Hip Street HS-10DTB2 Operating Instructions

HS-10DTB2-4GB

User Manual

June 2012

Please read this user’s manual carefully before use.

CONGRATULATIONS!

Thank you for your purchase of this Hip Street product and we hope you enjoy using
it. Please visit our website at
Please ensure that you fully read and understand the information within this user
manual prior to using your product. It is advised that you keep this user manual in a
safe place for future reference. We sincerely hope that this high quality produc t offers
you endless hours of entertainment.

Important saf et y precautions

• Always follow these basic safety precautions when using the unit.

This will reduce the risk of product damage and personal injury.

• Do not disassem ble, repair or modify the unit by yourself. Refer servicing to

qualified per so nnel.

• Do not dispose of the unit in extreme heat to avoid explosion.

• Keep the unit away from direct sunli ght or heat source.

• Do not expose the unit to ra in or moisture to avoid any malfunction.

www.hipstreet.com.

• Do not use the unit in a rather dry environment to avoid static.

• Never apply heavy impact on the unit like droppi ng it or placi ng it on a

magnet.

• Clean only with a dry cloth. Make sure the unit is turned off before cleaning.

Do not use liquid cleanser.

FCC WARNING:

This device complies with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules and the Canadian ICES-003. Operation is subject to the following
conditions:

- This device may not cause harmful interference, and

- This device must accept any interference received, including interference that

may cause undesired ope ration.

Chapter One – Overview

1-1 Appearance

1-2 Buttons/Ports

1. Power Button 7. 5V DC Jack

2. 3.5mm Headphone Jack 8. Micro-SD Port

3. Mini-HDMI Port

4. Micro-USB PC Port 10. Back Button

5. Micro-USB HOST Port 11. Volume Down Button

6. Reset 12. Volume Up Button

13. Speaker

9. Camera

1-3 Power ON/OFF and Sleep/Wake mode

Power ON

Long press the power button for about 3-4 seconds to power ON the tablet.

Power OFF (Shut down)

Long press the power button for about 3-4 seconds, press OK when prompted to shut down.

1-4 Standby Mode

Standby

Short press the power button to standby the tablet when the tablet is powered ON.

Wake up

Short press the power button to wake the screen up when the tablet is powered ON and in standby
mode.

1-5 Lock and Unlock the Screen

Lock

The system will automatically lock the screen and enter the standby mode if there is no activity
from the user. Preset sleep time designated by user. You can set up the sleep time in the system
settings under <display>.

Unlock

Drag to the right to unlock, shown below.
Drag to the left to enter the Camera/Video mode from the lock screen.

Once the tablet unlocked, the Home Screen will appear.
