Product Specifications Page 1
Product
Manufacturer Model Number 65P7
Image display
Screen size (rounded to nearest integer)
cm 164
Screen size (rounded to nearest integer)
inch 65
Display technology
LCD/LED
Lighting System
Elite Backlight
Resolution (Horiz x Vert)
pixel 3840 x 2160
Colour depth
bit 10
Smooth motion rate
200
Viewing Angle (Horiz / Vert)
Degrees 89 / 89
Wide colour gamut
Yes
processing
Backlight control Yes
Local dimming Yes
Zoom modes 4:3 / 16:9 / Auto / Zoom 1 / Zoom 2
HDR system HDR10
HEVC (H.265) decoder Yes
Motion enhancement and compensation (MEMC) Yes
Hardware
Processor
Quad Core
Colour (Front bezel, rear, stand) Silver / Black / Silver
Speakers mounted in a box Yes
Supply range (Voltage / Frequency) Volt / Hz 100 ~ 240V / 50, 60Hz
Standby consumption Watt < 0.5W
Inputs
HDMI inputs 4
HDMI type 4K@60Hz with HDCP version 2.2 Yes (HDMI 1, HDMI 2)
HDMI type 1.4 with HDCP version 1.4 Yes (HDMI 3, HDMI 4)
HDMI 2.0 compliant input Yes (HDMI 1, HDMI 2)
ARC -Audio Return Channel Yes (HDMI 2)
CEC- Consumer Electronics Control via HDMI Yes
RF- Radio frequency input 1
AV input 1
USB interface type 3.0 (Qty / List….) 1 / USB 2
USB interface type 2.0 (Qty / List ….) 1 / USB 1
Optical digital audio output (SPDIF) 1
Earphone jack 1
4/05/2018 1 / 3
Product Specifications Page 2
Smart TV
Ethernet port (RJ45 connector) 1
Wi-Fi protocols IEEE 802.11 {b, g, n, ac, ad, ..} b, g, n, ac
Wi-Fi bands GHz 2.4 / 5
DLNA compliance Yes
Bluetooth No
Anyview (Screen mirroring) Yes
Streaming Video On Demand Yes
UHD (4k) streaming Yes
Freeview Plus Yes
Web browser Yes
RemoteNow Smartphone App Supported Yes
Digital TV
Television system (DVB-T / DVB-T2) Yes / Yes
Video decoder (MPEG2 / MPEG 4) Yes / Yes
AC3 Surround sound decoder Yes
AS 4599.1 compliance Yes
AS 4933.1 compliance Yes
LCN- Logical channel number and DTV Service name support Yes
Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX Yes / Yes / Yes
Subtitles Yes
RF Signal strength indicator Yes
RF Signal quality indicator Yes
EPG- Electronic programming guide, 7 days for all services Yes
Audio description (vision impairment aid) Yes
Parental rating lock Yes
On/off timer Yes
Power off if no signal Yes
Sleep timer Yes
Program lock Yes
Favourite channels list Yes
USB media
player
Personal Video Recorder Yes
Time Shift Yes
DTV Recording (EPG scheduling / start from Standby ) Yes / Yes
DivX decoder Yes
MPEG4 (H.264) / HEVC (H.265) decoder Yes / Yes
Digital media player content (Music / Video / Photos / Text) Yes / Yes / Yes / No
Digital media player Auto-play Yes
Digital media player for UHD content via USB Yes
Supported File Formats FAT / FAT32 / NTFS
Sound
Audio power output per channel Watt 10
Number of speakers (Tweeter / Midrange / Woofer) 0 / 2 / 4
Automatic volume level (AVL) Yes
Audio equalizer Yes
Dolby Digital Yes
Audio enhancement -Type DBX
Lip-sync adjustment Yes
4/05/2018 2 / 3
Product Specifications Page 3
Hotel lock
Protected Hotel lock submenu (Password / fixed code) No / Yes
Clone function for programs, sound and image settings. Yes
Tuning lock Yes
Keyboard lock Yes
Maximum volume lock Yes
Power on volume Yes
Power on, apply default sound/image settings Yes
Power on source selection Yes
Power on RF channel selection Yes
Power on mode (On / Standby / Last) Yes / Yes / Yes
Inputs access (Enable / Disable) Yes
Installation
Stand area (Width / Depth) mm 1305 / 376
VESA Wall mount dimensions (Horiz / Vert) mm 400 / 200
Wall mount thread ( Size / Depth) mm M6 / 12
Power cord length cm 200
Accessories
included
Remote controller (Technology / Part number ) IR / ENC3C39
Battery (size / quantity) AAA / 2
Quick setup guide Yes
Warranty Sheet Yes
Dimensions
Dimensions with stand (W x H x D) mm 1450×921×376
Dimensions without stand (W x H x D) mm 1450×845×54
Carton box dimensions (W x H x D) mm 1618×985×155
Net weight (with stand / without stand) kg 27.3 / 26.3
Gross weight kg 34.7
4/05/2018 3 / 3
