Hisense 75U80G Quick Guide

QUICK SETUP GUIDE

Before using the TV, please read this guide thoroughly

and retain it for future reference. For more detailed

instructions, please see the User Manual or the E-manual.

ES-G

English

Declaration

A

Important Safety Precautions

This symbol alerts user about the
presence of a dangerous voltage not
isolated inside the product which can
be sufficiently powerful to constitute a
risk of electrocution.

This symbol alerts user about the
presence of important operating
instructions and maintenance in the
document enclosed in the package.

In no case the user is allowed to operate

ATTENTION

RISK OF SHOCK

ELECTRIC

Do not open the back cover.

inside the TV set. Only a qualified

technician is entitled to operate.

AC voltage: This symbol indicates that the rated voltage marked with the
symbol is AC voltage.

Class I product: This symbol indicates that it requires a safety connection of
protective earthing (ground).

Disposal of Used Electrical & Electronic Equipment

Packaging and electrical goods should be recycled appropriately, and
not treated as household waste. Please dispose of this equipment at
your applicable collection point for the recycling of electrical & electronic
equipment waste. By ensuring the correct disposal of this product,
you will help prevent potentially hazardous to the environment and to
human health, which could otherwise be caused by unsuitable waste
handling of this product. The recycling of materials will help conserve
natural resources. Please do not therefore dispose of your old electrical
and electronic equipment with your household waste. For more detailed
information about recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you
purchased the product.

B

Important Safety Precautions

Warning

Never place a television set in an unstable location. A television set may fall, causing
serious personal injury or death. Many injuries, particularly to children, can be avoided
by taking simple precautions such as:

Using stands recommended by the manufacturer of the television set.

Only using furniture that can safely support the television set.

Ensuring the television set is not overhanging the edge of the supporting furniture.

Not placing the television set on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the television set to a suitable
support.

Not placing the television set on cloth or other materials that may be located
between the television set and supporting furniture.

Educating children about the dangers of climbing on furniture to reach the television
set or its controls.

If your existing television set is being retained and relocated, the same considerations
as above should be applied.

C

Important Safety Precautions

Safeguards

Please read the following safeguards for your TV and retain for future reference.
Always follow all warnings and instructions marked on the television.

1. A note about safety and operating instructions
Read and follow all safety and operating instructions, and retain them safely for future
reference.

2. Heed Warnings
Adhere to all warnings on the appliance and in the operating instructions.

3. Cleaning
Unplug the TV from the wall outlet before cleaning. Do not use liquid, abrasive, or
aerosol cleaners. Cleaners can permanently damage the cabinet and screen. Use a
lightly dampened cloth for cleaning.

4. Wall Mount Bracket
Wall mount bracket is only available for some models. If wall mount bracket is not
supplied with this product, you can buy it at the local market.
Please refer to the Installing the Wall Mount Bracket page of Quick Setup Guide for
dimensions.

5. Water and Moisture
Avoid dripping or splashing of liquids onto the product. Objects filled with liquids, such
as vases, should not be placed on the product.

6. Setting
Do not place this TV on an unstable cart, stand or table. Placing the TV on an unstable
base can cause the TV to fall, resulting in serious personal injuries as well as damage
to the TV. Use only a cart, stand, bracket or table recommended by the manufacturer
or salesperson.

7. Ventilation
Slots and openings in the cabinet are provided for ventilation, to ensure reliable
operation of the TV and to protect it from overheating. Do not cover the ventilation
openings in the cabinet and never place the set in a confined space such as built-in
cabinet unless proper ventilation is provided. Leave a minimum 10cm gap all around
the unit, the rear of the TV should be 6cm away from the wall.

8. Power Source
This TV should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supplied to your home, consult
your appliance dealer or local power company.

D

Important Safety Precautions

9. Power-Cord Protection
Power- supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at
plug, wall outlets, and the point where they exit from the TV. MAIN plug is used as the
disconnect device, the disconnect device shall remain readily operable.

10. Lightning
For added protection for this TV during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the TV due to lightning or power­line surge.

11. Power Lines
An outside antenna system should not be located in the vicinity of overhead power
lines or other electric light or power circuits, or where it can fall into such power lines or
circuits. Where installing an outside antenna system, extreme care should be taken to
keep from touching such power lines or circuits as contact with them might be fatal.

12. Overloading
Do not overload wall outlets and extension cords as this can result in a risk of fire or
electric shock.

13. Object and Liquid Entry
Never push objects of any kind into this TV through openings as they may touch
dangerous voltage points or short-out parts that could result in fire or electric shock.
Never spill liquid of any kind on or into the TV.

14. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the TV, be sure the antenna or
cable system is grounded so as to provide some protection against voltage surges and
built-up static charges.

15. Servicing
Do not attempt to service this TV yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all servicing to qualified service
personnel.

16. Damage Requiring Service
Unplug the TV from the wall outlet and refer servicing to qualified service personnel
under the following conditions:
(a) When the power - supply cord or plug is damaged.
(b) If liquid has been spilled, or objects have fallen into the TV.
(c) If the TV has been exposed to rain or water.

E

Important Safety Precautions

(d) If the TV does not operate normally by following the operating instructions. Adjust

only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive

work by a qualified technician to restore the TV to its normal operation.
(e) If the TV has been dropped or the cabinet has been damaged.
(f) When the TV exhibits a distinct change in performance - this indicates a need for

service.

17. Replacement Parts
When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as
the original part. Unauthorized substitutions may result in fire, electric shock or other
hazards.

18. Safety Check
Upon completion of any service or repair to the TV, ask the service technician to
perform safety checks to determine that the TV is in safe operating condition.

19. Heat
The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers) that produce heat.

20. Fire
The product should be situated away from naked flame sources such as lighted candle.

21. Off-gassing
The TV smells of plastic is normal and will dissipate over time.

Do not mix and use new batteries with old batteries, or batteries with
different types. Do not expose batteries to heat such as direct sunlight or
fire. Make sure the batteries' positive and negative ends are facing the
correct direction.

The device should not be exposed to dripping and spraying and it cannot
be placed under objects filled with liquids.

To fully disconnect the TV, remove power plug from wall socket. Be sure
to have the wall socket and power plug readily accessible.

Apparatus with CLASS I construction shall be connected to a MAINS
socket outlet with a protective earthing connection.

F

Contents

Figures and illustrations in this manual are provided for reference only and may
differ from actual product appearance.

Parts of the software function changes with the system upgrade.

Contents

Accessories List............................................................................................................. 1

Installing the Stand ........................................................................................................ 2

Installing the Wall Mount Bracket .................................................................................. 3

TV Front......................................................................................................................... 5

TV Rear ......................................................................................................................... 6

Making Connections ...................................................................................................... 7

Remote Control ............................................................................................................11

Turning the TV on for the First Time ............................................................................ 15

Specifications .............................................................................................................. 16

Other Information......................................................................................................... 17

Accessories List

The following accessories are included with TV:

Installing Instructions

Quick Setup Guide × 1 Installing Instructions × 1 Remote Control × 1

Base Stand × 2 RCA jack to AV Cable× 1 Power cord × 1

Cover × 1 AAA Battery × 2 Screw × 4

The accessories may be different from the list above due to different models, countries/regions,
please refer to the actual accessory bag.

1

Installing the Stand or Wall Mount Bracket

CAUTION

Be sure to disconnect the AC power cord before removing a base stand or installing
wall mount brackets.

The display on your TV is fragile. Make sure the TV screen is not scratched or
damaged by hard objects or from pressure.

After the installation is complete, make sure the TV is steady on a table or firmly
attached to a wall mount, before removing all protective film, if any.

Installing the Stand

Follow the illustrations and textual instructions below to complete the installation steps:

1. Carefully place your TV back down on a flat surface to prevent damage to the TV.

2. Take out the 2 stands from the accessory bag and then insert the stands into the
bottom slots of the TV.

Tip:

Make sure to insert the stands according to the 'L' and 'R' directional marks

that are shown on the surface.

3. Secure the Base Stand to the TV with the 4 screws in the accessory bag tightly.

Base Stand

2

Screws:
M5×16

Screws

:

M5×16

Base Stand

Installing the Stand or Wall Mount Bracket

Installing the Wall Mount Bracket

Before you begin the installation of the wall mount bracket , be sure to do the following
things:

1. Place the TV in the bottom tray.

2. One person holds the TV to prevent from tipping over. Other person removes the
screws on the back of the TV, as shown in the picture below.

Screw

Screw

Screw

Screw

Bottom tray

CAUTION

When mounting the TV on a wall, follow instructions provided with the wall mount bracket. If
it is not correctly mounted, the TV may fall and cause property damage or personal injury.

Place spacers between the TV and bracket.

Make sure the tilt angle between the TV screen and the
vertical surface is no more than 15 degrees.

Standard dimensions are shown below.

≤15°

TV screen

Vertical
surface

Wall-Mount hole pattern (mm) 600 × 400

Wall-Mount screw size M8

3

Installing the Stand or Wall Mount Bracket

9.5~11.5mm

Rear cover of the TV

NOTE

The diameter and length of the screws differ depending on the wall mount bracket
model.

Wall mount bracket is optional, your device may not have wall mount bracket, please
refer to the actual accessories.

Wall Mount Bracket

Wall Mount Screw
Wall Mount Spacer

4

TV Front

TV back view

Joystick button

TV Front

MIC

Bluetooth Pairing

The far-eld Google Assistant control button

Power indicator/Remote sensor

The far-eld indicator lights

Item Description

Remote sensor

Power indicator

The far­field Google
Assistant
control button

Receive remote signals from the remote control.
Do not put anything near the sensor, as its function may be affected.

The light is off when the TV is turned on. The light is white in
standby mode.

Switch the button to to turn on the Google Assistant.
Say “OK Google” to start a conversation.

Before using this function, connect the TV to the Internet and
sign in your Google account.

Select among the different input signal sources or put the TV in
standby mode, or you can turn on the TV when the TV in standby
mode.

Toggle the OK button left and right to adjust the volume.

Toggle the OK button up and down to select the channel.

NOTE

Powering on the TV requires several seconds to load program. Do not rapidly turn
the TV off as it may cause the TV to work abnormally.

The far-field Google Assistant and some of its features are only available in
selected countries, regions and languages.

5

TV Rear

AC Input

TV Rear

NOTE

Check the jacks for position and type before making any
connections. Loose connections can result in image or color
problems. Make sure that all connections are tight and secure.

The TV may not be compatible with all external devices. To check
compatibility, please refer to the user manual of external device.

Do not connect external equipment while TV's power cord is
plugged in. It may cause electric shock.

Service jack is not available for you to connect an external device.
It can only be used by our factory for testing purposes.

6

Making Connections

ANT

Connect an outdoor VHF/UHF antenna or cable.

TV JACK

ANT

(not included)

or

Outdoor

Antenna

Antenna Cable (75Ω)

Cable

ANT OUT

VHF/UHF Antenna

HDMI / AV

Connect a HDMI / AV cable from an external AV equipment. No sound connection
is needed for HDMI to HDMI connection. If the signal resolution does not match the
specification table, you need to change the setting of device according to the table.
Please consult your device user manual for instruction.

·

To select the HDMI / AV
Press the

INPUT

button, when the list of input Source appears, press the

/ / < / >

buttons to select the source HDMI / AV, then press the OK button to connect.

NOTE

In order to ensure performance and compatibility, new Ultra-High Speed HDMI Cables
are required to enable 8K@60Hz or 4K@120Hz on HDMI 3/4.

Video Effect:

TV JACK

BETTER (HDMI)

HDMI

HDMI cable (not included)

GOOD (AV)Video Effect:

Red(R)

AV IN

TV JACK

White(L)

Yellow(Video)

(Cables are not included)

7

Video Camera/

Set-top Box/

Satellite Receiver

Making Connections

HEADPHONE

TV JACK

Connect Headphone for audio out of the TV.

ATTENTION

Excessive sound pressure from

HEADPHONE

Headphone (not included)

earphones and headphones can
cause hearing loss.

NOTE

Please make sure that the headphone you plug in is without microphone function, or it
may not be supported.

DIGITAL AUDIO OUT

Connect to an external digital audio system.

Before connecting a digital audio system to the DIGITAL AUDIO OUT jack, you
should decrease the volume of both the TV and the system to avoid that the
volume suddenly becomes bigger.

TV JACK

DIGITAL

AUDIO OUT

eARC/ARC

DIGITAL AUDIO cable (not included)

Connect an HDMI cable from an external digital audio system.

Audio Amplier/Speaker

eARC/ARC enables the TV to directly output the digital sound through an HDMI
cable. Please note that it works only when the TV is connected to the audio receiv­er that supports the eARC/ARC (Audio Return Channel) function.
When this port is used as the eARC/ARC function, it can't be used as signal input
at the same time.

TV JACK

HDMI

eARC/ARC

Audio Amplier/Speaker

HDMI

HDMI cable (not included)

8

Making Connections

USB

Connect the USB1.1 and USB2.0 devices such as hard drives, USB sticks and
digital cameras for browsing photos, listening music and watching movies.

TV JACK

USB 1 USB 2

DC 5V 0.5A(MAX)

NOTE

DC 5V 1A(MAX)

When connecting a hard disk or a USB hub, always connect the mains adapter of
the connected device to the power supply. If a USB 1.1 or USB2.0 device requires
more than 500mA or 5V, the USB device may not be supported. Max supported

current for USB 3.0 device is 1A (only for some models). Exceeding the max
supported current may result in damage or data loss.

Certain digital cameras may not be compatible with the TV.

LAN (Wired setup)

Connect your TV to your network by connecting the LAN port on the back of your
TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the
illustration below.

·

We recommend you to use a modem or router that supports Dynamic Host
Configuration Protocol (DHCP). Modems and routers that support DHCP
automatically provide the IP address, subnet mask, gateway, and DNS, so you
don’t have to enter them manually. Most home networks already have DHCP.

TV JACK

LAN

IP Sharer (Router)

(with DHCP server)

External Modem

(ADSL / VDSL / Cable TV)

Modem CableLAN CableLAN Cable

9

Making Connections

Wireless setup

Connect your TV to your wireless network, you need a wireless router or modem.
See the illustration below.

·

The TV’s built-in Wireless LAN Adapter supports the IEEE 802.11 a/b/g/n/ac
communication protocols.

Wireless router with DHCP

Wireless LAN Adapter

built-in TV set

LAN Cable

NOTE

You must use the built-in Wireless LAN Adapter to use a wireless network because
the set doesn’t support external USB network adapter.

If the wireless router supports DHCP, your TV can connect more easily to the
wireless network.

If you apply a security system which is not listed below, it will not work with the TV.

Security system : WPA, WEP, WPA2.

In order to guarantee smooth network, the distance between router and TV should be
less than 10 meters.

10

Remote Control

Microphone

/ Power indicator

Power Standby button:

Power on / Standby

Select a channel or input

numbers

Display the Electronic

Program Guide (DTV mode)

Quick setup

D-pad (up / down / left /

right navigation buttons)

Under the Menu or App,

return to the previous

place

Adjust the volume

Turn on/off the teletext

function

Google Assistant of TV

Display the present
program information

Select input sources

Display the channel
list on the screen

Special function buttons

Fast access to all
applications

OK / Display the on-screen
keyboard

Playpad keys
Display the Home screen

Switch channel

Mute and restore sound

Display subtitles in the
Live TV

Quick access buttons to
apps

NOTE

The included remote control will vary depending on model, country. Check information
according to the actual remote control in the accessory bag.

11

Remote Control

Pairing the Remote Control (only for bluetooth remote control)

1. Pair the remote to the TV after you power it on. Keep the remote control within 3
metres from the TV. Press and hold the

2. If the remote paired successfully then a confirmation will display on the screen. If it
did not pair successfully then an 'unsuccessful' message will display. Repeat step 1.

NOTE

If an unknown error occurred with the remote then it could have been caused by
interference. Try to remove what's causing the interference and pair it again.

If an unknown error occurred in the remote control while the battery power is normal, you
can take out the batteries, press any key for 1~2 seconds, and insert them back. then the
remote control will work normally.

The remote cannot be paired to the TV while the TV is in standby mode.

Using the Google Assistant

You can ask for information, search for your favourite movies, control your TV and
more, just by asking Google Assistant.
Before using this function, pair the remote control to the TV and connect the TV to the
Internet.

button at least 3 seconds to start pairing.

Set up your Google Assistant

1. On your remote control, press the Assistant

2. On your TV screen, an introduction will appear. Follow the steps to finish setup.

Talk to your Google Assistant

1. Press
up, and the microphone is active.

2. Say a command immediately, such as saying "What can you do?". Search results
will be displayed at the bottom of the screen.

NOTE

This function is available for remote controls that have a button.

Some functions may not be supported if you are not signed in to your Google account.

The Google Assistant function only supports some languages, and the supported
functions may differ depending on countries/regions.

You can download and install the Google Assistant app on your mobile device to use
your voice.

button on your remote control, the blue light on the remote control lights

12

button.

Remote Control

Installing Batteries in the Remote Control

1. Press the switch and the battery case will pop up
automatically.

2. Insert two AAA size batteries. Make sure to match
the (+) and ( - ) ends of the batteries with the (+)
and ( - ) ends indicated in the battery compartment.

3. Push the battery case back to the remote control.

NOTE

Product image is only for reference, actual product may vary in appearance.

Dispose of your batteries in a designated disposal area. Do not throw the batteries into fire.

Do not mix battery types or combine used batteries with new ones.

Remove depleted batteries immediately to prevent battery acid from leaking into
the battery compartment.

If you do not intend to use the remote control for a long time, remove the batteries.

Batteries should not be exposed to excessive heat, such as sunshine, heat
registers, or fire.

Battery chemicals can cause a rash. If the batteries leak, clean the battery
compartment with a cloth. If chemicals touch your skin, wash immediately.

13

Remote Control

Remote Control Operation Range

1. The remote control can work at a distance of up
to 8 meters in front of the TV set.

2. The remote control angle: taking the remote
sensor as an apex, 6 meters away, its controlled

horizontal angle is within ±30°, while the vertical
angle is within ±15°.

3. The operating distance may vary depending on
the brightness of the room.

Disposal of this unit

Product should not be damaged, dismantled or thrown in municipal waste.
It should be packed and handed over to authorised re-cycler.

14

Turning the TV on for the First Time

Turning the TV on for the First Time

Connect the mains cable to the mains socket after you have completed all the
connections.

The first time you turn the TV on, it will go straight to the Installation Guide.

The guide setting is completed according to the boot navigation prompt. The
navigation information is specific to the actual condition.

The Home screen will be your starting point for navigating the TV.

15

Specifications

Features, appearance and specifications are subject to change without notice.
If you encountered difficulty when setting up your TV, we suggest you refer to the

troubleshooting tips in the User Manual or the E-manual.

Item

Without Stand

Dimension
(mm)

Weight
(kg)

Active Screen Size
(Diagonal)
(cm)

Screen resolution

Audio power

Power consumption

Power supply

Standby Power

Receiving
systems

Environmental conditions

HDMI Input

(W × H × D)

With Stand
(W × H × D)

Without Stand

With Stand

Analog

Digital

75"

1676 × 990 × 76

1676 × 1088 × 424

37.0

38.2

189

7680 × 4320

15W + 15W

Please refer to the rating label.

100 - 240V 50/60Hz

0.5W

PAL-D/K, B/G, I SECAM-D/K, B/G

DVB-T/T2, DVB-C

Temperature: 5°C - 45°C

Humidity: 20% - 80% RH
Atmospheric pressure: 86 kPa - 106 kPa

60Hz (640×480, 800×600, 1024×768)
60Hz (480 I, 480 P, 720 P, 1080 I, 1080 P)
50Hz (576 I, 576 P, 720 P, 1080 I, 1080 P)
24Hz 25Hz 30Hz 50Hz 60Hz (3840×2160)
1080P@100HZ, 1080P@120HZ
24Hz 25Hz 30Hz 50Hz 60Hz (7680×4320 HDMI3,4)
3840×2160@100Hz, 3840×2160@120Hz (HDMI3,4)

16

Other Information

What is Freeview Plus?

Freeview Plus is a new television service delivered via broadband providing a state of
the art Electronic Program Guide (EPG) and seamless access to catch-up TV across
the free-to-air networks with the simple press of a button.

How does it work?

First ensure the TV is connected to internet and an antenna system. Then when you’re

watching TV, you’ll briey see a prompt at the top left of the screen. Press the ‘Green’

button on your remote to launch Freeview Plus. More information about Freeview Plus
can be found on http://www.freeview.com.au/

The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. in the United
States and other countries.

Dolby, Dolby Vision, Dolby Atmos, and the double-D symbol
are registered trademarks of Dolby Laboratories Licensing
Corporation. Manufactured under license from Dolby

Laboratories. Condential unpublished works. Copyright ©

2012-2020 Dolby Laboratories. All rights reserved.

For DTS patents, see http://patents.dts.com. Manufactured
under license from DTS Licensing Limited. DTS, the Symbol,
DTS and the Symbol together, DTS-HD, and the DTS-HD logo
are registered trademarks and/or trademarks of DTS, Inc. in

the United States and/or other countries. © DTS, Inc. All Rights

Reserved.

17
