HIMS LifeStyle HD740 User Manual
LifeStyle HD
1
Table of Contents
1. What is the LifeStyle HD? ....................................................................... 3
2. Safety Precautions .................................................................................. 4
3. Package .................................................................................................... 5
4. Overview of LifeStyle HD ........................................................................ 6
1) Front side ...................................................................................... 6
2) Rear side ........................................................................................ 7
5. How to install ........................................................................................... 8
5.1 Connect the Power cable ................................................................ 8
6. Using the Front Controller ...................................................................... 9
6.1 Composition of the button .............................................................. 9
1) Front side ...................................................................................... 9
2) Left and bottom side .................................................................. 10
6.2 Description of front controller buttons ........................................ 11
1) Power button ............................................................................... 11
2) Zoom in/out button ..................................................................... 11
3) Color mode buttons .................................................................... 12
4) Contrast Slide-switch ................................................................. 12
5) Switching PC/CCTV button ........................................................ 13
6) Marker button .............................................................................. 13
7) Moving marker buttons .............................................................. 14
7. Use the basic features .......................................................................... 15
1) Before using the feature ............................................................ 15
2) Power on/off ................................................................................ 15
3) Adjusting the magnification ...................................................... 15
4) Changing the color mode .......................................................... 16
5) Adjusting the Contrast ............................................................... 16
6) Using the Marker ......................................................................... 17
8. Using the advanced feature .................................................................. 20
1) Selecting the various color modes ........................................... 20
LifeStyle HD
2
2) Switching PICTURE/TEXT Mode ............................................... 23
3) Using a PC with LifeStyle HD .................................................... 23
4) Using the Focus Lock ................................................................ 24
5) Adjusting the transparency of Window Marker ....................... 25
6) Initialization ................................................................................. 26
9. Using the Reading table ........................................................................ 27
1) Moving the Reading table .......................................................... 27
2) Lock/Unlock the Reading table ................................................. 27
10. Light on/off ........................................................................................... 28
11. Troubleshooting .................................................................................. 29
1) [NO SIGLAL] Display on the screen while switching to PC
screen .............................................................................................. 29
2) The image on the screen is not clear ........................................ 29
3) Cannot execute the mode setup in color mode ....................... 29
12. Technical Specifications of the LifeStyle HD .................................... 30
13. Warranty ............................................................................................... 31
LifeStyle HD
3
ZOOM
CONTRAS
T
COLOR
1. What is the LifeStyle HD?
Thanks for purchasing LifeStyle HD. The LifeStyle HD is an electronic
magnifier for low vision and the elderly to read books, manuals, grocery
information with the large screen monitor.
In LifeStyle HD, you can change magnification level for your convenience
depending on the size of text.
In LifeStyle HD provides you with the various color modes. You can select
the color that best matches your needs.
In LifeStyle HD, you can adjust the contrast to see the image clearly
irrespective of the material being viewed.
LifeStyle HD
4
2. Safety Precautions
※To protect both yourself and the equipment, observe the following
precautions.
※Please read the following the safety precaution carefully before using the
LifeStyle HD.
1) Do not use damaged power plug or unsuitable outlet to prevent
electronic shock or fire.
2) Do not touch power plug with wet hands to prevent electronic shock.
3) Do not disassemble, remodeling or repair by unauthorized person. It
may damage the unit and void the product warranty.
4) Install the unit in flat and stable place. Put on a table enough to bear the
unit’s weight.
5) Do not pull down monitor too aggressively. It can cause the monitor to
fall down, and it can bear a serious damage.
6) Do not press down the Reading table firmly when moved toward you.
The unit may fall down.
7) Do not disconnect the Controller cable when the power is on. It may
damage to the unit.
8) Do not use this unit in moisture environment or high temperature such as
over 40 degree, 40 to prevent any damage.
LifeStyle HD
5
3. Package
The LifeStyle HD consists of the following items.
LifeStyle HD
User manual
DVI-D cable
Power cable
LifeStyle HD
6
4. Overview of LifeStyle HD
1) Front side
(1) LCD monitor
(2) Front controller
(3) Camera
(4) Lock Switch of Reading table
(5) Reading table
(6) Camera module
(7) Monitor arm
(1)
(2)
(3)
(4)
(7)
(6)
(5)
LifeStyle HD
7
2) Rear side
(8) DVI-D input port
(9) AC Power port
(8)
(9)
LifeStyle HD
8
5. How to install
5.1 Connect the Power cable
You can make the LifeStyle HD ready to be used simply by connecting the
power cable to the AC Power port.
LifeStyle HD
9
6. Using the Front Controller
6.1 Composition of the button
The buttons of front controller are located in the front, bottom and left side.
1) Front side
Buttons in the front side consist of as follows.
<Buttons of front side>
1- Color mode buttons
Left: Previous color button
Right: Next color button
2- Zoom in/out buttons
Up (+): Zoom in button
Down (-): Zoom out button
3- Power button
4- Power LED
