Hisense 100L5G-DLT100B Quick Start Guide

Model 100L5G

120L5G

Quick Setup Guide

Before using the Laser Cinema, please read this guide carefully and keep it for future reference.

Disclaimer: This Quick Setup Guide is intended as a general guideline to help you set up your Laser Cinema. Images throughout this document are for illustrative purposes only
and may differ from the actual product.

© 2021 Hisense Company Ltd. All Rights Reserved.

All material in this Quick Setup Guide is the property of Hisense Company Ltd. and its subsidiaries, and is protected under US,
CANADA, MEXICO and International copyright and/or other intellectual property laws. Reproduction or transmission of the materials,
in whole or in part, in any manner, electronic, print, or otherwise, without the prior written consent of Hisense Company Ltd. is a
violation of Hisense Company Ltd. rights under the aforementioned laws.

No part of this publication may be stored, reproduced, transmitted or distributed, in whole or in part, in any manner, electronic or
otherwise, whether or not for a charge or other or no consideration, without the prior written permission of Hisense Company Ltd.

Requests for permission to store, reproduce, transmit or distribute materials may be made to one of the following addresses:
U.S.A. Hisense USA Corporation
7310 McGinnis Ferry Road
Suwanee, GA 30024

MEXICO
IMPORTER:

Hisense Mexico S. de R.L. de C.V.
Blvd. Miguel de Cervantes Saavedra No 301
Torre Norte Piso 2, Col. Ampliación Granada
Miguel Hidalgo, Ciudad de México, C.P. 11520
RFC: HME110512IY3
TEL: (52) (55) 5531-3515
CANADA Hisense Canada Co., Ltd
2283 Argentia Road, Unit 16
Mississauga, ON, Canada
L5N 5Z2
Hisense, and any and all other Hisense product names, logo’s, slogans or marks are registered trademarks of Hisense Company Ltd.
and its subsidiaries. All other trademarks are the property of their respective holders.

Congratulations on the purchase of your new Laser Cinema! This Quick Setup Guide will walk you through
a few easy steps to set up your Laser Cinema.

Table of Contents

Register Your Laser Cinema! 2

Important Safety Information 3

Packaged Contents 5

Laser Cinema Diagram 6

STEP 1. Mount the Screen 7

STEP 2. Set up the Laser Cinema 7

STEP 3. Adjust the Display Image and the Screen 10

STEP 4. Use Your Remote 14

STEP 5 Proceed through the Screen Setup Menu 16

Begin to Enjoy Your Laser Cinema 17

Maintenance & Quick Problem-Solving Tips 18

Product Specifications 21

Certification and Compliance 23

For detailed instructions, please refer to the E-Manual.

1

Register Your Laser Cinema!

Because we value your business, we want to keep you in the know of 'all things Hisense'. Using your mobile phone, scan the
Registration page QR code to register your Laser Cinema. Depending on the make and model of your phone, you may need to
download a QR code scanning app.

U.S. Mexico Canada

http://www.hisense-usa.com/support/
register

https://hisense.com.mx/support/register http://www.hisense- canada.com/

support/productReg.asp

2

Important Safety Information

SAFETY WARNINGS

Do not look directly at the lens when this device is on!

• This product comes with a laser module. Do not tear or modify this device in any manner; otherwise, it
may result in personal injury.

RG2

As with any bright light source, DO NOT STARE INTO THE BEAM IEC 62471-5: 2015

CLASS 1 LASER PRODUCT

λ = 455±6nm
Wavelength 455±6nm
CLASS 1 LASER PRODUCT IEC 60825-1: 2014

Caution—use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous
radiation exposure.
The Device Complies with 21 CFR 1040.10 and 1040.11 except for confromance as a Risk Group[0,1 or 2-Select appropriate RG]LIP as
defined in IEC 62471-5: Ed.1.0. For more information see Laser Notice No.57, dated May 8, 2019.

• If this device requires a repair, please wear laser eye protection with an optical density OD that is 4 or
higher and has a wave length of 445-465 nm.

• Do not place any water-containing vessel on this device, such as cosmetics or liquid medicine.

• If any object or water enters this device, please unplug this device and contact the service staff of Hisense.

• Do not place any exposed fire source (e.g. burning candle) on this device. Keep away from high temperature and heat.

• Do not expose the battery to direct sunlight or candle light.

• Keep air vents on both sides clear from any objects to prevent the device from overheating inside.

• To avoid a short circuit, product damage or electric shock, do not use any sharp object or metal to touch the ports or other

openings on the Laser Cinema.

3

• If this device has been in a warm environment, allow any built-up condensation to evaporate first BEFORE you switch the device
on.

• Do not allow a child to stand on or climb up this device.

• Do NOT place any object above or in front of the lens because the laser light could cause the object to become flammable.

• Clean the lens periodically with a clean cloth and make sure the Laser Cinema is turned off before you start.

Low Blue light Content

• The long-term exposure to blue light may damage your eyes, in particular the retina, causing visual fatigue or eye strain. Children
are particularly vulnerable to excessive blue light and the damage to them is irreversible. The product can decrease blue light ratio
to reduce blue light hazard.

Health recommendations

• Avoid long time continuous use product, ensure adequate break time.

• Looking at distant objects or exercises for the eye after use product.

4

Packaged Contents

• Laser Cinema

• 1 Remote control

• 2 AAA batteries

• 2 pairs of gloves for handling the Laser Cinema

• 1 Power Cord

• 1 Wrench to adjust the bottom of the Laser Cinema

• 1 Audio Out Cable

ADDITIONAL ITEMS THAT COME WITH THE LASER CINEMA IN A SEPARATE PACKAGE

• A Display Screen (optional equipment)*

• A set of Wall Mount Brackets (optional equipment)*

Additional items you receive will be based upon your order.

*

• Hisense 4K Laser Cinema Quick Setup Guide

• Important Safety Information & Warranty Card

• Cleaning kit for the lens

• 2 C-shaped blocks

• C-shaped Block Installing Instruction

• 1 USB extension cable

5

Laser Cinema Diagram

Power
Indicator

Remote control receiver

Eye
protection
sensor

Air vents

Power buttonLens with laser

We strongly recommend that two people handle this device when moving it from one place to another. Be
sure to protect the lens when you handle this device.

6

STEP 1 Mount the Screen

If you purchased a screen from Hisense to include with your Laser Cinema, then refer to the Screen
Installation Guide that’s included in the package.

STEP 2 Set up the Laser Cinema

To begin setting up the Laser Cinema, we strongly recommend that TWO people move it from one place
to another because of the weight. Be sure to protect the lens when you handle this device.

1. Now, to get started, we recommend that you connect all cables to the
ports on the back of the Laser Cinema before you position it. (Audio,
video, Ethernet cables and external devices are not included.)

2. Position the Laser Cinema so it is parallel with the screen surface.
We recommend the distance from the back panel of the Laser
Cinema to the wall to be 8 1/8 inches.

3. Plug the power cord into a wall outlet.

4. Press the POWER button to turn on the Laser Cinema.

Power Cord

Wall Outlet

7

WARNING: Insufficient ventilation space will cause this
device to overheat or become damaged.

• Do not block the air vents or place any object on this device.

• Do not place this device in any narrow, enclosed or poorly

ventilated space.

Laser beam

At a minimum, leave the amount of space shown in the diagram
below for this device to have proper ventilation.

2 in

8 in8 in

Ports to connect certain cables to

Coaxial

USB devices for browsing photos, music and movies. This unit only recognizes USB
Memory Sticks.

NOTE:

Use the USB extension cable (included) for easier connection and
disconnection.

When connecting a hard disk or a USB hub, always connect the mains
adapter of the connected device to the power supply. Exceeding a total
current consumption may result in damage. The USB2.0 device maximum
current consumption is 500mA. The USB3.0 device maximum current
consumption is 1A.

If the impulse current for an individual non-standard high-capacity mobile
hard disk is greater than or equal to 1A, it may cause the Laser Cinema to
reboot or lock.

The USB port supports a voltage of 5V.

Ethernet (you will need a router for Internet connectivity)

Outdoor VHF/UHF antenna

VHF/UHF Antenna

Cable

ANT OUT

Check to ensure that you have selected the right cables for the ports and that they are connected securely. Loose connections can
affect the quality of the picture image and color.

8

External AV devices

It may be used to connect to
a home automation system or
Custom Integrated Audio/Video
(A/V) system. It is recommended
that it should only be completed
by a professional installer.

HDMI

4

audio adapter

Digital audio adapter

White

Red

VCR

Set-top Box

Satellite Receiver

External audio devices

Speakers

Audio Amplier

DVD Player

Video Camera

9

STEP 3 Adjust the Display Image and the Screen

Follow the steps in the order shown below, only if they apply to your situation.
Note: Before adjusting, fold the wall-mount bracket wands so that screen is vertically level. Rotate feet from an overlooking view, but
do not look directly at the lens when this device is on because the laser light may damage your eyes.

PARALLEL THE BOTTOM OF THE IMAGE WITH THE SCREEN

If the bottom of the image is lower on the left and higher on the
right, rotate the device counterclockwise.

If the bottom of the image is lower on the right and higher on
the left, rotate the device clockwise.

FIT THE BOTTOM OF THE IMAGE TO THE SCREEN

• If the image shifts to the left side, then move the Laser
Cinema to the right.

If the image shifts to the right side, then move the Laser
Cinema to the left.

10

• If the bottom of the image is wider than the screen, then
move the Laser Cinema closer to the screen.

If the bottom of the image is narrower than the screen, then
move the Laser Cinema farther from the screen.

NOTE: Make sure the bottom of the image always stays parallel
with the screen. If not, rotate the Laser Cinema following
previous instructions.

ADJUST THE UPPER-RIGHT CORNER OF THE IMAGE

1. If the top of the image is lower on the left and higher on the
right, then use the wrench to rotate the front-right foot and
the back-right foot clockwise to the same height.

back-right foot

front-right foot

2. Now, rotate the Laser Cinema counterclockwise so that the
bottom of the image is parallel with the screen.

3. Repeat the steps above until the top of the image is parallel
with the screen.

11

4. If the upper-right corner is inside the screen after adjusting,
use the wrench to rotate the front-right foot and the back­right foot counterclockwise to the same height, and rotate
the Laser Cinema clockwise, to make the image parallel with
the screen.

ADJUST THE UPPER-LEFT CORNER OF THE IMAGE

1. If the top of the image is higher on the left and lower on the
right, then use the wrench to rotate the front-left foot and
the back-left foot of the Laser Cinema clockwise to the same
height.

back-left foot

front-left foot

2. Now, rotate the Laser Cinema clockwise so that the bottom of
the image is parallel with the screen.

3. Repeat the steps above until the top of the image is parallel
with the screen.

4. If the upper-left corner is inside the screen after adjusting, use
the wrench to rotate the front-left foot and the back-left foot
counterclockwise to the same height, and rotate the Laser
Cinema counterclockwise, to make the image is parallel with
the screen.

12

FILL THE TOP OF THE IMAGE TO THE SCREEN

If the top of the imge is wider than the screen, then use the
wrench to rotate the left- and right-front feet of the Laser
Cinema clockwise.

If the top of the image is narrower than the screen, then use
the wrench to rotate the left- and right-back feet of the Laser
Cinema clockwise, until the left and right borders of the image
are parallel with the screen borders.
Next, move the projector further from the screen to fill the image
to screen width.
If the back feet are already at their maximum height, rotate the
left- and right-front feet of the Laser Cinema counterclockwise.

Rotate the back feet clockwise Rotate the front feet

counterclockwise

Do not look directly at the lens when this device is on because the laser light may damage your eyes!

13

STEP 4 Use Your Remote

BUTTON DESCRIPTION

Power on/off

INPUT Change Laser Cinema input source

Enter Channels/input numbers and
special function buttons
Press to enter your customized

FAV

input source/app
Press and hold to enter
customization settings

OK Confirmation button

D-pad (up/down/left/right

˄ / ˅ / ˂ / ˃

navigation buttons)

Press to enter Menu
Press and hold to pair the bluetooth
remote

Return to the previous place in the
menu or app

BUTTON DESCRIPTION

Display the Home screen

VOL Volume (up/down)

CH

Channel (up/down)
Google Assistant of Laser Cinema

Press to Mute or restore sound
Press and hold to display
Accessibility menu

/

/

Media content control function
buttons

MEDIA Quick access to Media

Apps Quick access buttons to apps

NOTE: The button descriptions are only provided as a

reference. The actual appearance of your remote may
differ from the buttons that are listed.

14

1. Press and slide the back cover to open the battery
compartment of the remote control.

2. Insert two AAA size batteries. Make sure to match the
(+) and (-) ends of the batteries with the (+) and (-) ends
indicated in the battery compartment.

3. Restore the battery compartment.

IMPORTANT INFORMATION ABOUT THE REMOTE AND
BATTERIES

• Discard batteries in a designated disposal area. Do not throw
them into a fire.

• Remove old batteries immediately to prevent them from
leaking into the battery compartment.

• If you do not intend to use the remote control for a long time,
then remove the batteries.

• Battery chemicals can cause a rash. If the batteries leak,
clean the battery compartment with a cloth. If chemicals
touch your skin then wash it immediately.

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc) or rechargeable

(NiCd, NiMH, etc.) batteries.

• Do not continue using the remote if it gets warm or hot.

• Call our Support Center immediately on the support website.

REMOTE CONTROL RANGE INFORMATION

• The remote control can work at a distance of up to 26 feet in
front of the Laser Cinema.

• It can work at a 30 degree horizontal or 15 degree vertical
angle.( This angle is used by infrared means in an unpaired
state.)

PAIRING THE REMOTE CONTROL

1. Pair the remote to the Laser Cinema after you power it on. Keep

the remote control within 10 feet from the Laser Cinema. Press
and hold the [ ] button at least 3 seconds to start pairing.

2. If the remote paired successfully then a confirmation will

display on the screen. If it did not pair successfully then an
unsuccessful message will display. Repeat step 1.

NOTE:

• If an unknown error occurred with the remote then it could
have been caused by interference. Try to remove what's
causing the interference and pair it again.

• If an unknown error occurred in the remote control while the
battery power is normal, you can take out the batteries and
press any key for 1~2 seconds, then the remote control can
work normally.

• The remote cannot be paired to the Laser Cinema while the
Laser Cinema is in standby mode.

15

STEP 5 Proceed through the Screen
Setup Menu

PROJECTION MODE

If you need to flip the image over top-to-bottom and/or left­to-right, select the Projection Mode and press the UP/DOWN
buttons.

AUTO GEOMETRIC CORRECTION

Before you use Auto Geometric Correction function, ensure that
the Laser Cinema and your mobile device are connected to the
same Wi-Fi network.

1. Position the Laser Cinema and use the leveling feet as
needed to fit the entire display border within the screen area.

2. Click Next to continue.

3. Scan the QR Code with your mobile device to begin
automatic geometric correction. When the app loads, the
Laser Cinema will display an alignment grid.

Alignment grid

4. Click "+" on your mobile device to take a photo of the entire
screen and image. For best results, stand about 10 feet away
from the screen and use landscape mode.

5. Click "upload" on your mobile device to complete the
automatic geometric correction.

GEOMETRIC CORRECTION

1. Select a point for adjustment using the UP/DOWN/LEFT/
RIGHT buttons. Adjust eight main points at the corners and
midpoints .

Press

to adjust the selected

OK

point

2. Adjust the position of the point by pressing the UP/DOWN/
LEFT/RIGHT buttons, then press the Back button to view and
select other points. Your changes will apply automatically.

NOTE: To return the picture position to the factory default,
select the Reset button on the screen.

EYE PROTECTION

In order to protect your eyes, do not look into the lens. This
projector is shutting down in 5 seconds, the Laser Cinema
screen is closed immediately.

16

Begin to Enjoy Your Laser Cinema

Text-to-Speech(TTS) and Video Description
functionalities on Laser Cinema

Your Smart Laser Cinema is easy to use and brag­worthy!

After you've completed setting up the language, time and
network connection, the Home screen will be your starting point
for navigating the Laser Cinema. Gone are the days where your
Laser Cinema only provides one way for you to be entertained.
This showpiece provides you the convenience of watching
a program on a live channel, accessing Video on Demand to
watch a movie and many other entertainment options.

Using your remote, press the Home button to begin enjoying
your Laser Cinema.

Disclaimer: Subscriptions or other payments may be required to access content through some applications. Some or all of the included or downloaded application services in
this Hisense device may not function depending on the Internet connection, local limitations of included applications or other reasons outside of Hisense’s control. HISENSE
EXPRESSLY DISCLAIMS RESPONSIBILITY FOR ANY APPLICATION SERVICE FROM FUNCTIONING AT ANY TIME, FOR CONTENT IN ANY APPLICATION SERVICE, FOR
DISRUPTIONS OF SERVICE, LOCAL OR REGIONAL LIMITATIONS, WARRANTIES OF TITLE, NO INFRINGEMENT, AND FOR IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. By purchasing this device, you accept such Disclaimer without any claim on Hisense at any time.

Text-to-Speech (TTS) and Video Description can help you to
navigate the menus on the screen and hear an audio description
of relevant programs.
Text-to-Speech can convert written text into voice text to help
visually impaired people listen to the information they are unable
to read. In addition, the Video Description has an audio narration
added to certain programs that will describe the main visual
elements which visually impaired users may not be able to see.
Follow the steps below to enable the functions:

1. Press the Menu button on your remote.

2. Next, select Settings to enter the Settings Menu.

3. Select Device Preferences > Accessibility > TalkBack or Video
Description to turn TalkBack or Video Description on or off.
When TalkBack is turned on, then the contents of each menu
displayed can be broadcasted out.
When Video Description is turned on, then you can hear the
introduction of relevant programs.

Note: TalkBack is enabled by selecting the checkbox. Video

Description is enabled by selecting the Toggle button.

https://www.hisense-usa.com/text-to-speech-hisense-android-tvs-1

17

Maintenance

• Do not touch this device when it is running or just turned off because it may be hot.

• Do not wipe this device with oil because it may deteriorate the exterior or damage the paint. Contact with rubber or ethylene

products for a long time may cause stains on this device.

• If the outside of the Laser Cinema is dirty, turn off the Laser Cinema and wipe with a damped soft cloth.

• Do not touch the lens with your hands.

• Do not touch or wipe the lens with ordinary cleaning cloth. Use a dust blower to remove the dust on the lens. Grease, dirt and

fingerprints should be cleaned carefully by the professional by using optical cleaning cloth, lens wiping paper or professional
cleaning solutions to avoid destroying the optical filming and affecting the image quality.

• To turn off this device, press the Power button on the remote control. Do not cut off the power directly when the device is working.

Quick Problem-Solving Tips

When you experience an issue with your Laser Cinema, turn it off and on again. If this does not resolve the problem, then refer to the
tips below.

When I turn on my Laser Cinema, there is a delay for a few seconds before the picture appears. Is this normal?

Yes, this is normal. The Laser Cinema is initializing and searching for previous setting information.

No sound or picture

1. Check if the power cord is plugged into a powered AC outlet.

2. Press the Power button on the remote control to activate the unit from 'Standby' mode.

18

3. Check to see if the LED light is on or not. If it is, then the Laser Cinema is receiving power.

I have connected an external source to my Laser Cinema and I get no picture and/or sound.

1. Check for the correct output connection on the external source and for the correct input connection on the Laser Cinema.

2. Make sure you have made the correct selection for the input mode for the incoming signal.

The picture is normal but there is no sound

1. Check the volume settings.

2. Check if 'Mute' mode is set to On.

Sound but no picture or black and white picture

1. If the picture is black and white, unplug the Laser Cinema from the AC outlet and replug it after 60 seconds.

2. Check that the Color is set to 50 or higher.

3. Try dierent Laser Cinema channels.

The sound and/or picture is distorted or appears wavy

1. An electric appliance may be aecting the Laser Cinema. Turn o any appliances that are nearby and move it farther away from
the Laser Cinema.

2. Insert the power plug of the Laser Cinema set into another power outlet.

The sound and picture is blurry or cuts out

1. If using an external antenna, check the direction, position and connection of the antenna.

2. Adjust the direction of your antenna or reset or fine tune the channel.

The plastic cabinet makes a "clicking" type of sound

The 'click' sound can occur when the temperature of the Laser Cinema changes. This change causes the Laser Cinema cabinet to
expand or contract, which makes the sound. This is normal and the Laser Cinema is OK.

19

The remote control does not work

1. Confirm that Laser Cinema still has power and is operational.

2. Change the batteries in the remote control.

3. Check if the batteries are correctly installed.

NEED MORE HELP?

Additional help is available online at support links. You will find answers to frequently asked questions, downloadable firmware and
more. If the problem is still not resolved, then contact us at one of the phone numbers below.

U.S.A.

http://www.hisense-usa.com/support/

Phone: [phone]
Monday - Friday 9 AM to 9 PM EST
Saturday - Sunday 9 AM to 6 PM EST

Email: [e-mail]

MEXICO

http://www.hisense.com.mx/support/

Phone: [phone]
Monday - Friday: 9:00-21:00 hrs
Saturday: 9:00-15:00 hrs
Email: [e-mail]

20

CANADA

http://www.hisense-canada.com/
support/

Phone: [phone]
Monday - Friday 8 AM to 8 PM EST

Email: [e-mail]

Product Specifications

MODEL NAME 100L5G 120L5G

DIMENSION (W × H × D) 21.5 × 6.2 × 13.6 inches

(547 × 158 × 346 mm)

WEIGHT 24.3 lbs (11.0 kg)

ACTIVE SCREEN SIZE (DIAGONAL) 100 inches 120 inches

SCREEN RESOLUTION 3840 × 2160

AUDIO POWER 2 × 15 W

POWER CONSUMPTION 320W

POWER SUPPLY 120 V ~60 Hz

CONNECTIVITY Built-in Wireless feature (2x2 dual band)

PORTS 3 HDMI ports, 2 USB ports, 1 LAN port for Ethernet, 1 Digital Audio Output, 1 RF Input,

1 Audio Output, 1 SERIAL port

ENVIRONMENTAL CONDITIONS Temperature: 41°F to 95°F (5°C to 35°C)

Humidity: 20% to 80% RH
Atmospheric pressure: 86 kPa to 106 kPa

STORAGE TEMPERATURE 5°F to 113°F (-15°C to 45°C)

STORAGE HUMIDITY 10% to 70%, non-condensing

21

RECEIVING CHANNELS VHF: 2 - 13, UHF: 14 - 69, CATV: 1 - 125

Digital Terrestrial Broadcast (8VSB): 2 - 69
Digital cable (64/256 QAM): 1 - 135

TUNER TYPE Frequency synthesized

RECEIVING SYSTEM Analog: NTSC

Digital: ATSC/QAM

Disclaimer: All products, product specifications, and data are subject to change without notice to improve reliability, function, design or otherwise.

22

Certification and Compliance

FCC Notice

This device has been tested and found to comply with the limits
for a Class B digital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
device generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this device does cause harmful
interference to radio or Laser Cinema reception, which can
be determined by turning the device off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the device and receiver.

• Connect the device into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/Laser Cinema
technician for help.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO

OR LASER CINEMA INTERFERENCE CAUSED BY UNAUTHORIZED

MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD

VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

The Wi-Fi Module complies with FCC radiation exposure limits set forth for

an uncontrolled environment. This device should be installed and operated

with a minimum distance of 20 centimeters between the radiator and your

body.

Declaration of Conformity

Trade Name: Hisense

Model: 100L5G/120L5G

Responsible Party: Hisense USA Corporation

Address: 7310 McGinnis Ferry Road, Suwanee, GA 30024

Telephone Number: 678-318-9060

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Dolby, Dolby Atmos, and the double-D symbol are registered trademarks of

Dolby Laboratories Licensing Corporation. Manufactured under license from

Dolby Laboratories. Confidential unpublished works. Copyright © 2012–2021

Dolby Laboratories. All rights reserved.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI

Logo are trademarks or registered trademarks of HDMI Licensing Administrator,

Inc. in the United States and other countries.

For DTS patents, see http://patents.dts.com. Manufactured under license

from DTS Licensing Limited. DTS, DTS-HD Master Audio, DTS-HD,

Virtual:X, and the DTS-HD logo are registered trademarks or trademarks

of DTS, Inc. in the United States and other countries. © 2020 DTS, Inc.

ALL RIGHTS RESERVED.

©2021. All rights reserved. Hisense and the Hisense logo are

registered trademarks of Hisense. Other brand and product names

are registered trademarks of their respective owners.

23

ES-L212114-1
