Hisense 65B4E30T, 32B4E30T, 43B4E30T, 50B4E30T, 55B4E30T User Manual

Read the manual carefully and ensure you have fully understood its

contents before operating this device for the first time.

English

Safety Instructions

This symbol indicates high voltage
is present inside. It is dangerous
to make any kind of contact with
any inside part of this product.

CAUTION: To reduce the risk of

This symbol alerts you that
important literature concerning
operation and maintenance has
been included with this product.

electric shock, do not remove cover
(or back). No user serviceable parts

service personnel.

Waste Electrical and Electronic Equipment-WEEE

Attention: users in European Union private households

This marking on the product or on its packaging illustrates that,
under European Directive 2012/19/EU governing used electrical
and electronic appliances, this product may not be disposed of with
normal household waste. You are responsible for disposal of this
equipment through a designated waste electrical and electronic
equipment collection. To determine the locations for dropping off
such waste electrical and electronic equipment, contact your local

government ofce, the waste disposal organization that serves your

household or the store at which you purchased the product.

End of Life Directives-Recycling

CAUTION

RISK OF SHOCK

ELECTRIC

Your new Public Information Display contains several materials that
can be recycled for new users.

Please dispose of according to all Local, State, and Federal laws.

End-of-Life Disposal

Your new Public Information Display contains materials that can be recycled and

reused. Specialized companies can recycle your product to increase the amount of
reusable materials and to minimize the amount to be disposed of.

Please nd out about the local regulations on how to dispose of your old display from

your local dealer.

For customers in Canada and U.S.A.

This product may contain lead and/or mercury. Dispose of in accordance to local­state and federal regulations. For additional information on recycling contact www.eia.
org (Consumer Education Initiative)

i

Safety Instructions

Important Safety Instructions

Read and follow these instructions when connecting and using your Public
Information Display.

• Unplug the display if you are not going to use it for an extensive period of time.

• Unplug the display if you need to clean it with a slightly damp cloth. The screen
may be wiped with a dry cloth when the power is off. However, never use alcohol,
solvents or ammonia-based liquids.

• Consult a service technician if the display does not operate normally when you
have followed the instructions in this manual.

• The casing cover should be opened only by qualied service personnel.

• Keep the display out of direct sunlight and away from stoves or any other heat
sources.

• Remove any object that could fall into the vents or prevent proper cooling of the
display’s electronics.

• Do not block the ventilation holes on the cabinet.

• Keep the display dry. To avoid electric shock, do not expose it to rain or excessive
moisture.

• If turning off the display by detaching the power cable, wait for 6 seconds before
re-attaching the power cable for normal operation.

• To avoid the risk of shock or permanent damage to the set, do not expose the
display to rain or excessive moisture.

• When positioning the display, make sure the power plug and outlet are easily
accessible.

• IMPORTANT

If a still image in high contrast remains on the screen for an extended period of
time, it may leave an ‘after-image’ or ‘ghost image’ on the front of the screen. This
is a well-known phenomenon that is caused by the shortcomings inherent in LCD
technology. In most cases the afterimage will disappear gradually over a period
of time after the power has been switched off. Be aware that the after-image
symptom cannot be repaired and is not covered under warranty.

: Always activate a screen saver program during your application.

Safeguards

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.

ii

Safety Instructions

8. Do not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type

plug has two blades and a third grounding prong. The wide blade or the third

prong is provided for your safety. If the provided plug does not t into your outlet,

consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specied by
the manufacturer, or sold with the apparatus. When a cart is used,
use cautiously when moving the cart/apparatus combination to avoid
injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of
time.

14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.

15. The batteries (batteries installed) shall not be exposed to excessive heat such as

sunshine, re or the like.

16. An all-pole MAINS SWITCH is used as the disconnect device, the location on the
apparatus and the function of the switch shall be described, and the switch shall
remain readily operable.

WARNING:

• To reduce the risk of re or electric shock, do not expose this apparatus to rain or
moisture.

• Apparatus shall not be exposed to dripping or splashing and no objects lled with
liquids, such as vases, shall be placed on the apparatus.

• The batteries (batteries installed) shall not be exposed to excessive heat such as

sunshine, re or the like.

• The mains plug or appliance coupler is used as the disconnect device,the
disconnect device shall remain readily operable.

• To prevent the spread of re, keep candles or other open ames away from this
product at all times.

• To prevent injury, this apparatus must be securely attached to the oor/wall in
accordance with the installation instructions.

iii

Safety Instructions

• The Class I apparatus shall be connected to a mains socket outlet with a
protective earthing connection.

Never place a television set in an unstable location. A television set may fall, causing
serious personal injury or death. Many injuries, particularly to children, can be
avoided by taking simple precautions such as:

• Using cabinets or stands recommended by the manufacturer of the television set.

• Only using furniture that can safely support the television set.

• Ensuring the television set is not overhanging the edge of the supporting furniture.

• Not placing the television set on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the television set to a
suitable support.

• Not placing the television set on cloth or other materials that may be located
between the television set and supporting furniture.

• Educating children about the dangers of climbing on furniture to reach the
television set or its controls.

If your existing television set is being retained or relocated, the same considerations
as above should be applied.

• This equipment is compliant with Class A of EN55032/CISPR 32. In a residential
environment this equipment may cause radio interference.

CAUTION:

• These servicing instructions are for use by qualied service personnel only. To
reduce the risk of electric shock,do not perform any servicing other than that

contained in the operating instructions unless you are qualied to do so.

• Excessive sound pressure from earphones and headphones can cause hearing

loss. Adjustment of the equalizer to maximum increases the earphone and

headphone output voltage and the sound pressure level. Therefore, to protect

your hearing, adjust the equalizer to an appropriate level.

• FCC/CSA regulations state that any unauthorized changes or modications to this
equipment may void the user’s authority to operate it.

• To prevent electric shock, match the wide blade of plug to the wide slot, and fully
insert the plug.

• To prevent damage which may result in re or electric shock hazard, do not
expose this appliance to rain or moisture.

• The Socket-outlet should be installed near the apparatus and be easily
accessible.

iv

Safety Instructions

NOTE:

This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.

v

Contents

1. Unpacking and Installation ..................................................................................1

1.1. Unpacking ................................................................................................1

1.2. Package Contents ....................................................................................1

1.3. Installation Notes......................................................................................2

1.4. Mounting on a Wall ..................................................................................2

2. Parts and Functions ............................................................................................4

2.1. Control Panel ...........................................................................................4

2.2. Input/Output Terminals .............................................................................5

2.3. Remote Control ........................................................................................6

3. Connecting External Equipment ..........................................................................8

3.1. Connecting External Equipment (DVD/VCR/VCD) ..................................8

3.2. Connecting a PC ......................................................................................8

3.3. Connect USB ...........................................................................................9

4. Operation ...........................................................................................................10

4.1. Media Player Introduction ......................................................................10

4.2. PDF Reader Play ...................................................................................12

4.3. U player Autoplay Instructions................................................................14

4.4. U Disk Files Playback and Copy Instructions.........................................15

4.5. App Customization .................................................................................15

5. OSD Menu .........................................................................................................16

5.1. Navigating the OSD Menu .....................................................................16

5.2. Operation on the OSD Menu..................................................................17

6. Compatibility of the USB Device .......................................................................22

7. Input Mode ........................................................................................................25

8. Cleaning and Troubleshooting ...........................................................................27

8.1. Cleaning .................................................................................................27

8.2. Troubleshooting .....................................................................................28

9. Technical Specications ....................................................................................30

vi

Unpacking and Installation

and AAA Batteries

This manual is for reference only, please refer to the actual machine.

1. Unpacking and Installation

1.1. Unpacking

• This product is packed in a carton, together with the standard accessories.

• Any other optional accessories will be packed separately.

• Move the display by at least two (2) adults.

• After opening the carton, ensure that the contents are complete and in good
condition.

1.2. Package Contents

Please verify that you received the following items with your package content:

• LCD Display

• User Manual

FUNCTION

• Remote Control
with AAA
Batteries

• Power Cord

• HDMI Cable

* The supplied power cord varies
depending on destination.

User Manual

FORMAT

SET

SOURCE

OK

INFO

OPTION

CH

VOL

RETURN

HELP

Remote Control

Power Cord

HDMI Cable

* Items may differ in different locations

* Display design and accessories may differ from the images
shown.

NOTES:

• For all other regions, apply a power cord that conforms to the AC voltage of the
power socket and has been approved by and complies with the safety regulations
of the particular country.

• Keep the packaging materials appropriately after unpacking the product.

1

Unpacking and Installation

Protective Sheet

VESA Grid

Table

1.3. Installation Notes

• Only use the power cable provided with this product. If an extension cord is
required, please consult your service agent.

• The product should be installed on a at surface, or the product may tip over.
Leave a space between the rear of the product and the wall for proper ventilation.
Do not install the product in a kitchen, bathroom or a place exposed to moisture,
failure to do so may shorten the life of the internal parts.

• Do not install the product where it is 3000m or higher in altitude. Failure to do so
may result in malfunctions.

1.4. Mounting on a Wall

To mount this monitor onto a wall, you will have to obtain a standard wall-mounting kit
(commercially available). We recommend using a mounting interface that complies
with TUV-GS and/or UL1678 standard in North America.

1. Lay a protective sheet on a table, which was wrapped around the monitor when it
was packaged, beneath the screen surface so as not to scratch the screen face.

2. Ensure you have all accessories for mounting this monitor (wall mount, ceiling
mount, table stand, etc).

3. Follow the instructions that come with the base mounting kit. Failure to follow
correct mounting procedures could result in damage to the equipment or injury to
the user or installer. Product warranty does not cover damage caused by improper
installation.

4. For the wall-mounting kit, use M6 mounting screws (having a length 10 mm longer
than the thickness of the mounting bracket) and tighten them securely.

2

Unpacking and Installation

To prevent the monitor from falling:

• For wall or ceiling installation, we recommend installing the monitor with metal
brackets which are commercially available. For detailed installation instructions,
refer to the guide received with the respective bracket.

• To lessen the probability of injury and damage resulting from fall of the monitor
in case of earthquake or other natural disasters, be sure to consult the bracket
manufacturer for installation location.

Ventilation Requirements for enclosure locating

To allow heat to disperse, leave space between surrounding objects as shown in the
diagram below.

100 mm

100 mm 100 mm

100 mm

3

Parts and Functions

MUTE INPUT

MENU

2. Parts and Functions

2.1. Control Panel

9

1

2 3

4 5 6 7 8

NOTE:

The appearance and color of the product are subject to the material object. The
picture is for reference only.

1

[ ] button

Turn the display on or put the display
to standby.

2

[MUTE] button

Mute or reactivate the audio.

3

[INPUT] button

• Select an input source when

OSD menu is off.

4

[ ] button

• Increase the volume of the audio

when OSD menu is off.

• Move to the right item or Increase

the adjustment while OSD menu
is on.

5

[ ] button

• Decrease the volume of the

audio when OSD menu is off.

6

[ ] button

Move the highlight bar up to adjust
the selected item while OSD menu is
on.

7

[ ] button

Move the highlight bar down to
adjust the selected item while OSD
menu is on.

8

[MENU] button

Enter next submenu when OSD
menu is on, or to activate the OSD
menu when OSD menu is off.

9

Remote control sensor and power
status indicator

• Receive command signals from
the remote control.

• Indicate the operating status of
the display.

• Move to the left item or decrease
the adjustment while OSD menu
is on.

4

Parts and Functions

USB 2.0

5.0V 500mA

USB 3.0

5.0V 900mA

RS232

MICRO SD

2.2. Input/Output Terminals

12

11

10

9

1 2

AUDIO OUT

AUDIO IN

3 4 5 6 7 8

LAN

D-SUB

HDMI 2

HDMI 1

NOTE:

The appearance and color of the product are subject to the material object. The
picture is for reference only.

1

AC IN

AC power input from the wall outlet.

2

MAIN POWER SWITCH

Switch the main power on/off.

3

AUDIO IN

Audio input for VGA source (3.5mm
stereo phone).

4

AUDIO OUT

10

USB PORT

Connect to a USB storage device.

11

MICRO SD

Connect your MICRO SD CARD

12

OPS SLOT

Slot for installing the optional OPS
module.

Audio output for external AV device.

5

LAN

Internet function.

6

D-SUB (VGA IN)

VGA video input.

7

HDMI2 IN / 8 HDMI1 IN

Connect to a source device via an
HDMI cable.

9

RS232

Receive command signals from the
external RS232 device.

5

Parts and Functions

2.3. Remote Control

2.3.1. General Functions

1

2

3
4
6

9

FORMAT

SOURCE

10 11

12

13
14

INFO

16

17

VOL

18

20

21

1

[ ] POWER button

RETURN

Turn the display on or put the display
to standby.

Long press POWER button until
power is off.

2

[PLAY] buttons

Control playback of media les.

3

[USB] button

Go to

USB source

4

[CMS] button

Go to

CMS app

5

[ ] Time button

FUNCTION

SET

OK

OPTION

CH

HELP

.

.

15

19

22

Go to Time Setup OSD.

6

[ ] FORMAT button

Reserved.

7

[ ] HOME button

Go to Android Launcher rst widgets.

8

FUNCTION button

Reserved.

5

8

7

9

COLOR buttons

Reserved.

10

[ ] Source Button

Choose input source.

11

[ ] Settings Button

Access the OSD menu.

12

[ ] [ ] [ ] [ ]NAVIGATION buttons

Up, down, left and right operation
key.

13

[OK] button

Conrm an entry or selection.

14

[ ] INFO button

Show Information OSD.

15

[ ] OPTIONS button

Access currently available options,
for Media Input/PDF Player.

16

[ ] [ ] VOLUME button

Adjust volume level.

17

[ ] BACK button

Return to the previous page or exit
from the previous function.

18

[ ] MUTE button

Mute or restore volume.

19

[ ] [ ] Channel button

Reserved.

20

[Number] button

Input gures or text.

21

[RETURN] button

Reserved.

22

[HELP] Button

Reserved.

6

Parts and Functions

2.3.2. Inserting the Batteries in the Remote Control

The remote control is powered by two 1.5V AAA batteries.

To install or replace the batteries:

1. Press and then slide the cover to
open it.

2. Insert the batteries with the correct
polarity (+) and (–).

3. Replace the cover.

CAUTION:

Incorrect use of batteries may cause leakage or explosion. Be sure to follow the
instructions below:

• Insert “AAA” batteries with the correct polarity (+ and -).

• Do not mix battery types.

• Do not use a new battery with a used one together. Otherwise, it may cause
leakage or shorten the life of the batteries.

• Remove the dead batteries immediately to avoid battery leakage in the battery
compartment. Do not touch exposed battery acid, as it may cause injury to your
skin.

NOTE:

Remove the batteries from the battery compartment when not using for an extended
period of time.

2.3.3. Handling the Remote Control

• Do not drop or apply shock to the remote control.

• Do not allow any liquid to get inside the remote control. If water has entered the
remote control, wipe the remote control with a dry cloth immediately.

• Do not place the remote control near heat and steam sources.

• Do not attempt to disassemble the remote control, unless you need to place
batteries in the remote control.

2.3.4. Operating Range of the Remote Control

Point the top front of the remote control to the
remote sensor on the display when you press
the buttons.

NOTE:

The remote control may not function properly
when the remote control sensor on the display
is under direct sunlight or strong illumination,
or when there is an object between the remote
control and the remote sensor of the display.

7

Connecting External Equipment

RS232

RS232

RS232

HDMI 1HDMI 2

LAN

RS232

HDMI 1HDMI 2

D-SUB

AUDIO

OUT

3. Connecting External Equipment

3.1. Connecting External Equipment (DVD/VCR/VCD)

3.1.1. Using HDMI Video Input

HDMI 1HDMI 2

DVD / VCR / VCD

HDMI OUT

HDMI IN

3.2. Connecting a PC

3.2.1. Using HDMI Input

PC

HDMI 1HDMI 2

HDMI OUT

3.2.2. Using VGA Input

AUDIO

IN

VGA AUDIO IN

D-SUB

HDMI IN

VGA IN

VGA OUT

8

PC

AUDIO OUT

Connecting External Equipment

HDMI 2

LAN

RS232

HDMI 1HDMI 2

D-SUB

3.2.3. Display Control Connection

RS232

PC

RS232

3.2.4. Using Network Interface

or

WiFi

INTERNET

3.2.5. Connecting an External Audio Device

AUDIO

OUT

AUDIO OUT

RS232

LAN

LAN

3.3. Connect USB

USB 2.0

5.0V 500mA

USB 3.0

5.0V 900mA

9

Operation

4. Operation

4.1. Media Player

Introduction

1. The front page of the media player,
this page contains three items:
“Play”, “Compose” and “Settings”.
Play: choose to play the playlist.
Compose: edit playlist.
Settings: set the playback content.

2. Select the “Play” on the home page,

and you should rst select a playlist

to play between File 1 and File 7.
The pencil icon represents the play
list is non-empty.

4. If you select the empty playlist, the
application will guide you to choose
media sources.

All media les should be located in

the root directory. For example:

- Video at /root/movies/

- Photos /root/pictures/

- Music /root/music/

5. You can edit or delete non-empty
playlists, just select the required
playlist with pencil icons.

3. Select the “Compose” on the home

page, and you should rst select a

playlist to edit between File 1 and
File 7.
The pencil icon represents the play
list is non-empty.

6. You could rename the playlist, just
input new name after pressing the
“OPTIONS” key on the remote
control.

10

Operation

7. After you start editing the playlist,
you will see the following screen.

Source - storage device les.
Playlist - playlist le.

There are 4 icons which map to the
keys of remote controller.
Option key - start rolling.
Play key - play media les.
Info key - media information display.
OK key - select / deselect les.

7-1 in a scroll bar can help you to
perform the following items：

- Select all: Select all the storage
les.

- Delete all: Delete all the playlist
les.

- Add/Remove: Update from the
playlist.

- Sort: Sort playlists.

- Save/Abort: save or abort the
playlist.

- Back: return.

10. In choosing the desired le and
pressing the play button, you can

directly play media les.

11. If you make a playlist containing all

of the image les, the application

will ask you if you want to play
background music while playing the
video.

8. If you are in a scroll bar and select
“Sort”, you can change the order of

les one by one.

9. In choosing the desired le
information and press button, you
can get detailed information.

12. On the rst page of “Settings”, this
page contains three parts:
“Repeat Mode”, “Slideshow Effect”
and “Effect Duration”.
Repeat Mode: playback mode.
Slideshow Effect: photo slide effect.
Effect Duration: photo duration
effect.

11

Operation

4.2. PDF Reader Play

1. Home page of PDF app, this page
has three items: “Play”, “Compose”
and “Settings”.

Play: select playlist to play.

Compose: edit playlist.

Settings: set play properties.

2. Select “Play” on home page, rst you
should choose one playlist to play
between File 1 and File 7.
The pencil icon means the playlist is
non-empty.

4. If an empty playlist is chosen, the
app will guide you to select the
media source.

All media les should be placed in

root directory.
For example,

- pdfs in/root/pdf/

5. You could edit or delete a non-empty
playlist, just choose the desired
playlist which is with pencil icon.

3. Select “Compose” on home page,

rst you should choose one playlist

to edit from File 1 and File 7.
The pencil icon means the playlist is
non-empty.

6. You could rename the playlist, just
input new name after pressing the
“OPTIONS” key on the remote
control.

12

Operation

7. Once you start to edit a playlist, you
will see below screen.

Source - les in storage.

Playlist – les in playlist.

There are 4 icons which map to the
keys of remote controller.
Option key – launch slide bar.

Play key – play media le.

Info key – show media info.

OK key – select/unselect le.

7-1. In the slide bar, it helps you to
do the followings:

- Select all: select all storage les.

- Delete all: delete all playlist les.

- Add/Remove: update playlist from
source.

- Sort: sort playlist.

- Save/Abort: save or abort the
playlist.

- Back: return.

9. Select “Settings” on home page, this
page has two parts, “Repeat Mode”
and “Effect Duration”.

Repeat Mode: play mode.

Effect Duration: photo effect duration.

8. If you choose “Sort” in the slidebar,

you can change the order of les one

by one.

13

Operation

USB LESLIE

MsComm32控件
7个

SuperU
1个

4.3. U player Autoplay Instructions

1. U disk, the format must be FAT32,

and only one partition can not be
partitioned, the capacity can not
exceed 32G.

2. Create a SuperU folder in the root

directory of the U disk, and place the
video or image you want to play in
this folder.

3. Connect your USB device to the

USB port on the display.

4. Press the remote control [ ] setting

button to enter the OSD menu

5. Press [ ] right button to select

advanced options.

.

7. Press [ / ] left/right button to
switch on or off.

8. Repeat time, to set how long to play
a picture, it does not affect video
playback. The video playback will
play the next program after the end
of previous program.

9. When completed the above settings,
the U disk will start playing the
content automatically after re­plugged or re-booted.

6. Press [ ] down button to select
UPlayer setting, press [OK] to enter

UPlayer setting.

14

Operation

4.4. U Disk Files Playback

and Copy Instructions

1. U disk, the format must be FAT32,
and only one partition can not be
partitioned, the capacity can not
exceed 32G.

2. Connect your USB device to the
USB port on the display.

3. Select the USB ash drive icon and
click OK to enter the le browser.

4. Press [ / ] up/down button to select
video or picture you want to play.

5. Click the [OK] button to open directly.
Press [ ] OPTIONS button to pop
up the option menu.

6. Users can choose to play, copy or
move, etc., for example, if you want

to copy a le to the internal storage

Movies folder, select copy and it will
pop up "Destination".

7. After selecting the directory to copy
to, press the [ / ] left / right
buttons on the remote control to
select Paste or Cancel, as shown
below.

8. Press the [OK] button to complete

the le copy.

4.5. App Customization

The user can set the client-source
application programs.

NOTES:

1. Display the app installed by users
only.

2. Do not display the app pre-installed
by the system.

15

OSD Menu

VOL

CH

SET

5. OSD Menu

An overview of the On-Screen Display
(OSD) structure is shown below. You
can use it as a reference for further
adjustment of your display.

5.1. Navigating the OSD Menu

5.1.1. Navigating the OSD Menu
Using the Remote Control

SOURCE

O K

INFO

1. Press [ ] button on the remote

control to display the OSD menu.

OPTION

5. Press [ ] button to return to the
previous menu.

5.1.2. Navigating the OSD

Menu Using the Display’s
Control Buttons

1. Press [

2. Press [ ] or [ ] button to select the

3. Press [

4. In the submenu, press [ ] or [

5. Press [

MENU

] button to display the

OSD menu.

item to adjust.

MENU

] button to enter the

submenu.

] button to toggle between items,
press [ ] or [ ].
button to adjust settings. If there is
a submenu, press [

MENU

] button to

enter the submenu.

INPUT

] button to return to the

previous menu.

2. Press [ ] or [ ] button to select the
item to adjust.

3. Press [OK] button to enter the
submenu.

4. In the submenu, press [ ] or [ ] button
to toggle between items, press [
] or [ ] button to adjust the settings.
If there is a submenu, press [OK]

button to enter the submenu.

16

OSD Menu

5.2. Operation on the OSD Menu

Column 1 Column 2 Column 1, 3

Mode

Mode

Black Level [ 0 … 100 ]
Brightness [ 0 … 100 ]
Contrast [ 0 … 100 ]
Dynamic

Brightness


Advanced

Screen
Orientation

VGA

Eyes Protect
Mode

Color temp

Over scan On/Off

RGB Range

PC Mode PC/Video/Auto

0,90,180,270

Column 2, 3 or
Column 2, 2

Airport and train
station

Hotel and
convenient store

Dining and clothing
Security control

and monitoring

Ofce

Outdoor

Customize

On/Off

Auto Adjust
Horizontal [0…100]
Vertical [0…100]
Clock [0…100]
Phase [0…100]

On/Off

Standard
Cool
Warm

Auto
Full Range
Limited Range

Remarks

Available only in the
HDMI1/2

Available when PC
mode = Video.

You can use this
function to change
the PC timing or video
timing.

Source

17

OSD Menu

Sound

Lock

Sound
Mode

Audio
Source

Advanced

Key Lock

Change
Password

Standard
News
Music

Movie

HDMI
Line in
Balance [-50 … +50]
Volume [0 … 100]

Off

Type Password

Current Password

New Password

Conrm Password

Cancel/OK

Audio cannot be set
through restoring
settings.

You can reset audio
by Restore Default.

Available only in the
HDMI Source

Default password:
0000

Switch Key Lock On:

Step 1: Lock the
remote control, button
and mouse operation
functions after 5s if
there is no operation.

Step 2: After the
functions are locked,
press the “Set”
button on the remote
control for 5 seconds,
and then enter the
correct password in
the password dialog
box to unlock the
functions.

Step 3: Repeat step
1 after operation.
Or press the “Set”
button on the remote
control to turn off lock
function thoroughly.

18

OSD Menu

Time

Time
Setup

Time Setting Date Picker

Shutdown Time

Power Time

Sleep Time

Auto Sleep

Time Sync Network Time/Off

Time Zone

Repeat

Time Set the time.

Repeat

Time Set the time.

Source

File Number
[1 … 7]

Off/10min/20min/3
0min/60min/90min/
120min/180min/24
0min

Off/5S/10S/30S
/60S

London/Calcutta/
Harare/Karachi/

Brazzaville/

Beirut/Jerusalem/
Tehran/Baghdad/
Ulaanbaatar/
Damascus/Sydney/
Paris/Rome/
London/Dubai/
Tokyo

Set Year/Month/Date
Time: Minute

OFF/Once/Everyday/
Workday

OFF/Once/Everyday/
Workday

VGA/HDMI1/
HDMI2/OPS/home/
PDF/Media/CMS/
Customer/Last
Source

It depends on the
source(=MEDIA/
PDF).

19

OSD Menu

Advanced

Language

HDMI
Version

Power On
Mode

Boot On
Source

Boot Wake

RS322
Control

Pixel Shift On/Off

English

中文（中国）

HDMI1.4

HDMI2.0

Power On

Standby

Last Status

Switch On/Off

Boot On Source

Play List Play list [1 … 7]

UART Wake On/Off

HDMI/VGA Wake On/Off

RS322 Control On/Off

RS322 Source RS232/OPS

HDMI1/HDMI2/
OPS/PDF/Media/
CMS/Customer/
Last Source/VGA/
USB

1. When SCHEDULE
is set with startup
time, but the startup
time has not arrived
yet, boot the device
according to the
signal source set in
the “Boot On Source”.

2. If the source is set
in USB, the booting
page is the “U disc
homepage”.

1.Play List is grayed

2.When the Boot On
Source is PDF or
Media Player, Play
List is available.

When UART wake =
On，RC off or power
saving can either be
waken up by UART
wake.

When HDMI Wake =
On, and the current
source is HDMI1/2,
power saving and the
current HDMI source
are waken up with
signals.

20

OSD Menu

1.When Uplayer
Setting switch on,
Boot On Source is
grayed, the setting is
unavailable.

2.Supported le

name：SuperU

3. To play content in
UPlayer, the system

Switch On/Off

Uplayer

Advanced

NOTES:

• To wake up PD in the HDMI source, you can set HDMI wakeup “On”.

• This product supports timed shutdown and timed startup functions. Refer to the
“Shutdown time/Startup time” in the upper table for details.

• Some options may vary for different signals, please subject to the actual machine.

Setting

Repeat Time 8S/16S/24S/32S

Restore Restore Default Cancel/OK System Reset

will cut the signal
source to USB, and
stay at the USB
source when plugging
and unplugging the

USB ash drive.

4. Pivot jump to
UPlayer when
booting, the priority
is higher than the

source specied by

the schedule boot.

Supported le type：

1. Photo: ".png", ".jpg"

2. Video: ".dat", ".vob",
".ts", ".mkv", ".mov",

".3gp", ".v", ".webm",

".wmv", ".asf", ".mp4",
".avi", ".mpg".

21

Compatibility of the USB device

6. Compatibility of the USB Device

Format of the USB multi-media coder-decoder

Video decoding

Video

Type

MPEG1/2 MPEG1/2

MPEG-4 MPEG4

H.263 H.263

coder-

decoder

Container Decoding Coding Channel Remarks

File

format:

VOB

File

format:

MKV,

MP4, 3GP

File

format:

3GP, MP4

V

V

V

Supported size in a

range from 48x48
pixels to 1920X1080
pixels

Max. frame rate:30fps

Max. bit rate: 80Mbps

Audio coder-decoder:
MP2, MP3

Supported picture

size in a range

From 48x48 pixels
1920x1080 pixels

Max. frame rate:30fps

Max. bit rate:

38.4Mbps

Audio coder-decoder:
MP2, MP3, AAC,

(1) MS MPEG4 v1/v2/
v3 is not supported.

(2) GMC (global
movement
compensation) is not
supported.

Supported picture

size: SQCIF(128x96),
QCIF(176x144),

CIF(352x288),
4CIF(704x576)

Max. frame rate:
30fps

Max. bit rate:

38.4Mbps

Audio coder-decoder:
MP3

(1) Not support
H.263+

22

H.264 H.264

VC-1 VC1

Audio decoding

Compatibility of the USB device

Supported picture

size: from 48x48

pixels to 1920x1080
pixels

File

format:

MKV,

MP4, 3GP

File

format:

MKV

V

V

Max. frame rate:30fps

Max. bit rate:

57.2Mbps

Audio coder-decoder:
MP2, MP3, AAC

(1) Not support
MBAFF

Supported picture

size: frame 48x48

pixels to 1920x1088
pixels

Max. frame rate:30fps

Max. bit rate: 45Mbps

Audio coder-decoder:
MP2, MP3, AAC,
WMA

Type

MPEG

audio

Windows

Media

Audio

AAC

audio

Audio coder-

decoder

MPEG1/2/

2.5 Audio

Layer1/2/3

WMA version
4,4.1, 7, 8, 9,

wmapro

MAIN, ADIF,

ATDS Header

AAC-LC and

AAC-HE

Container Decoding Coding Channel Remarks

Bit rate:

Decode:

MP1, MP2,

MP3

Decode:

WMA

File format:

AAC, M4A

V 2

V 2

V 5.1

23

8Kbps~320Kbps,
CBR and VBR
Sampling rate:

8KHz~48KHz

Bit rate:
8Kbps~320Kbps
Sampling rate:
8KHz~48KHz
Do not support
WMA Pro non­destructive and
MBR

Bit rate: N/A
Sampling rate:

8KHz~48KHz

Compatibility of the USB device

Picture decoding

Picture coder-

Type

JPEG

BMP BMP

GIF GIF

PNG PNG

NOTES:

• If the standard bite rate/frame rate of the contents is higher than the compatible
frames/second listed in the above table, audio or video may not work.

• Video contents with a bit rate or frame rate higher than the designated rate in the
above table may result in discontinuation of video during display.

decoder

JFIF le format

1.02

Picture Decoding Coding Channel Remarks

Decode:
Resolution
ratio 48X48 to
8176X8176

(1) Row-by-row

File format:
JPG, JPEG

File format:

BMP

File format:

GIF

File format:

PNG

V

V

V

V

scanning is not
supported.

(2) Software
supports SRGB
JPEG.

(3) Software
supports Adobe
RGB JPEG.

Supported max.

picture size:

4096x4096 pixels
No limit in

resolution ratio
No limit in

resolution ratio

24

Input mode

7. Input Mode

HDMI computer mode

Standard

Resolution

VGA 640 480

WVGA 720 400 70 Hz 28.32 MHz 4:3

SVGA 800 600 60 Hz 40 MHz 4:3

XGA 1024 768 60 Hz 65 MHz 4:3
WXGA 1152 870 75 Hz 100 MHz 4:3
WXGA 1280 720 60 Hz 74.5 MHz 5:3

SXGA 1280 1024 60 Hz 108 MHz 5:4
UXGA 1600 900 60 Hz 108 MHz 4:3
UXGA 1680 1050 60 Hz 146.25 MHz 16:10

HD1080 1920 1080 60 Hz 148.5 MHz 16:9

4K2K 3840 2160 60 Hz 594 MHz 16:9

Recommended resolution ratio: 3840x2160@60Hz

HDMI video mode

Standard

Resolution

3840 x 2160 P 60 Hz 3840 2160 60 Hz 594 MHz 16:9
3840 x 2160 P 30 Hz 3840 2160 30 Hz 297 MHz 16:9
3840 x 2160 P 25 Hz 3840 2160 25 Hz 297 MHz 16:9
3840 x 2160 P 24 Hz 3840 2160 24 Hz 297 MHz 16:9

1080 P 59.94/60 Hz 1920 1080 60 Hz 148.5 MHz 16:9

1080 P 50 Hz 1920 1080 50 Hz 148.5 MHz 16:9

1080 P 29.97/30 Hz 1920 1080 30 Hz 74.25 MHz 16:9

1080 P 25 Hz 1920 1080 25 Hz 74.25 MHz 16:9

1080 P 23.97/24 Hz 1920 1080 24 Hz 74.25 MHz 16:9

1080 I 59.94/60 Hz 1920 1080 60 Hz 74.25 MHz 16:9

1080 I 50 Hz 16:9 1920 1080 50 Hz 74.25 MHz 16:9

720 P 50 Hz 16:9 1280 720 50 Hz 74.25 MHz 16:9

720 P 59.94/60 Hz 1280 720 60 Hz 74.25 MHz 16:9

576 I 50 Hz 4:3 720 576 50 Hz 13.5 MHz 4:3

576 I 50 Hz 16:9 720 576 50 Hz 13.5 MHz 16:9

480 I 59.94/60 Hz 720 480 60 Hz 13.5 MHz 4:3

576 P 50 Hz 4:3 720 576 50 Hz 27 MHz 4:3

576 P 50 Hz 16:9 720 576 50 Hz 27 MHz 16:9
480 P 59.94/60 Hz 720 480 60 Hz 27 MHz 16:9
480 P 59.94/60 Hz 720 480 60 Hz 27 MHz 4:3

Active Resolution

H Pixel V Lines

Active Resolution

H Pixel V Lines

Refresh

Rate

60 Hz 25.175 MHz
75 Hz 31.5 MHz

Refresh

Rate

Pixel Rate

Pixel Rate

Aspect

Ratio

4:3

Aspect

Ratio

25

PC mode

Input mode

Standard

Resolution

VGA 640 480

WVGA 720 400 70 Hz 28.32 MHz 4:3

SVGA 800 600 60 Hz 40 MHz 4:3

XGA 1024 768 60 Hz 65 MHz 4:3
WXGA 1152 870 75 Hz 100 MHz 4:3
WXGA 1280 720 60 Hz 74.5 MHz 5:3

SXGA 1280 1024 60 Hz 108 MHz 5:4
UXGA 1600 900 60 Hz 108 MHz 4:3
UXGA 1680 1050 60 Hz 146.25 MHz 16:10

HD1080 1920 1080 60 Hz 148.5 MHz 16:9

WXGA 1366 768 60 Hz 85.75 MHz 16:9

Active Resolution

H Pixel V Lines

Refresh

Rate

60 Hz 25.175 MHz
75 Hz 31.5 MHz

Pixel Rate Aspect Ratio

4:3

26

Cleaning and Troubleshooting

8. Cleaning and Troubleshooting

8.1. Cleaning

Caution When Using the Display

• Do not bring your hands, face or objects close to the ventilation holes of the
display. The top of the display is usually very hot due to the high temperature
of exhaust air being released through the ventilation holes. Burns or personal
injuries may occur if any body parts are brought too close. Placing any object
near the top of the display could also result in heat related damage to the
object as well as the display itself.

• Be sure to disconnect all cables before moving the display. Moving the display

with its cables attached may damage the cables and thus cause re or electric

shock.

• Disconnect the power plug from the wall outlet as a safety precaution before
carrying out any type of cleaning or maintenance procedure.

Front Panel Cleaning Instructions

• The front of the display has been specially treated. Wipe the surface gently
using only a cleaning cloth or a soft, lint-free cloth.

• If the surface becomes dirty, soak a soft, lint-free cloth in a mild detergent
solution. Wring the cloth to remove excess liquid. Wipe the surface of the
display to remove dirt. Then use a dry cloth of the same type to dry.

• Do not scratch or hit the surface of the panel with ngers or hard objects of
any kind.

• Do not use volatile substances such as insert sprays, solvents and thinners.

Cabinet Cleaning Instructions

• If the cabinet becomes dirty, wipe the cabinet with a soft, dry cloth.

• If the cabinet is extremely dirty, soak a lint-free cloth in a mild detergent
solution. Wring the cloth to remove as much moisture as possible. Wipe the
cabinet. Use another dry cloth to wipe over until the surface is dry.

• Do not allow any water or detergent to come into contact with the surface
of the display. If water or moisture gets inside the unit, operating problems,

electrical and shock hazards may result.

• Do not scratch or hit the cabinet with ngers or hard objects of any kind.

• Do not use volatile substances such as insert sprays, solvents and thinners on
the cabinet.

• Do not place anything made from rubber or PVC near the cabinet for any
extended periods of time.

27

Cleaning and Troubleshooting

8.2. Troubleshooting

Symptom Possible Cause Remedy

No picture is displayed 1. The power cord is

disconnected.

2. The main power
switch on the back
of the display is not
switched on.

3. The selected input
has no connection.

4. The display is in
the standby mode.

Interference displayed
on the display or an
audible noise is heard

Color is abnormal The signal cable is not

Picture is distorted
with abnormal patterns

Caused by surrounding
electrical appliances or

uorescent lights.

connected properly.

1. The signal cable
is not connected
properly.

2. The input signal
is beyond the
capabilities of the
display.

1. Plug in the power cord.

2. Make sure that the power
switch is switched on.

3. Connect a signal connection to
the display.

Move the display to another
location to see if the interference is
reduced.

Make sure that the signal cable is

attached rmly to the back of the

display.

1. Make sure that the signal cable

is attached rmly.

2. Check the video signal source
to see if it is beyond the range
of the display. Please verify its

specications with this display’s
specication section.

Can hear sound, but
no picture

Can see picture but no
sound is heard

Source signal cable is
connected improperly.

1. Source signal
cable is connected
improperly.

2. Volume is turned
all the way down.

Mute

3. {

4. No external

} is turned

on.

speaker is
connected.

28

Make sure that both video inputs
and sound inputs are correctly
connected.

1. Make sure that both video
inputs and sound inputs are
connected correctly.

2. Press [ ] or [ ] button to hear
sound.

3. Switch MUTE off by using the
[ ] button.

4. Connect external speakers and
adjust the volume to a suitable
level.

Cleaning and Troubleshooting

Some picture
elements do not light
up

After-Images can
still be seen on the
display after the
display is powered
off. (Examples of
still pictures include
logos, video games,
computer images, and
images displayed in
4:3 normal mode)

Some pixels of the
display are off.

A still picture is
displayed for an over
extended period of
time.

This display is designed using an
extremely high level of precision
technology: however, sometimes
some pixels of the display may not
display. This is not a malfunction.

Do not allow a still image to be
displayed for an extended period
of time as this can cause a
permanent after-image to remain
on the display.

29

Technical Specications

9. Technical Specifications

Display:

Item Specications

Screen Size (Active Area) 64.5 inches

Aspect Ratio 16:9

Number of pixels 3840 (H) x 2160 (V)

Pixel pitch

Displayable colors

Brightness (Typ.) 400 cd/m2

Contrast ratio (Typ.) 1200:1

Viewing angle 178 degrees

General:

Item Specications

Internal memory 8GB eMMC

Power 100 - 240V~, 50 - 60Hz, 4A

Power Consumption (Max) 280 W

Power Consumption (Typ.) 170 W

Power Consumption (Standby & Off) <0.5 W

Dimensions (Without Stand) [W x H x D] 1459 x 835 x 82 mm

0.372 (H) x 0.372 (V) [mm]

1.07B (8bits+

FRC)

Environmental Condition:

Item Specications

Temperature

Humidity

Altitude

Internal Speaker:

Item Specications

Number of Speakers 2

Input 12 W X 2

Impedance 8 Ω

Frequency Response 160 Hz ~ 13 KHz

Operational 5 ~ 40°C

Storage -20 ~ 60°C

Operational 20 ~ 80% RH (No condensation)

Storage 10 ~ 90% RH (No condensation)

Operational 0 ~ 3,000 m

Storage/Shipment 0 ~ 9,000 m

30

2019 © All rights reserved.

Specications are subject to change without notice.

Q41G65M166101B
