Hiland GSF-PR-PC User Manual

OUTDOOR
FIRE PIT

MODEL #GSF-PR-PC

Precaution!

The Powder Coating paint process has become the most
common widely used application in the outdoor furniture
category. Unfortunately powder coating is extremely
sensitive to Humidity and Moisture. A simple process to

R

R

R

C

US

protect your furniture, especially flat surfaces is to apply a
simple coat of good quality car wax prior to using. If this
process is done every few months it will protect your
furniture for years to come.

ANSI Z21.97-2014/CSA 2.41-2014 Outdoor decorative gas appliances

Questions, problems, missing parts? Before returning to your retailer, call our customer

service department at 1-888-775-1330, 7 a.m. - 4 p.m., PST, Monday - Friday.

1

HOW TO REMOVE OXIDATION

Rub the surface with automotive rubbing or polishing compound to abrade away oxidation.

1. Apply a coat of automotive paste wax to the surface.

2. Allow the wax to dry for a few minutes.

3. Remove residue and polish surface with a clean cloth.

Oxidation can be a problem on metal painted surfaces, since the outermost layers of paint are
constantly exposed to air and water. If the outer finish is not protected by a wax coating or
polyurethane,the oxygen molecules in the air will eventually start interacting with the paint.

As the oxygen burns up the free radicals contained in the paint, the finish becomes duller and duller.
Restoration efforts may include removing a layer of affected paint and reapplying a new layer of
protectant. This is why professional detailers recommend at least one layer of wax or other
protectant be used every time the metal surface is washed.

The secret to preventing oxidation caused by oxygen is to provide a layer of protection between the
exposed material and the air. This could mean a wax or polyurethane coating similar to a car, a layer
of paint on metal objects or a quick spray of an anti-oxidant, like lemon juice, on exposed fruit.
Destructive oxidation cannot occur if the oxygen cannot penetrate a surface to reach the free radicals
it craves.

The Powder Coating paint process has become the most common widely used application in the
outdoor furniture category. Unfortunately powder coating is extremely sensitive to Humidity and
Moisture. A simple process to protect your furniture, especially flat surfaces is to apply a simple
coat of good quality car wax prior using. If this process is done every few months it will protect your
furniture for years to come.

Powder coating is a type of coating that is applied as a free-flowing, dry powder. The main difference
between a conventional liquid paint and a powder coating is that the powder coating does not require
a solvent to keep the binder and filler parts in a liquid suspension form. The coating is typically applied
electrostatically and is then cured under heat to allow it to flow and form a "skin". The powder may be
a thermoplastic or a thermoset polymer. It is usually used to create a hard finish that is tougher
than conventional paint. Powder coating is mainly used for coating of metals, such as household
appliances, aluminium extrusions, drum hardware, and automobile and bicycle parts.

2

PACKAGE CONTENTS

A

B

C

D

E

F

G

H

I

J

K

L

M

N

NOITPIRCSED TRAP QUANTITY

A
B 1
C 1
D 1
E
F 1

G

H 1

I

J
K
L

M
N

Knob

Lid
Table

Side Panel (Right)
Back Panel

Gas Cylinder Block Belt
Side Panel (Left)
Bottom plate

Glass (One Pack)

Front top plate

Burner Assembly

Control Knob

Door Panel

Door Handle

3

1

1

1

1
1
1

1
1
1

HARDWARE CONTENTS

DANGER

DANGER

DANGER

AA

BB

CC

DD

EE

N

A

Philips
screwdriver

Qty. 1

M4 X 5
Screw

Qty. 3

M4 X 8
Screw

Qty. 2

M6 X 12
Screw

Qty. 8

M5 X 8
Screw

Qty. 4

Door Handle

Qty. 1

Knob

Qty. 1

SAFETY INFORMATION

Please read and understand this entire manual before attempting to assemble, operate or install
the product. If you have any questions regarding the product, please call customer service at

1-888-775-1330, 7 a.m. - 4 p.m., PST, Monday - Friday.

This appliance has been tested to and complies with the ANSI Z21.97-2014/CSA 2.41-2014
Outdoor decorative gas appliances. The installation must conform to local codes or the absence
of local codes to the National Fuel Gas Code. ANS Z223.1.This manual contains important

information about the assembly, operation and maintenance of this fire pit. General safety information
is presented in these first few pages and is also located throughout the manual. Keep this manual for
future reference and to educate new users of this product. This manual should be read in conjunction
with the labeling on the product. Safety precautions are essential when any mechanical or propane
fueled equipment is involved. These precautions are necessary when using, storing, and servicing.
Using this equipment with the respect and caution demanded will reduce the possibilities of personal
injury or property damage. The following symbols shown below are used extensively throughout this
manual. Always heed these precautions, as they are essential when using any mechanical or fueled
equipment.

DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.

Failure to comply with the precautions and instructions
provided with this fire pit can result in death, serious
bodily injury and property loss or damage from
hazards of fire, explosion, burn, asphyxiation, and/or
carbon monoxide poisoning. Only persons who can
understand and follow the instructions should use or
service this fire pit.

FOR YOUR SAFETY
If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flame.

3. If odor continues, keep away from the appliance and
immediately call you gas supplier or fire department.

Solid fuels shall not be burned in this appliance.

4

SAFETY INFORMATION

DANGER

WARNING

DANGER

WARNING

WARNING

DANGER

WARNING

• EXPLOSION - FIRE HAZARD

• Keep solid combustibles, such as building materials,
paper or cardboard, a safe distance away from the
fire pit as recommended by the instructions.

• Provide adequate clearances around air openings
into the combustion chamber.

• Never use the fire pit in spaces which do or may
contain volatile or airborne combustibles, or products
such as gasoline, solvents, paint thinner, dust particles
or unknown chemicals.

• During operation, this product can be a source of
ignition. Keep fire pit area clear and free from
combustible materials, gasoline, paint thinner, cleaning
solvents and other flammable vapors and liquids. Do
not use fire pit in areas with high dust content.
Minimum fire pit clearances from combustible
materials: two (2) feet from the sides & two (2) feet
from the rear, 6 feet from ceiling.

• EXPLOSION - FIRE HAZARD

• Never store propane near high heat, open flames,
pilot lights, direct sunlight, other ignition sources or
where temperatures exceed 120 degrees F (49°C).

• Propane vapors are heavier than air and can
accumulate in low places. If you smell gas, leave the
area immediately.

• Never install or remove propane cylinder while fire pit
is lighted, near flame, pilot lights, other ignition sources
or while fire pit is hot to touch.

• This fire pit is red hot during use and can ignite
flammables too close to the burner. Keep flammables
at least 2 feet from sides & 2 feet from rear, 6 feet
from ceiling. Keep gasoline and other flammable liquids
and vapors well away from fire pit.

• Store the propane cylinder outdoors in a well ventilated
space out of reach of children. Never store the propane
cylinder in an enclosed area (house, garage, etc.). If
fire pit is to be stored indoors, disconnect the propane
cylinder for outdoor storage.

We cannot foresee every use which may be made of
our fire pit.
Check with your local fire safety authority if you have
questions about fire pit use.
Other standards govern the use of fuel gases and heat
producing products for specific uses. Your local
authorities can advise you about these.
If no local codes exist, follow National Fuel Gas Code,
ANS Z223.1. In Canada, installation must conform to
local codes. If no local codes exist, follow the current
National standards of CANADA CAN/CGA-B 149.2.

• CARBON MONOXIDE HAZARD

• This fire pit is a combustion appliance. All combustion
appliances produce carbon monoxide (CO) during the
combustion process. This product is designed to produce
extremely minute, non-hazardous amounts of CO if used
and maintained in accordance with all warnings and
instructions. Do not block air flow into or out of the fire pit.

• Carbon Monoxide (CO) poisoning produces flu-like
symptoms, watery eyes, headaches, dizziness, fatigue
and possibly death. You can't see it and you can't
smell it. It's an invisible killer. If these symptoms are
present during operation of this product get fresh air
immediately!

• For outdoor use only.

• Never use inside house, or other unventilated or
enclosed areas.

• This fire pit consumes air (oxygen). Do not use in
unventilated or enclosed areas to avoid endangering
your life.

WARNING indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.

Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.

WARNING: For Outdoor Use Only

DANGER

Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or
death. Read the installation, operation and
maintenance instructions thoroughly before installing
or servicing this equipment.

CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has
no odor. Using it in an enclosed
space can kill you. Never use this
appliance in an enclosed space
such as a camper, tent or home.

5

WARNING

WARNING

WARNING

WARNING

SAFETY INFORMATION

CAUTION

CAUTION

WARNING

California Proposition 65
Combustion by-products produced when using
this product contain chemicals known to the State
of California to cause cancer, birth defects, and
other reproductive harm.

BURN HAZARD

• Never leave fire pit unattended when hot or in use.

• Keep out of reach of children.

Certain materials or items, when stored under the
fire pit, will be subjected to radiant heat and could be
seriously damaged.

SERVICE SAFETY

• Keep all connections and fittings clean. Make sure
propane cylinder valve outlet is clean.

• During set up, check all connections and fittings for
leaks using soapy water. Never use a flame.

• Use as a heating appliance only. Never alter in any
way or use with any device.

CAUTION indicates an imminently hazardous situation
which, if not avoided, may result in minor or moderate
personal injury, or property damage.

• This product is fueled by propane gas. Propane gas
is invisible, odorless, and flammable. An odorant is
normally added to help detect leaks and can be
described as a “rotten egg” smell. The odorant can
fade over time so leaking gas is not always detectable
by smell alone.

• Propane gas is heavier than air and leaking propane
will sink to the lowest level possible. It can ignite by
ignition sources including matches, lighters, sparks or
open flames of any kind many feet away from the
original leak. Use only propane gas set up for vapor
withdrawal.

• Store or use propane gas in compliance with local
ordinances and codes or with ANS/NFPA 58. Turn off
propane when not in use.

• Alert children and adults to the hazards of high surface
temperatures. Stay away from these surfaces to avoid
burning skin or igniting clothing.

• Carefully supervise young children when in the vicinity
of the fire pit.

• Do not hang clothing or any other flammable materials
from the fire pit, or place on or near the fire pit.

• Replace any guard or protective device removed for
servicing the appliance prior to placing back in service.

• Installation and repair should be done by a qualified
service person. The fire pit should be inspected
before use and annually by a qualified service person.
More frequent cleaning may be required as necessary.
It is imperative that the control compartment, burners,
and circulating air passageway of the appliance be
kept clean.

PREPARATION

Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents above. If any part is missing or damaged, do not
attempt to assemble the product. Contact customer service for replacement parts.

Estimated Assembly Time: 60 minutes

Tools Required for Assembly (not included):
Phillips screwdriver w/ medium blade. Leak Detection Solution.

6
