Hisense 65XT910 User Manual

ES-A151111-1

Italiano

Español

English

Français

Português

Deutsch

Read the manual carefully and ensure you have fully understood

its contents before operating this device for the first time.

English

Read the manual carefully and ensure you have fully understood

its contents before operating this device for the first time.

English

A

Important Safety Instructions

Paragraphs beginning with the symbol indicate important instructions, tips or
conditions for the following settings.

For your own safety and the optimal performance of your TV, ensure to

read the safety instructions before performing any installation.

Hisense does not guarantee operation and performance of peripheral devices made by
other manufacturers. We disclaim any liability or damage that may arise from operation
and/or performance from usage of such other maker’s peripheral devices.

The recording and playback of content on this or any other device may require
permission from the owner of the copyright or other such rights in that content. It is
your responsibility to ensure that your use of this or any other device complies with
applicable copyright legislation in your country. Please refer to that legislation for more
information on the relevant laws and regulations involved or contact the owner of the
rights of the content you wish to record or playback.

The Index/Glossary explains certain terms used in this user manual and in the TV menu.

Declaration of Conformity (DoC)

This TV is CE marked and complies with EU directives. The complete declaration of
conformity is included in this manual, and can also be downloaded from the Hisense
homepage.

Hisense declares that this TV is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EG. It may be operated in all countries in
the EU and also Iceland, Norway and Switzerland. In France and Italy it may only be
used indoors.

Read these instructions
Follow all instructions
Heed all warnings
Keep these instructions

All rights reserved.

▐ Important Notice

English

B

Important Safety Instructions

To ensure safe and correct use of this product, always comply with the following
precautions to avoid dangerous situations and damage to your unit:

The intended use and ambient conditions for this TV

This TV is intended for the rendering of video and audio signals, on a table-top or wall-

mounted, in a home or ofce environment. It must not be used in rooms with a high

level of humidity or dust concentration. The warranty is only valid if used as intended
by the manufacturer.

WARNING

High humidity and dust concentration may lead to current leaks in the device. To

reduce the risk of re or electrical shock:

- Do not expose this unit to rain, moisture, dripping or splashing water, and do

not place objects lled with liquids, such as vases, cups, etc. on or over the

unit.

- Do not touch the TV with wet hands.

- Do not expose to direct air-conditioning and keep candles or other naked

ames away from the TV at all times.

If the TV is moved from a cold environment to a hot environment, leave it switched of
for at least an hour to avoid condensation. If used outside, make sure it is protected
from moisture.

If you notice anything unusual, immediately turn off the main power supply switch and
remove the power plug.

In case of re, use preferably a CO2 gas or powder re extinguisher. If such

extinguishers are not accessible, try to isolate the electrical supply before using a

water re extinguisher.

▌Safety Instructions

The lightning flash with arrowhead
symbol, within an equilateral triangle is
intended to alert the user to the presence
of uninsulated dangerous voltage within
the product's enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock.

The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.

English

C

Important Safety Instructions

Moving/Transportation

Before moving this TV, disconnect all
cables and move in the vertical position
only. Grasp the device on the upper and
lower edges of the frame.

- Do not press or put stress on the front
panel of the TV. It may take two or
more people to carry larger TVs.

If you have to briey lay down the TV,

place the unit with its entire front surface

lying at on soft material.

The LED screen is made of glass and can
break if is not handled properly. Always
wear rubber gloves to carry the unit. If
the LED screen is damaged, liquid crystal
might leak out. In case of skin contact,
immediately rinse thoroughly with water.

Power Supply

Incorrect voltages can damage the TV.

Only connect this unit to a power supply

with the correct voltage and frequency
noted on the type plate, using the
supplied power cable.

The power plug must be easily accessible
so that the device can be disconnected

at all time. The unit is live, even if the I/O

button is switched off, as long as the unit
is connected to a power outlet.

It is recommended that this unit is placed
on a dedicated circuit.

- Do not overload the power outlets by
connect too many appliances to the

same outlet. Overloaded wall outlets,

extension cords, etc. are dangerous
and can result in electric shock and

re.

After power off, don't turn it on again in
5 seconds. Frequent switching power
supply in a short period of time can cause
abnormal TV.

Power plug and power cable

- Do not touch the power plug with wet
hands.

- Do not place heavy objects on the
power cable. Route the cable so that it
is not kinked or laid over sharp edges,
walked on or exposed to chemicals. A
power cable with damaged insulation

can cause electric shock and re.

- Pull the power plug, NOT on the cable

when disconnecting. The cable can
become damaged and cause a short
circuit if pulled on.

- Do not place the power cable near a
high temperature object.

- Do not move the TV with the power
cable plugged into a socket.

- Do not use a damaged or loose power
cable, or a damaged socket outlet.

- Do not use any power cords other
then the one supplied with this unit.

Set-up

Check that the location is suitable to bear
the load of the TV. Place on a level, sturdy
and horizontal base. Ensure that the unit
does not hang over the edge of the base
when placed in or on furniture. If placed
on a cart, use caution when moving to
avoid the unit from tipping over.

- Place the unit in a normal upright
horizontal position. It must never

be operated vertically, lying at or

hanging overhead from the ceiling.

- Place the unit where it is not exposed to
direct sunlight or other sources of heat.

When mounting the TV on a wall, follow
the instructions supplied with the wall­mount, make sure not to install the TV by
hanging the power and signal cables on
the back of the TV.

English

D

Air ventilation and high

temperatures

Install your TV only where there is proper
ventilation, and ensure that there is at least

10 cm free space on the sides and 20 cm

above the unit for air circulation. Excessive
heat and obstruction of ventilation could

lead to re or early failure of some electric

components.

- Do not block any ventilation openings
with newspapers, tablecloths, curtains,
etc.

- Do not dry clothing etc. on top of the unit.

- Take care not to touch the ventilation
openings since they may become hot.

- Do not insert foreign objects into the TV
through the vents.

The Stand

- Do not use any stand other than the one
supplied with this unit.

- Do not modify or use the stand if it
becomes warped of physically damaged.

- During setup, make sure that all the
screws are securely tightened.

- Ensure that the TV does not suffer any
impact during the attachment of the
stand.

- Ensure that children do not climb onto
the stand.

- Attach or remove the stand with at least
two people.

Important Safety Instructions

20cm

10cm 10cm 10cm

Prevent small items from getting into the
interior of the device through the ventilation
slots. Such objects may cause short circuits,

which may cause re.

If something should get inside the unit,
immediately unplug the power plug of the
device and contact service support.

The LED screen

Despite thorough care when manufacturing
this display, it cannot be 100% guaranteed
that no sub-pixel defects will occur due
to technical reasons. These cannot be
considered as a device defect in terms
of the guarantee. They will not affect the
performance and reliability of the TV.

To prevent “image burn”, avoid displaying
still images for long periods of time, there
is a possibility that a copy of the image
may remain. If the aspect ratio is set to 4:3
for a long period of time, image burn may
occur on the black areas. Image burn is not
covered by the warranty.

- Do not apply strong force or impact on
the display panel.

Avoid touching the LED screen or touching
it for long periods of time. Doing so may
produce some temporary distortion effects
on the screen.

English

E

Important Safety Instructions

Supervision

- Do not let children play unsupervised
close to the TV. It could tip over, be
pushed off or pulled down from the
stand surface and injure someone.

- Do not allow a switched-on TV to run
unattended.

Volume

Loud music and noises can lead to
irreversible damage to your ears. Avoid
extreme volume, especially over long
periods and when using headphones.

If you hear a drumming noise in your ears,
turn down the volume or temporarily stop
using headphones.

Thunder Storms

Pull out the power plug and all connected
antenna cables from the TV during a

thunderstorm. Overvoltage caused by

lightning strikes can damage the TV via
the antenna system, as well as the wall
socket.

Long periods of absence

As long as the power plug is connected to
a live socket outlet, the TV will consume

power even in “OFF”-mode. The power

plug and all connected antenna cables
should be disconnected out during long
periods of absence.

Radio waves

- Do not use the TV in any medical
institutions or locations with medical
equipment. Radio waves may interfere
with medical equipment and cause
malfunction.

- Do not use the TV near any automatic
control equipment such as automatic

doors or re alarms. Radio waves

may interfere with automatic control
equipment and cause malfunction.

If you have a cardiac pacemaker, keep a

distance of at least 22 cm from the TV. Radio

waves may interfere with the operation of a
pacemaker.

Built-in wireless LAN

- Do not connect to wireless networks
that you do not have the usage rights
for. Data transmitted and received over
radio waves may be intercepted and
monitored.

The built-in wireless LAN uses 2.4 GHz

and 5 GHz frequency bands. To avoid
malfunctions or slow response caused
by radio wave interference, keep the TV
away from devices such as other wireless
LAN devices, microwaves, mobile phones,

and other devices that use 2.4 and 5 GHz

signals.

English

F

Cleaning and care

CAUTION:

Unplug the power cord prior to
cleaning the TV.

Clean the TV, the screen, and the remote
control with a soft, moist, clean and
color-natural cloth only. Do not use any
chemicals.

- Do not subject the surfaces to insect
repellent, solvent, thinner or other
volatile substances. This may degrade
the surface quality.

- Do not spray water or other liquids
directly on the TV. Liquid inside the TV
could lead to product failure.

- The surface of the display panel is
treated and may be easily damaged.
Take care not to scratch it with

ngernails or other hard objects.

- Also wipe the power plug with a dry
cloth at regular intervals

Service/Repair

Never remove the cover/back of the TV;
there are no user serviceable parts inside.

Refer all service to qualied service

personnel.

Packaging

Keep the anti-moisture materials and
plastic bags out of reach of children.

Plastic bags can cause suffocation and
the anti-moisture material is harmful if
swallowed. If swallowed by mistake, force
the patient to vomit and visit the nearest
hospital.

Modication

Do not attempt to modify this product

in any way. Unauthorized modication

could void the warranty of this unit, cause

electric shock and res.

Remote Control batteries

- Incorrect installation may cause battery
leakage, corrosion and explosion.

- Replace only with the same or
equivalent type.

- Do not mix old and new batteries.

- Do not mix different battery types

- Do no use rechargeable batteries

- Do not burn or break up batteries.

- Do not expose batteries to excessive
heat

- Be sure to dispose of batteries
correctly

Outdoor Antenna Grounding

If an outdoor antenna used, be sure the
antenna system is protected against
voltage surges and built-up static charges.

Disposal

Refer to the recycling section of this
manual.

Using the 3D function

Read the following safety instructions
before using the 3D function of your TV.

The function is only applicable to the
products which support it.

Important Safety Instructions

English

G

WARNING

People that have a visual disorder may
not be able to perceive 3D effects or
may only be able to perceive them to a
limited extent.

Only watch 3D images after consulting
your doctor if you have a history

of oversensitivity to light/ickering

images, heart problems, are pregnant
and/or any other medical condition
such as epilepsy, cardiac disorder,
blood pressure disease, etc.

Do not watch 3D content if you feel
nauseous, are fatigued from lack of
sleep, overwork or intoxication.

3D content is not recommended
for those who suffer from stereo
blindness or stereo anomaly. Double
images or viewing discomfort may be
experienced.

If you are cross-eyed, weak sighted
or have astigmatism, you may have
trouble sensing depth and easily feel
fatigue due to double images. It is

advised to take more frequent breaks

than the average adult.
If you experience any of these

symptoms, stop using/watching 3D
video immediately and get enough

rest until the symptoms subsides:

headache, eyeball pain, dizziness,
nausea, palpitation, blurriness,
discomfort, double image, visual
inconvenience or fatigue. Consult your
doctor if the symptoms persist.

CAUTION

Viewing Distance – Maintain a distance
of at least twice the screens diagonal
length when watching 3D content.
If you feel discomfort in viewing 3D
content, move further away from the
TV.

Have longer pauses when watching 3D
images then regular movies. Failure to
do so can result in headaches, fatigue,
dizziness, eye strain or discomfort.

Position yourself comfortably in
front of the TV and ensure that you

are seated rmly. When viewing 3D

images your sense of distance may
be fooled or go wrong. Be careful not
to hit the TV screen or other people
unintentionally. Ensure there are no
breakable objects around you to avoid
any accidental damage or injury.

Infants/Children

- Children under the age of 5 should
not view 3D images, as a guideline.

- Children under the age of 10 may
overreact and become overly
excited because their vision is in
development. All children must
be fully supervised by parents or
guardians to ensure their safety and
health while they are watching 3D
images.

- Children perceive more stereoscopic
depth compared to adults because
the distance between the eyes is
shorter.

Teenagers

- Teenagers under the age of 19 may
be stimulated to light coming from
3D images. Advise them not to watch
3D videos for a long time when they
are tired.

Elderly

- The elderly may perceive less
of a 3D effect than the youth. Do
not sit closer to the TV than the
recommended distance.

Important Safety Instructions

English

H

Cautions when using 3D

glasses

- Only use the 3D glasses for the

intended purpose and nothing else.
Do not use 3D glasses instead of
your normal glasses, sunglasses or
protective goggles.

- Do not move around while wearing 3D
glasses to avoid falling or accidental
injury.

- Be careful of the tips of the frame in
relation to your eyes when putting on
the 3D glasses.

- Be careful not to trap your ngers in

the hinge section of the 3D wear.

- Do not use 3D glasses if they are
physically damaged.

- Using modied 3D glasses may cause

eye strain or image distortion.

- Do not keep your 3D glasses in
extremely high or low temperatures. It
will cause deformation.

- The 3D glasses are fragile and are
easy to scratch. Use a soft, clean piece
of cloth when wiping the lenses. Do not
scratch the lenses with sharp objects
or clean/wipe them with chemicals.

- Do not drop, exert pressure, or step on
the 3D glasses.

- If you suffer from eyesight problems
(short-/farsighted, astigmatism,
eyesight difference between left and
right), ensure that you correct you
vision before using the 3D glasses.
The 3D glasses can be worn over
vision correction glasses.

- Stop using the 3D glasses immediately
if you experience any redness, pain
or skin irritation around the nose or
temples. In rare cases, the materials
used in the 3D glasses may cause an
allergic reaction.

Notes

- Use only approved 3D glasses.

Otherwise, you may not be able to

view 3D images properly.

- It may take some time for you to get
used to the 3D glasses, and before
you can perceive the 3D effects
properly.

- Switch of any articial light sources

between the 3D TV set and the 3D
glasses. These could interfere with
the infrared reception or the TV

picture may icker as a result.

- To prevent interference with other TVs
or wireless devices, the 3D glasses
needs to be paired with the TV. Press
the power key on the 3D glasses to
start pairing, when the indicator light

ashes, the pairing is complete.

- Certain functions like Zoom are not
available when watching 3D images.

- This TV automatically identies

3D formats when connected to a

HDMI v1.4 compatible source. Other

sources require manual setup.

Important Safety Instructions

English

1

Contents

Contents

Accessories List..............................................................................................................1

Installing the Stand ......................................................................................................... 2

TV Front..........................................................................................................................3

TV Rear ..........................................................................................................................4

Making Connections ....................................................................................................... 5

Remote Control ............................................................................................................ 11

Turning the TV on for the First Time .............................................................................15

Specifications ...............................................................................................................16

Other Information..........................................................................................................17

TV Base Stand Rear Stand

User Manual European Guarantee AAA Battery × 4

Remote Control × 2 screw × 8 3D Glasses

Accessories List

The following accessories are included with TV:

Apparatus with CLASS I construction shall be connected to a MAINS
socket outlet with a protective earthing connection.

PVR

VOLCH

OK

BACK EXIT

INPUT

EN2D27

TXT

LiveTV

Subtitle

CH.List

EPG Info

Please visit Hisense ofcial website for more details.

Product image is only for reference, actual product may vary in appearance.

English

2

Installing the Stand

Installing the Stand

CAUTION

Be sure to disconnect the A/C power cord before installing a stand or Wall-Mount
brackets.

The LED display is very fragile, and must be protected at all times when installing
the base stand. Be sure that no hard or sharp object, or anything that could scratch

or damage the LED display, comes into contact with it. DO NOT exert pressure on

the front of the TV at any time because the screen could crack.

To attach the left and right leg that forms the stand:

1. Unpack the carton and remove the two
side cushions, take the TV out of the
carton together with the top cushion,
then put them on the horizontal table
with the LCD downward.

Attention: The way of TV's taking-out is
shown on the label which is pasted on
the top cushion.

3. Take the curved base stand out of the
top cushion, secure it to the TV with the
4 provided screws in the accessory bag.

Attention: It is suggested to be done
with two persons.

2. Remove the screws of the side covers

as shown in figure, and then take off
the two covers.

4. Take the two rear base stands out of the
top cushion, secure them to the TV with the
4 provided screws in the accessory bag.

Cover

Cover

M4×12

M4×12

M4×12

Top Cushion

Rear Stand

Base Stand

M4×12

English

3

TV Front

TV Front

Power indicator Remote sensor

NOTES

The Picture is Only for Reference.

Powering on the TV requires several seconds to load program. Do not rapidly turn
the TV off as it may cause the TV to work abnormally.

Power Switch I O

OK

TV Bottom Panel

TV Back View

Item Description

Power switch Turn the main power ON or OFF.

Remote sensor

Receive remote signals from the remote control.

Do not put anything near the sensor, as its function may be affected.

Power indicator

The light is off when turned on.

Lights up in standby mode.

Select among the different input signal sources and put the TV
in standby mode, and you can turn on the TV when the TV in
standby mode.

Toggle the OK button left and right to adjust the volume.

Toggle the OK button up and down to select the channel.

Bluetooth device pairing

English

4

TV Rear

TV Rear

NOTES

ANT2 Jack supports power supply for satellite antenna
(13/18V, 0.5A max.)

Check the jacks for position and type before making any
connections. Loose connections can result in image or
color problems. Make sure that all connections are tight and
secure.

Not all A/V devices have the ability to connect to a TV, please
refer to the user’s manual of your A/V device for compatibility
and connections procedure.

Before connecting external equipment, remove the mains plug
from the wall socket. This may cause electric shock.

TV Bottom Panel

TV Side View

ANT 1

ANT 2

ANT 1

DVB-T/T2/C

ANT 2

DVB-S/S2

HEADPHONE

HDMI

HDMI

COMMON

INTERFACE

SERVICE

HDMI 1(MHL)HDMI 2(ARC)

SERVICE

HEADPHONE

USB

USB

USB

USB 3(3.0)

DC 5V --- 1A(MAX)

COMMON INTERFACE

DC 5V 0.5A(MAX)

USB 1

USB 2

LAN

HDMI 3(2.0)

HDMI 4(2.0)

OPTICAL

Y

VIDEO

P

B

L

P

R

R

AV IN

COMPONENT IN

SCART

English

5

Making Connections

LAN (

Wired setup

)

Connect your TV to your network by connecting the LAN port on the back of your
TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the
illustration below.

·

We recommend to use a modem or router that supports Dynamic Host
Configuration Protocol (DHCP). Modems and routers that support DHCP
automatically provide the IP address, subnet mask, gateway, and DNS, so you
don’t have to enter them manually. Most home networks already have DHCP.

Wireless setup

Connect your TV to your network wirelessly, you need a wireless router or modem.
See the illustration below.

·

The built-in Wireless LAN Adapter supports the IEEE 802.11 b/g/n
communication protocols. We recommend using IEEE 802.11n router. Low

transfer rates for b/g may have the influence on the quality of streamed videos
and other media.

Wireless router with DHCP

LAN Cable

Wireless LAN Adapter

built-in TV set

TV JACK

Modem CableLAN CableLAN Cable

External Modem

(ADSL / VDSL / Cable TV)

IP Sharer (Router)

(with DHCP server)

LAN

NOTES

You must use the built-in Wireless LAN Adapter to use a wireless network because
the set doesn’t support external USB network adapter.

If the wireless router supports DHCP, your TV can connect more easily to the wireless
network.

If you apply a security system other than the systems listed below, it will not work with
the TV.

Security system:WPA,WEP,WPA2.

In order to guarantee smooth network, the distance between router and TV is less
than 10 meters.

English

6

HDMI 1(MHL)

Connect an MHL cable (not provided) from your MHL-enabled device,

such as a cell phone.

Making Connections

HDMI 2(ARC)

Connect an HDMI cable from an external digital audio system.

ARC enables the TV to directly output the digital sound through an HDMI cable.
Please note that it works only when the TV is connected to the audio receiver that
supports the ARC (Audio Return Channel) function.

When this port is used as the ARC function, it can't be used as signal input at the
same time.

TV JACK

TV JACK

HDMI cable (not included)

MHL cable (not included)

HDMI 2(ARC)

HDMI

Audio Amplier/Speaker

Phone

HDMI

Connect an HDMI cable from an external A/V equipment.

Some devices such as PVR or DVD player require HDMI signal to be set to output
in the device's settings. Please consult your device user manual for instructions.
Please note that the HDMI connector provides both video and audio signals, it’s

not necessary to connect an audio cable.

TV JACK

(not included)

HDMI

DVD/Blu-Ray/AV receiver/

Set-top Box

HDMI

NOTES

Sources of UHD (4K) content must be connected to the HDMI1 / HDMI2 / HDMI3 / HDMI4

input.

For the moment digital television channels do not deliver UHD content.

The repetition rate is fixed at 100%, and it can not be adjusted.

HDMI 1(MHL)

English

7

Making Connections

HEADPHONE Connect Headphone for audio out of the TV.

TV JACK

Headphone (not included)

HEADPHONE

ANT Connect an outdoor VHF/UHF antenna or cable.

ANT Connecting a satellite antenna.

TV JACK

Outdoor

Antenna

Antenna Cable (75Ω)

or

ANT OUT

Cable

VHF/UHF Antenna

ANT 1

DVB-T/T2/C

(not included)

(not included)

TV JACK

ANT 2

DVB-S/S2

SCART Connect an external A/V Device using an Scart cable.

TV JACK

VCR/DVD Player/Recorder/

Set-top box/Satellite Receiver

(not included)

SCART

English

8

Making Connections

USB

Connect the USB devices such as hard drives, USB sticks and digital cameras
for browsing photos, listening music and watching recorded movies. You can use
Timeshift and record (refer to “PVR/Timeshift”). At the same time update is also an
easy thing and will be done just by plugging the USB with the updating files into
the same interface.

NOTES

When connecting a hard disk or a USB hub, always connect the mains
adapter of the connected device to the power supply. Exceeding a total current

consumption may result in damage. The USB1.1 and USB2.0 devices maximum

current consumption are 500mA. The USB3.0 device maximum current
consumption is 1A.

For individual non-standard high-capacity mobile hard disk, if it's impulse current
is greater than or equal 1A, it may cause TV-rebooting or self-locking. So the TV
does not support it.

The USB port supports a voltage of 5V.

The maximum supported storage space of the hard disk is 1T.

If you want to store the video streaming of a DTV program, the transfer rate of
the USB storage device must not be less than 5MB/s.

The USB 3(3.0) supports the FHD picture and 4K × 2K video.

Since the function record temporary the program onto a hard disk only. Please

connect a hard disk which its storage capacity is no less than 8G.

TV JACK

DC 5V 0.5A(MAX)

USB 1

USB 2

USB 3(3.0)

DC 5V --- 1A(MAX)

English

9

Making Connections

COMMON INTERFACE

Insert the CI+ module for watching scrambled services like pay-tv channels or
some HD channels.

SMART CARD

CAM CARD

TV JACK

1 2

NOTES

Before you insert/remove the CI+ module, ensure that the TV is switched off.
Then insert the CI card into the CI+ module in accordance with the Service
Provider’s instructions.

Do not repeatedly insert or remove the Common Access Module as this may
damage the interface and cause a malfunction.

You must obtain a CI+ module and card from the service provider of the
channels you want to watch.

Insert the CI+ module with the SmartCard in the direction marked on the module
and SmartCard.

CI+ is not supported in some countries and regions; check with your authorized
dealer.

OPTICAL Connect to an external digital audio device.

Before connecting a digital audio system to the OPTICAL jack, you should

decrease the volume of both the TV and the system to avoid that the volume
suddenly become bigger.

TV JACK

OPTICAL cable (not included)

Audio Amplier/Speaker

OPTICAL

English

10

Making Connections

AV IN

Connect the Composite cable from an external A/V Device.

Use the audio and video cables to connect the external A/V device’s composite
video/audio jacks to the TV’s jacks. (Video = yellow, Audio Left = white, and Audio
Right = red)

COMPONENT IN

Connect a component cable and an audio cable from an external

A/V Device.

The component output ports Y, P

B

and PR on the VCD or DVD can sometimes be

identified as Y, C

B

and CR.

Yellow(Video)

(not included)

(not included)

White(L)

(not included)

Red(R)

TV JACK

VCR/DVD Player/

Recorder/Set-top box/

Satellite Receiver/Video Camera

Video

L

A/V OUT

R

Y

VIDEO

P

B

L

P

R

R

AV IN

COMPONENT IN

(not included)

RL PRPBY

Component

(not included)

Blue(PB/CB)

Green(Y)

(not included)

White(L)

(not included)

Red(R)

(not included)

Red(PR/CR)

TV JACK

Y

VIDEO

P

B

L

P

R

R

AV IN

COMPONENT IN

VCR/DVD Player/Recorder/

Set-top box/Satellite Receiver/

Video Camera

English

11

Remote Control

1

POWER: Switch the TV on or into standby

mode

2

Special function buttons direct selection
of options

3

Adjust the volume

4

To speak a voice command press and

hold the VOICE button and say a voice

command

5

Navigation buttons ▲/▼/◄/►: Up/Down/

Left/Right

6

OK: Confirm the selection in the OSD

menus

7

BACK: Return to previous menu

8

HOME: Enter the Smart

9

CH + /-: Switch channel

10

Playback and record keys

11

Receive the voice

12

INPUT: Select input sources

13

KPAD: Brings up the virtual keyboard.

14

EXIT: Exit the menu

1

2

3

4

5

7

8

9

6

10

12

11

13

14

1. Lift the back cover to open the battery compartment of the remote control.

2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the

batteries with the (+) and ( - ) ends indicated in the battery compartment.

3. Close the battery compartment with the cover.

Installing Batteries in the Remote Control

Remove the battery
compartment cover

1

2

Insert the batteries

3

Close the battery compart­ment cover

English

12

Remote Control

Pairing the Remote Control

Voice Control (optional)

Keep the remote control close to the Bluetooth device pairing window . Press the
voice key

to open the voice control function, and hold the blue button until the red

light on the remote control remains lit, and wait until the remote pairing is complete.

If the remote control pairing is successful, the screen will display "Remote control
pairing is successful. Welcome to experience!"

If the remote control pairing fails, the screen will display "Remote control pairing
fails. Please try again".

Press the voice key

to open the voice control function. Press the voice key,
the screen displays the voice helper, then you can say a voice command, the
corresponding voice control function will be executed. After a period of time without
voice input, the remote control automatically turns off the microphone.

Please only use the following voice commands. If you say any voice command that
are not provided by the system, it cannot be recognized.

Supported voice commands

Volume Control

For example, Set volume to 25 / Volume 10 / Volume up / Mute.

Channel Switching

For example, Channel 3.

Source switching

For example, Change to HDMI2 / Switch input source.

System Setting

For example, Open settings / Audio settings / Change my location / Start the

network settings menu / Go to picture settings.

Google Search

For example, Search movies on Google.

Application Management

For example, Netflix / Open Netflix / Start Netflix.

NOTES

Pairing the remote control from 10cm away from the Bluetooth device pairing window .

When the TV is in standby mode, it does not support Bluetooth pairing.

If you want to cancel pairing, hold the blue button, the indicator light flashes purple
and then turns off. If the remote control unpairing is successful, when you press
any button on the remote control, the indicator light will turn red.

NOTES

When you say a voice command, keep a distance of 10cm ~ 15cm from the
microphone.

English

13

PVR

VO

LC

H

OK

BACK EXIT

INPUT

EN2D27

TXT

LiveTV

Subtitle

CH.List

EPG Info

Remote Control

1

POWER: Switch the TV on or into

standby mode

2

INPUT: Select input sources

3

Channel Number: Direct channel
selection or numbers input

4

EPG: Display the Electronic Program
Guide (DTV mode)

5

Info: Display the present program
information such as the current channel
and the input source

6

Color keys for direct selection of options

7

SETTING: Display the Settings menu

8

Fast access to the all applications

9

/ / < / >: Allows you to navigate the

OSD menus and adjust the system

settings to your preference

10

OK: Confirm the selection in the OSD

menus

11

BACK: Return to previous menu

12

EXIT: Exit the menu

13

HOME: Enter the Smart

14

CH.List: Display the Channel List on the
screen

15

VOL + /-: Adjust the volume

16

CH + /-: Switch channel

17

MUTE:Mute or restore the TV sound

18

Playback and record keys

19

PVR: Record the current program (DTV
mode)

20

NETFLIX:Press to launch NETFLIX
instant video streaming

21

YouTube:Enter the YouTube app

22

Subtitle:Activate or deactivate the subtitle
mode

23

TXT: Turn on/off the teletext function

1

4

5

7

9

11

16

13

15

18

20

22

2

3

6

8

10

12

14

17

19

23

21

English

14

Remote Control

Remote Control Operation Range

1. Point the remote control at the
TV within no more than 5 metres
from the remote control sensor
on the TV and within 60° in front
of the TV.

2. The operating distance may vary

depending on the brightness of
the room.

1. Slide the back cover to open the battery compartment of the remote control.

2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the

batteries with the (+) and ( - ) ends indicated in the battery compartment.

3. Close the battery compartment with the cover.

Installing Batteries in the Remote Control

NOTES

Product image is only for reference, actual product may vary in appearance.

Handling the Batteries

Incorrect use of batteries may cause corrosion or battery leakage, which could
cause fire, personal injury or damage to property.

Only use the battery type indicated in this manual

Do not mix old and new batteries or different types of batteries .

Do not dispose of used batteries as domestic waste. Dispose of them in
accordance with local regulations.

Insert the batteriesGently push and slide Gently push and slide

English

15

Turning the TV on for the First Time

1. Connect the mains cable to the mains socket after you have completed all the
connections.

2. The first time you turn the TV on, it will go straight into the Installation Guide. It will
assist you to specify the Language, Location, Time Zone, Mode, EULA, Network
and Input.

3.

Press the [

/ / < / >] to navigate the menu and change the settings. Press the [OK]

button to confirm.

Turning the TV on for the First Time

Language Select your desired language to be displayed on the menu.

Location Select the country where you will operate the TV.

Time Zone

Select the time zone you are located at.
Use the Forward arrow to navigate through selections and press

[OK] button.

Mode

Select Home Mode and then navigate to the Forward arrow to
press [OK] button.
Note: ‘Store mode’ should only be selected by Retailers who
plan to demonstrate the TV.

EULA

Accept EULA
Help promote the TV user experience.

Network

If your TV does not automatically detect an Ethernet connection,
then select Wireless. When you’re done, select your network
from the list that displays and move to the next screen.

Input

Select how you receive your TV channels. Choose from one of
the following sources below and then move to the next screen.

• TV

• AV

• COMPONENT

• Scart

• HDMI

Note: If you use an antenna to receive channels, then you must
complete the first-time setup menu in order to run a channel
scan.

Complete

Congratulations! Your TV is now ready to use.

Press [OK] on your remote if you are fine with the selections.

Otherwise, navigate to the back arrow on the screen to change

your selection.

English

16

Specifications

Features, appearance and specifications are subject to change without notice.

Model Name

65"

Dimension

Without Stand

Width: 56.9 inches (1446 mm)

Height: 33.0 inches (839 mm)
Depth: 6.0 inches (152 mm)

With Stand

Width: 56.9 inches (1446 mm)

Height: 34.5 inches (877 mm)
Depth: 11.3 inches (288 mm)

Weight

Without Stand 61.7 lbs (28 kg)

With Stand 70.5 lbs (32 kg)

LED Panel Minimum size
(diagonal)

163cm

Screen resolution 3840 × 2160

Audio power 15 W +15 W

Power consumption Please refer to the rating label.

Power supply Please refer to the rating label.

Receiving
systems

Analog PAL-D/K, B/G, I,SECAM-D/K, B/G, L/L’

Digital DVB-T/T2,DVB-C,DVB-S/S2

Environmental conditions

Temperature: 41°F - 95°F (5°C - 35°C)

Humidity: 20% - 80% RH
Atmospheric pressure: 86 kPa - 106 kPa

Component Input

480 I / 60 Hz, 480 P / 60 Hz, 576 I /50 Hz, 576 P /50
Hz, 720 P / 50 Hz, 720 P / 60 Hz, 1080 I / 50 Hz, 1080
I / 60 Hz, 1080 P / 50 Hz,1080 P / 60 Hz

HDMI Input

HDMI1, HDMI2:
RGB / 60 Hz (640×480, 800×600, 1024×768)
YUV / 60 Hz (480 I, 480 P, 720 P, 1080 I, 1080 P)
YUV /50Hz (576 I, 720 P, 1080 I, 1080 P)
3840×2160/24Hz, 3840×2160/25Hz, 3840×2160/30Hz

HDMI3, HDMI4:

RGB / 60 Hz (640×480, 800×600, 1024×768)
YUV / 60 Hz (480 I, 480 P, 720 P, 1080 I, 1080 P)
YUV /50Hz (576 I, 720 P, 1080 I, 1080 P)
3840×2160/24Hz,3840×2160/25Hz,3840×2160/30Hz,
3840×2160/50Hz, 3840×2160/60Hz

English

17

Other Information

Recycling/Licenses

WEEE (Waste Electronic Electric Equipment)

European Directive 2002/96/EC

This symbol on the product or on its packaging indicates that
this product must not be disposed of with your household
waste. Instead, it is your responsibility to dispose of your waste
equipment by handing it over to a designated collection point
for the recycling of waste electrical and electronic equipment.
The separate collection and recycling of your waste equipment
at the time of disposal will help to conserve natural resources
and ensure that it is recycled in a manner that protects human
health and the environment. For more information about where
you can drop off your waste equipment for recycling, please

contact your local city ofce, your household waste disposal

service or the shop where you purchased the product.

Batteries

In accordance with the Battery Directive, used batteries should
not be disposed of in the domestic waste. Dispose your

batteries in the collection containers specic for this purpose in

retail stores.

ROHS (Restriction of Hazardous Substance)
European Directive 2011/65/EU

This European directive limits the use of dangerous and haz­ardous substances which are difficult to recycle.

This allows recycling easily the EEE and contributes to the
safeguard of the environment.

Substances included in this product match to the RoHS direc­tive.

The terms HDMI and HDMI High-Denition Multimedia

Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing LLC in the United States and
other countries.
