Owner's Manual
OUTDOOR FIRE PIT
Model #F-1201-FPT
service department at 1-888-775-1330, 8 a.m. - 4 p.m. PST, Monday - Friday.
Questions, problems, missing parts?
Before returning product to your retailer, call our customer
R
RR
C
ANS Z21 .97-2010 , Outdoor Decorative Gas Appliances
CGA CR 97-003 Outdoor Gas Fireplaces
US
1
PACKAGE CONTENTS
G
A
F
E
C1
C2
K
B
D
PART DESCRIPTION QUANTITY
A
B
C1
C2
D
E
F
G
H
J
J1
K
L
M
BracketrenruB
renruB
I
Washer,Spring washer nut (8mm) 4
Bolt (6*22), Washer,Spring washernut 20
Latch plate 2
hcnerW
1poTelbaT
1latsedeP
3lenaP ediS
1lenaP ediS
1rooD
1
1
1revoCrenruBelbaevomeR
4)04*8(Stud
1troppusknaTsaG
1hcnerW
1
2
HARDWARE CONTENTS
H
Stud
Qty. 4
J1
(8*40)
I
Washer,
Spring washer nut
(8mm)
Qty. 4
.
M
J
Bolt (6*22), Washer,
Spring washer nut
Qty. 20
L
Wrench,
Qty. 1
Latch plate
Qty.2
Wrench
Qty. 1
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assem ble , operate or install
the product
1-888-775-1330,
. If you have any questions regarding the product , please call customer service at
8 a.m. - 4 p.m., PST , Monday - Friday.
This appliance has been tested to and complies with the ANS Z21.97-2010, Outdoor Decorative
Gas Appliances CGA CR 9 7-00 3 Outdoor Gas Fireplaces. The installation must conform to local
codes or to the National Fuel Gas Code. ANSIZ223.1 .This manual contains important information
about the assembly, operation and maintenance of this fire pit. General
is presented in these first few pages and is also located throughout the manual. Keep
safety information
this
manual for future reference and to educate new users of this product. This manual should be read
in conjunction with the labeling on the product. Safety precautions are essential when any mechanical
or propane fueled
equipment is involved. These precautions are necessary when using, storing, and
servicing. Using this equipment with the respect and caution demanded will reduce the possibilities of
personal injury or property damage. The following symbols shown below are used extensively throughout
this manual. Always heed these precautions, as they are essential when using any mechanical or fueled
equipment.
DANGER
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
DANGER
Failure to comply with the precautions and instructions
provided with this fire pit can result in death, serious
bodily injury and property loss or damage from
hazards of fire, explosion, burn, asphyxiation, and/or
carbon monoxide poisoning. Only persons who can
understand and follow the instructions should use or
service this fire pit.
DANGER
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and
immediately call you gas supplier or fire department.
Solid fuels shall not be burned in this appliance.
3
SAFETY INFORMATION
DANGER
·EXPLOSION - FIRE HAZARD
·Keep solid combustibles, such as building materials,
paper or cardboard, a safe distance away from the
fire pit as recommended by the instructions.
·Provide adequate clearances around air openings
into the combustion chamber.
·Never use the fire pit in spaces which do or may
contain volatile or airborne combustibles, or products
such as gasoline, solvents, paint thinner, dust particles
or unknown chemicals.
·During operation, this product can be a source of
ignition. Keep fire pit area clear and free from
combustible materials, gasoline, paint thinner, cleaning
solvents and other flammable vapors and liquids. Do
not use fire pit in areas with high dust content.
Minimum fire pit clearances from combustible
materials: two (2) feet from the sides
from the rear, six(6) feet from ceiling.
two (2) feet
DANGER
·EXPLOSION - FIRE HAZARD
·Never store propane near high heat, open flames,
pilot lights, direct sunlight, other ignition sources or
where temperatures exceed 120 degrees F (49C).
·Propane vapors are heavier than air and can
accumulate in low places. If you smell gas, leave the
area immediately.
·Never install or remove propane cylinder while fire pit
is lighted, near flame, pilot lights, other ignition sources
or while fire pit is hot to touch.
·This fire pit is red hot during use and can ignite
flammables too close to the burner. Keep flammables
at least 2 feet from sides 2 feet from rear, 6 feet
from ceiling. Keep gasoline and other flammable liquids
and vapors well away from fire pit.
·Store the propane cylinder outdoors in a well ventilated
space out of reach of children. Never store the propane
cylinder in an enclosed area (house, garage, etc.). If
fire pit is to be stored indoors, disconnect the propane
cylinder for outdoor storage.
WARNING
We cannot foresee every use which may be made of
our fire pit.
Check with your local fire safety authority if you have
questions about fire pit use.
Other standards govern the use of fuel gases and heat
producing products for specific uses. Your local
authorities can advise you about these.
If no local codes exist, follow National Fuel Gas Code,
ANSI Z223.1. In Canada, installation must conform to
local codes. If no local codes exist, follow the current
National standards of CANADA CAN/CGA-B 149.2.
DANGER
·CARBON MONOXIDE HAZARD
·This fire pit is a combustion appliance. All combustion
appliances produce carbon monoxide (CO) during the
combustion process. This product is designed to produce
extremely minute, non-hazardous amounts of CO if used
and maintained in accordance with all warnings and
instructions. Do not block air flow into or out of the fire pit.
·Carbon Monoxide (CO) poisoning produces flu-like
symptoms, watery eyes, headaches, dizziness, fatigue
and possibly death. You can't see it and you can't
smell it. It's an invisible killer. If these symptoms are
present during operation of this product get fresh air
immediately!
·For outdoor use only.
·Never use inside house, or other unventilated or
enclosed areas.
·This fire pit consumes air (oxygen). Do not use in
unventilated or enclosed areas to avoid endangering
your life.
WARNING
WARNING indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING: For Outdoor Use Only
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has
no odor. Using it in an enclosed
space can kill you. Never use this
appliance in an enclosed space
such as a camper, tent or home.
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or
death. Read the installation, operation and
maintenance instructions thoroughly before installing
or servicing this equipment.
4
SAFETY INFORMATION
WARNING
California Proposition 65
Combustion by-products produced when using
this product contain chemicals known to the State
of California to cause cancer, birth defects, and
other reproductive harm.
WARNING
BURN HAZARD
·Never leave fire pit unattended when hot or in use.
·Keep out of reach of children.
WARNING
Certain materials or items, when stored under the
fire pit, will be subjected to radiant heat and could be
seriously damaged.
CAUTION
SERVICE SAFETY
·Keep all connections and fittings clean. Make sure
propane cylinder valve outlet is clean.
·During set up, check all connections and fittings for
leaks using soapy water. Never use a flame.
·Use as a heating appliance only. Never alter in any
way or use with any device.
CAUTION
CAUTION indicates an imminently hazardous situation
which, if not avoided, may result in minor or moderate
personal injury, or property damage.
WARNING
·This product is fueled by propane gas. Propane gas
is invisible, odorless, and flammable. An odorant is
normally added to help detect leaks and can be
described as a
fade over time so leaking gas is not always detectable
by smell alone.
·Propane gas is heavier than air and leaking propane
will sink to the lowest level possible. It can ignite by
ignition sources including matches, lighters, sparks or
open flames of any kind many feet away from the
original leak. Use only propane gas set up for vapor
withdrawal.
·Store or use propane gas in compliance with local
ordinances and codes or with ANSI/NFPA 58. Turn off
propane when not in use.
rotten egg smell. The odorant
can
WARNING
·Alert children and adults to the hazards of high surface
temperatures. Stay away from these surfaces to avoid
burning skin or igniting clothing.
·Carefully supervise young children when in the vicinity
of the fire pit.
·Do not hang clothing or any other flammable materials
from the fire pit, or place on or near the fire pit.
·Replace any guard or protective device removed for
servicing the appliance prior to placing back in service.
·Installation and repair should be done by a qualified
service person. The fire pit should be inspected
before use and annually by a qualified service person.
More frequent cleaning may be required as necessary.
It is imperative that the control compartment, burners,
and circulating air passageway of the appliance be
kept clean.
5
OPERATION CHECKLIST
Operation Checklist
For a safe and pleasurable heating experience, perform this check before each use.
Before Operating:
1. I am familiar with entire owner’s manual and understand all precautions noted.
2. All components are properly assembled, intact and operable.
3. No alterations have been made.
4. All gas connections are secure and do not leak.
5. Wind velocity is below 10 mph.
6. Unit will operate at reduced efficiency below 40F
7. Fire pit is outdoors (outside any enclosure).
8. There is adequate fresh air ventilation.Do not use this appliance if any part has been under water.
Immediately call a a qualified service technician to inspect the appliance and to replace any part of
the control system and gas control which has been under water.
9. Fire pit is away from gasoline or other flammable liquids or vapors.
10. Fire pit is away from windows, air intake openings, sprinklers and other water sources.
11. Fire pit is at least 24 in. on rear and at least 24 in. on sides from combustible materials.
12. Fire pit is on a hard and level surface.
13. There are no signs of spider or insect nests.
14. All burner passages are clear.
15. All air circulation passages are clear.
16. Children and adults should be alerted to the hazards of high surface temperatures and should stay
away to avoid burns or clothing ignition.
17. Young children should be carefully supervised when they are in the area of the fire pit.
18. Clothing or other protective material should not be hung from the fire pit, or placed on or near the
fire pit.
19. Any guard or other protective device removed for servicing the fire pit must be replaced prior to
operating the fire pit.
20. Installation and repair should be done by a qualified service person. The fire pit should be inspected
before use and at least annually by a qualified service person.
21. More frequent cleaning may be required as necessary. It is imperative that control compartment,
burner and circulating air passageways of the fire pit be kept clean.
After Operation
1. Gas control is in OFF position.
2. Gas Tank valve is OFF.
3. Disconnect Gas line.
4. After each use, replace cap on tank.
/4.44C
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents above. If any part is missing or damaged, do not
attempt to assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 60 minutes
Tools Required for Assembly (not included):
Phillips screwdriver w/ medium blade. Leak Detection Solution.
6
ASSEMBLY INSTRUCTIONS
1. Fix the Gas Tank Support (K) onto the Pedestal (B).
2. Use Bolt (6*22), Washer,Spring washer &
n
ut
J
to connect and fix the side Panel C1 and C2 onto the
unit.(Refer to the following figures, and DO NOT OVER
TIGHTEN the screws)
Hardware Used
1
2
B
K
C2
C1
C1
C1
Bolt (6*22),
J
Washer,
x 12
Spring washer
& nut
3. Attach the Door(D) to the side panel,using the Latch
plate(J1)
Hardware Used
J1
Latch plate
x 2
3
D
7
ASSEMBLY INSTRUCTIONS
4.Fix the Burner Bracket (E) to the unit using
Bolt (6*22), Washer, Spring washer & nut (J).
Place the Burner (F) on the Burner Bracket (E).
Make sure the switch of the burner is aligned
with the Door.
Hardware Used
Bolt (6*22),
J
Washer,
Spring washer
ut
& n
4
E
x 8
F
5. Fix the Table Top (A) onto the Unit with Stud (8*40) (H),
Washer,Spring washer & nut (8mm)(I).
Hardware Used
Stud
H
(8*40)
Washer,
I
Spring washer
& nut (8mm)
x 4
x 4
5
A
8
ASSEMBLY INSTRUCTIONS
6. Put the Removeable Burner Cover (G) on the burner.
7. Connect hose and regulator to cylinder.
The propane gas and cylinder are sold separately.
Use a standard 20 lb. propane cylinder only.
Use this heater only with a propane vapor withdrawal
supply system. See chapter 5 of the standard for
storage and handling of liquefied petroleum gas,
ANSI/NFPA 58. <our local library or fire department
should have this book.
Storage of an appli ance indoors is permissible only if
the cylinder is disconnected and removed from the
appliance. A cylinder must be stored outdoors in a
well-v entilated area out of the reach of children. A
isconnected cylin der must have dust caps tightly
d
installed and must not be stored in a building, garage or
any other enclosed area. The maximum inlet gas supply
pressure: 250 psi, The minimum inlet gas supply
pressure: 5 psi.
The minimum hourly of 10000 Btu is required input
rating for a heater for automatic operation at ratings less
than full input rating.
The pressure regulator and hose assembly supplied
with the appliance must be used.
The installation must conform with local codes, or in the
absence of local c odes,with national fuel gas code,
ANSI Z223.1/NFPA54 , natural gas and propane
Installation Code, CSA B149.1, or propane storage and
handling code, B149.2.
6
7
Standard 20 lb. tank
9
ASSEMBLY INSTRUCTIONS
A dented, rusted or damaged propane cylinder may be
hazardous and should be checked by your cylinder
supplier. Never u se a propane cylinder with a damaged
valve connection .
The propane cylinder must be constructed and marked
in accordance wit h the specifications for LP gas
cylinders of the U .S. Department of Transportation
(DOT) or the standard for cylinders, spheres and
tubes for transpor tation of dangerous goods and
commission, CAN/CSA-B339.
The cylinder must have a liste d overfillin g prevention
device.
The cylinder must have a connection device compatible
with the connecti on for the appliance.
The cylinder used must include a collar to protect the
cylinder valve .
Never connect an unregulated propane cylinder to the
heater.
Attach regulator t o cylinder. Complete attachment.
Install cylinder .
The propane cylinder must use fixer and nut fixed ,
then tighten them securely.
Do not store a spare LP-gas cylinder under or near this appliance;
Never fill the cylind er beyond 80 percent full;
“Place the dust cap on the cylinder valve outlet whenever the cylinder is not
in use. Only install the type of dust cap on the cylin der valve that is provided with
the cylinder valve. Other type of caps or plugs may result in leakage of propane.”
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE IN TENDED
FOR RESIDENT IAL USE ONLY.
Do not sit or stand on this table .
Keep children away during assembly, as this item contains small parts which can be
swallowed by children.
Do not use indoors or inside any enclosure.
Retain the assembly instructions for future reference.
Installer ? Please leave these instructions with the owner.
10
OPERATION INSTRUCTIONS
Leak Check
WARNING
·Perform all leak tests outdoors.
·Extinguish all open flames.
·NEVER leak test when smoking.
·Do not use the fire pit until all connections have been
leak tested and do not leak.
Hose / Regulator
connection
Regulator / Cylinder
connection
1. Make 2-3 oz. of leak check solution (one part liquid dishwashing detergent and three parts water).
2. Apply several drops of solution where hose attaches to regulator.
3. Apply several drops of solution where regulator connects to cylinder.
4. Make sure all fire pit and light valves are OFF.
5. Turn cylinder valve ON.
If bubbles appear at any connection, there is a leak.
1. Turn cylinder valve OFF.
2. If leak is at hose/regulator connection: tighten connection and perform another leak test. If bubbles
continue appearing, the hose should be returned to the place of purchase.
3. If leak is at regulator/cylinder valve connection: disconnect, reconnect, and perform another leak
check. If you continue to see bubbles after several attempts, cylinder valve is defective and should be
returned to cylinder’s place of purchase.
If NO bubbles appear at any connection, the connections are secure.
NOTE: Whenever gas connections are loosened or removed, you must perform a complete leak test.
Complete installation.
11
OPERATION INSTRUCTIONS
DANGER
·CARBON MONOXIDE HAZARD
·For outdoor use only. Never use inside house, or other
unventilated or enclosed areas. This fire pit consumes air
(oxygen). Do not use in unventilated or enclosed areas to
avoid endangering your life.
Caution:
Do not attempt to operate until you have read and understand all General Safety Information
Very hot while in a operation!
Never lean over the fireplace while in use.
Do not touch tile of spark guard while the fire pit is in
operation, wait until the fire pit has cooled down after use.
Failure to comply with these instructions may result in
serious bodily injury.
WARNING
in this manual and all assembly is complete and leak checks have been performed.
Before Turning Gas Supply ON:
1. Your fire pit was designed and approved for outdoor use only. Do NOT use it inside a building,
garage, or any other enclosed area.
2. Make sure surrounding areas are free of combustible materials, gasoline, and other flammable
vapors or liquids.
3. Ensure that there is no obstruction to air ventilation. Be sure all gas connections are tight and
there are no leaks.
4. Be sure the cylinder cover is clear of debris. Be sure any component removed during assembly
or servicing is replaced and fastened prior to starting.
Before Lighting:
1. Fire pit should be thoroughly inspected before each use, and by a qualified service person at least
annually. If relighting a hot fire pit, always wait at least 5 minutes.
2. Inspect the hose assembly for evidence of excessive abrasion, cuts, or wear. Suspected areas
should be leak tested. If the hose leaks, it must be replaced prior to operation. Only use the
replacement hose assembly specified by manufacturer. The burner must be replaced prior to the
appliance being put into operations if it is evident that the burner is damaged. The replacement burner
should be specified by manufacturer.
Lighting:
1) Turn the control knob to the “OFF”position (Figure A).
2) Fully open LP cylinder valve.
Note: For initial start or after any cylinder change, hold Control Knob IN for
2 minutes to purge air from gas lines before proceeding.
3) Push in gas control knob and turn counterclockwise to “IGNITE”
(Figure B) to light the fire pit. If needed, keep depressing and turning control knob
counterclockwise until the heater lights (You should hear a clicking sound).
4) After fire pit lights, release control knob. Push in and turn the control knob counterclockwise to
the “HIGH” Position, then
release control knob. If you want a lower temperature, push in the control knob and turn
counterclockwise to the “LOW” (Figure C).Position
Note: If burner fails to remain lit, all valves should be closed and a waiting period of at least 5
minutes should pass before attempting to light.
F
F
O
E
T
I
N
G
I
H
G
I
H
Figure A
F
F
O
E
P
u
s
h
t
o
t
u
r
n
LOW
T
I
N
G
I
H
G
I
H
P
u
s
h
t
o
t
u
H
r
G
n
I
H
W
LO
Figure B
F
F
O
E
T
I
N
G
I
Figure C
P
u
s
h
t
o
t
u
r
n
W
LO
in.
in.
in.
in.
in.
in.
Normal Abnormal
12
OPERATION INSTRUCTIONS
WARNING
FOR YOUR SAFETY
Be careful when attempting to manually ignite this
fire pit. Holding in the control know for more than 10
seconds before igniting the gas will cause a ball of
flame upon ignition.
When fire pit is ON:
Burner will display tongues of blue and yellow flame. These flames should not be yellow or produce thick
black smoke, which would indicate an obstruction of airflow through the burners. The flame should be
blue with straight yellow tops. If excessive yellow flame is detected, turn off heater and consult
“Troubleshooting”on page 15.
Re-lighting:
1. Turn control knob to OFF.
2. Repeat the “Lighting” steps on prior page.
WARNING
FOR YOUR SAFETY
Fire pit will be hot after use. Handle with extreme care.
Shut Down:
1. To extinguish burner depress control knob and continue to turn it clockwise to OFF.
2. Turn cylinder valve clockwise to OFF and disconnect regulator when heater is not in use.
CARE AND MAINTENANCE
WARNING
FOR YOUR SAFETY:
·Do NOT touch or move fire pit for at least 45
minutesafter use.
·Fire Pit is hot to the touch.
·Allow Fire Pit to cool before touching.
To enjoy years of outstanding performance from your fire pit, make sure you perform the following
maintenance activities on a regular basis:
Keep exterior surfaces clean.
1. Use warm soapy water for cleaning. Never use flammable or corrosive cleaning agents.
2. While cleaning your unit, be sure to keep the area around the burner dry at all times. Do not submerge
the control valve assembly. If the gas control is submerged in water, do NOT use it. It must be replaced.
a. Keep the appliance area clear and free from combustible materials, gasoline and other
flammable vapors and liquids.
b. Do not obstruct the flow of combustion and ventilation air.
c. Keep the ventilation opening(s) of the cylinder enclosure free and clear from debris.
3. Air flow must be unobstructed. Keep controls, burner, and circulating air passageways clean. Signs
of possible blockage include:
13
CARE AND MAINTENANCE
Gas odor with extreme yellow tipping of flame.
Fire pit does NOT reach the desired temperature.
Fire pit glow is excessively uneven.
Fire pit makes popping noises.
Spiders and insects can nest in burner or orifices. This dangerous condition can damage fire pit and
render it unsafe for use. Clean burner holes by using a heavy-duty pipe cleaner. Compressed air may
help clear away smaller particles.
Carbon deposits may create a fire hazard. Clean dome and burner screen with warm soapy water if
any carbon deposits develop.
Note: In a salt-air environment (such as near an ocean), corrosion occurs more quickly than normal.
Frequently check for corroded areas and repair them promptly.
TIP:
Use high-quality automobile wax to help maintain the appearance of
your fire pit. Apply to exterior surfaces from the pole down. Do not
apply to emitter screen or domes.
Storage
Between uses:
Turn Control Knob OFF.
Disconnect LP source.
Store fire pit upright in an area sheltered from direct contact with inclement weather (such as rain,
sleet, hail, snow, dust and debris).
If desired, cover fire pit to protect exterior surfaces and to help prevent build-up in air passages.
Note: Wait until fire pit is cool before covering.
During periods of extended inactivity or when transporting:
Turn Control Knob OFF.
Disconnect LP source and move to a secure, well-ventilated location outdoors.
Store fire pit upright in an area sheltered from direct contact with inclement weather (such as rain,
sleet, hail, snow, dust and debris).
If desired, cover fire pit to protect exterior surfaces and to help prevent build-up in air passages.
Never leave LP cylinder exposed to direct sunlight or excessive heat.
Note: Wait until fire pit is cool before covering.
Make sure to properly locate the gas hose by keeping it out of pathways where people may
trip over it or in an area where the hose may be subject to accidental damage. Always
inspect the hose for evidence of excessive abrasion, cuts or wear prior to use, and make
sure to leak test.
Service
Only a qualified service person should repair gas passages and associated components.
Caution: Always allow fire pit to cool before attempting service.
14
TROUBLESHOOTING
NOITCAEVITCERROCESUAC ELBISSOPMELBORP
Burner won’t light
Burner flame is low
Carbon build-up
Thick black smoke
Propane cylinder is empty
Blockage in orifice
Control knob is not in ON position
Gas pressure is low
Outdoor temperature is less than 40F and
tank is less than 1/4 full
Control knob fully ON
Dirt or film on reflector and burner screen
Blockage in burner
Replace propane cylinder
Clear blockage
Turn control knob to ON
Turn cylinder valve OFF and fill the
cylinder
Use a full cylinder
Check burner and orifices for
blockage
Clean reflector and burner screen
Remove blockage and clean burner
inside and outside
15
ONE-YEAR LIMITED WARRANTY
CUSTOMERS IN USA
Do not return this product to the store where you purchased it. Please call 1-888-775-1330
for assistance.
IMPORTANT
This product is inspected, tested and carefully packaged to minimize the chance of damage
during shipment. If a part (excluding light bulbs and fuses*) within one year from the date of
purchase proves to be defective in material or fabrication under normal use, the part will be
repaired or replaced. The Company's obligation under the warranty is to replace or repair
defective parts at our discretion. Any expenses or damage resulting from the installation,
removal or transportation of the product will the responsibility of the owner and are not
covered by this warranty. The owner assumes all other risks arising out from the use or
misuse of the product. The warranty will be void if the product damage or failure is deemed
by the Company to be caused by accident, alteration, misuse, abuse, incorrect installation or
removal, or connection to an incorrect power source by the owner. The Company neither
assumes, nor authorizes any person or entity to assume for it any obligation or liability
associated with its products.
* Light bulbs and fuses are not covered under this warranty.
* We are also not responsible if there is damaged cause by the weather or salt water elements
if the customer does not protect it as specified in the owners manual.
If you have any questions regarding the warranty or service, please call our toll
free number:
1-888-775-1330.
AZ PATIO HEATERS
8550 N 91 AVE, SUITE C-25
PEORIA, AZ 85345
www.azpatioheaters.com
21
