4K HDR Smart TV
Quick Setup Guide
Help Hisense improve the environment by reducing pa-
per waste. For detailed instructions and feature descrip-
tions, access the full User Manual online. Before using
the TV, please read this guide carefully and keep it for
future reference.
ES-G194998-1
English
Copyright statement
© 2020 Hisense Company Ltd. All Rights Reserved.
All material in this Quick Setup Guide is the property of Hisense Company Ltd.
and its subsidiaries, and is protected under the laws of the US, Canada, Mexico
and international copyright and/or other intellectual property laws. Reproduction or
transmission of the materials, in whole or in part, in any manner, electronic, print, or
otherwise, without the prior written consent of the Hisense Company Ltd. is a violation
of the rights of Hisense Company Ltd. under the aforementioned laws.
No part of this publication may be stored, reproduced, transmitted or distributed, in
whole or in part, in any manner, electronic or otherwise, whether or not for a charge or
for other or no consideration, without the prior written permission of Hisense Company
Ltd. Requests for permission to store, reproduce, transmit or distribute materials may
be made to one of the following addresses:
USA:
Hisense USA Corporation
7310 McGinnis Ferry Road
Suwanee, GA 30024
CANADA:
Hisense Canada Co., Ltd
2283 Argentia Road, Unit 16
Mississauga, ON, Canada
L5N 5Z2
MEXICO:
Hisense Mexico S. de R.L. de C.V.
Blvd. Miguel de Cervantes Saavedra No 301
Torre Norte Piso 2, Col. Ampliación Granada
Miguel Hidalgo, Ciudad de México, C.P. 11520
Hisense, and any and all other Hisense product names, logos, slogans or marks
are registered trademarks of Hisense Company Ltd. and its subsidiaries. All other
trademarks are the property of their respective holders.
Disclaimer
Disclaimer: Subscriptions or other payments may be required to access content
through some applications. Some or all of the included or downloaded application
services in this Hisense device may not function depending on the Internet
connection, local limitations of included applications or other reasons outside of
Hisense’s control. HISENSE EXPRESSLY DISCLAIMS RESPONSIBILITY FOR ANY
APPLICATION SERVICE FROM FUNCTIONING AT ANY TIME, FOR CONTENT
IN ANY APPLICATION SERVICE, FOR DISRUPTIONS OF SERVICE, LOCAL OR
REGIONAL LIMITATIONS, WARRANTIES OF TITLE, NO INFRINGEMENT, AND FOR
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. By purchasing this device, you accept such Disclaimer without any claim
on Hisense at any time.
This Quick Setup Guide supports the following models:
50Q7G 55Q7G 65Q7G 75Q7G
50Q8G 55Q8G 65Q8G 75Q8G
50H8G 55H8G 65H8G 75H8G
Table of Contents
What's in the box ............................................................................................................3
Getting started ................................................................................................................4
Step 1. Attach stand or mount ....................................................................................4
Step 2. Connect devices to your TV ..........................................................................8
Step 3. Get your remote ready .................................................................................11
Step 4. Power on the TV ..........................................................................................14
Step 5. Complete the rst-time setup .......................................................................14
Step 6. Establish a network connection ...................................................................14
Step 7. Enjoy your TV! ............................................................................................16
Troubleshooting ......................................................................................................17
Product Specications .............................................................................................18
Certication and Compliance ...................................................................................20
1
Congratulations on the purchase of your Hisense TV! If you would like to know 'all
things Hisense', contact us using the support info:
The model and serial number of the TV is located on the back and/or on one side of
the TV. We recommend that you record this if you ever need.
Country
U.S.A
CANADA
MEXICO
Customer Care
Center
• Phone: 1-888-935-
8880
• Hours of Operation:
Monday - Friday: 9 AM
to 9 PM EST
Saturday - Sunday: 9
AM to 6 PM EST
• Service Email:
Service@hisenseusa.com
• Phone: 1-855-344-
7367
• Hours of Operation:
Monday - Friday: 8 AM
to 8 PM EST
• Service Email:
canadasupport@
hisense.com
• Phone: 01-800-008
8880
• Hours of Operation:
Monday - Friday: 9:0021:00 hrs
Saturday: 9:00-15:00
hrs
• Service Email:
servicio@hisense.
com.mx
Hisense Support
Page
http://www.hisense-usa.
com/support/
http://www.hisensecanada.com/support/
https://hisense.com.mx/
support/
*Scan to download user manual
Register your TV
http://www.hisense-usa.
com/support/register
http://www.hisensecanada.com/support/
productReg.asp
https://hisense.com.mx/
product-registration/
Disclaimer:
This Quick Setup Guide is intended as a general guideline to
help you set up your TV. Images throughout this document are for illustrative
purposes only and may differ from the actual product.
2
What's in the box
Your Hisense TV comes with the following items:
● TV ● Quick Setup Guide (this document)
● power cord ● 1 set of AAA batteries
● remote control ● Important Safety Information and Warranty Card
● 2 base stands ● 4 screws (M5×12)(50"/55"/65")
● 4 screws (M5×16)(75") ● 4 hanging wheel (75”)
IMPORTANT:
To prevent accidentally discarding items that came with your TV, be sure to
of the foam
You will also need the following items (which are not included) to set up your TV:
● Wireless router (not included) for Internet connectivity
● Phillips screwdriver (not included) to secure the TV stand
● HDMI and other types of cables (not included) to connect external devices to the TV
● Wall mount bracket (not included) if you prefer to mount the TV on the wall
in the carton box.
Please check foam for accessories before discarding.
·
Veuillez vérifier la mousse pour qu'il n'y ait pas d'accessoires avant de la jeter.
·
Antes de desechar la espuma, asegúrese de retirar todos los accesorios.
·
check ALL
3
Getting started
Step 1. Attach stand or mount
Before you start using your TV, attach your TV stand or mount it on the wall.
CAUTION:
• Disconnect the A/C power cord before installing a stand or a wall mount bracket.
• The LED display on your TV is fragile. Make sure the TV screen is not scratched or
damaged by hard objects or from pressure.
• After the installation is complete, make sure the TV is steady on a table or firmly
attached to a wall mount, before removing all protective film, if any.
Attach the TV stand
To attach the TV stand legs to your TV:
1. Carefully place your TV face down on a clean, soft, flat surface.
2. Insert the TV Base Stand into the bottom slots on your TV.
3. Use the screws provided to secure each leg tightly.
50"
Base Stand
Base Stand
Screws: M5×12
Screws: M5×12
4
Note:
If your table is long enough to place the TV on top of, then insert the base
stands into the screw holes ‘A’ that are shown in the illustration. If your table is NOT
long enough, then insert the base stand into the screw holes ‘B’ that are shown in the
illustration. Note that these two installation methods types cannot be mixed.
55"
Base Stand
65"
A
Base Stand
Screws: M5×12
A
A
Base Stand
Screws: M5×12
B
Base Stand
A
B
Screws: M5×12
Base Stand
Base Stand
Screws: M5×12
Base Stand
Base Stand
B
B
Screws: M5×12
5
Screws: M5×12
75"
A
Base Stand
Screws: M5×16
Base Stand
A
Base Stand
B
B
Screws: M5×16
Screws: M5×16
Screws:
M5×16
Base Stand
Attach the Wall Mount Bracket (not included) (only for 75")
Before you begin the third-party manufacturer instructions, be sure to do the following
things:
1. Place the TV face down on a clean, safe and cushioned surface.
2. Remove the TV stand if you already attached it.
3. Remove the two screws (as shown in the following figure) on the handle first, and
remove the handles, then remove the two screws at the bottom of the back.
Figure 1. Screws to remove
4. Fix the four wheels in the accessory bag at the position shown in the following
gure.
Figure 2. Fix the wheels
5. Place the spacers (not included) in the corresponding bracket holes. See the
6
Figure 3.
Attach the wall mount bracket (not included)
(not included)
(not included)
Rear cover of the
t
9.5 - 11.5 mm
Before you begin the third-party
manufacturer instructions, be sure to do
the following things:
Screw
1. Place the TV face down on a clean,
safe and cushioned surface.
2. Remove the TV stand if you have
already attached it.
3. Place spacers (not included) in the
corresponding bracket holes.
Spacer
(not included)
Bracket
Figure 3. Location to insert the spacers
CAUTION:
• When you attach the mount, be sure to use spacers (provided by the third-party
manufacturer) between the TV and the bracket.
• To prevent internal damage to the TV and to ensure it is mounted securely, be sure
to use fixing screws (not included) that are 9.5 - 11.5 mm in length when measured
from the attaching surface of the rear cover.
Wall mount bracke
TV Spacer
Wall mount hole pattern (mm)
Wall mount screw size (mm) M6
Screw
300 × 200 (50"/55"/65")
600 × 300 (75")
Follow instructions provided with the wall mount bracket.
● To complete the installation, please contact the wall mount manufacturer or the
retailer from which you purchased the TV.
● The selected screws are 9.5 - 11.5 mm in length when measured from the attaching
surface of the rear cover.
NOTE:
The diameter and length of the screws differ depending on the wall mount
bracket model.
7
Step 2. Connect devices to your TV
Check to ensure that you have connected right cables for right ports securely. Loose
connections can affect the quality of the picture image and color.
Side View
50"/55"/65"
Back View
75"
Power Input
75"
LAN
Bottom View
DIGITAL
AUDIO OUT
HDMI 4(
AV IN
4K@60Hz
RLVIDEO
)
4K@60Hz
HDMI 1(
)
4K@60Hz
HDMI 2(
)
4K@60Hz
HDMI 3(
SERVICE
USB 1
USB 2
ANT / CABLE
HEADPHONE
ARC
0.5A(MAX)
DC 5V
DC 5V 0.5A(MAX)
ANT / CABLE
)
4K@60Hz
ARC
HDMI 1(
)
4K@60Hz
HDMI 2(
)
4K@60Hz
50"/55"/65"
R
4K@60Hz
AV IN
L
)
VIDEO
SERVICEHEADPHONE
LAN
)
HDMI 4(
HDMI 3(
USB 1
USB 2
DIGITAL
AUDIO OUT
0.5A(MAX)
DC 5V
DC 5V 0.5A(MAX)
8
TV label Port Cable External Equipment Brief De-
scription
ANT/CABLE
HDMI
VIDEO
AV IN
L
R
DIGITAL AUDIO
OUT
Yellow
White
Red
Antenna
Video
Camera
Audio Amplier
VHF/UHF Antenna
ANT OUT
VCR
DVD Player/Recorder
Set-top Box
Satellite Receiver
Speaker
Satellite
antenna
cable
Connect an
outdoor VHF/
UHF antenna.
Connect a
High Denition
Multimedia
Interface
(HDMI)
cable from
an external
device.
Connect a
composite
video cable
and left-right
audio cables
from an
external AV
device.
Connect an
optical cable
from an
external digital
audio system.
HEADPHONE
Connect
headphones
to hear audio
from the TV.
Headphones
with
microphones
are not
supported.
9
TV label Port Cable External
Equipment
Connect a USB device for browsing photos,
music and movies.
USB
LAN
Hard disks with a total current consumption
or impulse current consumption greater than
500mA are not supported.
Brief
Description
Connect an
Ethernet
cable to
access a
network or
the Internet.
The TV
also has
a wireless
connectivity
feature.
SERVICE
This port is not available for you to connect an external device, but
can only be used by factory for testing purposes.
10
Step 3. Get your remote ready
The following table shows the buttons on your remote control and describes what they
are for.
BUTTON
(Red/Green/Yellow/Blue)
INPUT Change TV input source
Number Enter Channels/input numbers
CC Turn Closed Caption On/Off and turn Closed Caption on when mute
TV Return to the previous source
˄ / ˅ / ˂ / ˃ D-pad (up/down/left/right navigation buttons)
OK Conrmation button
DESCRIPTION
Power on/off
Special function buttons
Google Assistant of TV
The button for the Menu
Return to the previous place in the menu or app
Display the Home screen
VOL Volume (up/down)
CH Channel (up/down)
Mute and restore sound
MTS Set the audio language (MTS)
/ /
NRT Choose to leave the Video description feature On or Off
APPS Quick access to all applications
App Quick access buttons to apps
/
Media content control function buttons
Microphone
11
BUTTON DESCRIPTION
Select a digital sub-channel
NOTE:
vary.
Buttons listed here are for reference only. Actual remote control models may
Insert the batteries
1. Take off the back cover to open the battery compartment of the remote control.
2. Insert two AAA size batteries. Make sure to match the (+) and (-) ends of the
batteries with the (+) and (-) ends indicated in the battery compartment.
3. Restore the battery compartment cover.
Important Information about the remote and batteries
• Discardbatteriesinadesignateddisposalarea.Donotthrowthemintoafire.
• Removeoldbatteriesimmediatelytopreventthemfromleakingintothebattery
compartment.
• Ifyoudonotintendtousetheremotecontrolforalongtime,thenremovethe
batteries.
• Batterychemicalscancausearash.Ifthebatteriesleak,cleanthebattery
compartment with a cloth. If chemicals touch your skin then wash it
immediately.
• Donotmixoldandnewbatteries.
• Donotmixalkaline,standard(carbon-zinc)orrechargeable(NiCd,NiMH,etc.)
batteries.
• Donotcontinueusingtheremoteifitgetswarmorhot.
• CallourSupportCenterimmediatelyonthesupportwebsite.
Remote Control Range Information
● The remote control can work at a distance of up to 26 feet in front of the TV set.
● It can work at a 30 degree horizontal or vertical angle.
Program Your Universal Cable or Satellite Remote Control to Operate
Your New Television (only for USA)
If you would like to program your other household remote controls to your new
television, please refer to the User Manual supplied by your Cable or Satellite provider.
It should include instructions on how to program their remote to your television.
A list of codes for the most common Cable and Satellite providers are listed below. Use
the code that is associated with your Cable or Satellite provider (if applicable).
12
DIRECTV
11204, 11326, 11517, 11564, 11641, 11963, 12002, 12183
Time Warner Cable
10463
Comcast
11517, 11641, 11780, 11785, 11892, 11963, 12002
Cox Communications
Dish Network
If the code associated with your Cable or Satellite provider is not listed, does not work
or you cannot locate the instructions to program your remote, call your local Cable or
Satellite provider’s
customer service center.
If your Cable or Satellite provider does not have a code available, please contact us at
one of the phone numbers on Page 2.
......0178, 10178, 10019, 10748, 11314, 11660, 11710, 11780, 12049, 10171,
......386, 0178, 10178, 400, 450, 461, 456, 0748, 1463, 0463,
......0178, 10178, 10463, 11463, 10748, 11314, 11660, 10171, 11204, 11326,
......0178, 10178, 1326, 1463
......505, 627, 538, 720, 659
Using Your Cable Set-top Box or Satellite Receiver Remote as a
‘Universal’ Remote
If you prefer to use your Cable Set-top Box or Satellite Receiver Remote as a ‘Universal’
Remote, then visit the Support page to view a list of the codes.
Pairing the remote control
1. Pair the remote to the TV after you power it on. Keep the remote control within 10
feet from the TV. Press and hold the [ ] button at least 3 seconds to start pairing.
2. If the remote pairs successfully, a conrmation will display on the screen. If it does
not pair successfully, an unsuccessful message will display. Repeat step 1.
NOTE:
• If an unknown error occurs with the remote, it could have been caused by
interference. Try to remove what's causing the interference and pair the remote
again.
• If an unknown error occurs with the remote control while the battery power is
normal, you can take out the batteries and press any key for 1~2 seconds, and
the remote control can work normally.
• The remote cannot be paired to the TV while the TV is in the standby mode.
13
Step 4. Power on the TV
TV JACK
Connect your power cord to the TV and plug it into a power outlet.
Your TV will display a launch screen showing the Hisense logo.
Power Cord
Wall Outlet
Step 5. Complete the first-time setup
The first time you turn on your TV, there is a guided setup to make it easy to connect
your TV to the Internet and complete the setup of your TV.
STEP 6. Establish a network connection
1. Press the
Settings
2. Select
Home
button on the remote control, and select the icon to select
to enter the Settings menu
Network & Internet
.
.
Establish a wired network connection
External Modem
(ADSL / VDSL / Cable TV)
Modem Cable LAN CableLAN Cable
IP Sharer (Router)
(with DHCP server)
LAN
14
Automatically obtain an IP address
Wireless router with DHCP
1. If you connect to the wired network, the TV will automatically obtain an IP address
and connect to the network.
NOTE:
2. If the connection fails, “
enter the
The default option of IP Settings Mode is DHCP.
IP settings
Not Connected
, and select
” will display for the Ethernet status. Retry or
Static
to input the information again.
Manually enter the IP address
1. Enter the
IP settings
to select
Static
.
2. Enter the IP address, Gateway, Network prefix length, DNS 1 and DNS 2 in the
menu.
Establish a wireless network connection
Wireless LAN Adapter
built-in TV set
LAN Cable
The TV can directly receive network signals via wireless router.
1.Turn on your Wi-Fi.
2. The list of networks will display automatically.
3. Select a wireless network from the list, input the password.
4. If the network connection does not appear in the list, select
list, or select
Add new network
to input a Wi-Fi name, select the type of security
See all
to display all the
mode, and enter password.
Close the network connection
Unplug the network cable or turn off your Wi-Fi. The network connection will close.
15
Step 7. Enjoy your TV!
Now that you’ve completed the first-time setup, your Home screen is your starting point
for using your TV. Your Hisense TV provides a variety of entertainment options, so
you’ll always find something new. Use your TV to watch live channels, access video on
demand to watch movies, and much more.
Press the Home button on your remote to get started.
Text-to-Speech(TTS) and Video Description functionalities on TV
Text-to-Speech (TTS) and Video Description can help you to navigate the menus
on the screen and hear an audio description of relevant programs. Text-to-Speech
can convert written text into voice text to help visually impaired people listen to the
information they are unable to read. In addition, the Video Description has an audio
narration added to certain programs that will describe the main visual elements which
visually impaired users may not be able to see.
Follow the steps below to enable the functions:
1. Press the button to access the Menu.
2. Next, select
3. Select
Video Description on or off by selecting the appropriate choice that is presented.
Settings
Accessibility > TalkBack
to enter the
Device Preferences
Video Description
or
menu.
to turn the Menu Audio or
NOTE: TalkBack
by selecting the Toggle button.
www.hisense-usa.com/text-to-speech-hisense-android-tvs
is enabled by selecting the checkbox.
16
Video Description
is enabled
Troubleshooting
If you are having trouble with your TV, first try turning it off and on again. If this does not fix the
problem, check the tips in the following table. If your problem is not listed in the following table,
then contact us at one of the phone numbers on Page 2.
Issues Possible solutions
• Check if the power cord is plugged into a powered AC
outlet.
No sound or picture
I have connected an external
source to my TV and I get no
picture and/or sound.
When I turn on my TV, there is a
delay for a few seconds before the
picture appears. Is this normal?
The picture is normal but there is
no sound
Sound but no picture or black and
white picture
The sound and/or picture is
distorted or appears wavy
The sound and picture is blurry or
cuts out
A horizontal or vertical stripe
appears on the picture and/or the
picture is shaking
The plastic cabinet makes a
"clicking" type of sound
The remote control does not work
• Press the Power button on the remote control to activate
the unit from 'Standby' mode.
• Check to see if the LED light is on or not. If it is, then the
TV is receiving power.
• Check for the correct output connection on the external
source and for the correct input connection on the TV.
• Make sure you have made the correct selection for the
input mode for the incoming signal.
• Yes, this is normal. The TV is initializing and searching
for previous setting information.
• Check the volume settings.
• Check if 'Mute' mode is set to On.
• If the picture is black and white, unplug the TV from the
AC outlet and replug it after 60 seconds.
• Check that the Color is set to 50 or higher.
• Try different TV channels.
• An electric appliance may be affecting the TV. Turn off
any appliances that are nearby and move it farther away
from the TV.
• Insert the power plug of the TV set into another power
outlet.
• If using an external antenna, check the direction, position
and connection of the antenna.
• Adjust the direction of your antenna or reset or ne tune
the channel.
• Check if there is an appliance or electric tool nearby that
is causing interference.
• The 'click' sound can occur when the temperature of the
television changes. This change causes the television
cabinet to expand or contract, which makes the sound.
This is normal and the TV is OK.
• Conrm that TV still has power and is operational.
• Change the batteries in the remote control.
• Check if the batteries are correctly installed.
17
Product Specifications
Model Name 50Q7G / 50Q8G / 50H8G 55Q7G / 55Q8G / 55H8G
Dimension
(W × H × D)
Weight Without Stand 28.2 lbs (12.8 kg) 32.4 lbs (14.7 kg)
TV Stand Width(W × D) 38.7 × 9.5 inches
Class 50" 55"
Active Screen Size (Diagonal) 49.5 inches 54.6 inches
Screen Resolution 3 840 × 2 160
Audio Power 10 W + 10 W
Power consumption 200 W 220 W
Power Supply 120 V ~ 60 Hz
Connectivity Built-in Wireless feature (2x2 dual band)
Ports 4 HDMI ports, 2 USB ports, 1 LAN port for Ethernet, 1 Digital
Receiving Channels VHF: 2 - 13, UHF: 14 - 69, CATV: 1 - 125
Tuner Type Frequency synthesized
Receiving System Analog: NTSC
Operating Temperature 41°F - 95°F (5°C - 35°C)
Operating Humidity 20% to 80% non-condensing
Storage Temperature 5°F to 113°F (-15°C to 45°C)
Storage Humidity 10% to 70%, non-condensing
Without Stand 43.8 × 25.4 × 3.1 inches
(1 112 × 645 × 79 mm)
With Stand 43.8 × 28.3 × 9.4 inches
(1 112 × 719 × 241 mm)
With Stand 28.7 lbs (13.0 kg) 33.1 lbs (15.0 kg)
(984 × 241 mm)
Audio Output, 1 RF Input, 1 Headphone Audio Output, 1 RCA
Composite Video Input , 1 left/right Audio Input for Composite
Digital Terrestrial Broadcast (8VSB): 2 - 69
Digital cable (64/256 QAM): 1 - 135
Digital: ATSC/QAM
48.3 × 28.0 × 3.1 inches
(1 227 × 711 × 78 mm)
48.3 × 30.7 × 9.5 inches
(1 227 × 781 × 241 mm)
44.1 × 9.5 inches
(1 120 × 241 mm)
Disclaimer:
All products, product specifications, and data are subject to change
without notice to improve reliability, function, design or otherwise.
18
Product Specifications
Model Name 65Q7G / 65Q8G / 65H8G 75Q7G / 75Q8G / 75H8G
Dimension
(W × H × D)
Weight Without Stand 43.0 lbs (19.5 kg) 63.5 lbs (28.8 kg)
TV Stand Width(W × D) 51.5 × 11.1 inches
Class 65" 75"
Active Screen Size (Diagonal) 64.5 inches 74.5 inches
Screen Resolution 3 840 × 2 160
Audio Power 10 W + 10 W 15 W + 15 W
Power consumption 260 W 350 W
Power Supply 120 V ~ 60 Hz
Connectivity Built-in Wireless feature (2x2 dual band)
Ports 4 HDMI ports, 2 USB ports, 1 LAN port for Ethernet, 1 Digital
Receiving Channels VHF: 2 - 13, UHF: 14 - 69, CATV: 1 - 125
Tuner Type Frequency synthesized
Receiving System Analog: NTSC
Operating Temperature 41°F - 95°F (5°C - 35°C)
Operating Humidity 20% to 80% non-condensing
Storage Temperature 5°F to 113°F (-15°C to 45°C)
Storage Humidity 10% to 70%, non-condensing
Without Stand 57.0 × 32.9 × 3.1 inches
(1 447 × 835 × 79 mm)
With Stand 57.0 × 35.8 ×11.1 inches
(1 447 × 909 × 283 mm)
With Stand 44.1 lbs (20.0 kg) 64.8 lbs (29.4 kg)
(1 309 × 283 mm)
Audio Output, 1 RF Input, 1 Headphone Audio Output, 1 RCA
Composite Video Input , 1 left/right Audio Input for Composite
Digital Terrestrial Broadcast (8VSB): 2 - 69
Digital cable (64/256 QAM): 1 - 135
Digital: ATSC/QAM
66.0 × 37.8 × 3.3 inches
(1 676 × 961 × 85 mm)
66.0 × 41.4 × 14.5 inches
(1 676 × 1 052 × 368 mm)
59.3 × 14.5 inches
(1 507 × 368 mm)
Disclaimer:
All products, product specifications, and data are subject to change
without notice to improve reliability, function, design or otherwise.
19
Certification and Compliance
FCC Notice
This device has been tested and found to comply with the limits for a Class B digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
device generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this device does cause harmful interference to radio or television
reception, which can be determined by turning the device off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the device and receiver.
● Connect the device into an outlet on a circuit different from that to which the receiver
is connected.
● Consult the dealer or an experienced radio/TV technician for help.
NOTE:
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.
The Wi-Fi Module complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This device should be installed and operated with a
minimum distance of 20 centimeters between the radiator and your body.
The manufacturer is not responsible for any radio or TV interference caused by
This device complies with Industry Canada’s licence-exempt RSSs. Operation is
subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Declaration of Conformity
Trade Name: Hisense
Model: 50Q7G / 50Q8G / 50H8G / 55Q7G / 55Q8G / 55H8G / 65Q7G / 65Q8G /
65H8G / 75Q7G / 75Q8G / 75H8G
Responsible Party: Hisense USA Corporation
Address: 7310 McGinnis Ferry Road, Suwanee, GA 30024
Telephone Number: 678-318-9060
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
20
Manufactured under license from Dolby Laboratories. Dolby, Dolby Atmos,
Dolby Vision, and the double-D symbol are trademarks of Dolby Laboratories.
Condential unpublished works. Copyright © 2012-2019 Dolby Laboratories.
All rights reserved.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
Environmental Protection
This mark indicates that this product should not be disposed together with other
domestic garbage, to avoid damage to the environment or human health due to the
disposal of uncontrolled waste. Recycle it responsibly for promoting the sustainable
reuse of material resources. To return your used device, please use the return systems
available in your location or contact the vendor where you purchased your product they
could take this product for recycling and protection of the environment.
©2020. All rights reserved. Hisense and the Hisense logo are registered trademarks of
Hisense. Other brand and product names are registered trademarks of their respective
owners.
21
Loading...
