX
POD_VPP
R142
R142
0
0
R-RESC1608N-HX
R-RESC1608N-HX
R148
R148
100K
100K
R-RESC1608N-HX
R-RESC1608N-HX
8
7
6
5
4
C50
C50
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
PODOUTCLK
POD_VPP
4
C49
C49
10uF/10v
10uF/10v
R-CAPC2012N-HX
R-CAPC2012N-HX
POD_VCC
+
CE21
+
CE21
220uF/16V
220uF/16V
M-ED6.3-05.0-HX
M-ED6.3-05.0-HX
+
CE26
+
CE26
220uF/16V
220uF/16V
M-ED6.3-05.0-HX
M-ED6.3-05.0-HX
RN31
RN31
PODINDATA5
PODINCLK
PODINDATA6
PODINDATA7
POD_VCC
R143
R143
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
PDIREQ#
POD_VCC POD_VCC
R151
R151
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
PDCD1# PDVS1#
POD_VCC
R154
R154
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
PDVS2#
POD_VCC
R159
R159
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
PDINPACK#
POD_VCC
POD_VCC
R164
R164
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
R165
R165
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
PODOUTSYNC
PODOUTVALID
PDCTRLVPP PDCTRLVPP#
PODINDATA2
PODINDATA3
PODINDATA4
PODINVALID
PODINSYNC
PODINDATA0
PODINDATA1
POD_VCC
R144
R144
NS/10K
NS/10K
R-RESC1608N-HX
R-RESC1608N-HX
PDIOIS16#
R152
R152
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
POD_VCC
R155
R155
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
PDWAIT#
POD_VCC
R160
R160
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
PDCD2#
R37
R37
R35
R35
DV33
147
U140A
U140A
1 2
74HC14
74HC14
R-TSOP14N-0.650-6.40-HX
R-TSOP14N-0.650-6.40-HX
DV33
147
U140B
U140B
3 4
74HC14
74HC14
R-TSOP14N-0.650-6.40-HX
R-TSOP14N-0.650-6.40-HX
RN32
RN32
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
RN33
RN33
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESCA3216-8N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
R-RESC1608N-HX
CB217
CB217
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
PDENPOD#PDENPOD
45
36
27
18
45
36
27
18
45
36
27
18
GPIO_795
PDA14POD
R145
R145
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
PDA6
R153
R153
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
PDIOIS16#
R188
R188
10K
10K
R-RESC1608N-HX
R-RESC1608N-HX
OSDA1
NS/0
NS/0
NS/0
NS/0
47Kx4
47Kx4
OSCL1
3
47Kx4
47Kx4
47Kx4
47Kx4
PDENPOD#
GPIO_79
U37
PDA14
PDA15
TS0INSYNC
TS0INVALID
TS0INCLK TS0VALID
PDENPOD PDENPOD
SMCE#
DCLK
MCLK
PODOUTDATA0
PODOUTDATA1
PODOUTDATA2
PODOUTDATA3
PODOUTDATA4
PODOUTDATA5
PODOUTDATA6
PODOUTDATA7
R213 NS/0
R213 NS/0
R-RESC1608N-HX
R-RESC1608N-HX
R217 0
R217 0
R-RESC1608N-HX
R-RESC1608N-HX
TS0INDATA0
TS0INDATA1
TS0INDATA2
TS0INDATA3
TS0INDATA4
TS0INDATA5
TS0INDATA6
TS0INDATA7
PDENPOD
U37
2
1A1
VCC
4
1A2
1Y1
6
1A3
1Y2
8
1A4
1Y3
11
2A1
1Y4
13
2A2
2Y1
15
2A3
2Y2
17
2A4
2Y3
2Y4
1
1G
19
2G
GND
SN74LVC244APW
SN74LVC244APW
R-TSOP20N-0.650-6.40-HX
R-TSOP20N-0.650-6.40-HX
R139 0
R-RESC1608N-HX
R139 0
R-RESC1608N-HX
R140 0
R-RESC1608N-HX
R140 0
R-RESC1608N-HX
R141 0
R-RESC1608N-HX
R141 0
R-RESC1608N-HX
U32
U32
2
1A1
VCC
4
1A2
1Y1
6
1A3
1Y2
8
1A4
1Y3
11
2A1
1Y4
13
2A2
2Y1
15
2A3
2Y2
17
2A4
2Y3
2Y4
1
1G
19
2G
GND
SN74LVC244APW
SN74LVC244APW
R-TSOP20N-0.650-6.40-HX
R-TSOP20N-0.650-6.40-HX
IN-BAND SIGNAL
U30
EDATA0
EDATA1
EDATA2
EDATA3
EDATA4
EDATA5
EDATA6
EDATA7
PDENPOD
PDOE#
PDOE# WRITE READ
U30
2
A1
3
A2
4
A3
5
A4
6
A5
7
A6
8
A7
9
A8
19
G
1
DIR
NS/74LVC245A
NS/74LVC245A
R-TSOP20N-0.650-6.40-HX
R-TSOP20N-0.650-6.40-HX
1
U28
U28
2
1A1
4
1A2
6
1A3
8
1A4
11
2A1
13
2A2
15
2A3
17
2A4
1
1G
19
2G
SN74LVC244APW
SN74LVC244APW
R-TSOP20N-0.650-6.40-HX
R-TSOP20N-0.650-6.40-HX
VCC
B1
B2
B3
B4
B5
B6
B7
B8
GND
VCC
1Y1
1Y2
1Y3
1Y4
2Y1
2Y2
2Y3
2Y4
GND
20
PDA14POD
18
PODINCLKPDA16
16
PODINVALIDPDA17
14
PODINSYNC
12
TS0SYNC
9
7
TS0CLK
5
3
10
PDA23
PDA24
PDA25
DV33 DV33
20
TS0DATA0
18
TS0DATA1
16
TS0DATA2
14
TS0DATA3
12
TS0DATA4
9
TS0DATA5
7
TS0DATA6
5
TS0DATA7
3
10
DV33
20
PODOUTDATA0
18
PODOUTDATA1
17
PODOUTDATA2
16
PODOUTDATA3
15
PODOUTDATA4
14
PODOUTDATA5
13
PODOUTDATA6
12
PODOUTDATA7
11
10
0
DV33
20
TS0DATA0
18
TS0DATA1
16
TS0DATA2
14
TS0DATA3
12
TS0DATA4
9
TS0DATA5
7
TS0DATA6
5
TS0DATA7
3
10
PDENPOD#
GPIO_79
CB209
CB209
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
2
U34
U34
2
1A1
4
1A2
6
1A3
8
1A4
11
2A1
13
2A2
15
2A3
17
2A4
1
1G
19
2G
CB218
CB218
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
SN74LVC244APW
SN74LVC244APW
R-TSOP20N-0.650-6.40-HX
R-TSOP20N-0.650-6.40-HX
DV33
CB212
CB212
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
PDA18
PDA20
PDA21
PDA22
PDA23
PDA24
PDA25
BUS SWITCHING FOR A14-A25
U31
PODOUTSYNC
PODOUTVALID
PODOUTCLK
R224 NS/0
R224 NS/0
R-RESC1608N-HX
R-RESC1608N-HX
R218 0
R218 0
R-RESC1608N-HX
R-RESC1608N-HX
DV33
2
4
6
8
11
13
15
17
1
19
CB210
CB210
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
U31
1A1
1A2
1A3
1A4
2A1
2A2
2A3
2A4
1G
2G
SN74LVC244APW
SN74LVC244APW
R-TSOP20N-0.650-6.40-HX
R-TSOP20N-0.650-6.40-HX
DV33
CB213
CB213
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
VCC
1Y1
1Y2
1Y3
1Y4
2Y1
2Y2
2Y3
2Y4
GND
VCC
1Y1
1Y2
1Y3
1Y4
2Y1
2Y2
2Y3
2Y4
GND
CB215
CB215
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
DV33DV33
20
PODINDATA0PDA19
18
PODINDATA1
16
PODINDATA2
14
PODINDATA3
12
PODINDATA4
9
PODINDATA5
7
PODINDATA6
5
PODINDATA7
3
10
20
TS0SYNC
18
TS0VALID
16
TS0CLK
14
12
9
7
5
3
10
CB208
CB208
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
1
+5V1,2,3,7,11
DV332,5,6,7,12
GND1,2,3,4,5,6,7,8,9,10,11,12,13
GLOBAL SIGNAL
PDCD1#5
PDD[0..7]5,7
PDCE1#5
PDCE2#5
PDOE#5
PDIORD#5
PDIOWR#5
PDA[0..22]5,7
PDWE#5
PDIREQ#5
PDRESET5
PDWAIT#5
PDINPACK#5
PDREG#5
PDIOIS16#5
PDCD2#5
PDENPOD5
PDVS1#5
PDVS2#5
PDCTRLVPP5
SMCE#5,7
DCLK5,7
MCLK5,7
PCMCIA INTERFACE
GPIO_125
GPIO_795
TS0INDATA[0..7]4
TS0INSYNC4
TS0INVALID4
TS0INCLK4
TS INPUT FROM MT5131
TS0DATA[0..7]5
TS0SYNC5
TS0VALID5
TS0CLK5
TS TO MT5331
EDATA[0..7]5
OSDA15,11
OSCL15,11
+5V
DV33
GND
PDCD1#
PDD[0..7]
PDCE1#
PDCE2#
PDOE#
PDIORD#
PDIOWR#
PDA[0..22]
PDWE#
PDIREQ#
PDRESET
PDWAIT#
PDINPACK#
PDREG#
PDIOIS16#
PDCD2#
PDENPOD
PDVS1#
PDVS2#
PDCTRLVPP
SMCE#
DCLK
MCLK
GPIO_12
GPIO_79
TS0INDATA[0..7]
TS0INSYNC
TS0INVALID
TS0INCLK
TS0DATA[0..7]
TS0SYNC
TS0VALID
TS0CLK
EDATA[0..7]
OSDA1
OSCL1
TS bypass
U29
TS0INDATA0
TS0INDATA1
TS0INDATA2
TS0INDATA3
TS0INDATA4
TS0INDATA5
TS0INDATA6
TS0INDATA7
PDENPOD#
R221 NS/0
R221 NS/0
R-RESC1608N-HX
R-RESC1608N-HX
GPIO_80
R230 0
GPIO_805
3
R230 0
R-RESC1608N-HX
R-RESC1608N-HX
U29
2
1A1
4
1A2
6
1A3
8
1A4
11
2A1
13
2A2
15
2A3
17
2A4
1
1G
19
2G
SN74LVC244APW
SN74LVC244APW
R-TSOP20N-0.650-6.40-HX
R-TSOP20N-0.650-6.40-HX
DV33
DV33 DV33
20
VCC
PODINDATA0
18
1Y1
PODINDATA1
16
1Y2
PODINDATA2
14
1Y3
PODINDATA3
12
1Y4
PODINDATA4
9
2Y1
PODINDATA5
7
2Y2
PODINDATA6
5
2Y3
PODINDATA7
3
2Y4
10
GND
CB214
CB214
CB216
CB216
0.1uF
0.1uF
0.1uF
0.1uF
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
R-CAPC1608N-HX
PDENPOD#
GPIO_80
TS0INSYNC
TS0INVALID
TS0INCLK
R231 NS/0
R231 NS/0
R-RESC1608N-HX
R-RESC1608N-HX
R232 0
R232 0
R-RESC1608N-HX
R-RESC1608N-HX
2
U33
U33
2
1A1
4
1A2
6
1A3
8
1A4
11
2A1
13
2A2
15
2A3
17
2A4
1
1G
19
2G
SN74LVC244APW
SN74LVC244APW
R-TSOP20N-0.650-6.40-HX
R-TSOP20N-0.650-6.40-HX
20
VCC
PODINSYNC
18
1Y1
PODINVALID
16
1Y2
PODINCLK
14
1Y3
12
1Y4
9
2Y1
7
2Y2
5
2Y3
3
2Y4
10
GND
MediaTek Confidential
MediaTek Confidential
MediaTek Confidential
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
No.1-2, Innovation Rd 1, SBIP, Hsin-Chu City 300
TEL:(03)567-0766 FAX:(03)578-7610
TEL:(03)567-0766 FAX:(03)578-7610
MediaTek Inc.
MediaTek Inc.
MediaTek Inc.
Title
Title
Title
POD CARD
POD CARD
POD CARD
Document Number
Document Number
Document Number
Size
Size
Size
MT5331RA-V1.8
MT5331RA-V1.8
MT5331RA-V1.8
Custom
Custom
Custom
Date: Sheet
Date: Sheet
Date: Sheet
TEL:(03)567-0766 FAX:(03)578-7610
Drawn
Drawn
Drawn
1
Rev
Rev
Rev
1
1
1
14 14Wednesday, September 05, 2007
14 14Wednesday, September 05, 2007
14 14Wednesday, September 05, 2007
of
of
of
Loading...
