HIOTH TECHNOLOGY CO., LTD. USER MANUAL
www.HiotH.com
Door/Window Detector
Introduction
Door/Window Detector is used to detect the door, window or drawer whether is illegally opened
or moved. As the first line of defense of smart home security, the door/window detector can be
divided into the door switch, door sensor and door alarm.
This wireless detector is with power-saving design; when the door is closed, it does not emit radio
signals and the power consumption is only a few microamperes. When the door is opened, immediately fired about 1 second wireless alarm signal, and then stop on their own, even if the door has
been opened will not be transmitting signals.
Technical Information
Solar powered without external power supply;
Achieve linkage, scene and other functions under HiotH system;
Easy installation and long service life.
CT-SMEO2001-ID
HIOTH TECHNOLOGY CO., LTD. USER MANUAL
www.HiotH.com
Specification
1. Wireless protocol: EnOcean 868.3MHz
2. Data rate/Modulation type: 125kbps/ASK
3. Power supply: Wireless passive, Solar energy or use CR1216 battery
(CR1216 battery, about 5 years in total, for dark area usage)
4. Initial operation time in darkness: About 6 days, at least 90 hours
(In the condition of 25 ℃, full powered and no external battery charged)
5. Solar storage time: about 2.5 minutes from exhausted status
(Under 400lux / 25 ℃ incandescent or fluorescent lamp)
6. Operating temperature: 0～40℃
7. Operating range: 30m
8. Dimension: 80mm×26mm×18mm
Operation
NETWORK ENTRY
1) Please follow the below menu order on APP to find the network join interface:
Log in > Menu bar > Device Management > Add device
1） Choose "Enocean" and the corresponding gateway as well as enter the device ID on APP,
then click "";
HIOTH TECHNOLOGY CO., LTD. USER MANUAL
www.HiotH.com
2) Open the rear lid, press the pairing button on the back in 8 seconds.
2） Refresh the device list after prompting "Add device successfully", the device will be dis-
played.
Installation Instruction
This EnOcean wireless detector can be directly powered by solar energy as well as installed a
CR1216 battery. If you want to secure it in one place, simply paste the double-sided adhesive in
the back and attach it to the door or window. On the other hand, you can also remove the door to
re-paste in the future if necessary.
INSTALLATION
Paste
GUIDE
Pay attention to the following situations before installation, so as to prevent the abnormalities.
Do not place it:
Pairing Button
In easily damaged locations
In a stable place
Nearby magnetic objects
HIOTH TECHNOLOGY CO., LTD. USER MANUAL
www.HiotH.com
Safety Notice
Do not place the device to work in the metal container, in case the signal is blocked.
Keep the device away from acid-base and corrosive solids, liquids, gases, to avoid damage.
Avoid overexertion during operation, to protect device from mechanical damage.
Pay attention to the using range.
